Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAyNC0wNC0xMiswNSUzQTE4JTNBMTYuMzYxNjEzJTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDI0LTA0LTEyKzA1JTNBMTglM0E0NC43OTYzNzYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAyNC0wNC0xMiswNyUzQTMzJTNBMzAuOTEyMjM4JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2024-04-12T07:33:30.912238Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jeonyl/13.embed", "fid": "jeonyl:13", "filename": "Relaxation_voltage_after_charging.png", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jeonyl:13/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jeonyl:13/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jeonyl:13/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jeonyl:13/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jeonyl:13", "plots": "https://api.plotly.com/v2/plots/jeonyl:13", "parent": "https://api.plotly.com/v2/folders/home?user=jeonyl" }, "owner": "jeonyl", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~jeonyl/13/", "world_readable": true, "date_modified": "2024-04-12T08:06:22.470Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jeonyl/13/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "59", "type": "scatter", "xsrc": "jeonyl:12:825488", "ysrc": "jeonyl:12:cefec6", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "58", "type": "scatter", "xsrc": "jeonyl:12:90e348", "ysrc": "jeonyl:12:98d4da", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "57", "type": "scatter", "xsrc": "jeonyl:12:974916", "ysrc": "jeonyl:12:c9b3a5", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "56", "type": "scatter", "xsrc": "jeonyl:12:ad7b99", "ysrc": "jeonyl:12:91098f", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "55", "type": "scatter", "xsrc": "jeonyl:12:ffcdeb", "ysrc": "jeonyl:12:eaeb6b", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "54", "type": "scatter", "xsrc": "jeonyl:12:6bd74d", "ysrc": "jeonyl:12:323c47", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "53", "type": "scatter", "xsrc": "jeonyl:12:8eefc6", "ysrc": "jeonyl:12:25d7a0", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "52", "type": "scatter", "xsrc": "jeonyl:12:a7af5f", "ysrc": "jeonyl:12:bab3a9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "51", "type": "scatter", "xsrc": "jeonyl:12:6a2076", "ysrc": "jeonyl:12:e5e491", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "50", "type": "scatter", "xsrc": "jeonyl:12:a4ba39", "ysrc": "jeonyl:12:4adbe4", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "49", "type": "scatter", "xsrc": "jeonyl:12:d9f1c3", "ysrc": "jeonyl:12:ebd3b9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "48", "type": "scatter", "xsrc": "jeonyl:12:844319", "ysrc": "jeonyl:12:fb3575", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "47", "type": "scatter", "xsrc": "jeonyl:12:c1fd78", "ysrc": "jeonyl:12:06e843", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "46", "type": "scatter", "xsrc": "jeonyl:12:df6023", "ysrc": "jeonyl:12:ca943b", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "45", "type": "scatter", "xsrc": "jeonyl:12:a7a145", "ysrc": "jeonyl:12:033eb0", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "44", "type": "scatter", "xsrc": "jeonyl:12:f5c471", "ysrc": "jeonyl:12:8223fe", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "43", "type": "scatter", "xsrc": "jeonyl:12:982a58", "ysrc": "jeonyl:12:eb54e9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "42", "type": "scatter", "xsrc": "jeonyl:12:04acca", "ysrc": "jeonyl:12:fa3ea2", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "41", "type": "scatter", "xsrc": "jeonyl:12:f3f695", "ysrc": "jeonyl:12:4d52da", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "40", "type": "scatter", "xsrc": "jeonyl:12:ca5491", "ysrc": "jeonyl:12:3667f7", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "39", "type": "scatter", "xsrc": "jeonyl:12:10a4ec", "ysrc": "jeonyl:12:00459e", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "38", "type": "scatter", "xsrc": "jeonyl:12:3c37b7", "ysrc": "jeonyl:12:d271c2", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "37", "type": "scatter", "xsrc": "jeonyl:12:759ebf", "ysrc": "jeonyl:12:c353c6", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "36", "type": "scatter", "xsrc": "jeonyl:12:d371ac", "ysrc": "jeonyl:12:8ae720", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "35", "type": "scatter", "xsrc": "jeonyl:12:f64154", "ysrc": "jeonyl:12:ca2e66", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "34", "type": "scatter", "xsrc": "jeonyl:12:ecc5ac", "ysrc": "jeonyl:12:d4edae", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "33", "type": "scatter", "xsrc": "jeonyl:12:16d356", "ysrc": "jeonyl:12:7d6a49", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "32", "type": "scatter", "xsrc": "jeonyl:12:01fd8c", "ysrc": "jeonyl:12:047b10", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "31", "type": "scatter", "xsrc": "jeonyl:12:484330", "ysrc": "jeonyl:12:5621e1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "30", "type": "scatter", "xsrc": "jeonyl:12:1180d8", "ysrc": "jeonyl:12:186ecd", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "29", "type": "scatter", "xsrc": "jeonyl:12:c96281", "ysrc": "jeonyl:12:6ed786", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "28", "type": "scatter", "xsrc": "jeonyl:12:378ca3", "ysrc": "jeonyl:12:ddfebc", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "27", "type": "scatter", "xsrc": "jeonyl:12:c41c1e", "ysrc": "jeonyl:12:82b376", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "26", "type": "scatter", "xsrc": "jeonyl:12:b2bcda", "ysrc": "jeonyl:12:1d65b0", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "25", "type": "scatter", "xsrc": "jeonyl:12:67c3aa", "ysrc": "jeonyl:12:fdc1eb", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "24", "type": "scatter", "xsrc": "jeonyl:12:4ac6e4", "ysrc": "jeonyl:12:47c7a4", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "23", "type": "scatter", "xsrc": "jeonyl:12:addb8a", "ysrc": "jeonyl:12:8f3ba3", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "22", "type": "scatter", "xsrc": "jeonyl:12:e9a745", "ysrc": "jeonyl:12:870f7e", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "21", "type": "scatter", "xsrc": "jeonyl:12:a1b454", "ysrc": "jeonyl:12:4fc10e", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "20", "type": "scatter", "xsrc": "jeonyl:12:067f03", "ysrc": "jeonyl:12:904387", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "19", "type": "scatter", "xsrc": "jeonyl:12:eb5063", "ysrc": "jeonyl:12:25589f", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "18", "type": "scatter", "xsrc": "jeonyl:12:43e83f", "ysrc": "jeonyl:12:4ec6c7", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "17", "type": "scatter", "xsrc": "jeonyl:12:f77b18", "ysrc": "jeonyl:12:acede7", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "16", "type": "scatter", "xsrc": "jeonyl:12:0949f9", "ysrc": "jeonyl:12:d910a5", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "15", "type": "scatter", "xsrc": "jeonyl:12:584335", "ysrc": "jeonyl:12:44c1d8", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "14", "type": "scatter", "xsrc": "jeonyl:12:285814", "ysrc": "jeonyl:12:9f2348", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "13", "type": "scatter", "xsrc": "jeonyl:12:abbe79", "ysrc": "jeonyl:12:925e91", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "12", "type": "scatter", "xsrc": "jeonyl:12:4363dc", "ysrc": "jeonyl:12:bfa8d1", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "11", "type": "scatter", "xsrc": "jeonyl:12:cb1aac", "ysrc": "jeonyl:12:2b56cc", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "10", "type": "scatter", "xsrc": "jeonyl:12:3c0a27", "ysrc": "jeonyl:12:80c28c", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "9", "type": "scatter", "xsrc": "jeonyl:12:e3f676", "ysrc": "jeonyl:12:399397", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "8", "type": "scatter", "xsrc": "jeonyl:12:13f226", "ysrc": "jeonyl:12:5d2c44", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "7", "type": "scatter", "xsrc": "jeonyl:12:f59732", "ysrc": "jeonyl:12:f6ba46", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "6", "type": "scatter", "xsrc": "jeonyl:12:7c81fa", "ysrc": "jeonyl:12:b85711", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "5", "type": "scatter", "xsrc": "jeonyl:12:79d9b9", "ysrc": "jeonyl:12:fc4cc0", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "4", "type": "scatter", "xsrc": "jeonyl:12:791588", "ysrc": "jeonyl:12:b4478a", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "3", "type": "scatter", "xsrc": "jeonyl:12:93d6c7", "ysrc": "jeonyl:12:366a86", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "2", "type": "scatter", "xsrc": "jeonyl:12:208854", "ysrc": "jeonyl:12:36bf13", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "1", "type": "scatter", "xsrc": "jeonyl:12:640b3a", "ysrc": "jeonyl:12:ea014f", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "59", "type": "scatter", "xsrc": "jeonyl:12:bc830a", "ysrc": "jeonyl:12:41a279", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "58", "type": "scatter", "xsrc": "jeonyl:12:645aee", "ysrc": "jeonyl:12:5fc488", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "57", "type": "scatter", "xsrc": "jeonyl:12:74c494", "ysrc": "jeonyl:12:81bbdd", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "56", "type": "scatter", "xsrc": "jeonyl:12:ef703e", "ysrc": "jeonyl:12:4b186c", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "55", "type": "scatter", "xsrc": "jeonyl:12:dcbfff", "ysrc": "jeonyl:12:d6c2e6", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "54", "type": "scatter", "xsrc": "jeonyl:12:cd59b8", "ysrc": "jeonyl:12:259210", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "53", "type": "scatter", "xsrc": "jeonyl:12:ca0a86", "ysrc": "jeonyl:12:cc9399", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "52", "type": "scatter", "xsrc": "jeonyl:12:008609", "ysrc": "jeonyl:12:1f6863", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "51", "type": "scatter", "xsrc": "jeonyl:12:ad9b3d", "ysrc": "jeonyl:12:1d0d49", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "50", "type": "scatter", "xsrc": "jeonyl:12:a850cc", "ysrc": "jeonyl:12:16d2a0", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "49", "type": "scatter", "xsrc": "jeonyl:12:1134ec", "ysrc": "jeonyl:12:3c5c56", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "48", "type": "scatter", "xsrc": "jeonyl:12:2b5eca", "ysrc": "jeonyl:12:227205", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "47", "type": "scatter", "xsrc": "jeonyl:12:74c4e7", "ysrc": "jeonyl:12:3ccec8", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "46", "type": "scatter", "xsrc": "jeonyl:12:ea2ace", "ysrc": "jeonyl:12:28aee5", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "45", "type": "scatter", "xsrc": "jeonyl:12:765a07", "ysrc": "jeonyl:12:5be5e7", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "44", "type": "scatter", "xsrc": "jeonyl:12:48e436", "ysrc": "jeonyl:12:a9e2f9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "43", "type": "scatter", "xsrc": "jeonyl:12:69cff5", "ysrc": "jeonyl:12:0c21e0", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "42", "type": "scatter", "xsrc": "jeonyl:12:fcaf1d", "ysrc": "jeonyl:12:ba33c9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "41", "type": "scatter", "xsrc": "jeonyl:12:be1ba4", "ysrc": "jeonyl:12:2ba774", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "40", "type": "scatter", "xsrc": "jeonyl:12:c1a685", "ysrc": "jeonyl:12:f3b283", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "39", "type": "scatter", "xsrc": "jeonyl:12:f02b05", "ysrc": "jeonyl:12:0892d7", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "38", "type": "scatter", "xsrc": "jeonyl:12:1c0721", "ysrc": "jeonyl:12:ca99d1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "37", "type": "scatter", "xsrc": "jeonyl:12:d3e1d3", "ysrc": "jeonyl:12:83ee2f", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "36", "type": "scatter", "xsrc": "jeonyl:12:8b5722", "ysrc": "jeonyl:12:db9657", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "35", "type": "scatter", "xsrc": "jeonyl:12:6df613", "ysrc": "jeonyl:12:e204cc", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "34", "type": "scatter", "xsrc": "jeonyl:12:4b0e36", "ysrc": "jeonyl:12:fb028d", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "33", "type": "scatter", "xsrc": "jeonyl:12:7393b1", "ysrc": "jeonyl:12:db9c69", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "32", "type": "scatter", "xsrc": "jeonyl:12:3f4c1b", "ysrc": "jeonyl:12:d81d78", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "31", "type": "scatter", "xsrc": "jeonyl:12:fea7d6", "ysrc": "jeonyl:12:46eab7", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "30", "type": "scatter", "xsrc": "jeonyl:12:bae8cd", "ysrc": "jeonyl:12:3e01a3", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "29", "type": "scatter", "xsrc": "jeonyl:12:304e1b", "ysrc": "jeonyl:12:ceaae3", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "28", "type": "scatter", "xsrc": "jeonyl:12:cab2e6", "ysrc": "jeonyl:12:2ec1c7", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "27", "type": "scatter", "xsrc": "jeonyl:12:7f8774", "ysrc": "jeonyl:12:ed78b3", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "26", "type": "scatter", "xsrc": "jeonyl:12:2f3aa5", "ysrc": "jeonyl:12:f2579b", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "25", "type": "scatter", "xsrc": "jeonyl:12:fe9344", "ysrc": "jeonyl:12:694a83", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "24", "type": "scatter", "xsrc": "jeonyl:12:752d89", "ysrc": "jeonyl:12:25663a", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "23", "type": "scatter", "xsrc": "jeonyl:12:db619b", "ysrc": "jeonyl:12:ea272c", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "22", "type": "scatter", "xsrc": "jeonyl:12:e8708a", "ysrc": "jeonyl:12:0d5d69", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "21", "type": "scatter", "xsrc": "jeonyl:12:c4e080", "ysrc": "jeonyl:12:b0b84d", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "20", "type": "scatter", "xsrc": "jeonyl:12:ecc944", "ysrc": "jeonyl:12:f6d914", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "19", "type": "scatter", "xsrc": "jeonyl:12:62b638", "ysrc": "jeonyl:12:36114f", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "18", "type": "scatter", "xsrc": "jeonyl:12:24551d", "ysrc": "jeonyl:12:8ece77", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "17", "type": "scatter", "xsrc": "jeonyl:12:412f58", "ysrc": "jeonyl:12:63e9aa", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "16", "type": "scatter", "xsrc": "jeonyl:12:68eb06", "ysrc": "jeonyl:12:a7b7ec", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "15", "type": "scatter", "xsrc": "jeonyl:12:e75459", "ysrc": "jeonyl:12:82f60d", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "14", "type": "scatter", "xsrc": "jeonyl:12:66ef50", "ysrc": "jeonyl:12:1cba8d", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "13", "type": "scatter", "xsrc": "jeonyl:12:8411f9", "ysrc": "jeonyl:12:3bfe0e", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "12", "type": "scatter", "xsrc": "jeonyl:12:9f9451", "ysrc": "jeonyl:12:e1d163", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "11", "type": "scatter", "xsrc": "jeonyl:12:bc7c06", "ysrc": "jeonyl:12:b0f583", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "10", "type": "scatter", "xsrc": "jeonyl:12:8b93d2", "ysrc": "jeonyl:12:255343", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "9", "type": "scatter", "xsrc": "jeonyl:12:a68c8d", "ysrc": "jeonyl:12:6311fd", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "8", "type": "scatter", "xsrc": "jeonyl:12:d859f0", "ysrc": "jeonyl:12:fe5747", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "7", "type": "scatter", "xsrc": "jeonyl:12:cc1364", "ysrc": "jeonyl:12:eb82e9", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "6", "type": "scatter", "xsrc": "jeonyl:12:af1af5", "ysrc": "jeonyl:12:beb034", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "5", "type": "scatter", "xsrc": "jeonyl:12:bb2235", "ysrc": "jeonyl:12:2e0bb3", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "4", "type": "scatter", "xsrc": "jeonyl:12:5e5ce8", "ysrc": "jeonyl:12:e37dbe", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "3", "type": "scatter", "xsrc": "jeonyl:12:276f65", "ysrc": "jeonyl:12:81d978", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "2", "type": "scatter", "xsrc": "jeonyl:12:8ff216", "ysrc": "jeonyl:12:6d4206", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "1", "type": "scatter", "xsrc": "jeonyl:12:163558", "ysrc": "jeonyl:12:d75c05", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "59", "type": "scatter", "xsrc": "jeonyl:12:3db2e1", "ysrc": "jeonyl:12:7df281", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "58", "type": "scatter", "xsrc": "jeonyl:12:d0d82b", "ysrc": "jeonyl:12:f76f68", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "57", "type": "scatter", "xsrc": "jeonyl:12:4c2d75", "ysrc": "jeonyl:12:9a0687", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "56", "type": "scatter", "xsrc": "jeonyl:12:20fd6f", "ysrc": "jeonyl:12:ee7ec1", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "55", "type": "scatter", "xsrc": "jeonyl:12:fa4691", "ysrc": "jeonyl:12:09cd6d", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "54", "type": "scatter", "xsrc": "jeonyl:12:2ad2c1", "ysrc": "jeonyl:12:a9176b", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "53", "type": "scatter", "xsrc": "jeonyl:12:7aff8e", "ysrc": "jeonyl:12:804d86", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "52", "type": "scatter", "xsrc": "jeonyl:12:49123b", "ysrc": "jeonyl:12:872504", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "51", "type": "scatter", "xsrc": "jeonyl:12:de072f", "ysrc": "jeonyl:12:07136a", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "50", "type": "scatter", "xsrc": "jeonyl:12:7df814", "ysrc": "jeonyl:12:459ea1", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "49", "type": "scatter", "xsrc": "jeonyl:12:84c04b", "ysrc": "jeonyl:12:b908aa", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "48", "type": "scatter", "xsrc": "jeonyl:12:3d62cf", "ysrc": "jeonyl:12:5968ef", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "47", "type": "scatter", "xsrc": "jeonyl:12:a109fc", "ysrc": "jeonyl:12:233f4b", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "46", "type": "scatter", "xsrc": "jeonyl:12:dc5332", "ysrc": "jeonyl:12:97afbb", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "45", "type": "scatter", "xsrc": "jeonyl:12:4f1b7e", "ysrc": "jeonyl:12:1c8342", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "44", "type": "scatter", "xsrc": "jeonyl:12:f952d4", "ysrc": "jeonyl:12:64b4e1", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "43", "type": "scatter", "xsrc": "jeonyl:12:04c70b", "ysrc": "jeonyl:12:e250c6", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "42", "type": "scatter", "xsrc": "jeonyl:12:45ba2c", "ysrc": "jeonyl:12:4ec9d9", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "41", "type": "scatter", "xsrc": "jeonyl:12:5f9fc7", "ysrc": "jeonyl:12:27313d", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "40", "type": "scatter", "xsrc": "jeonyl:12:1d4572", "ysrc": "jeonyl:12:696ab6", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "39", "type": "scatter", "xsrc": "jeonyl:12:5c8fb3", "ysrc": "jeonyl:12:9215e6", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "38", "type": "scatter", "xsrc": "jeonyl:12:228fc4", "ysrc": "jeonyl:12:a051b2", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "37", "type": "scatter", "xsrc": "jeonyl:12:cb193f", "ysrc": "jeonyl:12:41d8e1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "36", "type": "scatter", "xsrc": "jeonyl:12:5972bb", "ysrc": "jeonyl:12:fbbe56", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "35", "type": "scatter", "xsrc": "jeonyl:12:641972", "ysrc": "jeonyl:12:45971f", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "34", "type": "scatter", "xsrc": "jeonyl:12:17162e", "ysrc": "jeonyl:12:c1cc84", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "33", "type": "scatter", "xsrc": "jeonyl:12:0f285a", "ysrc": "jeonyl:12:0d9bb1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "32", "type": "scatter", "xsrc": "jeonyl:12:51035d", "ysrc": "jeonyl:12:b27dca", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "31", "type": "scatter", "xsrc": "jeonyl:12:823d80", "ysrc": "jeonyl:12:d1fb21", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "30", "type": "scatter", "xsrc": "jeonyl:12:cf1564", "ysrc": "jeonyl:12:d6b46b", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "29", "type": "scatter", "xsrc": "jeonyl:12:b3f0af", "ysrc": "jeonyl:12:f78edd", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "28", "type": "scatter", "xsrc": "jeonyl:12:5e9f09", "ysrc": "jeonyl:12:9e90ef", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "27", "type": "scatter", "xsrc": "jeonyl:12:49966a", "ysrc": "jeonyl:12:bb4920", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "26", "type": "scatter", "xsrc": "jeonyl:12:d35edf", "ysrc": "jeonyl:12:0677eb", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "25", "type": "scatter", "xsrc": "jeonyl:12:3ddb17", "ysrc": "jeonyl:12:32e546", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "24", "type": "scatter", "xsrc": "jeonyl:12:f5bdcb", "ysrc": "jeonyl:12:a966c7", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "23", "type": "scatter", "xsrc": "jeonyl:12:fdb6ff", "ysrc": "jeonyl:12:16444b", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "22", "type": "scatter", "xsrc": "jeonyl:12:dcbce2", "ysrc": "jeonyl:12:844da5", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "21", "type": "scatter", "xsrc": "jeonyl:12:38d144", "ysrc": "jeonyl:12:c3a593", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "20", "type": "scatter", "xsrc": "jeonyl:12:89f99c", "ysrc": "jeonyl:12:43aedb", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "19", "type": "scatter", "xsrc": "jeonyl:12:7a0470", "ysrc": "jeonyl:12:c68e81", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "18", "type": "scatter", "xsrc": "jeonyl:12:7c29cf", "ysrc": "jeonyl:12:3b3fce", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "17", "type": "scatter", "xsrc": "jeonyl:12:1f7fbe", "ysrc": "jeonyl:12:4717ff", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "16", "type": "scatter", "xsrc": "jeonyl:12:c04adf", "ysrc": "jeonyl:12:01b099", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "15", "type": "scatter", "xsrc": "jeonyl:12:541f2d", "ysrc": "jeonyl:12:2060e8", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "14", "type": "scatter", "xsrc": "jeonyl:12:bc4227", "ysrc": "jeonyl:12:f469da", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "13", "type": "scatter", "xsrc": "jeonyl:12:b8e636", "ysrc": "jeonyl:12:5d71e7", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "12", "type": "scatter", "xsrc": "jeonyl:12:8b587d", "ysrc": "jeonyl:12:6d3846", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "11", "type": "scatter", "xsrc": "jeonyl:12:33d30e", "ysrc": "jeonyl:12:12dc1c", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "10", "type": "scatter", "xsrc": "jeonyl:12:2bd9ce", "ysrc": "jeonyl:12:7310c3", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "9", "type": "scatter", "xsrc": "jeonyl:12:f7df0d", "ysrc": "jeonyl:12:769374", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "8", "type": "scatter", "xsrc": "jeonyl:12:9cc98c", "ysrc": "jeonyl:12:8541ed", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "7", "type": "scatter", "xsrc": "jeonyl:12:b27f9b", "ysrc": "jeonyl:12:228689", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "6", "type": "scatter", "xsrc": "jeonyl:12:b87e5a", "ysrc": "jeonyl:12:81911a", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "5", "type": "scatter", "xsrc": "jeonyl:12:061b12", "ysrc": "jeonyl:12:1ce8dc", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "4", "type": "scatter", "xsrc": "jeonyl:12:4de023", "ysrc": "jeonyl:12:38b1c7", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "3", "type": "scatter", "xsrc": "jeonyl:12:1a920d", "ysrc": "jeonyl:12:51f324", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "2", "type": "scatter", "xsrc": "jeonyl:12:5e2fd4", "ysrc": "jeonyl:12:c3931e", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "1", "type": "scatter", "xsrc": "jeonyl:12:f90d2e", "ysrc": "jeonyl:12:df5b9b", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "49", "type": "scatter", "xsrc": "jeonyl:12:d7655c", "ysrc": "jeonyl:12:3cc6ff", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "48", "type": "scatter", "xsrc": "jeonyl:12:51fcf4", "ysrc": "jeonyl:12:3bf428", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "47", "type": "scatter", "xsrc": "jeonyl:12:526b6b", "ysrc": "jeonyl:12:c2ee65", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "46", "type": "scatter", "xsrc": "jeonyl:12:45df46", "ysrc": "jeonyl:12:d0bff1", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "45", "type": "scatter", "xsrc": "jeonyl:12:94cabc", "ysrc": "jeonyl:12:7f717a", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "44", "type": "scatter", "xsrc": "jeonyl:12:9ad535", "ysrc": "jeonyl:12:5eca6a", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "43", "type": "scatter", "xsrc": "jeonyl:12:0f0b9e", "ysrc": "jeonyl:12:2ff751", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "42", "type": "scatter", "xsrc": "jeonyl:12:872aee", "ysrc": "jeonyl:12:139f70", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "41", "type": "scatter", "xsrc": "jeonyl:12:7f0c4d", "ysrc": "jeonyl:12:bcd666", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "40", "type": "scatter", "xsrc": "jeonyl:12:df8778", "ysrc": "jeonyl:12:832fce", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "39", "type": "scatter", "xsrc": "jeonyl:12:d55024", "ysrc": "jeonyl:12:f7b226", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "38", "type": "scatter", "xsrc": "jeonyl:12:00ff08", "ysrc": "jeonyl:12:b36ef4", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "37", "type": "scatter", "xsrc": "jeonyl:12:c600c6", "ysrc": "jeonyl:12:421447", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "36", "type": "scatter", "xsrc": "jeonyl:12:c7f929", "ysrc": "jeonyl:12:e116d6", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "35", "type": "scatter", "xsrc": "jeonyl:12:707c49", "ysrc": "jeonyl:12:e0e315", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "34", "type": "scatter", "xsrc": "jeonyl:12:957549", "ysrc": "jeonyl:12:c866e5", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "33", "type": "scatter", "xsrc": "jeonyl:12:b48407", "ysrc": "jeonyl:12:574bd1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "32", "type": "scatter", "xsrc": "jeonyl:12:962856", "ysrc": "jeonyl:12:ffb41b", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "31", "type": "scatter", "xsrc": "jeonyl:12:25d505", "ysrc": "jeonyl:12:702d2e", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "30", "type": "scatter", "xsrc": "jeonyl:12:26279d", "ysrc": "jeonyl:12:885e21", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "29", "type": "scatter", "xsrc": "jeonyl:12:5034d5", "ysrc": "jeonyl:12:404257", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "28", "type": "scatter", "xsrc": "jeonyl:12:ff5ae9", "ysrc": "jeonyl:12:d5d6f6", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "27", "type": "scatter", "xsrc": "jeonyl:12:28257b", "ysrc": "jeonyl:12:fd3e28", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "26", "type": "scatter", "xsrc": "jeonyl:12:737ef9", "ysrc": "jeonyl:12:3f8cf6", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "25", "type": "scatter", "xsrc": "jeonyl:12:6d206c", "ysrc": "jeonyl:12:4e2f0f", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "24", "type": "scatter", "xsrc": "jeonyl:12:9a7263", "ysrc": "jeonyl:12:fb56fd", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "23", "type": "scatter", "xsrc": "jeonyl:12:f053ed", "ysrc": "jeonyl:12:302393", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "22", "type": "scatter", "xsrc": "jeonyl:12:f962d9", "ysrc": "jeonyl:12:51968e", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "21", "type": "scatter", "xsrc": "jeonyl:12:f2cb7d", "ysrc": "jeonyl:12:f41676", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "20", "type": "scatter", "xsrc": "jeonyl:12:9b7e34", "ysrc": "jeonyl:12:11fe3c", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "19", "type": "scatter", "xsrc": "jeonyl:12:2ffd0e", "ysrc": "jeonyl:12:b26457", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "18", "type": "scatter", "xsrc": "jeonyl:12:9a9f8a", "ysrc": "jeonyl:12:07c191", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "17", "type": "scatter", "xsrc": "jeonyl:12:c1f8a3", "ysrc": "jeonyl:12:acc1b1", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "16", "type": "scatter", "xsrc": "jeonyl:12:4ff78e", "ysrc": "jeonyl:12:1b74c7", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "15", "type": "scatter", "xsrc": "jeonyl:12:85b675", "ysrc": "jeonyl:12:fd694f", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "14", "type": "scatter", "xsrc": "jeonyl:12:072651", "ysrc": "jeonyl:12:46338a", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "13", "type": "scatter", "xsrc": "jeonyl:12:6ac83e", "ysrc": "jeonyl:12:9d46c4", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "12", "type": "scatter", "xsrc": "jeonyl:12:2f3226", "ysrc": "jeonyl:12:80e196", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "11", "type": "scatter", "xsrc": "jeonyl:12:49a441", "ysrc": "jeonyl:12:a2897e", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "10", "type": "scatter", "xsrc": "jeonyl:12:6af753", "ysrc": "jeonyl:12:d001dd", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "9", "type": "scatter", "xsrc": "jeonyl:12:5ee40c", "ysrc": "jeonyl:12:38aa78", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "8", "type": "scatter", "xsrc": "jeonyl:12:b4c727", "ysrc": "jeonyl:12:291e95", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "7", "type": "scatter", "xsrc": "jeonyl:12:5780b1", "ysrc": "jeonyl:12:e4e214", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "6", "type": "scatter", "xsrc": "jeonyl:12:94a351", "ysrc": "jeonyl:12:d7c32c", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "5", "type": "scatter", "xsrc": "jeonyl:12:2bc82e", "ysrc": "jeonyl:12:b626d9", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "4", "type": "scatter", "xsrc": "jeonyl:12:5fb665", "ysrc": "jeonyl:12:797fc7", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "3", "type": "scatter", "xsrc": "jeonyl:12:3e622f", "ysrc": "jeonyl:12:838438", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "2", "type": "scatter", "xsrc": "jeonyl:12:32a294", "ysrc": "jeonyl:12:1782ba", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "1", "type": "scatter", "xsrc": "jeonyl:12:91fda9", "ysrc": "jeonyl:12:ca43a4", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "59", "type": "scatter", "xsrc": "jeonyl:12:1f7f7e", "ysrc": "jeonyl:12:b07550", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "58", "type": "scatter", "xsrc": "jeonyl:12:c82613", "ysrc": "jeonyl:12:cb9ddd", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "57", "type": "scatter", "xsrc": "jeonyl:12:0c1e32", "ysrc": "jeonyl:12:9b529e", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "56", "type": "scatter", "xsrc": "jeonyl:12:c51249", "ysrc": "jeonyl:12:45472d", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "55", "type": "scatter", "xsrc": "jeonyl:12:ba9b9c", "ysrc": "jeonyl:12:3ac371", "showlegend": false }, { "line": { "color": "rgba(0,0,255,0.5)" }, "mode": "lines", "name": "54", "type": "scatter", "xsrc": "jeonyl:12:54f1f0", "ysrc": "jeonyl:12:138623", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "53", "type": "scatter", "xsrc": "jeonyl:12:30f9e8", "ysrc": "jeonyl:12:dcbd60", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "52", "type": "scatter", "xsrc": "jeonyl:12:ed28f8", "ysrc": "jeonyl:12:d50907", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "51", "type": "scatter", "xsrc": "jeonyl:12:cf8fcf", "ysrc": "jeonyl:12:0ea964", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "50", "type": "scatter", "xsrc": "jeonyl:12:215d2c", "ysrc": "jeonyl:12:f641be", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "49", "type": "scatter", "xsrc": "jeonyl:12:2c4fee", "ysrc": "jeonyl:12:5cd013", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "48", "type": "scatter", "xsrc": "jeonyl:12:31ec7e", "ysrc": "jeonyl:12:4b58b3", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "47", "type": "scatter", "xsrc": "jeonyl:12:f3faa3", "ysrc": "jeonyl:12:be9b44", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "46", "type": "scatter", "xsrc": "jeonyl:12:2141a5", "ysrc": "jeonyl:12:c8525e", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "45", "type": "scatter", "xsrc": "jeonyl:12:92d2b3", "ysrc": "jeonyl:12:5c7aa1", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "44", "type": "scatter", "xsrc": "jeonyl:12:a5d0bc", "ysrc": "jeonyl:12:3f2159", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "43", "type": "scatter", "xsrc": "jeonyl:12:bda29d", "ysrc": "jeonyl:12:d4f7d7", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "42", "type": "scatter", "xsrc": "jeonyl:12:be300f", "ysrc": "jeonyl:12:17d03f", "showlegend": false }, { "line": { "color": "rgba(0,255,0,0.5)" }, "mode": "lines", "name": "41", "type": "scatter", "xsrc": "jeonyl:12:6e3f49", "ysrc": "jeonyl:12:448203", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "40", "type": "scatter", "xsrc": "jeonyl:12:ddf2ff", "ysrc": "jeonyl:12:15914a", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "39", "type": "scatter", "xsrc": "jeonyl:12:7ee052", "ysrc": "jeonyl:12:f66310", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "38", "type": "scatter", "xsrc": "jeonyl:12:f547c1", "ysrc": "jeonyl:12:e54821", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "37", "type": "scatter", "xsrc": "jeonyl:12:2bcd68", "ysrc": "jeonyl:12:480004", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "36", "type": "scatter", "xsrc": "jeonyl:12:e3bc2e", "ysrc": "jeonyl:12:d09a41", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "35", "type": "scatter", "xsrc": "jeonyl:12:acaece", "ysrc": "jeonyl:12:163dc1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "34", "type": "scatter", "xsrc": "jeonyl:12:07e1d6", "ysrc": "jeonyl:12:ca5b2e", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "33", "type": "scatter", "xsrc": "jeonyl:12:5df2fa", "ysrc": "jeonyl:12:bc4078", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "32", "type": "scatter", "xsrc": "jeonyl:12:f99b65", "ysrc": "jeonyl:12:a663a1", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "31", "type": "scatter", "xsrc": "jeonyl:12:7943a2", "ysrc": "jeonyl:12:17ca83", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "30", "type": "scatter", "xsrc": "jeonyl:12:748b77", "ysrc": "jeonyl:12:850091", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "29", "type": "scatter", "xsrc": "jeonyl:12:95978b", "ysrc": "jeonyl:12:2187a2", "showlegend": false }, { "line": { "color": "rgba(255,255,0,0.5)" }, "mode": "lines", "name": "28", "type": "scatter", "xsrc": "jeonyl:12:cc1741", "ysrc": "jeonyl:12:df1e73", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "27", "type": "scatter", "xsrc": "jeonyl:12:546b87", "ysrc": "jeonyl:12:0f607d", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "26", "type": "scatter", "xsrc": "jeonyl:12:c6ea19", "ysrc": "jeonyl:12:65f3f1", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "25", "type": "scatter", "xsrc": "jeonyl:12:c3e226", "ysrc": "jeonyl:12:e59a69", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "24", "type": "scatter", "xsrc": "jeonyl:12:2c07cc", "ysrc": "jeonyl:12:10c0f8", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "23", "type": "scatter", "xsrc": "jeonyl:12:ef1481", "ysrc": "jeonyl:12:212070", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "22", "type": "scatter", "xsrc": "jeonyl:12:99d784", "ysrc": "jeonyl:12:e786e0", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "21", "type": "scatter", "xsrc": "jeonyl:12:a5f106", "ysrc": "jeonyl:12:ff6876", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "20", "type": "scatter", "xsrc": "jeonyl:12:acac3e", "ysrc": "jeonyl:12:95e9f5", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "19", "type": "scatter", "xsrc": "jeonyl:12:6cfbe7", "ysrc": "jeonyl:12:cb94bd", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "18", "type": "scatter", "xsrc": "jeonyl:12:cf2a32", "ysrc": "jeonyl:12:bcd7bb", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "17", "type": "scatter", "xsrc": "jeonyl:12:53b470", "ysrc": "jeonyl:12:659a33", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "16", "type": "scatter", "xsrc": "jeonyl:12:7c43c3", "ysrc": "jeonyl:12:c5a2b2", "showlegend": false }, { "line": { "color": "rgba(255,127,0,0.5)" }, "mode": "lines", "name": "15", "type": "scatter", "xsrc": "jeonyl:12:f8219a", "ysrc": "jeonyl:12:f5bf75", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "14", "type": "scatter", "xsrc": "jeonyl:12:a5f8c7", "ysrc": "jeonyl:12:ac16b8", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "13", "type": "scatter", "xsrc": "jeonyl:12:cc9744", "ysrc": "jeonyl:12:1c8825", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "12", "type": "scatter", "xsrc": "jeonyl:12:3514aa", "ysrc": "jeonyl:12:063549", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "11", "type": "scatter", "xsrc": "jeonyl:12:1b460f", "ysrc": "jeonyl:12:b6791d", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "10", "type": "scatter", "xsrc": "jeonyl:12:658b7b", "ysrc": "jeonyl:12:e98bb4", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "9", "type": "scatter", "xsrc": "jeonyl:12:e83f8c", "ysrc": "jeonyl:12:8fc28d", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "8", "type": "scatter", "xsrc": "jeonyl:12:f3f707", "ysrc": "jeonyl:12:6f63a1", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "7", "type": "scatter", "xsrc": "jeonyl:12:7d527e", "ysrc": "jeonyl:12:7dd5c6", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "6", "type": "scatter", "xsrc": "jeonyl:12:824b03", "ysrc": "jeonyl:12:4babf8", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "5", "type": "scatter", "xsrc": "jeonyl:12:404e47", "ysrc": "jeonyl:12:2a63f7", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "4", "type": "scatter", "xsrc": "jeonyl:12:838957", "ysrc": "jeonyl:12:7b5883", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "3", "type": "scatter", "xsrc": "jeonyl:12:690127", "ysrc": "jeonyl:12:adba0d", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "2", "type": "scatter", "xsrc": "jeonyl:12:9c3a46", "ysrc": "jeonyl:12:6fe7ab", "showlegend": false }, { "line": { "color": "rgba(255,0,0,0.5)" }, "mode": "lines", "name": "1", "type": "scatter", "xsrc": "jeonyl:12:6537c5", "ysrc": "jeonyl:12:354623", "showlegend": false }, { "mode": "markers", "type": "scatter", "xsrc": "jeonyl:12:2803d5", "ysrc": "jeonyl:12:a06711", "marker": { "cmax": 80, "cmin": 1, "size": 100, "colorbar": { "x": 1.0, "len": 0.95, "title": { "side": "top", "text": "RSL" }, "lenmode": "fraction", "xanchor": "left", "tickmode": "array", "thickness": 20, "ticktextsrc": "jeonyl:12:3baab0", "tickvalssrc": "jeonyl:12:81ee97", "thicknessmode": "pixels" }, "colorscale": [ [ 0.0, "rgba(255,0,0,0.5)" ], [ 0.013513513513513514, "rgba(255,0,0,0.5)" ], [ 0.02702702702702703, "rgba(255,0,0,0.5)" ], [ 0.04054054054054054, "rgba(255,0,0,0.5)" ], [ 0.05405405405405406, "rgba(255,0,0,0.5)" ], [ 0.06756756756756757, "rgba(255,0,0,0.5)" ], [ 0.08108108108108109, "rgba(255,0,0,0.5)" ], [ 0.0945945945945946, "rgba(255,0,0,0.5)" ], [ 0.10810810810810811, "rgba(255,0,0,0.5)" ], [ 0.12162162162162163, "rgba(255,0,0,0.5)" ], [ 0.13513513513513514, "rgba(255,0,0,0.5)" ], [ 0.14864864864864866, "rgba(255,0,0,0.5)" ], [ 0.16216216216216217, "rgba(255,0,0,0.5)" ], [ 0.17567567567567569, "rgba(255,0,0,0.5)" ], [ 0.1891891891891892, "rgba(255,0,0,0.5)" ], [ 0.20270270270270271, "rgba(255,127,0,0.5)" ], [ 0.21621621621621623, "rgba(255,127,0,0.5)" ], [ 0.22972972972972974, "rgba(255,127,0,0.5)" ], [ 0.24324324324324326, "rgba(255,127,0,0.5)" ], [ 0.25675675675675674, "rgba(255,127,0,0.5)" ], [ 0.2702702702702703, "rgba(255,127,0,0.5)" ], [ 0.28378378378378377, "rgba(255,127,0,0.5)" ], [ 0.2972972972972973, "rgba(255,127,0,0.5)" ], [ 0.3108108108108108, "rgba(255,127,0,0.5)" ], [ 0.32432432432432434, "rgba(255,127,0,0.5)" ], [ 0.33783783783783783, "rgba(255,127,0,0.5)" ], [ 0.35135135135135137, "rgba(255,127,0,0.5)" ], [ 0.36486486486486486, "rgba(255,127,0,0.5)" ], [ 0.3783783783783784, "rgba(255,255,0,0.5)" ], [ 0.3918918918918919, "rgba(255,255,0,0.5)" ], [ 0.40540540540540543, "rgba(255,255,0,0.5)" ], [ 0.4189189189189189, "rgba(255,255,0,0.5)" ], [ 0.43243243243243246, "rgba(255,255,0,0.5)" ], [ 0.44594594594594594, "rgba(255,255,0,0.5)" ], [ 0.4594594594594595, "rgba(255,255,0,0.5)" ], [ 0.47297297297297297, "rgba(255,255,0,0.5)" ], [ 0.4864864864864865, "rgba(255,255,0,0.5)" ], [ 0.5, "rgba(255,255,0,0.5)" ], [ 0.5135135135135135, "rgba(255,255,0,0.5)" ], [ 0.527027027027027, "rgba(255,255,0,0.5)" ], [ 0.5405405405405406, "rgba(255,255,0,0.5)" ], [ 0.5540540540540541, "rgba(0,255,0,0.5)" ], [ 0.5675675675675675, "rgba(0,255,0,0.5)" ], [ 0.581081081081081, "rgba(0,255,0,0.5)" ], [ 0.5945945945945946, "rgba(0,255,0,0.5)" ], [ 0.6081081081081081, "rgba(0,255,0,0.5)" ], [ 0.6216216216216216, "rgba(0,255,0,0.5)" ], [ 0.6351351351351351, "rgba(0,255,0,0.5)" ], [ 0.6486486486486487, "rgba(0,255,0,0.5)" ], [ 0.6621621621621622, "rgba(0,255,0,0.5)" ], [ 0.6756756756756757, "rgba(0,255,0,0.5)" ], [ 0.6891891891891891, "rgba(0,255,0,0.5)" ], [ 0.7027027027027027, "rgba(0,255,0,0.5)" ], [ 0.7162162162162162, "rgba(0,255,0,0.5)" ], [ 0.7297297297297297, "rgba(0,0,255,0.5)" ], [ 0.7432432432432432, "rgba(0,0,255,0.5)" ], [ 0.7567567567567568, "rgba(0,0,255,0.5)" ], [ 0.7702702702702703, "rgba(0,0,255,0.5)" ], [ 0.7837837837837838, "rgba(0,0,255,0.5)" ], [ 0.7972972972972973, "rgba(0,0,255,0.5)" ], [ 0.8108108108108109, "rgba(0,0,255,0.5)" ], [ 0.8243243243243243, "rgba(0,0,255,0.5)" ], [ 0.8378378378378378, "rgba(0,0,255,0.5)" ], [ 0.8513513513513513, "rgba(0,0,255,0.5)" ], [ 0.8648648648648649, "rgba(0,0,255,0.5)" ], [ 0.8783783783783784, "rgba(0,0,255,0.5)" ], [ 0.8918918918918919, "rgba(0,0,255,0.5)" ], [ 0.9054054054054054, "rgba(75,0,130,0.5)" ], [ 0.918918918918919, "rgba(75,0,130,0.5)" ], [ 0.9324324324324325, "rgba(75,0,130,0.5)" ], [ 0.9459459459459459, "rgba(75,0,130,0.5)" ], [ 0.9594594594594594, "rgba(75,0,130,0.5)" ], [ 0.972972972972973, "rgba(75,0,130,0.5)" ], [ 0.9864864864864865, "rgba(75,0,130,0.5)" ], [ 1.0, "rgba(75,0,130,0.5)" ] ] }, "hoverinfo": "none", "showlegend": false } ], "layout": { "font": { "family": "Arial, sans-serif" }, "width": 