Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE3JTNBMDQlM0ExMi44NjExNjAlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBNTklM0E0OS4zMjgzNTglMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNyUzQTAzJTNBNDkuNDgzNDEyJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T17:03:49.483412Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~nehapspathak/2.embed", "fid": "nehapspathak:2", "filename": "active_users.html", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/nehapspathak:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/nehapspathak:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/nehapspathak:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/nehapspathak:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/nehapspathak:2", "plots": "https://api.plotly.com/v2/plots/nehapspathak:2", "parent": "https://api.plotly.com/v2/folders/home?user=nehapspathak" }, "owner": "nehapspathak", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Month of Creation", "views": 40, "web_url": "https://chart-studio.plotly.com/~nehapspathak/2/month-of-creation/", "world_readable": true, "date_modified": "2019-07-04T09:51:12.423Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~nehapspathak/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b5fc12e2-1cf6-4cb9-bb2b-46c9a59bc89b", "type": "bar", "xsrc": "nehapspathak:3:441ba9", "ysrc": "nehapspathak:3:0214cb", "marker": { "color": "rgb(158,202,225)" } } ], "layout": { "title": { "font": { "size": 18, "color": "#000000", "family": "Courier New, monospace" }, "text": "Month of Creation", "xref": "paper" }, "xaxis": { "title": { "font": { "size": 14, "color": "#000000", "family": "Courier New, monospace" }, "text": "Creation Time" }, "tickfont": { "size": 12, "color": "#000000", "family": "Courier New, monospace" }, "tickangle": 45, "automargin": true }, "yaxis": { "title": { "font": { "size": 14, "color": "#000000", "family": "Courier New, monospace" }, "text": "User Count" }, "tickfont": { "size": 12, "color": "#000000", "family": "Courier New, monospace" }, "automargin": true }, "legend": { "x": 0.5, "y": -0.25, "font": { "size": 12, "color": "#000", "family": "sans-serif" }, "bgcolor": "#E2E2E2", "traceorder": "normal", "bordercolor": "#FFFFFF", "borderwidth": 2, "orientation": "h" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~nehapspathak", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/8.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-05-22 16:32:31", "mapbox_access_tokens": null, "has_password": null, "username": "nehapspathak", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:03:30.248540Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srt7/22.embed", "fid": "srt7:22", "filename": "Corrosion1560791006.029569", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/srt7:22/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/srt7:22/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/srt7:22/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/srt7:22/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srt7:22", "plots": "https://api.plotly.com/v2/plots/srt7:22", "parent": "https://api.plotly.com/v2/folders/home?user=srt7" }, "owner": "srt7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~srt7/22/", "world_readable": true, "date_modified": "2019-06-17T17:03:30.265Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srt7/22/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": false, "caption": "", "figure": { "data": [ { "fill": "tozeroy", "line": { "color": "rgb(255, 0, 255)" }, "mode": "lines", "name": "Corrosion", "type": "scatter", "xsrc": "srt7:21:91d2e7", "ysrc": "srt7:21:027524", "fillcolor": "rgba(255, 0, 255, 0.5)" } ], "frames": [ { "data": [ { "xsrc": "srt7:21:91d2e7", "ysrc": "srt7:21:027524" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:bf0e39", "ysrc": "srt7:21:c50717" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:bf8e00", "ysrc": "srt7:21:4a1624" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:a82899", "ysrc": "srt7:21:3a0126" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:408f05", "ysrc": "srt7:21:6c077a" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:12f9a0", "ysrc": "srt7:21:6ff4b2" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:554c78", "ysrc": "srt7:21:dea0a8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:bab771", "ysrc": "srt7:21:4ed146" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:ffb5be", "ysrc": "srt7:21:7a8e0e" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:e39bff", "ysrc": "srt7:21:dc6bf8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:f157f3", "ysrc": "srt7:21:ffc138" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:b3eae0", "ysrc": "srt7:21:94cb42" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:1e567a", "ysrc": "srt7:21:5a5b11" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:09a26d", "ysrc": "srt7:21:31d93c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:e1bf9e", "ysrc": "srt7:21:498824" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:a00d39", "ysrc": "srt7:21:fd927e" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:0c0b5c", "ysrc": "srt7:21:e849dc" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:f4944e", "ysrc": "srt7:21:0b96ed" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:3d4f8d", "ysrc": "srt7:21:620889" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:01131b", "ysrc": "srt7:21:70f1c4" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:c0c938", "ysrc": "srt7:21:01edc0" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:868dba", "ysrc": "srt7:21:a725a1" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:600131", "ysrc": "srt7:21:18823f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:ea7a78", "ysrc": "srt7:21:4ffb82" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:269fda", "ysrc": "srt7:21:54d189" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:519d8f", "ysrc": "srt7:21:1ee680" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:b0f028", "ysrc": "srt7:21:55f914" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:4cc62a", "ysrc": "srt7:21:ce58cc" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:481454", "ysrc": "srt7:21:0f8bae" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:21:188374", "ysrc": "srt7:21:ed0b8a" } ], "traces": [ 0 ] } ], "layout": { "font": { "family": "Balto" }, "title": "Corrosion", "width": 800, "xaxis": { "range": [ 0, 40 ], "mirror": true, "nticks": 12, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false, "tickangle": -45 }, "yaxis": { "range": [ 0, 1500 ], "title": "$", "mirror": true, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "height": 400, "autosize": false, "showlegend": false, "updatemenus": [ { "x": 1.1, "y": 1, "pad": { "r": 10, "t": 0 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 50 }, "transition": { "duration": 0 }, "fromcurrent": true } ], "mode": "auto", "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "showactive": false } ] } }, "height": 400, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~srt7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 07:53:25", "mapbox_access_tokens": null, "has_password": null, "username": "srt7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:02:58.423145Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~rsm5909/231.embed", "fid": "rsm5909:231", "filename": "LimeLight refund total by Day", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/rsm5909/231/9_KEBH2AE29WSATK4R1G8HWXUM5B2MC8.png", "image_urls": { "default": "https://api.plotly.com/v2/files/rsm5909:231/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/rsm5909/231/8_EKYJCSXXN8CKSNBSVFHN488F1YLA1G.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/rsm5909/231/9_KEBH2AE29WSATK4R1G8HWXUM5B2MC8.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/rsm5909:231", "plots": "https://api.plotly.com/v2/plots/rsm5909:231", "parent": "https://api.plotly.com/v2/folders/home?user=rsm5909" }, "owner": "rsm5909", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Limelight Daily Refunds", "views": 1, "web_url": "https://chart-studio.plotly.com/~rsm5909/231/limelight-daily-refunds/", "world_readable": true, "date_modified": "2019-06-18T23:44:31.468Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~rsm5909/231/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c3fd096b-a496-4547-8399-ecbbe0c881db", "name": "Mother Democracy", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:6b7569" }, { "uid": "08a3f079-374d-4803-b7fe-38aaf7906b0d", "name": "National Self-Reliance Initiative", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:3f2a1c" }, { "uid": "4672f899-6f41-4095-ba85-033658e7953b", "name": "SoS Self Defense Tools", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:14ba4f" }, { "uid": "6710bebd-5c56-4c27-9bf5-e67eb2032c8c", "name": "Survival Constitution", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:7078ec" }, { "uid": "4e91e554-1e82-4241-8596-d6c2d8bce435", "name": "Survival Offers", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:a9320e" }, { "uid": "91afaea1-8046-46bc-8745-81b3a980e4ab", "name": "Tactical Independence", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:01bf52" }, { "uid": "4b916a14-dfa9-4169-803a-551817c2545e", "name": "Tactical Outdoors Gear", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:21171c" }, { "uid": "0ffa17cb-61e2-468d-a4ee-b6c07db030bb", "name": "KZ", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:7abce8" }, { "uid": "9af6dbeb-1e30-4dee-be7e-b6b070907d82", "name": "Steel River", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:7abce8" }, { "uid": "df25a4ca-5e4a-4a21-844a-49078ade3be3", "name": "Valley Food", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:7abce8" }, { "uid": "3ab13771-ea0c-4246-8bec-685197feaf64", "name": "Fortified", "type": "bar", "xsrc": "rsm5909:232:7fa0b2", "ysrc": "rsm5909:232:7abce8" } ], "layout": { "font": { "size": 13, "color": "rgb(0,0,0)", "family": "Roboto" }, "title": { "text": "Limelight Daily Refunds" }, "barmode": "stack", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~rsm5909", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/32.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-10-30 21:15:15", "mapbox_access_tokens": null, "has_password": null, "username": "rsm5909", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:02:42.195609Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srt7/20.embed", "fid": "srt7:20", "filename": "Corrosion1560790957.737633", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/srt7:20/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/srt7:20/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/srt7:20/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/srt7:20/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srt7:20", "plots": "https://api.plotly.com/v2/plots/srt7:20", "parent": "https://api.plotly.com/v2/folders/home?user=srt7" }, "owner": "srt7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~srt7/20/", "world_readable": true, "date_modified": "2019-06-17T17:02:42.206Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srt7/20/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": false, "caption": "", "figure": { "data": [ { "fill": "tozeroy", "line": { "color": "rgb(255, 255, 255)" }, "mode": "lines", "name": "Corrosion", "type": "scatter", "xsrc": "srt7:19:2b829f", "ysrc": "srt7:19:854f23", "fillcolor": "rgba(255, 255, 255, 0.5)" } ], "frames": [ { "data": [ { "xsrc": "srt7:19:2b829f", "ysrc": "srt7:19:854f23" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:e85d8a", "ysrc": "srt7:19:d60216" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:7d07ae", "ysrc": "srt7:19:684074" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:92ca79", "ysrc": "srt7:19:31273a" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:f828c3", "ysrc": "srt7:19:b6d289" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:7ea56e", "ysrc": "srt7:19:ed11f9" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:25759f", "ysrc": "srt7:19:ae5521" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:346eee", "ysrc": "srt7:19:12618e" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:7704fb", "ysrc": "srt7:19:967fdd" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:1ee7d8", "ysrc": "srt7:19:917436" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:98a8b3", "ysrc": "srt7:19:4e1985" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:bb48d8", "ysrc": "srt7:19:a64ec9" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:7ab112", "ysrc": "srt7:19:d651e1" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:5427c6", "ysrc": "srt7:19:a32b84" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:04ef84", "ysrc": "srt7:19:c68bac" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:efb8fb", "ysrc": "srt7:19:ca8475" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:4d25c8", "ysrc": "srt7:19:9ee731" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:7bc61b", "ysrc": "srt7:19:862ae7" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:877a30", "ysrc": "srt7:19:8ac7ad" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:0dfac2", "ysrc": "srt7:19:c2ad5b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:bd1c61", "ysrc": "srt7:19:a78a8c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:49401d", "ysrc": "srt7:19:47e8b8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:09a02f", "ysrc": "srt7:19:a8e9e7" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:3a341e", "ysrc": "srt7:19:975676" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:97439e", "ysrc": "srt7:19:25ba7f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:988e3a", "ysrc": "srt7:19:34b531" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:755d77", "ysrc": "srt7:19:bb42a4" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:281ddf", "ysrc": "srt7:19:d97c24" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:a0f3ca", "ysrc": "srt7:19:ed0fca" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:19:2d48db", "ysrc": "srt7:19:e9f184" } ], "traces": [ 