Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBNTAlM0ExNC4xOTMyNjMlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBNDUlM0E1NS4yNDczMTAlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNiUzQTQ5JTNBMjguNTQwNjE1JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T16:49:28.540615Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~michaelbabyn/978.embed", "fid": "michaelbabyn:978", "filename": "Plot 978", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/978/9_B2KSTCMP5UB9BZ2RO5RDJJPZCUNGQT.png", "image_urls": { "default": "https://api.plotly.com/v2/files/michaelbabyn:978/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/978/8_JVOX5W50A1VPOU7QE37JEYGSSWLVYQ.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/978/9_B2KSTCMP5UB9BZ2RO5RDJJPZCUNGQT.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/michaelbabyn:978", "plots": "https://api.plotly.com/v2/plots/michaelbabyn:978", "parent": "https://api.plotly.com/v2/folders/home?user=michaelbabyn" }, "owner": "michaelbabyn", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~michaelbabyn/978/", "world_readable": true, "date_modified": "2019-06-17T16:49:28.562Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~michaelbabyn/978/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "scatter", "ysrc": "michaelbabyn:977:bb1ef9" }, { "type": "bar", "ysrc": "michaelbabyn:977:9cbbf8" } ], "layout": { "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~michaelbabyn", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/74.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-07-09 16:52:34", "mapbox_access_tokens": null, "has_password": null, "username": "michaelbabyn", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:49:27.548633Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ChrisTDick/136.embed", "fid": "ChrisTDick:136", "filename": "plot from API (8)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ChrisTDick:136/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ChrisTDick:136/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ChrisTDick:136/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ChrisTDick:136/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ChrisTDick:136", "plots": "https://api.plotly.com/v2/plots/ChrisTDick:136", "parent": "https://api.plotly.com/v2/folders/home?user=ChrisTDick" }, "owner": "ChrisTDick", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Entity Vectors", "views": 0, "web_url": "https://chart-studio.plotly.com/~ChrisTDick/136/entity-vectors/", "world_readable": true, "date_modified": "2019-06-17T16:49:28.040Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ChrisTDick/136/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "78e8944d-31ad-4dec-b466-f8614c08d8ba", "mode": "text", "type": "scattergl", "xsrc": "ChrisTDick:137:9d4c3c", "ysrc": "ChrisTDick:137:51fb82", "marker": { "opacity": 0.5 }, "textsrc": "ChrisTDick:137:929317" } ], "layout": { "title": { "text": "Entity Vectors" }, "xaxis": { "title": { "text": "x" } }, "yaxis": { "title": { "text": "y" } }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ChrisTDick", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-15 09:55:45", "mapbox_access_tokens": null, "has_password": null, "username": "ChrisTDick", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:48:50.292268Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~VasilisHadjigeorgiou/3.embed", "fid": "VasilisHadjigeorgiou:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/VasilisHadjigeorgiou:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/VasilisHadjigeorgiou:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/VasilisHadjigeorgiou/3/8_20TSL55N7LBUPQYZU60CXVIQW7WYRT.png", "list-thumb": "https://api.plotly.com/v2/files/VasilisHadjigeorgiou:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/VasilisHadjigeorgiou:3", "plots": "https://api.plotly.com/v2/plots/VasilisHadjigeorgiou:3", "parent": "https://api.plotly.com/v2/folders/home?user=VasilisHadjigeorgiou" }, "owner": "VasilisHadjigeorgiou", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~VasilisHadjigeorgiou/3/", "world_readable": true, "date_modified": "2019-06-17T16:48:50.309Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~VasilisHadjigeorgiou/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "contour", "xsrc": "VasilisHadjigeorgiou:2:908492", "ysrc": "VasilisHadjigeorgiou:2:1acdf1", "zsrc": "VasilisHadjigeorgiou:2:bcaf2d", "contours": { "end": 3, "size": 0.2, "start": 1 }, "autocontour": true, "autocolorscale": true } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 0, 2 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 1, 9 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~VasilisHadjigeorgiou", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/31.