Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzIyJTNBNTYlM0E1OS41MzkxODMlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzIyJTNBNTElM0EyMC4yNzI5MjMlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsyMiUzQTU2JTNBMzMuNDAwMzgwJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T22:56:33.400380Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~samgrac/29.embed", "fid": "samgrac:29", "filename": "Plot 29", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/samgrac:29/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/samgrac:29/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/samgrac/29/8_0JLEK5HG50PBYI6A3QV58XJQOEP3SW.png", "list-thumb": "https://api.plotly.com/v2/files/samgrac:29/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/samgrac:29", "plots": "https://api.plotly.com/v2/plots/samgrac:29", "parent": "https://api.plotly.com/v2/folders/home?user=samgrac" }, "owner": "samgrac", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~samgrac/29/", "world_readable": true, "date_modified": "2019-03-20T22:56:33.414Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~samgrac/29/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "type": "scatter", "xsrc": "samgrac:28:2c249c", "ysrc": "samgrac:28:85bacc", "hoverinfo": "x+y", "showlegend": false, "hovertemplate": "" }, { "mode": "markers", "name": "percentuálna úspešnosť siete", "type": "scatter", "xsrc": "samgrac:28:2c249c", "ysrc": "samgrac:28:85bacc", "opacity": 1 } ], "frames": [], "layout": { "title": { "text": "Úspešnosť siete na testovacích vzorkách v závislosti od počtu okien" }, "xaxis": { "type": "category", "range": [ -0.24465078724263226, 4.244650787242632 ], "title": { "text": "počeť okien" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 51.163781374618814, 65.63621862538119 ], "title": { "text": "úspešnosť siete [%]" }, "autorange": true }, "legend": { "x": 0.6945314101222025, "y": 1.1431535269709543 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~samgrac", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-21 21:51:07", "mapbox_access_tokens": null, "has_password": null, "username": "samgrac", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:55:34.226199Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ekin.akkol/154.embed", "fid": "ekin.akkol:154", "filename": "plot from API (20)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ekin.akkol:154/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ekin.akkol:154/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ekin.akkol/154/8_L88HHRD881AYJOI86QHAH8HX3MSRJX.png", "list-thumb": "https://api.plotly.com/v2/files/ekin.akkol:154/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ekin.akkol:154", "plots": "https://api.plotly.com/v2/plots/ekin.akkol:154", "parent": "https://api.plotly.com/v2/folders/home?user=ekin.akkol" }, "owner": "ekin.akkol", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Yangin Sayısı", "views": 0, "web_url": "https://chart-studio.plotly.com/~ekin.akkol/154/yangin-says/", "world_readable": true, "date_modified": "2019-03-20T22:55:34.973Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ekin.akkol/154/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e8248f46-3bb7-48af-a085-3c6802dd1784", "line": { "color": "red" }, "type": "scatter", "xsrc": "ekin.akkol:155:8df658", "ysrc": "ekin.akkol:155:9905b9" } ], "layout": { "title": { "text": "Yangin Sayısı" }, "xaxis": { "type": "date", "rangeslider": { "visible": true }, "rangeselector": { "buttons": [ { "step": "all" } ] } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ekin.akkol", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/85.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-09 15:03:14", "mapbox_access_tokens": null, "has_password": null, "username": "ekin.akkol", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:54:26.745091Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~LuisR21/1.embed", "fid": "LuisR21:1", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/LuisR21:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/LuisR21:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/LuisR21:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/LuisR21:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/LuisR21:1", "plots": "https://api.plotly.com/v2/plots/LuisR21:1", "parent": "https://api.plotly.com/v2/folders/home?user=LuisR21" }, "owner": "LuisR21", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "distribución de los rasgos de las flores iris", "views": 