Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTAyJTNBNDEuNTQ2Mjk4JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA0LTIyKzA0JTNBMDUlM0E0Ny4yNjI2MDMlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswNCUzQTE5JTNBMzMuOTAzNjE1JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-04-22T04:19:33.903615Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tinaprisma/61.embed", "fid": "tinaprisma:61", "filename": "plot from API (12)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tinaprisma:61/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tinaprisma:61/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/tinaprisma/61/8_H5NM9RQNUAO24D2Q9DTIG6BRP2MPCF.png", "list-thumb": "https://api.plotly.com/v2/files/tinaprisma:61/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tinaprisma:61", "plots": "https://api.plotly.com/v2/plots/tinaprisma:61", "parent": "https://api.plotly.com/v2/folders/home?user=tinaprisma" }, "owner": "tinaprisma", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "views": 47, "web_url": "https://chart-studio.plotly.com/~tinaprisma/61/summer-winter-temperatures-in-us-cities-2000-2018/", "world_readable": true, "date_modified": "2019-04-22T04:19:34.378Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tinaprisma/61/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(73,124,81)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:d520da", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:05f554", "xaxis": "x1", "yaxis": "y1", "fillcolor": "rgba(73,124,81,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(73,124,81)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:019896", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:0c8a4b", "xaxis": "x1", "yaxis": "y1", "fillcolor": "rgba(73,124,81,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:102247", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:793794", "xaxis": "x2", "yaxis": "y2", "fillcolor": "rgba(81,73,124,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:103c10", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:af2f46", "xaxis": "x2", "yaxis": "y2", "fillcolor": "rgba(81,73,124,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:35da19", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:7675ff", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:0d09fa", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:947a04", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:a1641a", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:4e04e3", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:4c7584", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:ace461", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:e2d8bf", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:e65b82", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:4ad087", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:ab0b29", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:bf73a4", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:f6eeab", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:62:dc1ba6", "ysrc": "tinaprisma:62:0d546a", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:62:13b5d9", "ysrc": "tinaprisma:62:277695", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false } ], "layout": { "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "xaxis1": { "anchor": "y1", "domain": [ 0.0, 0.45 ] }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.0, 0.45 ] }, "xaxis4": { "anchor": "y4", "domain": [ 0.55, 1.0 ] }, "xaxis5": { "anchor": "y5", "domain": [ 0.0, 0.45 ] }, "xaxis6": { "anchor": "y6", "domain": [ 0.55, 1.0 ] }, "yaxis1": { "anchor": "x1", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis4": { "anchor": "x4", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis5": { "anchor": "x5", "domain": [ 0.0, 0.22222222222222224 ] }, "yaxis6": { "anchor": "x6", "domain": [ 0.0, 0.22222222222222224 ] }, "annotations": [ { "x": 0.225, "y": 1.0, "font": { "size": 16 }, "text": "Houston", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 1.0, "font": { "size": 16 }, "text": "Austin", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Denver", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Seattle", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "San Francisco", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "Portland", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tinaprisma", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-19 22:53:00", "mapbox_access_tokens": null, "has_password": null, "username": "tinaprisma", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:17:41.191638Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~theom/237.embed", "fid": "theom:237", "filename": "overlaid histogram", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/theom:237/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/theom/237/2_D8CBHB4M09W34C4NJNAZJT3W8VF8LV.png", "block-thumb": "https://api.plotly.com/v2/files/theom:237/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/theom:237/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/theom:237", "plots": "https://api.plotly.com/v2/plots/theom:237", "parent": "https://api.plotly.com/v2/folders/home?user=theom" }, "owner": "theom", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Google, Facebook, Netflix", "views": 