Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBNDMlM0E1MS45NzI5MjUlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBMzUlM0ExNy40NjQwOTclMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsxOCUzQTQyJTNBNDQuOTgyMzY2JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T18:42:44.982366Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~soadx909/19.embed", "fid": "soadx909:19", "filename": "Monthly AD OR", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/soadx909/19/9_T0JRJP2FB9YQZ87JZ710JETFOGSL14.png", "image_urls": { "default": "https://api.plotly.com/v2/files/soadx909:19/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/soadx909/19/8_ZQFLWKNG722ZKT1AJ4JG8ZYHXC02A6.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/soadx909/19/9_T0JRJP2FB9YQZ87JZ710JETFOGSL14.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/soadx909:19", "plots": "https://api.plotly.com/v2/plots/soadx909:19", "parent": "https://api.plotly.com/v2/folders/home?user=soadx909" }, "owner": "soadx909", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~soadx909/19/", "world_readable": true, "date_modified": "2019-05-14T22:52:15.825Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~soadx909/19/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a3aad0", "mode": "markers", "name": "<b>AD Success</b>", "type": "bar", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:18:34881b", "marker": { "color": "rgb(36, 49, 207)" }, "orientation": "v" }, { "uid": "3349e2", "name": "<b>Full Install DD-1</b>", "type": "bar", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:18:14c0b9", "yaxis": "y", "marker": { "color": "rgb(89, 189, 207)" }, "orientation": "v" }, { "uid": "d377d6", "name": "<b>NOAC-Premises</b>", "type": "bar", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:18:809759", "marker": { "color": "rgb(204, 0, 40)" }, "orientation": "v" }, { "uid": "a977b5", "name": "<b>NOAC-Other Reasons</b>", "type": "bar", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:18:899731", "marker": { "color": "rgb(173, 170, 179)" }, "orientation": "v" }, { "uid": "fc44da", "name": "<b>Total</b>", "type": "bar", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:18:4c7273", "marker": { "line": { "color": "rgb(38, 235, 45)" }, "color": "rgb(67, 133, 21)" }, "orientation": "v" }, { "uid": "f1ec52", "fill": "tonextx", "line": { "dash": "dot" }, "mode": "markers+lines", "name": "<b>AD Success TPJ (mins)</b>", "type": "scatter", "xsrc": "soadx909:18:b06af6", "ysrc": "soadx909:17:ca7ce0", "yaxis": "y2", "marker": { "color": "rgb(27, 26, 27)", "symbol": "cross-open" }, "fillcolor": "rgba(228, 217, 228, 0.5)", "orientation": "v" } ], "frames": [], "layout": { "title": { "font": { "size": 22 }, "text": "<b>Number of AD Ontario- 13th Feb-13th Mar " }, "xaxis": { "type": "category", "range": [ -0.5, 8.5 ], "title": { "font": { "size": 18 }, "text": "<b>NPA</b>" }, "showgrid": false, "tickfont": { "size": 19 }, "zeroline": false, "autorange": true, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 0, 246.31578947368422 ], "title": { "font": { "size": 18 }, "text": "<b>Number of AD Initiated</b>" }, "showgrid": false, "tickfont": { "size": 18 }, "autorange": true }, "legend": { "x": 1.0457926376851319, "y": 1.1213991769547325 }, "yaxis2": { "side": "right", "type": "linear", "range": [ 46.50832466181061, 110.49167533818938 ], "title": { "font": { "size": 18, "color": "rgb(84, 94, 184)" }, "text": "<b>AD Success TPJ (mins)</b>" }, "showgrid": false, "tickfont": { "size": 11 }, "autorange": true, "overlaying": "y" }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~soadx909", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-01-31 20:09:25", "mapbox_access_tokens": null, "has_password": null, "username": "soadx909", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:42:39.795953Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~johngatop/0.embed", "fid": "johngatop:0", "filename": "basic-line", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/johngatop:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/johngatop:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/johngatop:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/johngatop:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/johngatop:0", "plots": "https://api.plotly.com/v2/plots/johngatop:0", "parent": "https://api.plotly.com/v2/folders/home?user=johngatop" }, "owner": "johngatop", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 9, "web_url": "https://chart-studio.plotly.com/~johngatop/0/", "world_readable": true, "date_modified": "2019-04-04T23:28:48.111Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~johngatop/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "0a3c5e7e-a779-48eb-8ba2-c7915fa1788d", "type": "scatter", "xsrc": "johngatop:1:ccf99e", "ysrc": "johngatop:1:18d71c" }, { "uid": "556becc8-4dd6-442d-b1f6-fe628acbfc11", "type": "scatter", "xsrc": "johngatop:1:ccf99e", "ysrc": "johngatop:1:534d77" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~johngatop", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/90.