Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE3JTNBMjYlM0EwOC42ODEwNDglMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE3JTNBMjIlM0EyOC43MDMxNDYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNyUzQTI1JTNBNDMuMzU3Mjg5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T17:25:43.357289Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~neujeffski/9.embed", "fid": "neujeffski:9", "filename": "Plotly Playground 2019-06-17 19:25:42", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/neujeffski:9/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/neujeffski:9/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/neujeffski:9/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/neujeffski:9/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/neujeffski:9", "plots": "https://api.plotly.com/v2/plots/neujeffski:9", "parent": "https://api.plotly.com/v2/folders/home?user=neujeffski" }, "owner": "neujeffski", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#151516'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~neujeffski/9/font-color-151516/", "world_readable": true, "date_modified": "2019-06-17T17:25:43.819Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~neujeffski/9/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c413bcc2-bdcf-4069-ba22-8d4c30ad11b3", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(226, 74, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "YBG.YG", "text": "", "type": "scatter", "xsrc": "neujeffski:10:dc15df", "ysrc": "neujeffski:10:4cf115", "fillcolor": "rgba(226, 74, 51, 0.3)" }, { "uid": "593b0357-3e4f-4495-b795-eb8cf8f5d16c", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(62, 111, 176, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "TLI.GA", "text": "", "type": "scatter", "xsrc": "neujeffski:10:dc15df", "ysrc": "neujeffski:10:8520de", "fillcolor": "rgba(62, 111, 176, 0.3)" } ], "layout": { "title": { "font": { "color": "#151516" } }, "xaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "yaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "legend": { "font": { "color": "#666666" }, "bgcolor": "#FFFFFF" }, "plot_bgcolor": "#E5E5E5", "paper_bgcolor": "#FFFFFF" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~neujeffski", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:57:42", "mapbox_access_tokens": null, "has_password": null, "username": "neujeffski", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:25:32.573153Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~moiz_sakha/36.embed", "fid": "moiz_sakha:36", "filename": "Saarlouis_Scheid_Bahnhofstr_14_2017-11-15.png", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/moiz_sakha:36/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/moiz_sakha:36/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/moiz_sakha/36/8_KMZAC0HJ988U8J2ZM7H4YFQWXITMJD.png", "list-thumb": "https://api.plotly.com/v2/files/moiz_sakha:36/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/moiz_sakha:36", "plots": "https://api.plotly.com/v2/plots/moiz_sakha:36", "parent": "https://api.plotly.com/v2/folders/home?user=moiz_sakha" }, "owner": "moiz_sakha", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Location: Saarlouis_Scheid_Bahnhofstr_14, Date: 2017-11-15", "views": 0, "web_url": "https://chart-studio.plotly.com/~moiz_sakha/36/location-saarlouis-scheid-bahnhofstr-14-date-2017-11-15/", "world_readable": true, "date_modified": "2019-06-17T17:25:33.100Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~moiz_sakha/36/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e8581c8e-9124-11e9-9122-340286037753", "mode": "lines", "name": "label", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:495a32" }, { "uid": "e8581c8f-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_nodb", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:15af0e" }, { "uid": "e8581c90-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_db", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:04bdbc" }, { "uid": "e8581c91-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_rf", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:f901f1" }, { "uid": "e8581c92-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_rf_conf", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:f901f1", "error_y": { "arraysrc": "moiz_sakha:37:57a481", "symmetric": false, "arrayminussrc": "moiz_sakha:37:a7dfa9" } }, { "uid": "e8581c93-9124-11e9-9122-340286037753", "fill": "tonexty", "line": { "color": "rgb(180, 142, 31)" }, "mode": "lines", "name": "pred_dropout", "type": "scatter", "xsrc": "moiz_sakha:37:28ea32", "ysrc": "moiz_sakha:37:424425", "fillcolor": "rgba(68, 68, 68, 0.3)" } ], "layout": { "title": "Location: Saarlouis_Scheid_Bahnhofstr_14, Date: 2017-11-15", "xaxis": { "title": "Time" }, "yaxis": { "title": "mpower (kW)" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~moiz_sakha", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/87.