Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xOCswNSUzQTQ3JTNBNTkuNjM2MTA2JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE4KzA1JTNBNDglM0ExMS41MzY3MTYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xOCswNSUzQTU4JTNBMTMuODE5OTc5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-18T05:58:13.819979Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~caijun/7.embed", "fid": "caijun:7", "filename": "Plot 7", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/caijun/7/9_WOPPHNE9BFEKIE524I4XT7ZG05ZET6.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/caijun/7/2_FIU95SWTU5NKSH3PHDBCCVJLT8AQCU.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/caijun/7/8_9JG3H7RBBXW9I7US7OOV7BZSOQSRB9.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/caijun/7/9_WOPPHNE9BFEKIE524I4XT7ZG05ZET6.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/caijun:7", "plots": "https://api.plotly.com/v2/plots/caijun:7", "parent": "https://api.plotly.com/v2/folders/home?user=caijun" }, "owner": "caijun", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 8, "web_url": "https://chart-studio.plotly.com/~caijun/7/", "world_readable": true, "date_modified": "2019-06-18T05:58:13.835Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~caijun/7/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "name": "response_in_window", "type": "bar", "xsrc": "caijun:5:b8492d", "ysrc": "caijun:5:43f964", "visible": true, "orientation": "v" }, { "name": "response_all", "type": "bar", "xsrc": "caijun:5:b8492d", "ysrc": "caijun:5:16a997", "visible": true, "orientation": "v" }, { "mode": "markers", "name": "request-succeed", "type": "bar", "xsrc": "caijun:5:b8492d", "ysrc": "caijun:5:e6c14b", "visible": true, "stackgroup": null, "orientation": "v" }, { "mode": "markers", "name": "500B-10S", "type": "scatter", "xsrc": "caijun:6:9ad343", "ysrc": "caijun:6:34de83" }, { "mode": "markers", "name": "500B-30S", "type": "scatter", "xsrc": "caijun:6:d77c16", "ysrc": "caijun:6:51a16e", "stackgroup": null }, { "mode": "markers", "name": "500B-50S", "type": "scatter", "xsrc": "caijun:6:33afa8", "ysrc": "caijun:6:c58822", "stackgroup": null }, { "mode": "markers", "name": "500B-70S", "type": "scatter", "xsrc": "caijun:6:c59408", "ysrc": "caijun:6:3938fd", "stackgroup": null }, { "mode": "markers", "name": "500B-90S", "type": "scatter", "xsrc": "caijun:6:949706", "ysrc": "caijun:6:579396", "stackgroup": null }, { "mode": "markers", "name": "500B-110S", "type": "scatter", "xsrc": "caijun:6:5eadc4", "ysrc": "caijun:6:c9115f", "stackgroup": null }, { "mode": "markers", "name": "500B-130S", "type": "scatter", "xsrc": "caijun:6:be167e", "ysrc": "caijun:6:03fdb0", "stackgroup": null }, { "mode": "markers", "name": "500B-150S", "type": "scatter", "xsrc": "caijun:6:9add52", "ysrc": "caijun:6:7ab3c2", "stackgroup": null }, { "mode": "markers", "name": "500B-170S", "type": "scatter", "xsrc": "caijun:6:1bd07d", "ysrc": "caijun:6:a5a9ab", "stackgroup": null }, { "mode": "markers", "name": "500B-190S", "type": "scatter", "xsrc": "caijun:6:384e31", "ysrc": "caijun:6:dbda39", "stackgroup": null }, { "mode": "markers", "name": "500B-210S", "type": "scatter", "xsrc": "caijun:6:6e3277", "ysrc": "caijun:6:813092", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ -14.81637293916998, 263.81637293917 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -68.70366320393657, 1053.0896664844176 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~caijun", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-05 03:40:04", "mapbox_access_tokens": null, "has_password": null, "username": "caijun", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:57:13.632843Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~arnavobero1/8.embed", "fid": "arnavobero1:8", "filename": "Plot 8", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/arnavobero1:8/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/arnavobero1:8/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/arnavobero1:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/arnavobero1:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/arnavobero1:8", "plots": "https://api.plotly.com/v2/plots/arnavobero1:8", "parent": "https://api.plotly.com/v2/folders/home?user=arnavobero1" }, "owner": "arnavobero1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~arnavobero1/8/", "world_readable": true, "date_modified": "2019-06-18T05:57:13.647Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~arnavobero1/8/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "bar", "xsrc": "arnavobero1:7:8f79d2", "ysrc": "arnavobero1:7:0929aa", "orientation": "v" } ], "frames": [], "layout": { "scene": { "aspectmode": "auto", "aspectratio": { "x": 1, "y": 1, "z": 1 } }, "title": { "font": { "family": "Arial" }, "text": "Trending 25 Skills " }, "xaxis": { "type": "category", "range": [ -0.5, 24.5 ], "title": { "text": "" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 