Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE4KzAzJTNBMDclM0E1OC4wOTcwNDMlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE4KzAzJTNBMDIlM0EwNC45NDA4NzQlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xOCswMyUzQTA3JTNBMzcuNjI1MjIyJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-18T03:07:37.625222Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~wanner.95/15.embed", "fid": "wanner.95:15", "filename": "Plot 15", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/wanner.95:15/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/wanner.95/15/2_CMX8DUTTLTD1PKMIIRTF8CZ0KABXUV.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/wanner.95/15/8_XU9P54NV635GW4ENU3Z7ACGLH5ZG7V.png", "list-thumb": "https://api.plotly.com/v2/files/wanner.95:15/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/wanner.95:15", "plots": "https://api.plotly.com/v2/plots/wanner.95:15", "parent": "https://api.plotly.com/v2/folders/home?user=wanner.95" }, "owner": "wanner.95", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 12, "web_url": "https://plotly.com/~wanner.95/15/", "world_readable": true, "date_modified": "2019-06-18T03:07:37.641Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~wanner.95/15/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "wanner.95:14:e36223", "ysrc": "wanner.95:14:f6c72e", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(152, 0, 0, .8)", "width": 1 }, "size": 10, "color": "rgba(255, 192, 182, 0.9)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" }, "opacity": 0.81 } ], "frames": [], "layout": { "font": { "size": 12, "color": "rgb(26, 25, 25)" }, "title": { "font": { "color": "rgb(33, 30, 30)" }, "text": "Gráfico de Dispersión" }, "xaxis": { "type": "linear", "range": [ -0.27087956698240867, 6.180879566982409 ], "title": { "text": "gasto en alcohol - tabaco" }, "domain": [ 0, 1 ], "zeroline": false, "autorange": true, "automargin": true }, "yaxis": { "type": "linear", "range": [ -0.5332967032967034, 6.973296703296704 ], "title": { "text": "gasto en salud" }, "domain": [ 0, 1 ], "zeroline": false, "autorange": true, "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "modebar": { "color": "rgba(8, 1, 1, 0.3)", "activecolor": "rgba(54, 13, 13, 0.7)" }, "colorway": [ "#4c78a8", "#f58518", "#e45756", "#72b7b2", "#54a24b", "#eeca3b", "#b279a2", "#ff9da6", "#9d755d", "#bab0ac" ], "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "rgb(231,231,240)" }, "line": { "color": "white" } }, "header": { "fill": { "color": "rgb(183,183,191)" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(36,36,36)", "minorgridcolor": "white", "startlinecolor": "rgb(36,36,36)" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "rgb(36,36,36)", "minorgridcolor": "white", "startlinecolor": "rgb(36,36,36)" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "outside", "ticklen": 8, "tickcolor": "rgb(36,36,36)", "tickwidth": 2, "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "rgb(234,234,242)", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "rgb(36,36,36)" }, "polar": { "bgcolor": "rgb(234,234,242)", "radialaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(234,234,242)" }, "yaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(234,234,242)" }, "zaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "rgb(234,234,242)" } }, "xaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white" }, "yaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white" }, "ternary": { "aaxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "showgrid": true, "gridcolor": "white", "linecolor": "white" }, "bgcolor": "rgb(234,234,242)" }, "colorway": [ "rgb(76,114,176)", "rgb(221,132,82)", "rgb(85,168,104)", "rgb(196,78,82)", "rgb(129,114,179)", "rgb(147,120,96)", "rgb(218,139,195)", "rgb(140,140,140)", "rgb(204,185,116)", "rgb(100,181,205)" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#67001f" ], [ 0.1, "#b2182b" ], [ 0.2, "#d6604d" ], [ 0.3, "#f4a582" ], [ 0.4, "#fddbc7" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#d1e5f0" ], [ 0.7, "#92c5de" ], [ 0.8, "#4393c3" ], [ 0.9, "#2166ac" ], [ 1, "#053061" ] ], "sequential": [ [ 0, "rgb(2,4,25)" ], [ 0.06274509803921569, "rgb(24,15,41)" ], [ 0.12549019607843137, "rgb(47,23,57)" ], [ 