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 18:40:32", "mapbox_access_tokens": null, "has_password": null, "username": "johngatop", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:42:28.993259Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Crim318/4.embed", "fid": "Crim318:4", "filename": "basic-bar", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Crim318:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Crim318:4/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Crim318/4/8_OLBCKQTOX5WKJHUGOJUGEXW5IEFKN6.png", "list-thumb": "https://api.plotly.com/v2/files/Crim318:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Crim318:4", "plots": "https://api.plotly.com/v2/plots/Crim318:4", "parent": "https://api.plotly.com/v2/folders/home?user=Crim318" }, "owner": "Crim318", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Crim318/4/", "world_readable": true, "date_modified": "2019-03-20T18:50:42.978Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Crim318/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "2ba38ff0-8a4d-441b-99c4-99df9633e541", "type": "bar", "xsrc": "Crim318:5:fcfca2", "ysrc": "Crim318:5:5f5112" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Crim318", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/20.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-17 20:17:20", "mapbox_access_tokens": null, "has_password": null, "username": "Crim318", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:41:00.530656Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ametaxas/59.embed", "fid": "ametaxas:59", "filename": "Top Category Seen Impression Clicks", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ametaxas:59/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ametaxas:59/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ametaxas/59/8_NJZ86LYGXLSHG6LI8UZ7X4U0R509R7.png", "list-thumb": "https://api.plotly.com/v2/files/ametaxas:59/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ametaxas:59", "plots": "https://api.plotly.com/v2/plots/ametaxas:59", "parent": "https://api.plotly.com/v2/folders/home?user=ametaxas" }, "owner": "ametaxas", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Top Category Seen Impressions Clicked", "views": 4, "web_url": "https://chart-studio.plotly.com/~ametaxas/59/top-category-seen-impressions-clicked/", "world_readable": true, "date_modified": "2019-03-20T18:49:05.822Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ametaxas/59/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "d4eed16c-4b40-11e9-99ae-98e0d9a53081", "line": { "color": "#C446A2" }, "name": "Fashion & Style", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:5acfd9", "opacity": 0.8 }, { "uid": "d4eed3ba-4b40-11e9-8a78-98e0d9a53081", "line": { "color": "#4FB6D8" }, "name": "Celebrity News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:980dd7", "opacity": 0.8 }, { "uid": "d4eed50c-4b40-11e9-b7e7-98e0d9a53081", "line": { "color": "#06C5F5" }, "name": "Apartments & Residential Rentals", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:b563db", "opacity": 0.8 }, { "uid": "d4eed61c-4b40-11e9-bf32-98e0d9a53081", "line": { "color": "#165DBB" }, "name": "Childhood Education", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:ae82bd", "opacity": 0.8 }, { "uid": "d4eed71e-4b40-11e9-aa84-98e0d9a53081", "line": { "color": "#B33C29" }, "name": "Social Networks", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:0ff81b", "opacity": 0.8 }, { "uid": "d4eed81a-4b40-11e9-b984-98e0d9a53081", "line": { "color": "#ECBA0C" }, "name": "Mobile & Wireless", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1d1dcb", "opacity": 0.8 }, { "uid": "d4eed914-4b40-11e9-8da6-98e0d9a53081", "line": { "color": "#C1BF52" }, "name": "Travel", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:8047f4", "opacity": 0.8 }, { "uid": "d4eeda0c-4b40-11e9-abc9-98e0d9a53081", "line": { "color": "#E57D6D" }, "name": "Directories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:980dd7", "opacity": 0.8 }, { "uid": "d4eedb08-4b40-11e9-8536-98e0d9a53081", "line": { "color": "#62A59C" }, "name": "Culture", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:59d7bf", "opacity": 0.8 }, { "uid": "d4eedc02-4b40-11e9-84ab-98e0d9a53081", "line": { "color": "#E9B5F3" }, "name": "Language Resources", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:59d7bf", "opacity": 0.8 }, { "uid": "d4eedcf4-4b40-11e9-9fd4-98e0d9a53081", "line": { "color": "#C1B919" }, "name": "Web Apps & Online Tools", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:cb77df", "opacity": 0.8 }, { "uid": "d4eeddec-4b40-11e9-a269-98e0d9a53081", "line": { "color": "#5A9EE3" }, "name": "Real Estate Listings", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:b22259", "opacity": 0.8 }, { "uid": "d4eedee6-4b40-11e9-890b-98e0d9a53081", "line": { "color": "#3916D6" }, "name": "Pets", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a1b5b0", "opacity": 0.8 }, { "uid": "d4eedfd8-4b40-11e9-a3e1-98e0d9a53081", "line": { "color": "#B3ED2B" }, "name": "Computer & Video Games", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:cb77df", "opacity": 0.8 }, { "uid": "d4eee0d0-4b40-11e9-b3c6-98e0d9a53081", "line": { "color": "#465675" }, "name": "Cheats & Walkthroughs", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:0e8139", "opacity": 0.8 }, { "uid": "d4eee1c0-4b40-11e9-b1cf-98e0d9a53081", "line": { "color": "#900779" }, "name": "Cooking & Recipes", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:29bdaa", "opacity": 0.8 }, { "uid": "d4eee2b0-4b40-11e9-98ed-98e0d9a53081", "line": { "color": "#62C6F4" }, "name": "World News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:3b8794", "opacity": 0.8 }, { "uid": "d4eee3a8-4b40-11e9-b89d-98e0d9a53081", "line": { "color": "#783746" }, "name": "(undefined)", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:c057d4", "opacity": 0.8 }, { "uid": "d4eee49a-4b40-11e9-a7f5-98e0d9a53081", "line": { "color": "#C4AAA2" }, "name": "Food & Drink", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:f2dd6a", "opacity": 0.8 }, { "uid": "d4eee594-4b40-11e9-be13-98e0d9a53081", "line": { "color": "#D750F5" }, "name": "Luggage & Travel Accessories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:930a06", "opacity": 0.8 }, { "uid": "d4eee686-4b40-11e9-887d-98e0d9a53081", "line": { "color": "#3839AC" }, "name": "(undefined)", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:c0eb27", "opacity": 0.8 }, { "uid": "d4eee774-4b40-11e9-bc33-98e0d9a53081", "line": { "color": "#4825C7" }, "name": "Apartments & Residential Rentals", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:c7dd45", "opacity": 0.8 }, { "uid": "d4eee8be-4b40-11e9-9079-98e0d9a53081", "line": { "color": "#F2E2FE" }, "name": "Childhood Education", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:bcdbf5", "opacity": 0.8 }, { "uid": "d4eee974-4b40-11e9-a23f-98e0d9a53081", "line": { "color": "#01CF5F" }, "name": "Cheats & Walkthroughs", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:bb8e2a", "opacity": 0.8 }, { "uid": "d4eeea30-4b40-11e9-a379-98e0d9a53081", "line": { "color": "#4A6C38" }, "name": "TV & Video", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a5c29c", "opacity": 0.8 }, { "uid": "d4eeeae4-4b40-11e9-98b8-98e0d9a53081", "line": { "color": "#5ED744" }, "name": "Cooking & Recipes", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:ba7e2c", "opacity": 0.8 }, { "uid": "d4eeeba2-4b40-11e9-a92e-98e0d9a53081", "line": { "color": "#0DD2B9" }, "name": "Real Estate Listings", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a73cbc", "opacity": 0.8 }, { "uid": "d4eeec58-4b40-11e9-88da-98e0d9a53081", "line": { "color": "#2477FC" }, "name": "Social Networks", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:cd240d", "opacity": 0.8 }, { "uid": "d4eeed0a-4b40-11e9-aa44-98e0d9a53081", "line": { "color": "#8EE017" }, "name": "Travel", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:ca57ba", "opacity": 0.8 }, { "uid": "d4eeedbe-4b40-11e9-a125-98e0d9a53081", "line": { "color": "#4CE760" }, "name": "Computers & Electronics", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:46c8df", "opacity": 0.8 }, { "uid": "d4eeee7a-4b40-11e9-9308-98e0d9a53081", "line": { "color": "#22EB2D" }, "name": "Directories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:3bbc7f", "opacity": 0.8 }, { "uid": "d4eeef30-4b40-11e9-9b17-98e0d9a53081", "line": { "color": "#95A21D" }, "name": "Undisclosed", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:58f9ad", "opacity": 0.8 }, { "uid": "d4eeefe4-4b40-11e9-805c-98e0d9a53081", "line": { "color": "#8AC5C4" }, "name": "Fashion & Style", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:282ec5", "opacity": 0.8 }, { "uid": "d4eef098-4b40-11e9-8fc8-98e0d9a53081", "line": { "color": "#42E7D7" }, "name": "Culture", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:7dd219", "opacity": 0.8 }, { "uid": "d4eef158-4b40-11e9-bd5a-98e0d9a53081", "line": { "color": "#18FF12" }, "name": "Celebrity News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:7e7bd9", "opacity": 0.8 }, { "uid": "d4eef20a-4b40-11e9-a956-98e0d9a53081", "line": { "color": "#B7256B" }, "name": "Mobile & Wireless", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:98cf30", "opacity": 0.8 }, { "uid": "d4eef2c8-4b40-11e9-9609-98e0d9a53081", "line": { "color": "#45B7B1" }, "name": "Computer & Video Games", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:2878af", "opacity": 0.8 }, { "uid": "d4eef37a-4b40-11e9-a501-98e0d9a53081", "line": { "color": "#471445" }, "name": "Pets", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a7f6a2", "opacity": 0.8 }, { "uid": "d4eef430-4b40-11e9-b24d-98e0d9a53081", "line": { "color": "#EA5D03" }, "name": "World News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:ffb5f4", "opacity": 0.8 }, { "uid": "d4eef4f8-4b40-11e9-a96c-98e0d9a53081", "line": { "color": "#F23BF1" }, "name": "Language Resources", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:12708f", "opacity": 0.8 }, { "uid": "d4eef5b6-4b40-11e9-9ed7-98e0d9a53081", "line": { "color": "#DF18EC" }, "name": "(undefined)", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:dbb39c", "opacity": 0.8 }, { "uid": "d4eef67e-4b40-11e9-8207-98e0d9a53081", "line": { "color": "#F72B88" }, "name": "Apartments & Residential Rentals", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:c7dd45", "opacity": 0.8 }, { "uid": "d4eef750-4b40-11e9-81bd-98e0d9a53081", "line": { "color": "#414062" }, "name": "Childhood Education", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:bcdbf5", "opacity": 0.8 }, { "uid": "d4eef818-4b40-11e9-88ea-98e0d9a53081", "line": { "color": "#F42DE4" }, "name": "Cheats & Walkthroughs", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:bb8e2a", "opacity": 0.8 }, { "uid": "d4eef8e2-4b40-11e9-9c3a-98e0d9a53081", "line": { "color": "#A09208" }, "name": "TV & Video", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:4272cf", "opacity": 0.8 }, { "uid": "d4eef99e-4b40-11e9-b952-98e0d9a53081", "line": { "color": "#2827A1" }, "name": "Cooking & Recipes", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:b93e4d", "opacity": 0.8 }, { "uid": "d4eefa5c-4b40-11e9-9c99-98e0d9a53081", "line": { "color": "#B9450E" }, "name": "Real Estate Listings", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a9b07b", "opacity": 0.8 }, { "uid": "d4eefb24-4b40-11e9-b38c-98e0d9a53081", "line": { "color": "#5C5601" }, "name": "Social Networks", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:bd2c41", "opacity": 0.8 }, { "uid": "d4eefbf6-4b40-11e9-9c4e-98e0d9a53081", "line": { "color": "#BCC9EA" }, "name": "Travel", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:3f2a1a", "opacity": 0.8 }, { "uid": "d4eefce6-4b40-11e9-bbe7-98e0d9a53081", "line": { "color": "#4BCAD1" }, "name": "Computers & Electronics", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1ea8e2", "opacity": 0.8 }, { "uid": "d4eefdc2-4b40-11e9-8c7b-98e0d9a53081", "line": { "color": "#5EB2EF" }, "name": "Directories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:26b1f2", "opacity": 0.8 }, { "uid": "d4eefe8a-4b40-11e9-a505-98e0d9a53081", "line": { "color": "#35E9B2" }, "name": "Undisclosed", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:eb8e04", "opacity": 0.8 }, { "uid": "d4eeff52-4b40-11e9-8479-98e0d9a53081", "line": { "color": "#866839" }, "name": "Fashion & Style", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:c21e90", "opacity": 0.8 }, { "uid": "d4ef001a-4b40-11e9-b65a-98e0d9a53081", "line": { "color": "#5FEC87" }, "name": "Culture", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:d2e127", "opacity": 0.8 }, { "uid": "d4ef00e2-4b40-11e9-9810-98e0d9a53081", "line": { "color": "#8CC9DC" }, "name": "Celebrity News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a4c84f", "opacity": 0.8 }, { "uid": "d4ef019e-4b40-11e9-87e3-98e0d9a53081", "line": { "color": "#BD1EFB" }, "name": "Mobile & Wireless", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:d712f1", "opacity": 0.8 }, { "uid": "d4ef025e-4b40-11e9-b254-98e0d9a53081", "line": { "color": "#AD99AF" }, "name": "Computer & Video Games", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:efc28b", "opacity": 0.8 }, { "uid": "d4ef0312-4b40-11e9-a141-98e0d9a53081", "line": { "color": "#91AF5C" }, "name": "Pets", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:e979de", "opacity": 0.8 }, { "uid": "d4ef03e4-4b40-11e9-966c-98e0d9a53081", "line": { "color": "#3C0226" }, "name": "World News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1f9066", "opacity": 0.8 }, { "uid": "d4ef04ac-4b40-11e9-979c-98e0d9a53081", "line": { "color": "#07392E" }, "name": "Language Resources", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:076945", "opacity": 0.8 }, { "uid": "d4ef0574-4b40-11e9-aa38-98e0d9a53081", "line": { "color": "#F03F6D" }, "name": "(undefined)", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:88085c", "opacity": 0.8 }, { "uid": "d4ef063a-4b40-11e9-9314-98e0d9a53081", "line": { "color": "#8856EA" }, "name": "Apartments & Residential Rentals", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:6caa08", "opacity": 0.8 }, { "uid": "d4ef0706-4b40-11e9-9dc7-98e0d9a53081", "line": { "color": "#6D0392" }, "name": "Childhood Education", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:3c4807", "opacity": 0.8 }, { "uid": "d4ef07cc-4b40-11e9-9059-98e0d9a53081", "line": { "color": "#CF4A70" }, "name": "Cheats & Walkthroughs", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:dfd3a6", "opacity": 0.8 }, { "uid": "d4ef0894-4b40-11e9-af45-98e0d9a53081", "line": { "color": "#BBEBE9" }, "name": "TV & Video", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a23021", "opacity": 0.8 }, { "uid": "d4ef0952-4b40-11e9-8e92-98e0d9a53081", "line": { "color": "#C72F2C" }, "name": "Cooking & Recipes", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:263c8a", "opacity": 0.8 }, { "uid": "d4ef0a1a-4b40-11e9-8c7a-98e0d9a53081", "line": { "color": "#51104F" }, "name": "Real Estate Listings", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:47cf82", "opacity": 0.8 }, { "uid": "d4ef0ad8-4b40-11e9-af9c-98e0d9a53081", "line": { "color": "#0A94F2" }, "name": "Social Networks", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:8995f7", "opacity": 0.8 }, { "uid": "d4ef0b8c-4b40-11e9-93d1-98e0d9a53081", "line": { "color": "#2D7FFD" }, "name": "Travel", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:d8d779", "opacity": 0.8 }, { "uid": "d4ef0c4a-4b40-11e9-90d5-98e0d9a53081", "line": { "color": "#EA2A53" }, "name": "Computers & Electronics", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1ea8e2", "opacity": 0.8 }, { "uid": "d4ef0cf4-4b40-11e9-b548-98e0d9a53081", "line": { "color": "#0FC4C8" }, "name": "Directories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:f940d5", "opacity": 0.8 }, { "uid": "d4ef0da8-4b40-11e9-8444-98e0d9a53081", "line": { "color": "#4BC0CA" }, "name": "Undisclosed", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:2e887e", "opacity": 0.8 }, { "uid": "d4ef0e66-4b40-11e9-a5c1-98e0d9a53081", "line": { "color": "#783653" }, "name": "Fashion & Style", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:2275ca", "opacity": 0.8 }, { "uid": "d4ef0f1a-4b40-11e9-87b3-98e0d9a53081", "line": { "color": "#F6C6C0" }, "name": "Culture", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:67aabd", "opacity": 0.8 }, { "uid": "d4ef0fcc-4b40-11e9-a529-98e0d9a53081", "line": { "color": "#61D5C6" }, "name": "Celebrity News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a4c84f", "opacity": 0.8 }, { "uid": "d4ef108c-4b40-11e9-acbe-98e0d9a53081", "line": { "color": "#DE0230" }, "name": "Mobile & Wireless", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:20031a", "opacity": 0.8 }, { "uid": "d4ef1154-4b40-11e9-b835-98e0d9a53081", "line": { "color": "#CCD776" }, "name": "Computer & Video Games", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:efc28b", "opacity": 0.8 }, { "uid": "d4ef121c-4b40-11e9-86af-98e0d9a53081", "line": { "color": "#48E69A" }, "name": "Pets", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1b7df2", "opacity": 0.8 }, { "uid": "d4ef12e4-4b40-11e9-abff-98e0d9a53081", "line": { "color": "#8AE583" }, "name": "World News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:996565", "opacity": 0.8 }, { "uid": "d4ef13ac-4b40-11e9-87b1-98e0d9a53081", "line": { "color": "#43E032" }, "name": "Language