Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTI1JTNBMzkuNDMyNzE3JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA0LTIyKzA0JTNBMjYlM0EwNS4zMzU4NzglMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTM1JTNBNTYuNTMzMTk4JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-04-22T04:35:56.533198Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~TriArdhiansa/1.embed", "fid": "TriArdhiansa:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/TriArdhiansa:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/TriArdhiansa:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/TriArdhiansa/1/8_W3NG5FZOMV1RZRBDWX73BVDM1AEGKM.png", "list-thumb": "https://api.plotly.com/v2/files/TriArdhiansa:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/TriArdhiansa:1", "plots": "https://api.plotly.com/v2/plots/TriArdhiansa:1", "parent": "https://api.plotly.com/v2/folders/home?user=TriArdhiansa" }, "owner": "TriArdhiansa", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~TriArdhiansa/1/", "world_readable": true, "date_modified": "2019-04-22T04:58:40.562Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~TriArdhiansa/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "width": 3 }, "mode": "markers", "name": "<br>", "rsrc": "TriArdhiansa:0:bd7d46", "type": "histogram", "xsrc": "TriArdhiansa:0:bd7d46", "marker": { "line": { "color": "rgb(0, 0, 0)", "width": 2 }, "color": "rgb(0, 59, 128)" }, "points": "outliers", "textsrc": "TriArdhiansa:0:bd7d46", "bandwidth": 0, "boxpoints": false, "fillcolor": "rgba(0, 69, 148, 0.5)", "hoverinfo": "x+y", "cumulative": { "enabled": false }, "orientation": "v", "hovertemplate": "", "autocolorscale": true } ], "frames": [], "layout": { "font": { "size": 18, "family": "Times New Roman" }, "polar": { "radialaxis": { "type": "linear", "range": [ 0, 618.7483870967742 ], "autorange": true }, "angularaxis": {} }, "title": { "font": { "size": 21 }, "text": "<b>Histogram Nilai TEFL Mahasiswa FTI 2018</b>" }, "xaxis": { "type": "linear", "range": [ 339.5, 619.5 ], "ticks": "outside", "title": { "font": { "size": 19 }, "text": "Nilai TEFL" }, "tickfont": { "size": 20 }, "autorange": true, "automargin": false, "showspikes": true, "rangeslider": { "range": [ 339.5, 619.5 ], "yaxis": {}, "visible": false, "autorange": true } }, "yaxis": { "range": [ 0, 29.473684210526315 ], "title": { "text": "Frekuensi" }, "autorange": true }, "barmode": "group", "autosize": true, "colorway": [ "#4c78a8", "#f58518", "#e45756", "#72b7b2", "#54a24b", "#eeca3b", "#b279a2", "#ff9da6", "#9d755d", "#bab0ac" ], "template": { "themeRef": "PLOTLY_CLASSIC" }, "hoverlabel": { "font": { "size": 17 } }, "showlegend": false, "plot_bgcolor": "rgb(207, 207, 209)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~TriArdhiansa", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 04:35:08", "mapbox_access_tokens": null, "has_password": null, "username": "TriArdhiansa", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:35:21.595976Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~chickenburrito1/4.embed", "fid": "chickenburrito1:4", "filename": "choropleth_california", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/chickenburrito1:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/chickenburrito1:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/chickenburrito1:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/chickenburrito1:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/chickenburrito1:4", "plots": "https://api.plotly.com/v2/plots/chickenburrito1:4", "parent": "https://api.plotly.com/v2/folders/home?user=chickenburrito1" }, "owner": "chickenburrito1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Map of Anonymous Revisions for Cal Poly Wiki in US", "views": 1, "web_url": "https://chart-studio.plotly.com/~chickenburrito1/4/map-of-anonymous-revisions-for-cal-poly-wiki-in-us/", "world_readable": true, "date_modified": "2019-04-28T19:42:20.709Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~chickenburrito1/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9bdf96c1-139f-400e-8ddc-f9404b4d336b", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "< 7.00", "type": "scatter", "xsrc": "chickenburrito1:5:e9b934", "ysrc": "chickenburrito1:5:b6efa8", "fillcolor": "#030512", "hoverinfo": "none" }, { "uid": "734d39dd-efe9-4780-ad2b-974346c09a64", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "7.00 - 109.00", "type": "scatter", "xsrc": "chickenburrito1:5:43dd1e", "ysrc": "chickenburrito1:5:605f21", "fillcolor": "#1d1d3b", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "ba0d92b8-bcd6-4e77-885d-b7f9f8685144", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "109.00 - 211.00", "type": "scatter", "fillcolor": "#323268", "hoverinfo": "none" }, { "uid": "995290f3-6edd-4244-bf49-e671ac0c6766", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "211.00 - 313.00", "type": "scatter", "xsrc": "chickenburrito1:5:834a19", "ysrc": "chickenburrito1:5:b9e062", "fillcolor": "#3d4b94", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "7e619895-6896-4e5c-bb68-f8b7fb1c0465", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "> 313.00", "type": "scatter", "fillcolor": "#3e6ab0", "hoverinfo": "none" }, { "uid": "a7da5151-6bc3-4996-a63a-0d3b526e0bf6", "mode": "markers", "name": "US Counties", "type": "scatter", "xsrc": "chickenburrito1:5:e9ee02", "ysrc": "chickenburrito1:5:7ca4ab", "marker": { "color": "white", "opacity": 0 }, "textsrc": "chickenburrito1:5:1bcf7f", "selected": { "marker": { "size": 3, "color": "white", "opacity": 1 } }, "hoverinfo": "text", "showlegend": false, "unselected": { "marker": { "opacity": 0 } }, "legendgroup": "centroids" }, { "uid": "2bdd2620-f8de-4e60-bdda-5ce907198315", "line": { "color": "rgb(240, 240, 240)", "width": 1 }, "mode": "lines", "type": "scatter", "xsrc": "chickenburrito1:5:7c8250", "ysrc": "chickenburrito1:5:e0ca85", "hoverinfo": "text", "showlegend": false, "legendgroup": "States" } ], "layout": { "title": { "text": "Map of Anonymous Revisions for Cal Poly Wiki in US" }, "width": 900, "xaxis": { "range": [ -125.0, -55.0 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "yaxis": { "range": [ 23.0, 51.0 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "height": 450, "legend": { "x": 1, "y": 1, "xanchor": "right", "yanchor": "top", "traceorder": "reversed" }, "margin": { "b": 20, "l": 20, "r": 20, "t": 40 }, "dragmode": "select", "hovermode": "closest", "annotations": [ { "x": 1, "y": 1.05, "text": "<b>Edits by County</b>", "xref": "paper", "yref": "paper", "xanchor": "right", "showarrow": false } ], "plot_bgcolor": "rgb(229,229,229)", "paper_bgcolor": "rgb(229,229,229)" } }, "height": 450, "width": 900, "user": { "profile_url": "https://chart-studio.plotly.com/~chickenburrito1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/56.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-13 05:26:37", "mapbox_access_tokens": null, "has_password": null, "username": "chickenburrito1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:29:56.429440Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~lokesh899/1.embed", "fid": "lokesh899:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/lokesh899:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/lokesh899:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/lokesh899/1/8_JOO398JP80VC19NZCDJDMIGZ7PSR00.png", "list-thumb": "https://api.plotly.com/v2/files/lokesh899:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/lokesh899:1", "plots": "https://api.plotly.com/v2/plots/lokesh899:1", "parent": "https://api.plotly.com/v2/folders/home?user=lokesh899" }, "owner": "lokesh899", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~lokesh899/1/", "world_readable": true, "date_modified": "2019-04-22T04:30:19.563Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~lokesh899/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "type": "scatter", "xsrc": "lokesh899:0:182b4e", "ysrc": "lokesh899:0:ee1823" } ], "frames": [], "layout": { "title": { "text": "" }, "xaxis": { "type": "linear", "range": [ 0, 50 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -3.94888888888889, 75.02888888888889 ], "autorange": true }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "paper_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~lokesh899", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/21.