26.31578947368421 ], "title": { "text": "Popularity" }, "autorange": true }, "autosize": true, "colorway": [ "#1f77b4", "#ff7f0e", "#2ca02c", "#d62728", "#9467bd", "#8c564b", "#e377c2", "#7f7f7f", "#bcbd22", "#17becf" ], "plot_bgcolor": "rgb(255, 255, 255)", "paper_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~arnavobero1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-07 06:02:22", "mapbox_access_tokens": null, "has_password": null, "username": "arnavobero1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:57:00.404926Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Frankie4Figz/9.embed", "fid": "Frankie4Figz:9", "filename": "pie_signal_dipsensitive_4hr_intensity", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Frankie4Figz/9/9_8XGTDGBHIJBTMQOOESKL9E6F3UI4MU.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Frankie4Figz/9/2_FNZ9V4Q9EEO69FPW2SU5OPGYIOQKNH.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Frankie4Figz/9/8_1C9S8E4903N2E0YHTADYPZESQN46FK.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Frankie4Figz/9/9_8XGTDGBHIJBTMQOOESKL9E6F3UI4MU.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Frankie4Figz:9", "plots": "https://api.plotly.com/v2/plots/Frankie4Figz:9", "parent": "https://api.plotly.com/v2/folders/home?user=Frankie4Figz" }, "owner": "Frankie4Figz", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Frankie4Figz/9/", "world_readable": true, "date_modified": "2019-06-18T05:57:54.150Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Frankie4Figz/9/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "pie", "frame": null, "marker": { "line": { "color": "rgba(255,255,255,1)" }, "color": "rgba(31,119,180,1)" }, "labelssrc": "Frankie4Figz:8:6a137a", "valuessrc": "Frankie4Figz:8:8474fe" } ], "layout": { "title": "Variable Importance", "xaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "yaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Frankie4Figz", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/28.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:57:08", "mapbox_access_tokens": null, "has_password": null, "username": "Frankie4Figz", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:56:41.439016Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~um22/21.embed", "fid": "um22:21", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/um22:21/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/um22/21/2_F31MV70K7S3GNP6WALQ3SLE515R4YH.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/um22/21/8_X1HJIL9UQXSQUG5F8AY2XNB7816JY4.png", "list-thumb": "https://api.plotly.com/v2/files/um22:21/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/um22:21", "plots": "https://api.plotly.com/v2/plots/um22:21", "parent": "https://api.plotly.com/v2/folders/home?user=um22" }, "owner": "um22", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Icecube", "views": 0, "web_url": "https://chart-studio.plotly.com/~um22/21/icecube/", "world_readable": true, "date_modified": "2019-06-18T05:56:42.012Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~um22/21/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "00999875-4e41-45de-b58d-f22fd061d30c", "mode": "markers", "type": "scatter3d", "xsrc": "um22:22:70ec68", "ysrc": "um22:22:aa06b5", "zsrc": "um22:22:d1e664", "marker": { "size": 3 } } ], "layout": { "title": { "text": "Icecube" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~um22", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/89.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-07 13:54:40", "mapbox_access_tokens": null, "has_password": null, "username": "um22", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:56:38.508811Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~um22/19.embed", "fid": "um22:19", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/um22:19/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/um22/19/2_92IRZUV21SP20YCST7DV726IH2D8MJ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/um22/19/8_PSUSOE5AI6QBSBSLHJ4P1GTKDPJMAG.png", "list-thumb": "https://api.plotly.com/v2/files/um22:19/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/um22:19", "plots": "https://api.plotly.com/v2/plots/um22:19", "parent": "https://api.plotly.com/v2/folders/home?user=um22" }, "owner": "um22", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Icecube", "views": 1, "web_url": "https://chart-studio.plotly.com/~um22/19/icecube/", "world_readable": true, "date_modified": "2019-06-18T05:56:39.332Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~um22/19/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "5b19a84c-0b3f-4641-90b3-440e60645b72", "mode": "markers", "type": "scatter3d", "xsrc": "um22:20:1dbc82", "ysrc": "um22:20:ed4064", "zsrc": "um22:20:d7e429", "marker": { "size": 3 } } ], "layout": { "title": { "text": "Icecube" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~um22", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/89.