Resources", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:9f1355", "opacity": 0.8 }, { "uid": "d4ef1462-4b40-11e9-8cce-98e0d9a53081", "line": { "color": "#E8C8B4" }, "name": "(undefined)", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:88085c", "opacity": 0.8 }, { "uid": "d4ef1514-4b40-11e9-83ce-98e0d9a53081", "line": { "color": "#5AB3B5" }, "name": "Apartments & Residential Rentals", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:6caa08", "opacity": 0.8 }, { "uid": "d4ef15c8-4b40-11e9-8a11-98e0d9a53081", "line": { "color": "#B1FCE8" }, "name": "Childhood Education", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:3c4807", "opacity": 0.8 }, { "uid": "d4ef167a-4b40-11e9-9510-98e0d9a53081", "line": { "color": "#78A957" }, "name": "Cheats & Walkthroughs", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:dfd3a6", "opacity": 0.8 }, { "uid": "d4ef1730-4b40-11e9-8abd-98e0d9a53081", "line": { "color": "#9C3168" }, "name": "TV & Video", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a23021", "opacity": 0.8 }, { "uid": "d4ef17e4-4b40-11e9-ab0a-98e0d9a53081", "line": { "color": "#1C5037" }, "name": "Cooking & Recipes", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:263c8a", "opacity": 0.8 }, { "uid": "d4ef1898-4b40-11e9-a3e2-98e0d9a53081", "line": { "color": "#0910D5" }, "name": "Real Estate Listings", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:47cf82", "opacity": 0.8 }, { "uid": "d4ef194c-4b40-11e9-8d2d-98e0d9a53081", "line": { "color": "#8B6790" }, "name": "Social Networks", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:8995f7", "opacity": 0.8 }, { "uid": "d4ef1a00-4b40-11e9-bbbf-98e0d9a53081", "line": { "color": "#D8094F" }, "name": "Travel", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:d8d779", "opacity": 0.8 }, { "uid": "d4ef1abe-4b40-11e9-8def-98e0d9a53081", "line": { "color": "#02B4F9" }, "name": "Computers & Electronics", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1ea8e2", "opacity": 0.8 }, { "uid": "d4ef1b74-4b40-11e9-bbe4-98e0d9a53081", "line": { "color": "#62B4CF" }, "name": "Directories", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:f940d5", "opacity": 0.8 }, { "uid": "d4ef1c26-4b40-11e9-9a63-98e0d9a53081", "line": { "color": "#1883C4" }, "name": "Undisclosed", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:2e887e", "opacity": 0.8 }, { "uid": "d4ef1ce4-4b40-11e9-829a-98e0d9a53081", "line": { "color": "#8C1623" }, "name": "Fashion & Style", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:2275ca", "opacity": 0.8 }, { "uid": "d4ef1d98-4b40-11e9-b1de-98e0d9a53081", "line": { "color": "#2AECCF" }, "name": "Culture", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:67aabd", "opacity": 0.8 }, { "uid": "d4ef1e4c-4b40-11e9-a769-98e0d9a53081", "line": { "color": "#E6B8EA" }, "name": "Celebrity News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:a4c84f", "opacity": 0.8 }, { "uid": "d4ef1f34-4b40-11e9-9e7c-98e0d9a53081", "line": { "color": "#CC6B95" }, "name": "Mobile & Wireless", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:20031a", "opacity": 0.8 }, { "uid": "d4ef1ff0-4b40-11e9-9eb9-98e0d9a53081", "line": { "color": "#6A5C65" }, "name": "Computer & Video Games", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:efc28b", "opacity": 0.8 }, { "uid": "d4ef20a4-4b40-11e9-8d87-98e0d9a53081", "line": { "color": "#9F45D1" }, "name": "Pets", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:1b7df2", "opacity": 0.8 }, { "uid": "d4ef2158-4b40-11e9-88fe-98e0d9a53081", "line": { "color": "#D4C707" }, "name": "World News", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:996565", "opacity": 0.8 }, { "uid": "d4ef220c-4b40-11e9-b9e7-98e0d9a53081", "line": { "color": "#AFB4B3" }, "name": "Language Resources", "type": "scatter", "xsrc": "ametaxas:60:62e393", "ysrc": "ametaxas:60:9f1355", "opacity": 0.8 } ], "layout": { "title": "Top Category Seen Impressions Clicked", "xaxis": { "range": [ "2016-07-14", "2016-07-28" ] } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ametaxas", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-11-29 