Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xOCswNCUzQTQwJTNBMDAuMjM1MjQzJTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE4KzA0JTNBNDAlM0E1Ny4zNjM1OTclMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xOCswNCUzQTQ5JTNBMzUuNTc0ODU2JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-18T04:49:35.574856Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~eduard.c./1.embed", "fid": "eduard.c.:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/eduard.c.:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/eduard.c./1/2_J28ALIH0X42TOZ9G932FXO5NM7NJV7.png", "block-thumb": "https://api.plotly.com/v2/files/eduard.c.:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/eduard.c.:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/eduard.c.:1", "plots": "https://api.plotly.com/v2/plots/eduard.c.:1", "parent": "https://api.plotly.com/v2/folders/home?user=eduard.c." }, "owner": "eduard.c.", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~eduard.c./1/", "world_readable": true, "date_modified": "2019-06-18T05:07:17.582Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~eduard.c./1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(234, 132, 124)" }, "mode": "markers+lines", "name": "% of third parties who punish", "type": "scatter", "xsrc": "eduard.c.:0:546dc8", "ysrc": "eduard.c.:0:bec435", "marker": { "size": 12, "symbol": "diamond" }, "showlegend": true }, { "mode": "markers+lines", "name": "% of receivers who believe that third parties punish", "type": "scatter", "xsrc": "eduard.c.:0:546dc8", "ysrc": "eduard.c.:0:29a606", "marker": { "size": 12, "color": "rgb(40, 165, 199)", "symbol": "square" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Figure 1: Percentage of third parties who punish in the dictator game" }, "xaxis": { "type": "linear", "range": [ -2.256916178547364, 51.09670115660268 ], "title": { "text": "Dictator's transfer to recipient" }, "autorange": false, "showspikes": true }, "yaxis": { "type": "linear", "range": [ 0.03369734764395815, 1.022319840555355 ], "title": { "text": "Percentage of punishers" }, "autorange": false, "showspikes": true }, "legend": { "x": 0, "y": -1.734723475976807e-17, "font": { "family": "Balto" }, "valign": "top", "xanchor": "left", "yanchor": "bottom", "itemsizing": "trace", "traceorder": "reversed", "orientation": "h" }, "modebar": { "bgcolor": "rgba(255, 255, 255, 0.5)" }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "rgb(237,237,237)" }, "line": { "color": "white" } }, "header": { "fill": { "color": "rgb(217,217,217)" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(51,51,51)", "minorgridcolor": "white", "startlinecolor": "rgb(51,51,51)" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(51,51,51)", "minorgridcolor": "white", "startlinecolor": "rgb(51,51,51)" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "len": 0.2, "ticks": "inside", "ticklen": 6, "tickcolor": "rgb(237,237,237)", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "rgb(237,237,237)", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "rgb(51,51,51)" }, "polar": { "bgcolor": "rgb(237,237,237)", "radialaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)" }, "angularaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)" } }, "scene": { "xaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "tickcolor": "rgb(51,51,51)", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(237,237,237)" }, "yaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "tickcolor": "rgb(51,51,51)", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(237,237,237)" }, "zaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "tickcolor": "rgb(51,51,51)", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(237,237,237)" } }, "xaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)", "automargin": true, "zerolinecolor": "white" }, "yaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)", "automargin": true, "zerolinecolor": "white" }, "ternary": { "aaxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)" }, "baxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)" }, "caxis": { "ticks": "outside", "showgrid": true, "gridcolor": "white", "linecolor": "white", "tickcolor": "rgb(51,51,51)" }, "bgcolor": "rgb(237,237,237)" }, "colorway": [ "#F8766D", "#A3A500", "#00BF7D", "#00B0F6", "#E76BF3" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#40004b" ], [ 0.1, "#762a83" ], [ 0.2, "#9970ab" ], [ 0.3, "#c2a5cf" ], [ 0.4, "#e7d4e8" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#d9f0d3" ], [ 0.7, "#a6dba0" ], [ 0.8, "#5aae61" ], [ 0.9, "#1b7837" ], [ 1, "#00441b" ] ], "sequential": [ [ 0, "rgb(20,44,66)" ], [ 1, "rgb(90,179,244)" ] ], "sequentialminus": [ [ 0, "rgb(20,44,66)" ], [ 1, "rgb(90,179,244)" ] ] }, "plot_bgcolor": "rgb(237,237,237)", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.3, "fillcolor": "black" }, "annotationdefaults": { "arrowhead": 0, "arrowwidth": 1 } }, "themeRef": "GGPLOT2" }, "showlegend": true, "plot_bgcolor": "rgb(237, 237, 237)", "paper_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~eduard.c.", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/22.