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-07 13:54:40", "mapbox_access_tokens": null, "has_password": null, "username": "um22", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:52:20.594715Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~eonr/10.embed", "fid": "eonr:10", "filename": "2hour-imageclusters_visualized", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/eonr/10/9_SXD6IOQSUR1TANDBFSH2DS6OELEAZN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/eonr/10/2_0AWJYRHDHZ6A6B4ZSIGEC4KFLOW35D.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/eonr/10/8_C229B6AB01DRA2DBRL3VX24QJ9A0QD.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/eonr/10/9_SXD6IOQSUR1TANDBFSH2DS6OELEAZN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/eonr:10", "plots": "https://api.plotly.com/v2/plots/eonr:10", "parent": "https://api.plotly.com/v2/folders/home?user=eonr" }, "owner": "eonr", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 16, "web_url": "https://chart-studio.plotly.com/~eonr/10/", "world_readable": true, "date_modified": "2019-06-18T05:52:33.034Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~eonr/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "28c02eab-94b1-4a86-996b-d8bb1f162068", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:54abd4", "ysrc": "eonr:11:3107f0", "zsrc": "eonr:11:3487c2", "marker": { "line": { "color": "rgba(103, 231, 96, 0.8100374332716793)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "b55f78f3-3737-4dcc-9e2c-ec41ebfeeda2", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:a2d553", "ysrc": "eonr:11:5f8e9d", "zsrc": "eonr:11:004de1", "marker": { "line": { "color": "rgba(231, 165, 212, 0.6526499337437797)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "897bfce3-f454-42fb-b5e6-7c5013f97d43", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:cbc69a", "ysrc": "eonr:11:c6b8ad", "zsrc": "eonr:11:b3ac13", "marker": { "line": { "color": "rgba(21, 121, 198, 0.9144149247917768)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "c5711e04-b8f2-43db-a579-76a0adc3784b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:de8b58", "ysrc": "eonr:11:986dca", "zsrc": "eonr:11:769a93", "marker": { "line": { "color": "rgba(61, 35, 210, 0.9138646352597242)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "f9ea3183-f505-4135-99a3-6711dd66fb91", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:58f033", "ysrc": "eonr:11:cedbb6", "zsrc": "eonr:11:e36b38", "marker": { "line": { "color": "rgba(125, 231, 236, 0.31010795888800696)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "41f6bcd8-fc07-4433-8b93-e6b7e413c1db", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ef220f", "ysrc": "eonr:11:004f18", "zsrc": "eonr:11:534ed2", "marker": { "line": { "color": "rgba(56, 14, 224, 0.28749654853878187)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "46e6cb05-e6e9-4690-a32a-ccc44d45d09a", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ef3283", "ysrc": "eonr:11:231e00", "zsrc": "eonr:11:4af71a", "marker": { "line": { "color": "rgba(145, 91, 40, 0.6800786835461348)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "06a35edd-25ed-4c83-a4d7-b1b7da933097", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:eebcaf", "ysrc": "eonr:11:bcfaec", "zsrc": "eonr:11:915391", "marker": { "line": { "color": "rgba(162, 117, 141, 0.7083161734837959)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "6eb7264d-31f7-4239-ad41-0d768ffcafeb", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:a7adf9", "ysrc": "eonr:11:c92c08", "zsrc": "eonr:11:4707fc", "marker": { "line": { "color": "rgba(139, 157, 58, 0.6542120319835598)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "23d0ff0c-883f-4a33-9448-216598b979ed", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:af0b0c", "ysrc": "eonr:11:1da0be", "zsrc": "eonr:11:c3a38e", "marker": { "line": { "color": "rgba(198, 24, 109, 0.6856342583541579)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "7359981d-6e39-4f2a-8f6c-51c30491cb7b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:d27abd", "ysrc": "eonr:11:3f10bb", "zsrc": "eonr:11:36d70c", "marker": { "line": { "color": "rgba(47, 249, 114, 0.33757170534156467)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "a7ae3562-6c9a-4d8e-af61-50625ee24a32", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:8e95c8", "ysrc": "eonr:11:5e1375", "zsrc": "eonr:11:72d989", "marker": { "line": { "color": "rgba(55, 111, 14, 0.27758602079983224)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "02a801b0-4612-456d-b85a-9d4a002f3c29", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:4000e5", "ysrc": "eonr:11:d7dc3b", "zsrc": "eonr:11:61146a", "marker": { "line": { "color": "rgba(144, 215, 92, 0.5896830471876842)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "d0507519-fd38-41df-92f1-2a40ad5da535", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:600a57", "ysrc": "eonr:11:7afd3a", "zsrc": "eonr:11:09a7c0", "marker": { "line": { "color": "rgba(15, 