Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzIxJTNBNDclM0EwOC4yODM3ODglMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzIxJTNBNDAlM0E1OC4zODIyMjYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsyMSUzQTQ2JTNBMjcuMDc4Mzg0JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T21:46:27.078384Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ar795/4.embed", "fid": "ar795:4", "filename": "Plot 4", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ar795:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ar795:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ar795:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ar795:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ar795:4", "plots": "https://api.plotly.com/v2/plots/ar795:4", "parent": "https://api.plotly.com/v2/folders/home?user=ar795" }, "owner": "ar795", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~ar795/4/", "world_readable": true, "date_modified": "2019-03-20T21:59:49.178Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ar795/4/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "name": "RDF", "type": "scatter", "ysrc": "ar795:3:d2faa2" }, { "mode": "lines", "name": "DF ", "type": "scatter", "ysrc": "ar795:3:722e9d", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "RDF VS DF -Seed 4-" }, "xaxis": { "range": [ 0, 199 ], "title": { "text": "Episodes" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0.6363333333333333, 0.9896666666666667 ], "title": { "text": "Acceptance Ratio" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ar795", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/49.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-08-27 09:18:14", "mapbox_access_tokens": null, "has_password": null, "username": "ar795", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:45:01.095350Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~keeganhughes/24.embed", "fid": "keeganhughes:24", "filename": "plot from API (11)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/keeganhughes:24/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/keeganhughes:24/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/keeganhughes:24/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/keeganhughes:24/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/keeganhughes:24", "plots": "https://api.plotly.com/v2/plots/keeganhughes:24", "parent": "https://api.plotly.com/v2/folders/home?user=keeganhughes" }, "owner": "keeganhughes", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Scottish Referendum Voters who now want Independence", "views": 0, "web_url": "https://chart-studio.plotly.com/~keeganhughes/24/scottish-referendum-voters-who-now-want-independence/", "world_readable": true, "date_modified": "2019-03-20T21:45:01.545Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~keeganhughes/24/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "link": { "colorsrc": "keeganhughes:25:af2f10", "valuesrc": "keeganhughes:25:2f0ce9", "sourcesrc": "keeganhughes:25:bf5d35", "targetsrc": "keeganhughes:25:f669c9" }, "node": { "pad": 10, "line": { "color": "black", "width": 0 }, "colorsrc": "keeganhughes:25:4fdeb1", "labelsrc": "keeganhughes:25:33deb4", "thickness": 30 }, "type": "sankey", "domain": { "x": [ 0, 1 ], "y": [ 0, 1 ] }, "orientation": "h", "valueformat": ".0f" } ], "layout": { "font": { "size": 10 }, "sort": false, "title": "Scottish Referendum Voters who now want Independence", "height": 772 } }, "height": 772, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~keeganhughes", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/91.