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-01 11:22:04", "mapbox_access_tokens": null, "has_password": null, "username": "moiz_sakha", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:25:31.893481Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~neujeffski/7.embed", "fid": "neujeffski:7", "filename": "Plotly Playground 2019-06-17 19:25:30", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/neujeffski:7/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/neujeffski:7/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/neujeffski:7/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/neujeffski:7/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/neujeffski:7", "plots": "https://api.plotly.com/v2/plots/neujeffski:7", "parent": "https://api.plotly.com/v2/folders/home?user=neujeffski" }, "owner": "neujeffski", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#151516'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~neujeffski/7/font-color-151516/", "world_readable": true, "date_modified": "2019-06-17T17:25:32.321Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~neujeffski/7/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1901d39b-5fc3-4914-9b7f-08b9c6626022", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(226, 74, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "KDY.MM", "text": "", "type": "scatter", "xsrc": "neujeffski:8:5de9f5", "ysrc": "neujeffski:8:d221ee", "fillcolor": "rgba(226, 74, 51, 0.3)" }, { "uid": "0dd3f7f0-698a-433d-b510-f3a7cdf99783", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(62, 111, 176, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "UXW.EQ", "text": "", "type": "scatter", "xsrc": "neujeffski:8:5de9f5", "ysrc": "neujeffski:8:a924a1", "fillcolor": "rgba(62, 111, 176, 0.3)" }, { "uid": "43b4aaf6-8ba5-4233-8f2e-23beb634175a", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(132, 118, 202, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "DLO.LV", "text": "", "type": "scatter", "xsrc": "neujeffski:8:5de9f5", "ysrc": "neujeffski:8:ecd558", "fillcolor": "rgba(132, 118, 202, 0.3)" }, { "uid": "594fd6e7-6724-48fa-90e2-64f6ce8a6185", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(101, 101, 101, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "OFQ.XU", "text": "", "type": "scatter", "xsrc": "neujeffski:8:5de9f5", "ysrc": "neujeffski:8:84f902", "fillcolor": "rgba(101, 101, 101, 0.3)" } ], "layout": { "title": { "font": { "color": "#151516" } }, "xaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "yaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "legend": { "font": { "color": "#666666" }, "bgcolor": "#FFFFFF" }, "plot_bgcolor": "#E5E5E5", "paper_bgcolor": "#FFFFFF" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~neujeffski", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:57:42", "mapbox_access_tokens": null, "has_password": null, "username": "neujeffski", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:25:17.399574Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~neujeffski/5.embed", "fid": "neujeffski:5", "filename": "Plotly Playground 2019-06-17 19:25:16", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/neujeffski:5/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/neujeffski:5/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/neujeffski:5/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/neujeffski:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/neujeffski:5", "plots": "https://api.plotly.com/v2/plots/neujeffski:5", "parent": "https://api.plotly.com/v2/folders/home?user=neujeffski" }, "owner": "neujeffski", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#151516'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~neujeffski/5/font-color-151516/", "world_readable": true, "date_modified": "2019-06-17T17:25:17.895Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~neujeffski/5/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "a432ec9b-27a7-4332-a3aa-d491076e4a10", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(226, 74, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "TOW.LA", "text": "", "type": "scatter", "xsrc": "neujeffski:6:99a928", "ysrc": "neujeffski:6:e9da46", "xaxis": "x", "yaxis": "y", "fillcolor": "rgba(226, 74, 51, 0.3)" }, { "uid": "3acfcad1-f4b6-4180-8e83-1248cf68982a", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(62, 111, 176, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "ZSI.JV", "text": "", "type": "scatter", "xsrc": "neujeffski:6:99a928", "ysrc": "neujeffski:6:c2068c", "xaxis": "x", "yaxis": "y2", "fillcolor": "rgba(62, 111, 176, 0.3)" }, { "uid": "e966428c-d593-45bb-91ba-e6de74f12a52", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(132, 