Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBNTMlM0EwNy45MjQ0NzUlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBNTAlM0ExNC4xOTMyNjMlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNiUzQTUyJTNBMzcuMDE0NjQ5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T16:52:37.014649Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fsdfsdfds/6.embed", "fid": "fsdfsdfds:6", "filename": "DB_table", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/fsdfsdfds:6/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/fsdfsdfds/6/2_ANPDJFYFHS8C2JSGAWG18E46613K4J.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fsdfsdfds/6/8_CJI4E5DU57TFLELGOVFNGZPX855R5Q.png", "list-thumb": "https://api.plotly.com/v2/files/fsdfsdfds:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fsdfsdfds:6", "plots": "https://api.plotly.com/v2/plots/fsdfsdfds:6", "parent": "https://api.plotly.com/v2/folders/home?user=fsdfsdfds" }, "owner": "fsdfsdfds", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 6, "web_url": "https://chart-studio.plotly.com/~fsdfsdfds/6/", "world_readable": true, "date_modified": "2019-06-17T16:52:37.456Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fsdfsdfds/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "1cd63d3a-9659-4bd5-889c-cf494f7800ab", "type": "table", "cells": { "fill": { "colorsrc": "fsdfsdfds:7:22eeb0" }, "font": { "size": 12, "color": "#506784" }, "line": { "color": "#506784" }, "height": 30, "alignsrc": "fsdfsdfds:7:80bc55", "valuessrc": "fsdfsdfds:7:-80bc55,22eeb0,7ef96c" }, "header": { "fill": { "color": "#119DFF" }, "font": { "size": 12, "color": "white" }, "line": { "color": "#506784" }, "height": 40, "alignsrc": "fsdfsdfds:7:80bc55", "valuessrc": "fsdfsdfds:7:7ef96c" } } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fsdfsdfds", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "plotme", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-02 11:09:08", "mapbox_access_tokens": null, "has_password": null, "username": "fsdfsdfds", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:52:32.861565Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srt7/10.embed", "fid": "srt7:10", "filename": "Corrosion1560790348.373002", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/srt7:10/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/srt7:10/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/srt7:10/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/srt7:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srt7:10", "plots": "https://api.plotly.com/v2/plots/srt7:10", "parent": "https://api.plotly.com/v2/folders/home?user=srt7" }, "owner": "srt7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~srt7/10/", "world_readable": true, "date_modified": "2019-06-17T16:52:32.919Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srt7/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": false, "caption": "", "figure": { "data": [ { "fill": "tozeroy", "line": { "color": "rgb(114, 186, 59)" }, "mode": "lines", "name": "Corrosion", "type": "scatter", "xsrc": "srt7:9:619a9c", "ysrc": "srt7:9:588dbe", "fillcolor": "rgba(114, 186, 59, 0.5)" } ], "frames": [ { "data": [ { "xsrc": "srt7:9:619a9c", "ysrc": "srt7:9:588dbe" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:58f3c6", "ysrc": "srt7:9:4d7237" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:9edeec", "ysrc": "srt7:9:8193f3" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:956618", "ysrc": "srt7:9:16115c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:d85a0b", "ysrc": "srt7:9:373917" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:18a6ef", "ysrc": "srt7:9:bcbb51" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:a7e768", "ysrc": "srt7:9:b8f7e8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:31e7e4", "ysrc": "srt7:9:ee7d33" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:00bcf3", "ysrc": "srt7:9:bfd9cb" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:6882ff", "ysrc": "srt7:9:7c980b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:b38ef3", "ysrc": "srt7:9:48024b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:d5e4df", "ysrc": "srt7:9:3c9a41" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:80d491", "ysrc": "srt7:9:c06ee7" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:e113e9", "ysrc": "srt7:9:e41a82" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:adea4c", "ysrc": "srt7:9:a81ed9" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:1f9677", "ysrc": "srt7:9:785b92" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:910b42", "ysrc": "srt7:9:f0a416" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:b20a8b", "ysrc": "srt7:9:4da49c" