Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzIxJTNBMDUlM0E0NC43NTk1MTMlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzIwJTNBNTclM0EyNS40ODAzNzIlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysyMSUzQTA1JTNBMDkuMzI1MjI3JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T21:05:09.325227Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aplukis/12.embed", "fid": "aplukis:12", "filename": "Male by Level", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aplukis:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aplukis:12/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aplukis/12/8_LZTL9WR9UGG0CBN90Q8GNPHIBZFV2K.png", "list-thumb": "https://api.plotly.com/v2/files/aplukis:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aplukis:12", "plots": "https://api.plotly.com/v2/plots/aplukis:12", "parent": "https://api.plotly.com/v2/folders/home?user=aplukis" }, "owner": "aplukis", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Course Evaluations Means by Level: Male", "views": 0, "web_url": "https://chart-studio.plotly.com/~aplukis/12/course-evaluations-means-by-level-male/", "world_readable": true, "date_modified": "2019-06-17T21:05:10.595Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aplukis/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c534c7e0-127c-4880-a3a2-b12879c7e7d3", "name": "Level 100", "type": "bar", "xsrc": "aplukis:13:828d57", "ysrc": "aplukis:13:f352a3", "marker": { "color": "rgb(233,117,90)" } }, { "uid": "7078b747-8f59-4f28-8b77-8deddcfafa0c", "name": "Level 200", "type": "bar", "xsrc": "aplukis:13:828d57", "ysrc": "aplukis:13:d63c07", "marker": { "color": "rgb(72,139,165)" } }, { "uid": "3c86ea8d-c72c-4430-9cc8-214e484fee3f", "name": "Level 300", "type": "bar", "xsrc": "aplukis:13:828d57", "ysrc": "aplukis:13:6b39d4", "marker": { "color": "rgb(204,180,0)" } }, { "uid": "7d8670e1-5aab-4089-abdc-daea6ea7a08c", "name": "Level 400", "type": "bar", "xsrc": "aplukis:13:828d57", "ysrc": "aplukis:13:9929a7", "marker": { "color": "rgb(143,176,140)" } } ], "layout": { "title": { "text": "Course Evaluations Means by Level: Male" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aplukis", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/58.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 20:30:43", "mapbox_access_tokens": null, "has_password": null, "username": "aplukis", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:03:56.014498Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67152.embed", "fid": "amper:67152", "filename": "06-15-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67152/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67152/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67152/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67152/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67152", "plots": "https://api.plotly.com/v2/plots/amper:67152", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-15-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67152/_06-15-19-ds-1976-alg-5421-param-1407-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T21:03:56.908Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67152/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "6a9759eb-7de1-4a6a-b81c-aaf3c642c8cb", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67153:76b3f8", "ysrc": "amper:67153:9f0962", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false } ], "layout": { "title": "06-15-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:03:08.734780Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67150.embed", "fid": "amper:67150", "filename": "06-14-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67150/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67150/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67150/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67150/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67150", "plots": "https://api.plotly.com/v2/plots/amper:67150", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-14-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67150/_06-14-19-ds-1976-alg-5421-param-1407-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T21:03:10.364Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67150/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "cbe0649c-540d-417e-8670-64fb54d7b6f5", "mode": "lines", "name": "Off", "type": "scattergl", "xsrc": "amper:67151:99c8f8", "ysrc": "amper:67151:86de6f", "marker": { "line": { "color": "rgb(248, 19, 0)", "width": 1 }, "size": 1, "color": "rgb(248, 19, 0)" } }, { "uid": "087bfb0c-f24f-434d-afb6-414d8a42922a", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67151:99c8f8", "ysrc": "amper:67151:77f096", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "a62e06a7-1ab2-4209-93d6-660355cbfa0c", "mode": "lines", "name": "Other", "type": "scattergl", "xsrc": "amper:67151:99c8f8", "ysrc": "amper:67151:0132f2", "marker": { "line": { "color": "rgb(169,169,169)", "width": 1 }, "size": 1, "color": "rgb(169,169,169)" } } ], "layout": { "title": "06-14-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:01:21.774686Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~asiren/0.embed", "fid": "asiren:0", "filename": "pyguide_1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/asiren:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/asiren:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/asiren/0/8_H3YU4GYB3FK4M0LII54B8PHZHRHDIO.png", "list-thumb": "https://api.plotly.com/v2/files/asiren:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/asiren:0", "plots": "https://api.plotly.com/v2/plots/asiren:0", "parent": "https://api.plotly.com/v2/folders/home?user=asiren" }, "owner": "asiren", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "feature importance", "views": 0, "web_url": "https://chart-studio.plotly.com/~asiren/0/feature-importance/", "world_readable": true, "date_modified": "2019-06-17T21:01:22.240Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~asiren/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "6ef3b3a8-695e-4db1-9049-ec93ecd4d67b", "type": "bar", "xsrc": "asiren:1:71b039", "ysrc": "asiren:1:9dd636", "textsrc": "asiren:1:eadfd0", "textposition": "auto" } ], "layout": { "title": { "text": "feature importance" }, "xaxis": { "automargin": true }, "yaxis": { "title": { "text": "importance score" } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~asiren", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/35.