Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzIzJTNBMDklM0EyNy40NjY0MTclMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzIyJTNBNTMlM0EwOC44OTY1MDAlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysyMyUzQTA2JTNBNDEuMzUzNzM2JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T23:06:41.353736Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~antonypaulson/0.embed", "fid": "antonypaulson:0", "filename": "basic histogram", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/antonypaulson:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/antonypaulson:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/antonypaulson:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/antonypaulson:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/antonypaulson:0", "plots": "https://api.plotly.com/v2/plots/antonypaulson:0", "parent": "https://api.plotly.com/v2/folders/home?user=antonypaulson" }, "owner": "antonypaulson", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~antonypaulson/0/", "world_readable": true, "date_modified": "2019-06-17T23:06:41.816Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~antonypaulson/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a8767663-4173-478c-92ae-b2b4597a1393", "type": "histogram", "xsrc": "antonypaulson:1:eb8245" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~antonypaulson", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:54:45", "mapbox_access_tokens": null, "has_password": null, "username": "antonypaulson", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T23:06:41.171878Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~abibibo/22.embed", "fid": "abibibo:22", "filename": "plot from API (4)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/abibibo:22/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/abibibo/22/2_Y65TBABF8G1IHBM462AJBHA4XY1H5O.png", "block-thumb": "https://api.plotly.com/v2/files/abibibo:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/abibibo:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/abibibo:22", "plots": "https://api.plotly.com/v2/plots/abibibo:22", "parent": "https://api.plotly.com/v2/folders/home?user=abibibo" }, "owner": "abibibo", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 5, "web_url": "https://chart-studio.plotly.com/~abibibo/22/", "world_readable": true, "date_modified": "2019-06-17T23:06:41.619Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~abibibo/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "box", "ysrc": "abibibo:23:ae634c", "jitter": 0.0, "pointpos": 0, "boxpoints": "all", "selectedpoints": [ 1, 3, 5 ] } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~abibibo", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/40.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2015-02-20 17:01:48", "mapbox_access_tokens": null, "has_password": null, "username": "abibibo", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T23:06:23.025673Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~abibibo/20.embed", "fid": "abibibo:20", "filename": "plot from API (3)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/abibibo:20/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/abibibo/20/2_DNBMIH6LG4248LGG2CP0A423IGWB3Z.png", "block-thumb": "https://api.plotly.com/v2/files/abibibo:20/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/abibibo:20/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/abibibo:20", "plots": "https://api.plotly.com/v2/plots/abibibo:20", "parent": "https://api.plotly.com/v2/folders/home?user=abibibo" }, "owner": "abibibo", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 6, "web_url": "https://chart-studio.plotly.com/~abibibo/20/", "world_readable": true, "date_modified": "2019-06-17T23:06:23.481Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~abibibo/20/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "box", "ysrc": "abibibo:21:f1ff5b", "jitter": 0.0, "pointpos": 0, "boxpoints": "all", "selectedpoints": [ 1 ] } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~abibibo", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/40.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2015-02-20 17:01:48", "mapbox_access_tokens": null, "has_password": null, "username": "abibibo", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T23:04:15.398867Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gaurav0/12.embed", "fid": "gaurav0:12", "filename": "plot from API (6)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/gaurav0:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/gaurav0:12/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/gaurav0:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/gaurav0:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gaurav0:12", "plots": "https://api.plotly.com/v2/plots/gaurav0:12", "parent": "https://api.plotly.com/v2/folders/home?user=gaurav0" }, "owner": "gaurav0", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Distribution of petal length (cm)", "views": 0, "web_url": "https://chart-studio.plotly.com/~gaurav0/12/distribution-of-petal-length-cm/", "world_readable": true, "date_modified": "2019-06-17T23:04:15.870Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gaurav0/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "aa0d6d63-247e-4c76-9bea-27fe6cf68b15", "type": "histogram", "xsrc": "gaurav0:13:a1802d" } ], "layout": { "title": { "font": { "size": 32 }, "text": "Distribution of petal length (cm)" }, "xaxis": { "title": { "font": { "size": 18 }, "text": "petal length (cm)" } }, "yaxis": { "title": { "font": { "size": 18 }, "text": "Frequency" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gaurav0", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/63.