Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBMjclM0E1MC4zOTk2NDUlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTAzLTIwKzE4JTNBMjQlM0EwNy42MTU5NjAlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wMy0yMCsxOCUzQTI3JTNBMjkuNzg0MzIxJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-03-20T18:27:29.784321Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ripan263/18.embed", "fid": "ripan263:18", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ripan263:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ripan263:18/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ripan263:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ripan263:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ripan263:18", "plots": "https://api.plotly.com/v2/plots/ripan263:18", "parent": "https://api.plotly.com/v2/folders/home?user=ripan263" }, "owner": "ripan263", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Emergency vs Non Emergency", "views": 0, "web_url": "https://chart-studio.plotly.com/~ripan263/18/emergency-vs-non-emergency/", "world_readable": true, "date_modified": "2019-03-20T18:27:30.166Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ripan263/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "58b02e32-463c-4bd2-b9b5-faf0bdbc811b", "name": "Emergency", "type": "bar", "xsrc": "ripan263:19:50c4ac", "ysrc": "ripan263:19:253e73" }, { "uid": "d0902fd3-1b44-4617-82ef-f464122c03ba", "name": "Non Emergency", "type": "bar", "xsrc": "ripan263:19:50c4ac", "ysrc": "ripan263:19:869d6c" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ripan263", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-11 09:47:49", "mapbox_access_tokens": null, "has_password": null, "username": "ripan263", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:26:49.952704Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/18.embed", "fid": "tkarch:18", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:18/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:18/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:18", "plots": "https://api.plotly.com/v2/plots/tkarch:18", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total, proceed, predicted", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/18/total-proceed-predicted/", "world_readable": true, "date_modified": "2019-03-20T18:26:50.416Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "592f71e0-4c5c-4422-8a8b-787307a2d39e", "name": "total", "type": "bar", "xsrc": "tkarch:19:a8164a", "ysrc": "tkarch:19:958be3" }, { "uid": "19c03f33-fb12-4052-8a7c-ecb857bf5627", "name": "proceed", "type": "bar", "xsrc": "tkarch:19:a8164a", "ysrc": "tkarch:19:05d3c5" }, { "uid": "d9c4b0cd-eebb-4706-8561-b1c3b3c04f95", "name": "predicted", "type": "bar", "xsrc": "tkarch:19:a8164a", "ysrc": "tkarch:19:bb8e9e" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:26:19.593145Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/16.embed", "fid": "tkarch:16", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:16/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:16", "plots": "https://api.plotly.com/v2/plots/tkarch:16", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total vs proceed", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/16/total-vs-proceed/", "world_readable": true, "date_modified": "2019-03-20T18:26:20.160Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a21c5f67-0d30-4448-ac81-8b23c71f216d", "mode": "lines", "name": "total", "type": "scatter", "xsrc": "tkarch:17:42ebbd", "ysrc": "tkarch:17:55463a" }, { "uid": "6def7110-d139-425d-9c02-ef3336b5e649", "name": "proceed", "type": "bar", "xsrc": "tkarch:17:42ebbd", "ysrc": "tkarch:17:2f3096" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:25:23.684845Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ripan263/16.embed", "fid": "ripan263:16", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ripan263:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ripan263:16/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ripan263:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ripan263:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ripan263:16", "plots": "https://api.plotly.com/v2/plots/ripan263:16", "parent": "https://api.plotly.com/v2/folders/home?user=ripan263" }, "owner": "ripan263", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Emergency vs Non Emergency", "views": 0, "web_url": "https://chart-studio.plotly.com/~ripan263/16/emergency-vs-non-emergency/", "world_readable": true, "date_modified": "2019-03-20T18:25:24.259Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ripan263/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "cacff516-5ba9-4405-840b-1666d8fbf458", "name": "Emergency", "type": "bar", "xsrc": "ripan263:17:d6e40d", "ysrc": "ripan263:17:061285" }, { "uid": "a651c1fa-fe06-480c-aab8-2506e3bd3326", "name": "Non Emergency", "type": "bar", "xsrc": "ripan263:17:d6e40d", "ysrc": "ripan263:17:e7db94" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ripan263", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/88.