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:31ed8f", "ysrc": "srt7:9:02f1c1" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:b8b8d5", "ysrc": "srt7:9:c464f6" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:1e1feb", "ysrc": "srt7:9:caa581" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:fbc1b9", "ysrc": "srt7:9:c75d3f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:eb1829", "ysrc": "srt7:9:a0cd8f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:3ed3c7", "ysrc": "srt7:9:6a91ee" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:d214ac", "ysrc": "srt7:9:a4f044" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:63e3fb", "ysrc": "srt7:9:8c1f5b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:adb097", "ysrc": "srt7:9:a0a9d8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:f04948", "ysrc": "srt7:9:f05364" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:cd46b4", "ysrc": "srt7:9:ecb33f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:9:f4633f", "ysrc": "srt7:9:f34454" } ], "traces": [ 0 ] } ], "layout": { "font": { "family": "Balto" }, "title": "Corrosion", "width": 800, "xaxis": { "range": [ 0, 1500 ], "mirror": true, "nticks": 12, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false, "tickangle": -45 }, "yaxis": { "range": [ 0, 40 ], "title": "$", "mirror": true, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "height": 400, "autosize": false, "showlegend": false, "updatemenus": [ { "x": 1.1, "y": 1, "pad": { "r": 10, "t": 0 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 50 }, "transition": { "duration": 0 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "showactive": false } ] } }, "height": 400, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~srt7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 07:53:25", "mapbox_access_tokens": null, "has_password": null, "username": "srt7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:52:27.782914Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~kylejscampbell/6.embed", "fid": "kylejscampbell:6", "filename": "Point Like with Ring", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/kylejscampbell:6/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/kylejscampbell:6/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/kylejscampbell:6/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/kylejscampbell:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/kylejscampbell:6", "plots": "https://api.plotly.com/v2/plots/kylejscampbell:6", "parent": "https://api.plotly.com/v2/folders/home?user=kylejscampbell" }, "owner": "kylejscampbell", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~kylejscampbell/6/", "world_readable": true, "date_modified": "2019-06-17T17:00:42.588Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~kylejscampbell/6/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid" }, "mode": "markers", "type": "contour", "xsrc": "kylejscampbell:5:0fa40d", "ysrc": "kylejscampbell:5:be43ed", "zsrc": "kylejscampbell:5:fd7042", "contours": { "end": 3.2, "size": 0.05, "start": 1, "coloring": "heatmap" }, "colorscale": [ [ 0, "#fff5eb" ], [ 0.125, "#fee6ce" ], [ 0.25, "#fdd0a2" ], [ 0.375, "#fdae6b" ], [ 0.5, "#fd8d3c" ], [ 0.625, "#f16913" ], [ 0.75, "#d94801" ], [ 0.875, "#a63603" ], [ 1, "#7f2704" ] ], "autocontour": false, "autocolorscale": false } ], "frames": [], "layout": { "title": { "text": "Electric Potential with Point Like Terminals and a Faraday Cage" }, "xaxis": { "type": "linear", "range": [ 1, 9 ], "title": { "text": "x Position" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 1, 9 ], "title": { "text": "y Position" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~kylejscampbell", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/36.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 15:53:51", "mapbox_access_tokens": null, "has_password": null, "username": "kylejscampbell", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:52:19.951444Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Ethan.sun/16.embed", "fid": "Ethan.sun:16", "filename": "xgb_importance", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Ethan.sun:16/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Ethan.sun:16/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/Ethan.sun:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/Ethan.sun:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Ethan.sun:16", "plots": "https://api.plotly.com/v2/plots/Ethan.sun:16", "parent": "https://api.plotly.com/v2/folders/home?user=Ethan.sun" }, "owner": "Ethan.sun", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Ethan.sun/16/", "world_readable": true, "date_modified": "2019-06-17T20:10:29.552Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Ethan.sun/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3fcf91c5-8c54-45a9-90e7-2c6b2bc15b9c", "type": "bar", "xsrc": "Ethan.sun:17:e26e1a", "ysrc": "Ethan.sun:17:11118e" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Ethan.sun", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 