Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBMTYlM0ExMC43NzczMDElMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE2JTNBMDglM0E0MC4yNTc1ODMlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNiUzQTE1JTNBNDAuNjczNDA0JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T16:15:40.673404Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67072.embed", "fid": "amper:67072", "filename": "06-06-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67072/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67072/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67072/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67072/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67072", "plots": "https://api.plotly.com/v2/plots/amper:67072", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-06-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67072/_06-06-19-ds-1642-alg-5421-param-1250-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T17:24:03.189Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67072/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "8c6e6bc2-2fb9-412a-976f-e6602d7dd3c8", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67073:e6b204", "ysrc": "amper:67073:a8fb70", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "b85349e6-f852-4517-b1f7-47f5f173453e", "mode": "lines", "name": "Production", "type": "scattergl", "xsrc": "amper:67073:e6b204", "ysrc": "amper:67073:4866f3", "marker": { "line": { "color": "rgb(0, 166, 73)", "width": 1 }, "size": 1, "color": "rgb(0, 166, 73)" }, "connectgaps": false }, { "uid": "57a5bcf2-90bd-4cdc-936a-6637bfdefc68", "mode": "lines", "name": "Other", "type": "scattergl", "xsrc": "amper:67073:e6b204", "ysrc": "amper:67073:097566", "marker": { "line": { "color": "rgb(169,169,169)", "width": 1 }, "size": 1, "color": "rgb(169,169,169)" } } ], "layout": { "title": "06-06-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:14:56.867261Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67070.embed", "fid": "amper:67070", "filename": "06-05-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67070/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67070/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67070/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67070/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67070", "plots": "https://api.plotly.com/v2/plots/amper:67070", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-05-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67070/_06-05-19-ds-1642-alg-5421-param-1250-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T17:23:04.402Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67070/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "d8fa3ddc-315d-4b9f-8a33-de60647ca17a", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67071:ee4ecb", "ysrc": "amper:67071:91c2ce", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "2867d59e-2463-4407-a9d3-9a8f157072f8", "mode": "lines", "name": "Production", "type": "scattergl", "xsrc": "amper:67071:ee4ecb", "ysrc": "amper:67071:f3fece", "marker": { "line": { "color": "rgb(0, 166, 73)", "width": 1 }, "size": 1, "color": "rgb(0, 166, 73)" }, "connectgaps": false }, { "uid": "c2b3140e-86a5-42e6-a2f7-33460373c0b8", "mode": "lines", "name": "Other", "type": "scattergl", "xsrc": "amper:67071:ee4ecb", "ysrc": "amper:67071:c40e6f", "marker": { "line": { "color": "rgb(169,169,169)", "width": 1 }, "size": 1, "color": "rgb(169,169,169)" } } ], "layout": { "title": "06-05-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:14:44.986218Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jas_usc/283.embed", "fid": "jas_usc:283", "filename": "projection-matrix-Affs: LEMNISCATE Trajectory (20x)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jas_usc:283/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jas_usc:283/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/jas_usc/283/8_PBKJN59QQ7XZAJUD9W0ZTWZ59LO5TB.png", "list-thumb": "https://api.plotly.com/v2/files/jas_usc:283/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jas_usc:283", "plots": "https://api.plotly.com/v2/plots/jas_usc:283", "parent": "https://api.plotly.com/v2/folders/jas_usc:252" }, "owner": "jas_usc", "parent": 252, "preview": "", "referencers": [], "references": [], "title": "PC1 vs.PC2: LEMNISCATE Trajectory (20x)", "views": 