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 04:29:32", "mapbox_access_tokens": null, "has_password": null, "username": "lokesh899", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:28:32.599133Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~joemanto/12.embed", "fid": "joemanto:12", "filename": "Plot 12", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/joemanto:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/joemanto:12/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/joemanto/12/8_6MTNHM3MZ22LTGQBI9B9SON8YDGKSI.png", "list-thumb": "https://api.plotly.com/v2/files/joemanto:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/joemanto:12", "plots": "https://api.plotly.com/v2/plots/joemanto:12", "parent": "https://api.plotly.com/v2/folders/home?user=joemanto" }, "owner": "joemanto", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~joemanto/12/", "world_readable": true, "date_modified": "2019-04-22T04:28:32.612Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~joemanto/12/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "test1", "type": "bar", "xsrc": "joemanto:11:c43612", "ysrc": "joemanto:11:2e2729", "orientation": "v" }, { "name": "test2", "type": "bar", "xsrc": "joemanto:11:0410d3", "ysrc": "joemanto:11:6e1e7e", "orientation": "v" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 70.5, 178.5 ], "title": { "text": "Systolic" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 183.1578947368421 ], "title": { "text": "Biastolic" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~joemanto", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/56.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-15 23:12:10", "mapbox_access_tokens": null, "has_password": null, "username": "joemanto", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:28:31.377719Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~timothynguye/9.embed", "fid": "timothynguye:9", "filename": "world_temp_map", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/timothynguye:9/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/timothynguye:9/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/timothynguye/9/8_U04FQ3CCZ8U2UBSM56XMEF62MZJYF7.png", "list-thumb": "https://api.plotly.com/v2/files/timothynguye:9/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/timothynguye:9", "plots": "https://api.plotly.com/v2/plots/timothynguye:9", "parent": "https://api.plotly.com/v2/folders/home?user=timothynguye" }, "owner": "timothynguye", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Average land temperature in countries", "views": 0, "web_url": "https://chart-studio.plotly.com/~timothynguye/9/average-land-temperature-in-countries/", "world_readable": true, "date_modified": "2019-04-25T01:47:49.476Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~timothynguye/9/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "choropleth", "zsrc": "timothynguye:10:e065f0", "marker": { "line": { "color": "rgb(0,0,0)", "width": 1 } }, "textsrc": "timothynguye:10:d6ba5d", "colorbar": { "title": "# Average<br>Temperature,<br>°C" }, "locationmode": "country names", "locationssrc": "timothynguye:10:b59752" } ], "layout": { "geo": { "showframe": false, "showocean": true, "oceancolor": "rgb(0,255,255)" }, "title": "Average land temperature in countries" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~timothynguye", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:59:01", "mapbox_access_tokens": null, "has_password": null, "username": "timothynguye", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:27:41.971695Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~AimonAllouache/56.embed", "fid": "AimonAllouache:56", "filename": "potd-lr-4-19-22", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/AimonAllouache:56/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/AimonAllouache/56/2_LZQIXYQKK7G18H85SHVRVBR814HXOM.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/AimonAllouache/56/8_KOO60L8D1OG51B5W4VLF6ENJSOWB3S.png", "list-thumb": "https://api.plotly.com/v2/files/AimonAllouache:56/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/AimonAllouache:56", "plots": "https://api.plotly.com/v2/plots/AimonAllouache:56", "parent": "https://api.plotly.com/v2/folders/home?user=AimonAllouache" }, "owner": "AimonAllouache", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 256, "web_url": "https://chart-studio.plotly.com/~AimonAllouache/56/", "world_readable": true, "date_modified": "2019-04-22T04:27:42.363Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~AimonAllouache/56/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1e70cc28-c609-4b4c-a05e-c31236b215f6", "type": "heatmap", "zsrc": "AimonAllouache:57:", "opacity": 0.75, "hoverinfo": "none", "showscale": false, "colorscale": [ [ 0, "#00083e" ], [ 0.5, "#ededee" ], [ 