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-26 23:51:15", "mapbox_access_tokens": null, "has_password": null, "username": "keeganhughes", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:44:58.907991Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~sligarbros/0.embed", "fid": "sligarbros:0", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/sligarbros:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/sligarbros:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/sligarbros:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/sligarbros:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sligarbros:0", "plots": "https://api.plotly.com/v2/plots/sligarbros:0", "parent": "https://api.plotly.com/v2/folders/home?user=sligarbros" }, "owner": "sligarbros", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~sligarbros/0/", "world_readable": true, "date_modified": "2019-03-20T21:44:59.363Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~sligarbros/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b2ab8dab-be38-49c6-835a-fb92fe487f8b", "type": "ohlc", "xsrc": "sligarbros:1:7cf251", "lowsrc": "sligarbros:1:bad879", "highsrc": "sligarbros:1:88d27c", "opensrc": "sligarbros:1:ef39f2", "closesrc": "sligarbros:1:04b577" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~sligarbros", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:41:53", "mapbox_access_tokens": null, "has_password": null, "username": "sligarbros", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:44:49.994553Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jzenemig/6.embed", "fid": "jzenemig:6", "filename": "basic-bar-chart", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jzenemig:6/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jzenemig:6/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jzenemig:6/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jzenemig:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jzenemig:6", "plots": "https://api.plotly.com/v2/plots/jzenemig:6", "parent": "https://api.plotly.com/v2/folders/home?user=jzenemig" }, "owner": "jzenemig", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~jzenemig/6/", "world_readable": true, "date_modified": "2019-03-20T21:44:50.449Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jzenemig/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f0df93cf-0f44-40b0-9987-b28af64e6f45", "type": "bar", "xsrc": "jzenemig:7:2d90bc", "ysrc": "jzenemig:7:a683c8" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jzenemig", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/23.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:37:15", "mapbox_access_tokens": null, "has_password": null, "username": "jzenemig", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:44:01.963000Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~narayanan_infiswift/6.embed", "fid": "narayanan_infiswift:6", "filename": "grouped-bar-direct-labels", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/narayanan_infiswift:6/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/narayanan_infiswift:6/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/narayanan_infiswift/6/8_AVWBY3KOX2C708XE7K1AQM6JHG0MAM.png", "list-thumb": "https://api.plotly.com/v2/files/narayanan_infiswift:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/narayanan_infiswift:6", "plots": "https://api.plotly.com/v2/plots/narayanan_infiswift:6", "parent": "https://api.plotly.com/v2/folders/home?user=narayanan_infiswift" }, "owner": "narayanan_infiswift", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Correlation with Errors for Anomaly vs Normal", "views": 0, "web_url": "https://chart-studio.plotly.com/~narayanan_infiswift/6/correlation-with-errors-for-anomaly-vs-normal/", "world_readable": true, "date_modified": "2019-03-21T19:07:33.863Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~narayanan_infiswift/6/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "552d40c1-0506-4cfb-b1b5-49d12a611737", "name": "Anomaly", "type": "bar", "xsrc": "narayanan_infiswift:7:f23397", "ysrc": "narayanan_infiswift:7:ac1ff7", "opacity": 0.6 }, { "uid": "eb2d653c-8623-4fff-a335-d29f0fcd233d", "name": "Normal", "type": "bar", "xsrc": "narayanan_infiswift:7:f23397", "ysrc": "narayanan_infiswift:7:449a01", "opacity": 0.6 } ], "layout": { "font": { "size": 16, "color": "white", "family": "Arial" }, "title": { "text": "Correlation with Errors for Anomaly vs Normal" }, "xaxis": { "title": { "font": { "size": 18, "color": "white", "family": "Arial, sans-serif" }, "text": "Feature" }, "tickfont": { "size": 14, "color": "white", "family": "Arial" }, "showexponent": "all", "exponentformat": "e", "showticklabels": true }, "yaxis": { "title": { "font": { "size": 18, "color": "white", "family": "Arial, sans-serif" }, "text": "Correlation" }, "tickfont": { "size": 14, "color": "white", "family": "Old Standard TT, serif" }, "showexponent": "all", "exponentformat": "e", "showticklabels": true }, "plot_bgcolor": "black", "paper_bgcolor": "black" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~narayanan_infiswift", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/6.