118, 202, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "SCU.OW", "text": "", "type": "scatter", "xsrc": "neujeffski:6:99a928", "ysrc": "neujeffski:6:90d047", "xaxis": "x", "yaxis": "y3", "fillcolor": "rgba(132, 118, 202, 0.3)" }, { "uid": "57431953-a6d2-4c22-876e-d825feddb02f", "fill": "tozeroy", "line": { "dash": "solid", "color": "rgba(101, 101, 101, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "KRT.LJ", "text": "", "type": "scatter", "xsrc": "neujeffski:6:99a928", "ysrc": "neujeffski:6:6c4c94", "xaxis": "x", "yaxis": "y4", "fillcolor": "rgba(101, 101, 101, 0.3)" } ], "layout": { "title": { "font": { "color": "#151516" } }, "xaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "anchor": "y4", "domain": [ 0.0, 1.0 ], "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "yaxis": { "title": { "font": { "color": "#666666" }, "text": "" }, "anchor": "free", "domain": [ 0.80625, 1.0 ], "position": 0.0, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "legend": { "font": { "color": "#666666" }, "bgcolor": "#FFFFFF" }, "yaxis2": { "title": { "font": { "color": "#666666" }, "text": "" }, "anchor": "free", "domain": [ 0.5375, 0.73125 ], "position": 0.0, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "yaxis3": { "title": { "font": { "color": "#666666" }, "text": "" }, "anchor": "free", "domain": [ 0.26875, 0.4625 ], "position": 0.0, "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "yaxis4": { "title": { "font": { "color": "#666666" }, "text": "" }, "anchor": "x", "domain": [ 0.0, 0.19375 ], "showgrid": true, "tickfont": { "color": "#666666" }, "gridcolor": "#F6F6F6", "zerolinecolor": "#F6F6F6" }, "plot_bgcolor": "#E5E5E5", "paper_bgcolor": "#FFFFFF" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~neujeffski", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:57:42", "mapbox_access_tokens": null, "has_password": null, "username": "neujeffski", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:25:10.504902Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~VSA72/2.embed", "fid": "VSA72:2", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/VSA72:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/VSA72:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/VSA72:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/VSA72:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/VSA72:2", "plots": "https://api.plotly.com/v2/plots/VSA72:2", "parent": "https://api.plotly.com/v2/folders/home?user=VSA72" }, "owner": "VSA72", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~VSA72/2/", "world_readable": true, "date_modified": "2019-06-17T17:25:11.003Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~VSA72/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "795f491c-e8d2-4f0b-8ec4-c28eaecaebaa", "type": "scatter", "xsrc": "VSA72:3:6cb5d8", "ysrc": "VSA72:3:698df5" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~VSA72", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/96.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 18:18:38", "mapbox_access_tokens": null, "has_password": null, "username": "VSA72", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:24:42.114881Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~bmtxzg064982/2.embed", "fid": "bmtxzg064982:2", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/bmtxzg064982:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/bmtxzg064982:2/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/bmtxzg064982/2/8_WXB4DJW022Y9YJNAGQOZ8EQM5K5ZR2.png", "list-thumb": "https://api.plotly.com/v2/files/bmtxzg064982:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/bmtxzg064982:2", "plots": "https://api.plotly.com/v2/plots/bmtxzg064982:2", "parent": "https://api.plotly.com/v2/folders/home?user=bmtxzg064982" }, "owner": "bmtxzg064982", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Scatterplot Matrix", "views": 1, "web_url": "https://chart-studio.plotly.com/~bmtxzg064982/2/scatterplot-matrix/", "world_readable": true, "date_modified": "2019-06-17T17:24:42.620Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~bmtxzg064982/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "219ac7e3-de9a-4caf-b101-40b3eb7748af", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x", "yaxis": "y", "marker": { "size": 6 }, "showlegend": false }, { "uid": "7e2c493e-d75b-49be-b684-73f7351c1b5b", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x2", "yaxis": "y2", "marker": { "size": 6 }, "showlegend": false }, { "uid": "3bd27e28-d054-4a86-b4bf-72775ecf4004", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x3", "yaxis": "y3", "marker": { "size": 6 }, "showlegend": false }, { "uid": "6f01fc61-0b43-4ef9-94e9-f91f4260b872", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x4", "yaxis": "y4", "marker": { "size": 6 }, "showlegend": false }, { "uid": "9b40f2bc-b997-4d08-a67b-5fa5ca5ca8ea", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x5", "yaxis": "y5", "marker": { "size": 6 }, "showlegend": false }, { "uid": "4ab3e36d-a76b-4ea4-b73c-daa50b73c994", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x6", "yaxis": "y6", "marker": { "size": 6 }, "showlegend": false }, { "uid": "40fe9d68-b2e3-42c8-969b-2d7e70318407", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:35a092", "xaxis": "x7", "yaxis": "y7", "marker": { "size": 6 }, "showlegend": false }, { "uid": "20549f89-2659-44e7-b2e0-e817c0b1f39b", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x8", "yaxis": "y8", "marker": { "size": 6 }, "showlegend": false }, { "uid": "4eb62828-dd2b-41aa-8048-3f646c0da74c", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x9", "yaxis": "y9", "marker": { "size": 6 }, "showlegend": false }, { "uid": "885651f7-1d8b-4217-8bf1-01a0393c3ac6", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x10", "yaxis": "y10", "marker": { "size": 6 }, "showlegend": false }, { "uid": "cc6c3203-6441-48fa-aa8f-bc1a2c03dab7", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x11", "yaxis": "y11", "marker": { "size": 6 }, "showlegend": false }, { "uid": "2a6b077a-0ac0-40e7-9603-366b0089633a", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x12", "yaxis": "y12", "marker": { "size": 6 }, "showlegend": false }, { "uid": "b4f013cc-cb18-4df6-bca5-87d9bff2d8bd", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x13", "yaxis": "y13", "marker": { "size": 6 }, "showlegend": false }, { "uid": "8a0fca82-cd76-4d99-bcb2-8a25b383a264", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:c09c4c", "xaxis": "x14", "yaxis": "y14", "marker": { "size": 6 }, "showlegend": false }, { "uid": "1a72528e-2662-4f30-894a-08b363c72897", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x15", "yaxis": "y15", "marker": { "size": 6 }, "showlegend": false }, { "uid": "bd6a4c03-d068-4a9f-9ae1-19d4d7aad883", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x16", "yaxis": "y16", "marker": { "size": 6 }, "showlegend": false }, { "uid": "c7dc5f01-26c1-4529-acde-1380d92e2930", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x17", "yaxis": "y17", "marker": { "size": 6 }, "showlegend": false }, { "uid": "24945b19-cbcb-47fc-b872-9549e07305e3", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x18", "yaxis": "y18", "marker": { "size": 6 }, "showlegend": false }, { "uid": "2ca12529-bba3-4a04-ad67-221544baac26", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x19", "yaxis": "y19", "marker": { "size": 6 }, "showlegend": false }, { "uid": "0d3f34c8-e881-4584-84d2-a2b1cfbd7d94", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x20", "yaxis": "y20", "marker": { "size": 6 }, "showlegend": false }, { "uid": "b1c2c21e-0ad1-445d-bd80-df62e74e7421", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:815f82", "xaxis": "x21", "yaxis": "y21", "marker": { "size": 6 }, "showlegend": false }, { "uid": "4e05f4b7-f5c3-4f67-a499-a86084fb5267", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x22", "yaxis": "y22", "marker": { "size": 6 }, "showlegend": false }, { "uid": "9ce69a4b-0a7e-428b-a9d9-1e3a41e17380", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x23", "yaxis": "y23", "marker": { "size": 6 }, "showlegend": false }, { "uid": "58195019-2966-43c2-b6ff-83aaba400fa6", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x24", "yaxis": "y24", "marker": { "size": 6 }, "showlegend": false }, { "uid": "9a29ecee-7673-475a-9654-5eecceddc40d", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x25", "yaxis": "y25", "marker": { "size": 6 }, "showlegend": false }, { "uid": "b88aec6c-58b7-4e83-ad5a-4a017b07aa11", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x26", "yaxis": "y26", "marker": { "size": 6 }, "showlegend": false }, { "uid": "6f8f4589-3ad2-473f-a152-25def4b12297", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x27", "yaxis": "y27", "marker": { "size": 6 }, "showlegend": false }, { "uid": "697dfb48-1209-4f31-855a-be2dfb15e34c", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:64ba1d", "xaxis": "x28", "yaxis": "y28", "marker": { "size": 6 }, "showlegend": false }, { "uid": "c34e1afd-f916-4e49-a13d-ae35af4306ba", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x29", "yaxis": "y29", "marker": { "size": 6 }, "showlegend": false }, { "uid": "b1021a57-3787-4471-9df7-116c8e0c78e0", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x30", "yaxis": "y30", "marker": { "size": 6 }, "showlegend": false }, { "uid": "04c91c71-249b-4bd0-a4cd-92ca3ff20f9a", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x31", "yaxis": "y31", "marker": { "size": 6 }, "showlegend": false }, { "uid": "0411dd6c-26ce-44b9-8065-0fe30fa0124c", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x32", "yaxis": "y32", "marker": { "size": 