Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDI0LTAzLTI3KzA1JTNBNTMlM0EwMS40MTAxODclMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDI0LTAzLTI3KzA0JTNBNDclM0EzMi42MTI5NTYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAyNC0wMy0yNyswNSUzQTI5JTNBMTUuNjkxNTI0JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2024-03-27T05:29:15.691524Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~f20200969/5.embed", "fid": "f20200969:5", "filename": "Plot 5", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/f20200969:5/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/f20200969:5/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/f20200969/5/8_T0JYBBH3EZZKIYETBHBL544838IL81.png", "list-thumb": "https://api.plotly.com/v2/files/f20200969:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/f20200969:5", "plots": "https://api.plotly.com/v2/plots/f20200969:5", "parent": "https://api.plotly.com/v2/folders/home?user=f20200969" }, "owner": "f20200969", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~f20200969/5/", "world_readable": true, "date_modified": "2024-03-27T05:39:30.847Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~f20200969/5/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "scatter", "xsrc": "f20200969:4:7d9cdf", "ysrc": "f20200969:4:219c5d" } ], "frames": [], "layout": { "title": { "text": "Data Insertion Time vs Granuality" }, "xaxis": { "type": "linear", "range": [ 1024, 262144 ], "title": { "text": "Granuality" }, "tickfont": { "color": "rgb(21, 24, 29)" }, "zeroline": true, "autorange": true, "zerolinecolor": "rgb(19, 24, 32)" }, "yaxis": { "type": "linear", "range": [ 1.7806111111111111, 4.1883888888888885 ], "title": { "text": "Insertion Time (seconds)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~f20200969", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/48.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2023-09-24 21:01:47", "mapbox_access_tokens": null, "has_password": null, "username": "f20200969", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T05:22:42.313091Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~nev546/1.embed", "fid": "nev546:1", "filename": "Warframe Ability Radars", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/nev546/1/9_3G2RE8LE3445V8I10NJA20WIN9O76Y.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/nev546/1/2_J7YNYNFU965LGM1XTIN4NBP0TDT1JX.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/nev546/1/8_MHKS7P870N9NJOJRCYGVX5TMQB42US.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/nev546/1/9_3G2RE8LE3445V8I10NJA20WIN9O76Y.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/nev546:1", "plots": "https://api.plotly.com/v2/plots/nev546:1", "parent": "https://api.plotly.com/v2/folders/home?user=nev546" }, "owner": "nev546", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~nev546/1/", "world_readable": true, "date_modified": "2024-03-29T22:09:22.542Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~nev546/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "fill": "toself", "line": { "shape": "spline", "smoothing": 1 }, "meta": { "columnNames": { "r": "Average", "theta": "Categories", "marker": { "color": "D" } } }, "mode": "markers+lines", "name": "Community Average", "rsrc": "nev546:0:915359", "type": "scatterpolar", "marker": { "meta": { "columnNames": { "color": "D" } }, "color": "#636efa" }, "opacity": 1, "subplot": "polar5", "visible": true, "thetasrc": "nev546:0:0113c7", "hoverinfo": "r+theta+name", "thetaunit": "degrees", "selectedpoints": [ 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18 ] }, { "fill": "toself", "line": { "shape": "spline" }, "meta": { "columnNames": { "r": "Nev Rate", "theta": "Categories" } }, "mode": "markers+lines", "name": "Nev Plot", "rsrc": "nev546:0:9d0c11", "type": "scatterpolar", "subplot": "polar4", "thetasrc": "nev546:0:0113c7", "selectedpoints": [ 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18 ] }, { "fill": "toself", "line": { "shape": "spline", "smoothing": 0.3 }, "meta": { "columnNames": { "r": "Mode", "theta": "Categories" } }, "name": "Community Mode", "rsrc": "nev546:0:5f904d", "type": "scatterpolar", "thetasrc": "nev546:0:0113c7", "connectgaps": true } ], "frames": [], "layout": { "font": { "color": "rgb(237, 138, 14)" }, "polar": { "domain": { "x": [ 0.625, 1 ], "y": [ 0, 0.5 ] }, "radialaxis": { "side": "clockwise", "type": "linear", "dtick": 0, "range": [ 0, 10.280373831775702 ], "tick0": 1, "ticks": "outside", "tickmode": "linear", "autorange": true, "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false }, "angularaxis": { "side": "clockwise", "type": "category", "dtick": 0, "tick0": 1, "ticks": "outside", "rotation": -268.18813318349856, "tickmode": "linear", "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false } }, "title": { "text": "Ash: Community Average Purple, Community Most common Green, Nev Red" }, "xaxis": { "range": [ 0.2909379968203498, 2.355325914149444 ], "autorange": false }, "yaxis": { "range": [ -1, 4 ], "autorange": true }, "legend": { "x": -0.020000000000000018, "y": 1.0364926192237718, "title": { "font": { "size": 1 }, "text": "<br>" }, "valign": "middle", "xanchor": "left", "yanchor": "top", "itemsizing": "trace", "traceorder": "grouped", "tracegroupgap": 0 }, "polar4": { "domain": { "x": [ 0, 0.375 ], "y": [ 0, 0.5 ] }, "radialaxis": { "side": "clockwise", "type": "linear", "dtick": 0, "range": [ 0, 10.280373831775702 ], "tick0": 1, "ticks": "outside", "title": { "text": "" }, "tickmode": "linear", "autorange": true, "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false }, "angularaxis": { "side": "clockwise", "type": "category", "dtick": 0, "tick0": 1, "ticks": "outside", "rotation": 90.77848358437312, "tickmode": "linear", "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false } }, "polar5": { "domain": { "x": [ 0.25, 0.75 ], "y": [ 0.5, 1 ] }, "radialaxis": { "side": "clockwise", "type": "linear", "dtick": 0, "range": [ 0.6029808352544872, 10.292813837317427 ], "tick0": 1, "ticks": "outside", "title": { "text": "" }, "tickmode": "linear", "autorange": false, "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false }, "angularaxis": { "side": "clockwise", "type": "category", "dtick": 0, "tick0": 1, "ticks": "outside", "rotation": 91.09893556187924, "tickmode": "linear", "tickangle": "auto", "tickformat": "", "tickprefix": "", "exponentformat": "none", "separatethousands": false } }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#506784" }, "line": { "color": "rgb(17,17,17)" } }, "header": { "fill": { "color": "#2a3f5f" }, "line": { "color": "rgb(17,17,17)" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" }, "baxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "rgb(17,17,17)", "showland": true, "lakecolor": "rgb(17,17,17)", "landcolor": "rgb(17,17,17)", "showlakes": true, "subunitcolor": "#506784" }, "font": { "color": "#f2f5fa" }, "polar": { "bgcolor": "rgb(17,17,17)", "radialaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "angularaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "yaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "zaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "baxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "caxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "bgcolor": "rgb(17,17,17)" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "rgb(17,17,17)", "paper_bgcolor": "rgb(17,17,17)", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#f2f5fa" }, "sliderdefaults": { "bgcolor": "#C8D4E3", "tickwidth": 0, "bordercolor": "rgb(17,17,17)", "borderwidth": 1 }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#f2f5fa", "arrowwidth": 1 }, "updatemenudefaults": { "bgcolor": "#506784", "borderwidth": 0 } }, "themeRef": "PLOTLY_DARK" }, "hovermode": "closest", "showlegend": true, "paper_bgcolor": "rgb(0, 0, 0)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~nev546", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/52.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 05:21:17", "mapbox_access_tokens": null, "has_password": null, "username": "nev546", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T05:19:57.110646Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~adityac24/9.embed", "fid": "adityac24:9", "filename": "Plot 9", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/adityac24:9/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/adityac24:9/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/adityac24/9/8_FDA105EZSS7M2ONQ6NTJ0WCGTAOJVJ.png", "list-thumb": "https://api.plotly.com/v2/files/adityac24:9/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/adityac24:9", "plots": "https://api.plotly.com/v2/plots/adityac24:9", "parent": "https://api.plotly.com/v2/folders/home?user=adityac24" }, "owner": "adityac24", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~adityac24/9/", "world_readable": true, "date_modified": "2024-03-27T05:19:57.122Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~adityac24/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "F" } }, "mode": "lines", "name": "USA", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:4ad410" }, { "meta": { "columnNames": { "x": "A", "y": "BB" } }, "mode": "lines", "name": "China", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:047f86", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "U" } }, "mode": "lines", "name": "Japan", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:d504fa", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "AF" } }, "mode": "lines", "name": "Germany", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:6df4da", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "AE" } }, "mode": "lines", "name": "UK", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:6b5ceb", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "DF" } }, "mode": "lines", "name": "India", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:3eac73", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "BF" } }, "mode": "lines", "name": "France", "type": "scatter", "xsrc": "adityac24:8:00fc5c", "ysrc": "adityac24:8:d22fc4", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "2019 Sustainable Development Index (SDI) By Country" }, "xaxis": { "type": "linear", "range": [ 1990, 2019 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 13.88888888888889, 76.11111111111111 ], "autorange": true }, "bargap": 0.19999999999999996, "margin": { "pad": 0 }, "barmode": "group", "barnorm": "", "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "colorscale": { "sequential": [ [ 0, "#fcfbfd" ], [ 0.125, "#efedf5" ], [ 0.25, "#dadaeb" ], [ 0.375, "#bcbddc" ], [ 0.5, "#9e9ac8" ], [ 0.625, "#807dba" ], [ 0.75, "#6a51a3" ], [ 0.875, "#54278f" ], [ 1, "#3f007d" ] ] }, "bargroupgap": 0 } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~adityac24", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/2.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-18 19:42:24", "mapbox_access_tokens": null, "has_password": null, "username": "adityac24", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T05:15:04.572433Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~rohitsanghotra/1.embed", "fid": "rohitsanghotra:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/rohitsanghotra:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/rohitsanghotra:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/rohitsanghotra/1/8_18I4WYV3764VK09WJO48E1YG0SDNOU.png", "list-thumb": "https://api.plotly.com/v2/files/rohitsanghotra:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/rohitsanghotra:1", "plots": "https://api.plotly.com/v2/plots/rohitsanghotra:1", "parent": "https://api.plotly.com/v2/folders/home?user=rohitsanghotra" }, "owner": "rohitsanghotra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~rohitsanghotra/1/", "world_readable": true, "date_modified": "2024-03-27T05:15:04.582Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~rohitsanghotra/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "y": "Year" } }, "mode": "markers", "type": "scatter", "ysrc": "rohitsanghotra:0:85b7a0", "stackgroup": null }, { "mode": "markers", "type": "scatter", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "range": [ -1, 1 ], "autorange": true }, "yaxis": { "type": "category", "range": [ -1, 1 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~rohitsanghotra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/13.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 05:14:34", "mapbox_access_tokens": null, "has_password": null, "username": "rohitsanghotra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T05:05:50.518875Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~swifty2205/12.embed", "fid": "swifty2205:12", "filename": "plot from API (6)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/swifty2205/12/9_CLJV24826OJQ2TDPHOK53ZI5V8A359.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/swifty2205/12/2_78Y3LC56C5EBD0FU3L9VBU9QKEYHBJ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/12/8_7J3DCFWMXZAY5HS85XK5AW14FCJDZ4.