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-07 20:23:41", "mapbox_access_tokens": null, "has_password": null, "username": "narayanan_infiswift", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:43:42.546026Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jzenemig/4.embed", "fid": "jzenemig:4", "filename": "cf-simple-line-chart", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jzenemig:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jzenemig:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jzenemig:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jzenemig:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jzenemig:4", "plots": "https://api.plotly.com/v2/plots/jzenemig:4", "parent": "https://api.plotly.com/v2/folders/home?user=jzenemig" }, "owner": "jzenemig", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Chart From Pandas DataFrame", "views": 0, "web_url": "https://chart-studio.plotly.com/~jzenemig/4/chart-from-pandas-dataframe/", "world_readable": true, "date_modified": "2019-03-20T21:43:42.995Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jzenemig/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b103e081-f8d4-4035-b24e-c97ac42fd295", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "cyl", "text": "", "type": "scatter", "xsrc": "jzenemig:5:c4da01", "ysrc": "jzenemig:5:6aa673" }, { "uid": "b1486804-ee6a-4b20-9d83-ddd71c5a2248", "line": { "dash": "solid", "color": "rgba(55, 128, 191, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "wt", "text": "", "type": "scatter", "xsrc": "jzenemig:5:c4da01", "ysrc": "jzenemig:5:1e44a7" }, { "uid": "5a2518b5-9dec-4b76-a72f-825ecd540efb", "line": { "dash": "solid", "color": "rgba(50, 171, 96, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "mpg", "text": "", "type": "scatter", "xsrc": "jzenemig:5:c4da01", "ysrc": "jzenemig:5:bd0a44" } ], "layout": { "title": { "text": "Chart From Pandas DataFrame" }, "xaxis": { "title": { "text": "x-axis" } }, "yaxis": { "title": { "text": "y-axis" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jzenemig", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/23.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:37:15", "mapbox_access_tokens": null, "has_password": null, "username": "jzenemig", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:42:54.189804Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mccountystat/28.embed", "fid": "mccountystat:28", "filename": "Recycling Rate", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mccountystat:28/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/mccountystat/28/2_CDKVBOVXJNPOIYTL55P3AVMG0GKJDS.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/mccountystat/28/8_HDPMP3MB311UTRHSJMPV3ZJVODY1KU.png", "list-thumb": "https://api.plotly.com/v2/files/mccountystat:28/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mccountystat:28", "plots": "https://api.plotly.com/v2/plots/mccountystat:28", "parent": "https://api.plotly.com/v2/folders/mccountystat:7" }, "owner": "mccountystat", "parent": 7, "preview": "", "referencers": [], "references": [], "title": "", "views": 1177, "web_url": "https://chart-studio.plotly.com/~mccountystat/28/", "world_readable": true, "date_modified": "2019-08-06T14:12:42.286Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mccountystat/28/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "width": 3 }, "mode": "markers+lines", "name": "Recycling Rate", "type": "scatter", "xsrc": "mccountystat:18:282005", "ysrc": "mccountystat:18:624b49", "marker": { "size": 7 }, "transforms": [ { "type": "filter", "value": "Recycling