Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTE5JTNBMzMuOTAzNjE1JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA0LTIyKzA0JTNBMjElM0EyNy43MTA5OTElMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTI1JTNBMzkuNDMyNzE3JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-04-22T04:25:39.432717Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/12.embed", "fid": "pallavi_s:12", "filename": "plot from API (3)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:12/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/pallavi_s/12/2_WEGDTIMNIRVDONNLIS1ECQJ3CL8SKC.png", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:12", "plots": "https://api.plotly.com/v2/plots/pallavi_s:12", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~pallavi_s/12/", "world_readable": true, "date_modified": "2019-04-22T04:25:40.008Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "add7bc12-64b6-11e9-b136-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:13:20c47b", "ysrc": "pallavi_s:13:d15e27", "zsrc": "pallavi_s:13:45464f", "color": "#FFB6C1", "opacity": 1, "alphahull": -1 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:25:38.978675Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~timothynguye/5.embed", "fid": "timothynguye:5", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/timothynguye:5/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/timothynguye:5/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/timothynguye:5/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/timothynguye:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/timothynguye:5", "plots": "https://api.plotly.com/v2/plots/timothynguye:5", "parent": "https://api.plotly.com/v2/folders/home?user=timothynguye" }, "owner": "timothynguye", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Average land temperature in world", "views": 0, "web_url": "https://chart-studio.plotly.com/~timothynguye/5/average-land-temperature-in-world/", "world_readable": true, "date_modified": "2019-04-22T04:25:39.423Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~timothynguye/5/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "584d55da-e542-4cc3-b5c1-45bc95308579", "line": { "color": "rgb(0, 255, 255)" }, "mode": "lines", "name": "Uncertainty top", "type": "scatter", "xsrc": "timothynguye:6:fb0c50", "ysrc": "timothynguye:6:a4624e" }, { "uid": "0eb7d41a-ec4f-4eeb-a0ba-66355bd67a28", "fill": "tonexty", "line": { "color": "rgb(0, 255, 255)" }, "mode": "lines", "name": "Uncertainty bot", "type": "scatter", "xsrc": "timothynguye:6:fb0c50", "ysrc": "timothynguye:6:0cfaa5" }, { "uid": "ba890727-bd07-4751-bc76-765d4e5bffcc", "line": { "color": "rgb(199, 121, 093)" }, "name": "Average Temperature", "type": "scatter", "xsrc": "timothynguye:6:fb0c50", "ysrc": "timothynguye:6:6d5545" } ], "layout": { "title": { "text": "Average land temperature in world" }, "xaxis": { "title": { "text": "year" } }, "yaxis": { "title": { "text": "Average Temperature, °C" } }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~timothynguye", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:59:01", "mapbox_access_tokens": null, "has_password": null, "username": "timothynguye", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:25:34.598609Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~oaklea/0.embed", "fid": "oaklea:0", "filename": "basic-scatter", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/oaklea:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/oaklea:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/oaklea:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/oaklea:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/oaklea:0", "plots": "https://api.plotly.com/v2/plots/oaklea:0", "parent": "https://api.plotly.com/v2/folders/home?user=oaklea" }, "owner": "oaklea", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Technology", "views": 0, "web_url": "https://chart-studio.plotly.com/~oaklea/0/technology/", "world_readable": true, "date_modified": "2019-04-25T20:09:41.268Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~oaklea/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1e745997-ad70-4625-9e59-02cc30153697", "mode": "markers", "name": "Technology", "type": "scatter", "xsrc": "oaklea:2:204dd0", "ysrc": "oaklea:2:d36842" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~oaklea", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/49.