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/12/9_CLJV24826OJQ2TDPHOK53ZI5V8A359.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/swifty2205:12", "plots": "https://api.plotly.com/v2/plots/swifty2205:12", "parent": "https://api.plotly.com/v2/folders/home?user=swifty2205" }, "owner": "swifty2205", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~swifty2205/12/", "world_readable": true, "date_modified": "2024-03-27T05:05:51.074Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~swifty2205/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines markers", "type": "line", "xsrc": "swifty2205:13:94568f", "ysrc": "swifty2205:13:64158a" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~swifty2205", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/1.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 02:23:05", "mapbox_access_tokens": null, "has_password": null, "username": "swifty2205", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T05:03:55.817937Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~S4051774/1.embed", "fid": "S4051774:1", "filename": "body-fat-percent", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/S4051774:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/S4051774:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/S4051774/1/8_V8W5XACMASOINNA76LTW49W0NTH2NV.png", "list-thumb": "https://api.plotly.com/v2/files/S4051774:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/S4051774:1", "plots": "https://api.plotly.com/v2/plots/S4051774:1", "parent": "https://api.plotly.com/v2/folders/home?user=S4051774" }, "owner": "S4051774", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~S4051774/1/", "world_readable": true, "date_modified": "2024-03-27T05:05:17.963Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~S4051774/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "data.1.x", "y": "data.1.y", "text": "data.1.text", "hoverinfo": "data.1.hoverinfo" } }, "mode": "markers", "type": "scatter", "xsrc": "S4051774:0:209185", "ysrc": "S4051774:0:5c3898", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 262.75, "cmin": 118.5, "line": { "cmax": 262.75, "cmin": 118.5, "meta": { "columnNames": { "color": "data.1.marker.line.color" } }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "S4051774:0:608019", "showscale": false, "colorscale": [ [ "0", "rgba(165,0,38,1)" ], [ "0.0416666666666667", "rgba(186,25,39,1)" ], [ "0.0833333333333334", "rgba(207,42,39,1)" ], [ "0.125", "rgba(222,66,46,1)" ], [ "0.166666666666667", "rgba(235,91,57,1)" ], [ "0.208333333333333", "rgba(245,115,69,1)" ], [ "0.25", "rgba(249,143,82,1)" ], [ "0.291666666666667", "rgba(253,169,94,1)" ], [ "0.333333333333333", "rgba(254,191,112,1)" ], [ "0.375", "rgba(254,212,132,1)" ], [ "0.416666666666667", "rgba(254,229,152,1)" ], [ "0.458333333333333", "rgba(255,242,171,1)" ], [ "0.5", "rgba(255,255,191,1)" ], [ "0.541666666666667", "rgba(244,250,215,1)" ], [ "0.583333333333333", "rgba(230,245,239,1)" ], [ "0.625", "rgba(211,236,244,1)" ], [ "0.666666666666667", "rgba(189,226,238,1)" ], [ "0.708333333333333", "rgba(167,213,231,1)" ], [ "0.75", "rgba(144,195,221,1)" ], [ "0.791666666666667", "rgba(121,177,211,1)" ], [ "0.833333333333333", "rgba(101,154,199,1)" ], [ "0.875", "rgba(82,131,187,1)" ], [ "0.916666666666667", "rgba(67,106,175,1)" ], [ "0.958333333333334", "rgba(59,80,162,1)" ], [ "1", "rgba(49,54,149,1)" ] ] }, "meta": { "columnNames": { "size": "data.1.marker.size", "color": "data.1.marker.color" } }, "sizesrc": "S4051774:0:88e066", "colorbar": { "title": { "text": "Weight" }, "ticklen": 2 }, "colorsrc": "S4051774:0:7a1c8b", "sizemode": "area", "showscale": false, "colorscale": [ [ "0", "rgba(165,0,38,1)" ], [ "0.0416666666666667", "rgba(186,25,39,1)" ], [ "0.0833333333333334", "rgba(207,42,39,1)" ], [ "0.125", "rgba(222,66,46,1)" ], [ "0.166666666666667", "rgba(235,91,57,1)" ], [ "0.208333333333333", "rgba(245,115,69,1)" ], [ "0.25", "rgba(249,143,82,1)" ], [ "0.291666666666667", "rgba(253,169,94,1)" ], [ "0.333333333333333", "rgba(254,191,112,1)" ], [ "0.375", "rgba(254,212,132,1)" ], [ "0.416666666666667", "rgba(254,229,152,1)" ], [ "0.458333333333333", "rgba(255,242,171,1)" ], [ "0.5", "rgba(255,255,191,1)" ], [ "0.541666666666667", "rgba(244,250,215,1)" ], [ "0.583333333333333", "rgba(230,245,239,1)" ], [ "0.625", "rgba(211,236,244,1)" ], [ "0.666666666666667", "rgba(189,226,238,1)" ], [ "0.708333333333333", "rgba(167,213,231,1)" ], [ "0.75", "rgba(144,195,221,1)" ], [ "0.791666666666667", "rgba(121,177,211,1)" ], [ "0.833333333333333", "rgba(101,154,199,1)" ], [ "0.875", "rgba(82,131,187,1)" ], [ "0.916666666666667", "rgba(67,106,175,1)" ], [ "0.958333333333334", "rgba(59,80,162,1)" ], [ "1", "rgba(49,54,149,1)" ] ] }, "error_x": { "width": [] }, "error_y": { "width": [] }, "textsrc": "S4051774:0:085bea", "textfont": { "meta": { "columnNames": { "size": "data.1.textfont.size" } }, "sizesrc": "S4051774:0:609dc6" }, "hoverinfosrc": "S4051774:0:d6a154" }, { "meta": { "columnNames": { "x": "data.2.x", "y": "data.2.y" } }, "mode": "markers", "type": "scatter", "xsrc": "S4051774:0:6d7456", "ysrc": "S4051774:0:d5cbee", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 262.75, "cmin": 118.5, "line": { "color": "rgba(255,127,14,1)" }, "meta": { "columnNames": { "color": "data.2.marker.color" } }, "colorbar": { "x": 1.02, "y": 1, "len": 0.5, "title": { "text": "Weight" }, "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "S4051774:0:4a89c3", "showscale": true, "colorscale": [ [ "0", "rgba(165,0,38,1)" ], [ "0.0416666666666667", "rgba(186,25,39,1)" ], [ "0.0833333333333334", "rgba(207,42,39,1)" ], [ "0.125", "rgba(222,66,46,1)" ], [ "0.166666666666667", "rgba(235,91,57,1)" ], [ "0.208333333333333", "rgba(245,115,69,1)" ], [ "0.25", "rgba(249,143,82,1)" ], [ "0.291666666666667", "rgba(253,169,94,1)" ], [ "0.333333333333333", "rgba(254,191,112,1)" ], [ "0.375", "rgba(254,212,132,1)" ], [ "0.416666666666667", "rgba(254,229,152,1)" ], [ "0.458333333333333", "rgba(255,242,171,1)" ], [ "0.5", "rgba(255,255,191,1)" ], [ "0.541666666666667", "rgba(244,250,215,1)" ], [ "0.583333333333333", "rgba(230,245,239,1)" ], [ "0.625", "rgba(211,236,244,1)" ], [ "0.666666666666667", "rgba(189,226,238,1)" ], [ "0.708333333333333", "rgba(167,213,231,1)" ], [ "0.75", "rgba(144,195,221,1)" ], [ "0.791666666666667", "rgba(121,177,211,1)" ], [ "0.833333333333333", "rgba(101,154,199,1)" ], [ "0.875", "rgba(82,131,187,1)" ], [ "0.916666666666667", "rgba(67,106,175,1)" ], [ "0.958333333333334", "rgba(59,80,162,1)" ], [ "1", "rgba(49,54,149,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "frames": [], "layout": { "title": { "text": "Body Fat Percentage by Abdomen, Weight and Age (point size)" }, "xaxis": { "type": "linear", "range": [ 65.35129267368801, 130.32637966128794 ], "title": { "text": "Abdomen Circumference (in)" }, "domain": [ 0, 1 ], "zeroline": false, "autorange": true, "automargin": true }, "yaxis": { "type": "linear", "range": [ -3.146047675033119, 50.73791486725449 ], "title": { "text": "Body Fat % (Siri Method)" }, "domain": [ 0, 1 ], "zeroline": false, "autorange": true, "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~S4051774", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/96.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 04:17:52", "mapbox_access_tokens": null, "has_password": null, "username": "S4051774", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T04:54:45.087717Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Burnsie79/18.embed", "fid": "Burnsie79:18", "filename": "pricerisk3.26.24", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Burnsie79:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Burnsie79:18/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Burnsie79/18/8_VKIZWBH1R346BAI9D3GIGZ6AS3G1QI.png", "list-thumb": "https://api.plotly.com/v2/files/Burnsie79:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Burnsie79:18", "plots": "https://api.plotly.com/v2/plots/Burnsie79:18", "parent": "https://api.plotly.com/v2/folders/home?user=Burnsie79" }, "owner": "Burnsie79", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Burnsie79/18/", "world_readable": true, "date_modified": "2024-03-27T05:01:49.735Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Burnsie79/18/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Offering Price ($)", "y": "Heat Risk Score" } }, "mode": "markers", "name": "Heat Risk", "type": "scatter", "xsrc": "Burnsie79:17:29e1f1", "ysrc": "Burnsie79:17:fd6ecb", "marker": { "color": "rgb(250, 202, 99)", "symbol": "triangle-se" } }, { "meta": { "columnNames": { "x": "Offering Price ($)", "y": "Fire Risk Score" } }, "mode": "markers", "name": "Fire