600, "xaxis": { "title": { "font": { "size": 22 }, "text": "time[m]" }, "mirror": true }, "yaxis": { "title": { "font": { "size": 22 }, "text": "Relaxation voltage[V]" }, "mirror": true }, "height": 600, "legend": { "font": { "size": 18 } }, "margin": { "t": 50 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "white", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "rgb(36,36,36)" }, "error_y": { "color": "rgb(36,36,36)" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "rgb(237,237,237)" }, "line": { "color": "white" } }, "header": { "fill": { "color": "rgb(217,217,217)" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(36,36,36)", "minorgridcolor": "white", "startlinecolor": "rgb(36,36,36)" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(36,36,36)", "minorgridcolor": "white", "startlinecolor": "rgb(36,36,36)" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "white", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "line": { "color": "white", "width": 0.6 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 }, "colorscale": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "rgb(36,36,36)" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "outside", "showgrid": false, "showline": true, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)" }, "angularaxis": { "ticks": "outside", "showgrid": false, "showline": true, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)" } }, "scene": { "xaxis": { "ticks": "outside", "showgrid": false, "showline": true, "zeroline": false, "gridcolor": "rgb(232,232,232)", "gridwidth": 2, "linecolor": "rgb(36,36,36)", "zerolinecolor": "rgb(36,36,36)", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "outside", "showgrid": false, "showline": true, "zeroline": false, "gridcolor": "rgb(232,232,232)", "gridwidth": 2, "linecolor": "rgb(36,36,36)", "zerolinecolor": "rgb(36,36,36)", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "outside", "showgrid": false, "showline": true, "zeroline": false, "gridcolor": "rgb(232,232,232)", "gridwidth": 2, "linecolor": "rgb(36,36,36)", "zerolinecolor": "rgb(36,36,36)", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "outside", "title": { "standoff": 15 }, "showgrid": false, "showline": true, "zeroline": false, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)", "automargin": true, "zerolinecolor": "rgb(36,36,36)" }, "yaxis": { "ticks": "outside", "title": { "standoff": 15 }, "showgrid": false, "showline": true, "zeroline": false, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)", "automargin": true, "zerolinecolor": "rgb(36,36,36)" }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "outside", "showgrid": false, "showline": true, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)" }, "baxis": { "ticks": "outside", "showgrid": false, "showline": true, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)" }, "caxis": { "ticks": "outside", "showgrid": false, "showline": true, "gridcolor": "rgb(232,232,232)", "linecolor": "rgb(36,36,36)" }, "bgcolor": "white" }, "colorway": [ "#1F77B4", "#FF7F0E", "#2CA02C", "#D62728", "#9467BD", "#8C564B", "#E377C2", "#7F7F7F", "#BCBD22", "#17BECF" ], "coloraxis": { "colorbar": { "ticks": "outside", "tickcolor": "rgb(36,36,36)", "outlinewidth": 1 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0.0, "rgb(103,0,31)" ], [ 0.1, "rgb(178,24,43)" ], [ 0.2, "rgb(214,96,77)" ], [ 0.3, "rgb(244,165,130)" ], [ 0.4, "rgb(253,219,199)" ], [ 0.5, "rgb(247,247,247)" ], [ 0.6, "rgb(209,229,240)" ], [ 0.7, "rgb(146,197,222)" ], [ 0.8, "rgb(67,147,195)" ], [ 0.9, "rgb(33,102,172)" ], [ 1.0, "rgb(5,48,97)" ] ], "sequential": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ], "sequentialminus": [ [ 0.0, "#440154" ], [ 0.1111111111111111, "#482878" ], [ 0.2222222222222222, "#3e4989" ], [ 0.3333333333333333, "#31688e" ], [ 0.4444444444444444, "#26828e" ], [ 0.5555555555555556, "#1f9e89" ], [ 0.6666666666666666, "#35b779" ], [ 0.7777777777777778, "#6ece58" ], [ 0.8888888888888888, "#b5de2b" ], [ 1.0, "#fde725" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.3, "fillcolor": "black" }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowwidth": 1 } } } } }, "height": 600, "width": 600, "user": { "profile_url": "https://chart-studio.plotly.com/~jeonyl", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/19.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 07:16:01", "mapbox_access_tokens": null, "has_password": null, "username": "jeonyl", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T07:13:34.222587Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~sven.sandberg/51.embed", "fid": "sven.sandberg:51", "filename": "Provtryckning 8 april", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/sven.sandberg/51/9_KEHPKAP8ZFFDRFIK6KAZIFFZECO75L.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/sven.sandberg/51/2_29LW2GZ7SBN82A8GH94ZFD3ZIGH86W.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/sven.sandberg/51/8_4XYPQ4T1W4WQ015CEBTXJAQAXP54TW.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/sven.sandberg/51/9_KEHPKAP8ZFFDRFIK6KAZIFFZECO75L.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sven.sandberg:51", "plots": "https://api.plotly.com/v2/plots/sven.sandberg:51", "parent": "https://api.plotly.com/v2/folders/home?user=sven.sandberg" }, "owner": "sven.sandberg", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~sven.sandberg/51/", "world_readable": true, "date_modified": "2024-04-12T07:13:34.233Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~sven.sandberg/51/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "name": "Uthus", "type": "scatter", "xsrc": "sven.sandberg:50:134131", "ysrc": "sven.sandberg:50:079914" }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "lines", "name": "Under trappan", "type": "scatter", "xsrc": "sven.sandberg:50:134131", "ysrc": "sven.sandberg:50:05016c", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "", "type": "scatter", "xsrc": "sven.sandberg:50:134131", "ysrc": "sven.sandberg:50:079914" }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "markers", "name": "", "type": "scatter", "xsrc": "sven.sandberg:50:134131", "ysrc": "sven.sandberg:50:05016c", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "date", "range": [ "2024-04-08 11:57:28.1663", "2024-04-11 12:52:31.8337" ], "tickmode": "auto", "autorange": true, "gridwidth": 1 }, "yaxis": { "type": "linear", "dtick": 0.1, "range": [ 0, 1.7 ], "tickmode": "linear", "autorange": false }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~sven.sandberg", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-12-21 19:57:34", "mapbox_access_tokens": null, "has_password": null, "username": "sven.sandberg", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:35:49.522741Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~AllenDG/1.embed", "fid": "AllenDG:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/AllenDG:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/AllenDG:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/AllenDG/1/8_K7HEEAC2AS4EM5LOYNEYAT99T3RGUN.png", "list-thumb": "https://api.plotly.com/v2/files/AllenDG:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/AllenDG:1", "plots": "https://api.plotly.com/v2/plots/AllenDG:1", "parent": "https://api.plotly.com/v2/folders/home?user=AllenDG" }, "owner": "AllenDG", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~AllenDG/1/", "world_readable": true, "date_modified": "2024-04-26T02:04:08.091Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~AllenDG/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "fill": "none", "line": { "dash": "dash", "color": "rgb(239, 85, 59)" }, "meta": { "columnNames": { "x": "A", "y": "D", "text": "D", "textposition": "" } }, "mode": "markers+lines+text", "name": "Desired converted plastic<br>", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:fadeb1", "error_x": { "type": "percent", "color": "rgb(239, 85, 59)", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "opacity": 1, "textsrc": "AllenDG:0:fadeb1", "visible": true, "hoverinfo": "x+y+text+name", "showlegend": false, "connectgaps": true, "textposition": "top center" }, { "meta": { "columnNames": { "x": "A", "y": "B", "text": "B" } }, "mode": "markers+lines+text", "name": "Simulated Conversion", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:e9e5cc", "marker": { "size": 6, "color": "#EF553B" }, "textsrc": "AllenDG:0:e9e5cc", "showlegend": true, "textposition": "top center" }, { "meta": { "columnNames": { "x": "A", "y": "C", "text": "C" } }, "mode": "markers+lines+text", "name": "Historical