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 04:16:18", "mapbox_access_tokens": null, "has_password": null, "username": "oaklea", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:24:51.094227Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~timothynguye/3.embed", "fid": "timothynguye:3", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/timothynguye:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/timothynguye:3/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/timothynguye:3/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/timothynguye:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/timothynguye:3", "plots": "https://api.plotly.com/v2/plots/timothynguye:3", "parent": "https://api.plotly.com/v2/folders/home?user=timothynguye" }, "owner": "timothynguye", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Average land temperature in world", "views": 0, "web_url": "https://chart-studio.plotly.com/~timothynguye/3/average-land-temperature-in-world/", "world_readable": true, "date_modified": "2019-04-22T04:24:51.615Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~timothynguye/3/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "34a0a2f6-89ff-459d-93cf-b797aea67ffc", "line": { "color": "rgb(0, 255, 255)" }, "mode": "lines", "name": "Uncertainty top", "type": "scatter", "xsrc": "timothynguye:4:adefa9", "ysrc": "timothynguye:4:184c75" }, { "uid": "628756ec-93d8-46f8-908b-86c2b50f7017", "fill": "tonexty", "line": { "color": "rgb(0, 255, 255)" }, "mode": "lines", "name": "Uncertainty bot", "type": "scatter", "xsrc": "timothynguye:4:adefa9", "ysrc": "timothynguye:4:46d6e8" }, { "uid": "bd3af96d-14dc-40d3-a442-ac177a46fcee", "line": { "color": "rgb(199, 121, 093)" }, "name": "Average Temperature", "type": "scatter", "xsrc": "timothynguye:4:adefa9", "ysrc": "timothynguye:4:159af1" } ], "layout": { "title": { "text": "Average land temperature in world" }, "xaxis": { "title": { "text": "year" } }, "yaxis": { "title": { "text": "Average Temperature, °C" } }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~timothynguye", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:59:01", "mapbox_access_tokens": null, "has_password": null, "username": "timothynguye", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:24:09.543444Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/10.embed", "fid": "pallavi_s:10", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:10/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pallavi_s:10/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:10/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:10", "plots": "https://api.plotly.com/v2/plots/pallavi_s:10", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~pallavi_s/10/", "world_readable": true, "date_modified": "2019-04-22T04:24:10.153Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "7889f502-64b6-11e9-8594-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:11:c97268", "ysrc": "pallavi_s:11:44b7ab", "zsrc": "pallavi_s:11:9d6cd9", "color": "#FFB6C1", "opacity": 1, "alphahull": 5 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:23:42.005523Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paulinap2/16.embed", "fid": "paulinap2:16", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paulinap2:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/paulinap2:16/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paulinap2/16/8_MD3YVKSODJO4NBFDNAYYMH2JOFUZ36.png", "list-thumb": "https://api.plotly.com/v2/files/paulinap2:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paulinap2:16", "plots": "https://api.plotly.com/v2/plots/paulinap2:16", "parent": "https://api.plotly.com/v2/folders/home?user=paulinap2" }, "owner": "paulinap2", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~paulinap2/16/", "world_readable": true, "date_modified": "2019-04-22T04:23:42.479Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paulinap2/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "16dda6f1-8c37-4446-ab62-2508702f3308", "mode": "markers", "type": "scatter3d", "xsrc": "paulinap2:17:187cb1", "ysrc": "paulinap2:17:f8f091", "zsrc": "paulinap2:17:4a77cd", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "opacity": 0.8 } } ], "layout": { "margin": { "b": 0, "l": 0, "r": 0, "t": 0 } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~paulinap2", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:20:48", "mapbox_access_tokens": null, "has_password": null, "username": "paulinap2", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:23:37.542428Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/8.embed", "fid": "pallavi_s:8", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:8/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/pallavi_s/8/2_O0MG6XQI9EDZ8ZZD00G61IUFR14NKK.png", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:8", "plots": "https://api.plotly.com/v2/plots/pallavi_s:8", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~pallavi_s/8/", "world_readable": true, "date_modified": "2019-04-22T04:23:38.108Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "650cf062-64b6-11e9-9121-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:9:47017d", "ysrc": "pallavi_s:9:a54c2c", "zsrc": "pallavi_s:9:01a032", "color": "#FFB6C1", "opacity": 1 