0, "web_url": "https://chart-studio.plotly.com/~LuisR21/1/distribucion-de-los-rasgos-de-las-flores-iris/", "world_readable": true, "date_modified": "2019-03-20T22:54:26.765Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~LuisR21/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "x": [], "uid": "8685d087-2dca-4273-a2fa-0a173b8fd3b0", "name": "setosa", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "b8974d1d-c701-4dda-ae5d-08d44dca259d", "name": "versicolor", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "5241e960-1f43-49a1-a0a8-4c8968604310", "name": "virginica", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "c553c83c-54c4-40de-a7af-f1b563d88c8f", "name": "setosa", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "18bc0b27-6b37-4917-b3d1-0496028f552a", "name": "versicolor", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "afb693f5-0176-4872-a8fb-f7e436db892b", "name": "virginica", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "04cb6a1c-511a-41a3-97d8-00a1c1ab7554", "name": "setosa", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "b0714cf6-3cf4-4401-9535-c828d5559f9e", "name": "versicolor", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "d5e4c2b7-6f74-436f-9fda-116866010f65", "name": "virginica", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "4695278b-9c09-45e6-8bf9-4214f1ff39d0", "name": "setosa", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "5c76fc23-3b26-47e0-abd5-ac86b7b867f0", "name": "versicolor", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "a0572a60-fb4f-49c7-ab61-c503ae1da12c", "name": "virginica", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 } ], "layout": { "title": { "text": "distribución de los rasgos de las flores iris" }, "xaxis": { "title": { "text": "largo sépalo (cms)" }, "domain": [ 0, 0.25 ] }, "yaxis": { "title": { "text": "Número de ejemplares" } }, "xaxis2": { "title": { "text": "ancho sépalo (cms)" }, "domain": [ 0.3, 0.5 ] }, "xaxis3": { "title": { "text": "largo pétalo (cms)" }, "domain": [ 0.55, 0.75 ] }, "xaxis4": { "title": { "text": "ancho pétalo (cms)" }, "domain": [ 0.8, 1.0 ] }, "barmode": "overlay" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~LuisR21", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 22:34:52", "mapbox_access_tokens": null, "has_password": null, "username": "LuisR21", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:54:18.967103Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~andressadagostin/1.embed", "fid": "andressadagostin:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/andressadagostin/1/9_EX3OIPEES4IZX3R56VPN18IK860SES.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/andressadagostin/1/2_KQWGER6CHT4P05TS6HJLVAWXLP23XT.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/andressadagostin/1/8_CKTHFET7WNSJNFU28OV0MO7KJVGNI2.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/andressadagostin/1/9_EX3OIPEES4IZX3R56VPN18IK860SES.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/andressadagostin:1", "plots": "https://api.plotly.com/v2/plots/andressadagostin:1", "parent": "https://api.plotly.com/v2/folders/home?user=andressadagostin" }, "owner": "andressadagostin", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 5, "web_url": "https://chart-studio.plotly.com/~andressadagostin/1/", "world_readable": true, "date_modified": "2019-03-21T01:09:40.154Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~andressadagostin/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "5ce450", "mode": "markers", "name": "Life Expectancy", "type": "scatter", "xsrc": "andressadagostin:0:7e01d5", "ysrc": "andressadagostin:0:d9d94b", "marker": { "color": "#636efa" } }, { "uid": "d57558", "name": "", "visible": false, "transforms": [ { "rms": "", "type": "fit", "inputUid": "5ce450", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.05208809245129993, "value": 0.18277721460783644 }, { "hold": false, "name": "b", "error": 3.905808772146501, "value": -6.118987012206661 } ], "regressand": "y", "correlation": "", "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] } ], "frames": [], "layout": { "font": { "family": "Times New Roman" }, "title": { "font": { "size": 19 }, "text": "<b>Graph 2: Health Expenditure (% of GDP) vs. Life Expectancy (years) excluding outliers</b>" }, "xaxis": { "type": "linear", "range": [ 60.66439144736842, 85.13560855263158 ], "title": { "font": { "size": 16 }, "text": "<b>Life Expectancy (years)</b>" }, "nticks": 15, "showline": true, "tickfont": { "size": 16 }, "autorange": true, "linewidth": 2, "rangeslider": { "range": [ 49.41496710526316, 85.78503289473684 ], "yaxis": {}, "visible": false, "autorange": true } }, "yaxis": { "type": "linear", "range": [ 2.726902570003836, 12.683097429996165 ], "title": { "font": { "size": 16 }, "text": "<b>Health Expenditure (% of GDP)</b>" }, "nticks": 9, "tickfont": { "size": 16 }, "autorange": true, "gridwidth": 1 }, "shapes": [], "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~andressadagostin", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 