0, "web_url": "https://chart-studio.plotly.com/~jas_usc/283/pc1-vspc2-lemniscate-trajectory-20x/", "world_readable": true, "date_modified": "2019-06-17T16:15:50.296Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jas_usc/283/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "2bc6ba87-7bf7-4e2c-bdb3-acbcff1890a7", "mode": "markers", "name": "Phase One", "type": "scatter", "xsrc": "jas_usc:284:a885fe", "ysrc": "jas_usc:284:096f7d", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#1D65A6", "opacity": 0.8 } }, { "uid": "cfc2d27b-ccde-4f78-b40a-2249a9c175bd", "mode": "markers", "name": "Phase Two", "type": "scatter", "xsrc": "jas_usc:284:6f3b90", "ysrc": "jas_usc:284:44fc26", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#C0334D", "opacity": 0.8 } }, { "uid": "3ca5cd4b-9ff6-40f1-83b4-dff35ca262d0", "mode": "markers", "name": "Phase Three", "type": "scatter", "xsrc": "jas_usc:284:130ee1", "ysrc": "jas_usc:284:c6d039", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00743F", "opacity": 0.8 } }, { "uid": "29860400-c24d-4ef0-8b07-96232cddf3ee", "mode": "markers", "name": "Phase Four", "type": "scatter", "xsrc": "jas_usc:284:d50639", "ysrc": "jas_usc:284:6cd453", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#F2A104", "opacity": 0.8 } }, { "uid": "cb7ced29-befb-4d75-9cc3-8bb22fb04e99", "mode": "markers", "name": "Phase Five", "type": "scatter", "xsrc": "jas_usc:284:02c4d6", "ysrc": "jas_usc:284:baf17f", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#FF69B4", "opacity": 0.8 } }, { "uid": "9df6a049-325a-4f83-99c4-db90fcf17b81", "mode": "markers", "name": "Phase Six", "type": "scatter", "xsrc": "jas_usc:284:c36bc5", "ysrc": "jas_usc:284:94edfd", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00CED1", "opacity": 0.8 } }, { "uid": "3bb57fd4-a950-4dbe-a9d6-cfad61d7551e", "mode": "markers", "name": "Phase Seven", "type": "scatter", "xsrc": "jas_usc:284:df42a2", "ysrc": "jas_usc:284:6860c5", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#800080", "opacity": 0.8 } }, { "uid": "9ac9bd2d-41c0-42f3-9051-4ab0ec4a2842", "mode": "markers", "name": "Phase Eight", "type": "scatter", "xsrc": "jas_usc:284:25acbf", "ysrc": "jas_usc:284:941239", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00FF00", "opacity": 0.8 } }, { "uid": "22344e7e-18d8-4438-9219-4464bbb4a88b", "mode": "markers", "name": "Phase Nine", "type": "scatter", "xsrc": "jas_usc:284:0d755e", "ysrc": "jas_usc:284:31a64c", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#778899", "opacity": 0.8 } }, { "uid": "bed972c4-b8db-4a9d-ba32-f4297c868173", "mode": "markers", "name": "Phase Ten", "type": "scatter", "xsrc": "jas_usc:284:da999d", "ysrc": "jas_usc:284:230c22", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#A0522D", "opacity": 0.8 } }, { "uid": "ce0ace02-c6f5-4b24-b5c2-5fd26423537a", "mode": "markers", "name": "Phase Eleven", "type": "scatter", "xsrc": "jas_usc:284:886897", "ysrc": "jas_usc:284:77f34d", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#1D65A6", "opacity": 0.8 } }, { "uid": "e74a0f46-1442-476f-a98d-d5c250a46cd6", "mode": "markers", "name": "Phase Twelve", "type": "scatter", "xsrc": "jas_usc:284:554c82", "ysrc": "jas_usc:284:38b226", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#C0334D", "opacity": 0.8 } }, { "uid": "8d376f08-97c2-47b2-aa74-a38047bfaee3", "mode": "markers", "name": "Phase Thirteen", "type": "scatter", "xsrc": "jas_usc:284:4d1951", "ysrc": "jas_usc:284:7b6b0d", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00743F", "opacity": 0.8 } }, { "uid": "ad71df76-2a66-4693-a367-64d1b371fbe8", "mode": "markers", "name": "Phase Fourteen", "type": "scatter", "xsrc": "jas_usc:284:8c2010", "ysrc": "jas_usc:284:63fefe", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#F2A104", "opacity": 0.8 } }, { "uid": "b7f9bdfd-f894-4088-ac00-c2bfbe8ea5cf", "mode": "markers", "name": "Phase Fifteen", "type": "scatter", "xsrc": "jas_usc:284:b0f275", "ysrc": "jas_usc:284:cee208", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#FF69B4", "opacity": 0.8 } }, { "uid": "e3830187-bfb3-48dc-b249-55ddc5dc4923", "mode": "markers", "name": "Phase Sixteen", "type": "scatter", "xsrc": "jas_usc:284:6c0b49", "ysrc": "jas_usc:284:98c45e", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00CED1", "opacity": 0.8 } }, { "uid": "747a4f58-b097-4685-9762-fbd2646781be", "mode": "markers", "name": "Phase Seventeen", "type": "scatter", "xsrc": "jas_usc:284:5d48ea", "ysrc": "jas_usc:284:45ba88", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#800080", "opacity": 0.8 } }, { "uid": "a83ddda0-219b-4545-a341-b80b8ebbc9d6", "mode": "markers", "name": "Phase Eighteen", "type": "scatter", "xsrc": "jas_usc:284:70fa87", "ysrc": "jas_usc:284:44f952", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#00FF00", "opacity": 0.8 } }, { "uid": "ff61ed47-24b0-4517-893d-12b248050097", "mode": "markers", "name": "Phase Nineteen", "type": "scatter", "xsrc": "jas_usc:284:dd05c2", "ysrc": "jas_usc:284:9a8a49", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#778899", "opacity": 0.8 } }, { "uid": "3f6c6c80-199f-46bb-acfe-b3c41a55d87c", "mode": "markers", "name": "Phase Twenty", "type": "scatter", "xsrc": "jas_usc:284:615274", "ysrc": "jas_usc:284:332ea1", "marker": { "line": { "color": "rgba(217, 217, 217, 0.14)", "width": 0.5 }, "size": 12, "color": "#A0522D", "opacity": 0.8 } } ], "layout": { "title": { "text": "PC1 vs.PC2: LEMNISCATE Trajectory (20x)" }, "xaxis": { "title": { "text": "PC1" } }, "yaxis": { "title": { "text": "PC2" } }, "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jas_usc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2015-11-09 00:19:02", "mapbox_access_tokens": null, "has_password": null, "username": "jas_usc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:14:20.171164Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~amper/67068.embed", "fid": "amper:67068", "filename": "06-04-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/amper:67068/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/amper:67068/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/amper:67068/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/amper:67068/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/amper:67068", "plots": "https://api.plotly.com/v2/plots/amper:67068", "parent": "https://api.plotly.com/v2/folders/home?user=amper" }, "owner": "amper", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "06-04-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC", "views": 0, "web_url": "https://chart-studio.plotly.com/~amper/67068/_06-04-19-ds-1642-alg-5421-param-1250-showamps-true-state-res-sec/", "world_readable": true, "date_modified": "2019-06-17T16:14:21.634Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~amper/67068/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "db2cf8d2-a8f9-4ab0-a9ff-4724337d924d", "mode": "lines", "name": "Idle", "type": "scattergl", "xsrc": "amper:67069:87355f", "ysrc": "amper:67069:f74cfc", "marker": { "line": { "color": "rgb(255, 205, 0)", "width": 1 }, "size": 1, "color": "rgb(255, 205, 0)" }, "connectgaps": false }, { "uid": "00822477-49e6-4be9-8f80-6c460e9d8fe1", "mode": "lines", "name": "Production", "type": "scattergl", "xsrc": "amper:67069:87355f", "ysrc": "amper:67069:0c8360", "marker": { "line": { "color": "rgb(0, 166, 73)", "width": 1 }, "size": 1, "color": "rgb(0, 166, 73)" }, "connectgaps": false }, { "uid": "4c57a79f-b5b0-4ff3-bff6-7627df297638", "mode": "lines", "name": "Other", "type": "scattergl", "xsrc": "amper:67069:87355f", "ysrc": "amper:67069:b9eba4", "marker": { "line": { "color": "rgb(169,169,169)", "width": 1 }, "size": 1, "color": "rgb(169,169,169)" } } ], "layout": { "title": "06-04-19_ds-1642_alg-5421_param-1250_showamps-True-state_res-SEC" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~amper", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/99.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-03-17 16:47:16", "mapbox_access_tokens": null, "has_password": null, "username": "amper", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:13:00.514085Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/10.embed", "fid": "dangnguyen:10", "filename": "Plotly Playground 2019-06-17 16:12:59", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/10/9_UZ55G2NZKXKR5HCDLOH1MDG0H1KHBO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/10/2_72T1WTNMDMVJF8408VNETB4BJA8TEJ.png", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:10/image?image_name=block-thumb", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/10/9_UZ55G2NZKXKR5HCDLOH1MDG0H1KHBO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:10", "plots": "https://api.plotly.com/v2/plots/dangnguyen:10", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~dangnguyen/10/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-17T16:13:00.938Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "680fcd72-bed2-4f09-a6fe-d51618a914bb", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "# 