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:44:12", "mapbox_access_tokens": null, "has_password": null, "username": "VasilisHadjigeorgiou", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:48:19.334158Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srt7/8.embed", "fid": "srt7:8", "filename": "AAPL-stockprice1560790095.113385", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/srt7:8/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/srt7:8/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/srt7:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/srt7:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srt7:8", "plots": "https://api.plotly.com/v2/plots/srt7:8", "parent": "https://api.plotly.com/v2/folders/home?user=srt7" }, "owner": "srt7", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~srt7/8/", "world_readable": true, "date_modified": "2019-06-17T16:48:19.346Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srt7/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": false, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(114, 186, 59)" }, "mode": "lines", "name": "Corrosion", "type": "scatter", "xsrc": "srt7:7:c6b67c", "ysrc": "srt7:7:8743bd" } ], "frames": [ { "data": [ { "xsrc": "srt7:7:c6b67c", "ysrc": "srt7:7:8743bd" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:b9636e", "ysrc": "srt7:7:e6cffd" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:d087ee", "ysrc": "srt7:7:90fb2f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:8dc6de", "ysrc": "srt7:7:5aa0f4" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:3c94eb", "ysrc": "srt7:7:44d4dc" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:3d4f95", "ysrc": "srt7:7:81bf1b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:5da1e2", "ysrc": "srt7:7:77d763" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:a664f6", "ysrc": "srt7:7:ee18dd" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:bf4406", "ysrc": "srt7:7:6dddd8" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:a99e9e", "ysrc": "srt7:7:7413ca" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:1b2cf5", "ysrc": "srt7:7:871e77" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:154331", "ysrc": "srt7:7:d84e04" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:cb8bce", "ysrc": "srt7:7:d285fd" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:b0bd59", "ysrc": "srt7:7:539ba1" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:41ed52", "ysrc": "srt7:7:d99f0b" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:5e4c67", "ysrc": "srt7:7:f489e9" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:8b3fc6", "ysrc": "srt7:7:a35705" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:2db955", "ysrc": "srt7:7:2288d6" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:6f4819", "ysrc": "srt7:7:7cb069" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:8c9db8", "ysrc": "srt7:7:4fe23a" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:78ffaf", "ysrc": "srt7:7:f773f2" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:bd8aff", "ysrc": "srt7:7:b6c2d3" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:aee8f3", "ysrc": "srt7:7:974a72" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:2ac2b6", "ysrc": "srt7:7:3131bc" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:199958", "ysrc": "srt7:7:255c6e" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:15b39d", "ysrc": "srt7:7:053300" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:93fbf0", "ysrc": "srt7:7:60747f" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:fa6e21", "ysrc": "srt7:7:e88364" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:a79e86", "ysrc": "srt7:7:c42376" } ], "traces": [ 0 ] }, { "data": [ { "xsrc": "srt7:7:e17fe4", "ysrc": "srt7:7:3b8c65" } ], "traces": [ 0 ] } ], "layout": { "font": { "family": "Balto" }, "title": "Corrosion", "width": 800, "xaxis": { "range": [ 1424131200000.0, 1480464000000.0 ], "mirror": true, "nticks": 12, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false, "tickangle": -45 }, "yaxis": { "range": [ 0, 170 ], "title": "$", "mirror": true, "ticklen": 4, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "height": 400, "autosize": false, "showlegend": false, "updatemenus": [ { "x": 1.1, "y": 1, "pad": { "r": 10, "t": 0 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 50 }, "transition": { "duration": 0 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "showactive": false } ] } }, "height": 400, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~srt7", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-16 07:53:25", "mapbox_access_tokens": null, "has_password": null, "username": "srt7", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:47:57.181276Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~michaelbabyn/976.embed", "fid": "michaelbabyn:976", "filename": "Plot 976", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/976/9_KFU6XZQESHFJ1RSM37FBLUAKDMEA1M.png", "image_urls": { "default": "https://api.plotly.com/v2/files/michaelbabyn:976/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/976/8_58YNWJE7D9VJMY4QAZ6SPRXG5JROH6.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/976/9_KFU6XZQESHFJ1RSM37FBLUAKDMEA1M.