22:53:57", "mapbox_access_tokens": null, "has_password": null, "username": "andressadagostin", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:53:26.251691Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~selinaln/1.embed", "fid": "selinaln:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/selinaln:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/selinaln:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/selinaln:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/selinaln:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/selinaln:1", "plots": "https://api.plotly.com/v2/plots/selinaln:1", "parent": "https://api.plotly.com/v2/folders/home?user=selinaln" }, "owner": "selinaln", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~selinaln/1/", "world_readable": true, "date_modified": "2019-03-28T18:43:10.819Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~selinaln/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "selinaln:0:a11551", "ysrc": "selinaln:0:c9ada6" } ], "frames": [], "layout": { "title": { "text": "Cost for Renting and Renovating a Store " }, "xaxis": { "type": "linear", "range": [ -0.803921568627451, 13.803921568627452 ], "title": { "text": "Months" }, "domain": [ 0, 1 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -522.9312354312353, 7072.931235431235 ], "title": { "text": "Cost ($)" }, "domain": [ 0, 1 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~selinaln", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 22:52:25", "mapbox_access_tokens": null, "has_password": null, "username": "selinaln", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:52:58.919247Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~LuisR21/0.embed", "fid": "LuisR21:0", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/LuisR21:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/LuisR21:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/LuisR21:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/LuisR21:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/LuisR21:0", "plots": "https://api.plotly.com/v2/plots/LuisR21:0", "parent": "https://api.plotly.com/v2/folders/home?user=LuisR21" }, "owner": "LuisR21", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "distribución de los rasgos de las flores iris", "views": 0, "web_url": "https://chart-studio.plotly.com/~LuisR21/0/distribucion-de-los-rasgos-de-las-flores-iris/", "world_readable": true, "date_modified": "2019-03-20T22:52:58.935Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~LuisR21/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "x": [], "uid": "84d69517-16f0-4ecd-ad52-f5bce18b910b", "name": "setosa", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "ecc8c70c-1658-44ef-a5ea-f7d1b325d116", "name": "versicolor", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "88a6138b-649e-412f-9746-ba964febe5a4", "name": "virginica", "type": "histogram", "xaxis": "x", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "aa0758c9-06b9-4f7f-9cc0-9b0c0e058479", "name": "setosa", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "ec4b9539-4e22-4c78-8208-ef9d29ecd97c", "name": "versicolor", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "eae303b8-bc55-470e-ac2f-78fc82326391", "name": "virginica", "type": "histogram", "xaxis": "x2", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "98366c4a-a519-4403-a41c-dd338488275a", "name": "setosa", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "5acfeb7a-9f57-40de-b88d-30075cf125f7", "name": "versicolor", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "8f4212a0-58b7-4c3d-a010-a72129d6db87", "name": "virginica", "type": "histogram", "xaxis": "x3", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 }, { "x": [], "uid": "4818d7d7-d428-4bde-93a7-4dfbfcb530b9", "name": "setosa", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(255,127,20)" }, "opacity": 0.7 }, { "x": [], "uid": "2563ed84-23d0-427c-8f33-365d6d4a845a", "name": "versicolor", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(31,220,120)" }, "opacity": 0.7 }, { "x": [], "uid": "7a80cf99-f599-447a-b20f-de0ecf685448", "name": "virginica", "type": "histogram", "xaxis": "x4", "marker": { "color": "rgb(44,50,180)" }, "opacity": 0.7 } ], "layout": { "title": { "text": "distribución de los rasgos de las flores iris" }, "xaxis": { "title": { "text": "largo sépalo (cms)" }, "domain": [ 0, 0.25 ] }, "yaxis": { "title": { "text": "Número de ejemplares" } }, "xaxis2": { "title": { "text": "ancho sépalo (cms)" }, "domain": [ 0.3, 0.5 ] }, "xaxis3": { "title": { "text": "largo pétalo (cms)" }, "domain": [ 0.55, 0.75 ] }, "xaxis4": { "title": { "text": "ancho pétalo (cms)" }, "domain": [ 0.8, 1.0 ] }, "barmode": "overlay" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~LuisR21", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 