Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzIwJTNBMzUlM0E1MC4xMTYyMjElMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzIwJTNBMjglM0EwOC4wODc5MzYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysyMCUzQTM1JTNBMzEuMDMwODg1JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T20:35:31.030885Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~siboraseranaj/110.embed", "fid": "siboraseranaj:110", "filename": "plot from API (18)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/siboraseranaj:110/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/siboraseranaj:110/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/siboraseranaj/110/8_DSEWU7T6YXD678L24WWG4V51V0THN1.png", "list-thumb": "https://api.plotly.com/v2/files/siboraseranaj:110/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/siboraseranaj:110", "plots": "https://api.plotly.com/v2/plots/siboraseranaj:110", "parent": "https://api.plotly.com/v2/folders/home?user=siboraseranaj" }, "owner": "siboraseranaj", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Most frequent Customers (Pre-Tamr and Post-Tamr)", "views": 1, "web_url": "https://chart-studio.plotly.com/~siboraseranaj/110/most-frequent-customers-pre-tamr-and-post-tamr/", "world_readable": true, "date_modified": "2019-06-17T20:35:31.585Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~siboraseranaj/110/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1d536c41-a99d-44ca-b70c-e9c2b2722b25", "name": "Pre-Tamr", "type": "bar", "xsrc": "siboraseranaj:111:aed0b1", "ysrc": "siboraseranaj:111:50d594", "xaxis": "x", "yaxis": "y", "marker": { "colorsrc": "siboraseranaj:111:356802" }, "orientation": "h" }, { "uid": "c6ddb1b4-f567-475a-b551-eb4c7ab4df4d", "name": "Post-Tamr", "type": "bar", "xsrc": "siboraseranaj:111:1d31d8", "ysrc": "siboraseranaj:111:276884", "xaxis": "x2", "yaxis": "y2", "marker": { "colorsrc": "siboraseranaj:111:45ed5d" }, "orientation": "h" } ], "layout": { "title": { "text": "Most frequent Customers (Pre-Tamr and Post-Tamr)" }, "xaxis": { "anchor": "y", "domain": [ 0.0, 0.45 ], "showgrid": true, "showline": true, "zeroline": false, "showticklabels": true }, "yaxis": { "anchor": "x", "domain": [ 0.0, 1.0 ], "showgrid": false, "showline": true, "showticklabels": false }, "legend": { "x": 0.7, "y": 1.188, "font": { "size": 10 } }, "margin": { "b": 70, "l": 50, "r": 20, "t": 150 }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ], "showgrid": true, "showline": true, "zeroline": false, "showticklabels": true }, "yaxis2": { "anchor": "x2", "domain": [ 0.0, 1.0 ], "showgrid": false, "showline": true, "showticklabels": false }, "annotations": [ { "x": -0.2, "y": -0.109, "xref": "paper", "yref": "paper", "align": "right" } ], "plot_bgcolor": "rgb(248, 248, 255)", "paper_bgcolor": "rgb(248, 248, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~siboraseranaj", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 00:20:40", "mapbox_access_tokens": null, "has_password": null, "username": "siboraseranaj", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:35:18.437167Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67140.embed", "fid": "amper:67140", "filename": "06-10-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67140/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67140/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67140/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67140/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67140", "plots": "https://api.plotly.com/v2/plots/amper:67140", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-10-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67140/_06-10-19-ds-1976-alg-5421-param-1407-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T20:35:19.715Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67140/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "122f063f-7ea3-4a12-9c3b-936e7d1ff84a", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67141:b5e2b5", "ysrc": "amper:67141:e8e638", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false } ], "layout": { "title": "06-10-19_ds-1976_alg-5421_param-1407_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:34:17.588801Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~suhaib18/0.embed", "fid": "suhaib18:0", "filename": "basic-scatter", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/suhaib18:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/suhaib18:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/suhaib18:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/suhaib18:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/suhaib18:0", "plots": "https://api.plotly.com/v2/plots/suhaib18:0", "parent": "https://api.plotly.com/v2/folders/home?user=suhaib18" }, "owner": "suhaib18", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 3, "web_url": "https://chart-studio.plotly.com/~suhaib18/0/", "world_readable": true, "date_modified": "2019-07-02T05:55:34.986Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~suhaib18/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b988f580-947c-4210-93b3-b50fc0190122", "type": "bar", "xsrc": "suhaib18:1:6f74ca", "ysrc": "suhaib18:1:4008bc" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~suhaib18", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/63.