0", "text": "", "type": "scatter", "xsrc": "dangnguyen:11:36c2a7", "ysrc": "dangnguyen:11:221190" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:11:38.987453Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~unzule.keles/2.embed", "fid": "unzule.keles:2", "filename": "Time Series with Rangeslider", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/unzule.keles:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/unzule.keles:2/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/unzule.keles/2/8_C5FWU6L33NO18G7QUB25J3OOA604BE.png", "list-thumb": "https://api.plotly.com/v2/files/unzule.keles:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/unzule.keles:2", "plots": "https://api.plotly.com/v2/plots/unzule.keles:2", "parent": "https://api.plotly.com/v2/folders/home?user=unzule.keles" }, "owner": "unzule.keles", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Time Series with Rangeslider", "views": 0, "web_url": "https://chart-studio.plotly.com/~unzule.keles/2/time-series-with-rangeslider/", "world_readable": true, "date_modified": "2019-06-18T08:04:16.068Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~unzule.keles/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "922e6e7b-f2fa-4e8f-bc18-07aadb8e0a0f", "line": { "color": "#17BECF" }, "name": "Antalya", "type": "scatter", "xsrc": "unzule.keles:3:aaed4c", "ysrc": "unzule.keles:3:fa4c25", "opacity": 0.8 }, { "uid": "d505f32e-d338-4817-82fb-f35fd2927b44", "line": { "color": "#7F7F7F" }, "name": "Alanya", "type": "scatter", "xsrc": "unzule.keles:3:aaed4c", "ysrc": "unzule.keles:3:928599", "opacity": 0.8 } ], "layout": { "title": { "text": "Time Series with Rangeslider" }, "xaxis": { "type": "date", "rangeslider": { "visible": true }, "rangeselector": { "buttons": [ { "step": "month", "count": 1, "label": "1m", "stepmode": "backward" }, { "step": "month", "count": 6, "label": "6m", "stepmode": "backward" }, { "step": "all" } ] } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~unzule.keles", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/18.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 15:13:32", "mapbox_access_tokens": null, "has_password": null, "username": "unzule.keles", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:09:38.159630Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Loonycorn123/2.embed", "fid": "Loonycorn123:2", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Loonycorn123:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Loonycorn123:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/Loonycorn123:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/Loonycorn123:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Loonycorn123:2", "plots": "https://api.plotly.com/v2/plots/Loonycorn123:2", "parent": "https://api.plotly.com/v2/folders/home?user=Loonycorn123" }, "owner": "Loonycorn123", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~Loonycorn123/2/", "world_readable": true, "date_modified": "2019-06-17T16:09:38.676Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Loonycorn123/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ae38bb56-9730-4efb-9193-fc8fee11c249", "type": "scatter", "xsrc": "Loonycorn123:3:9e84ad", "ysrc": "Loonycorn123:3:385ebf" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Loonycorn123", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/19.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-09-04 06:31:17", "mapbox_access_tokens": null, "has_password": null, "username": "Loonycorn123", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:09:02.234801Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/8.embed", "fid": "dangnguyen:8", "filename": "Plotly Playground 2019-06-17 16:09:00", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/8/9_2IF6R3S55XTMWQSIM8R9RND80LHRBO.png", "image_urls": { "default": "https://api.plotly.com/v2/files/dangnguyen:8/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:8/image?image_name=block-thumb", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/8/9_2IF6R3S55XTMWQSIM8R9RND80LHRBO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:8", "plots": "https://api.plotly.com/v2/plots/dangnguyen:8", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~dangnguyen/8/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-17T16:09:03.283Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "b38b06b5-c7aa-41f2-8b8e-2cda9b508bf2", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "# 