Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzIyJTNBMTklM0EwMS4xMDkzNzYlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzIyJTNBMTMlM0E1NS42ODAzNTElMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsyMiUzQTE3JTNBNTcuNTg1ODkzJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T22:17:57.585893Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/61545.embed", "fid": "amper:61545", "filename": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c3_resolution-LOW", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:61545/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:61545/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:61545/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:61545/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:61545", "plots": "https://api.plotly.com/v2/plots/amper:61545", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c3_resolution-LOW", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/61545/raw-amps-03-20-19-ds-key-3f710000cb4a002c0047600f45164e45-c3-resolution-low/", "world_readable": true, "date_modified": "2019-03-20T22:17:58.603Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/61545/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines+markers", "name": "raw_amps", "type": "scattergl", "xsrc": "amper:61546:8929c1", "ysrc": "amper:61546:3b8981" } ], "layout": { "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c3_resolution-LOW" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:17:50.385246Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/61543.embed", "fid": "amper:61543", "filename": "03-20-19_ds-1556_alg-5421_param-1211_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:61543/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:61543/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:61543/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:61543/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:61543", "plots": "https://api.plotly.com/v2/plots/amper:61543", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "03-20-19_ds-1556_alg-5421_param-1211_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/61543/_03-20-19-ds-1556-alg-5421-param-1211-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-03-20T22:17:51.624Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/61543/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "273a14ee-6122-401f-a7d5-9a2dfbc22a16", "mode": "lines", "name": "Off", "type": "scattergl", "xsrc": "amper:61544:22a076", "ysrc": "amper:61544:6b4639", "marker": { "line": { "color": "rgb(248, 19, 0)", "width": 1 }, "size": 1, "color": "rgb(248, 19, 0)" } }, { "uid": "9c3c6ca3-b0eb-4b23-9c02-86976eccbb85", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:61544:22a076", "ysrc": "amper:61544:dd93bf", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "825db609-1ebc-4227-9608-e475a9a7bdce", "mode": "lines", "name": "Production", "type": "scattergl", "xsrc": "amper:61544:22a076", "ysrc": "amper:61544:850b1c", "marker": { "line": { "color": "rgb(0, 166, 73)", "width": 1 }, "size": 1, "color": "rgb(0, 166, 73)" }, "connectgaps": false } ], "layout": { "title": "03-20-19_ds-1556_alg-5421_param-1211_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:16:54.807010Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~smileandsaydl/341.embed", "fid": "smileandsaydl:341", "filename": "plot from API (11)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/smileandsaydl:341/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/smileandsaydl:341/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/smileandsaydl/341/8_IY55CSS0LBTV5S800Q7DG9SOMEFPKG.png", "list-thumb": "https://api.plotly.com/v2/files/smileandsaydl:341/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/smileandsaydl:341", "plots": "https://api.plotly.com/v2/plots/smileandsaydl:341", "parent": "https://api.plotly.com/v2/folders/home?user=smileandsaydl" }, "owner": "smileandsaydl", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Log-marginal-likelihood", "views": 0, "web_url": "https://chart-studio.plotly.com/~smileandsaydl/341/log-marginal-likelihood/", "world_readable": true, "date_modified": "2019-03-20T22:16:55.382Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~smileandsaydl/341/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "cfc7ead0-4b5d-11e9-b064-408d5c757ebb", "type": "heatmap", "xsrc": "smileandsaydl:342:d9362d", "ysrc": "smileandsaydl:342:c6a77d", "zsrc": "smileandsaydl:342:-d9362d,c6a77d,d7b7db,889452,f1d0d1,b2862a", "colorscale": "Jet" }, { "uid": "cfc7ead1-4b5d-11e9-a282-408d5c757ebb", "mode": "markers", "type": "scatter", "xsrc": "smileandsaydl:342:d7b7db", "ysrc": "smileandsaydl:342:889452", "marker": { "color": "black" }, "showlegend": false }, { "uid": "cfc7ead2-4b5d-11e9-8c86-408d5c757ebb", "mode": "markers", "type": "scatter", "xsrc": "smileandsaydl:342:f1d0d1", "ysrc": "smileandsaydl:342:b2862a", "marker": { "color": "black" }, "showlegend": false } ], "layout": { "title": "Log-marginal-likelihood", "xaxis": { "type": "log", "title": "Magnitude" }, "yaxis": { "type": "log", "title": "Length-scale" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~smileandsaydl", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/55.