0.18823529411764706, "rgb(71,28,72)" ], [ 0.25098039215686274, "rgb(97,30,82)" ], [ 0.3137254901960784, "rgb(123,30,89)" ], [ 0.3764705882352941, "rgb(150,27,91)" ], [ 0.4392156862745098, "rgb(177,22,88)" ], [ 0.5019607843137255, "rgb(203,26,79)" ], [ 0.5647058823529412, "rgb(223,47,67)" ], [ 0.6274509803921569, "rgb(236,76,61)" ], [ 0.6901960784313725, "rgb(242,107,73)" ], [ 0.7529411764705882, "rgb(244,135,95)" ], [ 0.8156862745098039, "rgb(245,162,122)" ], [ 0.8784313725490196, "rgb(246,188,153)" ], [ 0.9411764705882353, "rgb(247,212,187)" ], [ 1, "rgb(250,234,220)" ] ], "sequentialminus": [ [ 0, "rgb(2,4,25)" ], [ 0.06274509803921569, "rgb(24,15,41)" ], [ 0.12549019607843137, "rgb(47,23,57)" ], [ 0.18823529411764706, "rgb(71,28,72)" ], [ 0.25098039215686274, "rgb(97,30,82)" ], [ 0.3137254901960784, "rgb(123,30,89)" ], [ 0.3764705882352941, "rgb(150,27,91)" ], [ 0.4392156862745098, "rgb(177,22,88)" ], [ 0.5019607843137255, "rgb(203,26,79)" ], [ 0.5647058823529412, "rgb(223,47,67)" ], [ 0.6274509803921569, "rgb(236,76,61)" ], [ 0.6901960784313725, "rgb(242,107,73)" ], [ 0.7529411764705882, "rgb(244,135,95)" ], [ 0.8156862745098039, "rgb(245,162,122)" ], [ 0.8784313725490196, "rgb(246,188,153)" ], [ 0.9411764705882353, "rgb(247,212,187)" ], [ 1, "rgb(250,234,220)" ] ] }, "plot_bgcolor": "rgb(234,234,242)", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.5, "fillcolor": "rgb(67,103,167)" }, "annotationdefaults": { "arrowcolor": "rgb(67,103,167)" } }, "themeRef": "SEABORN" }, "hovermode": "closest", "showlegend": false, "plot_bgcolor": "rgb(120, 120, 163)", "paper_bgcolor": "rgb(235, 223, 223)" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~wanner.95", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/76.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-16 16:28:42", "mapbox_access_tokens": null, "has_password": null, "username": "wanner.95", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:07:31.898558Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~khuang316/14.embed", "fid": "khuang316:14", "filename": "JD Days from Session to Store Visit", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/khuang316:14/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/khuang316:14/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/khuang316:14/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/khuang316:14/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/khuang316:14", "plots": "https://api.plotly.com/v2/plots/khuang316:14", "parent": "https://api.plotly.com/v2/folders/home?user=khuang316" }, "owner": "khuang316", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Time From Site to Store Visit Distribution", "views": 54, "web_url": "https://plotly.com/~khuang316/14/time-from-site-to-store-visit-distribution/", "world_readable": true, "date_modified": "2019-06-28T15:31:23.170Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~khuang316/14/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b908f0d5-9b2d-4d8b-a1ec-2fae92a378b8", "name": "visit count", "type": "bar", "xsrc": "khuang316:15:9f6954", "ysrc": "khuang316:15:43ac63", "marker": { "color": "lightblue" } }, { "uid": "511a4739-e552-403d-ab67-78271ecee3b6", "name": "running pct of total", "type": "scatter", "xsrc": "khuang316:15:9f6954", "ysrc": "khuang316:15:02e5c6", "marker": { "color": "darkorchid" } } ], "layout": { "title": { "text": "Time From Site to Store Visit Distribution" }, "yaxis": { "title": { "font": { "color": "lightblue" }, "text": "visit count" } }, "yaxis2": { "side": "right", "title": { "font": { "color": "darkorchid" }, "text": "running pct of total" }, "overlaying": "y", "tickformat": "%" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~khuang316", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/61.