Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE4JTNBMzUlM0EyNC4yODYzNDglMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE4JTNBMjglM0EyNy40ODY5MDglMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxOCUzQTM1JTNBMjIuODE5NzUzJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T18:35:22.819753Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~brendan115/141.embed", "fid": "brendan115:141", "filename": "mean_corr_heatmap", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/brendan115:141/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/brendan115:141/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/brendan115/141/8_BLKIN5KYKTBPIEM57DUT6LQTW66GBI.png", "list-thumb": "https://api.plotly.com/v2/files/brendan115:141/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/brendan115:141", "plots": "https://api.plotly.com/v2/plots/brendan115:141", "parent": "https://api.plotly.com/v2/folders/home?user=brendan115" }, "owner": "brendan115", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~brendan115/141/", "world_readable": true, "date_modified": "2019-06-17T18:45:15.511Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~brendan115/141/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "51780e97-1d42-40ef-88d8-8b19a47a44d4", "type": "heatmap", "xsrc": "brendan115:142:dcff5e", "ysrc": "brendan115:142:6423d7", "zsrc": "brendan115:142:ae9f55,8a9adb,b5f060,99edb2,8b859a,f1e74d" } ], "layout": { "font": { "size": 18 }, "width": 850, "xaxis": { "side": "bottom" }, "height": 700 } }, "height": 700, "width": 850, "user": { "profile_url": "https://chart-studio.plotly.com/~brendan115", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/0.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-01-25 17:57:52", "mapbox_access_tokens": null, "has_password": null, "username": "brendan115", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:35:11.851004Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~YotamCohen/1.embed", "fid": "YotamCohen:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/YotamCohen:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/YotamCohen:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/YotamCohen/1/8_TENFD3AKCASAWBND5ZJWC0PBOX0XC1.png", "list-thumb": "https://api.plotly.com/v2/files/YotamCohen:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/YotamCohen:1", "plots": "https://api.plotly.com/v2/plots/YotamCohen:1", "parent": "https://api.plotly.com/v2/folders/home?user=YotamCohen" }, "owner": "YotamCohen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~YotamCohen/1/", "world_readable": true, "date_modified": "2019-06-17T18:35:11.864Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~YotamCohen/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "name": "nintendo", "type": "scatter", "xsrc": "YotamCohen:0:98c8a5", "ysrc": "YotamCohen:0:08bf24", "connectgaps": true }, { "mode": "lines", "name": "nintendoswitch", "type": "scatter", "xsrc": "YotamCohen:0:f1a876", "ysrc": "YotamCohen:0:a2defe" } ], "frames": [], "layout": { "xaxis": { "type": "date", "range": [ "2012-10-28 20:00", "2019-06-15 20:00" ], "autorange": true, "showspikes": false }, "yaxis": { "type": "linear", "range": [ -47590.3888888889, 1236357.388888889 ], "autorange": true, "showspikes": false }, "margin": { "b": 30, "l": 40, "r": 30, "t": 0, "pad": 0 }, "autosize": true, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~YotamCohen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/76.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 18:34:50", "mapbox_access_tokens": null, "has_password": null, "username": "YotamCohen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:34:14.711335Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ocing66/64.embed", "fid": "ocing66:64", "filename": "日照時數", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ocing66:64/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ocing66/64/2_E0XVGBA4LTEY1PO7MHO596Q0B0TVJO.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ocing66/64/8_LFY9Z4002JPE7MCB330QSCYXCLQQGU.png", "list-thumb": "https://api.plotly.com/v2/files/ocing66:64/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ocing66:64", "plots": "https://api.plotly.com/v2/plots/ocing66:64", "parent": "https://api.plotly.com/v2/folders/home?user=ocing66" }, "owner": "ocing66", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Manually Set Date Range", "views": 46, "web_url": "https://chart-studio.plotly.com/~ocing66/64/manually-set-date-range/", "world_readable": true, "date_modified": "2019-11-30T16:01:02.907Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ocing66/64/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ed6c45c1-232b-4227-8535-20e9a6e30096", "line": { "color": "#bfcf17" }, "name": "臺北(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:7dfdcd", "opacity": 0.8 }, { "uid": "4b86c5b2-0150-4217-9874-ee1a2f3a9328", "line": { "color": "#7F7F7F" }, "name": "高雄(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:df05ef", "opacity": 0.8 }, { "uid": "3950e06c-ba44-405f-a083-719b25b7d92e", "line": { "color": "#17becf" }, "name": "淡水(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:3760db", "opacity": 0.8 }, { "uid": "a84026f0-bd46-4354-87e1-76ccbb720d7c", "line": { "color": "#bf17cf" }, "name": "新竹(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:86d464", "opacity": 0.8 }, { "uid": "1774b06f-f75b-46e2-915b-7b826beaf8af", "line": { "color": "#cf6c17" }, "name": "臺中(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:aa3f82", "opacity": 0.8 }, { "uid": "2646a0a4-9d78-4892-acd7-8b262bbaef18", "line": { "color": "#1732cf" }, "name": "花蓮(小時)", "type": "scatter", "xsrc": "ocing66:65:ef682f", "ysrc": "ocing66:65:c4cb40", "opacity": 0.8 } ], "layout": { "title": { "text": "Manually Set Date Range" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ocing66", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/1.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-05-25 13:37:08", "mapbox_access_tokens": null, "has_password": null, "username": "ocing66", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:33:24.609114Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~msubasri/5.embed", "fid": "msubasri:5", "filename": "Plot 5", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/msubasri:5/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/msubasri:5/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/msubasri:5/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/msubasri:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/msubasri:5", "plots": "https://api.plotly.com/v2/plots/msubasri:5", "parent": "https://api.plotly.com/v2/folders/home?user=msubasri" }, "owner": "msubasri", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~msubasri/5/", "world_readable": true, "date_modified": "2019-06-17T18:33:24.625Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~msubasri/5/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "43340e", "name": "Tumor", "type": "bar", "xsrc": "msubasri:4:672e47", "ysrc": "msubasri:4:8b6e42", "marker": { "color": "#FF6666" } }, { "uid": "35a815", "name": "Normal", "type": "bar", "xsrc": "msubasri:4:672e47", "ysrc": "msubasri:4:d4c49c", "marker": { "color": "#444444" } } ], "frames": [], "layout": { "title": { "text": "TERT Retained Intron (ENST00000484238.6)" }, "xaxis": { "type": "category", "range": [ -0.5, 30.5 ], "tickfont": { "size": 14, "family": "Arial" }, "autorange": true, "tickangle": -45 }, "yaxis": { "type": "linear", "range": [ 0, 3.768421052631579 ], "title": { "text": "Expression - TPM" }, "autorange": true }, "barmode": "group", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~msubasri", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-04 17:17:06", "mapbox_access_tokens": null, "has_password": null, "username": "msubasri", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:32:52.148184Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gaioski/1.embed", "fid": "gaioski:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/gaioski:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/gaioski:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/gaioski:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/gaioski:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gaioski:1", "plots": "https://api.plotly.com/v2/plots/gaioski:1", "parent": "https://api.plotly.com/v2/folders/home?user=gaioski" }, "owner": "gaioski", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~gaioski/1/", "world_readable": true, "date_modified": "2019-06-17T18:32:52.161Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gaioski/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c307d7a7-b5fe-4d72-a40e-30473cf96305", "mode": "markers", "name": "2007", "type": "scatter", "xsrc": "gaioski:0:b10dd5", "ysrc": "gaioski:0:3c3081", "textsrc": "gaioski:0:e58871" } ], "frames": [], "layout": { "xaxis": { "type": "log", "range": [ 2.3102730036977253, 4.826421564351179 ], "title": { "text": "GDP per Capita" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 36.83870458952812, 85.37729541047187 ], "title": { "text": "Life Expectancy" }, "autorange": true }, "template": { "themeRef": "PLOTLY_CLASSIC" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gaioski", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/12.