1, "#ffffff" ] ] } ], "layout": { "xaxis": { "dtick": 1, "tick0": -0.5, "ticks": "", "zeroline": false, "gridwidth": 2, "showticklabels": false }, "yaxis": { "dtick": 1, "tick0": 0.5, "ticks": "", "zeroline": false, "autorange": "reversed", "gridwidth": 2, "showticklabels": false }, "height": 170, "margin": { "b": 0, "l": 0, "r": 0, "t": 0 }, "annotations": [ { "x": -0.45, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>Player</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>Probability</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 1, "font": { "color": "#000000" }, "text": "Jose Altuve", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 1, "font": { "color": "#000000" }, "text": "0.301", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 2, "font": { "color": "#000000" }, "text": "Kole Calhoun", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 2, "font": { "color": "#000000" }, "text": "0.284", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 3, "font": { "color": "#000000" }, "text": "Mitch Moreland", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 3, "font": { "color": "#000000" }, "text": "0.277", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false } ] } }, "height": 170, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~AimonAllouache", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-15 02:54:36", "mapbox_access_tokens": null, "has_password": null, "username": "AimonAllouache", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:27:33.302673Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/16.embed", "fid": "pallavi_s:16", "filename": "plot from API (5)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:16/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/pallavi_s/16/2_WCD2G3ABHSW91VXU3HUEB9LTJIDG7E.png", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:16", "plots": "https://api.plotly.com/v2/plots/pallavi_s:16", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~pallavi_s/16/", "world_readable": true, "date_modified": "2019-04-22T04:27:33.843Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f1a3747a-64b6-11e9-910f-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:17:8f2b4e", "ysrc": "pallavi_s:17:de0314", "zsrc": "pallavi_s:17:ccaec3", "color": "#FFB6C1", "opacity": 1 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:27:21.377798Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~AimonAllouache/54.embed", "fid": "AimonAllouache:54", "filename": "potd-rf-4-19-22", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/AimonAllouache:54/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/AimonAllouache/54/2_85XYUDW4S7I43USGQD4OLWA3J0HAON.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/AimonAllouache/54/8_KWS1QSIR1C1A24JIX5P2LRK6UCYFIQ.png", "list-thumb": "https://api.plotly.com/v2/files/AimonAllouache:54/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/AimonAllouache:54", "plots": "https://api.plotly.com/v2/plots/AimonAllouache:54", "parent": "https://api.plotly.com/v2/folders/home?user=AimonAllouache" }, "owner": "AimonAllouache", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 253, "web_url": "https://chart-studio.plotly.com/~AimonAllouache/54/", "world_readable": true, "date_modified": "2019-04-22T04:27:21.831Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~AimonAllouache/54/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9b811dad-8d69-45cb-be0f-0cc5ec11b9d6", "type": "heatmap", "zsrc": "AimonAllouache:55:", "opacity": 0.75, "hoverinfo": "none", "showscale": false, "colorscale": [ [ 0, "#00083e" ], [ 0.5, "#ededee" ], [ 1, "#ffffff" ] ] } ], "layout": { "xaxis": { "dtick": 1, "tick0": -0.5, "ticks": "", "zeroline": false, "gridwidth": 2, "showticklabels": false }, "yaxis": { "dtick": 1, "tick0": 0.5, "ticks": "", "zeroline": false, "autorange": "reversed", "gridwidth": 2, "showticklabels": false }, "height": 170, "margin": { "b": 0, "l": 0, "r": 0, "t": 0 }, "annotations": [ { "x": -0.45, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>Player</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 0, "font": { "color": "#ffffff" }, "text": "<b>Probability</b>", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 1, "font": { "color": "#000000" }, "text": "Mitch Moreland", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 1, "font": { "color": "#000000" }, "text": "0.275", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 