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-11 17:11:43", "mapbox_access_tokens": null, "has_password": null, "username": "khuang316", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:05:34.273111Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~shaddyjr/2.embed", "fid": "shaddyjr:2", "filename": "Distplot with Multiple Bin Sizes", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/shaddyjr:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/shaddyjr:2/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/shaddyjr/2/8_MOYVX5JYFPSJJ12DNVZOMSHFA4WI8P.png", "list-thumb": "https://api.plotly.com/v2/files/shaddyjr:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/shaddyjr:2", "plots": "https://api.plotly.com/v2/plots/shaddyjr:2", "parent": "https://api.plotly.com/v2/folders/home?user=shaddyjr" }, "owner": "shaddyjr", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "sepal length (cm), sepal width (cm), petal length (cm), petal width (cm), sepal length (cm), sepal width (cm), petal length (cm), petal width (cm)", "views": 1, "web_url": "https://plotly.com/~shaddyjr/2/sepal-length-cm-sepal-width-cm-petal-length-cm-petal-width-cm-sepal-length-cm-se/", "world_readable": true, "date_modified": "2019-06-21T15:25:17.736Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~shaddyjr/2/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a6ae88f1-5606-4267-8429-ac9cc567c110", "name": "sepal length (cm)", "type": "histogram", "xsrc": "shaddyjr:3:4db646", "xaxis": "x", "xbins": { "end": 7.9, "size": 0.5, "start": 4.3 }, "yaxis": "y", "marker": { "color": "rgb(31, 119, 180)" }, "opacity": 0.7, "autobinx": false, "histnorm": "probability density", "legendgroup": "sepal length (cm)" }, { "uid": "fd2b89dd-e909-42f0-8026-8a7b2fed8567", "name": "sepal width (cm)", "type": "histogram", "xsrc": "shaddyjr:3:923a04", "xaxis": "x", "xbins": { "end": 4.4, "size": 0.5, "start": 2.0 }, "yaxis": "y", "marker": { "color": "rgb(255, 127, 14)" }, "opacity": 0.7, "autobinx": false, "histnorm": "probability density", "legendgroup": "sepal width (cm)" }, { "uid": "4c027f31-40c0-45c4-bea8-33183423f17a", "name": "petal length (cm)", "type": "histogram", "xsrc": "shaddyjr:3:9a6a51", "xaxis": "x", "xbins": { "end": 6.9, "size": 0.5, "start": 1.0 }, "yaxis": "y", "marker": { "color": "rgb(44, 160, 44)" }, "opacity": 0.7, "autobinx": false, "histnorm": "probability density", "legendgroup": "petal length (cm)" }, { "uid": "9a3c34a5-1ed6-4eef-85f6-5c3c7984293b", "name": "petal width (cm)", "type": "histogram", "xsrc": "shaddyjr:3:cc9b4d", "xaxis": "x", "xbins": { "end": 2.5, "size": 0.5, "start": 0.1 }, "yaxis": "y", "marker": { "color": "rgb(214, 39, 40)" }, "opacity": 0.7, "autobinx": false, "histnorm": "probability density", "legendgroup": "petal width (cm)" }, { "uid": "8aae79a1-c3b8-453b-a265-f34642c5c334", "mode": "lines", "name": "sepal length (cm)", "type": "scatter", "xsrc": "shaddyjr:3:447ebb", "ysrc": "shaddyjr:3:5c13ca", "xaxis": "x", "yaxis": "y", "marker": { "color": "rgb(31, 119, 180)" }, "showlegend": false, "legendgroup": "sepal length (cm)" }, { "uid": "f22775e9-0f78-4df0-bf07-6d4e6b07b9b9", "mode": "lines", "name": "sepal width (cm)", "type": "scatter", "xsrc": "shaddyjr:3:9b9234", "ysrc": "shaddyjr:3:14acd6", "xaxis": "x", "yaxis": "y", "marker": { "color": "rgb(255, 127, 14)" }, "showlegend": false, "legendgroup": "sepal width (cm)" }, { "uid": "625d0f44-dbf7-49b9-a704-f32cf7c3c0a3", "mode": "lines", "name": "petal length (cm)", "type": "scatter", "xsrc": "shaddyjr:3:87d8ac", "ysrc": "shaddyjr:3:740abd", "xaxis": "x", "yaxis": "y", "marker": { "color": "rgb(44, 160, 44)" }, "showlegend": false, "legendgroup": "petal length (cm)" }, { "uid": "4f8f9a0a-482d-49ea-a4d2-1912b6ac60fc", "mode": "lines", "name": "petal width (cm)", "type": "scatter", "xsrc": "shaddyjr:3:a59f52", "ysrc": "shaddyjr:3:577b33", "xaxis": "x", "yaxis": "y", "marker": { "color": "rgb(214, 39, 40)" }, "showlegend": false, "legendgroup": "petal width (cm)" } ], "layout": { "xaxis": { "anchor": "y2", "domain": [ 0.0, 1.0 ], "zeroline": false }, "yaxis": { "anchor": "free", "domain": [ 0.0, 1 ], "position": 0.0 }, "legend": { "traceorder": "reversed" }, "barmode": "overlay", "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~shaddyjr", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/56.