0", "text": "", "type": "scatter", "xsrc": "dangnguyen:9:a03029", "ysrc": "dangnguyen:9:6bd066" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:08:45.513138Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~liudas/4.embed", "fid": "liudas:4", "filename": "Boy's Surface", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/liudas:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/liudas:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/liudas:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/liudas:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/liudas:4", "plots": "https://api.plotly.com/v2/plots/liudas:4", "parent": "https://api.plotly.com/v2/folders/home?user=liudas" }, "owner": "liudas", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Boy's Surface", "views": 0, "web_url": "https://chart-studio.plotly.com/~liudas/4/boys-surface/", "world_readable": true, "date_modified": "2019-06-17T16:17:08.272Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~liudas/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "96db325d-5cd7-4f8e-be97-47dff1830331", "isrc": "liudas:5:7dec00", "jsrc": "liudas:5:7b65c6", "ksrc": "liudas:5:2ec728", "name": "", "type": "mesh3d", "xsrc": "liudas:5:045575", "ysrc": "liudas:5:70e58e", "zsrc": "liudas:5:de2452", "facecolorsrc": "liudas:5:452a3f" }, { "uid": "88d41e69-1b7a-4c94-8056-a1353741ec58", "line": { "color": "rgb(50, 50, 50)", "width": 1.5 }, "mode": "lines", "type": "scatter3d", "xsrc": "liudas:5:101942", "ysrc": "liudas:5:f64d47", "zsrc": "liudas:5:2746ce", "showlegend": false }, { "uid": "761eaa22-cff8-44a7-9b84-d079f9e53aab", "mode": "markers", "type": "scatter3d", "xsrc": "liudas:5:c83642", "ysrc": "liudas:5:d8e7bc", "zsrc": "liudas:5:9a882e", "marker": { "size": 0.1, "colorsrc": "liudas:5:080de0", "showscale": true, "colorscale": [ [ 0.0, "rgb(50, 0, 75)" ], [ 0.5, "rgb(200, 0, 200)" ], [ 1.0, "rgb(200, 220, 200)" ] ] }, "hoverinfo": "none", "showlegend": false } ], "layout": { "scene": { "xaxis": { "gridcolor": "rgb(255, 255, 255)", "zerolinecolor": "rgb(255, 255, 255)", "showbackground": true, "backgroundcolor": "rgb(230, 230, 230)" }, "yaxis": { "gridcolor": "rgb(255, 255, 255)", "zerolinecolor": "rgb(255, 255, 255)", "showbackground": true, "backgroundcolor": "rgb(230, 230, 230)" }, "zaxis": { "gridcolor": "rgb(255, 255, 255)", "zerolinecolor": "rgb(255, 255, 255)", "showbackground": true, "backgroundcolor": "rgb(230, 230, 230)" }, "aspectratio": { "x": 1, "y": 1, "z": 1 } }, "title": { "text": "Boy's Surface" }, "width": 800, "height": 800 } }, "height": 800, "width": 800, "user": { "profile_url": "https://chart-studio.plotly.com/~liudas", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/45.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 15:22:52", "mapbox_access_tokens": null, "has_password": null, "username": "liudas", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T16:08:40.257583Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dangnguyen/6.embed", "fid": "dangnguyen:6", "filename": "Plotly Playground 2019-06-17 16:08:38", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/6/9_0HUCXEXYVK4T58LCOUQMT3SLAMU9UT.png", "image_urls": { "default": "https://api.plotly.com/v2/files/dangnguyen:6/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/dangnguyen:6/image?image_name=block-thumb", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/dangnguyen/6/9_0HUCXEXYVK4T58LCOUQMT3SLAMU9UT.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dangnguyen:6", "plots": "https://api.plotly.com/v2/plots/dangnguyen:6", "parent": "https://api.plotly.com/v2/folders/home?user=dangnguyen" }, "owner": "dangnguyen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "{'font': {'color': '#4D5663'}}", "views": 0, "web_url": "https://chart-studio.plotly.com/~dangnguyen/6/font-color-4d5663/", "world_readable": true, "date_modified": "2019-06-17T16:08:41.164Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dangnguyen/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "96dc0892-dac2-431e-ac74-4a0eff971eec", "line": { "dash": "solid", "color": "rgba(255, 153, 51, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "lines", "name": "# 0", "text": "", "type": "scatter", "xsrc": "dangnguyen:7:eb9ff7", "ysrc": "dangnguyen:7:1fee9f" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dangnguyen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-28 20:14:08", "mapbox_access_tokens": null, "has_password": null, "username": "dangnguyen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