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:23:29", "mapbox_access_tokens": null, "has_password": null, "username": "gaurav0", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T23:04:00.929477Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gaurav0/10.embed", "fid": "gaurav0:10", "filename": "plot from API (5)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/gaurav0:10/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/gaurav0:10/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/gaurav0:10/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/gaurav0:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gaurav0:10", "plots": "https://api.plotly.com/v2/plots/gaurav0:10", "parent": "https://api.plotly.com/v2/folders/home?user=gaurav0" }, "owner": "gaurav0", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Distribution of petal length (cm)", "views": 0, "web_url": "https://chart-studio.plotly.com/~gaurav0/10/distribution-of-petal-length-cm/", "world_readable": true, "date_modified": "2019-06-17T23:04:01.427Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gaurav0/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "80aad4e0-95be-4e60-be2c-06ab2ddec7d4", "type": "histogram", "xsrc": "gaurav0:11:3ee28a" } ], "layout": { "title": { "font": { "size": 24 }, "text": "Distribution of petal length (cm)" }, "xaxis": { "title": { "font": { "size": 18 }, "text": "petal length (cm)" } }, "yaxis": { "title": { "font": { "size": 18 }, "text": "Frequency" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gaurav0", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/63.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:23:29", "mapbox_access_tokens": null, "has_password": null, "username": "gaurav0", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T23:00:43.957149Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~janstatystyk/1.embed", "fid": "janstatystyk:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/janstatystyk:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/janstatystyk:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/janstatystyk:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/janstatystyk:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/janstatystyk:1", "plots": "https://api.plotly.com/v2/plots/janstatystyk:1", "parent": "https://api.plotly.com/v2/folders/home?user=janstatystyk" }, "owner": "janstatystyk", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~janstatystyk/1/", "world_readable": true, "date_modified": "2019-06-17T23:00:58.781Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~janstatystyk/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "type": "scatter", "xsrc": "janstatystyk:0:69cc5d", "ysrc": "janstatystyk:0:60a8a2" } ], "frames": [], "layout": { "title": { "text": "L6 CP" }, "xaxis": { "type": "linear", "range": [ -0.25, 0.65 ], "title": { "text": "Volt" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.0001640057222222222, 0.00013492872222222222 ], "title": { "text": "Amps" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~janstatystyk", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/53.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 23:00:14", "mapbox_access_tokens": null, "has_password": null, "username": "janstatystyk", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T22:57:12.669232Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gaurav0/8.embed", "fid": "gaurav0:8", "filename": "plot from API (4)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/gaurav0:8/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/gaurav0:8/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/gaurav0:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/gaurav0:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gaurav0:8", "plots": "https://api.plotly.com/v2/plots/gaurav0:8", "parent": "https://api.plotly.com/v2/folders/home?user=gaurav0" }, "owner": "gaurav0", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Distribution of petal length (cm)", "views": 0, "web_url": "https://chart-studio.plotly.com/~gaurav0/8/distribution-of-petal-length-cm/", "world_readable": true, "date_modified": "2019-06-17T22:57:13.258Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gaurav0/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a0ca0e30-1740-4383-9a59-46d9f16a9724", "type": "histogram", "xsrc": "gaurav0:9:f6ccbf" } ], "layout": { "title": { "text": "Distribution of petal length (cm)" }, "xaxis": { "title": { "text": "petal length (cm)" } }, "yaxis": { "title": { "text": "Frequency" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gaurav0", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/63.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:23:29", "mapbox_access_tokens": null, "has_password": null, "username": "gaurav0", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T22:54:07.076397Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~xyang6/36.embed", "fid": "xyang6:36", "filename": "plot from API (16)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/xyang6:36/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/xyang6:36/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/xyang6:36/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/xyang6:36/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/xyang6:36", "plots": "https://api.plotly.com/v2/plots/xyang6:36", "parent": "https://api.plotly.com/v2/folders/home?user=xyang6" }, "owner": "xyang6", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "<br>Weekly Network", "views": 0, "web_url": "https://chart-studio.plotly.com/~xyang6/36/weekly-network/", "world_readable": true, "date_modified": "2019-06-17T22:54:07.618Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~xyang6/36/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "59e4c979-6107-40d9-acc8-fa23b8c491e3", "line": { "color": "#888", "width": 0.5 }, "mode": "lines", "type": "scatter", "xsrc": "xyang6:37:e678eb", "ysrc": "xyang6:37:b442e3", "hoverinfo": "none" }, { "uid": "b136244c-2044-4f86-a0ca-5bc7766bc4fc", "mode": "markers", "type": "scatter", "xsrc": "xyang6:37:acd3e3", "ysrc": "xyang6:37:beb7a4", "marker": { "line": { "width": 0 }, "size": 5, "colorbar": { "title": { "side": "right", "text": "Node Connections" }, "xanchor": "left", "thickness": 15 }, "colorsrc": "xyang6:37:b37804", "showscale": true, "colorscale": "Viridis", "reversescale": true }, "textsrc": "xyang6:37:ea09aa", "hoverinfo": "text" } ], "layout": { "title": { "font": { "size": 16 }, "text": "<br>Weekly Network" }, "xaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "yaxis": { "showgrid": false, "zeroline": false, "showticklabels": false }, "margin": { "b": 20, "l": 5, "r": 5, "t": 40 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~xyang6", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-01 