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:23:09.012774Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pallavi_s/6.embed", "fid": "pallavi_s:6", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pallavi_s:6/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/pallavi_s/6/2_OQYXT9WZDMR2ZTFMUVSJJ78IULL4BY.png", "block-thumb": "https://api.plotly.com/v2/files/pallavi_s:6/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pallavi_s:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pallavi_s:6", "plots": "https://api.plotly.com/v2/plots/pallavi_s:6", "parent": "https://api.plotly.com/v2/folders/home?user=pallavi_s" }, "owner": "pallavi_s", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~pallavi_s/6/", "world_readable": true, "date_modified": "2019-04-22T04:23:09.645Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pallavi_s/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "52ea4a54-64b6-11e9-8359-d20049411001", "type": "mesh3d", "xsrc": "pallavi_s:7:0df936", "ysrc": "pallavi_s:7:157e0f", "zsrc": "pallavi_s:7:d17bea", "color": "#FFB6C1", "opacity": 0.5 } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pallavi_s", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-03 07:09:12", "mapbox_access_tokens": null, "has_password": null, "username": "pallavi_s", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:21:27.889850Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~madhushan75f/125.embed", "fid": "madhushan75f:125", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/madhushan75f:125/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/madhushan75f/125/2_RLEYIR3PEMVPUVPHKMDTMWY42BA6DF.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/madhushan75f/125/8_1JAZQV6BQFRSB1JM1P8DIT48HY815Y.png", "list-thumb": "https://api.plotly.com/v2/files/madhushan75f:125/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/madhushan75f:125", "plots": "https://api.plotly.com/v2/plots/madhushan75f:125", "parent": "https://api.plotly.com/v2/folders/home?user=madhushan75f" }, "owner": "madhushan75f", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "ROC Curve", "views": 33, "web_url": "https://chart-studio.plotly.com/~madhushan75f/125/roc-curve/", "world_readable": true, "date_modified": "2019-04-22T04:21:28.431Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~madhushan75f/125/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "18d2bfae-64b6-11e9-ac82-00155dcc03a0", "mode": "lines", "name": "AUC = 0.99", "type": "scatter", "xsrc": "madhushan75f:126:b21511", "ysrc": "madhushan75f:126:391273" }, { "uid": "18d2c378-64b6-11e9-ac82-00155dcc03a0", "line": { "dash": "dash", "color": "rgba(255, 0, 0, 0.5)", "width": 4 }, "name": "Reference", "type": "scatter", "xsrc": "madhushan75f:126:4ab19e", "ysrc": "madhushan75f:126:af13bc" } ], "layout": { "title": "ROC Curve", "xaxis": { "title": "False Positive Rate" }, "yaxis": { "title": "True Positive Rate" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~madhushan75f", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/77.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-02-12 19:53:17", "mapbox_access_tokens": null, "has_password": null, "username": "madhushan75f", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:21:27.710991Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Python-Demo-Account/18112.embed", "fid": "Python-Demo-Account:18112", "filename": "csvData.csv-histogram", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Python-Demo-Account/18112/9_HZRKYYI2H66CTMCW7UBLKWOYSOONRG.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Python-Demo-Account/18112/2_12CQNYMN8L0NU85313KXUSAAZDQ9ZS.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Python-Demo-Account/18112/8_SM3ZPTWGIMJR14DDRMOI26ZEH9CTJN.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Python-Demo-Account/18112/9_HZRKYYI2H66CTMCW7UBLKWOYSOONRG.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Python-Demo-Account:18112", "plots": "https://api.plotly.com/v2/plots/Python-Demo-Account:18112", "parent": "https://api.plotly.com/v2/folders/home?user=Python-Demo-Account" }, "owner": "Python-Demo-Account", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Distribution of the CH Signal", "views": 16, "web_url": "https://chart-studio.plotly.com/~Python-Demo-Account/18112/distribution-of-the-ch-signal/", "world_readable": true, "date_modified": "2019-04-22T18:15:11.021Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Python-Demo-Account/18112/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "x": [], "uid": "5b1c6d23-5341-4c32-a0ad-eb320fc2adf9", "name": "1", "type": "histogram", "xaxis": "x", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "cd693d76-03d2-48b0-94b3-b0286b81cc3c", "name": "0", "type": "histogram", "xaxis": "x", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "1e0dab0d-f0f8-4b4a-8da9-4be46b9c25c0", "name": "1", "type": "histogram", "xaxis": "x2", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "6e558558-11b2-4c51-82bf-5ba0c51cfdb5", "name": "0", "type": "histogram", "xaxis": "x2", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "4cec3cc8-525d-4a92-a207-8cb7ffeb4d0c", "name": "1", "type": "histogram", "xaxis": "x3", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "d4254611-cbe6-4d0d-980b-f5d61843c1e8", "name": "0", "type": "histogram", "xaxis": "x3", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "2cd9c3fc-b5dd-4a94-a435-fd469a49bef8", "name": "1", "type": "histogram", "xaxis": "x4", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "342e9ad9-9e12-4f4a-96c8-b49f137aba37", "name": "0", "type": "histogram