99, 205, 0.6108498430709346)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "383492e7-68d0-4b9f-ba54-6f633d7a9e3b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:fa557c", "ysrc": "eonr:11:0d4eb0", "zsrc": "eonr:11:03fe71", "marker": { "line": { "color": "rgba(109, 120, 88, 0.5157210514047723)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "0e785b32-9574-4d56-9e91-44ceb6710281", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:19fcba", "ysrc": "eonr:11:42ca96", "zsrc": "eonr:11:ccaee0", "marker": { "line": { "color": "rgba(70, 50, 248, 0.3362486409796178)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "e29ec035-e969-4e4c-81ff-299e4600097d", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:fb6803", "ysrc": "eonr:11:fd98a5", "zsrc": "eonr:11:6f5254", "marker": { "line": { "color": "rgba(38, 196, 229, 0.8886932239188525)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "f76f08de-3af7-4fe6-85f3-fed484cb01bc", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:108c73", "ysrc": "eonr:11:54530c", "zsrc": "eonr:11:71c09a", "marker": { "line": { "color": "rgba(247, 181, 228, 0.21064277634601042)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "09b3fce5-4ef8-40e6-b41a-629d0cdd3233", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5572f9", "ysrc": "eonr:11:708867", "zsrc": "eonr:11:a66e3d", "marker": { "line": { "color": "rgba(62, 78, 90, 0.34125293116346944)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "31ef71a4-e9a8-4a09-9acd-ccbecf23c2c8", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:f2affe", "ysrc": "eonr:11:4e9b3e", "zsrc": "eonr:11:8bf710", "marker": { "line": { "color": "rgba(25, 139, 226, 0.7047303813262751)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "20da435a-27aa-4631-bde9-a4c26901ec6d", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ac1361", "ysrc": "eonr:11:d2e58d", "zsrc": "eonr:11:668133", "marker": { "line": { "color": "rgba(19, 174, 151, 0.9733184434434203)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "2d2c49f7-0966-40e1-8762-1e7fd32f8102", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:0adb07", "ysrc": "eonr:11:789cde", "zsrc": "eonr:11:489020", "marker": { "line": { "color": "rgba(49, 9, 83, 0.8160005442271561)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "33ee84f4-7025-459f-8c70-2c0f0174d235", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5f4905", "ysrc": "eonr:11:37c1ce", "zsrc": "eonr:11:d56a35", "marker": { "line": { "color": "rgba(178, 85, 33, 0.7421000433513525)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "37d4f1ec-5973-45d9-a69f-3f03a809e2c7", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:d9efd2", "ysrc": "eonr:11:267247", "zsrc": "eonr:11:43f0f2", "marker": { "line": { "color": "rgba(157, 113, 249, 0.9814258474187763)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "6a59f220-7aa4-427e-9c2f-9f6734ffb621", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:d04137", "ysrc": "eonr:11:8c0e72", "zsrc": "eonr:11:bcb9e6", "marker": { "line": { "color": "rgba(3, 24, 75, 0.3825052572226915)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "14841430-c291-4dba-90d7-3584d44ef4c8", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:cc4b1c", "ysrc": "eonr:11:26e90c", "zsrc": "eonr:11:9cb585", "marker": { "line": { "color": "rgba(208, 18, 51, 0.7889413512461709)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "3d18ae3a-e391-492c-8c4c-f3e899d8c233", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ee9256", "ysrc": "eonr:11:ddd42a", "zsrc": "eonr:11:3f702c", "marker": { "line": { "color": "rgba(143, 41, 202, 0.2223147499640281)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "90d7ec12-ddd1-4545-8efa-6306b2a38896", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:b546d2", "ysrc": "eonr:11:da4a60", "zsrc": "eonr:11:d23d60", "marker": { "line": { "color": "rgba(34, 59, 172, 0.2389757669617282)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "c0d46343-db32-45ed-9a27-8b7b4d96030b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:026c50", "ysrc": "eonr:11:506f5d", "zsrc": "eonr:11:0acec5", "marker": { "line": { "color": "rgba(148, 51, 52, 0.4054034767843561)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "64a850cd-6962-464d-892b-e90617056846", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:b2af61", "ysrc": "eonr:11:542fe3", "zsrc": "eonr:11:e40368", "marker": { "line": { "color": "rgba(237, 77, 115, 0.5538658777227619)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "c6190862-aa21-4047-a1ce-62370783f355", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ab7ff6", "ysrc": "eonr:11:cf4ce7", "zsrc": "eonr:11:d56a35", "marker": { "line": { "color": "rgba(187, 28, 221, 0.8931957385356579)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "5f82f7ca-3656-4c19-8fe0-80fc636c63b2", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:35f536", "ysrc": "eonr:11:d65f49", "zsrc": "eonr:11:7e9f26", "marker": { "line": { "color": "rgba(154, 