25, "web_url": "https://chart-studio.plotly.com/~theom/237/google-facebook-netflix/", "world_readable": true, "date_modified": "2019-04-22T04:58:24.680Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~theom/237/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b7fd9b71-8d60-4db9-9b1f-87cbd344968c", "name": "Google", "type": "histogram", "xsrc": "theom:238:a41307", "xbins": { "size": 10 }, "marker": { "color": "rgb(150, 50, 50)" }, "opacity": 0.75 }, { "uid": "b8cbb36b-2e6c-49aa-b270-8fae80537439", "name": "Facebook", "type": "histogram", "xsrc": "theom:238:58bcd5", "xbins": { "size": 10 }, "marker": { "color": "rgb(150, 50, 150)" }, "opacity": 0.75 }, { "uid": "1d86c028-715f-4a78-acfb-7d66ad3c6207", "name": "Netflix", "type": "histogram", "xsrc": "theom:238:4494e7", "xbins": { "size": 10 }, "marker": { "color": "rgb(50, 50, 50)" }, "opacity": 0.75 } ], "layout": { "xaxis": { "range": [ 0, 2500 ] }, "barmode": "overlay" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~theom", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/87.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-06-22 06:30:23", "mapbox_access_tokens": null, "has_password": null, "username": "theom", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:17:33.589172Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tinaprisma/59.embed", "fid": "tinaprisma:59", "filename": "plot from API (11)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tinaprisma:59/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tinaprisma:59/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/tinaprisma/59/8_ORIC88QG3BDD2ZWMAQE7T5UPWQ4TVI.png", "list-thumb": "https://api.plotly.com/v2/files/tinaprisma:59/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tinaprisma:59", "plots": "https://api.plotly.com/v2/plots/tinaprisma:59", "parent": "https://api.plotly.com/v2/folders/home?user=tinaprisma" }, "owner": "tinaprisma", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "views": 0, "web_url": "https://chart-studio.plotly.com/~tinaprisma/59/summer-winter-temperatures-in-us-cities-2000-2018/", "world_readable": true, "date_modified": "2019-04-22T04:17:34.031Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tinaprisma/59/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:307bb8", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:f9be77", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:12973f", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:6df580", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(110, 115, 119)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:b3315c", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:b3315c", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:cbc248", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:e6f3c3", "xaxis": "x2", "yaxis": "y2", "fillcolor": "rgba(81,73,124,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:fe629a", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:c0756c", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:1e14bf", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:95bf42", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:6e6c63", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:19da1f", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:817c51", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:a5e334", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:d946cd", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:8d4186", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:63763d", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:9ad062", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:642f64", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:8e39fe", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:60:98a1d1", "ysrc": "tinaprisma:60:14206e", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:60:d6bd33", "ysrc": "tinaprisma:60:77c9c6", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false } ], "layout": { "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "xaxis1": { "anchor": "y1", "domain": [ 0.0, 0.45 ] }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.0, 0.45 ] }, "xaxis4": { "anchor": "y4", "domain": [ 0.55, 1.0 ] }, "xaxis5": { "anchor": "y5", "domain": [ 0.0, 0.45 ] }, "xaxis6": { "anchor": "y6", "domain": [ 0.55, 1.0 ] }, "yaxis1": { "anchor": "x1", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis4": { "anchor": "x4", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis5": { "anchor": "x5", "domain": [ 0.0, 0.22222222222222224 ] }, "yaxis6": { "anchor": "x6", "domain": [ 0.0, 0.22222222222222224 ] }, "annotations": [ { "x": 0.225, "y": 1.0, "font": { "size": 16 }, "text": "Houston", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 1.0, "font": { "size": 16 }, "text": "Austin", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Denver", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Seattle", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "San Francisco", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "Portland", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tinaprisma", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-19 