Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA2LTE3KzE0JTNBNDYlM0E0Ny4yNjQyMjQlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA2LTE3KzE0JTNBMzQlM0EyMC4yNTgwNzUlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNi0xNysxNCUzQTQ1JTNBMzEuODM5NDUyJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-06-17T14:45:31.839452Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~v0rtex/0.embed", "fid": "v0rtex:0", "filename": "untitled", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/v0rtex:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/v0rtex:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/v0rtex/0/8_KUB2OCT8ILNX13GHQN3F0CF2DYGST4.png", "list-thumb": "https://api.plotly.com/v2/files/v0rtex:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/v0rtex:0", "plots": "https://api.plotly.com/v2/plots/v0rtex:0", "parent": "https://api.plotly.com/v2/folders/home?user=v0rtex" }, "owner": "v0rtex", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "<b><b></b></b>", "views": 0, "web_url": "https://chart-studio.plotly.com/~v0rtex/0/", "world_readable": true, "date_modified": "2019-06-17T14:45:32.367Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~v0rtex/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "contour", "xsrc": "v0rtex:1:dc7e45", "ysrc": "v0rtex:1:f937f8", "zmax": 7.37889649423163, "zmin": -5.85036747339283, "zsrc": "v0rtex:1:-dc7e45,f937f8", "xaxis": "x1", "xtype": "array", "yaxis": "y1", "ytype": "array", "visible": true, "colorscale": [ [ 0, "rgb(53.0655,42.4065,134.946)" ], [ 0.0158730158730159, "rgb(53.9641,48.3941,147.3074)" ], [ 0.0317460317460317, "rgb(54.1244,54.5117,159.8777)" ], [ 0.0476190476190476, "rgb(53.0655,60.843,172.6569)" ], [ 0.0634920634920635, "rgb(49.9557,67.4366,185.6145)" ], [ 0.0793650793650794, "rgb(43.5358,74.4442,198.7081)" ], [ 0.0952380952380952, "rgb(31.9442,82.6819,211.7192)" ], [ 0.111111111111111, "rgb(15.079,91.7575,221.425)" ], [ 0.126984126984127, "rgb(2.9823,98.8149,224.8991)" ], [ 0.142857142857143, "rgb(1.5191,104.1966,225.1249)" ], [ 0.158730158730159, "rgb(4.2111,108.783,224.0515)" ], [ 0.174603174603175, "rgb(8.3774,112.9759,222.3491)" ], [ 0.19047619047619, "rgb(12.7026,116.9357,220.3346)" ], [ 0.206349206349206, "rgb(16.048,120.7911,218.1367)" ], [ 0.222222222222222, "rgb(18.428,124.61,215.9085)" ], [ 0.238095238095238, "rgb(19.8754,128.5164,213.7847)" ], [ 0.253968253968254, "rgb(20.2336,132.6061,211.9511)" ], [ 0.26984126984127, "rgb(19.1104,137.0734,210.6992)" ], [ 0.285714285714286, "rgb(16.3346,142.0314,210.1091)" ], [ 0.301587301587302, "rgb(12.4367,147.1921,209.8213)" ], [ 0.317460317460317, "rgb(8.7574,152.1281,209.0624)" ], [ 0.333333333333333, "rgb(6.7575,156.4935,207.4425)" ], [ 0.349206349206349, "rgb(6.0921,160.3088,204.9593)" ], [ 0.365079365079365, "rgb(5.8881,163.6554,201.773)" ], [ 0.380952380952381, "rgb(5.8067,166.6389,198.0731)" ], [ 0.396825396825397, "rgb(6.7988,169.3698,193.9834)" ], [ 0.412698412698413, "rgb(9.7847,171.9392,189.6059)" ], [ 0.428571428571429, "rgb(15.0377,174.3581,184.9734)" ], [ 0.444444444444444, "rgb(21.4965,176.6725,180.0725)" ], [ 0.46031746031746, "rgb(28.8903,178.8825,174.8936)" ], [ 0.476190476190476, "rgb(37.0442,180.9881,169.4803)" ], [ 0.492063492063492, "rgb(45.934,183.0026,163.8205)" ], [ 0.507936507936508, "rgb(55.5463,184.8859,157.9118)" ], [ 0.523809523809524, "rgb(65.9539,186.5871,151.8343)" ], [ 0.53968253968254, "rgb(77.0537,188.0892,145.6524)" ], [ 0.555555555555556, "rgb(88.7825,189.3205,139.553)" ], [ 0.571428571428571, "rgb(100.7906,190.2045,133.7329)" ], [ 0.587301587301587, "rgb(112.7124,190.7606,128.3451)" ], [ 0.603174603174603, "rgb(124.2166,191.0108,123.4139)" ], [ 0.619047619047619, "rgb(135.1573,191.0241,118.8591)" ], [ 0.634920634920635, "rgb(145.5686,190.8724,114.5946)" ], [ 0.650793650793651, "rgb(155.5124,190.5651,110.5899)" ], [ 0.666666666666667, "rgb(165.0615,190.128,106.794)" ], [ 0.682539682539683, "rgb(174.2719,189.5864,103.1305)" ], [ 0.698412698412698, "rgb(183.1944,188.989,99.5714)" ], [ 0.714285714285714, "rgb(191.8839,188.292,96.0876)" ], [ 0.73015873015873, "rgb(200.3899,187.5695,92.6342)" ], [ 0.746031746031746, "rgb(208.7187,186.847,89.1966)" ], [ 