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-11 09:47:49", "mapbox_access_tokens": null, "has_password": null, "username": "ripan263", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:25:12.747157Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/14.embed", "fid": "tkarch:14", "filename": "plot from API (7)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:14/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:14/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:14/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:14/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:14", "plots": "https://api.plotly.com/v2/plots/tkarch:14", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total vs proceed", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/14/total-vs-proceed/", "world_readable": true, "date_modified": "2019-03-20T18:25:13.160Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/14/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "2f24aa93-70be-4c9e-95e0-15602b76b683", "mode": "lines", "name": "total", "type": "scatter", "xsrc": "tkarch:15:affe53", "ysrc": "tkarch:15:2e5691" }, { "uid": "982ec6bf-be8e-4ea3-9768-3bae438506af", "name": "proceed", "type": "bar", "xsrc": "tkarch:15:08242e", "ysrc": "tkarch:15:637b80" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:25:08.266932Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~shp557/351.embed", "fid": "shp557:351", "filename": "9.5_old_3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/shp557/351/9_4ECI9GAF6SBDMJF4GOCCZXNS3FIVSE.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/shp557/351/2_YSX93KUC34CHASJUD9INP22BSMJX9X.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/shp557/351/8_UNKGRL6FN26YBA3YZGG3X3D4HQQPZA.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/shp557/351/9_4ECI9GAF6SBDMJF4GOCCZXNS3FIVSE.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shp557:351", "plots": "https://api.plotly.com/v2/plots/shp557:351", "parent": "https://api.plotly.com/v2/folders/home?user=shp557" }, "owner": "shp557", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~shp557/351/", "world_readable": true, "date_modified": "2019-03-20T18:25:09.502Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~shp557/351/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "heatmap", "zsrc": "shp557:352:", "colorscale": "Viridis" } ], "layout": { "width": 350, "xaxis": { "ticks": "", "showgrid": false, "showline": false, "zeroline": false, "autorange": true, "showticklabels": false }, "yaxis": { "ticks": "", "showgrid": false, "showline": false, "zeroline": false, "autorange": true, "showticklabels": false }, "height": 500 } }, "height": 500, "width": 350, "user": { "profile_url": "https://chart-studio.plotly.com/~shp557", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/14.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-09-26 18:57:22", "mapbox_access_tokens": null, "has_password": null, "username": "shp557", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:24:47.313415Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dpatel0698/24.embed", "fid": "dpatel0698:24", "filename": "interactive_state_health", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dpatel0698:24/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/dpatel0698:24/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/dpatel0698:24/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/dpatel0698:24/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dpatel0698:24", "plots": "https://api.plotly.com/v2/plots/dpatel0698:24", "parent": "https://api.plotly.com/v2/folders/home?user=dpatel0698" }, "owner": "dpatel0698", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~dpatel0698/24/", "world_readable": true, "date_modified": "2019-03-20T18:24:47.782Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dpatel0698/24/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "8c5e045f-92d9-4a7f-a68e-cd7ccaef35cf", "type": "scatter", "xsrc": "dpatel0698:25:119fc6", "ysrc": "dpatel0698:25:36eeff", "marker": { "color": "blue" }, "textsrc": "dpatel0698:25:7c0733", "showlegend": false } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dpatel0698", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-04-09 02:10:44", "mapbox_access_tokens": null, "has_password": null, "username": "dpatel0698", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:24:31.809789Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~tkarch/12.embed", "fid": "tkarch:12", "filename": "plot from API (6)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tkarch:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tkarch:12/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tkarch:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tkarch:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tkarch:12", "plots": "https://api.plotly.com/v2/plots/tkarch:12", "parent": "https://api.plotly.com/v2/folders/home?user=tkarch" }, "owner": "tkarch", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "total vs proceed", "views": 0, "web_url": "https://chart-studio.plotly.com/~tkarch/12/total-vs-proceed/", "world_readable": true, "date_modified": "2019-03-20T18:24:32.421Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~tkarch/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3824fa05-a8ae-41cc-8ddd-6dacb6abcd74", "mode": "lines", "name": "total", "type": "scatter", "xsrc": "tkarch:13:dfd58b", "ysrc": "tkarch:13:a0c737" }, { "uid": "b2aba3c1-dfbc-4c6c-97c2-7176a59e71e9", "name": "proceed", "type": "bar", "xsrc": "tkarch:13:dfd58b", "ysrc": "tkarch:13:311924" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~tkarch", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 15:32:08", "mapbox_access_tokens": null, "has_password": null, "username": "tkarch", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:24:17.989764Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~hmng/0.embed", "fid": "hmng:0", "filename": "grouped-bar", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/hmng:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/hmng:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/hmng:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/hmng:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/hmng:0", "plots": "https://api.plotly.com/v2/plots/hmng:0", "parent": "https://api.plotly.com/v2/folders/home?user=hmng" }, "owner": "hmng", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "SF Zoo vs LA Zoo", "views": 2, "web_url": "https://chart-studio.plotly.com/~hmng/0/sf-zoo-vs-la-zoo/", "world_readable": true, "date_modified": "2019-03-20T18:24:48.222Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~hmng/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e90cdfaa-df21-402f-83a0-c5ad3c6822d2", "name": "SF Zoo", "type": "bar", "xsrc": "hmng:1:344cbc", "ysrc": "hmng:1:30fe4d" }, { "uid": "162883b5-ecd3-4c23-8055-10f6894a71ba", "name": "LA Zoo", "type": "bar", "xsrc": "hmng:1:344cbc", "ysrc": "hmng:1:43f7dc" } ], "layout": { "barmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~hmng", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/19.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-07-24 23:49:20", "mapbox_access_tokens": null, "has_password": null, "username": "hmng", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-03-20T18:24:07.615960Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Salihimc/101.embed", "fid": "Salihimc:101", "filename": "Plot 101", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Salihimc:101/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Salihimc:101/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Salihimc/101/8_8TJM38Q4QIF0MPDT9BB3KP0EMHLTX2.png", "list-thumb": "https://api.plotly.com/v2/files/Salihimc:101/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Salihimc:101", "plots": "https://api.plotly.com/v2/plots/Salihimc:101", "parent": "https://api.plotly.com/v2/folders/home?user=Salihimc" }, "owner": "Salihimc", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~Salihimc/101/", "world_readable": true, "date_modified": "2019-03-20T18:24:07.632Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Salihimc/101/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "17e63e6c-43e2-11e9-918b-60f677db332c", "name": "Pharmaton 30", "type": "bar", "xsrc": "Salihimc:100:f764f3", "ysrc": "Salihimc:100:9fc3a5", "marker": { "line": { "color": "rgb(0, 0, 0)", "width": 1.5 }, "color": "#581E2D" }, "textsrc": "Salihimc:100:2015c4", "textposition": "auto" }, { "uid": "17e63e6d-43e2-11e9-8f43-60f677db332c", "name": "Supradyn 30", "type": "bar", "xsrc": "Salihimc:100:f764f3", "ysrc": "Salihimc:100:a8b282", "marker": { "line": { "color": "rgb(0, 0, 0)", "width": 1.5 }, "color": "#FAE411" }, "textsrc": "Salihimc:100:ba22be", "textposition": "auto" } ], "frames": [], "layout": { "title": { "text": "Pharmaton 30 vs. Supradyn FCT 30 Yearly Sales (2015 - 2018)" }, "xaxis": { "type": "linear", "range": [ 2014.5, 2018.5 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 1812970.5263157894 ], "autorange": true }, "barmode": "group", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Salihimc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/38.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-28 14:39:59", "mapbox_access_tokens": null, "has_password": null, "username": "Salihimc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