22:53:00", "mapbox_access_tokens": null, "has_password": null, "username": "tinaprisma", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:17:04.518935Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tinaprisma/57.embed", "fid": "tinaprisma:57", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tinaprisma:57/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tinaprisma:57/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/tinaprisma/57/8_C9FA6J1LSJANNVWIPQPR76IH8A6RIA.png", "list-thumb": "https://api.plotly.com/v2/files/tinaprisma:57/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tinaprisma:57", "plots": "https://api.plotly.com/v2/plots/tinaprisma:57", "parent": "https://api.plotly.com/v2/folders/home?user=tinaprisma" }, "owner": "tinaprisma", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "views": 0, "web_url": "https://chart-studio.plotly.com/~tinaprisma/57/summer-winter-temperatures-in-us-cities-2000-2018/", "world_readable": true, "date_modified": "2019-04-22T04:17:05.073Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tinaprisma/57/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:50c9cb", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:67e993", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:22cb71", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:24d5f3", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(110, 115, 119)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:b99456", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:b99456", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:87a0ca", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:8deefd", "xaxis": "x2", "yaxis": "y2", "fillcolor": "rgba(81,73,124,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:a7eed9", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:e3f6be", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:c90ee6", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:7cdd12", "xaxis": "x3", "yaxis": "y3", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:5a506d", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:d90f3c", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:3cd967", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:463f60", "xaxis": "x4", "yaxis": "y4", "fillcolor": "rgba(124,73,116,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:eb970d", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:fbcc37", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:c50537", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:6d1f8b", "xaxis": "x5", "yaxis": "y5", "fillcolor": "rgba(139,115,95,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Summer)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:c2f4c3", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:3d7e9b", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "°F (Winter)", "type": "scatter", "xsrc": "tinaprisma:58:398e67", "ysrc": "tinaprisma:58:7c6f5b", "xaxis": "x6", "yaxis": "y6", "showlegend": false }, { "fill": "tozerox", "line": { "color": "rgba(255,255,255,0)" }, "type": "scatter", "xsrc": "tinaprisma:58:468c5d", "ysrc": "tinaprisma:58:b5bfaa", "xaxis": "x6", "yaxis": "y6", "fillcolor": "rgba(95,119,139,0.2)", "hoverinfo": "none", "showlegend": false } ], "layout": { "title": "Summer & Winter Temperatures in U.S. Cities (2000-2018)", "xaxis1": { "anchor": "y1", "domain": [ 0.0, 0.45 ] }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.0, 0.45 ] }, "xaxis4": { "anchor": "y4", "domain": [ 0.55, 1.0 ] }, "xaxis5": { "anchor": "y5", "domain": [ 0.0, 0.45 ] }, "xaxis6": { "anchor": "y6", "domain": [ 0.55, 1.0 ] }, "yaxis1": { "anchor": "x1", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis4": { "anchor": "x4", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis5": { "anchor": "x5", "domain": [ 0.0, 0.22222222222222224 ] }, "yaxis6": { "anchor": "x6", "domain": [ 0.0, 0.22222222222222224 ] }, "annotations": [ { "x": 0.225, "y": 1.0, "font": { "size": 16 }, "text": "Houston", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 1.0, "font": { "size": 16 }, "text": "Austin", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Denver", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Seattle", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "San Francisco", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "Portland", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tinaprisma", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-19 22:53:00", "mapbox_access_tokens": null, "has_password": null, "username": "tinaprisma", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:15:07.735188Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paulinap2/14.embed", "fid": "paulinap2:14", "filename": "plot from API (5)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paulinap2:14/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/paulinap2:14/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paulinap2/14/8_WAW5P217OMV0UFYOQMF8WTSL74H8Y0.png", "list-thumb": "https://api.plotly.com/v2/files/paulinap2:14/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paulinap2:14", "plots": "https://api.plotly.com/v2/plots/paulinap2:14", "parent": "https://api.plotly.com/v2/folders/home?user=paulinap2" }, "owner": "paulinap2", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~paulinap2/14/", "world_readable": true, "date_modified": "2019-04-22T04:15:08.212Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paulinap2/14/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "38d1eba0-12a0-4cd2-96bf-61ead462b211", "mode": "markers", "type": "scatter3d", "xsrc": "paulinap2:15:b3283a", "ysrc": "paulinap2:15:aad1f6", "zsrc": "paulinap2:15:f75d1e", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "opacity": 0.8 } } ], "layout": { "margin": { "b": 0, "l": 0, "r": 0, "t": 0 } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~paulinap2", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:20:48", "mapbox_access_tokens": null, "has_password": null, "username": "paulinap2", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:13:14.175543Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ldylkj/3.embed", "fid": "ldylkj:3", "filename": "用户规模与企业付费", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ldylkj:3/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ldylkj/3/2_BXHJ8C2DM51P8NGW2ERWGO5YVVH13Y.png", "block-thumb": "https://api.plotly.com/v2/files/ldylkj:3/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ldylkj:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ldylkj:3", "plots": "https://api.plotly.com/v2/plots/ldylkj:3", "parent": "https://api.plotly.com/v2/folders/home?user=ldylkj" }, "owner": "ldylkj", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 5, "web_url": "https://chart-studio.plotly.com/~ldylkj/3/", "world_readable": true, "date_modified": "2019-04-22T05:33:40.763Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ldylkj/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "81eaf450-3460-4919-a428-23d91304ea1a", "name": "ChargedCount", "text": "", "type": "bar", "xsrc": "ldylkj:2:65faab", "ysrc": "ldylkj:2:9339bc", "marker": { "line": { "color": "rgba(255, 153, 51, 1.0)", "width": 1 }, "color": "rgba(255, 153, 51, 0.6)" }, "orientation": "v" }, { "uid": "39e6141e-0ce8-4dc5-b8d1-d77bed7b7220", "name": "EngineCount", "text": "", "type": "bar", "xsrc": "ldylkj:2:65faab", "ysrc": "ldylkj:2:277cce", "marker": { "line": { "color": "rgba(55, 128, 191, 1.0)", "width": 1 }, "color": "rgba(55, 128, 191, 0.6)" }, "orientation": "v" }, { "uid": "21e5cd63-fb35-4fdb-9262-5cb6a1f54dfb", "mode": "lines", "name": "ChargeRatio", "text": "", "type": "scatter", "xsrc": "ldylkj:2:65faab", "ysrc": "ldylkj:2:19becb", "yaxis": "y2", "marker": { "line": { "color": "rgba(50, 171, 96, 1.0)", "width": 1 }, "color": "rgba(50, 171, 96, 0.6)" }, "orientation": "v" } ], "frames": [], "layout": { "title": { "font": { "color": "#4D5663" }, "text": "用户规模与企业付费" }, "xaxis": { "side": "bottom", "type": "category", "range": [ -0.3125, 8.6875 ], "ticks": "", "title": { "font": { "color": "#4D5663" }, "text": "用户规模" }, "domain": [ 0, 1 ], "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": false, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "side": "left", "type": "linear", "range": [ -1010.1293638135743, 6968.8180046074785 ], "title": { "font": { "color": "#4D5663" }, "text": "企业数量" }, "domain": [ 0, 1 ], "showgrid": true, "tickfont": { "color": "#4D5663" }, "autorange": false, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "x": 1.02, "y": 0.9616161616161616, "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "yaxis2": { "side": "right", "type": "linear", "range": [ 0.000506937968798294, 0.11267998587310508 ], "title": { "text": "付费率" }, "autorange": false, "overlaying": "y" }, "barmode": "group", "autosize": true, "dragmode": "pan", "showlegend": true, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ldylkj", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/20.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-26 03:50:31", "mapbox_access_tokens": null, "has_password": null, "username": "ldylkj", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:11:09.009613Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~timothynguye/1.embed", "fid": "timothynguye:1", "filename": "worldmap", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/timothynguye:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/timothynguye:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/timothynguye/1/8_GXC28TL83W0HW3QAQX2P7ZRSD56XKM.png", "list-thumb": "https://api.plotly.com/v2/files/timothynguye:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/timothynguye:1", "plots": "https://api.plotly.com/v2/plots/timothynguye:1", "parent": "https://api.plotly.com/v2/folders/home?user=timothynguye" }, "owner": "timothynguye", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Average land temperature in countries", "views": 0, "web_url": "https://chart-studio.plotly.com/~timothynguye/1/average-land-temperature-in-countries/", "world_readable": true, "date_modified": "2019-04-25T02:00:46.674Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~timothynguye/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "choropleth", "zsrc": "timothynguye:2:a8d394", "marker": { "line": { "color": "rgb(0,0,0)", "width": 1 } }, "textsrc": "timothynguye:2:ae105b", "colorbar": { "title": "# Average<br>Temperature,<br>°F" }, "locationmode": "country