0.761904761904762, "rgb(216.9176,186.1245,85.6873)" ], [ 0.777777777777778, "rgb(225.0205,185.4955,82.0335)" ], [ 0.793650793650794, "rgb(233.053,185.0754,78.1004)" ], [ 0.80952380952381, "rgb(240.9641,185.1591,73.6039)" ], [ 0.825396825396825, "rgb(248.3433,186.5058,67.9951)" ], [ 0.841269841269841, "rgb(253.4117,190.0916,61.2886)" ], [ 0.857142857142857, "rgb(254.7559,195.1551,55.1856)" ], [ 0.873015873015873, "rgb(253.861,200.4446,50.1464)" ], [ 0.888888888888889, "rgb(251.94,205.683,45.7385)" ], [ 0.904761904761905, "rgb(249.6086,210.9214,41.6451)" ], [ 0.920634920634921, "rgb(247.2735,216.2752,37.6004)" ], [ 0.936507936507937, "rgb(245.4594,221.9811,33.3795)" ], [ 0.952380952380952, "rgb(244.5122,228.1995,28.8769)" ], [ 0.968253968253968, "rgb(244.7551,235.0675,24.1837)" ], [ 0.984126984126984, "rgb(246.3555,242.6179,19.261)" ], [ 1, "rgb(248.9565,250.6905,13.719)" ] ], "showlegend": true } ], "layout": { "title": "<b><b></b></b>", "width": 840, "height": 630, "margin": { "b": 0, "l": 0, "r": 0, "t": 80, "pad": 0 }, "xaxis1": { "side": "bottom", "type": "linear", "anchor": "y1", "domain": [ 0.13, 0.905 ] }, "yaxis1": { "side": "left", "type": "linear", "anchor": "x1", "domain": [ 0.11, 0.925 ] }, "showlegend": false, "annotations": [] } }, "height": 630, "width": 840, "user": { "profile_url": "https://chart-studio.plotly.com/~v0rtex", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/98.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 14:41:41", "mapbox_access_tokens": null, "has_password": null, "username": "v0rtex", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:41:40.478432Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Angilaka/80.embed", "fid": "Angilaka:80", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Angilaka:80/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Angilaka/80/2_7HPSB25XIIVQ54VF2ZB8R2173XVKHD.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Angilaka/80/8_JF6Z418DIBQPRZHI9V797OP94BF3ZS.png", "list-thumb": "https://api.plotly.com/v2/files/Angilaka:80/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Angilaka:80", "plots": "https://api.plotly.com/v2/plots/Angilaka:80", "parent": "https://api.plotly.com/v2/folders/home?user=Angilaka" }, "owner": "Angilaka", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "FRYco3 MODIS_6 2008: 2D Density Plot", "views": 0, "web_url": "https://chart-studio.plotly.com/~Angilaka/80/fryco3-modis-6-2008-2d-density-plot/", "world_readable": true, "date_modified": "2019-06-17T14:43:45.653Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Angilaka/80/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": false, "caption": "", "figure": { "data": [ { "uid": "35eb0d32-360a-4a44-90bb-54f593425c37", "mode": "markers", "name": "points", "type": "scatter", "xsrc": "Angilaka:81:3c8c10", "ysrc": "Angilaka:81:739afa", "marker": { "size": 4, "color": "rgb(0, 0, 128)", "opacity": 0.4 } }, { "uid": "c3eeb43f-9f19-471b-b4d9-b0b2dbdcab2c", "name": "density", "type": "histogram2dcontour", "xsrc": "Angilaka:81:3c8c10", "ysrc": "Angilaka:81:739afa", "colorbar": { "title": { "text": "" } }, "contours": { "end": 30, "size": 2, "start": 0 }, "ncontours": 10, "showscale": false, "colorscale": [ [ 0, "rgb(122, 69, 121)" ], [ 0.25, "rgb(213, 96, 115)" ], [ 0.5, "rgb(236, 158, 105)" ], [ 0.75, "rgb(255, 255, 51)" ], [ 1, "rgb(250, 250, 250)" ] ], "reversescale": true }, { "uid": "a44e141f-2e90-4af0-884c-b00b89c555e3", "name": "x density", "type": "histogram", "xsrc": "Angilaka:81:3c8c10", "yaxis": "y2", "marker": { "color": "rgb(192, 192, 192)" } }, { "uid": "86df03ad-be80-4ea5-a198-f8e466860a1f", "name": "y density", "type": "histogram", "ysrc": "Angilaka:81:739afa", "xaxis": "x2", "marker": { "color": "rgb(192, 192, 192)" } } ], "frames": [], "layout": { "title": { "text": "FRYco3 MODIS_6 2008: 2D Density Plot" }, "width": 600, "xaxis": { "type": "linear", "range": [ 0, 365 ], "title": { "text": "DOB" }, "domain": [ 0, 0.85 ], "showgrid": false, "zeroline": false }, "yaxis": { "type": "linear", "range": [ 0, 25 ], "title": { "text": "BA per pixel [ha]" }, "domain": [ 0, 0.82 ], "showgrid": false, "zeroline": false }, "bargap": 0, "height": 