Conversion", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:298fc2", "xaxis": "x", "yaxis": "y", "textsrc": "AllenDG:0:298fc2", "visible": true, "showlegend": true, "textposition": "bottom center" }, { "line": { "dash": "dash" }, "meta": { "columnNames": { "x": "A", "y": "E", "text": "E" } }, "mode": "markers+lines+text", "name": "Desired plastic collection", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:ce0aa8", "marker": { "color": "rgb(0, 204, 150)" }, "textsrc": "AllenDG:0:ce0aa8", "visible": true, "groupnorm": "", "stackgaps": "infer zero", "hoverlabel": { "align": "auto" }, "showlegend": false, "orientation": "v", "textposition": "bottom center" }, { "meta": { "columnNames": { "x": "A", "y": "F", "text": "F" } }, "mode": "markers+lines+text", "name": "Historical Plastic Collected", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:179c98", "textsrc": "AllenDG:0:179c98", "showlegend": true, "stackgroup": null, "textposition": "top center" }, { "line": { "dash": "dash" }, "meta": { "columnNames": { "x": "A", "y": "G", "text": "G" } }, "mode": "markers+lines+text", "type": "scatter", "xsrc": "AllenDG:0:8004a8", "ysrc": "AllenDG:0:c2cbe5", "marker": { "color": "rgb(25, 211, 243)" }, "opacity": 1, "textsrc": "AllenDG:0:c2cbe5", "showlegend": false, "stackgroup": null, "textposition": "top center" } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "side": "bottom", "type": "linear", "range": [ 2014.4039992234518, 2025.5960007765482 ], "title": { "text": "Years" }, "domain": [ 0, 1 ], "tickmode": "linear", "autorange": true, "automargin": true, "showspikes": false, "separatethousands": false }, "yaxis": { "side": "left", "type": "linear", "dtick": 0.05, "range": [ 1759.8310273972602, 92121.62897260273 ], "tick0": 0.15, "ticks": "", "title": { "text": "Weight collected annualy (Million Tons/Yr)" }, "nticks": 8, "tickmode": "linear", "autorange": true, "showspikes": false }, "legend": { "valign": "top" }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~AllenDG", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:35:23", "mapbox_access_tokens": null, "has_password": null, "username": "AllenDG", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:21:15.247988Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shinheepark/18.embed", "fid": "shinheepark:18", "filename": "spotify", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/shinheepark:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/shinheepark:18/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/shinheepark/18/8_EMY4DGHDT10HSKUJZNW1BA70XJC5TH.png", "list-thumb": "https://api.plotly.com/v2/files/shinheepark:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shinheepark:18", "plots": "https://api.plotly.com/v2/plots/shinheepark:18", "parent": "https://api.plotly.com/v2/folders/home?user=shinheepark" }, "owner": "shinheepark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 34, "web_url": "https://chart-studio.plotly.com/~shinheepark/18/", "world_readable": true, "date_modified": "2024-05-10T08:46:38.935Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shinheepark/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "#636efa" }, "mode": "markers+lines", "name": "", "type": "scattergl", "xsrc": "shinheepark:39:0d54a3", "ysrc": "shinheepark:39:261701", "xaxis": "x", "yaxis": "y", "marker": { "symbol": "circle" }, "showlegend": false, "legendgroup": "", "hovertemplate": "date=%{x}<br>acc=%{y}<extra></extra>" } ], "layout": { "title": { "text": "spotify" }, "width": 800, "xaxis": { "title": { "text": "date" }, "anchor": "y", "domain": [ 0.0, 1.0 ] }, "yaxis": { "title": { "text": "acc" }, "anchor": "x", "domain": [ 0.0, 1.0 ] }, "height": 500, "legend": { "tracegroupgap": 0 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": 500, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~shinheepark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:02:45", "mapbox_access_tokens": null, "has_password": null, "username": "shinheepark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:21:11.470987Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shinheepark/16.embed", "fid": "shinheepark:16", "filename": "twitter", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/shinheepark:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/shinheepark:16/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/shinheepark:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/shinheepark:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shinheepark:16", "plots": "https://api.plotly.com/v2/plots/shinheepark:16", "parent": "https://api.plotly.com/v2/folders/home?user=shinheepark" }, "owner": "shinheepark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 36, "web_url": "https://chart-studio.plotly.com/~shinheepark/16/", "world_readable": true, "date_modified": "2024-05-10T08:46:33.826Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shinheepark/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "#636efa" }, "mode": "markers+lines", "name": "", "type": "scattergl", "xsrc": "shinheepark:38:6c804f", "ysrc": "shinheepark:38:27af11", "xaxis": "x", "yaxis": "y", "marker": { "symbol": "circle" }, "showlegend": false, "legendgroup": "", "hovertemplate": "date=%{x}<br>acc=%{y}<extra></extra>" } ], "layout": { "title": { "text": "twitter" }, "width": 800, "xaxis": { "title": { "text": "date" }, "anchor": "y", "domain": [ 0.0, 1.0 ] }, "yaxis": { "title": { "text": "acc" }, "anchor": "x", "domain": [ 0.0, 1.0 ] }, "height": 500, "legend": { "tracegroupgap": 0 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": 500, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~shinheepark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:02:45", "mapbox_access_tokens": null, "has_password": null, "username": "shinheepark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:21:07.674027Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shinheepark/14.embed", "fid": "shinheepark:14", "filename": "instagram", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/shinheepark:14/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/shinheepark:14/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/shinheepark:14/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/shinheepark:14/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shinheepark:14", "plots": "https://api.plotly.com/v2/plots/shinheepark:14", "parent": "https://api.plotly.com/v2/folders/home?user=shinheepark" }, "owner": "shinheepark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 36, "web_url": "https://chart-studio.plotly.com/~shinheepark/14/", "world_readable": true, "date_modified": "2024-05-10T08:55:33.774Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shinheepark/14/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "#636efa" }, "mode": "markers+lines", "name": "", "type": "scattergl", "xsrc": "shinheepark:42:72ee77", "ysrc": "shinheepark:42:ab38bc", "xaxis": "x", "yaxis": "y", "marker": { "symbol": "circle" }, "showlegend": false, "legendgroup": "", "hovertemplate": "date=%{x}<br>acc=%{y}<extra></extra>" } ], "layout": { "title": { "text": "instagram" }, "width": 800, "xaxis": { "title": { "text": "date" }, "anchor": "y", "domain": [ 0.0, 1.0 ] }, "yaxis": { "title": { "text": "acc" }, "anchor": "x", "domain": [ 0.0, 1.0 ] }, "height": 500, "legend": { "tracegroupgap": 0 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": 500, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~shinheepark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:02:45", "mapbox_access_tokens": null, "has_password": null, "username": "shinheepark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:21:03.783794Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shinheepark/12.embed", "fid": "shinheepark:12", "filename": "channel", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/shinheepark:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/shinheepark:12/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/shinheepark:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/shinheepark:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shinheepark:12", "plots": "https://api.plotly.com/v2/plots/shinheepark:12", "parent": "https://api.plotly.com/v2/folders/home?user=shinheepark" }, "owner": "shinheepark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 45, "web_url": "https://chart-studio.plotly.com/~shinheepark/12/", "world_readable": true, "date_modified": "2024-05-10T08:55:28.808Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shinheepark/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "#636efa" }, "mode": "markers+lines", "name": "", "type": "scattergl", "xsrc": "shinheepark:41:3335c2", "ysrc": "shinheepark:41:ecc74f", "xaxis": "x", "yaxis": "y", "marker": { "symbol": "circle" }, "showlegend": false, "legendgroup": "", "hovertemplate": "date=%{x}<br>acc=%{y}<extra></extra>" } ], "layout": { "title": { "text": "channel" }, "width": 800, "xaxis": { "title": { "text": "date" }, "anchor": "y", "domain": [ 0.0, 1.0 ] }, "yaxis": { "title": { "text": "acc" }, "anchor": "x", "domain": [ 0.0, 1.0 ] }, "height": 500, "legend": { "tracegroupgap": 0 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": 500, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~shinheepark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:02:45", "mapbox_access_tokens": null, "has_password": null, "username": "shinheepark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:09:28.955515Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~lizlara12345678/1.embed", "fid": "lizlara12345678:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/lizlara12345678/1/9_EINL4IE7YJAORSSTNTEZ2EOIPIGRQF.