names", "locationssrc": "timothynguye:2:1691df" } ], "layout": { "geo": { "lataxis": { "showgrid": true, "gridcolor": "rgb(102, 102, 102)" }, "lonaxis": { "showgrid": true, "gridcolor": "rgb(102, 102, 102)" }, "showframe": false, "showocean": true, "oceancolor": "rgb(0,255,255)", "projection": { "type": "orthographic", "rotation": { "lat": 10, "lon": 60 } } }, "title": "Average land temperature in countries" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~timothynguye", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 03:59:01", "mapbox_access_tokens": null, "has_password": null, "username": "timothynguye", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:10:17.084525Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~madhushan75f/123.embed", "fid": "madhushan75f:123", "filename": "plot from API (7)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/madhushan75f:123/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/madhushan75f:123/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/madhushan75f/123/8_7LBM6T7YPUM25M3CI1I3KYQ07EY9GF.png", "list-thumb": "https://api.plotly.com/v2/files/madhushan75f:123/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/madhushan75f:123", "plots": "https://api.plotly.com/v2/plots/madhushan75f:123", "parent": "https://api.plotly.com/v2/folders/home?user=madhushan75f" }, "owner": "madhushan75f", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Actual vs. Predicted Useful Remaining Life (Cycles)", "views": 3, "web_url": "https://chart-studio.plotly.com/~madhushan75f/123/actual-vs-predicted-useful-remaining-life-cycles/", "world_readable": true, "date_modified": "2019-04-22T04:10:17.684Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~madhushan75f/123/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "88e6b2fc-64b4-11e9-ac82-00155dcc03a0", "line": { "dash": "dash", "color": "rgba(0, 0, 0, 0.2)", "width": 4 }, "name": "Reference", "type": "scatter", "xsrc": "madhushan75f:124:d4e8ad", "ysrc": "madhushan75f:124:804ffc" }, { "uid": "88e6b69e-64b4-11e9-ac82-00155dcc03a0", "mode": "markers", "name": "RUL", "type": "scatter", "xsrc": "madhushan75f:124:d4e8ad", "ysrc": "madhushan75f:124:fda84c", "marker": { "color": "rgb(22, 96, 167)" } } ], "layout": { "title": "Actual vs. Predicted Useful Remaining Life (Cycles)", "xaxis": { "title": "Actual Remaining Useful Life" }, "yaxis": { "title": "Predicted Remaining Useful Life" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~madhushan75f", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/77.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-02-12 19:53:17", "mapbox_access_tokens": null, "has_password": null, "username": "madhushan75f", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:07:33.918534Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~chickenburrito1/2.embed", "fid": "chickenburrito1:2", "filename": "choropleth_florida", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/chickenburrito1:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/chickenburrito1:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/chickenburrito1:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/chickenburrito1:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/chickenburrito1:2", "plots": "https://api.plotly.com/v2/plots/chickenburrito1:2", "parent": "https://api.plotly.com/v2/folders/home?user=chickenburrito1" }, "owner": "chickenburrito1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "< 8.28K, 8.28K - 869.20K, 869.20K - 1.73M, 1.73M - 2.59M, > 2.59M, US Counties", "views": 0, "web_url": "https://chart-studio.plotly.com/~chickenburrito1/2/_259m-us-counties/", "world_readable": true, "date_modified": "2019-04-22T04:07:34.442Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~chickenburrito1/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "251fee3e-e509-44fe-bd48-9d350ae97234", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "< 8.28K", "type": "scatter", "xsrc": "chickenburrito1:3:73f670", "ysrc": "chickenburrito1:3:9dfd8e", "fillcolor": "#030512", "hoverinfo": "none" }, { "uid": "43796e34-708e-4a6a-ad15-8cf7b20489f7", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "8.28K - 869.20K", "type": "scatter", "xsrc": "chickenburrito1:3:cf228b", "ysrc": "chickenburrito1:3:d8a3ee", "fillcolor": "#1d1d3b", "hoverinfo": "none" }, { "uid": "401684cb-99d7-4aee-86f1-5107556b7fe0", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "869.20K - 1.73M", "type": "scatter", "xsrc": "chickenburrito1:3:1383ef", "ysrc": "chickenburrito1:3:c940dc", "fillcolor": "#323268", "hoverinfo": "none" }, { "uid": "36ba5fdb-f604-4844-aa04-793117b7dddb", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "1.73M - 2.59M", "type": "scatter", "xsrc": "chickenburrito1:3:385719", "ysrc": "chickenburrito1:3:7ceb3f", "fillcolor": "#3d4b94", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "bfa5331f-7406-4538-9a22-76d725bf933c", "fill": "toself", "line": { "color": "rgb(255,255,255)", "width": 0.5 }, "mode": "lines", "name": "> 2.59M", "type": "scatter", "fillcolor": "#3e6ab0", "hoverinfo": "none" }, { "uid": "fbf1b9d4-c884-4310-b776-16e4b9b38994", "mode": "markers", "name": "US