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 20:31:46", "mapbox_access_tokens": null, "has_password": null, "username": "suhaib18", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:32:02.478407Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~siboraseranaj/108.embed", "fid": "siboraseranaj:108", "filename": "plot from API (17)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/siboraseranaj:108/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/siboraseranaj:108/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/siboraseranaj/108/8_SVD46F9VNB7T6SFA2UZOX6N8EKSBOD.png", "list-thumb": "https://api.plotly.com/v2/files/siboraseranaj:108/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/siboraseranaj:108", "plots": "https://api.plotly.com/v2/plots/siboraseranaj:108", "parent": "https://api.plotly.com/v2/folders/home?user=siboraseranaj" }, "owner": "siboraseranaj", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Most frequent Customers (Pre-Tamr and Post-Tamr)", "views": 1, "web_url": "https://chart-studio.plotly.com/~siboraseranaj/108/most-frequent-customers-pre-tamr-and-post-tamr/", "world_readable": true, "date_modified": "2019-06-17T20:32:03.041Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~siboraseranaj/108/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f63e4fac-e728-47e0-90b6-60d59b434050", "name": "Pre-Tamr", "type": "bar", "xsrc": "siboraseranaj:109:82efc3", "ysrc": "siboraseranaj:109:4777ca", "xaxis": "x", "yaxis": "y", "marker": { "colorsrc": "siboraseranaj:109:19e841" }, "orientation": "h" }, { "uid": "ea93a050-3797-4746-9bd1-f27e3b176e7b", "name": "Post-Tamr", "type": "bar", "xsrc": "siboraseranaj:109:1429fe", "ysrc": "siboraseranaj:109:f3b960", "xaxis": "x2", "yaxis": "y2", "marker": { "colorsrc": "siboraseranaj:109:f47945" }, "orientation": "h" } ], "layout": { "title": { "text": "Most frequent Customers (Pre-Tamr and Post-Tamr)" }, "xaxis": { "anchor": "y", "domain": [ 0.0, 0.45 ], "showgrid": true, "showline": true, "zeroline": false, "showticklabels": true }, "yaxis": { "anchor": "x", "domain": [ 0.0, 1.0 ], "showgrid": false, "showline": true, "showticklabels": false }, "legend": { "x": 0.7, "y": 1.188, "font": { "size": 10 } }, "margin": { "b": 70, "l": 50, "r": 20, "t": 150 }, "xaxis2": { "anchor": "y2", "domain": [ 0.55, 1.0 ], "showgrid": true, "showline": true, "zeroline": false, "showticklabels": true }, "yaxis2": { "anchor": "x2", "domain": [ 0.0, 1.0 ], "showgrid": false, "showline": true, "showticklabels": false }, "annotations": [ { "align": "right" } ], "plot_bgcolor": "rgb(248, 248, 255)", "paper_bgcolor": "rgb(248, 248, 255)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~siboraseranaj", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 00:20:40", "mapbox_access_tokens": null, "has_password": null, "username": "siboraseranaj", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:32:01.276748Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~camel_clarkson/670.embed", "fid": "camel_clarkson:670", "filename": "3ts_ano_gan_scores", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/camel_clarkson:670/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/camel_clarkson/670/2_I259N5NB2CD810PJD9QF14WK1VGGZK.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/camel_clarkson/670/8_M3INKANI3N2WT2IG7L1A45U50IADOL.png", "list-thumb": "https://api.plotly.com/v2/files/camel_clarkson:670/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/camel_clarkson:670", "plots": "https://api.plotly.com/v2/plots/camel_clarkson:670", "parent": "https://api.plotly.com/v2/folders/camel_clarkson:667" }, "owner": "camel_clarkson", "parent": 667, "preview": "", "referencers": [], "references": [], "title": "AnoGAN Scores on 3 Time Step Anomaly Detection", "views": 0, "web_url": "https://chart-studio.plotly.com/~camel_clarkson/670/anogan-scores-on-3-time-step-anomaly-detection/", "world_readable": true, "date_modified": "2019-06-18T02:39:35.213Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~camel_clarkson/670/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "46db5378-9172-11e9-b3c6-0242729651f2", "name": "normal", "type": "box", "xsrc": "camel_clarkson:671:3cc5b9", "ysrc": "camel_clarkson:671:4f78a2", "marker": { "color": "#2ecc71" } }, { "uid": "46db560c-9172-11e9-b3c6-0242729651f2", "name": "anomalous", "type": "box", "xsrc": "camel_clarkson:671:3cc5b9", "ysrc": "camel_clarkson:671:e91c68", "marker": { "color": "#c0392b" } } ], "layout": { "title": "AnoGAN Scores on 3 Time Step Anomaly Detection", "yaxis": { "title": "Score" }, "boxmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~camel_clarkson", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60IF3N1IBLFY7K13IM329ZJ7IU25K4.