00:40:19", "mapbox_access_tokens": null, "has_password": null, "username": "xyang6", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T22:53:22.725000Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mvanauken/0.embed", "fid": "mvanauken:0", "filename": "d3-flight-paths", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mvanauken:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/mvanauken:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/mvanauken:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/mvanauken:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mvanauken:0", "plots": "https://api.plotly.com/v2/plots/mvanauken:0", "parent": "https://api.plotly.com/v2/folders/home?user=mvanauken" }, "owner": "mvanauken", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Feb. 2011 American Airline flight paths<br>(Hover for airport names)", "views": 0, "web_url": "https://chart-studio.plotly.com/~mvanauken/0/feb-2011-american-airline-flight-paths-hover-for-airport-names/", "world_readable": true, "date_modified": "2019-06-17T22:53:23.379Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mvanauken/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "fe5bee8c-9005-4975-a3b3-4003305b579e", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:5bfafd", "lonsrc": "mvanauken:1:d0d072", "opacity": 0.48577680525164113, "locationmode": "USA-states" }, { "uid": "bd3c16d7-572a-43ba-ad87-4f8ca1d7229c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a8e627", "lonsrc": "mvanauken:1:13e6b9", "opacity": 0.18161925601750548, "locationmode": "USA-states" }, { "uid": "56dff5b2-206a-4009-92d9-8f1cce0e5459", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c062a1", "lonsrc": "mvanauken:1:977cdc", "opacity": 0.1772428884026258, "locationmode": "USA-states" }, { "uid": "8b1a7173-5084-469f-b914-9194121886a6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a9299d", "lonsrc": "mvanauken:1:9f63b9", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "b686c59b-ef70-422a-a3d6-d57b94e6d130", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c08377", "lonsrc": "mvanauken:1:62f313", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "51502aad-5e90-43cb-9a88-6a0288fb5121", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1a6558", "lonsrc": "mvanauken:1:5c60ca", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "280a42fc-9b6a-4ae9-8bfe-de755f53f158", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:6ad5ca", "lonsrc": "mvanauken:1:a80b31", "opacity": 0.4617067833698031, "locationmode": "USA-states" }, { "uid": "4236ad84-45d0-4bb8-b0b9-53ff8d91f2bc", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e4b040", "lonsrc": "mvanauken:1:71e62f", "opacity": 0.4288840262582057, "locationmode": "USA-states" }, { "uid": "aa40ae39-23cc-4f94-8a51-d651db0b417e", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d32448", "lonsrc": "mvanauken:1:1fb0db", "opacity": 0.47045951859956237, "locationmode": "USA-states" }, { "uid": "14f57272-8848-4130-8ee4-8e458a7758dd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:bf8102", "lonsrc": "mvanauken:1:8211f6", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "53a48daa-3083-4245-9475-fa2c7e53b5f4", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:3289f9", "lonsrc": "mvanauken:1:286a46", "opacity": 0.04814004376367615, "locationmode": "USA-states" }, { "uid": "e9f85e3b-7452-47ee-800e-a3880350fd4a", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:da0995", "lonsrc": "mvanauken:1:5ff068", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "5fae57ef-c927-48a9-999b-1267f1646b02", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:19e252", "lonsrc": "mvanauken:1:a9983b", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "e6b804ca-63dd-41f2-9a1d-7359f14466e2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a706e7", "lonsrc": "mvanauken:1:98facf", "opacity": 0.3938730853391685, "locationmode": "USA-states" }, { "uid": "b3da08d1-4c6a-4bdc-9de5-89b1d7bd0289", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b6885a", "lonsrc": "mvanauken:1:8968ab", "opacity": 0.3041575492341357, "locationmode": "USA-states" }, { "uid": "6590736a-8148-4603-b4e8-58a0fd8aadfb", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:6fd13a", "lonsrc": "mvanauken:1:6d1a8b", "opacity": 0.1137855579868709, "locationmode": "USA-states" }, { "uid": "f5d462ca-a6cf-4164-b8f5-1dbb3b008d3a", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:6214dd", "lonsrc": "mvanauken:1:93d034", "opacity": 0.6433260393873085, "locationmode": "USA-states" }, { "uid": "05047448-88f5-4139-8d82-e81c8646954b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a91e81", "lonsrc": "mvanauken:1:8310d8", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "46fa4355-dff1-4d15-8df6-61f3dd1520ad", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:4f02f6", "lonsrc": "mvanauken:1:577e09", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "fb31ab18-f10d-40e5-8300-523d2f4a24fd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:58d7c1", "lonsrc": "mvanauken:1:bbb17b", "opacity": 0.6345733041575492, "locationmode": "USA-states" }, { "uid": "42703783-5033-4329-8443-28ebb4bf8d6b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d75eaf", "lonsrc": "mvanauken:1:6b4b07", "opacity": 0.8971553610503282, "locationmode": "USA-states" }, { "uid": "1a8a5a25-f614-4cdd-ad70-bc4a5759c4cd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:5ea0b1", "lonsrc": "mvanauken:1:800c34", "opacity": 0.47702407002188185, "locationmode": "USA-states" }, { "uid": "5ee33d7b-3bd6-4c7b-aee1-b337a35dddab", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ce49f5", "lonsrc": "mvanauken:1:93bdb6", "opacity": 0.2275711159737418, "locationmode": "USA-states" }, { "uid": "0bde6261-e137-4bbe-b88d-6f7a9b24f3c2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:43b66a", "lonsrc": "mvanauken:1:b90bbc", "opacity": 0.35667396061269147, "locationmode": "USA-states" }, { "uid": "f738af0a-86af-40c9-8a66-fc9e3a98aec7", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:76691e", "lonsrc": "mvanauken:1:2fd64f", "opacity": 0.1137855579868709, "locationmode": "USA-states" }, { "uid": "2da0c34f-4264-44ce-8a12-f3640f2ce88c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a10fa4", "lonsrc": "mvanauken:1:e9bde7", "opacity": 0.6105032822757112, "locationmode": "USA-states" }, { "uid": "d0afb768-6d27-4154-a81c-6bccf5b3e942", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:0f41f5", "lonsrc": "mvanauken:1:76bdf6", "opacity": 0.2844638949671772, "locationmode": "USA-states" }, { "uid": "96b4354c-7c13-4a06-baf4-6df022ca2f8c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:2fef76", "lonsrc": "mvanauken:1:adbd67", "opacity": 