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-24 14:45:44", "mapbox_access_tokens": null, "has_password": null, "username": "smileandsaydl", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:16:36.422972Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~smileandsaydl/339.embed", "fid": "smileandsaydl:339", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/smileandsaydl:339/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/smileandsaydl:339/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/smileandsaydl/339/8_YQ0QVZTV1WBII4ED9M149KY8WJFDJC.png", "list-thumb": "https://api.plotly.com/v2/files/smileandsaydl:339/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/smileandsaydl:339", "plots": "https://api.plotly.com/v2/plots/smileandsaydl:339", "parent": "https://api.plotly.com/v2/folders/home?user=smileandsaydl" }, "owner": "smileandsaydl", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Class 1 probability vs Feature", "views": 0, "web_url": "https://chart-studio.plotly.com/~smileandsaydl/339/class-1-probability-vs-feature/", "world_readable": true, "date_modified": "2019-03-20T22:16:36.949Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~smileandsaydl/339/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c12b399e-4b5d-11e9-ad36-408d5c757ebb", "mode": "markers", "name": "Train data", "type": "scatter", "xsrc": "smileandsaydl:340:a86c08", "ysrc": "smileandsaydl:340:80446f", "marker": { "color": "black" } }, { "uid": "c12b399f-4b5d-11e9-b20f-408d5c757ebb", "mode": "markers", "name": "Test data", "type": "scatter", "xsrc": "smileandsaydl:340:a0b33d", "ysrc": "smileandsaydl:340:8c59bc", "marker": { "color": "green" } }, { "uid": "c12b39a0-4b5d-11e9-a20d-408d5c757ebb", "line": { "color": "red" }, "mode": "lines", "name": "Initial kernel: 1**2 * RBF(length_scale=1)", "type": "scatter", "xsrc": "smileandsaydl:340:defe5f", "ysrc": "smileandsaydl:340:094c3c" }, { "uid": "c12b60b0-4b5d-11e9-88c4-408d5c757ebb", "line": { "color": "blue" }, "mode": "lines", "name": "Optimized kernel: 66.3**2 * RBF(length_scale=1.33)", "type": "scatter", "xsrc": "smileandsaydl:340:defe5f", "ysrc": "smileandsaydl:340:cb4013" } ], "layout": { "xaxis": { "title": "Feature" }, "yaxis": { "title": "Class 1 probability" }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~smileandsaydl", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/55.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-24 14:45:44", "mapbox_access_tokens": null, "has_password": null, "username": "smileandsaydl", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:16:29.117777Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/61541.embed", "fid": "amper:61541", "filename": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c2_resolution-LOW", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:61541/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:61541/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:61541/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:61541/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:61541", "plots": "https://api.plotly.com/v2/plots/amper:61541", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c2_resolution-LOW", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/61541/raw-amps-03-20-19-ds-key-3f710000cb4a002c0047600f45164e45-c2-resolution-low/", "world_readable": true, "date_modified": "2019-03-20T22:56:13.021Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/61541/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines+markers", "name": "raw_amps", "type": "scattergl", "xsrc": "amper:61542:b36560", "ysrc": "amper:61542:864813" } ], "layout": { "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c2_resolution-LOW" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:15:36.651584Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~madelineahamilton/6.embed", "fid": "madelineahamilton:6", "filename": "simple-3d-scatter", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/madelineahamilton:6/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/madelineahamilton/6/2_YET2ET9H67DIQV1AJLD9RZT1HZGN9B.png", "block-thumb": "https://api.plotly.com/v2/files/madelineahamilton:6/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/madelineahamilton:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/madelineahamilton:6", "plots": "https://api.plotly.com/v2/plots/madelineahamilton:6", "parent": "https://api.plotly.com/v2/folders/home?user=madelineahamilton" }, "owner": "madelineahamilton", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 