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/lizlara12345678/1/2_RVAFINGUR2W9LXIXE2CLQIQMSGXD67.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/lizlara12345678/1/8_DEJD7SJGJXBGT3T0FF1KE5OKV97FIH.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/lizlara12345678/1/9_EINL4IE7YJAORSSTNTEZ2EOIPIGRQF.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/lizlara12345678:1", "plots": "https://api.plotly.com/v2/plots/lizlara12345678:1", "parent": "https://api.plotly.com/v2/folders/home?user=lizlara12345678" }, "owner": "lizlara12345678", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~lizlara12345678/1/", "world_readable": true, "date_modified": "2024-04-12T06:09:28.967Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~lizlara12345678/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "dot", "color": "rgb(86, 97, 213)" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers+lines", "name": "BPDE", "type": "scatter", "xsrc": "lizlara12345678:0:403832", "ysrc": "lizlara12345678:0:5cb077", "marker": { "size": 9, "symbol": "circle", "opacity": 0.76 } }, { "line": { "dash": "longdashdot", "color": "rgb(221, 141, 84)" }, "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers+lines", "name": "BPE", "type": "scatter", "xsrc": "lizlara12345678:0:f11e85", "ysrc": "lizlara12345678:0:8972ff", "marker": { "line": { "width": 1 }, "size": 9, "color": "rgb(233, 125, 49)", "symbol": "circle-open", "opacity": 0.48 } } ], "frames": [], "layout": { "title": { "x": 0.48, "font": { "size": 16, "family": "Old Standard TT" }, "text": "$\\text{Difference Between Ionization Energies (Simulation vs CAS - Cl)}$" }, "xaxis": { "type": "linear", "dtick": 0, "range": [ 0.9457154503189658, 3.058571855901696 ], "tick0": 0, "ticks": "inside", "title": { "text": "$\\rm R(H\\cdots H)/ A^°$" }, "showgrid": true, "showline": true, "tickfont": { "size": 15, "family": "Liberation Sans" }, "tickmode": "auto", "zeroline": true, "autorange": true, "linecolor": "rgb(38, 39, 40)", "linewidth": 4, "tickwidth": 4, "zerolinecolor": "rgb(18, 81, 190)", "zerolinewidth": 10 }, "yaxis": { "type": "linear", "range": [ -0.5717271213238411, 2.4317391745093584 ], "ticks": "inside", "title": { "text": "$\\Delta E_{ST}(S) - \\Delta E_{ST}(Cl)$" }, "showline": true, "tickfont": { "size": 15 }, "autorange": true, "linecolor": "rgb(38, 39, 40)", "linewidth": 3, "tickwidth": 4 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~lizlara12345678", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/85.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-11 20:05:42", "mapbox_access_tokens": null, "has_password": null, "username": "lizlara12345678", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T06:07:42.109607Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shinheepark/1.embed", "fid": "shinheepark:1", "filename": "test", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/shinheepark/1/9_710KFYJQVL8MDQPMGGHM0SK8T4A0IN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/shinheepark/1/2_GATWRMJQE0MN8HXZZCY5NU1A606NW4.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/shinheepark/1/8_H64NPJCDET8E58BR1LW09KDOII3HKL.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/shinheepark/1/9_710KFYJQVL8MDQPMGGHM0SK8T4A0IN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shinheepark:1", "plots": "https://api.plotly.com/v2/plots/shinheepark:1", "parent": "https://api.plotly.com/v2/folders/home?user=shinheepark" }, "owner": "shinheepark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 34, "web_url": "https://chart-studio.plotly.com/~shinheepark/1/", "world_readable": true, "date_modified": "2024-04-12T09:39:21.024Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shinheepark/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "indianred" }, "mode": "markers+lines", "name": "channel", "type": "scatter", "xsrc": "shinheepark:21:859813", "ysrc": "shinheepark:21:b160e5" }, { "line": { "color": "deeppink" }, "mode": "markers+lines", "name": "instagram", "type": "scatter", "xsrc": "shinheepark:21:5498b0", "ysrc": "shinheepark:21:b5da72" }, { "line": { "color": "skyblue" }, "mode": "markers+lines", "name": "twitter", "type": "scatter", "xsrc": "shinheepark:21:de53c5", "ysrc": "shinheepark:21:37bd05" }, { "line": { "color": "forestgreen" }, "mode": "markers+lines", "name": "spotify", "type": "scatter", "xsrc": "shinheepark:21:d7b04f", "ysrc": "shinheepark:21:0a7775" } ], "layout": { "title": { "text": "All" }, "width": 800, "xaxis": { "title": { "text": "date" } }, "yaxis": { "title": { "text": "rescaled" } }, "height": 500, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": 500, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~shinheepark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 06:02:45", "mapbox_access_tokens": null, "has_password": null, "username": "shinheepark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-12T05:18:44.796376Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~e21cseu0065/12.embed", "fid": "e21cseu0065:12", "filename": "Task4-dashboard-layout", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/e21cseu0065/12/9_J0B9DON1H9UHW6ALEBOQRHRUO7WLOH.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/e21cseu0065/12/2_097NS6GXBT9RCW55GFJMH91JK7DQQ4.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/e21cseu0065/12/8_DJS7O13IPE1JHXLM6CH5TOUKKDA5PX.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/e21cseu0065/12/9_J0B9DON1H9UHW6ALEBOQRHRUO7WLOH.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/e21cseu0065:12", "plots": "https://api.plotly.com/v2/plots/e21cseu0065:12", "parent": "https://api.plotly.com/v2/folders/home?user=e21cseu0065" }, "owner": "e21cseu0065", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~e21cseu0065/12/", "world_readable": true, "date_modified": "2024-04-15T05:34:50.842Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~e21cseu0065/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "text", "type": "scatter", "xsrc": "e21cseu0065:17:f518ed", "ysrc": "e21cseu0065:17:33520e", "xaxis": "x", "yaxis": "y", "textsrc": "e21cseu0065:17:0178c0", "textfont": { "size": 12, "color": "red", "family": "Arial" }, "showlegend": false }, { "mode": "markers", "type": "scatter", "xsrc": "e21cseu0065:17:443b2f", "ysrc": "e21cseu0065:17:8fce48", "xaxis": "x", "yaxis": "y" }, { "type": "box", "ysrc": "e21cseu0065:17:a87746", "xaxis": "x2", "yaxis": "y2" }, { "type": "box", "ysrc": "e21cseu0065:17:39e3bd", "xaxis": "x3", "yaxis": "y3" } ], "layout": { "font": { "size": 14, "color": "navy", "family": "Arial" }, "title": { "text": "Task4-Dashboard Layout" }, "xaxis": { "anchor": "y", "domain": [ 0.0, 0.45 ] }, "yaxis": { "anchor": "x", "domain": [ 0.625, 1.0 ] }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.0, 1.0 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.625, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.0, 0.375 ] }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "annotations": [ { "x": 0.225, "y": 1.0, "font": { "size": 16 }, "text": "Box 1", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 1.0, "font": { "size": 16 }, "text": "Box 2", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.375, "font": { "size": 16 }, "text": "Box 3", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ], "paper_bgcolor": "lightblue" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~e21cseu0065", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-12 04:39:18", "mapbox_access_tokens": null, "has_password": null, "username": "e21cseu0065", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