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/michaelbabyn:976", "plots": "https://api.plotly.com/v2/plots/michaelbabyn:976", "parent": "https://api.plotly.com/v2/folders/home?user=michaelbabyn" }, "owner": "michaelbabyn", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~michaelbabyn/976/", "world_readable": true, "date_modified": "2019-06-17T16:47:57.194Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~michaelbabyn/976/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "scatter", "ysrc": "michaelbabyn:974:837e88" } ], "layout": { "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~michaelbabyn", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/74.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-07-09 16:52:34", "mapbox_access_tokens": null, "has_password": null, "username": "michaelbabyn", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:47:39.348339Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~kwhanghk/4.embed", "fid": "kwhanghk:4", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/kwhanghk:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/kwhanghk:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/kwhanghk:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/kwhanghk:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/kwhanghk:4", "plots": "https://api.plotly.com/v2/plots/kwhanghk:4", "parent": "https://api.plotly.com/v2/folders/home?user=kwhanghk" }, "owner": "kwhanghk", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Estimated number of clusters: 33", "views": 2, "web_url": "https://chart-studio.plotly.com/~kwhanghk/4/estimated-number-of-clusters-33/", "world_readable": true, "date_modified": "2019-06-17T16:47:40.197Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~kwhanghk/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "6ba75c4f-9921-4d3f-b4d3-cf1e361f79e2", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:907d4b", "ysrc": "kwhanghk:5:d1522b", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(158, 1, 66)" } }, { "uid": "1c55ca52-b90f-46b4-b8eb-811403beb607", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:dbc0f9", "ysrc": "kwhanghk:5:71a7df", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(173, 17, 69)" } }, { "uid": "c3c6bc82-e60a-453c-bd41-4bf9c05249dc", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:145223", "ysrc": "kwhanghk:5:f9ebae", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(190, 36, 73)" } }, { "uid": "f0ea77f7-10b2-4aa9-95f2-a3b8359a0dcf", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:bbaedb", "ysrc": "kwhanghk:5:2f4e23", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(207, 56, 77)" } }, { "uid": "ca2625f1-33cd-45fa-ac92-e36ed562983e", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:70531e", "ysrc": "kwhanghk:5:f8e12f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(219, 72, 76)" } }, { "uid": "e2cbfc72-cb4d-46c0-abac-c7311af2c2c6", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:407d16", "ysrc": "kwhanghk:5:5d257c", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(228, 85, 73)" } }, { "uid": "5ec11f88-8c23-464f-9fbc-c6f5055b8ba7", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:57f10d", "ysrc": "kwhanghk:5:3a7788", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(237, 99, 69)" } }, { "uid": "1181bba4-a924-45ec-914a-3ffdbc9f64a3", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:33a369", "ysrc": "kwhanghk:5:a4a30d", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(245, 116, 70)" } }, { "uid": "abdc66be-05df-4981-9700-df5a7afc454f", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:4e45cf", "ysrc": "kwhanghk:5:f9270c", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(247, 137, 79)" } }, { "uid": "3141790c-4f7d-456a-a552-0c50e679cd3a", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:5905e2", "ysrc": "kwhanghk:5:f97248", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(250, 154, 88)" } }, { "uid": "830665bb-0674-40d5-b7aa-d5aa52115549", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:797efe", "ysrc": "kwhanghk:5:854deb", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 174, 97)" } }, { "uid": "933089cc-a1e2-42f2-8fc9-70f809f8a955", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:e8740f", "ysrc": "kwhanghk:5:a7f684", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 190, 110)" } }, { "uid": "770213cb-e9de-4d87-bc95-94d58da240b8", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:d0c1e6", "ysrc": "kwhanghk:5:87fce6", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 206, 124)" } }, { "uid": "3d8187a5-7b1f-40e2-bc81-405c54b8c0bc", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:1b52ee", "ysrc": "kwhanghk:5:399f82", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(253, 220, 135)" } }, { "uid": "4db72f9c-9603-4a67-a216-f11cea3358cd", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:e1b49a", "ysrc": "kwhanghk:5:386998", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(254, 231, 151)" } }, { "uid": "89a51bdd-763d-4224-a878-71064ac9788f", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:0b38c2", "ysrc": "kwhanghk:5:e69af2", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(254, 241, 