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 02:53:42", "mapbox_access_tokens": null, "has_password": null, "username": "shaddyjr", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:04:21.513633Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~lala7873/2.embed", "fid": "lala7873:2", "filename": "multiple-axes-multiple", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/lala7873:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/lala7873:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/lala7873:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/lala7873:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/lala7873:2", "plots": "https://api.plotly.com/v2/plots/lala7873:2", "parent": "https://api.plotly.com/v2/folders/home?user=lala7873" }, "owner": "lala7873", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "multiple y-axes example", "views": 0, "web_url": "https://plotly.com/~lala7873/2/multiple-y-axes-example/", "world_readable": true, "date_modified": "2019-06-18T03:04:22.048Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~lala7873/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "6accf992-7fff-4f9f-9701-1acbe6a687e6", "name": "yaxis1 data", "type": "scatter", "xsrc": "lala7873:3:efc663", "ysrc": "lala7873:3:184c3b" }, { "uid": "69ca1086-c76e-4517-a792-5cb51bfb34a5", "name": "yaxis2 data", "type": "scatter", "xsrc": "lala7873:3:aa09d9", "ysrc": "lala7873:3:dff276", "yaxis": "y2" }, { "uid": "58f254b6-03a1-483d-beda-6f4c9dd4c19a", "name": "yaxis3 data", "type": "scatter", "xsrc": "lala7873:3:018552", "ysrc": "lala7873:3:119fe6", "yaxis": "y3" }, { "uid": "c596ede6-c2a4-4945-bc70-d028e17e35fb", "name": "yaxis4 data", "type": "scatter", "xsrc": "lala7873:3:be99ff", "ysrc": "lala7873:3:0f55c5", "yaxis": "y4" } ], "layout": { "title": { "text": "multiple y-axes example" }, "width": 800, "xaxis": { "domain": [ 0.3, 0.7 ] }, "yaxis": { "title": { "font": { "color": "#1f77b4" }, "text": "yaxis title" }, "tickfont": { "color": "#1f77b4" } }, "yaxis2": { "side": "left", "title": { "font": { "color": "#ff7f0e" }, "text": "yaxis2 title" }, "anchor": "free", "position": 0.15, "tickfont": { "color": "#ff7f0e" }, "overlaying": "y" }, "yaxis3": { "side": "right", "title": { "font": { "color": "#d62728" }, "text": "yaxis4 title" }, "anchor": "x", "tickfont": { "color": "#d62728" }, "overlaying": "y" }, "yaxis4": { "side": "right", "title": { "font": { "color": "#9467bd" }, "text": "yaxis5 title" }, "anchor": "free", "position": 0.85, "tickfont": { "color": "#9467bd" }, "overlaying": "y" } } }, "height": null, "width": 800, "user": { "profile_url": "https://plotly.com/~lala7873", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/30.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-05-27 03:05:41", "mapbox_access_tokens": null, "has_password": null, "username": "lala7873", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:03:47.712825Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~jkulp/4.embed", "fid": "jkulp:4", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jkulp:4/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/jkulp/4/2_SGK31VJV4Y9VT38UTGA7GGJPBN8N77.png", "block-thumb": "https://api.plotly.com/v2/files/jkulp:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jkulp:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jkulp:4", "plots": "https://api.plotly.com/v2/plots/jkulp:4", "parent": "https://api.plotly.com/v2/folders/home?user=jkulp" }, "owner": "jkulp", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://plotly.com/~jkulp/4/", "world_readable": true, "date_modified": "2019-06-18T03:03:48.279Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~jkulp/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "2f176114-a42f-45e1-89fa-5d7d243dcb48", "type": "pie", "labelssrc": "jkulp:5:62bb92", "valuessrc": "jkulp:5:bfe43d" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~jkulp", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/96.