54, "web_url": "https://chart-studio.plotly.com/~madelineahamilton/6/", "world_readable": true, "date_modified": "2019-05-09T03:19:34.965Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~madelineahamilton/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter3d", "xsrc": "madelineahamilton:7:0142c6", "ysrc": "madelineahamilton:7:a4946f", "zsrc": "madelineahamilton:7:5df92b", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 1, "opacity": 0.8 } }, { "mode": "markers", "type": "scatter3d", "xsrc": "madelineahamilton:7:5dbc31", "ysrc": "madelineahamilton:7:e7f2e5", "zsrc": "madelineahamilton:7:908965", "marker": { "line": { "color": "rgb(204, 204, 204)", "width": 1 }, "size": 2, "color": "g", "symbol": "circle", "opacity": 0.9 } }, { "mode": "markers", "type": "scatter3d", "xsrc": "madelineahamilton:7:5dbc31", "ysrc": "madelineahamilton:7:e7f2e5", "zsrc": "madelineahamilton:7:908965", "marker": { "line": { "color": "rgb(204, 204, 204)", "width": 1 }, "size": 2, "color": "r", "symbol": "circle", "opacity": 0.9 } }, { "mode": "markers", "type": "scatter3d", "xsrc": "madelineahamilton:7:5dbc31", "ysrc": "madelineahamilton:7:e7f2e5", "zsrc": "madelineahamilton:7:908965", "marker": { "line": { "color": "rgb(204, 204, 204)", "width": 1 }, "size": 2, "color": "y", "symbol": "circle", "opacity": 0.9 } }, { "mode": "markers", "type": "scatter3d", "xsrc": "madelineahamilton:7:5dbc31", "ysrc": "madelineahamilton:7:e7f2e5", "zsrc": "madelineahamilton:7:908965", "marker": { "line": { "color": "rgb(204, 204, 204)", "width": 1 }, "size": 2, "color": "k", "symbol": "circle", "opacity": 0.9 } } ], "layout": { "margin": { "b": 0, "l": 0, "r": 0, "t": 0 } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~madelineahamilton", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-02 20:03:00", "mapbox_access_tokens": null, "has_password": null, "username": "madelineahamilton", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:14:38.540432Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~prattitl/156.embed", "fid": "prattitl:156", "filename": "1in Cork Panel", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/prattitl:156/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/prattitl/156/2_AUFWOGGSQPZ4T6BW9YVBULXPMZ6EJV.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/prattitl/156/8_00AGHPSY5U654ZAU1FYT7AW3ZBUE74.png", "list-thumb": "https://api.plotly.com/v2/files/prattitl:156/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/prattitl:156", "plots": "https://api.plotly.com/v2/plots/prattitl:156", "parent": "https://api.plotly.com/v2/folders/prattitl:151" }, "owner": "prattitl", "parent": 151, "preview": "", "referencers": [], "references": [], "title": "<b>SPL(dB)</b> vs <b>Frequency(Hz)</b>", "views": 492, "web_url": "https://chart-studio.plotly.com/~prattitl/156/spldb-vs-frequencyhz/", "world_readable": true, "date_modified": "2019-03-20T22:14:39.044Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~prattitl/156/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b3ed1dcc-ff24-4435-b853-3fed9b4990d0", "fill": "tozeroy", "line": { "color": "rgb(0,0,0)", "width": 1 }, "mode": "lines", "name": "1_cork", "type": "scatter", "xsrc": "prattitl:157:db51b1", "ysrc": "prattitl:157:1df9f7" } ], "layout": { "xaxis": { "type": "log", "title": { "text": "<b>Frequency(Hz)</b>" }, "showgrid": true, "showline": true, "autorange": true, "showticklabels": true }, "yaxis": { "range": [ -20, 30 ], "title": { "text": "<b>SPL(dB)</b>" }, "showgrid": true, "showline": false, "zeroline": false, "showticklabels": true }, "margin": { "b": 40, "l": 40, "r": 20, "t": 50, "autoexpand": false }, "shapes": [ { "x0": 125, "x1": 4000, "y0": 24, "y1": 27, "line": { "color": "rgba(0,0,0,0)", "width": 0 }, "type": "rect", "fillcolor": "rgba(0, 0, 0, 0.05)" }, { "x0": 20, "x1": 500, "y0": 27, "y1": 30, "line": { "color": "rgba(0, 0, 0, 0.1)", "width": 0 }, "type": "rect", "fillcolor": "rgba(0, 0, 0, 0.05)" }, { "x0": 2000, "x1": 20000, "y0": 27, "y1": 30, "line": { "color": "rgba(0, 0, 0, 0.1)", "width": 0 }, "type": "rect", "fillcolor": "rgba(0, 0, 0, 0.05)" } ], "autosize": true, "showlegend": false, "annotations": [ { "x": 0.52, "y": 0.89, "font": { "size": 10, "color": "rgb(0,0,0)", "family": "Droid Sans" }, "text": "Human Voice Frequency Range", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.25, "y": 0.95, "font": { "size": 10, "color": "rgb(0,0,0)", "family": "Droid Sans" }, "text": "low Frequency Range", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.825, "y": 0.95, "font": { "size": 10, "color": "rgb(0,0,0)", "family": "Droid Sans" }, "text": "high Frequency Range", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.06, "y": -0.09, "font": { "size": 8, "color": "rgb(0,0,0)", "family": "Droid Sans" }, "text": "Source Recording by Pratt ITL", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 1.01, "font": { "size": 14, "color": "rgb(0,0,0)", "family": "Droid Sans" }, "text": "1\" Cork Panel", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~prattitl", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/LYXVOQZL4YZ970MCGV564W96RE2T47.