Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzIxJTNBMTMlM0ExMC4wMjUwNjglMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzIxJTNBMDIlM0E1OC41MzAzMDUlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsyMSUzQTA4JTNBMTcuNTcwMTQ5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T21:08:17.570149Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~alexlambpops/8.embed", "fid": "alexlambpops:8", "filename": "SWP Sectors and Projects", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/alexlambpops:8/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/alexlambpops/8/2_N2WWUQ7GEX8AUO6M9S51F685ZATM3L.png", "block-thumb": "https://api.plotly.com/v2/files/alexlambpops:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/alexlambpops:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/alexlambpops:8", "plots": "https://api.plotly.com/v2/plots/alexlambpops:8", "parent": "https://api.plotly.com/v2/folders/home?user=alexlambpops" }, "owner": "alexlambpops", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "SWP Projects and Sectors (3D visualization)", "views": 4, "web_url": "https://chart-studio.plotly.com/~alexlambpops/8/swp-projects-and-sectors-3d-visualization/", "world_readable": true, "date_modified": "2019-03-20T21:08:18.220Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~alexlambpops/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a377e318-a0c2-4de9-8057-f33156a51eeb", "line": { "color": "rgb(125,125,125)", "width": 1 }, "mode": "lines", "type": "scatter3d", "xsrc": "alexlambpops:9:927630", "ysrc": "alexlambpops:9:70b5e1", "zsrc": "alexlambpops:9:b6f4d8", "hoverinfo": "none" }, { "uid": "3bd1cc0e-28df-49c4-92d9-299ccab8fa58", "mode": "markers", "name": "actors", "type": "scatter3d", "xsrc": "alexlambpops:9:bbb1e6", "ysrc": "alexlambpops:9:f47175", "zsrc": "alexlambpops:9:8fec80", "marker": { "line": { "color": "rgb(50,50,50)", "width": 0.5 }, "symbol": "circle", "sizesrc": "alexlambpops:9:75f94b", "colorsrc": "alexlambpops:9:78e162", "colorscale": "Rainbow" }, "textsrc": "alexlambpops:9:ba8852", "hoverinfo": "text" } ], "layout": { "scene": { "xaxis": { "title": { "text": "" }, "showgrid": false, "showline": false, "zeroline": false, "showbackground": false, "showticklabels": false }, "yaxis": { "title": { "text": "" }, "showgrid": false, "showline": false, "zeroline": false, "showbackground": false, "showticklabels": false }, "zaxis": { "title": { "text": "" }, "showgrid": false, "showline": false, "zeroline": false, "showbackground": false, "showticklabels": false } }, "title": { "text": "SWP Projects and Sectors (3D visualization)" }, "width": 1000, "height": 1000, "margin": { "t": 100 }, "hovermode": "closest", "showlegend": false, "annotations": [ { "x": 0, "y": 0.1, "font": { "size": 14 }, "text": "Data source: CCC Nova Sector/Project relationships for SWP", "xref": "paper", "yref": "paper", "xanchor": "left", "yanchor": "bottom", "showarrow": false } ] } }, "height": 1000, "width": 1000, "user": { "profile_url": "https://chart-studio.plotly.com/~alexlambpops", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/48.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-09-26 19:00:16", "mapbox_access_tokens": null, "has_password": null, "username": "alexlambpops", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:08:03.888995Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~davecampbell/1.embed", "fid": "davecampbell:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/davecampbell:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/davecampbell:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/davecampbell/1/8_N0Y3FJ6PJBL167Y5UZY7C0LV4HCAG9.png", "list-thumb": "https://api.plotly.com/v2/files/davecampbell:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/davecampbell:1", "plots": "https://api.plotly.com/v2/plots/davecampbell:1", "parent": "https://api.plotly.com/v2/folders/home?user=davecampbell" }, "owner": "davecampbell", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~davecampbell/1/", "world_readable": true, "date_modified": "2019-03-21T14:28:34.677Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~davecampbell/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "all timeout data", "type": "bar", "xsrc": "davecampbell:0:ed0712", "ysrc": "davecampbell:0:d933d8", "opacity": 1, "showlegend": true, "orientation": "v" }, { "name": "alerts", "type": "bar", "xsrc": "davecampbell:4:6587f4", "ysrc": "davecampbell:4:d96a66", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "SENDEN TIMEOUTS PER 5-MINUTES" }, "xaxis": { "type": "date", "dtick": 86400000, "range": [ "2019-02-27 20:15:34.761", "2019-03-06 20:15:34.761" ], "tick0": "2019-01-05 ", "title": { "text": "DATE / TIME" }, "showgrid": true, "tickmode": "linear", "zeroline": false, "autorange": false, "gridwidth": 1, "rangeslider": { "range": [ "2019-02-27 20:15:34.761", "2019-03-19 11:58:41.5" ], "yaxis": { "rangemode": "match" }, "visible": true, "autorange": true }, "rangeselector": { "buttons": [ { "step": "day", "stepmode": "backward" }, {}, { "step": "day", "count": 7 } ], "visible": true } }, "yaxis": { "type": "linear", "range": [ 0, 40 ], "title": { "text": "TIMEOUTS" }, "autorange": false }, "bargap": 0, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~davecampbell", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/92.