0 ] } ], "layout": { "font": { "family": "Balto" }, "title": "Corrosion", "width": 800, "xaxis": { "range": [ 0, 40 ], "mirror": true, "nticks": 12, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false, "tickangle": -45 }, "yaxis": { "range": [ 0, 1500 ], "title": "$", "mirror": true, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "height": 400, "autosize": false, "showlegend": false, "updatemenus": [ { "x": 1.1, "y": 1, "pad": { "r": 10, "t": 0 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 50 }, "transition": { "duration": 0 }, "fromcurrent": true } ], "mode": "auto", "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "showactive": false } ] } }, "height": 400, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~srt7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 07:53:25", "mapbox_access_tokens": null, "has_password": null, "username": "srt7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:01:58.509554Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~willemvelden/0.embed", "fid": "willemvelden:0", "filename": "time-series-simple", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/willemvelden:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/willemvelden:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/willemvelden:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/willemvelden:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/willemvelden:0", "plots": "https://api.plotly.com/v2/plots/willemvelden:0", "parent": "https://api.plotly.com/v2/folders/home?user=willemvelden" }, "owner": "willemvelden", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~willemvelden/0/", "world_readable": true, "date_modified": "2019-06-17T17:02:02.240Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~willemvelden/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "c8104268-4c21-4f5b-b1c6-54fe2eb5cc96", "type": "scatter", "xsrc": "willemvelden:1:f27478", "ysrc": "willemvelden:1:4a24d2" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~willemvelden", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/80.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:58:15", "mapbox_access_tokens": null, "has_password": null, "username": "willemvelden", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:01:33.478141Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srt7/18.embed", "fid": "srt7:18", "filename": "Corrosion1560790889.230997", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/srt7:18/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/srt7/18/2_KND98GH0M6FD6M5UUVS8H6ZMZCWCF6.png", "block-thumb": "https://api.plotly.com/v2/files/srt7:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/srt7:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srt7:18", "plots": "https://api.plotly.com/v2/plots/srt7:18", "parent": "https://api.plotly.com/v2/folders/home?user=srt7" }, "owner": "srt7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 5, "web_url": "https://chart-studio.plotly.com/~srt7/18/", "world_readable": true, "date_modified": "2019-06-17T17:01:33.499Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srt7/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": false, "caption": "", "figure": { "data": [ { "fill": "tozeroy", "line": { "color": "rgb(255, 255, 255)" }, "mode": "lines", "name": "Corrosion", "type": "scatter", "xsrc": "srt7:17:4f9463", "ysrc": "srt7:17:b8ab7c", "fillcolor": "rgba(0, 0, 0, 0)" } ], "frames": [ { "data": [ { "xsrc": "srt7:17:4f9463", "ysrc": "srt7:17:b8ab7c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:150e52", "ysrc": "srt7:17:8480c4" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:d2edbc", "ysrc": "srt7:17:f5d7b0" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:0f114b", "ysrc": "srt7:17:213f05" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:247abb", "ysrc": "srt7:17:aef451" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:fc970f", "ysrc": "srt7:17:f347df" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:ded832", "ysrc": "srt7:17:86839d" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:81ca56", "ysrc": "srt7:17:fe6300" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:37d123", "ysrc": "srt7:17:8243d1" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:03ee8b", "ysrc": "srt7:17:9ae944" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:25e363", "ysrc": "srt7:17:5c76a8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:b7cf17", "ysrc": "srt7:17:e8c0e6" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:4e34a2", "ysrc": "srt7:17:6b0814" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:6b4a5e", "ysrc": "srt7:17:1ace13" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:2f2143", "ysrc": "srt7:17:91171d" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:fa63b9", "ysrc": "srt7:17:603391" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:fbc692", "ysrc": "srt7:17:2e0ceb" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:6608c6", "ysrc": "srt7:17:63ce24" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:90b7cd", "ysrc": "srt7:17:b9ceaf" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:9d3515", "ysrc": "srt7:17:2d75e2" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:955a43", "ysrc": "srt7:17:84b0d5" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:000949", "ysrc": "srt7:17:52b9a4" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:1c6c72", "ysrc": "srt7:17:2305fb" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:b17978", "ysrc": "srt7:17:cfa92d" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:bfaeea", "ysrc": "srt7:17:8d939c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:bd5a7b", "ysrc": "srt7:17:d55fdf" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:f5e327", "ysrc": "srt7:17:25820c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:bd5630", "ysrc": "srt7:17:e4022e" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:dbf8ff", "ysrc": "srt7:17:b06a63" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:17:608273", "ysrc": "srt7:17:878f23" } ], "traces": [ 