Risk", "type": "scatter", "xsrc": "Burnsie79:17:29e1f1", "ysrc": "Burnsie79:17:02918f", "marker": { "color": "rgb(239, 59, 88)", "symbol": "triangle-up" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Comparing Property Cost on All Heat and Fire Risk Scores" }, "xaxis": { "type": "linear", "dtick": 1000000, "range": [ -3436519.3223928004, 61106519.3223928 ], "tick0": 50, "ticks": "", "title": { "text": "Price Property is Offered (US Dollar)" }, "nticks": 20, "tickmode": "auto", "autorange": true, "automargin": true, "showspikes": false, "rangeslider": { "range": [ -3436519.3223928004, 61106519.3223928 ], "yaxis": {}, "visible": false, "autorange": true }, "showticklabels": true, "separatethousands": false }, "yaxis": { "type": "linear", "range": [ 0.3572671888598782, 8.642732811140121 ], "title": { "text": "Risk Scores (1-10)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#506784" }, "line": { "color": "rgb(17,17,17)" } }, "header": { "fill": { "color": "#2a3f5f" }, "line": { "color": "rgb(17,17,17)" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" }, "baxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "rgb(17,17,17)", "showland": true, "lakecolor": "rgb(17,17,17)", "landcolor": "rgb(17,17,17)", "showlakes": true, "subunitcolor": "#506784" }, "font": { "color": "#f2f5fa" }, "polar": { "bgcolor": "rgb(17,17,17)", "radialaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "angularaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "yaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "zaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "baxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "caxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "bgcolor": "rgb(17,17,17)" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "rgb(17,17,17)", "paper_bgcolor": "rgb(17,17,17)", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#f2f5fa" }, "sliderdefaults": { "bgcolor": "#C8D4E3", "tickwidth": 0, "bordercolor": "rgb(17,17,17)", "borderwidth": 1 }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#f2f5fa", "arrowwidth": 1 }, "updatemenudefaults": { "bgcolor": "#506784", "borderwidth": 0 } }, "themeRef": "PLOTLY_DARK" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Burnsie79", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-02-01 01:50:39", "mapbox_access_tokens": null, "has_password": null, "username": "Burnsie79", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T04:48:46.736286Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~swifty2205/10.embed", "fid": "swifty2205:10", "filename": "plot from API (5)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/swifty2205/10/9_71CMD4MUKLAG44UT27B0EDD6NP3CHO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/swifty2205/10/2_KORN0J55RJ43TJJ54GT0LQ44MYZKJ7.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/10/8_IMHEEOSTGWIDCKBSRQ89ISEU2CMNRF.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/10/9_71CMD4MUKLAG44UT27B0EDD6NP3CHO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/swifty2205:10", "plots": "https://api.plotly.com/v2/plots/swifty2205:10", "parent": "https://api.plotly.com/v2/folders/home?user=swifty2205" }, "owner": "swifty2205", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~swifty2205/10/", "world_readable": true, "date_modified": "2024-03-27T04:48:47.045Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~swifty2205/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines markers", "type": "line", "xsrc": "swifty2205:11:6c87d9", "ysrc": "swifty2205:11:ba17b1" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~swifty2205", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/1.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 02:23:05", "mapbox_access_tokens": null, "has_password": null, "username": "swifty2205", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T04:48:08.147083Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tdeepanshi248/55.embed", "fid": "tdeepanshi248:55", "filename": "RMSF_chart", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/tdeepanshi248/55/9_51YRER0O2ST2FMSNCX47005AQON8TN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/tdeepanshi248/55/2_WWL855CBYWCF6DV6CMUJ48IMYFZPHM.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/tdeepanshi248/55/8_36SQKZ3O61GD8UWBNRI3H81X5J7JYL.