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-18 02:48:29", "mapbox_access_tokens": null, "has_password": null, "username": "jkulp", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:03:47.000885Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~claudevdmf/40.embed", "fid": "claudevdmf:40", "filename": "stacked-bar", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/claudevdmf:40/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/claudevdmf:40/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/claudevdmf/40/8_FAISJOB78TKHG8CNF9AY68IR41JXQB.png", "list-thumb": "https://api.plotly.com/v2/files/claudevdmf:40/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/claudevdmf:40", "plots": "https://api.plotly.com/v2/plots/claudevdmf:40", "parent": "https://api.plotly.com/v2/folders/home?user=claudevdmf" }, "owner": "claudevdmf", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Undergraduate, Graduate, Law, Continuing Education, Other", "views": 29, "web_url": "https://plotly.com/~claudevdmf/40/undergraduate-graduate-law-continuing-education-other/", "world_readable": true, "date_modified": "2019-06-19T22:53:16.521Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~claudevdmf/40/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "65bb5060-f52c-48db-a492-50d1722d4d65", "name": "Undergraduate", "type": "bar", "xsrc": "claudevdmf:41:a53af5", "ysrc": "claudevdmf:41:630766", "orientation": "h" }, { "uid": "bca4818e-a866-4f30-a558-467988007692", "name": "Graduate", "type": "bar", "xsrc": "claudevdmf:41:03ec1d", "ysrc": "claudevdmf:41:630766", "orientation": "h" }, { "uid": "a6a4ffdb-8c11-4338-a5df-154f9eb41264", "name": "Law", "type": "bar", "xsrc": "claudevdmf:41:5907c4", "ysrc": "claudevdmf:41:630766", "orientation": "h" }, { "uid": "b4441cc7-fc3f-466f-bed2-c59fbff23090", "name": "Continuing Education", "type": "bar", "xsrc": "claudevdmf:41:2bf4dc", "ysrc": "claudevdmf:41:630766", "orientation": "h" }, { "uid": "4d2a1b87-04e3-4687-80dc-ab5c21dadf13", "name": "Other", "type": "bar", "xsrc": "claudevdmf:41:cc4e33", "ysrc": "claudevdmf:41:630766", "orientation": "h" } ], "layout": { "barmode": "stack" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~claudevdmf", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-28 16:06:58", "mapbox_access_tokens": null, "has_password": null, "username": "claudevdmf", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:03:43.568312Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~manikkalra/24.embed", "fid": "manikkalra:24", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/manikkalra:24/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/manikkalra/24/2_Z9S6L1GQRBS72ZG2ZC018MYGUODLLG.png", "block-thumb": "https://api.plotly.com/v2/files/manikkalra:24/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/manikkalra:24/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/manikkalra:24", "plots": "https://api.plotly.com/v2/plots/manikkalra:24", "parent": "https://api.plotly.com/v2/folders/home?user=manikkalra" }, "owner": "manikkalra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Volume", "views": 3, "web_url": "https://plotly.com/~manikkalra/24/volume/", "world_readable": true, "date_modified": "2019-06-18T03:03:44.089Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~manikkalra/24/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e304c4c2-d33c-44be-9df5-39e138a8be52", "type": "candlestick", "xsrc": "manikkalra:25:a8a168", "lowsrc": "manikkalra:25:e293bd", "highsrc": "manikkalra:25:08c917", "opensrc": "manikkalra:25:1cf9ea", "closesrc": "manikkalra:25:f44af2" }, { "uid": "15bd866d-7846-40d6-b03b-5de30ff504b5", "name": "Volume", "type": "bar", "xsrc": "manikkalra:25:a8a168", "ysrc": "manikkalra:25:e2c351", "yaxis": "y", "marker": { "colorsrc": "manikkalra:25:0c0687" } } ], "layout": { "xaxis": { "rangeslider": { "visible": false } }, "plot_bgcolor": "rgb(0,0,0)" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~manikkalra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/70.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 21:53:50", "mapbox_access_tokens": null, "has_password": null, "username": "manikkalra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:03:33.982029Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~ValerieWanQi/22.embed", "fid": "ValerieWanQi:22", "filename": "basic-scatter", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/ValerieWanQi/22/9_R91MI3YZAYK12J58TV7ZNBTBB7205S.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ValerieWanQi/22/2_ZS7Q97UIEGGZ7O1F1L7P5A6HM61YQ6.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ValerieWanQi/22/8_MVE0A0JD6FJCKOHFQZX3GX11YTPAKO.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/ValerieWanQi/22/9_R91MI3YZAYK12J58TV7ZNBTBB7205S.