15:22:51", "mapbox_access_tokens": null, "has_password": null, "username": "Ethan.sun", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:52:16.917681Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~michaelbabyn/980.embed", "fid": "michaelbabyn:980", "filename": "Plot 980", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/980/9_3YHZ1QFYV4LOM4XI564K2ADPLKOYGH.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/980/2_MP75EA505MWHU3GSUHIX5NQUADZI32.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/980/8_G2GO2PI8DHEBVF2YBSSWQEJ54G2UYR.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/980/9_3YHZ1QFYV4LOM4XI564K2ADPLKOYGH.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/michaelbabyn:980", "plots": "https://api.plotly.com/v2/plots/michaelbabyn:980", "parent": "https://api.plotly.com/v2/folders/home?user=michaelbabyn" }, "owner": "michaelbabyn", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~michaelbabyn/980/", "world_readable": true, "date_modified": "2019-06-17T16:52:16.942Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~michaelbabyn/980/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "base": 1000, "type": "waterfall", "xsrc": "michaelbabyn:979:55ff28", "ysrc": "michaelbabyn:979:57fa2e", "measuresrc": "michaelbabyn:979:fcda3e" }, { "base": 1000, "type": "waterfall", "xsrc": "michaelbabyn:979:730ec4", "ysrc": "michaelbabyn:979:e6380b", "measuresrc": "michaelbabyn:979:701d53" } ], "layout": { "xaxis": { "ticks": "outside", "title": { "text": "MULTI-CATEGORY" }, "tickfont": { "size": 16 } }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } } }, "waterfallgroupgap": 0.5 } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~michaelbabyn", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/74.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-07-09 16:52:34", "mapbox_access_tokens": null, "has_password": null, "username": "michaelbabyn", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:51:37.953889Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~haitm7/12.embed", "fid": "haitm7:12", "filename": "simple-node-example", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/haitm7:12/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/haitm7:12/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/haitm7:12/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/haitm7:12/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/haitm7:12", "plots": "https://api.plotly.com/v2/plots/haitm7:12", "parent": "https://api.plotly.com/v2/folders/home?user=haitm7" }, "owner": "haitm7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~haitm7/12/", "world_readable": true, "date_modified": "2019-06-18T02:03:04.401Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~haitm7/12/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "bar", "xsrc": "haitm7:13:69d388", "ysrc": "haitm7:13:7f641a" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~haitm7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/34.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-01-11 05:43:58", "mapbox_access_tokens": null, "has_password": null, "username": "haitm7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:51:37.119854Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~codybarney/33.embed", "fid": "codybarney:33", "filename": "West Africa Gold Mines", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/codybarney:33/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/codybarney:33/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/codybarney/33/8_0ZL52KJVHKR71XLNYXNAJ3N6SIQPYV.png", "list-thumb": "https://api.plotly.com/v2/files/codybarney:33/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/codybarney:33", "plots": "https://api.plotly.com/v2/plots/codybarney:33", "parent": "https://api.plotly.com/v2/folders/home?user=codybarney" }, "owner": "codybarney", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 20, "web_url": "https://chart-studio.plotly.com/~codybarney/33/", "world_readable": true, "date_modified": "2019-07-09T18:10:16.230Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~codybarney/33/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "codybarney:32:5eda5f", "ysrc": "codybarney:32:020927", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 2, "cmin": 0, "line": { "cmax": 2, "cmin": 0, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "codybarney:32:14a0a6", "showscale": false, "colorscale": [ [ "0", "rgba(228,26,28,1)" ], [ "0.0416666666666667", "rgba(195,80,81,1)" ], [ "0.0833333333333333", "rgba(150,106,132,1)" ], [ "0.125", "rgba(55,126,184,1)" ], [ "0.166666666666667", "rgba(78,142,150,1)" ], [ "0.208333333333333", "rgba(83,158,114,1)" ], [ "0.25", "rgba(77,175,74,1)" ], [ "0.291666666666667", "rgba(117,147,108,1)" ], [ "0.333333333333333", "rgba(139,116,136,1)" ], [ "0.375", "rgba(152,78,163,1)" ], [ "0.416666666666667", "rgba(194,92,122,1)" ], [ "0.458333333333333", "rgba(227,109,79,1)" ], [ "0.5", "rgba(255,127,0,1)" ], [ "0.541666666666667", "rgba(255,172,18,1)" ], [ "0.583333333333333", "rgba(255,214,35,1)" ], [ "0.625", "rgba(255,255,51,1)" ], [ "0.666666666666667", "rgba(227,197,50,1)" ], [ "0.708333333333333", "rgba(197,141,46,1)" ], [ "0.75", "rgba(166,86,40,1)" ], [ "0.791666666666667", "rgba(195,100,90,1)" ], [ "0.833333333333333", "rgba(222,114,140,1)" ], [ "0.875", "rgba(247,129,191,1)" ], [ "0.916666666666667", "rgba(217,140,178,1)" ], [ "0.958333333333333", "rgba(186,148,166,1)" ], [ "1", "rgba(153,153,153,1)" ] ] }, "opacity": 0.8, "sizesrc": "codybarney:32:5d9d95", "colorbar": { "title": "marketCapRef", "ticklen": 2 }, "colorsrc": "codybarney:32:9f10ac", "sizemode": "diameter", "showscale": false, "colorscale": [ [ "0", "rgba(228,26,28,1)" ], [ "0.0416666666666667", "rgba(195,80,81,1)" ], [ "0.0833333333333333", "rgba(150,106,132,1)" ], [ "0.125", "rgba(55,126,184,1)" ], [ "0.166666666666667", "rgba(78,142,150,1)" ], [ "0.208333333333333", "rgba(83,158,114,1)" ], [ "0.25", "rgba(77,175,74,1)" ], [ "0.291666666666667", "rgba(117,147,108,1)" ], [ "0.333333333333333", "rgba(139,116,136,1)" ], [ "0.375", "rgba(152,78,163,1)" ], [ "0.416666666666667", "rgba(194,92,122,1)" ], [ "0.458333333333333", "rgba(227,109,79,1)" ], [ "0.5", "rgba(255,127,0,1)" ], [ "0.541666666666667", "rgba(255,172,18,1)" ], [ "0.583333333333333", "rgba(255,214,35,1)" ], [ "0.625", "rgba(255,255,51,1)" ], [ "0.666666666666667", "rgba(227,197,50,1)" ], [ "0.708333333333333", "rgba(197,141,46,1)" ], [ "0.75", "rgba(166,86,40,1)" ], [ "0.791666666666667", "rgba(195,100,90,1)" ], [ "0.833333333333333", "rgba(222,114,140,1)" ], [ "0.875", "rgba(247,129,191,1)" ], [ "0.916666666666667", "rgba(217,140,178,1)" ], [ "0.958333333333333", "rgba(186,148,166,1)" ], [ "1", "rgba(153,153,153,1)" ] ] }, "textsrc": "codybarney:32:279ca5", "hoverlabel": "text", "hovertextsrc": "codybarney:32:cbb6e7" }, { "mode": "markers", "type": "scatter", "xsrc": "codybarney:32:14efad", "ysrc": "codybarney:32:7d266f", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 2, "cmin": 0, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "marketCapRef", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "codybarney:32:a041b5", "showscale": false, "colorscale": [ [ "0", "rgba(228,26,28,1)" ], [ "0.0416666666666667", "rgba(195,80,81,1)" ], [ "0.0833333333333333", "rgba(150,106,132,1)" ], [ "0.125", "rgba(55,126,184,1)" ], [ "0.166666666666667", "rgba(78,142,150,1)" ], [ "0.208333333333333", "rgba(83,158,114,1)" ], [ "0.25", "rgba(77,175,74,1)" ], [ "0.291666666666667", "rgba(117,147,108,1)" ], [ "0.333333333333333", "rgba(139,116,136,1)" ], [ "0.375", "rgba(152,78,163,1)" ], [ "0.416666666666667", "rgba(194,92,122,1)" ], [ "0.458333333333333", "rgba(227,109,79,1)" ], [ "0.5", "rgba(255,127,0,1)" ], [ "0.541666666666667", "rgba(255,172,18,1)" ], [ "0.583333333333333", "rgba(255,214,35,1)" ], [ "0.625", "rgba(255,255,51,1)" ], [ "0.666666666666667", "rgba(227,197,50,1)" ], [ "0.708333333333333", "rgba(197,141,46,1)" ], [ "0.75", "rgba(166,86,40,1)" ], [ "0.791666666666667", "rgba(195,100,90,1)" ], [ "0.833333333333333", "rgba(222,114,140,1)" ], [ "0.875", "rgba(247,129,191,1)" ], [ "0.916666666666667", "rgba(217,140,178,1)" ], [ "0.958333333333333", "rgba(186,148,166,1)" ], [ "1", "rgba(153,153,153,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "layout": { "title": "West Africa Gold Mines", "xaxis": { "title": "Ore Tonnage, Reserves (Mt)", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "Ore Grade, Reserves (g/t)", "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~codybarney", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/85.