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-08-11 04:24:54", "mapbox_access_tokens": null, "has_password": null, "username": "camel_clarkson", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:31:36.375572Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~brmcdonnell/0.embed", "fid": "brmcdonnell:0", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/brmcdonnell:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/brmcdonnell:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/brmcdonnell/0/8_MQ5AX5KUFNVW3F1LI7WL5L4I4L77Z5.png", "list-thumb": "https://api.plotly.com/v2/files/brmcdonnell:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/brmcdonnell:0", "plots": "https://api.plotly.com/v2/plots/brmcdonnell:0", "parent": "https://api.plotly.com/v2/folders/home?user=brmcdonnell" }, "owner": "brmcdonnell", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~brmcdonnell/0/", "world_readable": true, "date_modified": "2019-06-17T20:31:36.845Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~brmcdonnell/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "09c74bf0-17e1-46d4-8f08-26791b28c616", "type": "histogram", "xsrc": "brmcdonnell:1:f7818e" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~brmcdonnell", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/85.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-10 17:47:23", "mapbox_access_tokens": null, "has_password": null, "username": "brmcdonnell", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:30:03.749017Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jic198/22.embed", "fid": "jic198:22", "filename": "plot from API (6)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jic198:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jic198:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/jic198:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/jic198:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jic198:22", "plots": "https://api.plotly.com/v2/plots/jic198:22", "parent": "https://api.plotly.com/v2/folders/home?user=jic198" }, "owner": "jic198", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Estimated number of clusters: 3", "views": 3, "web_url": "https://chart-studio.plotly.com/~jic198/22/estimated-number-of-clusters-3/", "world_readable": true, "date_modified": "2019-06-17T20:30:04.284Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jic198/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "4b923ecb-b4db-49b4-912a-eb7922c9302a", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:664153", "ysrc": "jic198:23:9e80ac", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(158, 1, 66)" } }, { "uid": "b8af8246-6073-4f3a-ba26-58372d8cfc8f", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:89109d", "ysrc": "jic198:23:025f5e", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(158, 1, 66)" } }, { "uid": "3cecb5e9-6b1c-433d-89d0-60fa27dac80e", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:5cb644", "ysrc": "jic198:23:7faa62", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 190, 110)" } }, { "uid": "9523924f-90e5-4578-8793-20fbff3f7b78", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:57837c", "ysrc": "jic198:23:816cbd", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 190, 110)" } }, { "uid": "d9d7d93e-e046-4da9-808c-c0ec1a0a1215", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:f6dc09", "ysrc": "jic198:23:a5b6c2", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(190, 229, 160)" } }, { "uid": "dd5802b7-88ba-47c4-a483-68bb79e18cee", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:b2a3e9", "ysrc": "jic198:23:fc227f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(190, 229, 160)" } }, { "x": [], "y": [], "uid": "3a1c517a-6313-4bec-9052-82dbc6e76fa4", "mode": "markers", "type": "scatter", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "black" } }, { "uid": "5fc121d8-76f0-4371-92bf-02870b832e32", "mode": "markers", "type": "scatter", "xsrc": "jic198:23:f3956f", "ysrc": "jic198:23:f81cb8", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "black" } } ], "layout": { "title": { "text": "Estimated number of clusters: 3" }, "xaxis": { "showgrid": false, "zeroline": false }, "yaxis": { "showgrid": false, "zeroline": false }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jic198", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/67.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:29:56", "mapbox_access_tokens": null, "has_password": null, "username": "jic198", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:28:56.082883Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aplukis/8.embed", "fid": "aplukis:8", "filename": "histogram-freq-female", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aplukis:8/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/aplukis/8/2_7J81T1MV5ELYQZF8KW2LFW2VZNH050.