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:49:12", "mapbox_access_tokens": null, "has_password": null, "username": "eduard.c.", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:45:19.747597Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~untitled/2.embed", "fid": "untitled:2", "filename": "normality-QQ", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/untitled:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/untitled:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/untitled:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/untitled:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/untitled:2", "plots": "https://api.plotly.com/v2/plots/untitled:2", "parent": "https://api.plotly.com/v2/folders/home?user=untitled" }, "owner": "untitled", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Quantile-Quantile Plot", "views": 0, "web_url": "https://chart-studio.plotly.com/~untitled/2/quantile-quantile-plot/", "world_readable": true, "date_modified": "2019-06-18T04:45:20.298Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~untitled/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "99ebc9fe-5717-43e2-ab03-5b085e415ebf", "mode": "markers", "type": "scatter", "xsrc": "untitled:3:2c5f68", "ysrc": "untitled:3:0d7b3d", "marker": { "color": "#19d3f3" } }, { "uid": "bc809d59-0114-4dea-8f60-45d43a55f67d", "line": { "color": "#636efa" }, "mode": "lines", "type": "scatter", "xsrc": "untitled:3:2c5f68", "ysrc": "untitled:3:095535" } ], "layout": { "title": { "text": "Quantile-Quantile Plot" }, "width": 800, "xaxis": { "title": { "text": "Theoritical Quantities" }, "zeroline": false }, "yaxis": { "title": { "text": "Sample Quantities" } }, "height": 700, "showlegend": false } }, "height": 700, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~untitled", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/53.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:42:19", "mapbox_access_tokens": null, "has_password": null, "username": "untitled", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:44:31.556655Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~maoyujun/4.embed", "fid": "maoyujun:4", "filename": "line-mode", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/maoyujun:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/maoyujun:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/maoyujun:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/maoyujun:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/maoyujun:4", "plots": "https://api.plotly.com/v2/plots/maoyujun:4", "parent": "https://api.plotly.com/v2/folders/home?user=maoyujun" }, "owner": "maoyujun", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Beijing, Shanghai, Guangzhou, Shenyang, Chengdu", "views": 1, "web_url": "https://chart-studio.plotly.com/~maoyujun/4/beijing-shanghai-guangzhou-shenyang-chengdu/", "world_readable": true, "date_modified": "2019-06-26T06:38:03.919Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~maoyujun/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "32df6db0-de8d-46e5-9761-3c78517e4fb2", "mode": "lines", "name": "Beijing", "type": "scatter", "xsrc": "maoyujun:5:c0a751", "ysrc": "maoyujun:5:a62d08" }, { "uid": "8e70c171-6322-4325-acf2-56c1c1e44db7", "mode": "lines", "name": "Shanghai", "type": "scatter", "xsrc": "maoyujun:5:c0a751", "ysrc": "maoyujun:5:e67f00" }, { "uid": "d67f62bb-0b44-465f-8d36-8b63fd31fbe6", "mode": "lines", "name": "Guangzhou", "type": "scatter", "xsrc": "maoyujun:5:c0a751", "ysrc": "maoyujun:5:df031a" }, { "uid": "f5bb8f78-54da-4625-9855-8add44c36fd9", "mode": "lines", "name": "Shenyang", "type": "scatter", "xsrc": "maoyujun:5:c0a751", "ysrc": "maoyujun:5:a567ee" }, { "uid": "9a8f0fa4-b723-415e-9ea5-329b61073054", "mode": "lines", "name": "Chengdu", "type": "scatter", "xsrc": "maoyujun:5:c0a751", "ysrc": "maoyujun:5:4238fe" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~maoyujun", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/19.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:12:13", "mapbox_access_tokens": null, "has_password": null, "username": "maoyujun", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:43:55.874405Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/109.embed", "fid": "dangnguyen:109", "filename": "Plotly Playground 2019-06-18 04:43:54", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dangnguyen:109/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/109/2_GOWARQ0WXKZLWJTGC7EOVCWWPDKKFS.png", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:109/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/dangnguyen:109/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:109", "plots": "https://api.plotly.com/v2/plots/dangnguyen:109", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~dangnguyen/109/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-18T04:43:56.502Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/109/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e30688d8-7b9e-48fd-b42b-0a4e9d25023c", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "2", "text": "", "type": "scatter", "xsrc": "dangnguyen:110:5e9346", "ysrc": "dangnguyen:110:2378e3" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:43:44.537559Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/107.embed", "fid": "dangnguyen:107", "filename": "Plotly