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-05 17:38:33", "mapbox_access_tokens": null, "has_password": null, "username": "codybarney", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:50:57.703878Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ChrisTDick/140.embed", "fid": "ChrisTDick:140", "filename": "plot from API (10)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ChrisTDick:140/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ChrisTDick:140/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ChrisTDick:140/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ChrisTDick:140/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ChrisTDick:140", "plots": "https://api.plotly.com/v2/plots/ChrisTDick:140", "parent": "https://api.plotly.com/v2/folders/home?user=ChrisTDick" }, "owner": "ChrisTDick", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Entity Vectors", "views": 0, "web_url": "https://chart-studio.plotly.com/~ChrisTDick/140/entity-vectors/", "world_readable": true, "date_modified": "2019-06-17T16:50:58.822Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ChrisTDick/140/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "eefb1e62-192d-4f58-820b-371ae8000b78", "mode": "text", "type": "scattergl", "xsrc": "ChrisTDick:141:606517", "ysrc": "ChrisTDick:141:8e01b1", "marker": { "opacity": 0.5 }, "textsrc": "ChrisTDick:141:c34901" } ], "layout": { "title": { "text": "Entity Vectors" }, "xaxis": { "title": { "text": "x" } }, "yaxis": { "title": { "text": "y" } }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ChrisTDick", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-15 09:55:45", "mapbox_access_tokens": null, "has_password": null, "username": "ChrisTDick", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:50:32.703346Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~JeffKatzy/217.embed", "fid": "JeffKatzy:217", "filename": "plot from API (92)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/JeffKatzy:217/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/JeffKatzy:217/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/JeffKatzy/217/8_EPEBDNVTO3BE3UMUVUKSAEIBA5KCEI.png", "list-thumb": "https://api.plotly.com/v2/files/JeffKatzy:217/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/JeffKatzy:217", "plots": "https://api.plotly.com/v2/plots/JeffKatzy:217", "parent": "https://api.plotly.com/v2/folders/home?user=JeffKatzy" }, "owner": "JeffKatzy", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "ad spending effect vs sales spending effect", "views": 2, "web_url": "https://chart-studio.plotly.com/~JeffKatzy/217/ad-spending-effect-vs-sales-spending-effect/", "world_readable": true, "date_modified": "2019-06-17T16:50:33.151Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~JeffKatzy/217/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "0231bb88-6ef8-4203-96ac-cb94038c34e9", "mode": "lines+markers", "name": "ad spending effect", "text": "", "type": "scatter", "xsrc": "JeffKatzy:218:4a648c", "ysrc": "JeffKatzy:218:86968c" }, { "uid": "a23c2f16-8b5f-42ba-9105-d790e8318b8f", "mode": "lines+markers", "name": "sales spending effect", "text": [], "type": "scatter", "xsrc": "JeffKatzy:218:29cf9d", "ysrc": "JeffKatzy:218:4ea87b" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~JeffKatzy", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/18.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-02-05 15:49:08", "mapbox_access_tokens": null, "has_password": null, "username": "JeffKatzy", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:50:14.193263Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ChrisTDick/138.embed", "fid": "ChrisTDick:138", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ChrisTDick:138/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ChrisTDick:138/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ChrisTDick:138/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ChrisTDick:138/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ChrisTDick:138", "plots": "https://api.plotly.com/v2/plots/ChrisTDick:138", "parent": "https://api.plotly.com/v2/folders/home?user=ChrisTDick" }, "owner": "ChrisTDick", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Entity Vectors", "views": 0, "web_url": "https://chart-studio.plotly.com/~ChrisTDick/138/entity-vectors/", "world_readable": true, "date_modified": "2019-06-17T16:50:14.992Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ChrisTDick/138/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "40ea67ec-01f0-48f4-b160-1ee349c960e2", "mode": "text", "type": "scattergl", "xsrc": "ChrisTDick:139:470f21", "ysrc": "ChrisTDick:139:429f9c", "marker": { "opacity": 0.5 }, "textsrc": "ChrisTDick:139:8bafc6" } ], "layout": { "title": { "text": "Entity Vectors" }, "xaxis": { "title": { "text": "x" } }, "yaxis": { "title": { "text": "y" } }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ChrisTDick", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-15 09:55:45", "mapbox_access_tokens": null, "has_password": null, "username": "ChrisTDick", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