167)" } }, { "uid": "a1e6eb70-e1c5-4a3e-a066-5973bd5208e0", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:182fa8", "ysrc": "kwhanghk:5:6f996f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(254, 250, 183)" } }, { "uid": "0aa8d1dd-1d6c-4d8f-a79d-6eac06bd880c", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:e949ed", "ysrc": "kwhanghk:5:ebe3de", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(251, 253, 185)" } }, { "uid": "20b1763c-1766-4287-8c6b-7b77a9d0c7bc", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:ce5c52", "ysrc": "kwhanghk:5:896d7b", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(243, 250, 173)" } }, { "uid": "5c1b996e-ba11-4fa3-bbb0-42170a722f7b", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:d36a51", "ysrc": "kwhanghk:5:c3921f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(235, 247, 161)" } }, { "uid": "de0c45ec-aae5-4b11-be96-f44244e8cd22", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:aae075", "ysrc": "kwhanghk:5:bdc864", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(225, 243, 152)" } }, { "uid": "19bcdd3a-9638-46a6-9073-8cbb69c9d733", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:324aee", "ysrc": "kwhanghk:5:0c18c8", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(209, 236, 156)" } }, { "uid": "d41637de-568f-4970-a863-c121e7994f39", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:34485f", "ysrc": "kwhanghk:5:6d0f7b", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(190, 229, 160)" } }, { "uid": "f7dc1f1a-dc0e-41d8-bce4-d7338163d316", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:a07d4d", "ysrc": "kwhanghk:5:4c3c22", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(172, 221, 163)" } }, { "uid": "f43dd0b4-1565-438b-9fac-8ceeea80ad43", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:144093", "ysrc": "kwhanghk:5:a8849d", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(150, 213, 164)" } }, { "uid": "c4f8c265-a8ce-41e9-89ac-c432359d4dbe", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:cea310", "ysrc": "kwhanghk:5:c8645d", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(131, 205, 164)" } }, { "uid": "9f8f07a3-9160-470a-bf8a-c8545e8bffb8", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:1f38f9", "ysrc": "kwhanghk:5:f55acf", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(110, 197, 164)" } }, { "uid": "ad38421d-ee10-424f-8d37-7ad86a889921", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:e815fb", "ysrc": "kwhanghk:5:4e437b", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(91, 182, 169)" } }, { "uid": "6d407998-6984-4c42-b322-2dc6ed83e821", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:f3d038", "ysrc": "kwhanghk:5:e574df", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(75, 164, 177)" } }, { "uid": "0c220e94-4c99-4776-b1c9-eaeb6d7c1b54", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:177f6f", "ysrc": "kwhanghk:5:330d7f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(61, 148, 183)" } }, { "uid": "c6987784-64c8-44e5-8c7c-2c393ae3f1c6", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:f40ec5", "ysrc": "kwhanghk:5:b0aee9", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(54, 130, 186)" } }, { "uid": "4e0f3907-df93-4956-b4e4-9a325645840b", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:a872fc", "ysrc": "kwhanghk:5:7b984d", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(68, 112, 177)" } }, { "uid": "b55f2970-3000-4e37-b02a-7c971d1dcbb6", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:54abd7", "ysrc": "kwhanghk:5:47bbab", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "rgb(81, 94, 169)" } }, { "uid": "33e18f33-7e6d-4e8a-a0e6-b15bd4cbdc05", "mode": "markers", "type": "scatter", "xsrc": "kwhanghk:5:3d77eb", "ysrc": "kwhanghk:5:1df15f", "marker": { "line": { "color": "black", "width": 1 }, "size": 14, "color": "black" } } ], "layout": { "title": { "text": "Estimated number of clusters: 33" }, "xaxis": { "showgrid": false, "zeroline": false }, "yaxis": { "showgrid": false, "zeroline": false }, "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~kwhanghk", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/83.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 16:39:07", "mapbox_access_tokens": null, "has_password": null, "username": "kwhanghk", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:46:40.509495Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~sophielaw96/42.embed", "fid": "sophielaw96:42", "filename": "Plot 42", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/sophielaw96:42/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/sophielaw96:42/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/sophielaw96:42/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/sophielaw96:42/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sophielaw96:42", "plots": "https://api.plotly.com/v2/plots/sophielaw96:42", "parent": "https://api.plotly.com/v2/folders/home?user=sophielaw96" }, "owner": "sophielaw96", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~sophielaw96/42/", "world_readable": true, "date_modified": "2019-06-17T16:52:27.091Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~sophielaw96/42/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "contour", "xsrc": "sophielaw96:41:b2a5d3", "ysrc": "sophielaw96:41:2962aa", "zsrc": "sophielaw96:41:49dd27", "contours": { "end": 