20:54:56", "mapbox_access_tokens": null, "has_password": null, "username": "ametaxas", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:40:21.862783Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cok8/21.embed", "fid": "cok8:21", "filename": "Golfchange", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cok8:21/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cok8:21/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cok8/21/8_3WNFRCW2VYER7LENE5EHVKA3A1T2T6.png", "list-thumb": "https://api.plotly.com/v2/files/cok8:21/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cok8:21", "plots": "https://api.plotly.com/v2/plots/cok8:21", "parent": "https://api.plotly.com/v2/folders/home?user=cok8" }, "owner": "cok8", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cok8/21/", "world_readable": true, "date_modified": "2019-03-20T19:57:05.515Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cok8/21/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a2588277-2832-4e3b-8072-c27c632a8452", "mode": "markers", "type": "scatter", "xsrc": "cok8:22:9dab25", "ysrc": "cok8:22:73ed3f" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cok8", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/20.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-09 23:38:52", "mapbox_access_tokens": null, "has_password": null, "username": "cok8", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:40:13.744601Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~BenjaBi/18.embed", "fid": "BenjaBi:18", "filename": "basic-bar", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/BenjaBi/18/9_6YT4TVHYTGAV2EQBF5N0EBEZNWYXK1.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/BenjaBi/18/2_BGXDR9W6AJN6G0EFJ8RRB9EBQDTK48.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/BenjaBi/18/8_04YG6B4ACES3YAJR16HDFJMQYQTAHO.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/BenjaBi/18/9_6YT4TVHYTGAV2EQBF5N0EBEZNWYXK1.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/BenjaBi:18", "plots": "https://api.plotly.com/v2/plots/BenjaBi:18", "parent": "https://api.plotly.com/v2/folders/home?user=BenjaBi" }, "owner": "BenjaBi", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 4, "web_url": "https://chart-studio.plotly.com/~BenjaBi/18/", "world_readable": true, "date_modified": "2019-03-20T18:40:14.762Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~BenjaBi/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "0806feb1-d92b-4cf1-8a16-bdab24bcc43b", "type": "bar", "xsrc": "BenjaBi:19:e8a3b8", "ysrc": "BenjaBi:19:63b9f7" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~BenjaBi", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/61.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-03 05:10:45", "mapbox_access_tokens": null, "has_password": null, "username": "BenjaBi", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:39:28.390347Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~asra/3.embed", "fid": "asra:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/asra:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/asra:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/asra/3/8_GLYFBM11IMFBPE6OR4XVEQFITBE6K8.png", "list-thumb": "https://api.plotly.com/v2/files/asra:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/asra:3", "plots": "https://api.plotly.com/v2/plots/asra:3", "parent": "https://api.plotly.com/v2/folders/home?user=asra" }, "owner": "asra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~asra/3/", "world_readable": true, "date_modified": "2019-03-20T18:39:28.405Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~asra/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "histogram", "xsrc": "asra:2:36be39", "ysrc": "asra:2:df8c29" } ], "frames": [], "layout": { "title": { "text": "Reads vs Preprocessed Reads" }, "xaxis": { "type": "linear", "range": [ -5, 105 ], "title": { "text": "Coverage %" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 136.8421052631579 ], "title": { "text": "Preprocessed Reads (millions)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~asra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 18:35:10", "mapbox_access_tokens": null, "has_password": null, "username": "asra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:35:54.883728Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pierricm/18.embed", "fid": "pierricm:18", "filename": "plot from API (4)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pierricm:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pierricm:18/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pierricm:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pierricm:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pierricm:18", "plots": "https://api.plotly.com/v2/plots/pierricm:18", "parent": "https://api.plotly.com/v2/folders/home?user=pierricm" }, "owner": "pierricm", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "PC2 