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 13:01:20", "mapbox_access_tokens": null, "has_password": null, "username": "gaioski", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:32:16.930355Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~msubasri/3.embed", "fid": "msubasri:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/msubasri:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/msubasri:3/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/msubasri:3/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/msubasri:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/msubasri:3", "plots": "https://api.plotly.com/v2/plots/msubasri:3", "parent": "https://api.plotly.com/v2/folders/home?user=msubasri" }, "owner": "msubasri", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~msubasri/3/", "world_readable": true, "date_modified": "2019-06-17T18:32:16.944Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~msubasri/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "96ecab", "name": "Tumor", "type": "bar", "xsrc": "msubasri:2:faf1f5", "ysrc": "msubasri:2:4385be", "marker": { "color": "#FF6666" } }, { "uid": "e59a88", "name": "Normal", "type": "bar", "xsrc": "msubasri:2:faf1f5", "ysrc": "msubasri:2:7bcb3a", "marker": { "color": "#444444" } } ], "frames": [], "layout": { "title": { "text": "TERT Full-Length (ENST00000310581.9)" }, "xaxis": { "type": "category", "range": [ -0.5, 30.5 ], "tickfont": { "size": 14, "family": "Arial" }, "autorange": true, "tickangle": -45 }, "yaxis": { "type": "linear", "range": [ 0, 1.3789473684210527 ], "title": { "text": "Expression - TPM" }, "autorange": true }, "barmode": "group", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~msubasri", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-04 17:17:06", "mapbox_access_tokens": null, "has_password": null, "username": "msubasri", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:30:45.055232Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~msubasri/1.embed", "fid": "msubasri:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/msubasri:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/msubasri/1/2_51S7I1A15609JQQ87HGCPKEWTTM159.png", "block-thumb": "https://api.plotly.com/v2/files/msubasri:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/msubasri:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/msubasri:1", "plots": "https://api.plotly.com/v2/plots/msubasri:1", "parent": "https://api.plotly.com/v2/folders/home?user=msubasri" }, "owner": "msubasri", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 6, "web_url": "https://chart-studio.plotly.com/~msubasri/1/", "world_readable": true, "date_modified": "2019-06-17T18:30:45.073Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~msubasri/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c45e97", "name": "Tumor", "type": "bar", "xsrc": "msubasri:0:e502ed", "ysrc": "msubasri:0:cd7b86", "marker": { "color": "#FF6666" } }, { "uid": "c88872", "name": "Normal", "type": "bar", "xsrc": "msubasri:0:e502ed", "ysrc": "msubasri:0:e079d2", "marker": { "color": "#444444" } } ], "frames": [], "layout": { "xaxis": { "type": "category", "range": [ -0.5, 30.5 ], "tickfont": { "size": 14, "family": "Arial" }, "autorange": true, "tickangle": -45 }, "yaxis": { "type": "linear", "range": [ 0, 2.8842105263157896 ], "title": { "text": "Expression - log2(TPM + 1)" }, "autorange": true }, "barmode": "group", "autosize": true, "dragmode": "lasso" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~msubasri", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-04 17:17:06", "mapbox_access_tokens": null, "has_password": null, "username": "msubasri", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:29:59.354387Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~wellaweg/2.embed", "fid": "wellaweg:2", "filename": "Basic Distplot", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/wellaweg:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/wellaweg:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/wellaweg:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/wellaweg:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/wellaweg:2", "plots": "https://api.plotly.com/v2/plots/wellaweg:2", "parent": "https://api.plotly.com/v2/folders/home?user=wellaweg" }, "owner": "wellaweg", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "distplot, distplot, distplot", "views": 10, "web_url": "https://chart-studio.plotly.com/~wellaweg/2/distplot-distplot-distplot/", "world_readable": true, "date_modified": "2019-06-20T06:15:46.694Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~wellaweg/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "97ffc309-025d-43a5-a10d-2d2778cf78c5", "name": "distplot", "type": "histogram", "xsrc": "wellaweg:3:2e8f92", "xaxis": "x", "xbins": { "end": 1121.85, "size": 1.0, "start": 260.28 }, "yaxis": "y", "marker": { "color": "rgb(31, 119, 180)" }, "opacity": 0.7, "autobinx": false, "histnorm": "probability density", "legendgroup": "distplot" }, { "uid": "f01c1c09-3be7-42a7-ba05-330d302df9d2", "mode": "lines", "name": "distplot", "type": "scatter", "xsrc": "wellaweg:3:fa9f6b", "ysrc": "wellaweg:3:67ffe0", "xaxis": "x", "yaxis": "y", "marker": { "color": "rgb(31, 119, 180)" }, "showlegend": false, "legendgroup": "distplot" }, { "uid": "5b667668-1723-47ef-91e1-86dccb41960d", "mode": "markers", "name": "distplot", "type": "scatter", "xsrc": "wellaweg:3:2e8f92", "ysrc": "wellaweg:3:a22746", "xaxis": "x", "yaxis": "y2", "marker": { "color": "rgb(31, 119, 180)", "symbol": "line-ns-open" }, "showlegend": false, "legendgroup": "distplot" } ], "layout": { "xaxis": { "anchor": "y2", "domain": [ 0.0, 1.0 ], "zeroline": false }, "yaxis": { "anchor": "free", "domain": [ 0.35, 