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:05:17", "mapbox_access_tokens": null, "has_password": null, "username": "davecampbell", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:07:59.092369Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mccountystat/26.embed", "fid": "mccountystat:26", "filename": "Number of Pedestrian-involved Crashes", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mccountystat:26/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/mccountystat/26/2_U1FTLHJJMLNJMD1MH1YQLOB88LXNMU.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/mccountystat/26/8_MFJMLHK5735HO7M1Z5AG7LBN9PMOUU.png", "list-thumb": "https://api.plotly.com/v2/files/mccountystat:26/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mccountystat:26", "plots": "https://api.plotly.com/v2/plots/mccountystat:26", "parent": "https://api.plotly.com/v2/folders/mccountystat:7" }, "owner": "mccountystat", "parent": 7, "preview": "", "referencers": [], "references": [], "title": "", "views": 760, "web_url": "https://chart-studio.plotly.com/~mccountystat/26/", "world_readable": true, "date_modified": "2019-08-06T14:12:42.286Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mccountystat/26/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "fill": "none", "line": { "dash": "solid", "shape": "linear", "width": 3 }, "mode": "markers+lines", "name": "Pedestrian-involved Collisions ", "type": "scatter", "xsrc": "mccountystat:18:282005", "ysrc": "mccountystat:18:a8f964", "marker": { "size": 8, "symbol": "circle", "opacity": 1, "maxdisplayed": 0 }, "textsrc": "mccountystat:18:a8f964", "hoverinfo": "x+y", "transforms": [ { "type": "filter", "value": "Pedestrian-Involved Traffic Collisions", "operation": "=", "targetsrc": "mccountystat:18:5109c4" }, { "type": "filter", "value": [ "2012", "2017" ], "operation": "[]", "targetsrc": "mccountystat:18:282005" } ], "connectgaps": true, "hovertemplate": "" } ], "frames": [], "layout": { "font": { "size": 18, "color": "rgb(0, 0, 0)", "family": "Roboto" }, "scene": { "aspectmode": "auto", "aspectratio": { "x": 1, "y": 1, "z": 1 } }, "title": { "x": 0, "font": { "size": 13 }, "text": "<br>" }, "xaxis": { "type": "linear", "range": [ 2011.70583898555, 2017.29416101445 ], "ticks": "", "title": { "font": { "size": 18, "color": "rgb(0, 0, 0)" }, "text": "<b>Year</b>" }, "nticks": 6, "ticklen": -1, "showgrid": false, "showline": false, "tickfont": { "color": "rgb(92, 94, 105)", "family": "Roboto" }, "zeroline": false, "autorange": true, "tickwidth": -1, "tickformat": "", "showexponent": "none", "separatethousands": false }, "yaxis": { "type": "linear", "range": [ 0, 700 ], "ticks": "", "title": { "font": { "size": 18 }, "text": "<b>Pedestrian-Involved Collisions </b>" }, "nticks": -1, "ticklen": -1, "tickfont": { "color": "rgb(66, 68, 71)" }, "autorange": false, "tickwidth": -1, "fixedrange": true, "ticksuffix": "" }, "legend": { "x": 0.6688068475842005, "y": 0.41268382352941174, "font": { "size": 16, "family": "Roboto" }, "xanchor": "center", "borderwidth": 0 }, "margin": { "b": 0, "r": 0, "t": 0 }, "autosize": true, "colorway": [ "#3366cc", "#dc3912", "#ff9900", "#109618", "#990099", "#0099c6", "#dd4477", "#66aa00", "#b82e2e", "#316395" ], "dragmode": "orbit", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "clickmode": "event+select", "colorscale": { "sequentialminus": [ [ 0, "#0508b8" ], [ 0.08333333333333333, "#1910d8" ], [ 0.16666666666666666, "#3c19f0" ], [ 0.25, "#6b1cfb" ], [ 0.3333333333333333, "#981cfd" ], [ 0.4166666666666667, "#bf1cfd" ], [ 0.5, "#dd2bfd" ], [ 0.5833333333333334, "#f246fe" ], [ 0.6666666666666666, "#fc67fd" ], [ 0.75, "#fe88fc" ], [ 0.8333333333333334, "#fea5fd" ], [ 0.9166666666666666, "#febefe" ], [ 1, "#fec3fe" ] ] }, "hoverlabel": { "font": { "size": 11, "color": "#000", "family": "Roboto" }, "bgcolor": "#FFF" }, "showlegend": true, "plot_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mccountystat", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-06-15 16:16:53", "mapbox_access_tokens": null, "has_password": null, "username": "mccountystat", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:07:34.518859Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pierricm/24.embed", "fid": "pierricm:24", "filename": "plot from API (7)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pierricm:24/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pierricm:24/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pierricm:24/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pierricm:24/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pierricm:24", "plots": "https://api.plotly.com/v2/plots/pierricm:24", "parent": "https://api.plotly.com/v2/folders/home?user=pierricm" }, "owner": "pierricm", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Representation