2, "font": { "color": "#000000" }, "text": "Jose Altuve", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 2, "font": { "color": "#000000" }, "text": "0.272", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": -0.45, "y": 3, "font": { "color": "#000000" }, "text": "Mike Trout", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false }, { "x": 0.55, "y": 3, "font": { "color": "#000000" }, "text": "0.27", "xref": "x", "yref": "y", "align": "left", "xanchor": "left", "showarrow": false } ] } }, "height": 170, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~AimonAllouache", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-15 02:54:36", "mapbox_access_tokens": null, "has_password": null, "username": "AimonAllouache", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:26:30.791848Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~timothynguye/7.embed", "fid": "timothynguye:7", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/timothynguye:7/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/timothynguye:7/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/timothynguye:7/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/timothynguye:7/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/timothynguye:7", "plots": "https://api.plotly.com/v2/plots/timothynguye:7", "parent": "https://api.plotly.com/v2/folders/home?user=timothynguye" }, "owner": "timothynguye", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Average land temperature on the continents", "views": 0, "web_url": "https://chart-studio.plotly.com/~timothynguye/7/average-land-temperature-on-the-continents/", "world_readable": true, "date_modified": "2019-04-22T04:26:31.187Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~timothynguye/7/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "56ce1fe0-95f5-48fe-b574-ea0c801f7f4c", "line": { "color": "rgb(0, 255, 255)" }, "mode": "lines", "name": "Russia", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:f348e2" }, { "uid": "5dcba6ff-f69d-483f-8703-8fff08e81657", "line": { "color": "rgb(255, 0, 255)" }, "mode": "lines", "name": "United States", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:14d94d" }, { "uid": "8ef41119-fdd0-4474-8f45-fde431cc113e", "line": { "color": "rgb(0, 0, 0)" }, "mode": "lines", "name": "Niger", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:83677f" }, { "uid": "bd8e8e57-dec6-414a-887f-fee3bb5edc4a", "line": { "color": "rgb(255, 0, 0)" }, "mode": "lines", "name": "Greenland", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:3cdfa1" }, { "uid": "3841ae33-2de1-4051-82df-dc93d0c9a807", "line": { "color": "rgb(0, 255, 0)" }, "mode": "lines", "name": "Australia", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:3e6399" }, { "uid": "bc7194ba-b395-4de4-8de1-d5cdb18d4dae", "line": { "color": "rgb(0, 0, 255)" }, "mode": "lines", "name": "Bolivia", "type": "scatter", "xsrc": "timothynguye:8:a770cf", "ysrc": "timothynguye:8:47c317" } ], "layout": { "title": { "text": "Average land temperature on the continents" }, "xaxis": { "title": { "text": "year" } }, "yaxis": { "title": { "text": "Average Temperature, °C" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~timothynguye", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:59:01", "mapbox_access_tokens": null, "has_password": null, "username": "timothynguye", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:26:05.335878Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/14.embed", "fid": "pallavi_s:14", "filename": "plot from API (4)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:14/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pallavi_s:14/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:14/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:14/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:14", "plots": "https://api.plotly.com/v2/plots/pallavi_s:14", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~pallavi_s/14/", "world_readable": true, "date_modified": "2019-04-22T04:26:05.808Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/14/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "bd6805a6-64b6-11e9-9a10-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:15:e62358", "ysrc": "pallavi_s:15:6a780a", "zsrc": "pallavi_s:15:cfb45c", "color": "#FFB6C1", "opacity": 1, "alphahull": 1 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
