Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBMzElM0EyMy4xNzkyNDklMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBMjclM0E1MC4zOTk2NDUlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsxOCUzQTMxJTNBMjEuMjkxMjk5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T18:31:21.291299Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/28.embed", "fid": "tkarch:28", "filename": "plot from API (14)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:28/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:28/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:28/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:28/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:28", "plots": "https://api.plotly.com/v2/plots/tkarch:28", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total vs proceed", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/28/total-vs-proceed/", "world_readable": true, "date_modified": "2019-03-20T18:31:21.974Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/28/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "19355506-9dc5-47e1-aa10-7af3c21e4ecb", "name": "total", "type": "bar", "xsrc": "tkarch:29:689fd9", "ysrc": "tkarch:29:702459" }, { "uid": "b5d25aea-2ec5-4ae3-a0a5-79ba719c5ba0", "name": "proceed", "type": "bar", "xsrc": "tkarch:29:689fd9", "ysrc": "tkarch:29:635db8", "opacity": 0.6, "textsrc": "tkarch:29:098a13", "textposition": "auto" } ], "layout": { "barmode": "stack" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:30:36.896107Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/26.embed", "fid": "tkarch:26", "filename": "plot from API (13)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:26/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:26/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:26/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:26/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:26", "plots": "https://api.plotly.com/v2/plots/tkarch:26", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total vs proceed", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/26/total-vs-proceed/", "world_readable": true, "date_modified": "2019-03-20T18:30:37.332Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/26/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9a978376-1905-4fee-8c3a-55e26f4484ce", "name": "total", "type": "bar", "xsrc": "tkarch:27:4ee983", "ysrc": "tkarch:27:27bdd2" }, { "uid": "2ae1932c-c567-4724-a5ed-cac96d60453c", "name": "proceed", "type": "bar", "xsrc": "tkarch:27:4ee983", "ysrc": "tkarch:27:8e7697", "opacity": 0.6, "textsrc": "tkarch:27:dd2c85", "textposition": "auto" } ], "layout": { "barmode": "stack" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:30:25.328424Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ripan263/22.embed", "fid": "ripan263:22", "filename": "plot from API (11)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ripan263:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ripan263:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ripan263:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ripan263:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ripan263:22", "plots": "https://api.plotly.com/v2/plots/ripan263:22", "parent": "https://api.plotly.com/v2/folders/home?user=ripan263" }, "owner": "ripan263", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Emergency vs Non Emergency", "views": 0, "web_url": "https://chart-studio.plotly.com/~ripan263/22/emergency-vs-non-emergency/", "world_readable": true, "date_modified": "2019-03-20T18:30:25.836Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ripan263/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "73d0e44b-83b8-4c31-b7e5-c909450d85b0", "name": "Emergency", "type": "bar", "xsrc": "ripan263:23:8b37e9", "ysrc": "ripan263:23:cadb73" }, { "uid": "80f6fc40-707e-416e-956c-81e9f642bc58", "name": "Non Emergency", "type": "bar", "xsrc": "ripan263:23:8b37e9", "ysrc": "ripan263:23:87bbf6" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ripan263", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-11 09:47:49", "mapbox_access_tokens": null, "has_password": null, "username": "ripan263", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:30:15.931753Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/24.embed", "fid": "tkarch:24", "filename": "plot from API (12)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:24/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:24/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:24/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:24/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:24", "plots": "https://api.plotly.com/v2/plots/tkarch:24", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total, proceed, predicted", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/24/total-proceed-predicted/", "world_readable": true, "date_modified": "2019-03-20T18:30:16.713Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/24/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "6589f877-208a-4a96-8b29-1ccb0903be50", "name": "total", "type": "bar", "xsrc": "tkarch:25:6e41e6", "ysrc": "tkarch:25:2941c6" }, { "uid": "e6507095-d656-4ad2-97ae-1dbbc2eafc52", "name": "proceed", "type": "bar", "xsrc": "tkarch:25:6e41e6", "ysrc": "tkarch:25:134577", "opacity": 