Rate", "targetsrc": "mccountystat:18:5109c4" }, { "type": "filter", "value": [ "2012", "2017" ], "operation": "[]", "targetsrc": "mccountystat:18:282005" } ] } ], "frames": [], "layout": { "font": { "size": 15, "color": "rgb(0, 0, 0)", "family": "Overpass" }, "scene": { "aspectmode": "auto", "aspectratio": { "x": 1, "y": 1, "z": 1 } }, "title": { "x": 0, "font": { "size": 14 }, "text": "<br>" }, "xaxis": { "type": "linear", "range": [ 2011.7012754772268, 2017.2987245227732 ], "ticks": "", "title": { "font": { "family": "Roboto" }, "text": "<b>Year</b>" }, "nticks": 6, "ticklen": -1, "showgrid": false, "showline": false, "tickfont": { "size": 18, "color": "rgb(92, 94, 105)", "family": "Roboto" }, "zeroline": false, "autorange": true, "tickwidth": -1, "tickformat": "", "showexponent": "none", "separatethousands": false }, "yaxis": { "range": [ 0, 100 ], "ticks": "", "title": { "font": { "family": "Roboto" }, "text": "<b> Recycling Rate </b>" }, "nticks": -1, "ticklen": -1, "tickfont": { "size": 18, "color": "rgb(66, 68, 71)", "family": "Roboto" }, "autorange": false, "tickwidth": -1, "fixedrange": true, "ticksuffix": "%" }, "legend": { "x": 0.813773243320982, "y": 0.8146853146853147, "font": { "family": "Liberation Sans" }, "xanchor": "center", "borderwidth": 0 }, "margin": { "b": 20, "t": 20 }, "autosize": true, "colorway": [ "#3366cc", "#dc3912", "#ff9900", "#109618", "#990099", "#0099c6", "#dd4477", "#66aa00", "#b82e2e", "#316395" ], "dragmode": "orbit", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "clickmode": "event+select", "colorscale": { "sequentialminus": [ [ 0, "#0508b8" ], [ 0.08333333333333333, "#1910d8" ], [ 0.16666666666666666, "#3c19f0" ], [ 0.25, "#6b1cfb" ], [ 0.3333333333333333, "#981cfd" ], [ 0.4166666666666667, "#bf1cfd" ], [ 0.5, "#dd2bfd" ], [ 0.5833333333333334, "#f246fe" ], [ 0.6666666666666666, "#fc67fd" ], [ 0.75, "#fe88fc" ], [ 0.8333333333333334, "#fea5fd" ], [ 0.9166666666666666, "#febefe" ], [ 1, "#fec3fe" ] ] }, "hoverlabel": { "font": { "size": 11, "color": "#000", "family": "Roboto" }, "bgcolor": "#FFF" }, "showlegend": true, "plot_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mccountystat", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-06-15 16:16:53", "mapbox_access_tokens": null, "has_password": null, "username": "mccountystat", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:42:32.900163Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~hn303/38.embed", "fid": "hn303:38", "filename": "Multiple Mapbox", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/hn303:38/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/hn303/38/2_0AV7HU1LO73JXPW3KCCAPMMLTOEA11.png", "block-thumb": "https://api.plotly.com/v2/files/hn303:38/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/hn303:38/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/hn303:38", "plots": "https://api.plotly.com/v2/plots/hn303:38", "parent": "https://api.plotly.com/v2/folders/home?user=hn303" }, "owner": "hn303", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~hn303/38/", "world_readable": true, "date_modified": "2019-03-21T15:50:10.466Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~hn303/38/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "437bb2cd-aae7-4985-851a-4220aecda0d3", "mode": "markers", "type": "scattermapbox", "latsrc": "hn303:39:b4477b", "lonsrc": "hn303:39:cbf426", "marker": { "size": 6 }, "textsrc": "hn303:39:4b0d24" } ], "layout": { "mapbox": { "zoom": 11, "pitch": 0, "center": { "lat": 52.2, "lon": 0.12 }, "bearing": 0, "accesstoken": "pk.eyJ1IjoiaGFpZmVuZyIsImEiOiJjanRoaWhnaW4wdjQ4NGFydWM4MXNkZXJkIn0.nw5GW8KzIdmwbEUvUqCkow" }, "autosize": true, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~hn303", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/19.