0.1487964989059081, "locationmode": "USA-states" }, { "uid": "57bab0ab-fcd7-46c2-b069-17d84e287421", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b6bba9", "lonsrc": "mvanauken:1:bb864b", "opacity": 0.33916849015317285, "locationmode": "USA-states" }, { "uid": "5f75bca6-2c21-4c21-b7fc-f4515f4a4f77", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:786c79", "lonsrc": "mvanauken:1:7f4b2d", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "2cc8e9bc-1b65-4b7b-b6a9-4d9d0c11c70c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b59607", "lonsrc": "mvanauken:1:2f6f02", "opacity": 0.3676148796498906, "locationmode": "USA-states" }, { "uid": "9815e99f-c673-476a-9919-33565137e8b4", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:4aaf63", "lonsrc": "mvanauken:1:58b553", "opacity": 0.17286652078774617, "locationmode": "USA-states" }, { "uid": "7607e468-6ff0-42bb-857b-a4073e965f76", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ff34ed", "lonsrc": "mvanauken:1:701b58", "opacity": 0.3544857768052516, "locationmode": "USA-states" }, { "uid": "26cd1ff1-c6d1-49c8-a661-2adfcede38e4", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:0366ef", "lonsrc": "mvanauken:1:ae7073", "opacity": 1.0, "locationmode": "USA-states" }, { "uid": "eb52615e-313c-43b8-8db1-811f21b3bb64", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:24310f", "lonsrc": "mvanauken:1:809d08", "opacity": 0.47702407002188185, "locationmode": "USA-states" }, { "uid": "2abac24b-0823-41eb-aa4a-ae7dd64b1fdc", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e7622c", "lonsrc": "mvanauken:1:e3ca8f", "opacity": 0.5470459518599562, "locationmode": "USA-states" }, { "uid": "f83d4a2a-e7eb-49c8-90fe-06c926915547", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e2ee54", "lonsrc": "mvanauken:1:d0bd5f", "opacity": 0.23413566739606126, "locationmode": "USA-states" }, { "uid": "2c66bdb7-27eb-45f2-a15c-f40c691ee30b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:68bf9b", "lonsrc": "mvanauken:1:cd8360", "opacity": 0.23413566739606126, "locationmode": "USA-states" }, { "uid": "4c525832-0d6d-4153-ad74-aa185c302f5c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:50ee4c", "lonsrc": "mvanauken:1:c7581d", "opacity": 0.612691466083151, "locationmode": "USA-states" }, { "uid": "3e5fa13d-a649-4b24-b81c-63c41dca11bd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:70633c", "lonsrc": "mvanauken:1:87158b", "opacity": 0.35667396061269147, "locationmode": "USA-states" }, { "uid": "2bd12bfe-c2df-4143-bb04-c7e352daa56e", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9939d8", "lonsrc": "mvanauken:1:1a36b5", "opacity": 0.0175054704595186, "locationmode": "USA-states" }, { "uid": "af1b1875-13ee-418a-a17d-ebacf4c261d4", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d0d52a", "lonsrc": "mvanauken:1:c09aa8", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "ef007c90-bd55-421c-842c-2951d4723990", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:76a72b", "lonsrc": "mvanauken:1:708864", "opacity": 0.42669584245076586, "locationmode": "USA-states" }, { "uid": "6c872405-a278-4608-8c95-87686c6b36a2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:834325", "lonsrc": "mvanauken:1:e25544", "opacity": 0.2975929978118162, "locationmode": "USA-states" }, { "uid": "c8e85b04-67ca-4352-8228-90a883cd3147", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:62c80b", "lonsrc": "mvanauken:1:368040", "opacity": 0.9026258205689278, "locationmode": "USA-states" }, { "uid": "cf8fa22f-8971-461b-b27f-494eb3b5d533", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:6ab375", "lonsrc": "mvanauken:1:c7c922", "opacity": 0.3522975929978118, "locationmode": "USA-states" }, { "uid": "409e4e4a-3c4c-4a64-843c-ed8f3a4d6604", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:636a28", "lonsrc": "mvanauken:1:01f41e", "opacity": 0.6017505470459519, "locationmode": "USA-states" }, { "uid": "bdc9634d-3a3b-4f27-8abf-f080d7a3a69b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:81465d", "lonsrc": "mvanauken:1:ccf552", "opacity": 0.18161925601750548, "locationmode": "USA-states" }, { "uid": "a4386a18-4abd-49bf-9121-ef99626aa4f5", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a5b439", "lonsrc": "mvanauken:1:ac805d", "opacity": 0.16411378555798686, "locationmode": "USA-states" }, { "uid": "2b525ebf-1c17-4d4f-a5e4-cfdf309134a7", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e3a1c3", "lonsrc": "mvanauken:1:c90217", "opacity": 0.5470459518599562, "locationmode": "USA-states" }, { "uid": "1f266e7d-d65e-4006-bef8-e215397db040", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d635a8", "lonsrc": "mvanauken:1:d295c3", "opacity": 0.9037199124726477, "locationmode": "USA-states" }, { "uid": "029a2ca3-8308-489a-9fa8-e780a515cc63", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d10bde", "lonsrc": "mvanauken:1:db6657", "opacity": 0.17943107221006566, "locationmode": "USA-states" }, { "uid": "265ab9c9-f9e0-4505-917d-8160e5694888", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:637ca1", "lonsrc": "mvanauken:1:307bc9", "opacity": 0.5754923413566739, "locationmode": "USA-states" }, { "uid": "8529734a-dc2b-4a71-a7f1-f5f977bb2cbd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c87a0b", "lonsrc": "mvanauken:1:80645f", "opacity": 0.3479212253829322, "locationmode": "USA-states" }, { "uid": "333d26a7-8447-4639-a4fd-c2874241e6ff", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:030d76", "lonsrc": "mvanauken:1:be0686", "opacity": 0.3063457330415755, "locationmode": "USA-states" }, { "uid": "d3fc7a95-74bd-4c25-8d85-21aae338ac83", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ad7a25", "lonsrc": "mvanauken:1:14d579", "opacity": 0.5317286652078774, "locationmode": "USA-states" }, { "uid": "99934818-977a-461d-9872-e1c5c60dbe45", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:74ac9a", "lonsrc": "mvanauken:1:bd7530", "opacity": 0.05470459518599562, "locationmode": "USA-states" }, { "uid": "01a239f1-357b-454a-affe-ebdd6e8f0a61", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:595c03", "lonsrc": "mvanauken:1:2e3c7a", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "d70486c0-df79-4f3e-8112-8d9245dcd2a3", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:48c076", "lonsrc": "mvanauken:1:de88d3", "opacity": 0.0087527352297593, "locationmode": "USA-states" }, { "uid": "bf1bef01-52c8-4fa3-983d-648300f657d2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:57aff6", "lonsrc": "mvanauken:1:98fbdf", "opacity": 