26, 146, 0.5687998501206595)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "10816f2c-2f0a-4954-a44f-f734e644dbbb", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:95bd2c", "ysrc": "eonr:11:4994c3", "zsrc": "eonr:11:3b4ef0", "marker": { "line": { "color": "rgba(197, 133, 220, 0.384248100610832)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "9386287c-f08c-4fa1-a874-295aec392622", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:6239aa", "ysrc": "eonr:11:a04523", "zsrc": "eonr:11:614417", "marker": { "line": { "color": "rgba(196, 239, 234, 0.2502510990894502)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "4eee103e-4cfd-46ee-a590-9ab7e8e3d80b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:928dc8", "ysrc": "eonr:11:228b34", "zsrc": "eonr:11:9d74cf", "marker": { "line": { "color": "rgba(114, 16, 128, 0.2768724762422977)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "297c29fd-baf5-421b-afaf-60d3039e574a", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5ad02b", "ysrc": "eonr:11:802f82", "zsrc": "eonr:11:d91197", "marker": { "line": { "color": "rgba(144, 29, 14, 0.9860854837071007)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "0270c153-bf2d-4dbb-8795-28c63100b825", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:53ebf9", "ysrc": "eonr:11:26e5f1", "zsrc": "eonr:11:9d2e57", "marker": { "line": { "color": "rgba(22, 173, 140, 0.5873177828699652)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "a6d4e4fc-a48a-42a9-a3f3-f7642102c434", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:b092cd", "ysrc": "eonr:11:6d76e3", "zsrc": "eonr:11:b5ec87", "marker": { "line": { "color": "rgba(71, 135, 147, 0.7537289406959975)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "05e7cbf3-f21a-491a-b73f-8683c9a6fe1c", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:3ee765", "ysrc": "eonr:11:29f37e", "zsrc": "eonr:11:d68285", "marker": { "line": { "color": "rgba(37, 64, 213, 0.4567352149081425)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "0b70c0f2-3a85-4637-8088-e1747ae7a6fb", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:bd3607", "ysrc": "eonr:11:73cfb0", "zsrc": "eonr:11:c1aa15", "marker": { "line": { "color": "rgba(102, 226, 153, 0.5170179917399311)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "6d942f63-6aa0-457e-90de-63a8fc8ef559", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:bfc20c", "ysrc": "eonr:11:8fa95f", "zsrc": "eonr:11:a2abf1", "marker": { "line": { "color": "rgba(99, 235, 200, 0.9382293523145149)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "0e9d6e47-cfdb-4210-b231-d00c0de76c10", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:0909c4", "ysrc": "eonr:11:d6acbd", "zsrc": "eonr:11:8f5539", "marker": { "line": { "color": "rgba(223, 8, 124, 0.3318122236572526)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "26a13349-b4d0-43aa-aad3-1fe8c59e472c", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:7e2549", "ysrc": "eonr:11:961be0", "zsrc": "eonr:11:523031", "marker": { "line": { "color": "rgba(16, 88, 91, 0.9086787988230851)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "cfa4b230-10e3-42f7-b027-1f52f281b3aa", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:4a79e4", "ysrc": "eonr:11:bd65d1", "zsrc": "eonr:11:c56693", "marker": { "line": { "color": "rgba(131, 8, 187, 0.8371804811552679)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "8f42a44d-d46d-42d7-984d-dfd6299e187a", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:c0142f", "ysrc": "eonr:11:6c1f33", "zsrc": "eonr:11:432e69", "marker": { "line": { "color": "rgba(87, 58, 185, 0.8913881698040067)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "20743dab-1b31-4275-a8ba-69c61d82558d", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:cf042c", "ysrc": "eonr:11:ab2d15", "zsrc": "eonr:11:eb51f1", "marker": { "line": { "color": "rgba(63, 142, 133, 0.7593476075623637)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "1c15261e-9f90-4abd-9387-591f69be28ef", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:fc3786", "ysrc": "eonr:11:40beb9", "zsrc": "eonr:11:48312f", "marker": { "line": { "color": "rgba(92, 33, 3, 0.6782561076134159)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "695cc195-2ba9-4635-a242-3ab50ca434f2", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:379d72", "ysrc": "eonr:11:1b7f70", "zsrc": "eonr:11:500582", "marker": { "line": { "color": "rgba(25, 236, 128, 0.6056502442803315)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "fabe28cd-8a10-4898-af25-fb163764a6a0", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:00e80b", "ysrc": "eonr:11:9dd906", "zsrc": "eonr:11:b1aa64", "marker": { "line": { "color": "rgba(146, 116, 5, 