Counties", "type": "scatter", "xsrc": "chickenburrito1:3:1da90b", "ysrc": "chickenburrito1:3:23d37a", "marker": { "color": "white", "opacity": 0 }, "textsrc": "chickenburrito1:3:02ac74", "selected": { "marker": { "size": 3, "color": "white", "opacity": 1 } }, "hoverinfo": "text", "showlegend": false, "unselected": { "marker": { "opacity": 0 } }, "legendgroup": "centroids" }, { "uid": "dfcbc18a-fbc7-40c4-9081-00eede0eb26b", "line": { "color": "rgb(240, 240, 240)", "width": 1 }, "mode": "lines", "type": "scatter", "xsrc": "chickenburrito1:3:4a8917", "ysrc": "chickenburrito1:3:be2a91", "hoverinfo": "text", "showlegend": false, "legendgroup": "States" } ], "layout": { "width": 900, "xaxis": { "range": [ -91.9300843943933, -75.7361218943933 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "yaxis": { "range": [ 24.523096, 31.000681 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "height": 450, "legend": { "x": 1, "y": 1, "xanchor": "right", "yanchor": "top", "traceorder": "reversed" }, "margin": { "b": 20, "l": 20, "r": 20, "t": 40 }, "dragmode": "select", "hovermode": "closest", "annotations": [ { "x": 1, "y": 1.05, "text": "<b>Population by County</b>", "xref": "paper", "yref": "paper", "xanchor": "right", "showarrow": false } ], "plot_bgcolor": "rgb(229,229,229)", "paper_bgcolor": "rgb(229,229,229)" } }, "height": 450, "width": 900, "user": { "profile_url": "https://chart-studio.plotly.com/~chickenburrito1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/56.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-13 05:26:37", "mapbox_access_tokens": null, "has_password": null, "username": "chickenburrito1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T04:05:47.262603Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tinaprisma/55.embed", "fid": "tinaprisma:55", "filename": "plot from API (20)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tinaprisma:55/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tinaprisma:55/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/tinaprisma/55/8_DV9AHRGCSM19MHA4Q4VXR0FXSBQNV0.png", "list-thumb": "https://api.plotly.com/v2/files/tinaprisma:55/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tinaprisma:55", "plots": "https://api.plotly.com/v2/plots/tinaprisma:55", "parent": "https://api.plotly.com/v2/folders/home?user=tinaprisma" }, "owner": "tinaprisma", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Total Precipitation in U.S. Cities (2000-2018)", "views": 48, "web_url": "https://chart-studio.plotly.com/~tinaprisma/55/total-precipitation-in-us-cities-2000-2018/", "world_readable": true, "date_modified": "2019-04-22T04:05:47.767Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tinaprisma/55/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(81,73,124)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:59e0a7", "xaxis": "x1", "yaxis": "y1", "showlegend": false }, { "line": { "color": "rgb(124,73,116)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:1b9f6b", "xaxis": "x2", "yaxis": "y2", "showlegend": false }, { "line": { "color": "rgb(139,115,95)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:7d472e", "xaxis": "x3", "yaxis": "y3", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:d9afaa", "xaxis": "x4", "yaxis": "y4", "showlegend": false }, { "line": { "color": "rgb(110, 115, 119)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:189240", "xaxis": "x5", "yaxis": "y5", "showlegend": false }, { "line": { "color": "rgb(95,119,139)" }, "mode": "lines", "name": "Inches", "type": "scatter", "xsrc": "tinaprisma:56:b30746", "ysrc": "tinaprisma:56:189240", "xaxis": "x6", "yaxis": "y6", "showlegend": false } ], "layout": { "title": "Total Precipitation in U.S. Cities (2000-2018)", "xaxis1": { "anchor": "y1", "domain": [ 0.0, 0.45 ] }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.0, 0.45 ] }, "xaxis4": { "anchor": "y4", "domain": [ 0.55, 1.0 ] }, "xaxis5": { "anchor": "y5", "domain": [ 0.0, 0.45 ] }, "xaxis6": { "anchor": "y6", "domain": [ 0.55, 1.0 ] }, "yaxis1": { "anchor": "x1", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.7777777777777778, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis4": { "anchor": "x4", "domain": [ 0.3888888888888889, 0.6111111111111112 ] }, "yaxis5": { "anchor": "x5", "domain": [ 0.0, 0.22222222222222224 ] }, "yaxis6": { "anchor": "x6", "domain": [ 0.0, 0.22222222222222224 ] }, "annotations": [ { "x": 0.225, "y": 1.0, "font": { "size": 16 }, "text": "Houston", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 1.0, "font": { "size": 16 }, "text": "Austin", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Denver", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.6111111111111112, "font": { "size": 16 }, "text": "Seattle", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.225, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "San Francisco", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.775, "y": 0.22222222222222224, "font": { "size": 16 }, "text": "Portland", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tinaprisma", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-19 22:53:00", "mapbox_access_tokens": null, "has_password": null, "username": "tinaprisma", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