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-11-04 14:12:51", "mapbox_access_tokens": null, "has_password": null, "username": "hn303", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:41:41.216588Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jzenemig/2.embed", "fid": "jzenemig:2", "filename": "styled-line-chart", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jzenemig:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jzenemig:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jzenemig:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jzenemig:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jzenemig:2", "plots": "https://api.plotly.com/v2/plots/jzenemig:2", "parent": "https://api.plotly.com/v2/folders/home?user=jzenemig" }, "owner": "jzenemig", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Double Line Chart", "views": 0, "web_url": "https://chart-studio.plotly.com/~jzenemig/2/double-line-chart/", "world_readable": true, "date_modified": "2019-03-20T21:41:41.906Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jzenemig/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9faf2940-3435-4904-9fcf-36daafbc18f6", "line": { "width": 5 }, "name": "List Object", "type": "scatter", "xsrc": "jzenemig:3:2455f2", "ysrc": "jzenemig:3:09647d" }, { "uid": "644a93bd-cc08-43e6-aa2a-aa0a71df87a3", "line": { "width": 10 }, "name": "List Object 2", "type": "scatter", "xsrc": "jzenemig:3:2455f2", "ysrc": "jzenemig:3:9038e9" } ], "layout": { "title": { "text": "Double Line Chart" }, "xaxis": { "title": { "text": "x-axis" } }, "yaxis": { "title": { "text": "y-axis" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jzenemig", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/23.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:37:15", "mapbox_access_tokens": null, "has_password": null, "username": "jzenemig", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:40:58.382226Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~smileandsaydl/337.embed", "fid": "smileandsaydl:337", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/smileandsaydl:337/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/smileandsaydl:337/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/smileandsaydl/337/8_8HMJTT77B61616MSGM94EXLYS42MXM.png", "list-thumb": "https://api.plotly.com/v2/files/smileandsaydl:337/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/smileandsaydl:337", "plots": "https://api.plotly.com/v2/plots/smileandsaydl:337", "parent": "https://api.plotly.com/v2/folders/home?user=smileandsaydl" }, "owner": "smileandsaydl", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "x<sub>2</sub> vs x<sub>1</sub>", "views": 0, "web_url": "https://chart-studio.plotly.com/~smileandsaydl/337/x-2-vs-x-1/", "world_readable": true, "date_modified": "2019-03-20T21:40:59.048Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~smileandsaydl/337/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ccff4730-4b58-11e9-937d-408d5c757ebb", "type": "heatmap", "xsrc": "smileandsaydl:338:d62987", "ysrc": "smileandsaydl:338:422293", "zsrc": "smileandsaydl:338:59495a,a067e1,83e790,7e3d59,5206e3,d6fa2f,21c794,077db7,7a23c8,f8b9a8,70ab2f,3df641,023346,3d7f1f,bdbcb0,9891f8,812657,bf8fcc,1156e1,6228e8,64857b,8a1731,1eb916,207013,52965a,aeb7aa,bf7a4f,2a127b,f41479,03a926,26691c,bcf3ed,cbb5d0,2e694a,fdfe9b,a04b20,7b9a8e,13ffa0,b9659f,1650c5,0ff56b,f892bf,6508ca,a99399,8084fa,0cf368,08fb12,4d8879,e03e3e,2bed14", "colorscale": [ [ 0.0, "rgb(255, 255, 255)" ], [ 0.05263157894736842, "rgb(242, 242, 242)" ], [ 0.10526315789473684, "rgb(229, 229, 229)" ], [ 0.15789473684210525, "rgb(215, 215, 215)" ], [ 0.21052631578947367, "rgb(202, 202, 202)" ], [ 0.2631578947368421, "rgb(188, 188, 188)" ], [ 0.3157894736842105, "rgb(175, 175, 175)" ], [ 0.3684210526315789, "rgb(161, 161, 161)" ], [ 0.42105263157894735, "rgb(147, 147, 147)" ], [ 0.47368421052631576, "rgb(134, 134, 134)" ], [ 0.5263157894736842, "rgb(121, 121, 121)" ], [ 0.5789473684210527, "rgb(107, 107, 107)" ], [ 0.631578947368421, "rgb(94, 94, 94)" ], [ 0.6842105263157894, "rgb(80, 80, 80)" ], [ 0.7368421052631579, "rgb(66, 66, 66)" ], [ 0.7894736842105263, "rgb(53, 53, 53)" ], [ 0.8421052631578947, "rgb(40, 40, 40)" ], [ 0.894736842105263, "rgb(25, 25, 25)" ], [ 0.9473684210526315, "rgb(13, 13, 13)" ], [ 1.0, "rgb(0, 0, 0)" ] ] }, { "uid": "ccff4731-4b58-11e9-bc0d-408d5c757ebb", "line": { "dash": "dashdot", "width": 