0.4388485436001454)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "268d24ff-4c27-45ac-9c97-65bda13e5c2f", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:fef084", "ysrc": "eonr:11:51b67a", "zsrc": "eonr:11:2477fb", "marker": { "line": { "color": "rgba(186, 253, 155, 0.4065928775426677)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "dcd14997-168d-4ccc-9f92-1ae23e13f8aa", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:4bd894", "ysrc": "eonr:11:0624b9", "zsrc": "eonr:11:eb625e", "marker": { "line": { "color": "rgba(54, 183, 83, 0.2792866815136214)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "07dbd650-ae67-4766-a543-445a6f936942", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:f80d01", "ysrc": "eonr:11:cab8ec", "zsrc": "eonr:11:9d8c37", "marker": { "line": { "color": "rgba(231, 12, 28, 0.46931182093132684)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "00323480-06ff-4809-b56c-a5e7875344ea", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:58da72", "ysrc": "eonr:11:10a7f9", "zsrc": "eonr:11:fbd8c6", "marker": { "line": { "color": "rgba(191, 129, 206, 0.3937741574377649)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "08d564d0-f382-44b2-b738-10a87914c221", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:b461e6", "ysrc": "eonr:11:c5765a", "zsrc": "eonr:11:b1e3ea", "marker": { "line": { "color": "rgba(59, 230, 123, 0.9706576775967466)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "d5059d88-7a5f-4ad3-bce1-55a0b239d891", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:c2b0db", "ysrc": "eonr:11:fe8c5d", "zsrc": "eonr:11:10a96a", "marker": { "line": { "color": "rgba(242, 162, 196, 0.8956737986329775)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "d0631c31-2be3-46bb-a9f0-04626bc0d290", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:536620", "ysrc": "eonr:11:1fb10d", "zsrc": "eonr:11:d9df8e", "marker": { "line": { "color": "rgba(224, 44, 187, 0.40689223462557345)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "3df8c861-d504-402a-a8f2-151598e4b523", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:f5adee", "ysrc": "eonr:11:3219b6", "zsrc": "eonr:11:b56c21", "marker": { "line": { "color": "rgba(23, 100, 146, 0.650767874216021)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "1ae98b0d-f4bc-4ea8-a8a3-6d6ec0d0a222", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:535467", "ysrc": "eonr:11:3f6c06", "zsrc": "eonr:11:589137", "marker": { "line": { "color": "rgba(70, 212, 187, 0.9512964753623971)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "fbe8823a-31c3-4286-83dc-be6dd8dc498e", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:e29f13", "ysrc": "eonr:11:80c1b4", "zsrc": "eonr:11:41adc4", "marker": { "line": { "color": "rgba(165, 24, 213, 0.738471422704909)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "d8a3fd29-9c99-4e37-9ea0-43e8e3b26f70", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:85b82b", "ysrc": "eonr:11:ad3896", "zsrc": "eonr:11:bc13e4", "marker": { "line": { "color": "rgba(201, 102, 6, 0.7092807484836416)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "f23cf120-a94d-443c-8cb1-59b46c789576", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:2c89d2", "ysrc": "eonr:11:0f0a0a", "zsrc": "eonr:11:190ed9", "marker": { "line": { "color": "rgba(37, 33, 203, 0.5092062523672005)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "495219f2-3072-4e46-a481-ee649a1e40ba", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:ba1858", "ysrc": "eonr:11:2f5b6c", "zsrc": "eonr:11:944874", "marker": { "line": { "color": "rgba(172, 178, 64, 0.9096374242403176)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "cbf51ded-6859-4df4-a124-7c1b065be015", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:deaf77", "ysrc": "eonr:11:a998ca", "zsrc": "eonr:11:9e9ef4", "marker": { "line": { "color": "rgba(57, 89, 99, 0.9056943282115097)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "4d17ca0e-dd1e-423a-bfe6-c050291ce395", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:4dc7a6", "ysrc": "eonr:11:dc3f03", "zsrc": "eonr:11:e9007c", "marker": { "line": { "color": "rgba(93, 134, 34, 0.7579314243846214)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "c3616cf2-29d9-4716-b865-7e706b654788", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5e0e46", "ysrc": "eonr:11:a6b823", "zsrc": "eonr:11:fb3393", "marker": { "line": { "color": "rgba(183, 145, 73, 0.30695363852519764)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "76799575-9335-4436-a321-7220e3c31f1b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:b092be", "ysrc": "eonr:11:4253e7", "zsrc": "eonr:11:e51199", "marker": { "line": { "color": "rgba(16, 50, 229, 0.7927796156782725)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "e8343786-4a52-45d2-ab2d-560e2eec6c8e", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:f8c0f5", "ysrc": "eonr:11:c61d33", "zsrc": "eonr:11:517349", "marker": { "line": { "color": "rgba(45, 81, 146, 