of carry values in the reduced space", "views": 0, "web_url": "https://chart-studio.plotly.com/~pierricm/24/representation-of-carry-values-in-the-reduced-space/", "world_readable": true, "date_modified": "2019-03-20T21:07:34.928Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pierricm/24/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b79f46bf-8b01-4d23-bb58-64f3e4800657", "mode": "markers", "name": "New space", "type": "scatter", "xsrc": "pierricm:25:098896", "ysrc": "pierricm:25:0bfd79", "marker": { "line": { "color": "rgba(100, 0, 150, 0.9)", "width": 0.5 }, "size": 12, "color": "rgba(100, 0, 150, 0.9)", "opacity": 0.8 } } ], "layout": { "title": { "text": "Representation of carry values in the reduced space" }, "xaxis": { "title": { "text": "PC1" }, "showline": false }, "yaxis": { "title": { "text": "PC2" }, "showline": false } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pierricm", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-10 12:43:05", "mapbox_access_tokens": null, "has_password": null, "username": "pierricm", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:07:13.966084Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~delpio88/3.embed", "fid": "delpio88:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/delpio88:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/delpio88:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/delpio88/3/8_6QWEG4GRWRI3QAMPBM4HWKL783BY37.png", "list-thumb": "https://api.plotly.com/v2/files/delpio88:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/delpio88:3", "plots": "https://api.plotly.com/v2/plots/delpio88:3", "parent": "https://api.plotly.com/v2/folders/home?user=delpio88" }, "owner": "delpio88", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~delpio88/3/", "world_readable": true, "date_modified": "2019-03-20T21:20:49.783Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~delpio88/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "22e0b1", "mode": "markers", "name": "KM", "type": "scatter", "xsrc": "delpio88:2:57197d", "ysrc": "delpio88:2:685a1a", "marker": { "color": "rgb(58, 71, 236)", "symbol": "circle" }, "opacity": 1, "fillcolor": "rgba(255, 255, 255, 0.5)", "groupnorm": "", "stackgaps": "infer zero", "stackgroup": 1, "orientation": "v", "hovertemplate": "" }, { "uid": "59f274", "mode": "markers", "name": "Scr", "type": "scatter", "xsrc": "delpio88:2:ac7143", "ysrc": "delpio88:2:c73cea", "marker": { "color": "rgb(255, 38, 0)", "symbol": "square-open" }, "stackgroup": null }, { "uid": "b7a304", "mode": "markers", "name": "Fla", "type": "scatter", "xsrc": "delpio88:2:872aa0", "ysrc": "delpio88:2:e05a2a", "marker": { "symbol": "circle-open" }, "stackgroup": null }, { "uid": "0c45a6", "mode": "markers", "name": "Bif", "type": "scatter", "xsrc": "delpio88:2:db7b56", "ysrc": "delpio88:2:1f6746", "marker": { "color": "rgb(235, 253, 47)", "symbol": "x" }, "stackgroup": null }, { "uid": "d3fa15", "transforms": [ { "rms": 4.559413354176036, "type": "fit", "xmid": 56.99999999999993, "ymid": 34.042230401322186, "inputUid": "22e0b1", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.04913031274214903, "value": 0.35300334683811874 }, { "hold": false, "name": "b", "error": 2.649338163579468, "value": 13.011449709353531 } ], "regressand": "y", "correlation": 0.7351162020691537, "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] }, { "uid": "eacf91", "transforms": [ { "rms": 10.303713685600323, "type": "fit", "xmid": 85.00000000000007, "ymid": 56.65377756353141, "inputUid": "59f274", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.058065171460069016, "value": 0.4683501142793116 }, { "hold": false, "name": "b", "error": 3.47203507625181, "value": 12.606786981318608 } ], "regressand": "y", "correlation": 0.6445373691188303, "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] }, { "uid": "25e631", "transforms": [ { "rms": 10.221725429047357, "type": "fit", "xmid": 64.49999999999997, "ymid": 46.08704451098566, "inputUid": "b7a304", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.06102950782982554, "value": 0.5208982046278545 }, { "hold": false, "name": "b", "error": 3.000105151052115, "value": 9.714660772590525 } ], "regressand": "y", "correlation": 0.6190589066055339, "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] }, { "uid": "e958c9", "transforms": [ { "rms": 7.028570393295684, "type": "fit", "xmid": 61.50000000000008, "ymid": 42.90162579132655, "inputUid": "0c45a6", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.1250147531227526, "value": 0.546469190290236 }, { "hold": false, "name": "b", "error": 7.481986603291649, "value": 9.929977932441755 } ], "regressand": "y", "correlation": 0.7520393787926724, "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 8.285896821593994, 147.71410317840602 ], "title": { "text": "Length" }, "showline": false, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 102.20458553791887 ], "title": { "text": "Width" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "plot_bgcolor": "rgb(255, 255, 255)", "paper_bgcolor": "rgb(255, 255, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~delpio88", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/53.