6 }, "showlegend": false }, { "uid": "7ab1ef0e-347f-4191-8af7-4ce5c1a38d04", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x33", "yaxis": "y33", "marker": { "size": 6 }, "showlegend": false }, { "uid": "c9fdd0ef-c0df-4e1b-9b50-b9a8424869dd", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x34", "yaxis": "y34", "marker": { "size": 6 }, "showlegend": false }, { "uid": "decb1268-cc60-4294-a50f-64d2c4d2b295", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:1765c5", "xaxis": "x35", "yaxis": "y35", "marker": { "size": 6 }, "showlegend": false }, { "uid": "d3c47383-002a-4ee4-ba25-8a8e1364dde4", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x36", "yaxis": "y36", "marker": { "size": 6 }, "showlegend": false }, { "uid": "ceb84644-473f-4157-a905-e313138f1f54", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x37", "yaxis": "y37", "marker": { "size": 6 }, "showlegend": false }, { "uid": "f96efd2e-8ffb-4d80-8cb8-9d680a6cf368", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x38", "yaxis": "y38", "marker": { "size": 6 }, "showlegend": false }, { "uid": "c8923bc0-ef99-4103-8d57-926ddcc283e2", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x39", "yaxis": "y39", "marker": { "size": 6 }, "showlegend": false }, { "uid": "98fff462-ee64-44f8-b9df-f6b577a05cff", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x40", "yaxis": "y40", "marker": { "size": 6 }, "showlegend": false }, { "uid": "f070f16b-bd90-4d13-9004-b0643cb78ed1", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x41", "yaxis": "y41", "marker": { "size": 6 }, "showlegend": false }, { "uid": "81f2c097-5624-4970-a074-07bd5183cd77", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:ba66a8", "xaxis": "x42", "yaxis": "y42", "marker": { "size": 6 }, "showlegend": false }, { "uid": "01359394-3f90-4472-b295-c840c519b76b", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:71ca4a", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x43", "yaxis": "y43", "marker": { "size": 6 }, "showlegend": false }, { "uid": "778066f4-fdf3-47f3-a48d-d9a013163d0c", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:b4e826", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x44", "yaxis": "y44", "marker": { "size": 6 }, "showlegend": false }, { "uid": "d7f5abf5-f169-4fc4-bacd-9a71cff96167", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:587299", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x45", "yaxis": "y45", "marker": { "size": 6 }, "showlegend": false }, { "uid": "023bf9bd-a35c-43b8-bbc7-b4fd5617ec4c", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:c3b7a1", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x46", "yaxis": "y46", "marker": { "size": 6 }, "showlegend": false }, { "uid": "02131cde-a9f0-45b9-8684-de91f66bf264", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:ccb4ea", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x47", "yaxis": "y47", "marker": { "size": 6 }, "showlegend": false }, { "uid": "b1737847-5e25-40f2-b244-d248a56a85b2", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:8c6b4d", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x48", "yaxis": "y48", "marker": { "size": 6 }, "showlegend": false }, { "uid": "95c3557a-2d41-4890-977c-50b1b8e04b59", "mode": "markers", "type": "scatter", "xsrc": "bmtxzg064982:3:218f89", "ysrc": "bmtxzg064982:3:a4f52a", "xaxis": "x49", "yaxis": "y49", "marker": { "size": 6 }, "showlegend": false } ], "layout": { "title": { "text": "Scatterplot Matrix" }, "width": 1200, "xaxis": { "anchor": "y", "domain": [ 0.0, 0.1183673469387755 ] }, "yaxis": { "title": { "text": "PassengerId" }, "anchor": "x", "domain": [ 0.8938775510204082, 1.0 ] }, "height": 1200, "xaxis2": { "anchor": "y2", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis3": { "anchor": "y3", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis4": { "anchor": "y4", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis5": { "anchor": "y5", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis6": { "anchor": "y6", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis7": { "anchor": "y7", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis8": { "anchor": "y8", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis9": { "anchor": "y9", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "yaxis2": { "anchor": "x2", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis3": { "anchor": "x3", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis4": { "anchor": "x4", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis5": { "anchor": "x5", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis6": { "anchor": "x6", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis7": { "anchor": "x7", "domain": [ 0.8938775510204082, 1.0 ] }, "yaxis8": { "title": { "text": "Survived" }, "anchor": "x8", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis9": { "anchor": "x9", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "xaxis10": { "anchor": "y10", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis11": { "anchor": "y11", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis12": { "anchor": "y12", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis13": { "anchor": "y13", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis14": { "anchor": "y14", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis15": { "anchor": "y15", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis16": { "anchor": "y16", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis17": { "anchor": "y17", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis18": { "anchor": "y18", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis19": { "anchor": "y19", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis20": { "anchor": "y20", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis21": { "anchor": "y21", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis22": { "anchor": "y22", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis23": { "anchor": "y23", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis24": { "anchor": "y24", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis25": { "anchor": "y25", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis26": { "anchor": "y26", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis27": { "anchor": "y27", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis28": { "anchor": "y28", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis29": { "anchor": "y29", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis30": { "anchor": "y30", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis31": { "anchor": "y31", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis32": { "anchor": "y32", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis33": { "anchor": "y33", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis34": { "anchor": "y34", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis35": { "anchor": "y35", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis36": { "anchor": "y36", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis37": { "anchor": "y37", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis38": { "anchor": "y38", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis39": { "anchor": "y39", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis40": { "anchor": "y40", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis41": { "anchor": "y41", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis42": { "anchor": "y42", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "xaxis43": { "title": { "text": "PassengerId" }, "anchor": "y43", "domain": [ 0.0, 0.1183673469387755 ] }, "xaxis44": { "title": { "text": "Survived" }, "anchor": "y44", "domain": [ 0.14693877551020407, 0.26530612244897955 ] }, "xaxis45": { "title": { "text": "Pclass" }, "anchor": "y45", "domain": [ 0.29387755102040813, 0.4122448979591836 ] }, "xaxis46": { "title": { "text": "Age" }, "anchor": "y46", "domain": [ 0.4408163265306122, 0.5591836734693877 ] }, "xaxis47": { "title": { "text": "SibSp" }, "anchor": "y47", "domain": [ 0.5877551020408163, 0.7061224489795918 ] }, "xaxis48": { "title": { "text": "Parch" }, "anchor": "y48", "domain": [ 0.7346938775510204, 0.8530612244897959 ] }, "xaxis49": { "title": { "text": "Fare" }, "anchor": "y49", "domain": [ 0.8816326530612244, 0.9999999999999999 ] }, "yaxis10": { "anchor": "x10", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis11": { "anchor": "x11", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis12": { "anchor": "x12", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis13": { "anchor": "x13", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis14": { "anchor": "x14", "domain": [ 0.7448979591836735, 0.8510204081632654 ] }, "yaxis15": { "title": { "text": "Pclass" }, "anchor": "x15", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis16": { "anchor": "x16", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis17": { "anchor": "x17", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis18": { "anchor": "x18", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis19": { "anchor": "x19", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis20": { "anchor": "x20", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis21": { "anchor": "x21", "domain": [ 0.5959183673469388, 0.7020408163265307 ] }, "yaxis22": { "title": { "text": "Age" }, "anchor": "x22", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis23": { "anchor": "x23", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis24": { "anchor": "x24", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis25": { "anchor": "x25", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis26": { "anchor": "x26", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis27": { "anchor": "x27", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis28": { "anchor": "x28", "domain": [ 