Playground 2019-06-18 04:43:42", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dangnguyen:107/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/107/2_BW545B1BPVG1EUDAYG9FMVXB0T3P1N.png", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:107/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/dangnguyen:107/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:107", "plots": "https://api.plotly.com/v2/plots/dangnguyen:107", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 1, "web_url": "https://chart-studio.plotly.com/~dangnguyen/107/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-18T04:43:45.172Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/107/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f4fd82ea-fbe2-4854-bd6f-2012a877d377", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "0", "text": "", "type": "scatter", "xsrc": "dangnguyen:108:ea5b05", "ysrc": "dangnguyen:108:9a4204" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:43:26.749265Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~untitled/0.embed", "fid": "untitled:0", "filename": "normality-histogram", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/untitled:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/untitled:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/untitled:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/untitled:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/untitled:0", "plots": "https://api.plotly.com/v2/plots/untitled:0", "parent": "https://api.plotly.com/v2/folders/home?user=untitled" }, "owner": "untitled", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~untitled/0/", "world_readable": true, "date_modified": "2019-06-18T04:43:27.224Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~untitled/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b961f896-dd6a-447c-ab51-e0adc86867c0", "type": "histogram", "xsrc": "untitled:1:e8088e" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~untitled", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/53.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:42:19", "mapbox_access_tokens": null, "has_password": null, "username": "untitled", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:42:44.663605Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/103.embed", "fid": "dangnguyen:103", "filename": "Plotly Playground 2019-06-18 04:42:42", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dangnguyen:103/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/dangnguyen:103/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:103/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/dangnguyen:103/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:103", "plots": "https://api.plotly.com/v2/plots/dangnguyen:103", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~dangnguyen/103/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-18T04:42:45.346Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/103/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9c7ce140-c239-4bf3-8a77-f47da119ff2a", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "0", "text": "", "type": "scatter", "xsrc": "dangnguyen:104:6938dd", "ysrc": "dangnguyen:104:ce0f2f" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:42:33.692477Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dvahmedt/18.embed", "fid": "dvahmedt:18", "filename": "P3a_Asz", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dvahmedt:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/dvahmedt:18/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/dvahmedt/18/8_782772NB5MBR38YXZJMTLNA032BN2P.png", "list-thumb": "https://api.plotly.com/v2/files/dvahmedt:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dvahmedt:18", "plots": "https://api.plotly.com/v2/plots/dvahmedt:18", "parent": "https://api.plotly.com/v2/folders/home?user=dvahmedt" }, "owner": "dvahmedt", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Journeys (Analysis per 0.2 seconds)", "views": 0, "web_url": "https://chart-studio.plotly.com/~dvahmedt/18/journeys-analysis-per-02-seconds/", "world_readable": true, "date_modified": "2019-06-18T04:44:34.949Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dvahmedt/18/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "55075562-7093-48b3-a90b-d18356b58cbd", "line": { "width": 0 }, "mode": "lines+markers", "name": "Lower Bound", "type": "scatter", "xsrc": "dvahmedt:19:c59312", "ysrc": "dvahmedt:19:3fdd14", "marker": { "color": "#444" }, "showlegend": false }, { "uid": "4990f8d5-d168-4727-a6d3-ddd5a0f323b4", "fill": "tonexty", "line": { "color": "rgb(0, 0, 0)" }, "mode": "lines+markers", "name": "Mean MMN Peak Amplitude (ASz)", "type": "scatter", "xsrc": "dvahmedt:19:c59312", "ysrc": "dvahmedt:19:371bbc", "fillcolor": "rgba(146, 214, 139, 0.3)", "showlegend": true }, { "uid": "5f29552d-0c45-4de6-8c3b-cc96c02a56b9", "fill": "tonexty", "line": { "width": 0 }, "mode": "lines+markers", "name": "Upper Bound", "type": "scatter", "xsrc": "dvahmedt:19:c59312", "ysrc": "dvahmedt:19:80ef7b", "marker": { "color": "#444" }, "fillcolor": "rgba(146, 214, 139, 0.3)", "showlegend": false }, { "uid": "d84c852c-f0cb-4beb-b0d6-0e81815350bc", "line": { "width": 0 }, "mode": "lines+markers", "name": "Lower Bound2", "type": "scatter", "xsrc": "dvahmedt:19:aa59e4", "ysrc": "dvahmedt:19:7708d9", "marker": { "color": "#444" }, "showlegend": false }, { "uid": "3314ec60-54b1-4450-8c25-12f624c12872", "fill": "tonexty", "line": { "color": "rgb(0, 0, 0)" }, "mode": "lines+markers", "name": "Mean MMN Peak Amplitude (TD)", "type": "scatter", "xsrc": "dvahmedt:19:aa59e4", "ysrc": "dvahmedt:19:622d8c", "fillcolor": "rgba(0,176,246,0.2)" }, { "uid": "89854f36-b01b-4d10-9725-f06e5ce02230", "fill": "tonexty", "line": { "width": 0 }, "mode": "lines+markers", "name": "Upper Bound2", "type": "scatter", "xsrc": "dvahmedt:19:aa59e4", "ysrc": "dvahmedt:19:b74374", "marker": { "color": "#444" }, "fillcolor": "rgba(0,176,246,0.2)", "showlegend": false } ], "frames": [], "layout": { "title": { "text": "Journeys (Analysis per 0.2 seconds)" }, "xaxis": { "type": "category", "range": [ -0.5505868069607447, 9.550586806960744 ], "tickfont": { "size": 17, "family": "Times New Roman" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -2.6265605483020575, 7.023127667747154 ], "title": { "text": "Mean MMN Peak Amplitude$\\mu V$V" }, "autorange": true }, "legend": { "orientation": "h" }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dvahmedt", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-21 01:17:20", "mapbox_access_tokens": null, "has_password": null, "username": "dvahmedt", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:42:01.593463Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Houdaifa99/4.embed", "fid": "Houdaifa99:4", "filename": "df-external-source-table", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Houdaifa99:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Houdaifa99:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/Houdaifa99:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/Houdaifa99:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Houdaifa99:4", "plots": "https://api.plotly.com/v2/plots/Houdaifa99:4", "parent": "https://api.plotly.com/v2/folders/home?user=Houdaifa99" }, "owner": "Houdaifa99", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Houdaifa99/4/", "world_readable": true, "date_modified": "2019-06-18T04:44:42.947Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Houdaifa99/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "fceafc15-a638-43ef-b0a5-21fde6a6821b", "type": "heatmap", "zsrc": "Houdaifa99:5:", "opacity": 0.75, "hoverinfo": "none", "showscale": false, "colorscale": [ [ 0, "#00083e" ], [ 0.5, "#ededee" ], [ 1, "#ffffff" ] ] } ], "layout": { "xaxis": { "dtick": 1, "tick0": -0.5, "ticks": "", "zeroline": false, "gridwidth": 2, "showticklabels": false }, "yaxis": { "dtick": 1, "tick0": 0.5, "ticks": "", "zeroline": false, "autorange": "reversed", "gridwidth": 2, "showticklabels": false }, "height": 230, "margin": { "b": 0, "l": 0, "r": 0, "t": 0 }, "annotations": [ { "x": -0.45, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>xltime</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>spread</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>traded_value</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>volatility</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>book_size</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 1, "font": { "color": "#000000" }, "text": "2015-01-02 01:10:00+01:00", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 1, "font": { "color": "#000000" }, "text": "0.1800000000000015", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 1, "font": { "color": "#000000" }, "text": "0.0", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 1, "font": { "color": "#000000" }, "text": "0.0", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 1, "font": { "color": "#000000" }, "text": "10.21", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 2, "font": { "color": "#000000" }, "text": "2015-01-02 01:15:00+01:00", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 2, "font": { "color": "#000000" }, "text": "1.3612222222222228", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 2, "font": { "color": "#000000" }, "text": "3678205.470000002", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 2, "font": { "color": "#000000" }, "text": "6.589660846814251e-05", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 