3.3000000000000003, "size": 0.1, "start": 0.9 }, "ncontours": 40, "autocontour": true, "autocolorscale": true } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "type": "linear", "range": [ 0, 2 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 1, 9 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~sophielaw96", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-06-08 10:13:31", "mapbox_access_tokens": null, "has_password": null, "username": "sophielaw96", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:46:31.799176Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~michaelbabyn/975.embed", "fid": "michaelbabyn:975", "filename": "Plot 975", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/975/9_N4PFVU4L76JI00AAW0OU3SOGZNLAN8.png", "image_urls": { "default": "https://api.plotly.com/v2/files/michaelbabyn:975/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/975/8_4GV743I7H7NJIDI23MJ93M4FHU41OK.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/michaelbabyn/975/9_N4PFVU4L76JI00AAW0OU3SOGZNLAN8.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/michaelbabyn:975", "plots": "https://api.plotly.com/v2/plots/michaelbabyn:975", "parent": "https://api.plotly.com/v2/folders/home?user=michaelbabyn" }, "owner": "michaelbabyn", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~michaelbabyn/975/", "world_readable": true, "date_modified": "2019-06-17T16:46:31.828Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~michaelbabyn/975/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "scatter", "ysrc": "michaelbabyn:974:837e88" } ], "layout": { "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~michaelbabyn", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/74.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-07-09 16:52:34", "mapbox_access_tokens": null, "has_password": null, "username": "michaelbabyn", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:46:10.053679Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ghu001/18.embed", "fid": "ghu001:18", "filename": "plot from API (9)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ghu001:18/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ghu001/18/2_7REOF1QD1DFM13XO94CFH7TVRY2F8H.png", "block-thumb": "https://api.plotly.com/v2/files/ghu001:18/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ghu001:18/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ghu001:18", "plots": "https://api.plotly.com/v2/plots/ghu001:18", "parent": "https://api.plotly.com/v2/folders/home?user=ghu001" }, "owner": "ghu001", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~ghu001/18/", "world_readable": true, "date_modified": "2019-06-17T16:46:10.537Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ghu001/18/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "2cfc260a-88e7-42c9-ad6e-c712bbdf9b7c", "type": "histogram", "xsrc": "ghu001:19:a08bfa" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ghu001", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/20.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-11 15:17:40", "mapbox_access_tokens": null, "has_password": null, "username": "ghu001", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:45:55.247310Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paigeponton1215/3.embed", "fid": "paigeponton1215:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paigeponton1215:3/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/paigeponton1215/3/2_VDH4HM7C01H81Y6CEA4O9FEOY85BKN.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paigeponton1215/3/8_6BIT2HRGO86IOAR5BLX0RH0VYBAAZK.png", "list-thumb": "https://api.plotly.com/v2/files/paigeponton1215:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paigeponton1215:3", "plots": "https://api.plotly.com/v2/plots/paigeponton1215:3", "parent": "https://api.plotly.com/v2/folders/home?user=paigeponton1215" }, "owner": "paigeponton1215", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~paigeponton1215/3/", "world_readable": true, "date_modified": "2019-06-17T16:46:24.217Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paigeponton1215/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "type": "scatter", "xsrc": "paigeponton1215:2:22dac8", "ysrc": "paigeponton1215:2:c8d951" } ], "frames": [], "layout": { "title": { "text": "Neutralisation of CH3COOH" }, "xaxis": { "type": "linear", "range": [ 0, 33.5 ], "title": { "text": "Volume of NaOH (mL)" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 3.0694444444444446, 12.480555555555554 ], "title": { "text": "pH" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~paigeponton1215", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/43.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-02-12 16:39:14", "mapbox_access_tokens": null, "has_password": null, "username": "paigeponton1215", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