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ValerieWanQi:22", "plots": "https://api.plotly.com/v2/plots/ValerieWanQi:22", "parent": "https://api.plotly.com/v2/folders/home?user=ValerieWanQi" }, "owner": "ValerieWanQi", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://plotly.com/~ValerieWanQi/22/", "world_readable": true, "date_modified": "2019-06-18T03:04:03.191Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~ValerieWanQi/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "7893c187-33de-4fcc-99c6-ab157ebb9d03", "mode": "markers", "type": "scatter", "xsrc": "ValerieWanQi:23:f2bc83", "ysrc": "ValerieWanQi:23:57c8b4" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~ValerieWanQi", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/96.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 01:34:58", "mapbox_access_tokens": null, "has_password": null, "username": "ValerieWanQi", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:02:15.721191Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~manikkalra/22.embed", "fid": "manikkalra:22", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/manikkalra:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/manikkalra:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/manikkalra:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/manikkalra:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/manikkalra:22", "plots": "https://api.plotly.com/v2/plots/manikkalra:22", "parent": "https://api.plotly.com/v2/folders/home?user=manikkalra" }, "owner": "manikkalra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://plotly.com/~manikkalra/22/", "world_readable": true, "date_modified": "2019-06-18T03:02:16.219Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~manikkalra/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1ada022a-8cd2-46e2-8e8d-673c7a91b656", "type": "candlestick", "xsrc": "manikkalra:23:15f3de", "lowsrc": "manikkalra:23:a50f57", "highsrc": "manikkalra:23:c6ca33", "opensrc": "manikkalra:23:1ae7fd", "closesrc": "manikkalra:23:68526a" } ], "layout": { "xaxis": { "rangeslider": { "visible": false } }, "plot_bgcolor": "rgb(0,0,0)" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~manikkalra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/70.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 21:53:50", "mapbox_access_tokens": null, "has_password": null, "username": "manikkalra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-18T03:02:04.940874Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~manikkalra/20.embed", "fid": "manikkalra:20", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/manikkalra:20/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/manikkalra/20/2_45N9DIVJ25JHEP18YVY89I0T9UZAZP.png", "block-thumb": "https://api.plotly.com/v2/files/manikkalra:20/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/manikkalra:20/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/manikkalra:20", "plots": "https://api.plotly.com/v2/plots/manikkalra:20", "parent": "https://api.plotly.com/v2/folders/home?user=manikkalra" }, "owner": "manikkalra", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Volume", "views": 3, "web_url": "https://plotly.com/~manikkalra/20/volume/", "world_readable": true, "date_modified": "2019-06-18T03:02:05.408Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~manikkalra/20/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "8a57d744-5288-4e18-af2d-c4046675272d", "type": "candlestick", "xsrc": "manikkalra:21:d121ed", "lowsrc": "manikkalra:21:c86806", "highsrc": "manikkalra:21:f70ad0", "opensrc": "manikkalra:21:953fb2", "closesrc": "manikkalra:21:2edbec" }, { "uid": "63617c6d-4135-4836-8b96-52fcf57cdd85", "name": "Volume", "type": "bar", "xsrc": "manikkalra:21:d121ed", "ysrc": "manikkalra:21:b272c6", "yaxis": "y", "marker": { "colorsrc": "manikkalra:21:01efea" } } ], "layout": { "xaxis": { "rangeslider": { "visible": false } }, "plot_bgcolor": "rgb(0,0,0)" } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~manikkalra", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/70.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 21:53:50", "mapbox_access_tokens": null, "has_password": null, "username": "manikkalra", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