600, "margin": { "t": 50 }, "xaxis2": { "range": [ 0, 1835.7894736842104 ], "title": { "text": "N" }, "domain": [ 0.85, 1 ], "showgrid": false, "zeroline": false, "autorange": true }, "yaxis2": { "range": [ 0, 256.8421052631579 ], "title": { "text": "N" }, "domain": [ 0.85, 1 ], "showgrid": false, "zeroline": false, "autorange": true }, "autosize": false, "hovermode": "closest", "showlegend": false } }, "height": 600, "width": 600, "user": { "profile_url": "https://chart-studio.plotly.com/~Angilaka", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 10:09:39", "mapbox_access_tokens": null, "has_password": null, "username": "Angilaka", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:40:53.282554Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~RRRRRRR/10.embed", "fid": "RRRRRRR:10", "filename": "soybean yield at county level", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/RRRRRRR:10/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/RRRRRRR:10/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/RRRRRRR:10/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/RRRRRRR:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/RRRRRRR:10", "plots": "https://api.plotly.com/v2/plots/RRRRRRR:10", "parent": "https://api.plotly.com/v2/folders/home?user=RRRRRRR" }, "owner": "RRRRRRR", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "soybean yield at county level", "views": 0, "web_url": "https://chart-studio.plotly.com/~RRRRRRR/10/soybean-yield-at-county-level/", "world_readable": true, "date_modified": "2019-06-21T08:59:43.928Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~RRRRRRR/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "x": [], "y": [], "uid": "28c4d323-6400-4256-94b6-5b39cd7b339d", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "< 5.0", "type": "scatter", "fillcolor": "#f7fbff", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "52e2098a-bf2c-4331-b241-6b04dd7a1573", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "5.0 - 9.67", "type": "scatter", "fillcolor": "#ebf3fb", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "dc7fc80d-385a-4ef5-afb9-7a12e117c0ee", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "9.67 - 14.33", "type": "scatter", "fillcolor": "#deebf7", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "49566df3-0474-43e5-a29a-46a077a7b058", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "14.33 - 19.0", "type": "scatter", "fillcolor": "#d2e3f3", "hoverinfo": "none" }, { "uid": "7744e883-b02b-4a51-814e-cc3314cba806", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "19.0 - 23.67", "type": "scatter", "xsrc": "RRRRRRR:11:d0d420", "ysrc": "RRRRRRR:11:a01b4f", "fillcolor": "#c6dbef", "hoverinfo": "none" }, { "uid": "cc7c7c06-b23c-4122-a1a7-194395f3ef42", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "23.67 - 28.33", "type": "scatter", "xsrc": "RRRRRRR:11:e05590", "ysrc": "RRRRRRR:11:27b5dd", "fillcolor": "#b3d2e9", "hoverinfo": "none" }, { "uid": "70c13ae0-408f-405f-8b08-046fd30611d9", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "28.33 - 33.0", "type": "scatter", "xsrc": "RRRRRRR:11:2d1340", "ysrc": "RRRRRRR:11:71d037", "fillcolor": "#9ecae1", "hoverinfo": "none" }, { "uid": "543f03ed-48ac-4733-b821-7cd3be10ac5b", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "33.0 - 37.67", "type": "scatter", "xsrc": "RRRRRRR:11:1179dd", "ysrc": "RRRRRRR:11:808fff", "fillcolor": "#85bcdb", "hoverinfo": "none" }, { "uid": "a40401d8-9822-4a6e-b940-5724e7b96458", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "37.67 - 42.33", "type": "scatter", "xsrc": "RRRRRRR:11:ef7a1c", "ysrc": "RRRRRRR:11:861f35", "fillcolor": "#6baed6", "hoverinfo": "none" }, { "uid": "7dd5f715-f8d0-4dec-a3c4-8c22a583c7c1", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "42.33 - 47.0", "type": "scatter", "xsrc": "RRRRRRR:11:7ede97", "ysrc": "RRRRRRR:11:8befa1", "fillcolor": "#57a0ce", "hoverinfo": "none" }, { "uid": "fdcb5320-c182-4cbd-9d71-91f2e1cbab71", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "47.0 - 51.67", "type": "scatter", "xsrc": "RRRRRRR:11:45b8d3", "ysrc": "RRRRRRR:11:3800d6", "fillcolor": "#4292c6", "hoverinfo": "none" }, { "uid": "cadb3c6d-e9e0-43e9-af80-454afb1629b7", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "51.67 - 56.33", "type": "scatter", "xsrc": "RRRRRRR:11:3c1d04", "ysrc": "RRRRRRR:11:0f28e4", "fillcolor": "#3082be", "hoverinfo": "none" }, { "uid": "37d35660-fc4b-42c3-b1b8-43bd96e46d20", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "56.33 - 61.0", "type": "scatter", "xsrc": "RRRRRRR:11:a7e0f4", "ysrc": "RRRRRRR:11:bc1b1d", "fillcolor": "#2171b5", "hoverinfo": "none" }, { "uid": "89fcbcc1-26c1-42be-b3c9-dbd339a95dee", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "61.0 - 65.67", "type": "scatter", "xsrc": "RRRRRRR:11:1ac244", "ysrc": "RRRRRRR:11:68abbe", "fillcolor": "#1361a9", "hoverinfo": "none" }, { "uid": "6da1f3d4-9f8c-4eea-bc3a-4a4683c7bce9", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "65.67 - 70.33", "type": "scatter", "xsrc": "RRRRRRR:11:c51aa0", "ysrc": "RRRRRRR:11:4e61b5", "fillcolor": "#08519c", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "0293f584-b8db-471e-a176-55c49aaf35c1", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "70.33 - 75.0", "type": "scatter", "fillcolor": "#0b4083", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "577515f2-5152-4d42-8272-62fbbbfa80d8", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "> 75.0", "type": "scatter", "fillcolor": "#08306b", "hoverinfo": "none" }, { "uid": "c2fd4906-8f6d-43b0-8386-cd1692557602", "mode": "markers", "name": "US Counties", "type": "scatter", "xsrc": "RRRRRRR:11:df27f0", "ysrc": "RRRRRRR:11:766504", "marker": { "color": "white", "opacity": 0 }, "textsrc": "RRRRRRR:11:5dae73", "selected": { "marker": { "opacity": 0 } }, "hoverinfo": "text", "showlegend": false, "unselected": { "marker": { "opacity": 0 } }, "legendgroup": "centroids" }, { "uid": "6d4c1078-d4c9-48ac-970d-6be12685764a", "line": { "color": "rgb(240, 240, 240)", "width": 1 }, "mode": "lines", "type": "scatter", "xsrc": "RRRRRRR:11:7f8548", "ysrc": "RRRRRRR:11:5428e9", "hoverinfo": "text", "showlegend": false, "legendgroup": "States" } ], "layout": { "title": { "text": "soybean yield at county level" }, "width": 900, "xaxis": { "range": [ -125.0, -55.0 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "yaxis": { "range": [ 24.93103448275862, 49.06896551724138 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "height": 450, "legend": { "x": 1, "y": 1, "xanchor": "right", "yanchor": "top", "traceorder": "reversed" }, "margin": { "b": 20, "l": 20, "r": 20, "t": 40 }, "dragmode": "select", "hovermode": "closest", "annotations": [ { "x": 1, "y": 1.05, "text": "<b>yield</b>", "xref": "paper", "yref": "paper", "xanchor": "right", "showarrow": false } ] } }, "height": 450, "width": 900, "user": { "profile_url": "https://chart-studio.plotly.com/~RRRRRRR", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 12:47:54", "mapbox_access_tokens": null, "has_password": null, "username": "RRRRRRR", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:40:12.951499Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~orenkishon1/1.embed", "fid": "orenkishon1:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/orenkishon1:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/orenkishon1/1/2_5M5WFZPO8YUAMLX9N9D33E5JJ4RM8Y.png", "block-thumb": "https://api.plotly.com/v2/files/orenkishon1:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/orenkishon1:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/orenkishon1:1", "plots": "https://api.plotly.com/v2/plots/orenkishon1:1", "parent": "https://api.plotly.com/v2/folders/home?user=orenkishon1" }, "owner": "orenkishon1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~orenkishon1/1/", "world_readable": true, "date_modified": "2019-06-17T14:40:12.967Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~orenkishon1/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "orenkishon1:0:65d16d", "ysrc": "orenkishon1:0:06a75b", "marker": { "line": { "width": 0 }, "size": 2, "color": "#636efa" }, "stackgaps": "interpolate", "stackgroup": "", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "July 17, 2019: Access by folder ID" }, "xaxis": { "type": "category", "range": [ -31.463807155684478, 554.4638071556844 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -1949.3977900552488, 29427.39779005525 ], "autorange": true, "tickformat": "", "exponentformat": "none", "separatethousands": false }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~orenkishon1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/22.