0.6, "textsrc": "tkarch:25:591e34", "textposition": "auto" }, { "uid": "e2d16b4a-d058-4537-a55f-009074fbbeeb", "name": "predicted", "type": "bar", "xsrc": "tkarch:25:6e41e6", "ysrc": "tkarch:25:80ca92" } ], "layout": { "barmode": "stack" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:30:02.519150Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dodoman/0.embed", "fid": "dodoman:0", "filename": "networkx", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dodoman:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/dodoman:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/dodoman/0/8_K5OMUCT1OZD18GOULJ3U5227PFB9H8.png", "list-thumb": "https://api.plotly.com/v2/files/dodoman:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dodoman:0", "plots": "https://api.plotly.com/v2/plots/dodoman:0", "parent": "https://api.plotly.com/v2/folders/home?user=dodoman" }, "owner": "dodoman", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "<br>Network graph made with Python", "views": 0, "web_url": "https://chart-studio.plotly.com/~dodoman/0/network-graph-made-with-python/", "world_readable": true, "date_modified": "2019-03-20T18:30:03.194Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dodoman/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f1a70b7f-436b-41f5-8b08-57892eae4f5a", "line": { "color": "#888", "width": 0.5 }, "mode": "lines", "type": "scatter", "xsrc": "dodoman:1:eb005c", "ysrc": "dodoman:1:0acf09", "hoverinfo": "none" }, { "uid": "a47331e3-7354-4da7-8fe8-fafc55d678dc", "mode": "markers", "type": "scatter", "xsrc": "dodoman:1:b78131", "ysrc": "dodoman:1:b82df5", "marker": { "line": { "width": 2 }, "size": 10, "colorbar": { "title": { "side": "right", "text": "Node Connections" }, "xanchor": "left", "thickness": 15 }, "colorsrc": "dodoman:1:d245f3", "showscale": true, "colorscale": "YlGnBu", "reversescale": true }, "textsrc": "dodoman:1:08d34f", "hoverinfo": "text" } ], "layout": { "title": { "font": { "size": 16 }, "text": "<br>Network graph made with Python" }, "xaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "yaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "margin": { "b": 20, "l": 5, "r": 5, "t": 40 }, "hovermode": "closest", "showlegend": false, "annotations": [ { "x": 0.005, "y": -0.002, "text": "Python code: <a href='https://plot.ly/ipython-notebooks/network-graphs/'> https://plot.ly/ipython-notebooks/network-graphs/</a>", "xref": "paper", "yref": "paper", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dodoman", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-20 18:24:52", "mapbox_access_tokens": null, "has_password": null, "username": "dodoman", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:29:09.752969Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ripan263/20.embed", "fid": "ripan263:20", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ripan263:20/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ripan263:20/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ripan263:20/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ripan263:20/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ripan263:20", "plots": "https://api.plotly.com/v2/plots/ripan263:20", "parent": "https://api.plotly.com/v2/folders/home?user=ripan263" }, "owner": "ripan263", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Emergency vs Non Emergency", "views": 0, "web_url": "https://chart-studio.plotly.com/~ripan263/20/emergency-vs-non-emergency/", "world_readable": true, "date_modified": "2019-03-20T18:29:10.177Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ripan263/20/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a1a8abc6-5a5a-4a23-b6da-847f980f9fc4", "name": "Emergency", "type": "bar", "xsrc": "ripan263:21:13a75a", "ysrc": "ripan263:21:bb52ef" }, { "uid": "256fe51f-f677-4ae3-b59a-4886597d8605", "name": "Non Emergency", "type": "bar", "xsrc": "ripan263:21:13a75a", "ysrc": "ripan263:21:e788c3" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ripan263", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-11 09:47:49", "mapbox_access_tokens": null, "has_password": null, "username": "ripan263", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:28:56.293962Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pierricm/16.embed", "fid": "pierricm:16", "filename": "plot from API (3)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pierricm:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pierricm:16/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/pierricm:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/pierricm:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pierricm:16", "plots": "https://api.plotly.com/v2/plots/pierricm:16", "parent": "https://api.plotly.com/v2/folders/home?user=pierricm" }, "owner": "pierricm", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "PC2 