0.4469387755102041, 0.553061224489796 ] }, "yaxis29": { "title": { "text": "SibSp" }, "anchor": "x29", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis30": { "anchor": "x30", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis31": { "anchor": "x31", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis32": { "anchor": "x32", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis33": { "anchor": "x33", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis34": { "anchor": "x34", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis35": { "anchor": "x35", "domain": [ 0.2979591836734694, 0.40408163265306124 ] }, "yaxis36": { "title": { "text": "Parch" }, "anchor": "x36", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis37": { "anchor": "x37", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis38": { "anchor": "x38", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis39": { "anchor": "x39", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis40": { "anchor": "x40", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis41": { "anchor": "x41", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis42": { "anchor": "x42", "domain": [ 0.1489795918367347, 0.25510204081632654 ] }, "yaxis43": { "title": { "text": "Fare" }, "anchor": "x43", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis44": { "anchor": "x44", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis45": { "anchor": "x45", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis46": { "anchor": "x46", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis47": { "anchor": "x47", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis48": { "anchor": "x48", "domain": [ 0.0, 0.10612244897959185 ] }, "yaxis49": { "anchor": "x49", "domain": [ 0.0, 0.10612244897959185 ] }, "showlegend": true } }, "height": 1200, "width": 1200, "user": { "profile_url": "https://chart-studio.plotly.com/~bmtxzg064982", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 17:13:59", "mapbox_access_tokens": null, "has_password": null, "username": "bmtxzg064982", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:23:54.283507Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~annacallahan/53.embed", "fid": "annacallahan:53", "filename": "Plot 53", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/annacallahan/53/9_USXTU7J6DJLJ18PV596UKA7C4HRT9L.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/annacallahan/53/2_R2RCUVJ4D3TP43C5EXO1CBEHZQD8M8.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/annacallahan/53/8_05P7N60VQFWVLG9BQ2X63BEL1XYMS2.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/annacallahan/53/9_USXTU7J6DJLJ18PV596UKA7C4HRT9L.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/annacallahan:53", "plots": "https://api.plotly.com/v2/plots/annacallahan:53", "parent": "https://api.plotly.com/v2/folders/home?user=annacallahan" }, "owner": "annacallahan", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~annacallahan/53/", "world_readable": true, "date_modified": "2019-06-17T22:54:32.582Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~annacallahan/53/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(116, 120, 255)", "shape": "spline", "width": 2, "smoothing": 1 }, "mode": "lines", "name": "all cases", "type": "scatter", "xsrc": "annacallahan:51:34e170", "ysrc": "annacallahan:51:2d66f9" }, { "line": { "color": "rgb(64, 194, 189)", "shape": "spline", "width": 2 }, "mode": "lines", "name": "street/sidewalk <br>cleaning requests", "type": "scatter", "xsrc": "annacallahan:52:397863", "ysrc": "annacallahan:52:60c027" } ], "frames": [], "layout": { "title": { "text": "16th and Mission % Change Comparison" }, "xaxis": { "type": "date", "range": [ "2008-07-01", "2019-06-01" ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.8340455840455842, 2.513532763532764 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~annacallahan", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-19 14:31:32", "mapbox_access_tokens": null, "has_password": null, "username": "annacallahan", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:23:53.275935Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~VSA72/0.embed", "fid": "VSA72:0", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/VSA72:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/VSA72:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/VSA72:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/VSA72:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/VSA72:0", "plots": "https://api.plotly.com/v2/plots/VSA72:0", "parent": "https://api.plotly.com/v2/folders/home?user=VSA72" }, "owner": "VSA72", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~VSA72/0/", "world_readable": true, "date_modified": "2019-06-17T17:23:53.765Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~VSA72/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "5f1fbf1b-d6b4-4caf-906f-b7431aee1e2b", "type": "scatter", "xsrc": "VSA72:1:ddf287", "ysrc": "VSA72:1:80c638" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~VSA72", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/96.