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-30 18:56:06", "mapbox_access_tokens": null, "has_password": null, "username": "delpio88", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:07:13.033794Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~drijhwan/0.embed", "fid": "drijhwan:0", "filename": "line-mode", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/drijhwan:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/drijhwan:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/drijhwan/0/8_TQJJC1QUMQYDO53F6ZVS96WL03Y5JB.png", "list-thumb": "https://api.plotly.com/v2/files/drijhwan:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/drijhwan:0", "plots": "https://api.plotly.com/v2/plots/drijhwan:0", "parent": "https://api.plotly.com/v2/folders/home?user=drijhwan" }, "owner": "drijhwan", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "lines, lines+markers, markers", "views": 0, "web_url": "https://chart-studio.plotly.com/~drijhwan/0/lines-linesmarkers-markers/", "world_readable": true, "date_modified": "2019-03-20T21:07:13.481Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~drijhwan/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "06ab9d81-7f16-4fef-9351-719d7b6944d9", "mode": "lines", "name": "lines", "type": "scatter", "xsrc": "drijhwan:1:eb10e3", "ysrc": "drijhwan:1:9d0dc9" }, { "uid": "da18c3d5-88f7-4cc6-bf95-9bebdce37856", "mode": "lines+markers", "name": "lines+markers", "type": "scatter", "xsrc": "drijhwan:1:eb10e3", "ysrc": "drijhwan:1:c1f601" }, { "uid": "bee22d96-5a31-4056-bd74-41b6ddbedf35", "mode": "markers", "name": "markers", "type": "scatter", "xsrc": "drijhwan:1:eb10e3", "ysrc": "drijhwan:1:d5793b" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~drijhwan", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:05:12", "mapbox_access_tokens": null, "has_password": null, "username": "drijhwan", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:07:05.403487Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~martijnvanvlie/34.embed", "fid": "martijnvanvlie:34", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/martijnvanvlie:34/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/martijnvanvlie:34/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/martijnvanvlie:34/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/martijnvanvlie:34/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/martijnvanvlie:34", "plots": "https://api.plotly.com/v2/plots/martijnvanvlie:34", "parent": "https://api.plotly.com/v2/folders/home?user=martijnvanvlie" }, "owner": "martijnvanvlie", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Top 10 road segments based on Criticalility and Vulnerability", "views": 2, "web_url": "https://chart-studio.plotly.com/~martijnvanvlie/34/top-10-road-segments-based-on-criticalility-and-vulnerability/", "world_readable": true, "date_modified": "2019-03-20T21:07:05.892Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~martijnvanvlie/34/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ffbf010b-8023-4d24-8500-8f0cda0f0afa", "mode": "markers", "name": "R roads", "type": "scatter", "xsrc": "martijnvanvlie:35:64620d", "ysrc": "martijnvanvlie:35:4af9ab", "marker": { "size": 12, "color": "rgb(255,127,14)" } }, { "uid": "d2da5955-d8ad-47de-b9fa-be1c0ca6be95", "mode": "markers", "name": "N roads", "type": "scatter", "xsrc": "martijnvanvlie:35:5e3c46", "ysrc": "martijnvanvlie:35:cdf7ef", "marker": { "size": 12, "color": "rgb(31,119,180)" } } ], "layout": { "title": { "text": "Top 10 road segments based on Criticalility and Vulnerability" }, "xaxis": { "title": { "text": "Criticality (normalised)" } }, "yaxis": { "title": { "text": "Vulnerability (normalised)" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~martijnvanvlie", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/50.