22:34:52", "mapbox_access_tokens": null, "has_password": null, "username": "LuisR21", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:52:57.338652Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~lubos.mjachky/3.embed", "fid": "lubos.mjachky:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/lubos.mjachky:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/lubos.mjachky:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/lubos.mjachky/3/8_SX2LNZV9BKSUUJT5FE2R1STGGZ57QZ.png", "list-thumb": "https://api.plotly.com/v2/files/lubos.mjachky:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/lubos.mjachky:3", "plots": "https://api.plotly.com/v2/plots/lubos.mjachky:3", "parent": "https://api.plotly.com/v2/folders/home?user=lubos.mjachky" }, "owner": "lubos.mjachky", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~lubos.mjachky/3/", "world_readable": true, "date_modified": "2019-03-20T22:52:57.358Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~lubos.mjachky/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "name": "Meranie 1", "type": "scatter", "xsrc": "lubos.mjachky:2:5e9c17", "ysrc": "lubos.mjachky:2:85f314", "visible": true, "decreasing": { "line": { "color": "#7f7f7f" }, "fillcolor": "rgba(127, 127, 127, 0.5)" }, "increasing": { "line": { "color": "#17becf" }, "fillcolor": "rgba(23, 190, 207, 0.5)" } }, { "mode": "lines", "name": "Meranie 2", "type": "scatter", "xsrc": "lubos.mjachky:2:837c9a", "ysrc": "lubos.mjachky:2:59c5a7", "visible": true, "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 62.76923, 991.4615 ], "title": { "text": "Čas výpočtu (µs)" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -10.722222222222218, 263.72222222222223 ], "title": { "text": "Počet prvkov" }, "autorange": true }, "legend": { "x": 1.0107407407407407, "y": 1 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~lubos.mjachky", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/78.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 22:28:28", "mapbox_access_tokens": null, "has_password": null, "username": "lubos.mjachky", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:51:39.914477Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mjaudon/3.embed", "fid": "mjaudon:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mjaudon:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/mjaudon:3/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/mjaudon:3/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/mjaudon:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mjaudon:3", "plots": "https://api.plotly.com/v2/plots/mjaudon:3", "parent": "https://api.plotly.com/v2/folders/home?user=mjaudon" }, "owner": "mjaudon", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~mjaudon/3/", "world_readable": true, "date_modified": "2019-03-20T23:05:14.694Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mjaudon/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "heatmap", "xsrc": "mjaudon:0:90c336", "ysrc": "mjaudon:0:3a8a51", "zsrc": "mjaudon:0:691b56,8d56b8,010d25,84444c,e4c3ba,2a4f80,96309f,6d61f9", "contours": { "end": 9, "size": 1, "start": 1 }, "autocontour": true, "autocolorscale": true } ], "frames": [], "layout": { "title": { "text": "Heat Map Concentric Circles" }, "xaxis": { "type": "linear", "range": [ 0, 4 ], "title": { "text": "X-axis" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 7 ], "title": { "text": "Y-Axis" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mjaudon", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/78.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-15 14:07:54", "mapbox_access_tokens": null, "has_password": null, "username": "mjaudon", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:51:34.509140Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mjaudon/2.embed", "fid": "mjaudon:2", "filename": "TwoPlanes", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mjaudon:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/mjaudon:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/mjaudon:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/mjaudon:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mjaudon:2", "plots": "https://api.plotly.com/v2/plots/mjaudon:2", "parent": "https://api.plotly.com/v2/folders/home?user=mjaudon" }, "owner": "mjaudon", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~mjaudon/2/", "world_readable": true, "date_modified": "2019-03-20T23:05:08.369Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mjaudon/2/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "heatmap", "xsrc": "mjaudon:1:e09e52", "ysrc": "mjaudon:1:b32277", "zsrc": "mjaudon:1:369b4b,790abf,2cef90,73802b,3b00e5,baf743,ccb2c4,6e9c19,f595ee,e60702,9ffbe0", "contours": { "end": 9, "size": 1, "start": 1 }, "autocontour": true, "autocolorscale": true } ], "frames": [], "layout": { "title": { "text": "Two Planes" }, "xaxis": { "type": "linear", "range": [ 0, 5.5 ], "title": { "text": "X-Axis" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.25, 7.25 ], "title": { "text": "Y-Axis" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mjaudon", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/78.