0.0700218818380744, "locationmode": "USA-states" }, { "uid": "0e35eb59-8959-4f02-a769-6f5bcfba9a23", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:de50d3", "lonsrc": "mvanauken:1:7f4501", "opacity": 0.474835886214442, "locationmode": "USA-states" }, { "uid": "61aa773f-b6a8-44cd-8e91-d536f6058468", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9e1f0f", "lonsrc": "mvanauken:1:ee9b96", "opacity": 0.05908096280087528, "locationmode": "USA-states" }, { "uid": "3956011e-a00e-426b-86e7-1f7ef295753c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ce46db", "lonsrc": "mvanauken:1:8fa40e", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "df72e685-122d-412b-b729-149fccfaf952", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:084b5c", "lonsrc": "mvanauken:1:58b35f", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "63b7af26-e36f-4767-91bf-a4f7f921687f", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:976b99", "lonsrc": "mvanauken:1:bcc6e9", "opacity": 0.0700218818380744, "locationmode": "USA-states" }, { "uid": "5297d652-616d-4d73-acf3-791c1e4e9b9f", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e8239e", "lonsrc": "mvanauken:1:0227aa", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "963034d9-e03d-4d52-81b5-21b725b5cadb", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:72e691", "lonsrc": "mvanauken:1:f086ec", "opacity": 0.2363238512035011, "locationmode": "USA-states" }, { "uid": "eedb1d59-b9f6-43ab-92c6-a8b753053c3d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:f8d51a", "lonsrc": "mvanauken:1:74ec86", "opacity": 0.33698030634573306, "locationmode": "USA-states" }, { "uid": "ba9fed30-6842-4988-921e-6695d5294833", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c9a51e", "lonsrc": "mvanauken:1:701b05", "opacity": 0.18161925601750548, "locationmode": "USA-states" }, { "uid": "50ac6e4c-cb16-4309-befe-eace62c4f218", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:8eabc7", "lonsrc": "mvanauken:1:c19cd2", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "30629dc0-bc36-479d-bc37-85e9b07eefe6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a5cd10", "lonsrc": "mvanauken:1:029042", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "61cf1858-4242-4835-a9dc-7c228b596294", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:7cca2d", "lonsrc": "mvanauken:1:1ab62f", "opacity": 0.23413566739606126, "locationmode": "USA-states" }, { "uid": "b44834e3-7e43-48e2-8ee2-865fa24861ca", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b397d5", "lonsrc": "mvanauken:1:fd3c59", "opacity": 0.3041575492341357, "locationmode": "USA-states" }, { "uid": "9ab5ac61-c121-43c3-a79b-c2c266dc7985", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fd8fa5", "lonsrc": "mvanauken:1:133dee", "opacity": 0.0262582056892779, "locationmode": "USA-states" }, { "uid": "0593fe00-fa7c-4bae-a670-7607002194dd", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:004405", "lonsrc": "mvanauken:1:724690", "opacity": 0.2363238512035011, "locationmode": "USA-states" }, { "uid": "24ba4509-1c01-4596-90fc-d06841279cda", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:349000", "lonsrc": "mvanauken:1:f4c04b", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "4df6e9af-3479-4962-a6ad-e162ca6fd598", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c4d770", "lonsrc": "mvanauken:1:bd7ba9", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "9931a4c2-f4e6-4a15-9e9e-69196370f409", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:0f282b", "lonsrc": "mvanauken:1:74e428", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "9b3cb6e9-6c6c-48b4-abca-633cfa745e01", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:56586e", "lonsrc": "mvanauken:1:dd2f47", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "a34bab26-2db7-401c-9d6e-5d7655fd0a43", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:7e4b23", "lonsrc": "mvanauken:1:82130f", "opacity": 0.4288840262582057, "locationmode": "USA-states" }, { "uid": "b66c80ac-bba4-4ec6-9198-fe4f12f1bad6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c7e65d", "lonsrc": "mvanauken:1:a1da2d", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "9ed18beb-388b-4375-bd8c-3f7dec9e923d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fd5e81", "lonsrc": "mvanauken:1:87b0ef", "opacity": 0.3041575492341357, "locationmode": "USA-states" }, { "uid": "f9ffd8b8-08a8-47e5-87c7-52571d6c5b8e", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9d52c1", "lonsrc": "mvanauken:1:bb7f56", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "c8b4bdcc-17e0-4a25-9774-686233c94120", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:21b13f", "lonsrc": "mvanauken:1:46252e", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "a1c2a375-fe6f-4bc9-9842-c703f79f0964", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d01978", "lonsrc": "mvanauken:1:a7a525", "opacity": 0.6225382932166302, "locationmode": "USA-states" }, { "uid": "88a88744-58ff-4873-8adf-6693ab5daada", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:da2d7a", "lonsrc": "mvanauken:1:601c41", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "27325a82-3243-405a-8ef8-16011dafdf32", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fced04", "lonsrc": "mvanauken:1:76d715", "opacity": 0.24288840262582057, "locationmode": "USA-states" }, { "uid": "936cfff4-0bdd-4f28-8099-edfb0cdedb6f", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:36772a", "lonsrc": "mvanauken:1:8ac3fa", "opacity": 0.3063457330415755, "locationmode": "USA-states" }, { "uid": "c23c2f15-22f8-4789-ad33-e495b07e44ec", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1e41d5", "lonsrc": "mvanauken:1:b59d93", "opacity": 0.1772428884026258, "locationmode": "USA-states" }, { "uid": "11a0ab3f-6de0-47d9-8118-6e43546e8c1b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9217e4", "lonsrc": "mvanauken:1:f544d7", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "b1a02b3c-ce16-478b-b37e-ee4db71f070b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:61194d", "lonsrc": "mvanauken:1:f325f6", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "8e8c0c09-61d5-4ad1-a14e-55ea2046021b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:28db53", "lonsrc": "mvanauken:1:7a275a", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "1b4ae934-dc65-438f-9d8d-476e22e2f43d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:4d20d3", "lonsrc": "mvanauken:1:2dcd41", "opacity": 