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-23 11:49:05", "mapbox_access_tokens": null, "has_password": null, "username": "martijnvanvlie", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:06:40.755904Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pierricm/22.embed", "fid": "pierricm:22", "filename": "plot from API (6)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pierricm:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pierricm:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pierricm:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pierricm:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pierricm:22", "plots": "https://api.plotly.com/v2/plots/pierricm:22", "parent": "https://api.plotly.com/v2/folders/home?user=pierricm" }, "owner": "pierricm", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Representation of carry values in the reduced space", "views": 0, "web_url": "https://chart-studio.plotly.com/~pierricm/22/representation-of-carry-values-in-the-reduced-space/", "world_readable": true, "date_modified": "2019-03-20T21:06:41.286Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pierricm/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "dbdd9a3d-939b-4e42-a157-c5c85f671748", "mode": "markers", "name": "New space", "type": "scatter", "xsrc": "pierricm:23:851678", "ysrc": "pierricm:23:a70d9e", "marker": { "line": { "color": "rgba(100, 0, 150, 0.9)", "width": 0.5 }, "size": 12, "color": "rgba(100, 0, 150, 0.9)", "opacity": 0.8 } } ], "layout": { "title": { "text": "Representation of carry values in the reduced space" }, "xaxis": { "title": { "text": "PC1" }, "showline": false }, "yaxis": { "title": { "text": "PC2" }, "showline": false } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pierricm", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-10 12:43:05", "mapbox_access_tokens": null, "has_password": null, "username": "pierricm", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:06:20.075597Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~martijnvanvlie/32.embed", "fid": "martijnvanvlie:32", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/martijnvanvlie:32/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/martijnvanvlie:32/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/martijnvanvlie:32/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/martijnvanvlie:32/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/martijnvanvlie:32", "plots": "https://api.plotly.com/v2/plots/martijnvanvlie:32", "parent": "https://api.plotly.com/v2/folders/home?user=martijnvanvlie" }, "owner": "martijnvanvlie", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Top 10 road segments based on Criticalility and Vulnerability", "views": 2, "web_url": "https://chart-studio.plotly.com/~martijnvanvlie/32/top-10-road-segments-based-on-criticalility-and-vulnerability/", "world_readable": true, "date_modified": "2019-03-20T21:06:20.741Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~martijnvanvlie/32/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ffe6541d-3588-46ce-8ead-5d5a954c8eb4", "mode": "markers", "name": "R roads", "type": "scatter", "xsrc": "martijnvanvlie:33:5d8ca6", "ysrc": "martijnvanvlie:33:e96d54", "marker": { "size": 12, "color": "rgb(255,127,14)" }, "textsrc": "martijnvanvlie:33:18c7fc" }, { "uid": "13c1a503-d664-4a07-9f89-0e6638bd497f", "mode": "markers", "name": "N roads", "type": "scatter", "xsrc": "martijnvanvlie:33:2da451", "ysrc": "martijnvanvlie:33:b9c5cd", "marker": { "size": 12, "color": "rgb(31,119,180)" }, "textsrc": "martijnvanvlie:33:e0b947" } ], "layout": { "title": { "text": "Top 10 road segments based on Criticalility and Vulnerability" }, "xaxis": { "title": { "text": "Criticality (normalised)" } }, "yaxis": { "title": { "text": "Vulnerability (normalised)" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~martijnvanvlie", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/50.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-23 11:49:05", "mapbox_access_tokens": null, "has_password": null, "username": "martijnvanvlie", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T21:02:58.530305Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aliutouray1997/1.embed", "fid": "aliutouray1997:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aliutouray1997:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aliutouray1997:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/aliutouray1997:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/aliutouray1997:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aliutouray1997:1", "plots": "https://api.plotly.com/v2/plots/aliutouray1997:1", "parent": "https://api.plotly.com/v2/folders/home?user=aliutouray1997" }, "owner": "aliutouray1997", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~aliutouray1997/1/", "world_readable": true, "date_modified": "2019-03-20T21:02:58.558Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aliutouray1997/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "bar", "xsrc": "aliutouray1997:0:24d754", "ysrc": "aliutouray1997:0:3a24c7", "orientation": "v" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 81.48091572870811, 97.5 ], "autorange": false }, "yaxis": { "type": "linear", "range": [ 0, 7.368421052631579 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aliutouray1997", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/8.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 21:02:42", "mapbox_access_tokens": null, "has_password": null, "username": "aliutouray1997", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