0 ] } ], "layout": { "font": { "family": "Balto" }, "title": "Corrosion", "width": 800, "xaxis": { "range": [ 0, 40 ], "mirror": true, "nticks": 12, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false, "tickangle": -45 }, "yaxis": { "range": [ 0, 1500 ], "title": "$", "mirror": true, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "height": 400, "autosize": false, "showlegend": false, "updatemenus": [ { "x": 1.1, "y": 1, "pad": { "r": 10, "t": 0 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 50 }, "transition": { "duration": 0 }, "fromcurrent": true } ], "mode": "auto", "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "showactive": false } ] } }, "height": 400, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~srt7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 07:53:25", "mapbox_access_tokens": null, "has_password": null, "username": "srt7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:01:26.333247Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~neujeffski/0.embed", "fid": "neujeffski:0", "filename": "filling-interior-area", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/neujeffski:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/neujeffski:0/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/neujeffski:0/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/neujeffski:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/neujeffski:0", "plots": "https://api.plotly.com/v2/plots/neujeffski:0", "parent": "https://api.plotly.com/v2/folders/home?user=neujeffski" }, "owner": "neujeffski", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~neujeffski/0/", "world_readable": true, "date_modified": "2019-06-17T17:01:26.831Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~neujeffski/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b6497a0d-351c-4f2c-9800-a1921863e998", "line": { "color": "rgb(143, 19, 131)" }, "mode": "lines", "type": "scatter", "xsrc": "neujeffski:1:2b82ac", "ysrc": "neujeffski:1:d2fd07" }, { "uid": "5c59bb88-221d-4315-a681-3f4b5f6d0a25", "fill": "tonexty", "line": { "color": "rgb(143, 19, 131)" }, "mode": "lines", "type": "scatter", "xsrc": "neujeffski:1:2b82ac", "ysrc": "neujeffski:1:3a51f4" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~neujeffski", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:57:42", "mapbox_access_tokens": null, "has_password": null, "username": "neujeffski", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:01:22.310817Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ShubhamHAgrawal/36.embed", "fid": "ShubhamHAgrawal:36", "filename": "Box Size ", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ShubhamHAgrawal:36/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ShubhamHAgrawal:36/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ShubhamHAgrawal:36/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ShubhamHAgrawal:36/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ShubhamHAgrawal:36", "plots": "https://api.plotly.com/v2/plots/ShubhamHAgrawal:36", "parent": "https://api.plotly.com/v2/folders/home?user=ShubhamHAgrawal" }, "owner": "ShubhamHAgrawal", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Point & Figure Chart in Python", "views": 0, "web_url": "https://chart-studio.plotly.com/~ShubhamHAgrawal/36/point-figure-chart-in-python/", "world_readable": true, "date_modified": "2019-06-20T06:31:41.020Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ShubhamHAgrawal/36/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b72cdcea-e33a-4a6b-be39-ff12b244e6fd", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:f4746f", "ysrc": "ShubhamHAgrawal:37:dfbba0", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "09953d8b-3d46-45ae-9cd3-5c73efe8e876", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:3d2e61", "ysrc": "ShubhamHAgrawal:37:8a2751", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "22408b46-c4cf-44f3-b3fb-4291728ed8df", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:7c299e", "ysrc": "ShubhamHAgrawal:37:9784e2", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "59faced2-070d-4203-b954-fb205ac5ac46", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:f4746f", "ysrc": "ShubhamHAgrawal:37:d0ab33", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "82b2c5a4-0575-4d00-9d63-79c533bdbd6c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:67725d", "ysrc": "ShubhamHAgrawal:37:d79c82", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "19336d08-d77a-432d-95db-a9032fd48542", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a0b890", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "cf0e7962-d9ad-4d02-9b52-b6cc92cc803d", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b073cd", "ysrc": "ShubhamHAgrawal:37:f7ab4d", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "da91ffc1-42a2-49ee-939b-0ee2f16ffa5c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:364c84", "ysrc": "ShubhamHAgrawal:37:d79c82", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "3c48879d-3b73-4cb0-b679-1c82f36bfa82", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:dbc488", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "b295ff7e-4c8d-4a8d-9cad-1e6eb561b5e7", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:dbc488", "ysrc": "ShubhamHAgrawal:37:25f0b4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "a49e40d1-ecc7-461a-976c-075b5b3b65c0", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:dbc488", "ysrc": "ShubhamHAgrawal:37:2f6bfc", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "c30f6d3c-b7d3-4cd3-8d35-229c1ee2675b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:dbc488", "ysrc": "ShubhamHAgrawal:37:c38318", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "e72febb3-6077-4825-ac35-bd31bd4b5ddc", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a26ba3", "ysrc": "ShubhamHAgrawal:37:0e0d4e", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "62fa641e-0665-4308-a5d4-995cfd4fea8a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:c98402", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "a58def8e-303c-47d1-ba13-87ef96db8163", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:a43e67", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "636baf61-3da5-418b-94be-c1f0d7df8434", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:8410e3", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "0444f89a-acd9-4883-a2d3-277f9774a018", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:d0ab33", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "8d791bac-1e28-4f96-8a66-f3a7578abe1a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:a45614", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "b0de6d58-f245-48fd-bc42-7fd4c1f3e24a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:43881a", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "a8ae58cb-2493-4e69-857f-87d0538c3bde", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:8ebb12", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "517f5a86-82de-40ba-8886-92a9589cb60c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:2898f5", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "8e854ed4-3080-4a01-ad5b-49dedf53a71f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:4432d3", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "8cca1a1f-e7fb-487d-899b-dfb56aa21ea0", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:bfc0a3", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "fbd61236-15ea-4944-bd58-5ab524db0d12", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:8c6144", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "fa4ff8bf-47ff-410e-b89c-90b435865635", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:dda9f2", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "e66c9a0c-58e4-431c-bf65-6927bebdc56a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:b2c8e4", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "31cb6c1e-f6b8-4bb0-99ce-6319531656af", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:597ff2", "ysrc": "ShubhamHAgrawal:37:4ebab1", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "362c6a9f-4088-44f2-8c9f-e62c2d1c915c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61d4b7", "ysrc": "ShubhamHAgrawal:37:9ab138", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "c8437624-6e09-487a-bcb4-0357ac5ec959", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:bb98c3", "ysrc": "ShubhamHAgrawal:37:bfc0a3", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "75c71540-c533-4da7-bd11-61db3c651787", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:bb98c3", "ysrc": "ShubhamHAgrawal:37:4432d3", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "92384420-6704-48fb-bc57-fd099817804d", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:bb98c3", "ysrc": "ShubhamHAgrawal:37:2898f5", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "5b283784-44bf-4d5d-90a8-2b47e00c0a77", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:bb98c3", "ysrc": "ShubhamHAgrawal:37:8ebb12", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "7d3ab5d9-d704-4406-97ee-e6eea217f236", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a9cd3f", "ysrc": "ShubhamHAgrawal:37:3113b4", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "c9763b85-83cd-407f-b2a4-69a6d18a5b32", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:1af06d", "ysrc": "ShubhamHAgrawal:37:8c6144", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "ef0d20c0-ce82-4660-bac7-99170125b221", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:1af06d", "ysrc": "ShubhamHAgrawal:37:dda9f2", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "320aea42-139a-4349-a4f0-fa780c88c076", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:4c2953", "ysrc": "ShubhamHAgrawal:37:a4f403", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "089ce926-1f28-4abe-907e-e48abc6c710e", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:731605", "ysrc": "ShubhamHAgrawal:37:9ab138", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "d75b826b-3327-41e1-a229-64f4e7d8e3a1", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:8c19e8", "ysrc": "ShubhamHAgrawal:37:bfc0a3", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "e0c8b78a-e722-4a6a-b02c-af5c72afacc0", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:8c19e8", "ysrc": "ShubhamHAgrawal:37:4432d3", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "f8e553c0-70a0-4060-981a-8d30b0453f30", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:59cd21", "ysrc": "ShubhamHAgrawal:37:95505a", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "dd7bcd8b-c193-449c-9614-f41fda200964", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a34181", "ysrc": "ShubhamHAgrawal:37:f32a8a", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "f92c6dd1-a54a-41d1-8fbc-19e8c647cf1f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:9fe651", "ysrc": "ShubhamHAgrawal:37:2898f5", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "8d179903-4935-4bc1-b6d4-2b53c69c867b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:9fe651", "ysrc": "ShubhamHAgrawal:37:8ebb12", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "94669c36-718d-4c4d-9f36-4b504ed9de03", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:08c0b6", "ysrc": "ShubhamHAgrawal:37:3113b4", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "b6a511f3-8554-4ab3-964b-bbdc78d4cf8b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b8dd1f", "ysrc": "ShubhamHAgrawal:37:8c6144", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "4c7594cc-d953-4e4b-af79-9d5c7073311b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a97b0f", "ysrc": "ShubhamHAgrawal:37:ba4960", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "501a260d-b23b-48b7-8c5c-51a56560ec6a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:44ff78", "ysrc": "ShubhamHAgrawal:37:8ebb12", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "40c2f70b-e892-4a18-8ec0-9a0b160a040f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:32a8be", "ysrc": "ShubhamHAgrawal:37:aa3999", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "aa3d3571-86f8-4588-81a1-5dcb360ccef8", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:44ff78", "ysrc": "ShubhamHAgrawal:37:d0ab33", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "df653628-0c7c-44d4-8be7-62114092f1f8", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:44ff78", "ysrc": "ShubhamHAgrawal:37:8410e3", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "8daf57b2-1795-44ec-925c-738e92be2cf2", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:44ff78", "ysrc": "ShubhamHAgrawal:37:a43e67", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "d2defab9-010b-4c52-ba29-572e51197431", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ba0ec5", "ysrc": "ShubhamHAgrawal:37:019e7e", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "242b9614-86ed-4186-944e-d1484387e99a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:9d84b5", "ysrc": "ShubhamHAgrawal:37:7944fa", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "a645f056-4e3f-4504-ae9a-ff2ef9de7669", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b888a0", "ysrc": "ShubhamHAgrawal:37:c98402", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "b6d3f0ec-0999-4081-bcd6-f0d70ee4d742", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b888a0", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "f7f4f3f5-54af-42ae-96d0-fe073f12ecee", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b888a0", "ysrc": "ShubhamHAgrawal:37:25f0b4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "18771c8b-2217-4b14-8c83-bef81e114b7c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b888a0", "ysrc": "ShubhamHAgrawal:37:2f6bfc", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "681bdfa9-014f-4415-8bd5-273464feee05", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b888a0", "ysrc": "ShubhamHAgrawal:37:c38318", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "deea6745-db27-4608-bb8d-0425f5296d74", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:16550a", "ysrc": "ShubhamHAgrawal:37:0e0d4e", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "36f01a84-05f4-4ed8-bb43-0ae62b3e062b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:8570d8", "ysrc": "ShubhamHAgrawal:37:71a555", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "4f687867-bf29-4ef4-a343-370e5fdc583b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:400e5c", "ysrc": "ShubhamHAgrawal:37:5d0d7c", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "03b53cd2-6fdb-4966-a7a9-a2fa88afb872", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:da8389", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "2b02086d-547c-4ece-93f1-021c7a280865", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "48bedb1e-9cfc-4ea5-bd7b-f41c9497a909", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "c4684f7e-da12-4b64-8667-981ce9e57a08", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:98b135", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "bed132cd-90cb-4bd3-ad14-bbf5d74bb5c5", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:10391b", "ysrc": "ShubhamHAgrawal:37:b19665", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "e3ab74a9-842b-4c19-aff7-547337350acd", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:d9c758", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "b30044b1-8a35-4447-b1be-406a78a487ed", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:5e139c", "ysrc": "ShubhamHAgrawal:37:3123ac", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "d0633088-71e7-4a84-a187-8798890135dc", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:10391b", "ysrc": "ShubhamHAgrawal:37:b6c411", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "b8ce1b42-bdc9-4b59-97de-82aa1bf357fd", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a5333d", "ysrc": "ShubhamHAgrawal:37:b24f1a", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "d5540b70-1e01-47c4-ab1a-57c1b5f3cd6d", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:faa1a0", "ysrc": "ShubhamHAgrawal:37:126d21", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "ef3128c6-6cfc-4405-bbc2-27cabf717a33", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:14b6a6", "ysrc": "ShubhamHAgrawal:37:141780", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "5d09cd64-a4a4-4319-acbb-07fd172915e4", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:56fced", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "b63e18aa-d2a3-4efe-9a46-492e8a812941", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:14b6a6", "ysrc": "ShubhamHAgrawal:37:bf32c9", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "18c4c42c-4d87-43c8-909b-9aa8b314aea7", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:483bab", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "5b7f3bf5-be49-4028-8754-5270a0dcc716", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:278568", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "5bd43f47-1637-4725-9ee1-26a7061aa597", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:d9c758", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "be5b6df8-aac2-4722-b68f-ab70fdadd32a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:2b4a74", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "06df0ca7-5e70-4476-a163-4876c45da896", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:2c56c4", "ysrc": "ShubhamHAgrawal:37:7c9198", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "8573aa4d-256e-4ebc-9a26-6f13a9d44bcf", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:295dd7", "ysrc": "ShubhamHAgrawal:37:0d9f89", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "694805f0-6946-432a-9c9c-355035118cd9", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:660b9b", "ysrc": "ShubhamHAgrawal:37:523264", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "62b1358c-3852-4846-8019-a0fac9f18a44", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ea60c3", "ysrc": "ShubhamHAgrawal:37:583ff4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "62a28d72-ee06-4205-8a76-320ced7be7a7", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:876aff", "ysrc": "ShubhamHAgrawal:37:38cbdc", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "f38bf013-5dee-45cb-96a0-1129dd81e6f5", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:d76ddf", "ysrc": "ShubhamHAgrawal:37:d9c758", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "5496ae29-e1e6-4204-886a-e6fdb4bad58f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:d76ddf", "ysrc": "ShubhamHAgrawal:37:2b4a74", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "c8ae0e1c-33ff-44f6-9f6b-dd86bb46556f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:d76ddf", "ysrc": "ShubhamHAgrawal:37:7c9198", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "97823739-50f1-4aa6-b35f-dc98ed3e1011", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:d76ddf", "ysrc": "ShubhamHAgrawal:37:98b135", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "a5f16b15-5cf5-433a-aec6-209d60b1de17", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:d76ddf", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "fabfb8ad-66dc-4cd0-870c-3b5fc5a4e6c6", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ebd988", "ysrc": "ShubhamHAgrawal:37:6113f4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "50dcd441-241f-443f-8dec-a56ca24a1c06", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:46ca3e", "ysrc": "ShubhamHAgrawal:37:d9c758", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "b55bcb62-b084-42b1-8f70-b644c1b046b2", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