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 14:39:10", "mapbox_access_tokens": null, "has_password": null, "username": "orenkishon1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:39:34.745206Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~yyyyyywwwwz/4.embed", "fid": "yyyyyywwwwz:4", "filename": "plot from API (2)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/yyyyyywwwwz:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/yyyyyywwwwz:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/yyyyyywwwwz:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/yyyyyywwwwz:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/yyyyyywwwwz:4", "plots": "https://api.plotly.com/v2/plots/yyyyyywwwwz:4", "parent": "https://api.plotly.com/v2/folders/home?user=yyyyyywwwwz" }, "owner": "yyyyyywwwwz", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Not Normalized vs Normalized", "views": 0, "web_url": "https://chart-studio.plotly.com/~yyyyyywwwwz/4/not-normalized-vs-normalized/", "world_readable": true, "date_modified": "2019-06-17T14:39:35.175Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~yyyyyywwwwz/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ac5ce5cb-f5fc-4685-bb1f-22912a78c3c0", "name": "Not Normalized", "type": "box", "xsrc": "yyyyyywwwwz:5:857780", "ysrc": "yyyyyywwwwz:5:c8c78c", "marker": { "color": "#3D9970" }, "boxmean": false, "orientation": "h" }, { "uid": "cafefae1-1c02-435c-9e56-02e76a6ac812", "name": "Normalized", "type": "box", "xsrc": "yyyyyywwwwz:5:08e712", "ysrc": "yyyyyywwwwz:5:c8c78c", "marker": { "color": "rgba(127, 96, 0, 0.5)" }, "boxmean": false, "orientation": "h" } ], "layout": { "xaxis": { "zeroline": false }, "boxmode": "group" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~yyyyyywwwwz", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/59.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 13:38:33", "mapbox_access_tokens": null, "has_password": null, "username": "yyyyyywwwwz", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:39:13.395261Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~RRRRRRR/8.embed", "fid": "RRRRRRR:8", "filename": "corn yield at county level", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/RRRRRRR:8/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/RRRRRRR/8/2_QFO5ENPBHLMD0XQGIBTSQ8B0LD8HP1.png", "block-thumb": "https://api.plotly.com/v2/files/RRRRRRR:8/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/RRRRRRR:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/RRRRRRR:8", "plots": "https://api.plotly.com/v2/plots/RRRRRRR:8", "parent": "https://api.plotly.com/v2/folders/home?user=RRRRRRR" }, "owner": "RRRRRRR", "parent": -1, "preview": "", "referencers": [], "references": [], "title": " corn yield at county level", "views": 1, "web_url": "https://chart-studio.plotly.com/~RRRRRRR/8/corn-yield-at-county-level/", "world_readable": true, "date_modified": "2019-06-21T08:59:32.473Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~RRRRRRR/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "x": [], "y": [], "uid": "2eba9d55-ebb1-4618-af97-9bff0b3f3e4c", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "< 10.0", "type": "scatter", "fillcolor": "#f7fbff", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "6f003e8c-91a7-4858-ae8b-e2c9187840a3", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "10.0 - 26.0", "type": "scatter", "fillcolor": "#ebf3fb", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "52668a6f-2c8d-411d-80ac-2cab2525fa28", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "26.0 - 42.0", "type": "scatter", "fillcolor": "#deebf7", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "0bf3bf01-70ce-45b1-abac-611ecef14428", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "42.0 - 58.0", "type": "scatter", "fillcolor": "#d2e3f3", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "ab02a383-b314-4ba8-b257-38f1a5ba9ccd", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "58.0 - 74.0", "type": "scatter", "fillcolor": "#c6dbef", "hoverinfo": "none" }, { "uid": "847e0516-9641-4270-92bc-21b5e10a4fd0", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "74.0 - 90.0", "type": "scatter", "xsrc": "RRRRRRR:9:64e14a", "ysrc": "RRRRRRR:9:f79428", "fillcolor": "#b3d2e9", "hoverinfo": "none" }, { "uid": "a474e4cb-b29f-4d12-99c6-7e041272579b", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "90.0 - 106.0", "type": "scatter", "xsrc": "RRRRRRR:9:5aefef", "ysrc": "RRRRRRR:9:f5097f", "fillcolor": "#9ecae1", "hoverinfo": "none" }, { "uid": "321cf2e9-16d5-4994-8dc1-cb40a8ed28fd", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "106.0 - 122.0", "type": "scatter", "xsrc": "RRRRRRR:9:9e76fd", "ysrc": "RRRRRRR:9:76b5ad", "fillcolor": "#85bcdb", "hoverinfo": "none" }, { "uid": "7789f60f-e03e-4ed8-ab64-d4c8f3f23d5b", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "122.0 - 138.0", "type": "scatter", "xsrc": "RRRRRRR:9:3c1e04", "ysrc": "RRRRRRR:9:fa4fe3", "fillcolor": "#6baed6", "hoverinfo": "none" }, { "uid": "bf5ca9b5-113f-4f6f-b1c4-60df526e8491", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "138.0 - 154.0", "type": "scatter", "xsrc": "RRRRRRR:9:3700c7", "ysrc": "RRRRRRR:9:fe1b85", "fillcolor": "#57a0ce", "hoverinfo": "none" }, { "uid": "a0757cf9-2687-4b23-86b3-af4a50ef62ee", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "154.0 - 170.0", "type": "scatter", "xsrc": "RRRRRRR:9:91208b", "ysrc": "RRRRRRR:9:50e114", "fillcolor": "#4292c6", "hoverinfo": "none" }, { "uid": "5d9b749d-8248-4431-8cd6-5efee70621ec", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "170.0 - 186.0", "type": "scatter", "xsrc": "RRRRRRR:9:7aa1d7", "ysrc": "RRRRRRR:9:2e81e0", "fillcolor": "#3082be", "hoverinfo": "none" }, { "uid": "3f84ae94-afbe-4b54-8d1b-a67e4204dfcb", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "186.0 - 202.0", "type": "scatter", "xsrc": "RRRRRRR:9:c75855", "ysrc": "RRRRRRR:9:a190c2", "fillcolor": "#2171b5", "hoverinfo": "none" }, { "uid": "15f0b77a-53ca-44ea-9755-b604dc493cff", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "202.0 - 218.0", "type": "scatter", "xsrc": "RRRRRRR:9:ef96d7", "ysrc": "RRRRRRR:9:6f41f4", "fillcolor": "#1361a9", "hoverinfo": "none" }, { "uid": "1aaccaef-802f-4b4b-893b-da004cdae4fa", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "218.0 - 234.0", "type": "scatter", "xsrc": "RRRRRRR:9:0b2dd4", "ysrc": "RRRRRRR:9:646f46", "fillcolor": "#08519c", "hoverinfo": "none" }, { "uid": "6926f809-23a4-4daf-bc4e-09932fac8579", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "234.0 - 250.0", "type": "scatter", "xsrc": "RRRRRRR:9:152f70", "ysrc": "RRRRRRR:9:88e367", "fillcolor": "#0b4083", "hoverinfo": "none" }, { "x": [], "y": [], "uid": "6d41be82-fd9c-45a3-9151-aebb730634c7", "fill": "toself", "line": { "color": "rgb(0, 0, 0)", "width": 0 }, "mode": "lines", "name": "> 250.0", "type": "scatter", "fillcolor": "#08306b", "hoverinfo": "none" }, { "uid": "7725a451-0e68-4ecb-80ef-b7ea3a38ddaa", "mode": "markers", "name": "US Counties", "type": "scatter", "xsrc": "RRRRRRR:9:976320", "ysrc": "RRRRRRR:9:862c44", "marker": { "color": "white", "opacity": 0 }, "textsrc": "RRRRRRR:9:e47634", "selected": { "marker": { "opacity": 0 } }, "hoverinfo": "text", "showlegend": false, "unselected": { "marker": { "opacity": 0 } }, "legendgroup": "centroids" }, { "uid": "e8437101-4a96-479a-8966-8211c17c42f7", "line": { "color": "rgb(240, 240, 240)", "width": 1 }, "mode": "lines", "type": "scatter", "xsrc": "RRRRRRR:9:2aefc3", "ysrc": "RRRRRRR:9:7a270e", "hoverinfo": "text", "showlegend": false, "legendgroup": "States" } ], "layout": { "title": { "text": " corn yield at county level" }, "width": 900, "xaxis": { "range": [ -125.0, -55.0 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "yaxis": { "range": [ 24.93103448275862, 49.06896551724138 ], "showgrid": false, "zeroline": false, "autorange": false, "fixedrange": true, "showticklabels": false }, "height": 450, "legend": { "x": 1, "y": 1, "xanchor": "right", "yanchor": "top", "traceorder": "reversed" }, "margin": { "b": 20, "l": 20, "r": 