1 }, "type": "contour", "xsrc": "smileandsaydl:338:d62987", "ysrc": "smileandsaydl:338:2073d0", "zsrc": "smileandsaydl:338:25f2f4,691a76,a31d21,942f86,19cf67,60e767,301248,f2b304,791357,a977f4,72a3d0,516b6c,f58c34,fd6ac6,fed757,c4b457,f9d688,6a0892,039a48,76983e,65a1f7,9dcc16,892df4,b46bb7,d2c231,03901d,b2c502,1fae93,0dcc70,ffe32d,d80657,4354f4,91f093,043c1b,44d21e,c17587,22598e,c03a87,184f6d,97adaf,9b2c9c,3b8c83,420ba7,136571,6d426a,8fb9d5,647448,bbed7c,d8fbb6,a89287", "contours": { "coloring": "lines" }, "ncontours": 2, "showscale": false, "colorscale": [ [ 0, "black" ], [ 1, "white" ] ] }, { "uid": "ccff4732-4b58-11e9-b625-408d5c757ebb", "line": { "width": 1 }, "type": "contour", "xsrc": "smileandsaydl:338:d62987", "ysrc": "smileandsaydl:338:2073d0", "zsrc": "smileandsaydl:338:59495a,a067e1,83e790,7e3d59,5206e3,d6fa2f,21c794,077db7,7a23c8,f8b9a8,70ab2f,3df641,023346,3d7f1f,bdbcb0,9891f8,812657,bf8fcc,1156e1,6228e8,64857b,8a1731,1eb916,207013,52965a,aeb7aa,bf7a4f,2a127b,f41479,03a926,26691c,bcf3ed,cbb5d0,2e694a,fdfe9b,a04b20,7b9a8e,13ffa0,b9659f,1650c5,0ff56b,f892bf,6508ca,a99399,8084fa,0cf368,08fb12,4d8879,e03e3e,2bed14", "contours": { "end": 0.667, "size": 0.01, "start": 0.666, "coloring": "lines" }, "ncontours": 2, "showscale": false, "colorscale": [ [ 0, "blue" ], [ 1, "white" ] ] }, { "uid": "ccff4733-4b58-11e9-8370-408d5c757ebb", "line": { "dash": "dash", "width": 1 }, "type": "contour", "xsrc": "smileandsaydl:338:d62987", "ysrc": "smileandsaydl:338:422293", "zsrc": "smileandsaydl:338:bc72b6,ed8ce4,895dc7,4b2dde,5eee2e,2701d3,05b348,4f33d1,942c2d,d15a42,f55289,955d33,1e6d45,75e86c,bbbdfc,a830ed,4c683b,e5c0d9,3047f1,cc2796,e75a7f,2312dc,9876f0,a683bc,3c700b,352b79,7f2c40,b6cf53,0a3c4d,61055f,a0f729,36b176,8f2b95,e89499,7f946f,389ec0,a80b7c,d0dd4d,e54755,90302a,523f01,2ce0ee,8768f2,401f40,4fc286,a1e5f7,36a387,2fc6d4,68caec,147900", "contours": { "end": 0.51, "size": 0.1, "start": 0.5, "coloring": "lines" }, "showscale": false, "colorscale": [ [ 0, "black" ], [ 1, "white" ] ] }, { "uid": "ccff4734-4b58-11e9-9f92-408d5c757ebb", "line": { "width": 1 }, "type": "contour", "xsrc": "smileandsaydl:338:d62987", "ysrc": "smileandsaydl:338:422293", "zsrc": "smileandsaydl:338:bc72b6,ed8ce4,895dc7,4b2dde,5eee2e,2701d3,05b348,4f33d1,942c2d,d15a42,f55289,955d33,1e6d45,75e86c,bbbdfc,a830ed,4c683b,e5c0d9,3047f1,cc2796,e75a7f,2312dc,9876f0,a683bc,3c700b,352b79,7f2c40,b6cf53,0a3c4d,61055f,a0f729,36b176,8f2b95,e89499,7f946f,389ec0,a80b7c,d0dd4d,e54755,90302a,523f01,2ce0ee,8768f2,401f40,4fc286,a1e5f7,36a387,2fc6d4,68caec,147900", "contours": { "end": 0.335, "size": 0.1, "start": 0.334, "coloring": "lines" }, "showscale": false, "colorscale": [ [ 0, "red" ], [ 1, "white" ] ] }, { "uid": "ccff4735-4b58-11e9-b1c6-408d5c757ebb", "mode": "markers", "type": "scatter", "xsrc": "smileandsaydl:338:ae1f7e", "ysrc": "smileandsaydl:338:3d64b7", "marker": { "size": 10, "color": "red" }, "showlegend": false }, { "uid": "ccff4736-4b58-11e9-b274-408d5c757ebb", "mode": "markers", "type": "scatter", "xsrc": "smileandsaydl:338:ede4ea", "ysrc": "smileandsaydl:338:2ee3f5", "marker": { "size": 10, "color": "blue" }, "showlegend": false } ], "layout": { "xaxis": { "title": "x<sub>1</sub>" }, "yaxis": { "title": "x<sub>2</sub>", "autorange": "reversed" }, "hovermode": "closest", "annotations": [ { "x": 2, "y": 4.5, "font": { "size": 12, "color": "blue", "family": "Courier New, monospace" }, "text": "0.666", "xref": "x", "yref": "y", "showarrow": false }, { "x": 2, "y": 0.9, "font": { "size": 12, "color": "black", "family": "Courier New, monospace" }, "text": "0.5", "xref": "x", "yref": "y", "showarrow": false }, { "x": 2, "y": -2.2, "font": { "size": 12, "color": "red", "family": "Courier New, monospace" }, "text": "0.334", "xref": "x", "yref": "y", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~smileandsaydl", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/55.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-24 14:45:44", "mapbox_access_tokens": null, "has_password": null, "username": "smileandsaydl", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