vs PC1", "views": 0, "web_url": "https://chart-studio.plotly.com/~pierricm/16/pc2-vs-pc1/", "world_readable": true, "date_modified": "2019-03-20T18:28:56.743Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pierricm/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3268eb72-e504-44bc-a2a2-49889e7596c2", "mode": "markers", "name": "New space", "type": "scatter", "xsrc": "pierricm:17:bb6ffa", "ysrc": "pierricm:17:a288b8", "marker": { "line": { "color": "rgba(100, 0, 150, 0.9)", "width": 0.5 }, "size": 12, "color": "rgba(100, 0, 150, 0.9)", "opacity": 0.8 } } ], "layout": { "xaxis": { "title": { "text": "PC1" }, "showline": false }, "yaxis": { "title": { "text": "PC2" }, "showline": false } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pierricm", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-10 12:43:05", "mapbox_access_tokens": null, "has_password": null, "username": "pierricm", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:28:49.623972Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/22.embed", "fid": "tkarch:22", "filename": "plot from API (11)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:22", "plots": "https://api.plotly.com/v2/plots/tkarch:22", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total, proceed, predicted", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/22/total-proceed-predicted/", "world_readable": true, "date_modified": "2019-03-20T18:28:50.144Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c1243836-42da-4e81-9390-964942d4ca1a", "name": "total", "type": "bar", "xsrc": "tkarch:23:a99e27", "ysrc": "tkarch:23:5847ba" }, { "uid": "eb0851af-dae4-4bc3-a1a7-a1fabe12245d", "name": "proceed", "type": "bar", "xsrc": "tkarch:23:a99e27", "ysrc": "tkarch:23:091829", "opacity": 0.6, "textsrc": "tkarch:23:8c7100", "textposition": "auto" }, { "uid": "fa3bc753-3124-487f-8785-50f6adc81516", "name": "predicted", "type": "bar", "xsrc": "tkarch:23:a99e27", "ysrc": "tkarch:23:2a1d8b" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:28:16.345055Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/20.embed", "fid": "tkarch:20", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:20/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:20/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:20/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:20/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:20", "plots": "https://api.plotly.com/v2/plots/tkarch:20", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total, proceed, predicted", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/20/total-proceed-predicted/", "world_readable": true, "date_modified": "2019-03-20T18:28:16.858Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/20/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "93ad89dc-da92-49a1-9fd1-4816c9fb8cfc", "name": "total", "type": "bar", "xsrc": "tkarch:21:482a37", "ysrc": "tkarch:21:7aafe2" }, { "uid": "725cde8c-1c48-4c0e-a275-5ed1c653b9ba", "name": "proceed", "type": "bar", "xsrc": "tkarch:21:482a37", "ysrc": "tkarch:21:718455", "textsrc": "tkarch:21:97b33d" }, { "uid": "9a1d57d7-3cfc-4423-a853-71e37d7668b1", "name": "predicted", "type": "bar", "xsrc": "tkarch:21:482a37", "ysrc": "tkarch:21:7bc57f" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:27:50.399645Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~valenvb/14.embed", "fid": "valenvb:14", "filename": "TILE_VALUE_HIGH-TILE_VALUE_VERY_HIGH", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/valenvb/14/9_J3XICZAYKBGBK821RL3M4IEH3M3S6X.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/valenvb/14/2_VN9XDYKFN5LOJRM6UXWP3OMJ4U90R7.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/valenvb/14/8_Q7OOW8KMD85W58BGNJKKLX56HPXP4U.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/valenvb/14/9_J3XICZAYKBGBK821RL3M4IEH3M3S6X.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/valenvb:14", "plots": "https://api.plotly.com/v2/plots/valenvb:14", "parent": "https://api.plotly.com/v2/folders/home?user=valenvb" }, "owner": "valenvb", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "TILE_VALUE_HIGH vs TILE_VALUE_VERY_HIGH", "views": 1, "web_url": "https://chart-studio.plotly.com/~valenvb/14/tile-value-high-vs-tile-value-very-high/", "world_readable": true, "date_modified": "2019-03-20T18:27:50.871Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~valenvb/14/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "TILE_VALUE_HIGH", "type": "scatter", "xsrc": "valenvb:15:950c9c", "ysrc": "valenvb:15:135938" }, { "name": "TILE_VALUE_VERY_HIGH", "type": "scatter", "xsrc": "valenvb:15:3a0134", "ysrc": "valenvb:15:135938" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~valenvb", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/94.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 16:15:53", "mapbox_access_tokens": null, "has_password": null, "username": "valenvb", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