20, "t": 40 }, "dragmode": "select", "hovermode": "closest", "annotations": [ { "x": 1, "y": 1.05, "text": "<b>yield</b>", "xref": "paper", "yref": "paper", "xanchor": "right", "showarrow": false } ] } }, "height": 450, "width": 900, "user": { "profile_url": "https://chart-studio.plotly.com/~RRRRRRR", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 12:47:54", "mapbox_access_tokens": null, "has_password": null, "username": "RRRRRRR", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:38:10.029356Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~agoodric/0.embed", "fid": "agoodric:0", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/agoodric:0/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/agoodric/0/2_RKUO2RSZN0J8N00JI3MPI835EBZ22Y.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/agoodric/0/8_DTKA2UXPL31UYVHRZG6PLX3ZICYOOT.png", "list-thumb": "https://api.plotly.com/v2/files/agoodric:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/agoodric:0", "plots": "https://api.plotly.com/v2/plots/agoodric:0", "parent": "https://api.plotly.com/v2/folders/home?user=agoodric" }, "owner": "agoodric", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Basic Sankey Diagram", "views": 11, "web_url": "https://chart-studio.plotly.com/~agoodric/0/basic-sankey-diagram/", "world_readable": true, "date_modified": "2019-06-17T14:38:10.552Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~agoodric/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "link": { "valuesrc": "agoodric:1:c4caf4", "sourcesrc": "agoodric:1:1ec767", "targetsrc": "agoodric:1:06123a" }, "node": { "pad": 15, "line": { "color": "black", "width": 0.5 }, "colorsrc": "agoodric:1:19266c", "labelsrc": "agoodric:1:27b3b0", "thickness": 20 }, "type": "sankey" } ], "layout": { "font": { "size": 10 }, "title": "Basic Sankey Diagram" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~agoodric", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/66.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-14 15:45:43", "mapbox_access_tokens": null, "has_password": null, "username": "agoodric", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:37:21.323818Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~zslt/16.embed", "fid": "zslt:16", "filename": "execkms-histogram", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/zslt:16/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/zslt/16/2_P6SVFAPDBB8BEZANR9XNISMBJ8OB3R.png", "block-thumb": "https://api.plotly.com/v2/files/zslt:16/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/zslt:16/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/zslt:16", "plots": "https://api.plotly.com/v2/plots/zslt:16", "parent": "https://api.plotly.com/v2/folders/home?user=zslt" }, "owner": "zslt", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Job distances", "views": 8, "web_url": "https://chart-studio.plotly.com/~zslt/16/job-distances/", "world_readable": true, "date_modified": "2019-06-28T11:44:52.298Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~zslt/16/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "e31910d1-ed40-42b3-9f57-99a127c9f299", "type": "histogram", "xsrc": "zslt:17:c4c8a6" } ], "layout": { "title": { "text": "Job distances" }, "xaxis": { "title": { "text": "Distance in km" } }, "yaxis": { "title": { "text": "Job" } }, "bargap": 0.2, "shapes": [ { "x0": 466.007, "x1": 466.007, "y0": -0.1, "y1": 1, "line": { "dash": "solid", "color": "#0099FF", "width": 1 }, "xref": "x", "yref": "paper" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~zslt", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/48.