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 21:00:01", "mapbox_access_tokens": null, "has_password": null, "username": "asiren", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:00:59.737195Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67148.embed", "fid": "amper:67148", "filename": "06-12-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67148/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67148/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67148/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67148/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67148", "plots": "https://api.plotly.com/v2/plots/amper:67148", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-12-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67148/_06-12-19-ds-1976-alg-5421-param-1407-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T21:01:00.967Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67148/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "5a94067b-46f5-4cfe-babf-0aabb6662350", "mode": "lines", "name": "Off", "type": "scattergl", "xsrc": "amper:67149:a87365", "ysrc": "amper:67149:029916", "marker": { "line": { "color": "rgb(248, 19, 0)", "width": 1 }, "size": 1, "color": "rgb(248, 19, 0)" } }, { "uid": "66e5677f-cdc5-4c74-b917-a4ad1d1f45e2", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67149:a87365", "ysrc": "amper:67149:11466d", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false } ], "layout": { "title": "06-12-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:00:21.195253Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aplukis/10.embed", "fid": "aplukis:10", "filename": "Female by Level", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aplukis:10/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aplukis:10/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aplukis/10/8_0WJZPIJE2USUN4IUHJ4ZO0UT02JP9G.png", "list-thumb": "https://api.plotly.com/v2/files/aplukis:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aplukis:10", "plots": "https://api.plotly.com/v2/plots/aplukis:10", "parent": "https://api.plotly.com/v2/folders/home?user=aplukis" }, "owner": "aplukis", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Course Evaluations Means by Level: Female", "views": 0, "web_url": "https://chart-studio.plotly.com/~aplukis/10/course-evaluations-means-by-level-female/", "world_readable": true, "date_modified": "2019-06-17T21:05:01.118Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aplukis/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "efb16394-ccfc-4bd6-a3c1-ba6a21367916", "name": "Level 100", "type": "bar", "xsrc": "aplukis:11:bcf3d1", "ysrc": "aplukis:11:ab4d7d", "marker": { "color": "rgb(233,117,90)" } }, { "uid": "9425e4dc-2db5-49c1-9aea-0680115fec75", "name": "Level 200", "type": "bar", "xsrc": "aplukis:11:bcf3d1", "ysrc": "aplukis:11:879fae", "marker": { "color": "rgb(72,139,165)" } }, { "uid": "84183864-7e06-46d9-8c2b-28a2aad2e9e4", "name": "Level 300", "type": "bar", "xsrc": "aplukis:11:bcf3d1", "ysrc": "aplukis:11:e0931e", "marker": { "color": "rgb(204,180,0)" } }, { "uid": "35f3ea0e-26df-4340-90c6-e5dd479153c8", "name": "Level 400", "type": "bar", "xsrc": "aplukis:11:bcf3d1", "ysrc": "aplukis:11:9d0007", "marker": { "color": "rgb(143,176,140)" } } ], "layout": { "title": { "text": "Course Evaluations Means by Level: Female" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aplukis", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/58.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 20:30:43", "mapbox_access_tokens": null, "has_password": null, "username": "aplukis", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T21:00:20.573485Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~reza7516/18.embed", "fid": "reza7516:18", "filename": "usrers for each day", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/reza7516:18/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/reza7516/18/2_GHG65N6TUWO78AR1XIVOSFIHGPIKSH.png", "block-thumb": "https://api.plotly.com/v2/files/reza7516:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/reza7516:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/reza7516:18", "plots": "https://api.plotly.com/v2/plots/reza7516:18", "parent": "https://api.plotly.com/v2/folders/home?user=reza7516" }, "owner": "reza7516", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 4, "web_url": "https://chart-studio.plotly.com/~reza7516/18/", "world_readable": true, "date_modified": "2019-06-17T21:04:53.856Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~reza7516/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e1497cb5-f67c-4695-b148-c72c0c2ee3e0", "type": "bar", "xsrc": "reza7516:19:f489c8", "ysrc": "reza7516:19:aa4cdd" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~reza7516", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 19:01:08", "mapbox_access_tokens": null, "has_password": null, "username": "reza7516", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:58:52.418110Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jingwenc/103.embed", "fid": "jingwenc:103", "filename": "plot from API (7)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jingwenc:103/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jingwenc:103/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jingwenc:103/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jingwenc:103/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jingwenc:103", "plots": "https://api.plotly.com/v2/plots/jingwenc:103", "parent": "https://api.plotly.com/v2/folders/home?user=jingwenc" }, "owner": "jingwenc", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Historical Property Cost", "views": 1, "web_url": "https://chart-studio.plotly.com/~jingwenc/103/historical-property-cost/", "world_readable": true, "date_modified": "2019-06-17T20:58:52.906Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jingwenc/103/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "aa3b9467-0036-4eaa-bc87-e2f267af18d6", "name": "10312", "type": "scatter", "xsrc": "jingwenc:104:f49085", "ysrc": "jingwenc:104:40a93e" }, { "uid": "0b92fe25-462f-447e-a329-9f6127802044", "name": "10306", "type": "scatter", "xsrc": "jingwenc:104:f49085", "ysrc": "jingwenc:104:7eb6b6" }, { "uid": "cc9cd001-c937-4194-a710-9b3eb8abdaf3", "name": "11434", "type": "scatter", "xsrc": "jingwenc:104:f49085", "ysrc": "jingwenc:104:9e319e" }, { "uid": "9391b15c-1ded-4597-ae71-3ccf8fa43c2d", "name": "11234", "type": "scatter", "xsrc": "jingwenc:104:f49085", "ysrc": "jingwenc:104:102842" }, { "uid": "e2cf4704-3af2-4387-b48f-6c045cc9af52", "name": "10304", "type": "scatter", "xsrc": "jingwenc:104:f49085", "ysrc": "jingwenc:104:b3f3b7" } ], "layout": { "title": { "text": "Historical Property Cost" }, "xaxis": { "type": "date", "rangeslider": { "visible": true }, "rangeselector": { "buttons": [ { "step": "month", "count": 1, "label": "1m", "stepmode": "backward" }, { "step": "month", "count": 6, "label": "6m", "stepmode": "backward" }, { "step": "year", "count": 1, "label": "YTD", "stepmode": "todate" }, { "step": "year", "count": 1, "label": "1y", "stepmode": "backward" }, { "step": "all" } ] } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jingwenc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/37.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-02-20 18:49:11", "mapbox_access_tokens": null, "has_password": null, "username": "jingwenc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:58:44.967997Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jbaniha/4.embed", "fid": "jbaniha:4", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jbaniha:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jbaniha:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jbaniha:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jbaniha:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jbaniha:4", "plots": "https://api.plotly.com/v2/plots/jbaniha:4", "parent": "https://api.plotly.com/v2/folders/home?user=jbaniha" }, "owner": "jbaniha", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~jbaniha/4/", "world_readable": true, "date_modified": "2019-06-17T20:58:45.516Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jbaniha/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b136dad8-9142-11e9-a024-b8ca3ad6c2d9", "type": "box", "ysrc": "jbaniha:5:a08f86", "jitter": 0.3, "pointpos": -1.8, "boxpoints": "all" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jbaniha", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-01-18 18:40:48", "mapbox_access_tokens": null, "has_password": null, "username": "jbaniha", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:57:25.480372Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~annacallahan/63.embed", "fid": "annacallahan:63", "filename": "Plot 63", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/annacallahan/63/9_BKMCIAYYJM3J3WLVO9317G2TKKVFLO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/annacallahan/63/2_F22M850YFI0BXS0HULDFZ4N5EPI2UL.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/annacallahan/63/8_72HQCXNU58H5AWXMS0WPRB15O3CWVS.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/annacallahan/63/9_BKMCIAYYJM3J3WLVO9317G2TKKVFLO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/annacallahan:63", "plots": "https://api.plotly.com/v2/plots/annacallahan:63", "parent": "https://api.plotly.com/v2/folders/home?user=annacallahan" }, "owner": "annacallahan", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~annacallahan/63/", "world_readable": true, "date_modified": "2019-06-17T20:58:06.207Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~annacallahan/63/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "all cases", "type": "bar", "xsrc": "annacallahan:56:73a691", "ysrc": "annacallahan:56:e908a8", "marker": { "color": "rgb(169, 172, 255)" }, "orientation": "v" }, { "name": "street/sidewalk<br>cleaning requests", "type": "bar", "xsrc": "annacallahan:56:73a691", "ysrc": "annacallahan:56:5f2b4f", "marker": { "color": "rgb(74, 204, 198)" }, "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "311 Cases within 150 m of the Golden Gate & Jones Pit Stop" }, "xaxis": { "type": "date", "range": [ "2008-06-17", "2019-06-15" ], "title": { "text": "time" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.6964368347987043, 316.87875983341047 ], "title": { "text": "311 cases" }, "autorange": true }, "bargap": 0.21999999999999997, "shapes": [ { "x0": "2014-07-01 18:00", "x1": "2014-07-01 06:00", "y0": 0, "y1": 300, "line": { "dash": "dot", "color": "rgb(255, 33, 33)", "width": 2 }, "type": "line", "opacity": 1, "fillcolor": "#7f7f7f" } ], "barmode": "overlay", "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "annotations": [ { "x": "2014-04-14 17:01:47.7844", "y": 224.5799861175382, "ax": -69, "ay": 0, "text": "pit stop installed" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~annacallahan", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 14:31:32", "mapbox_access_tokens": null, "has_password": null, "username": "annacallahan", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