0.5995623632385121, "locationmode": "USA-states" }, { "uid": "c2c95ab2-0d2f-4c74-8fd8-67726f4ac10f", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e7cbec", "lonsrc": "mvanauken:1:0f5e82", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "77d0bd63-822f-4bff-83c7-26ef8c33b8fc", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1d280b", "lonsrc": "mvanauken:1:51c0ba", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "5df109ef-8db9-478e-b1e3-f441f82ef2ac", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:c8c3d9", "lonsrc": "mvanauken:1:2d25c5", "opacity": 0.5426695842450766, "locationmode": "USA-states" }, { "uid": "38736666-bddd-4662-b9a7-9815455cdc7b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:577c0e", "lonsrc": "mvanauken:1:e520e9", "opacity": 0.18161925601750548, "locationmode": "USA-states" }, { "uid": "8576aa2f-27e6-4822-a231-3777d74a8234", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b234e2", "lonsrc": "mvanauken:1:21abed", "opacity": 0.11159737417943107, "locationmode": "USA-states" }, { "uid": "e0d42e3e-685f-41f9-87c7-bac7cce96641", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:bd812c", "lonsrc": "mvanauken:1:efa8fc", "opacity": 0.849015317286652, "locationmode": "USA-states" }, { "uid": "cffeefa4-d35c-409c-a642-8a0812973997", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:207003", "lonsrc": "mvanauken:1:1d9725", "opacity": 0.22538293216630198, "locationmode": "USA-states" }, { "uid": "1f4d1a63-f737-4b0e-96a5-a5b4fe1b4826", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fd034c", "lonsrc": "mvanauken:1:b76f40", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "150d8da2-7975-4481-9b1e-3e2a47900de0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:f817b1", "lonsrc": "mvanauken:1:3f6c72", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "1c24838a-847a-4837-b667-07864cb371a9", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:87bdde", "lonsrc": "mvanauken:1:ac5b45", "opacity": 0.49015317286652077, "locationmode": "USA-states" }, { "uid": "1c45c47e-3701-4fe5-a9f9-10a8234f67a0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:2c69f5", "lonsrc": "mvanauken:1:5b8331", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "c910302a-8719-453f-860c-fb71af312bf0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:165446", "lonsrc": "mvanauken:1:a885cd", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "7b55aaf6-3fdd-4bbd-92da-9dfd287e5635", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:748105", "lonsrc": "mvanauken:1:c16b37", "opacity": 0.5514223194748359, "locationmode": "USA-states" }, { "uid": "2657d221-b54b-4fb8-be7c-0536cd3b2956", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:56a74d", "lonsrc": "mvanauken:1:05a419", "opacity": 0.0525164113785558, "locationmode": "USA-states" }, { "uid": "025a5b97-2824-4e24-813b-853630d1e041", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:0cfcd9", "lonsrc": "mvanauken:1:58e50f", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "ae510f44-0796-4884-a0f3-529920793455", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a7ca36", "lonsrc": "mvanauken:1:8b65ef", "opacity": 0.4288840262582057, "locationmode": "USA-states" }, { "uid": "2c5cc46a-14bc-4624-bdc6-afbce48ee846", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:437ebd", "lonsrc": "mvanauken:1:856be7", "opacity": 0.6728665207877462, "locationmode": "USA-states" }, { "uid": "afed24f9-7b8c-4296-9ca0-376b658bd4ed", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:09b72a", "lonsrc": "mvanauken:1:2bd5ed", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "bfe39946-45b6-4108-9635-1cb9712739cb", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1d9172", "lonsrc": "mvanauken:1:7dede3", "opacity": 0.5525164113785558, "locationmode": "USA-states" }, { "uid": "d477df03-2b65-4f9d-9615-b5b4251d327d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d3b6f6", "lonsrc": "mvanauken:1:65e1c7", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "0ca606bc-5bbb-4178-8512-83dd43b81361", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:771c76", "lonsrc": "mvanauken:1:c62b6a", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "b15b2912-da98-4b33-953c-4f03f7702772", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:8b5c4d", "lonsrc": "mvanauken:1:4d5c72", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "44888ee5-d550-43e7-90f6-c2222832c165", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:5feedf", "lonsrc": "mvanauken:1:3c5f57", "opacity": 0.49015317286652077, "locationmode": "USA-states" }, { "uid": "d6d05751-db35-438f-9489-ccdaeab6758c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:7e6b22", "lonsrc": "mvanauken:1:950eb3", "opacity": 0.00437636761487965, "locationmode": "USA-states" }, { "uid": "91667611-49dd-48f4-a3f8-47ee7fad879e", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:3f9782", "lonsrc": "mvanauken:1:d7bb7b", "opacity": 0.175054704595186, "locationmode": "USA-states" }, { "uid": "e07cfa38-31ed-497e-9928-bbb0c2978c1b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:f20c6a", "lonsrc": "mvanauken:1:6b8fd6", "opacity": 0.3676148796498906, "locationmode": "USA-states" }, { "uid": "48faa8da-d0c2-4c8f-a6b8-ebba1ade518d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:08a642", "lonsrc": "mvanauken:1:1dad6e", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "5417ca34-2f3b-433d-9faf-306a28b6d8d4", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e797f9", "lonsrc": "mvanauken:1:edf127", "opacity": 0.16301969365426697, "locationmode": "USA-states" }, { "uid": "73ed5366-90fb-4e7f-9d73-2dfe0dec91fb", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:aa3b3b", "lonsrc": "mvanauken:1:d30576", "opacity": 0.24288840262582057, "locationmode": "USA-states" }, { "uid": "368e958d-05dd-4428-baab-fc5f91465c80", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:5e8d5c", "lonsrc": "mvanauken:1:80be07", "opacity": 0.3544857768052516, "locationmode": "USA-states" }, { "uid": "2257ba85-a44b-42e6-98a2-84324c4f10e5", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1f3537", "lonsrc": "mvanauken:1:35f9f6", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "13ad7822-0790-4688-be40-b70ad1eb704a", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:80b2f2", "lonsrc": "mvanauken:1:badb80", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "224fb700-7ae7-4c87-8a43-fdffb1611573", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:70942c", "lonsrc": "mvanauken:1:1418e1", "opacity": 