:1f59e6", "ysrc": "ShubhamHAgrawal:37:2e7044", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "1f648d5b-f8fc-4ecb-baeb-88fbbb32bce4", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:45b83a", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "20d1eb1b-3dda-4ff7-8848-e3aaabaf192f", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:45b83a", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "276f5975-6472-4da5-b00e-4a8ada2f9c81", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:45b83a", "ysrc": "ShubhamHAgrawal:37:da8389", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "11b6e2e6-663d-49d1-8c6f-c1dffa0662a4", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:45b83a", "ysrc": "ShubhamHAgrawal:37:483700", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "60c62f77-756d-4120-8bb2-c2b76404588b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:45b83a", "ysrc": "ShubhamHAgrawal:37:ce7565", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "d93d4a12-c532-4b79-863b-c8aaa69973bb", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ee6cdb", "ysrc": "ShubhamHAgrawal:37:2e4713", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "a59e3a79-aaf7-44e3-981b-b1443f674322", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:430b6d", "ysrc": "ShubhamHAgrawal:37:9b8e63", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "2879f22b-d167-4c64-8cd9-7e8eedc8c66c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ed6198", "ysrc": "ShubhamHAgrawal:37:da8389", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "15be7bfe-ec53-4aa8-8286-8b6ee27b2e16", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ed6198", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "90d8d70f-fd9d-4dc1-a607-4ad5bab14947", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b9e70a", "ysrc": "ShubhamHAgrawal:37:f7cfa1", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "689a7c2d-b530-4b09-a379-9475fce406a8", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:4a6c4d", "ysrc": "ShubhamHAgrawal:37:6e845f", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "527e0aed-0548-4348-ac1f-4454d5b2a7d3", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:4a6c4d", "ysrc": "ShubhamHAgrawal:37:dfbba0", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "06886675-1651-498d-9959-72d1b2ee6dfd", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:4a6c4d", "ysrc": "ShubhamHAgrawal:37:c38318", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "69e0738c-6ba2-4295-b098-b85a7d1837b5", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:4a6c4d", "ysrc": "ShubhamHAgrawal:37:2f6bfc", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "f74c3997-fdba-4829-afc3-b85a15ac4e84", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:9ed147", "ysrc": "ShubhamHAgrawal:37:0bdd1e", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "83a8d829-d17f-4f26-91be-9bff1a31ff71", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:aa9acb", "ysrc": "ShubhamHAgrawal:37:6c4a2b", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "f5cda05e-727d-4c6f-83a1-2b36641937f4", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a4cbc8", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "84f9b8d3-feb7-4f4d-b8fa-f084ce162f0b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a4cbc8", "ysrc": "ShubhamHAgrawal:37:25f0b4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "c74aa574-91fb-448a-a826-6f21758796f2", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:a4cbc8", "ysrc": "ShubhamHAgrawal:37:2f6bfc", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "9b569b03-f8b5-4121-9f68-4ff796eb5a27", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:1a328e", "ysrc": "ShubhamHAgrawal:37:1e8260", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "21e3a437-6a6a-4977-90de-4b0fd28cb1f7", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:6a2ed2", "ysrc": "ShubhamHAgrawal:37:a43e67", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "ed472195-8862-489a-95e7-98df11d7021a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:002206", "ysrc": "ShubhamHAgrawal:37:e90ea6", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "1f89ad1c-45ef-4334-9f3d-b431b34750fe", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ebd0d6", "ysrc": "ShubhamHAgrawal:37:d79c82", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "026a8934-4de3-41c8-a60e-c0afa5a0a4d4", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:3121b4", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "9134af92-709e-4453-8bf7-00e8dc65c2b9", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:3121b4", "ysrc": "ShubhamHAgrawal:37:25f0b4", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "4ac5474a-764c-4540-b761-813b95cd3bb9", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:3121b4", "ysrc": "ShubhamHAgrawal:37:2f6bfc", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "445b39ed-9a6d-42f3-974f-d5d1790e8934", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:40361f", "ysrc": "ShubhamHAgrawal:37:1e8260", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "59f21f01-61c5-4185-8aec-1fad71c667ae", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:b1009b", "ysrc": "ShubhamHAgrawal:37:a43e67", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "5f34d197-f131-44e6-b758-77335ed6fb53", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:92f7eb", "ysrc": "ShubhamHAgrawal:37:0eb2fc", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "ac59a507-7232-4dba-9108-b3da31d29800", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:55a1b5", "ysrc": "ShubhamHAgrawal:37:0a997f", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "01e4370b-e734-452f-8815-bf4641496c0b", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ac29d5", "ysrc": "ShubhamHAgrawal:37:6b3e5e", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "bde6bd34-0ed5-4e84-a2ed-67e26021a820", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ac29d5", "ysrc": "ShubhamHAgrawal:37:c98402", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "d16a6078-fc6b-4a4f-a42d-99d10650c136", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:c62af1", "ysrc": "ShubhamHAgrawal:37:b284a7", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "036f578a-26fe-4e8c-8cce-d9477918b715", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:c38318", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "91a7aabf-915a-4c79-b13f-c41154f693d7", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:dfbba0", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "d3db29b5-0d2b-40c5-8176-db4e0a9212fa", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:6e845f", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "82737a5f-2f00-4e72-a8e9-7355ff3ea134", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:ce7565", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "a4951852-74e7-4dbb-bf73-8651e6f8501e", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:483700", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "9c0a1c54-b069-4557-8350-e79f2b33994a", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:da8389", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "9483a573-262b-4827-8fd8-3a79f9884452", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "895e887c-67b3-4b82-8987-ac4f13e5e4d3", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:253d7c", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "0171c4ce-e1f9-42a3-a794-e267fa584851", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:19532e", "ysrc": "ShubhamHAgrawal:37:b2fd8a", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "9cc9e5a3-89b6-417e-8a0a-ff04afea6227", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:67d418", "ysrc": "ShubhamHAgrawal:37:3180d9", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "04833002-556d-421c-ba6d-743fbaea2567", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "c5ad7d45-983f-42c6-ad9e-71c69cd38667", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "01150c92-2e7d-42c7-a38a-549b5d745ac0", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:98b135", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "32ca78c2-5357-4680-81c5-a0c5b27b7b4e", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:7c9198", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "6da1cb71-f498-48d4-8495-375ef410d692", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:2b4a74", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "700bdd71-dafc-40ca-8505-9a77c1f0ba94", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:61f6e6", "ysrc": "ShubhamHAgrawal:37:d9c758", "marker": { "size": 5, "color": "rgb(255,0,0)", "symbol": "circle-open" } }, { "uid": "658dfd40-b8cd-4ee6-9ae8-5290f01f50aa", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:432a14", "ysrc": "ShubhamHAgrawal:37:2e7044", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "7fe27dc2-c042-4e02-b043-6e3a8c8f280c", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ade876", "ysrc": "ShubhamHAgrawal:37:fb1071", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "c4760a10-9459-44fc-92f7-268701ed7db1", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ade876", "ysrc": "ShubhamHAgrawal:37:f92db0", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "a39d9b85-9116-4ba7-bc2a-fcb1c98e91c5", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ade876", "ysrc": "ShubhamHAgrawal:37:da8389", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } }, { "uid": "c2debaa3-a511-4320-8767-de57e61332b2", "mode": "markers", "type": "scatter", "xsrc": "ShubhamHAgrawal:37:ade876", "ysrc": "ShubhamHAgrawal:37:483700", "marker": { "size": 5, "color": "rgb(0,128,0)", "symbol": "x" } } ], "layout": { "title": { "text": "Point & Figure Chart in Python" }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ShubhamHAgrawal", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/87.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-06-16 16:52:53", "mapbox_access_tokens": null, "has_password": null, "username": "ShubhamHAgrawal", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T17:01:15.423431Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ccpagencia/1.embed", "fid": "ccpagencia:1", "filename": "COBERTURA MÍDIA EXTERIOR", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ccpagencia:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ccpagencia:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ccpagencia/1/8_VUDJ0PZLX4XRUN1GB5CD2B8KQL6QKY.png", "list-thumb": "https://api.plotly.com/v2/files/ccpagencia:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ccpagencia:1", "plots": "https://api.plotly.com/v2/plots/ccpagencia:1", "parent": "https://api.plotly.com/v2/folders/home?user=ccpagencia" }, "owner": "ccpagencia", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~ccpagencia/1/", "world_readable": true, "date_modified": "2019-06-17T17:01:15.440Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ccpagencia/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "bar", "xsrc": "ccpagencia:0:1ad617", "xaxis": "x", "orientation": "h" }, { "type": "bar", "xsrc": "ccpagencia:0:7551d5", "orientation": "h" } ], "frames": [], "layout": { "xaxis": { "range": [ -0.9362298528381219, -0.28871758934828307 ], "title": { "text": "Click to enter X axis title" }, "autorange": false }, "yaxis": { "range": [ 3.1107382550335565, 3.6560402684563753 ], "autorange": false }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ccpagencia", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:51:17", "mapbox_access_tokens": null, "has_password": null, "username": "ccpagencia", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:59:49.328358Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~remmelh/1.embed", "fid": "remmelh:1", "filename": "volcano1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/remmelh:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/remmelh/1/2_EP3HICA04RVFEE9J1VA16WQ0R59E94.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/remmelh/1/8_DQ66SY1RFDXZ43QABG090BEKTXKKXH.png", "list-thumb": "https://api.plotly.com/v2/files/remmelh:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/remmelh:1", "plots": "https://api.plotly.com/v2/plots/remmelh:1", "parent": "https://api.plotly.com/v2/folders/home?user=remmelh" }, "owner": "remmelh", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 12, "web_url": "https://chart-studio.plotly.com/~remmelh/1/", "world_readable": true, "date_modified": "2019-06-17T16:59:49.357Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~remmelh/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "surface", "zsrc": "remmelh:0:0fbb08", "frame": null, "colorbar": { "y": 1, "len": 0.5, "title": "volcano", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666666", "rgba(70,19,97,1)" ], [ "0.0833333333333334", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666666", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] } ], "layout": { "scene": { "zaxis": { "title": "volcano" } }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~remmelh", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/90.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:56:11", "mapbox_access_tokens": null, "has_password": null, "username": "remmelh", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