0.2841639382160824)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "614c457b-ccb3-4b1a-8dab-6134a76f6a12", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:196d14", "ysrc": "eonr:11:f62fef", "zsrc": "eonr:11:fdfc71", "marker": { "line": { "color": "rgba(28, 0, 76, 0.3409676122982993)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "6bbad2e0-5260-4015-ba3b-40bc4acd0cf5", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5c844c", "ysrc": "eonr:11:6032de", "zsrc": "eonr:11:875031", "marker": { "line": { "color": "rgba(77, 118, 146, 0.9937787019550659)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "39eaaae7-51ae-4df2-b79c-347b07fee614", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:afa1de", "ysrc": "eonr:11:b745f4", "zsrc": "eonr:11:25aa03", "marker": { "line": { "color": "rgba(72, 193, 153, 0.4921444925628765)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "33a7ddec-ea94-4a90-888f-7c1218275d95", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:493e32", "ysrc": "eonr:11:0136eb", "zsrc": "eonr:11:4c4f17", "marker": { "line": { "color": "rgba(246, 242, 137, 0.45925615267094266)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "9fa8690c-6543-4648-939a-8fe40b43d809", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:5ad897", "ysrc": "eonr:11:3d88f1", "zsrc": "eonr:11:f6fdf4", "marker": { "line": { "color": "rgba(46, 142, 174, 0.8808114356561485)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "2af44109-ef8b-4434-9d84-497abdd5eeac", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:d10942", "ysrc": "eonr:11:516eda", "zsrc": "eonr:11:73eeb3", "marker": { "line": { "color": "rgba(123, 241, 101, 0.7445808303891)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "b028e1ab-a980-462d-9b0b-bad6a15355fd", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:46b8fc", "ysrc": "eonr:11:a96a08", "zsrc": "eonr:11:831ea0", "marker": { "line": { "color": "rgba(181, 197, 139, 0.7814733077426477)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "bbe826a0-e3ad-46a2-a00d-62d3d526c47b", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:16fb01", "ysrc": "eonr:11:328f7f", "zsrc": "eonr:11:f98ea8", "marker": { "line": { "color": "rgba(9, 176, 144, 0.6950288196203385)", "width": 0.5 }, "size": 12, "opacity": 0.8 } }, { "uid": "ac44c253-3090-40f3-921b-822fb0b9626e", "mode": "markers", "type": "scatter3d", "xsrc": "eonr:11:870afd", "ysrc": "eonr:11:3324bf", "zsrc": "eonr:11:218862", "marker": { "line": { "color": "rgba(216, 37, 239, 0.9172922653609688)", "width": 0.5 }, "size": 12, "opacity": 0.8 } } ], "layout": { "margin": { "b": 0, "l": 0, "r": 0, "t": 0 } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~eonr", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/83.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 12:45:49", "mapbox_access_tokens": null, "has_password": null, "username": "eonr", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:52:07.593815Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~annaskobeleva/2.embed", "fid": "annaskobeleva:2", "filename": "test_nw", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/annaskobeleva:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/annaskobeleva:2/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/annaskobeleva/2/8_YLHDJEJ4X2LGCJYW8KBGELAXZ52SKN.png", "list-thumb": "https://api.plotly.com/v2/files/annaskobeleva:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/annaskobeleva:2", "plots": "https://api.plotly.com/v2/plots/annaskobeleva:2", "parent": "https://api.plotly.com/v2/folders/home?user=annaskobeleva" }, "owner": "annaskobeleva", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~annaskobeleva/2/", "world_readable": true, "date_modified": "2019-06-19T01:00:54.689Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~annaskobeleva/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "25ee7ac5-4e1d-4c76-a519-cd88a86ed345", "line": { "color": "#888", "width": 0.5 }, "mode": "lines", "type": "scatter", "xsrc": "annaskobeleva:3:55d05b", "ysrc": "annaskobeleva:3:8c7603" }, { "uid": "739f3e6b-320c-4f6f-a0b0-ad1277cbac28", "line": { "width": 2 }, "mode": "markers", "type": "scatter", "xsrc": "annaskobeleva:3:c54588", "ysrc": "annaskobeleva:3:2bcfe2" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~annaskobeleva", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 05:08:08", "mapbox_access_tokens": null, "has_password": null, "username": "annaskobeleva", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:49:54.552732Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~babit13/13.embed", "fid": "babit13:13", "filename": "Plot 13", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/babit13:13/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/babit13/13/2_4P6FI63QFZYL1GC5SCURZJZFUCHUKU.