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aplukis/8/8_3YM22RF0915NI7DU1EGZ2B1BLPZFFB.png", "list-thumb": "https://api.plotly.com/v2/files/aplukis:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aplukis:8", "plots": "https://api.plotly.com/v2/plots/aplukis:8", "parent": "https://api.plotly.com/v2/folders/home?user=aplukis" }, "owner": "aplukis", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Frequency of Overall Course Ratings: Female", "views": 0, "web_url": "https://chart-studio.plotly.com/~aplukis/8/frequency-of-overall-course-ratings-female/", "world_readable": true, "date_modified": "2019-06-17T20:28:56.564Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aplukis/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3ec2e674-62d2-4f04-a39f-3fd09625668d", "type": "histogram", "xsrc": "aplukis:9:33e44a", "xbins": { "end": 5.0, "size": 0.13530514769659457, "start": 2.68 }, "marker": { "color": "rgb(143,176,140)" } } ], "layout": { "title": { "text": "Frequency of Overall Course Ratings: Female" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aplukis", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/58.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 20:30:43", "mapbox_access_tokens": null, "has_password": null, "username": "aplukis", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:28:44.399336Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~david.yaffe/0.embed", "fid": "david.yaffe:0", "filename": "pandas-continuous-error-bars", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/david.yaffe:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/david.yaffe:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/david.yaffe/0/8_38BQOZDI86BZK3NOS47W3INKZI5X63.png", "list-thumb": "https://api.plotly.com/v2/files/david.yaffe:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/david.yaffe:0", "plots": "https://api.plotly.com/v2/plots/david.yaffe:0", "parent": "https://api.plotly.com/v2/folders/home?user=david.yaffe" }, "owner": "david.yaffe", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Boston Housing (Predictions with Random Forest Regressor and 95% Confidence Intervals using Conformal Prediction)", "views": 0, "web_url": "https://chart-studio.plotly.com/~david.yaffe/0/boston-housing-predictions-with-random-forest-regressor-and-95-confidence-interv/", "world_readable": true, "date_modified": "2019-07-25T17:09:58.657Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~david.yaffe/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e276df30-929c-40ed-9340-7a51c20c1168", "line": { "width": 0 }, "mode": "lines", "name": "Lower Bound", "type": "scatter", "xsrc": "david.yaffe:1:2419c1", "ysrc": "david.yaffe:1:04d52d", "marker": { "color": "#444" } }, { "uid": "8692ea7b-a702-41b2-bd3d-7e7c684afdbf", "fill": "tonexty", "line": { "color": "rgb(31, 119, 180)" }, "mode": "lines", "name": "Predicted value of Target", "type": "scatter", "xsrc": "david.yaffe:1:2419c1", "ysrc": "david.yaffe:1:8c19d6", "fillcolor": "rgba(68, 68, 68, 0.3)" }, { "uid": "3f347994-5519-4acc-ae3d-762293912497", "fill": "tonexty", "line": { "width": 0 }, "mode": "lines", "name": "Upper Bound", "type": "scatter", "xsrc": "david.yaffe:1:2419c1", "ysrc": "david.yaffe:1:659e57", "marker": { "color": "#444" }, "fillcolor": "rgba(68, 68, 68, 0.3)" } ], "layout": { "title": { "text": "Boston Housing (Predictions with Random Forest Regressor and 95% Confidence Intervals using Conformal Prediction)" }, "yaxis": { "title": { "text": "Prediction value of Target" } }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~david.yaffe", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/65.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 20:15:28", "mapbox_access_tokens": null, "has_password": null, "username": "david.yaffe", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T20:28:08.087936Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ghbellesis/0.embed", "fid": "ghbellesis:0", "filename": "basic-line-chart", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ghbellesis:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ghbellesis:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ghbellesis/0/8_7UEXDPHPD21MHOEJRY7K9LCNT8Q4RG.png", "list-thumb": "https://api.plotly.com/v2/files/ghbellesis:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ghbellesis:0", "plots": "https://api.plotly.com/v2/plots/ghbellesis:0", "parent": "https://api.plotly.com/v2/folders/home?user=ghbellesis" }, "owner": "ghbellesis", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~ghbellesis/0/", "world_readable": true, "date_modified": "2019-06-17T20:28:08.684Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ghbellesis/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "f7338e1a-89a4-4cd0-b319-2cfe2e952e89", "type": "scatter", "xsrc": "ghbellesis:1:5d6d05", "ysrc": "ghbellesis:1:75a2b2" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ghbellesis", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 20:18:34", "mapbox_access_tokens": null, "has_password": null, "username": "ghbellesis", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