0.0525164113785558, "locationmode": "USA-states" }, { "uid": "8375d291-b704-43de-89a4-f2c4298b0398", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b0143a", "lonsrc": "mvanauken:1:d5537d", "opacity": 0.05032822757111598, "locationmode": "USA-states" }, { "uid": "4597e7e2-3667-450b-be02-3be620974c37", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:45c29b", "lonsrc": "mvanauken:1:6f9faa", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "f1131813-ddea-4401-a043-039e13157a1d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a0fe2a", "lonsrc": "mvanauken:1:ac1b27", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "dfdcff1c-445f-422b-8a9e-cf8311207ea5", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:92b1ab", "lonsrc": "mvanauken:1:37dee9", "opacity": 0.9409190371991247, "locationmode": "USA-states" }, { "uid": "0f5d945d-222d-4bbc-86ba-04412ab54095", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e620fb", "lonsrc": "mvanauken:1:2a8d5f", "opacity": 0.23413566739606126, "locationmode": "USA-states" }, { "uid": "6fd8ec97-51a4-4c20-ac2f-d72bf0526616", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fb060b", "lonsrc": "mvanauken:1:0b3e16", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "82c9dbaa-9912-4c83-ad12-827b3ed3e047", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:2524ee", "lonsrc": "mvanauken:1:1cfb41", "opacity": 0.17067833698030635, "locationmode": "USA-states" }, { "uid": "c49d69cd-8009-435e-9f8c-f788e0e33b4a", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:dc833a", "lonsrc": "mvanauken:1:25c9ed", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "564f43b3-729a-4f9d-89b5-7a77abf5c8b2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:871f03", "lonsrc": "mvanauken:1:9afda1", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "aeea68ab-ad64-4ee6-9e60-c0907842a7b0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:405c12", "lonsrc": "mvanauken:1:0668dc", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "3641bbfa-5bf1-452a-ad0b-3ef271e80aca", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:da37e3", "lonsrc": "mvanauken:1:c6e45d", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "001b67a0-c6e2-4498-81cb-d38ec7d3d526", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:adfef7", "lonsrc": "mvanauken:1:103e88", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "07221348-c3af-4128-a2a2-98f59e595ef0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:56af7f", "lonsrc": "mvanauken:1:4f1a8b", "opacity": 0.5284463894967177, "locationmode": "USA-states" }, { "uid": "d81307b7-8cd1-4c23-bb51-4a69c0026619", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:2eec6a", "lonsrc": "mvanauken:1:22d72a", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "f4918122-cc6d-44b2-88c0-238b368534c6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ddbac2", "lonsrc": "mvanauken:1:31cb33", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "0984b3a1-f67d-4c3c-8702-62dbd77c4419", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:4dd9af", "lonsrc": "mvanauken:1:86b4a2", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "d8f399a9-8519-4448-bf1a-fcda8055a775", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:39ffba", "lonsrc": "mvanauken:1:fb09d5", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "cf461b88-fa0c-4d01-a89c-b0b818f35441", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:abcea0", "lonsrc": "mvanauken:1:e0068c", "opacity": 0.16411378555798686, "locationmode": "USA-states" }, { "uid": "1ac0830d-d04e-4b82-8df6-4b688e45fc35", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:38229b", "lonsrc": "mvanauken:1:3815f4", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "51ca2f46-7d5c-4145-b969-5a03cc72e494", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:1cd807", "lonsrc": "mvanauken:1:cc7b49", "opacity": 0.12035010940919037, "locationmode": "USA-states" }, { "uid": "bbe15bb1-5cc8-4e30-be38-a7688a8da0ab", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:6622a5", "lonsrc": "mvanauken:1:dac1f7", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "07f8a048-4d59-4041-8b47-0108e4dae0fa", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:2f4aa0", "lonsrc": "mvanauken:1:f5a151", "opacity": 0.3063457330415755, "locationmode": "USA-states" }, { "uid": "0e45ce94-054a-4e1a-8fea-a8dc268f790b", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:bf2db7", "lonsrc": "mvanauken:1:1bc58f", "opacity": 0.18599562363238512, "locationmode": "USA-states" }, { "uid": "4578dfa2-200f-4d3d-90ff-c4b542018283", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:32d797", "lonsrc": "mvanauken:1:9f91af", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "79895e51-928d-4902-94c8-8210d880f7d6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e05487", "lonsrc": "mvanauken:1:099ea2", "opacity": 0.0700218818380744, "locationmode": "USA-states" }, { "uid": "4c0ede0a-056c-4ea4-9e29-b843dde84dda", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:55cb22", "lonsrc": "mvanauken:1:f26a73", "opacity": 0.3041575492341357, "locationmode": "USA-states" }, { "uid": "b943c996-7686-4491-b248-cd42df75b1f5", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:cd3613", "lonsrc": "mvanauken:1:27b1e6", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "f3fa8137-b019-4d4f-bdc4-b7f62d4dd225", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:38d64f", "lonsrc": "mvanauken:1:aef78a", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "d45442fa-79b1-4dcd-b381-1286ab420351", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:42a628", "lonsrc": "mvanauken:1:27de0c", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "149ff025-93c2-4d1a-b57e-6f07b6bc5480", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:74c82c", "lonsrc": "mvanauken:1:24de1e", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "03a95a96-5d26-429d-86b9-383b68d959ac", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:890257", "lonsrc": "mvanauken:1:849edb", "opacity": 0.4288840262582057, "locationmode": "USA-states" }, { "uid": "895aea65-89a1-49f1-a137-a0785f8d3232", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:947957", "lonsrc": "mvanauken:1:08b6d9", "opacity": 