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/babit13/13/8_35QLI5FY7P3MHT9QRA4X3XDQSLKJ8W.png", "list-thumb": "https://api.plotly.com/v2/files/babit13:13/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/babit13:13", "plots": "https://api.plotly.com/v2/plots/babit13:13", "parent": "https://api.plotly.com/v2/folders/home?user=babit13" }, "owner": "babit13", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 12, "web_url": "https://chart-studio.plotly.com/~babit13/13/", "world_readable": true, "date_modified": "2019-06-18T09:29:20.865Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~babit13/13/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "0", "text": "", "type": "scatter", "xsrc": "babit13:12:7754c0", "ysrc": "babit13:12:8fdf2e", "visible": "legendonly" }, { "line": { "dash": "solid", "color": "rgba(55, 128, 191, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "Forecast", "text": "", "type": "scatter", "xsrc": "babit13:12:7754c0", "ysrc": "babit13:12:4f33ec", "visible": true } ], "frames": [], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "type": "date", "range": [ "1982-09-30", "1994-03-01" ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "type": "linear", "range": [ 14357.676689959892, 18017.055247728167 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "autosize": true, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~babit13", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/67.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 05:17:06", "mapbox_access_tokens": null, "has_password": null, "username": "babit13", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:48:36.611239Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~babit13/11.embed", "fid": "babit13:11", "filename": "Plot 11", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/babit13:11/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/babit13:11/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/babit13/11/8_XHQ0HX5S3GZNV18ADFRZE7VI685F6Y.png", "list-thumb": "https://api.plotly.com/v2/files/babit13:11/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/babit13:11", "plots": "https://api.plotly.com/v2/plots/babit13:11", "parent": "https://api.plotly.com/v2/folders/home?user=babit13" }, "owner": "babit13", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 14, "web_url": "https://chart-studio.plotly.com/~babit13/11/", "world_readable": true, "date_modified": "2019-06-18T05:48:36.629Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~babit13/11/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "1992", "text": "", "type": "scatter", "xsrc": "babit13:10:1c0eb5", "ysrc": "babit13:10:2ee8e6" }, { "line": { "dash": "solid", "color": "rgba(55, 128, 191, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "1993", "text": "", "type": "scatter", "xsrc": "babit13:10:1c0eb5", "ysrc": "babit13:10:59500a" }, { "line": { "dash": "solid", "color": "rgba(50, 171, 96, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "1994", "text": "", "type": "scatter", "xsrc": "babit13:10:1c0eb5", "ysrc": "babit13:10:3f2fce" } ], "frames": [], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "type": "category", "range": [ 0, 11 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "type": "linear", "range": [ 14357.676689959892, 18017.055247728167 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "autosize": true, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~babit13", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/67.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 05:17:06", "mapbox_access_tokens": null, "has_password": null, "username": "babit13", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T05:48:11.536716Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~um22/17.embed", "fid": "um22:17", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/um22:17/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/um22:17/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/um22:17/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/um22:17/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/um22:17", "plots": "https://api.plotly.com/v2/plots/um22:17", "parent": "https://api.plotly.com/v2/folders/home?user=um22" }, "owner": "um22", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Icecube", "views": 0, "web_url": "https://chart-studio.plotly.com/~um22/17/icecube/", "world_readable": true, "date_modified": "2019-06-18T05:48:12.081Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~um22/17/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "bfe3f06a-7154-43a1-ad06-b79d2e19cae5", "mode": "markers", "type": "scatter3d", "xsrc": "um22:18:712f94", "ysrc": "um22:18:ed9989", "zsrc": "um22:18:45284e", "marker": { "size": 3 } } ], "layout": { "title": { "text": "Icecube" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~um22", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/89.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-07 13:54:40", "mapbox_access_tokens": null, "has_password": null, "username": "um22", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