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/tdeepanshi248/55/9_51YRER0O2ST2FMSNCX47005AQON8TN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tdeepanshi248:55", "plots": "https://api.plotly.com/v2/plots/tdeepanshi248:55", "parent": "https://api.plotly.com/v2/folders/home?user=tdeepanshi248" }, "owner": "tdeepanshi248", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 3, "web_url": "https://chart-studio.plotly.com/~tdeepanshi248/55/", "world_readable": true, "date_modified": "2024-04-13T19:13:37.096Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tdeepanshi248/55/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "hole": 0, "line": { "color": "rgb(255, 120, 120)", "shape": "spline" }, "meta": { "columnNames": { "y": "A", "labels": "A", "values": "B" } }, "mode": "lines", "name": "proLC3B", "pull": 0.07, "sort": false, "type": "scatter", "ysrc": "tdeepanshi248:54:453990", "marker": { "line": { "color": "rgb(0, 0, 0)", "width": 1 } }, "rotation": 0, "textfont": { "color": "rgb(0, 0, 0)" }, "textinfo": "label+percent", "direction": "clockwise", "labelssrc": "tdeepanshi248:54:453990", "valuessrc": "tdeepanshi248:54:4a957d", "showlegend": true, "legendgroup": "", "textposition": "middle center" }, { "line": { "color": "rgb(90, 145, 255)", "shape": "spline" }, "meta": { "columnNames": { "y": "B" } }, "mode": "lines", "name": "LC3BII", "type": "scatter", "ysrc": "tdeepanshi248:54:4a957d", "stackgroup": null }, { "line": { "color": "rgb(90, 145, 255)", "shape": "spline" }, "meta": { "columnNames": { "y": "C" } }, "mode": "lines", "type": "scatter", "ysrc": "tdeepanshi248:54:c177df", "showlegend": false, "stackgroup": null }, { "line": { "color": "rgb(90, 145, 255)", "shape": "spline" }, "meta": { "columnNames": { "y": "D" } }, "mode": "lines", "type": "scatter", "ysrc": "tdeepanshi248:54:79a009", "showlegend": false, "stackgroup": null } ], "frames": [], "layout": { "font": { "size": 25, "color": "rgb(0, 0, 0)", "family": "Times New Roman" }, "xaxis": { "range": [ 0, 124 ], "title": { "font": { "size": 25, "family": "Times New Roman" }, "text": "LC3B residues" }, "mirror": "ticks", "showline": true, "autorange": true, "linecolor": "rgb(0, 0, 0)", "linewidth": 1 }, "yaxis": { "type": "linear", "range": [ -0.003866666666666671, 1.0414666666666665 ], "title": { "text": "RMSF (nm)" }, "mirror": "ticks", "showline": true, "autorange": true, "linecolor": "rgb(0, 0, 0)", "linewidth": 1 }, "legend": { "x": 0.00996935024490247, "y": 0.9999999999999997 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": true, "extendpiecolors": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tdeepanshi248", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/71.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2022-05-12 23:50:19", "mapbox_access_tokens": null, "has_password": null, "username": "tdeepanshi248", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-03-27T04:47:32.612956Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~swifty2205/8.embed", "fid": "swifty2205:8", "filename": "plot from API (4)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/swifty2205/8/9_8X0WTQ3I3G0EQKHKLG1YAC0RVEN3A6.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/swifty2205/8/2_IQ09H30L8RB5BJSOTBTF6C8DY6S76P.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/8/8_3TUYT9V8EDQ9J2Y03VAUXT0SMRDB6C.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/swifty2205/8/9_8X0WTQ3I3G0EQKHKLG1YAC0RVEN3A6.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/swifty2205:8", "plots": "https://api.plotly.com/v2/plots/swifty2205:8", "parent": "https://api.plotly.com/v2/folders/home?user=swifty2205" }, "owner": "swifty2205", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 9, "web_url": "https://chart-studio.plotly.com/~swifty2205/8/", "world_readable": true, "date_modified": "2024-03-27T04:47:32.919Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~swifty2205/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines markers", "type": "bar", "xsrc": "swifty2205:9:21bba3", "ysrc": "swifty2205:9:ac3804" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~swifty2205", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/1.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-27 02:23:05", "mapbox_access_tokens": null, "has_password": null, "username": "swifty2205", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