0.23413566739606126, "locationmode": "USA-states" }, { "uid": "e097be46-6f31-4faa-88b2-80d1e9d6bf8d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fa6da5", "lonsrc": "mvanauken:1:d357fc", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "98b5fcca-4ecc-4dc0-8fbd-811d35be8da1", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:85145f", "lonsrc": "mvanauken:1:dc8142", "opacity": 0.3676148796498906, "locationmode": "USA-states" }, { "uid": "f1ddbd97-2881-4617-b8d5-7fba83c796a3", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:16645c", "lonsrc": "mvanauken:1:73cb14", "opacity": 0.35667396061269147, "locationmode": "USA-states" }, { "uid": "5f0068ff-cb76-4e4b-9080-bc5721957739", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:ec5d8d", "lonsrc": "mvanauken:1:13fd2f", "opacity": 0.13129102844638948, "locationmode": "USA-states" }, { "uid": "673a5840-3512-4beb-b41d-e7d7c4587ead", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:a73165", "lonsrc": "mvanauken:1:2b45b3", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "ecd017af-2faa-47e4-bdfd-caf8cc137055", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d000ea", "lonsrc": "mvanauken:1:9f092b", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "6c5e4e01-b129-491c-88c7-c5fa8caa30aa", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:5a6758", "lonsrc": "mvanauken:1:03a72d", "opacity": 0.0175054704595186, "locationmode": "USA-states" }, { "uid": "f94ea878-356d-49fe-b11d-b8d2b59d81b6", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:59ec06", "lonsrc": "mvanauken:1:10e217", "opacity": 0.24507658643326038, "locationmode": "USA-states" }, { "uid": "f856d115-5b3c-4a55-a3d6-02db7364e660", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d95d88", "lonsrc": "mvanauken:1:e98de4", "opacity": 0.6323851203501094, "locationmode": "USA-states" }, { "uid": "550f2438-6f6b-4042-ba99-2b9ade1da3c3", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:0b2d3f", "lonsrc": "mvanauken:1:f96f6d", "opacity": 0.16630196936542668, "locationmode": "USA-states" }, { "uid": "899daea1-8634-4883-a6f1-0c4a9819a76d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:e24bc4", "lonsrc": "mvanauken:1:609637", "opacity": 0.2188183807439825, "locationmode": "USA-states" }, { "uid": "8fe24a0d-a840-4ed0-a2be-369cda6c5aa0", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9ae2b5", "lonsrc": "mvanauken:1:bd7562", "opacity": 0.1838074398249453, "locationmode": "USA-states" }, { "uid": "8e1e1f2c-c16a-4e8e-8aac-c2502e9077f2", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:60a308", "lonsrc": "mvanauken:1:89ce01", "opacity": 0.12253829321663019, "locationmode": "USA-states" }, { "uid": "42bb2aca-b3e5-4840-8b63-c3a9df2c04c5", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:d249f5", "lonsrc": "mvanauken:1:ef0902", "opacity": 0.06783369803063458, "locationmode": "USA-states" }, { "uid": "f8a4fafc-353e-4947-811e-d958a6b3257c", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:bfd366", "lonsrc": "mvanauken:1:739ece", "opacity": 0.4288840262582057, "locationmode": "USA-states" }, { "uid": "17770973-95f0-4720-83df-36b92c030b4a", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:86ee6a", "lonsrc": "mvanauken:1:c16a9e", "opacity": 0.32603938730853393, "locationmode": "USA-states" }, { "uid": "1f17a581-f5a4-4445-bac4-383ecc6d523d", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:10239e", "lonsrc": "mvanauken:1:aca9a0", "opacity": 0.16411378555798686, "locationmode": "USA-states" }, { "uid": "739e478f-d25b-43b3-bb92-8f4f5a084d03", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:b6eb6e", "lonsrc": "mvanauken:1:e7b844", "opacity": 0.061269146608315096, "locationmode": "USA-states" }, { "uid": "dc978e7e-6108-4f1b-a0c3-bb7376186d91", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:fa7088", "lonsrc": "mvanauken:1:52d506", "opacity": 0.42669584245076586, "locationmode": "USA-states" }, { "uid": "7548aa7f-7b22-4790-9049-a13fda1dc340", "line": { "color": "red", "width": 1 }, "mode": "lines", "type": "scattergeo", "latsrc": "mvanauken:1:9c1062", "lonsrc": "mvanauken:1:04c014", "opacity": 0.45842450765864334, "locationmode": "USA-states" }, { "uid": "8d86f421-b02d-444b-a4d6-3c671c2da6d8", "mode": "markers", "type": "scattergeo", "latsrc": "mvanauken:1:8e92c6", "lonsrc": "mvanauken:1:d1d3dd", "marker": { "line": { "color": "rgba(68, 68, 68, 0)", "width": 3 }, "size": 2, "color": "rgb(255, 0, 0)" }, "textsrc": "mvanauken:1:22ab5e", "hoverinfo": "text", "locationmode": "USA-states" } ], "layout": { "geo": { "scope": "north america", "showland": true, "landcolor": "rgb(243, 243, 243)", "projection": { "type": "azimuthal equal area" }, "countrycolor": "rgb(204, 204, 204)" }, "title": { "text": "Feb. 2011 American Airline flight paths<br>(Hover for airport names)" }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mvanauken", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/33.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:39:52", "mapbox_access_tokens": null, "has_password": null, "username": "mvanauken", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T22:53:08.896500Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~esmaksimov/0.embed", "fid": "esmaksimov:0", "filename": "basic-bar", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/esmaksimov:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/esmaksimov:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/esmaksimov:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/esmaksimov:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/esmaksimov:0", "plots": "https://api.plotly.com/v2/plots/esmaksimov:0", "parent": "https://api.plotly.com/v2/folders/home?user=esmaksimov" }, "owner": "esmaksimov", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 25, "web_url": "https://chart-studio.plotly.com/~esmaksimov/0/", "world_readable": true, "date_modified": "2019-06-18T00:41:28.705Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~esmaksimov/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "fbb3a707-e0dc-44f0-af04-03ca94d3fcfc", "type": "bar", "xsrc": "esmaksimov:1:226b8c", "ysrc": "esmaksimov:1:781e65", "textsrc": "esmaksimov:1:7eb52e", "textposition": "auto" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~esmaksimov", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 22:50:34", "mapbox_access_tokens": null, "has_password": null, "username": "esmaksimov", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