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 18:18:38", "mapbox_access_tokens": null, "has_password": null, "username": "VSA72", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:22:44.671719Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cwalton2/5.embed", "fid": "cwalton2:5", "filename": "Plot 5", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cwalton2:5/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cwalton2:5/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/cwalton2:5/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/cwalton2:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cwalton2:5", "plots": "https://api.plotly.com/v2/plots/cwalton2:5", "parent": "https://api.plotly.com/v2/folders/home?user=cwalton2" }, "owner": "cwalton2", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cwalton2/5/", "world_readable": true, "date_modified": "2019-06-17T17:22:44.686Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cwalton2/5/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "type": "scatter", "xsrc": "cwalton2:4:a369ec", "ysrc": "cwalton2:4:21ff0f", "stackgroup": 1, "orientation": "h" } ], "frames": [], "layout": { "xaxis": { "type": "category", "range": [ -7.833333333333334, 148.83333333333334 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 241.1658765, 113523.1329 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cwalton2", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/18.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:35:51", "mapbox_access_tokens": null, "has_password": null, "username": "cwalton2", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:22:28.703146Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~moiz_sakha/34.embed", "fid": "moiz_sakha:34", "filename": "Saarlouis_Scheid_Bahnhofstr_14_2017-12-10.png", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/moiz_sakha:34/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/moiz_sakha:34/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/moiz_sakha/34/8_AZS8EU0HT73ZYBWCYU08VVIA4V2O29.png", "list-thumb": "https://api.plotly.com/v2/files/moiz_sakha:34/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/moiz_sakha:34", "plots": "https://api.plotly.com/v2/plots/moiz_sakha:34", "parent": "https://api.plotly.com/v2/folders/home?user=moiz_sakha" }, "owner": "moiz_sakha", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Location: Saarlouis_Scheid_Bahnhofstr_14, Date: 2017-12-10", "views": 0, "web_url": "https://chart-studio.plotly.com/~moiz_sakha/34/location-saarlouis-scheid-bahnhofstr-14-date-2017-12-10/", "world_readable": true, "date_modified": "2019-06-17T17:22:29.213Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~moiz_sakha/34/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "7ab4afc6-9124-11e9-9122-340286037753", "mode": "lines", "name": "label", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:941fd9" }, { "uid": "7ab4afc7-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_nodb", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:98d06b" }, { "uid": "7ab4afc8-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_db", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:abc0a9" }, { "uid": "7ab4afc9-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_rf", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:c84969" }, { "uid": "7ab4afca-9124-11e9-9122-340286037753", "mode": "lines", "name": "pred_rf_conf", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:c84969", "error_y": { "arraysrc": "moiz_sakha:35:5d005d", "symmetric": false, "arrayminussrc": "moiz_sakha:35:8ed7e8" } }, { "uid": "7ab4afcb-9124-11e9-9122-340286037753", "fill": "tonexty", "line": { "color": "rgb(180, 142, 31)" }, "mode": "lines", "name": "pred_dropout", "type": "scatter", "xsrc": "moiz_sakha:35:bf63ee", "ysrc": "moiz_sakha:35:205e3b", "fillcolor": "rgba(68, 68, 68, 0.3)" } ], "layout": { "title": "Location: Saarlouis_Scheid_Bahnhofstr_14, Date: 2017-12-10", "xaxis": { "title": "Time" }, "yaxis": { "title": "mpower (kW)" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~moiz_sakha", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/87.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-01 11:22:04", "mapbox_access_tokens": null, "has_password": null, "username": "moiz_sakha", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