vs PC1", "views": 0, "web_url": "https://chart-studio.plotly.com/~pierricm/18/pc2-vs-pc1/", "world_readable": true, "date_modified": "2019-03-20T18:35:55.310Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pierricm/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "dcc9bfeb-b8f0-40cb-9c1e-d56755f5a2d9", "mode": "markers", "name": "New space", "type": "scatter", "xsrc": "pierricm:19:803cc3", "ysrc": "pierricm:19:5f56d3", "marker": { "line": { "color": "rgba(100, 0, 150, 0.9)", "width": 0.5 }, "size": 12, "color": "rgba(100, 0, 150, 0.9)", "opacity": 0.8 } } ], "layout": { "xaxis": { "title": { "text": "PC1" }, "showline": false }, "yaxis": { "title": { "text": "PC2" }, "showline": false } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pierricm", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-10 12:43:05", "mapbox_access_tokens": null, "has_password": null, "username": "pierricm", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:35:48.480905Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~asra/1.embed", "fid": "asra:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/asra:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/asra:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/asra/1/8_4J9U85Q8T5ENU12XB1Y31PTC9OC0UH.png", "list-thumb": "https://api.plotly.com/v2/files/asra:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/asra:1", "plots": "https://api.plotly.com/v2/plots/asra:1", "parent": "https://api.plotly.com/v2/folders/home?user=asra" }, "owner": "asra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~asra/1/", "world_readable": true, "date_modified": "2019-03-20T18:35:48.547Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~asra/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "histogram", "xsrc": "asra:0:2c6c7c", "ysrc": "asra:0:51d0dc", "orientation": "v" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ -5, 105 ], "title": { "text": "Coverage %" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 136.8421052631579 ], "title": { "text": "Preprocessed reads (millions)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~asra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 18:35:10", "mapbox_access_tokens": null, "has_password": null, "username": "asra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:35:17.464097Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~iDrwish/12.embed", "fid": "iDrwish:12", "filename": "d3-world-map", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/iDrwish:12/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/iDrwish/12/2_O62V2UOSYTF9NPSXEI9G484X0R6VUB.png", "block-thumb": "https://api.plotly.com/v2/files/iDrwish:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/iDrwish:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/iDrwish:12", "plots": "https://api.plotly.com/v2/plots/iDrwish:12", "parent": "https://api.plotly.com/v2/folders/home?user=iDrwish" }, "owner": "iDrwish", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Halan Expanding Regionally", "views": 60, "web_url": "https://chart-studio.plotly.com/~iDrwish/12/halan-expanding-regionally/", "world_readable": true, "date_modified": "2019-05-22T10:19:42.982Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~iDrwish/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c31900e7-8389-4018-b448-1582a3567e0f", "type": "choropleth", "zsrc": "iDrwish:13:c36982", "marker": { "line": { "color": "rgb(180,180,180)", "width": 0.5 } }, "textsrc": "iDrwish:13:dee472", "colorscale": [ [ 0, "rgb(5, 10, 172)" ], [ 0.35, "rgb(40, 60, 190)" ], [ 0.5, "rgb(70, 100, 245)" ], [ 0.6, "rgb(90, 120, 245)" ], [ 0.7, "rgb(106, 137, 247)" ], [ 1, "rgb(220, 220, 220)" ] ], "showlegend": false, "locationssrc": "iDrwish:13:f77a38", "reversescale": true, "autocolorscale": false } ], "layout": { "geo": { "showframe": false, "projection": { "type": "equirectangular" }, "showcoastlines": false }, "title": { "text": "Halan Expanding Regionally" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~iDrwish", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/RGW1LB3E8RR1Y8WBULLK6RLMJQ901O.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "Schizophrenic Ninja", "nickname": "Mohamed Darwish", "website": "mohameddarwish.com", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-03-03 13:54:42", "mapbox_access_tokens": null, "has_password": null, "username": "iDrwish", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