2, "font": { "color": "#000000" }, "text": "1.3655000000000004", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 3, "font": { "color": "#000000" }, "text": "2015-01-02 01:20:00+01:00", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 3, "font": { "color": "#000000" }, "text": "0.018300222937707392", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 3, "font": { "color": "#000000" }, "text": "4174258.985000005", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 3, "font": { "color": "#000000" }, "text": "0.00016257828340560243", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 3, "font": { "color": "#000000" }, "text": "10.15156712905607", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 4, "font": { "color": "#000000" }, "text": "2015-01-02 01:25:00+01:00", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 4, "font": { "color": "#000000" }, "text": "0.012823974971205132", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 4, "font": { "color": "#000000" }, "text": "3100136.6", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 4, "font": { "color": "#000000" }, "text": "2.2907689133831518e-05", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 4, "font": { "color": "#000000" }, "text": "10.150755804380164", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 5, "font": { "color": "#000000" }, "text": "2015-01-02 01:30:00+01:00", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 5, "font": { "color": "#000000" }, "text": "0.012599366359147268", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 1.55, "y": 5, "font": { "color": "#000000" }, "text": "1004186.1000000004", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 2.55, "y": 5, "font": { "color": "#000000" }, "text": "1.075456252945106e-05", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 3.55, "y": 5, "font": { "color": "#000000" }, "text": "10.163744959677505", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false } ] } }, "height": 230, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Houdaifa99", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 04:35:03", "mapbox_access_tokens": null, "has_password": null, "username": "Houdaifa99", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T04:40:57.363597Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~baranidharan/32.embed", "fid": "baranidharan:32", "filename": "Plot 32", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/baranidharan:32/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/baranidharan/32/2_IUE6N4J966O1D0BMS4MVBIDCWVV9M3.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/baranidharan/32/8_HYDCOH350UVNYBQL52R1FX2MLPLPWF.png", "list-thumb": "https://api.plotly.com/v2/files/baranidharan:32/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/baranidharan:32", "plots": "https://api.plotly.com/v2/plots/baranidharan:32", "parent": "https://api.plotly.com/v2/folders/home?user=baranidharan" }, "owner": "baranidharan", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 6, "web_url": "https://chart-studio.plotly.com/~baranidharan/32/", "world_readable": true, "date_modified": "2019-06-18T04:40:57.389Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~baranidharan/32/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "7ea39f58-4a08-49b8-9b14-c57ad543e27a", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "q1", "text": "", "type": "scatter", "xsrc": "baranidharan:31:69dd0e", "ysrc": "baranidharan:31:e9f133" }, { "uid": "625e8b0f-0dbe-4b53-9356-d93c29f907d3", "line": { "dash": "solid", "color": "rgba(55, 128, 191, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "q2", "text": "", "type": "scatter", "xsrc": "baranidharan:31:69dd0e", "ysrc": "baranidharan:31:9c9d15" }, { "uid": "bed59486-f177-4521-82ea-6375e30fcf68", "line": { "dash": "solid", "color": "rgba(50, 171, 96, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "q3", "text": "", "type": "scatter", "xsrc": "baranidharan:31:69dd0e", "ysrc": "baranidharan:31:2d7271" }, { "uid": "fdd7c84b-93b9-4112-8a81-bfcf1b95d80c", "line": { "dash": "solid", "color": "rgba(128, 0, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "q4", "text": "", "type": "scatter", "xsrc": "baranidharan:31:69dd0e", "ysrc": "baranidharan:31:0379a8" } ], "frames": [], "layout": { "title": { "font": { "color": "#4D5663" }, "text": "energy production quarterly wise" }, "xaxis": { "type": "linear", "range": [ 1939, 2018 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "type": "linear", "range": [ -2.699953703703704, 119.84378703703705 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": true, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "autosize": true, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~baranidharan", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/93.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-05-23 15:04:19", "mapbox_access_tokens": null, "has_password": null, "username": "baranidharan", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