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-11 15:23:22", "mapbox_access_tokens": null, "has_password": null, "username": "zslt", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:35:43.703739Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ntr002/1.embed", "fid": "ntr002:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ntr002:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ntr002/1/2_DEQNHA7ZD8ZLTG71IX1HBZ5T6XOTEJ.png", "block-thumb": "https://api.plotly.com/v2/files/ntr002:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ntr002:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ntr002:1", "plots": "https://api.plotly.com/v2/plots/ntr002:1", "parent": "https://api.plotly.com/v2/folders/home?user=ntr002" }, "owner": "ntr002", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 25, "web_url": "https://chart-studio.plotly.com/~ntr002/1/", "world_readable": true, "date_modified": "2019-06-17T14:36:22.888Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ntr002/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "9623a328-5a81-49e5-ae0b-2c4ab9007b17", "type": "heatmap", "xsrc": "ntr002:0:1fdbda", "ysrc": "ntr002:0:5fd419", "zsrc": "ntr002:0:09f778,22d84d,e05617", "showscale": false, "colorscale": "Viridis", "reversescale": false } ], "frames": [], "layout": { "title": { "text": "Outstanding Dues" }, "xaxis": { "side": "top", "type": "category", "dtick": 1, "range": [ -0.5, 2.5 ], "ticks": "", "title": { "text": "Click to enter X axis title" }, "autorange": true, "gridcolor": "rgb(0, 0, 0)" }, "yaxis": { "type": "category", "dtick": 1, "range": [ -0.5, 2.5 ], "ticks": "", "title": { "text": "Propensity to pay Back" }, "autorange": true, "ticksuffix": " " }, "annotations": [ { "x": "Low", "y": "High", "font": { "color": "#FFFFFF" }, "text": "Minimal Collections Efforts", "xref": "x", "yref": "y", "showarrow": false }, { "x": "Medium", "y": "High", "font": { "color": "#FFFFFF" }, "text": "Strict Follow-Up", "xref": "x", "yref": "y", "showarrow": false }, { "x": "High", "y": "High", "font": { "color": "#FFFFFF" }, "text": "Accelerated Collection Efforts", "xref": "x", "yref": "y", "showarrow": false }, { "x": "Low", "y": "Medium", "font": { "color": "#000000" }, "text": "Minimal Collections Efforts", "xref": "x", "yref": "y", "showarrow": false }, { "x": "Medium", "y": "Medium", "font": { "color": "#000000" }, "text": "Steady Follow-Up", "xref": "x", "yref": "y", "showarrow": false }, { "x": "High", "y": "Medium", "font": { "color": "#FFFFFF" }, "text": "Strict Follow-Up", "xref": "x", "yref": "y", "showarrow": false }, { "x": "Low", "y": "Low", "font": { "color": "#000000" }, "text": "<a href=\"/vgood/Sites/n1.html/?sub=low\" target=\"_self\">Low</a>", "xref": "x", "yref": "y", "showarrow": false }, { "x": "Medium", "y": "Low", "font": { "color": "#000000" }, "text": "Do Nothing", "xref": "x", "yref": "y", "showarrow": false }, { "x": "High", "y": "Low", "font": { "color": "#FFFFFF" }, "text": "Steady Follow-Up", "xref": "x", "yref": "y", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ntr002", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/61.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 14:35:26", "mapbox_access_tokens": null, "has_password": null, "username": "ntr002", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-06-17T14:34:20.258075Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jmunozu/0.embed", "fid": "jmunozu:0", "filename": "basic-line", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/jmunozu:0/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/jmunozu:0/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/jmunozu/0/8_T9QLQRPLTX118I32WNWXFKR4XJGEHG.png", "list-thumb": "https://api.plotly.com/v2/files/jmunozu:0/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jmunozu:0", "plots": "https://api.plotly.com/v2/plots/jmunozu:0", "parent": "https://api.plotly.com/v2/folders/home?user=jmunozu" }, "owner": "jmunozu", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~jmunozu/0/", "world_readable": true, "date_modified": "2019-07-02T14:41:42.817Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jmunozu/0/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "d6601f44-1938-40a7-9af6-c5ffe40f5ad7", "type": "scatter", "xsrc": "jmunozu:1:923d74", "ysrc": "jmunozu:1:dd1a1a" }, { "uid": "b0aade9e-ef32-4739-a006-9dacd7c3cab6", "type": "scatter", "xsrc": "jmunozu:1:923d74", "ysrc": "jmunozu:1:7c4712" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jmunozu", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/91.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-06-17 13:36:30", "mapbox_access_tokens": null, "has_password": null, "username": "jmunozu", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