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-15 14:07:54", "mapbox_access_tokens": null, "has_password": null, "username": "mjaudon", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:51:20.272923Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~bipint63/20.embed", "fid": "bipint63:20", "filename": "Plot 20", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/bipint63/20/9_9T29357R3NTONDX14YDJYDOWA2P88B.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/bipint63/20/2_H6YY0RNCQLI5YJAVOTOC4XRTFY6ZP6.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/bipint63/20/8_X38CBUN67IO8A85BMLAZ4PDGIW34BY.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/bipint63/20/9_9T29357R3NTONDX14YDJYDOWA2P88B.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/bipint63:20", "plots": "https://api.plotly.com/v2/plots/bipint63:20", "parent": "https://api.plotly.com/v2/folders/home?user=bipint63" }, "owner": "bipint63", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 16, "web_url": "https://chart-studio.plotly.com/~bipint63/20/", "world_readable": true, "date_modified": "2019-03-20T22:51:20.291Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~bipint63/20/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:8d50f9", "lonsrc": "bipint63:19:4d7318", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:f657ec", "lonsrc": "bipint63:19:592898", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:beb10e", "lonsrc": "bipint63:19:7ce034", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:c5cc26", "lonsrc": "bipint63:19:a23d68", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:66766f", "lonsrc": "bipint63:19:5723f0", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:855104", "lonsrc": "bipint63:19:aa44fd", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:18e5b1", "lonsrc": "bipint63:19:147e32", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:ddc743", "lonsrc": "bipint63:19:493593", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:63e603", "lonsrc": "bipint63:19:a9c7ac", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:49e0cf", "lonsrc": "bipint63:19:b2b9bc", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:24c34b", "lonsrc": "bipint63:19:b1092a", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:565455", "lonsrc": "bipint63:19:92785f", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:a2a14d", "lonsrc": "bipint63:19:0eff6b", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:89e5db", "lonsrc": "bipint63:19:095e51", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:396567", "lonsrc": "bipint63:19:9f9b62", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:c84b17", "lonsrc": "bipint63:19:efb368", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:279040", "lonsrc": "bipint63:19:c6dfcb", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:0117ba", "lonsrc": "bipint63:19:99c2ea", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:fb543a", "lonsrc": "bipint63:19:f79ee5", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:4dd8f0", "lonsrc": "bipint63:19:5df9b5", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:e9009d", "lonsrc": "bipint63:19:f1a9fb", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:ef3a18", "lonsrc": "bipint63:19:7391ef", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:b635e5", "lonsrc": "bipint63:19:8002ec", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:347a2a", "lonsrc": "bipint63:19:820c9e", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:9cb8ab", "lonsrc": "bipint63:19:1b3fb9", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:9d7fc3", "lonsrc": "bipint63:19:fb68b4", "locationmode": "USA-states" }, { "line": { "color": "blue", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "bipint63:19:a25918", "lonsrc": "bipint63:19:84d603", "locationmode": "USA-states" }, { "mode": "markers", "type": "scattergeo", "latsrc": "bipint63:19:b36ad8", "lonsrc": "bipint63:19:ba52ce", "marker": { "line": { "color": "red", "width": 3 }, "size": 5, "color": "red" }, "textsrc": "bipint63:19:3ab319", "hoverinfo": "text", "locationmode": "USA-states" } ], "frames": [], "layout": { "geo": { "scope": "north america", "showland": true, "landcolor": "rgb(243, 243, 243)", "projection": { "type": "azimuthal equal area", "scale": 1 }, "countrycolor": "rgb(204, 204, 204)" }, "title": { "text": "CIE Freight Plan <br> (Hover for Terminal Names)" }, "autosize": true, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~bipint63", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/12.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-16 13:28:34", "mapbox_access_tokens": null, "has_password": null, "username": "bipint63", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