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-04 21:12:04", "mapbox_access_tokens": null, "has_password": null, "username": "prattitl", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:14:35.906310Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/61539.embed", "fid": "amper:61539", "filename": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c1_resolution-LOW", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:61539/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:61539/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:61539/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:61539/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:61539", "plots": "https://api.plotly.com/v2/plots/amper:61539", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c1_resolution-LOW", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/61539/raw-amps-03-20-19-ds-key-3f710000cb4a002c0047600f45164e45-c1-resolution-low/", "world_readable": true, "date_modified": "2019-03-20T22:14:36.704Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/61539/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines+markers", "name": "raw_amps", "type": "scattergl", "xsrc": "amper:61540:f047d5", "ysrc": "amper:61540:8b807c" } ], "layout": { "title": "raw_amps_03-20-19_ds_key-3f710000cb4a002c0047600f45164e45_c1_resolution-LOW" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:13:57.224525Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~xpedro/8.embed", "fid": "xpedro:8", "filename": "plot from API (3)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/xpedro:8/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/xpedro:8/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/xpedro:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/xpedro:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/xpedro:8", "plots": "https://api.plotly.com/v2/plots/xpedro:8", "parent": "https://api.plotly.com/v2/folders/home?user=xpedro" }, "owner": "xpedro", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Total Revenue by Traffic Source<br>(day of week)", "views": 0, "web_url": "https://chart-studio.plotly.com/~xpedro/8/total-revenue-by-traffic-source-day-of-week/", "world_readable": true, "date_modified": "2019-03-20T22:13:57.634Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~xpedro/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "bea493b5-54ec-4100-9379-302268cdbc17", "type": "heatmap", "xsrc": "xpedro:9:6117dd", "ysrc": "xpedro:9:41411e", "zsrc": "xpedro:9:abd23b,899f25,da8703,8bad39,1cfdcb,bee19a,7c6d31", "colorscale": "Reds" } ], "layout": { "title": { "text": "Total Revenue by Traffic Source<br>(day of week)" }, "margin": { "l": 150 } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~xpedro", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-03 03:04:07", "mapbox_access_tokens": null, "has_password": null, "username": "xpedro", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T22:13:55.680351Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/61537.embed", "fid": "amper:61537", "filename": "03-20-19_ds-1553_alg-5421_param-1208_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:61537/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:61537/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:61537/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:61537/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:61537", "plots": "https://api.plotly.com/v2/plots/amper:61537", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "03-20-19_ds-1553_alg-5421_param-1208_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/61537/_03-20-19-ds-1553-alg-5421-param-1208-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-03-20T22:13:56.618Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/61537/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f418ebcf-29d7-43c0-9762-a911468c7fa3", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:61538:bb5988", "ysrc": "amper:61538:b0325b", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "6173e4ff-d1ca-4caf-84f0-11f1a952485e", "mode": "lines", "name": "Production", "type": "scattergl", "xsrc": "amper:61538:bb5988", "ysrc": "amper:61538:c334fd", "marker": { "line": { "color": "rgb(0, 166, 73)", "width": 1 }, "size": 1, "color": "rgb(0, 166, 73)" }, "connectgaps": false } ], "layout": { "title": "03-20-19_ds-1553_alg-5421_param-1208_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