", "xaxis": "x4", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "a8e453a4-79a8-4523-af29-e3dbae61622f", "name": "1", "type": "histogram", "xaxis": "x5", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "aac698f1-edc6-4f1a-9af1-0ec24a5aae7f", "name": "0", "type": "histogram", "xaxis": "x5", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "ca9f3133-017f-4f7f-adca-b94a8271e266", "name": "1", "type": "histogram", "xaxis": "x6", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "886c79fa-6af7-4b1a-95a3-5c93d2ebe79e", "name": "0", "type": "histogram", "xaxis": "x6", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "749ef964-cb51-449b-813e-b0326db064f3", "name": "1", "type": "histogram", "xaxis": "x7", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "370bb31b-e30a-4258-831e-7c53794e2a61", "name": "0", "type": "histogram", "xaxis": "x7", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "d4000df4-d78a-4a04-8fca-9fca4f16a50d", "name": "1", "type": "histogram", "xaxis": "x8", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "d8bbca28-7730-4402-8076-e744c70d71bc", "name": "0", "type": "histogram", "xaxis": "x8", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "2e47cce6-0433-4a7f-83ef-1639a2a0971e", "name": "1", "type": "histogram", "xaxis": "x9", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "532aabb6-0d8e-4371-8ff9-e66947fbb01d", "name": "0", "type": "histogram", "xaxis": "x9", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "b759ebc3-d572-4892-8987-d9ff2d6b40f6", "name": "1", "type": "histogram", "xaxis": "x10", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "7cae7a06-0e7b-4417-acd6-a8381b8c6786", "name": "0", "type": "histogram", "xaxis": "x10", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "3e8bc39a-11ef-4e50-b5e5-9a67c25234f6", "name": "1", "type": "histogram", "xaxis": "x11", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "5a849957-8bff-4ed5-9349-d11cf918a6de", "name": "0", "type": "histogram", "xaxis": "x11", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "80cb91b8-e870-4d9f-a14f-e1d0fabe5978", "name": "1", "type": "histogram", "xaxis": "x12", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "f607f33c-e134-4f04-ae5a-6a0ff8275616", "name": "0", "type": "histogram", "xaxis": "x12", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "61cdb0fd-dc18-4404-8ec0-5fc48e92600c", "name": "1", "type": "histogram", "xaxis": "x13", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "de0af5c6-4df7-4f8c-b081-c62fe3872a05", "name": "0", "type": "histogram", "xaxis": "x13", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "48376b0c-740d-4eee-b971-03de629c51e8", "name": "1", "type": "histogram", "xaxis": "x14", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "7a6a1027-3d6b-43ef-9875-76e2cbba031a", "name": "0", "type": "histogram", "xaxis": "x14", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "d8ca5416-ac61-45b3-8a0e-ed91e5e4a87a", "name": "1", "type": "histogram", "xaxis": "x15", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "962fa3cc-9213-4133-8f58-f073b94290c9", "name": "0", "type": "histogram", "xaxis": "x15", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "d7069845-2961-4b57-a3da-fa4d031a2710", "name": "1", "type": "histogram", "xaxis": "x16", "marker": { "color": "#0D76BF" }, "opacity": 0.75, "showlegend": false }, { "x": [], "uid": "11b3f40a-537f-4a95-97ad-ffaa74392e50", "name": "0", "type": "histogram", "xaxis": "x16", "marker": { "color": "#00cc96" }, "opacity": 0.75, "showlegend": false } ], "layout": { "title": { "text": "Distribution of the CH Signal" }, "xaxis": { "title": { "text": "CH1" }, "domain": [ 0, 0.05 ] }, "yaxis": { "title": { "text": "Point Count" } }, "xaxis2": { "title": { "text": "CH2" }, "domain": [ 0.06, 0.11 ] }, "xaxis3": { "title": { "text": "CH3" }, "domain": [ 0.12, 0.17 ] }, "xaxis4": { "title": { "text": "CH4" }, "domain": [ 0.18, 0.23 ] }, "xaxis5": { "title": { "text": "CH5" }, "domain": [ 0.24, 0.29 ] }, "xaxis6": { "title": { "text": "CH6" }, "domain": [ 0.3, 0.35 ] }, "xaxis7": { "title": { "text": "CH7" }, "domain": [ 0.36, 0.41 ] }, "xaxis8": { "title": { "text": "CH8" }, "domain": [ 0.42, 0.47 ] }, "xaxis9": { "title": { "text": "CH9" }, "domain": [ 0.48, 0.53 ] }, "barmode": "overlay", "xaxis10": { "title": { "text": "CH10" }, "domain": [ 0.54, 0.59 ] }, "xaxis11": { "title": { "text": "CH11" }, "domain": [ 0.6, 0.65 ] }, "xaxis12": { "title": { "text": "CH12" }, "domain": [ 0.66, 0.71 ] }, "xaxis13": { "title": { "text": "CH13" }, "domain": [ 0.72, 0.77 ] }, "xaxis14": { "title": { "text": "CH14" }, "domain": [ 0.78, 0.83 ] }, "xaxis15": { "title": { "text": "CH15" }, "domain": [ 0.84, 0.89 ] }, "xaxis16": { "title": { "text": "CH16" }, "domain": [ 0.93, 1 ] } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Python-Demo-Account", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/59.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-06-19 14:17:58", "mapbox_access_tokens": null, "has_password": null, "username": "Python-Demo-Account", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