1 ], "position": 0.0 }, "legend": { "traceorder": "reversed" }, "yaxis2": { "dtick": 1, "anchor": "x", "domain": [ 0, 0.25 ], "showticklabels": false }, "barmode": "overlay", "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~wellaweg", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 11:02:15", "mapbox_access_tokens": null, "has_password": null, "username": "wellaweg", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:29:13.458106Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ocing66/62.embed", "fid": "ocing66:62", "filename": "Manually Set Range", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ocing66:62/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ocing66:62/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ocing66/62/8_QKGFPEO1P1ZY4EXV04BU65247IK1W4.png", "list-thumb": "https://api.plotly.com/v2/files/ocing66:62/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ocing66:62", "plots": "https://api.plotly.com/v2/plots/ocing66:62", "parent": "https://api.plotly.com/v2/folders/home?user=ocing66" }, "owner": "ocing66", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Manually Set Date Range", "views": 0, "web_url": "https://chart-studio.plotly.com/~ocing66/62/manually-set-date-range/", "world_readable": true, "date_modified": "2019-06-17T19:36:35.746Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ocing66/62/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "572fb746-6a74-43c0-82c2-2a4ab7f7a7fb", "line": { "color": "#17BECF" }, "name": "臺北(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:b21813", "opacity": 0.8 }, { "uid": "c1ffaa18-862a-46ff-8859-24c2dd992e7b", "line": { "color": "#7F7F7F" }, "name": "高雄(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:a13390", "opacity": 0.8 }, { "uid": "2797e1fd-5928-4773-a749-b08f24bb25e5", "line": { "color": "#17becf" }, "name": "淡水(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:623194", "opacity": 0.8 }, { "uid": "b6a8f8cc-86e5-4d6d-a391-b16686f5f02a", "line": { "color": "#bf17cf" }, "name": "新竹(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:d75f15", "opacity": 0.8 }, { "uid": "26c01b55-4be7-4c64-ae74-b8f8ac275ec7", "line": { "color": "#cf6c17" }, "name": "臺中(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:8dac3e", "opacity": 0.8 }, { "uid": "cede2179-3e3f-47b3-835b-6102fd13bc73", "line": { "color": "#1732cf" }, "name": "花蓮(日)", "type": "scatter", "xsrc": "ocing66:63:37d99c", "ysrc": "ocing66:63:257653", "opacity": 0.8 } ], "layout": { "title": { "text": "Manually Set Date Range" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ocing66", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/1.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-05-25 13:37:08", "mapbox_access_tokens": null, "has_password": null, "username": "ocing66", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T18:28:27.486908Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mtsznowak9/1.embed", "fid": "mtsznowak9:1", "filename": "przyjazdy", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mtsznowak9:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/mtsznowak9/1/2_0KZI9JV6FDSTMXW9N86A7W2FF75K8M.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/mtsznowak9/1/8_OAM8PQKQKYT10PL9QE5EQ58HAOHYY8.png", "list-thumb": "https://api.plotly.com/v2/files/mtsznowak9:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mtsznowak9:1", "plots": "https://api.plotly.com/v2/plots/mtsznowak9:1", "parent": "https://api.plotly.com/v2/folders/home?user=mtsznowak9" }, "owner": "mtsznowak9", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~mtsznowak9/1/", "world_readable": true, "date_modified": "2019-06-17T20:52:39.578Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mtsznowak9/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "name": "trace 0", "sort": true, "type": "pie", "xsrc": "mtsznowak9:0:f9869e", "ysrc": "mtsznowak9:0:1ac258", "textfont": { "size": 23 }, "textinfo": "label+percent", "labelssrc": "mtsznowak9:0:1ac258", "valuessrc": "mtsznowak9:0:f9869e", "orientation": "v" } ], "frames": [], "layout": { "font": { "size": 20 }, "title": { "text": "Sei venuto in Italia:" }, "xaxis": { "type": "linear", "range": [ 14.5, 28.5 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 1.0526315789473684 ], "autorange": true }, "legend": { "font": { "size": 25 } }, "barmode": "group", "autosize": true, "colorway": [ "#66c2a5", "#fc8d62", "#8da0cb", "#e78ac3", "#a6d854", "#ffd92f", "#e5c494", "#b3b3b3" ], "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#fff7fb" ], [ 0.125, "#ece2f0" ], [ 0.25, "#d0d1e6" ], [ 0.375, "#a6bddb" ], [ 0.5, "#67a9cf" ], [ 0.625, "#3690c0" ], [ 0.75, "#02818a" ], [ 0.875, "#016c59" ], [ 1, "#014636" ] ] } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mtsznowak9", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/54.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 18:22:29", "mapbox_access_tokens": null, "has_password": null, "username": "mtsznowak9", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
