Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDE5LTA0LTIyKzAyJTNBMTQlM0ExMi4wNTM1ODAlMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots?cursor=cD0yMDE5LTA0LTIyKzAxJTNBNTclM0E1NC44NTg1MDUlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots?cursor=cj0xJnA9MjAxOS0wNC0yMiswMiUzQTEzJTNBNTEuNjcwODg3JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2019-04-22T02:13:51.670887Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~sonal987/3.embed", "fid": "sonal987:3", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/sonal987:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/sonal987:3/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/sonal987:3/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/sonal987:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sonal987:3", "plots": "https://api.plotly.com/v2/plots/sonal987:3", "parent": "https://api.plotly.com/v2/folders/home?user=sonal987" }, "owner": "sonal987", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Sales Over Time", "views": 0, "web_url": "https://plotly.com/~sonal987/3/sales-over-time/", "world_readable": true, "date_modified": "2019-04-22T02:13:52.110Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~sonal987/3/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "2013", "type": "scatter", "xsrc": "sonal987:4:633623", "ysrc": "sonal987:4:715d0b", "opacity": 0.8 }, { "name": "2014", "type": "scatter", "xsrc": "sonal987:4:6ccd1d", "ysrc": "sonal987:4:8ec146", "opacity": 0.8 }, { "name": "2015", "type": "scatter", "xsrc": "sonal987:4:aae189", "ysrc": "sonal987:4:00dbdc", "opacity": 0.8 } ], "layout": { "title": "Sales Over Time", "xaxis": { "title": "Date" }, "yaxis": { "title": "Sales" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~sonal987", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-06-18 03:35:07", "mapbox_access_tokens": null, "has_password": null, "username": "sonal987", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:11:25.315114Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~ah040604/53.embed", "fid": "ah040604:53", "filename": "Plot 53", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/ah040604:53/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/ah040604:53/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/ah040604:53/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/ah040604:53/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ah040604:53", "plots": "https://api.plotly.com/v2/plots/ah040604:53", "parent": "https://api.plotly.com/v2/folders/home?user=ah040604" }, "owner": "ah040604", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://plotly.com/~ah040604/53/", "world_readable": true, "date_modified": "2019-04-22T02:11:25.378Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~ah040604/53/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "lines", "name": "rana draytonii alone", "type": "scatter", "ysrc": "ah040604:49:ab1052" }, { "mode": "lines", "name": "pseudacris regilla alone", "type": "scatter", "ysrc": "ah040604:51:e89b1e", "stackgroup": null }, { "mode": "lines", "name": "pseudacis regilla w/ rana catesbeiana", "type": "scatter", "ysrc": "ah040604:50:cf2f6a", "stackgroup": null }, { "mode": "lines", "name": "rana draytonii w/ rana catesbeiana", "type": "scatter", "ysrc": "ah040604:52:96e845", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "rana draytonii & pseudacris regilla v. rana catesbeiana" }, "xaxis": { "range": [ 0, 5 ], "title": { "text": "time" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 138.88888888888889, 1361.111111111111 ], "title": { "text": "population numbers" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~ah040604", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/69.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2017-08-29 16:26:56", "mapbox_access_tokens": null, "has_password": null, "username": "ah040604", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:11:03.580528Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~sonal987/1.embed", "fid": "sonal987:1", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/sonal987:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/sonal987:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/sonal987:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/sonal987:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sonal987:1", "plots": "https://api.plotly.com/v2/plots/sonal987:1", "parent": "https://api.plotly.com/v2/folders/home?user=sonal987" }, "owner": "sonal987", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Sales Distribution", "views": 0, "web_url": "https://plotly.com/~sonal987/1/sales-distribution/", "world_readable": true, "date_modified": "2019-04-22T02:11:05.875Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~sonal987/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "histogram", "xsrc": "sonal987:2:b088e6", "marker": { "color": "pink" } } ], "layout": { "title": "Sales Distribution", "xaxis": { "title": "daily sales in $" }, "yaxis": { "title": "number of observations" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~sonal987", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/60.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2018-06-18 03:35:07", "mapbox_access_tokens": null, "has_password": null, "username": "sonal987", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:10:48.024418Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~zmark/4.embed", "fid": "zmark:4", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/zmark:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/zmark:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/zmark:4/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/zmark:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/zmark:4", "plots": "https://api.plotly.com/v2/plots/zmark:4", "parent": "https://api.plotly.com/v2/folders/home?user=zmark" }, "owner": "zmark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Marks Distribution", "views": 1, "web_url": "https://plotly.com/~zmark/4/marks-distribution/", "world_readable": true, "date_modified": "2019-04-22T02:10:48.402Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~zmark/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "8dcfa743-b267-41cc-8114-0853c8d1fae3", "type": "bar", "xsrc": "zmark:5:a0d40d", "ysrc": "zmark:5:9a47b4" } ], "layout": { "title": { "text": "Marks Distribution" }, "xaxis": { "title": { "text": "Subjects" } }, "yaxis": { "title": { "text": "Marks" } } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~zmark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/71.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-06 05:01:26", "mapbox_access_tokens": null, "has_password": null, "username": "zmark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:09:37.330882Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~zmark/2.embed", "fid": "zmark:2", "filename": "plot from API", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/zmark:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/zmark:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/zmark:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/zmark:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/zmark:2", "plots": "https://api.plotly.com/v2/plots/zmark:2", "parent": "https://api.plotly.com/v2/folders/home?user=zmark" }, "owner": "zmark", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Marks Distribution", "views": 0, "web_url": "https://plotly.com/~zmark/2/marks-distribution/", "world_readable": true, "date_modified": "2019-04-22T02:09:37.830Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~zmark/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "7d1dc715-1e73-4e6c-a456-c079fa29a3ad", "type": "bar", "xsrc": "zmark:3:64b2e7", "ysrc": "zmark:3:800fe4" } ], "layout": { "title": { "text": "Marks Distribution" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~zmark", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/71.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-06 05:01:26", "mapbox_access_tokens": null, "has_password": null, "username": "zmark", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:05:50.277303Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~WeixiangFang/42.embed", "fid": "WeixiangFang:42", "filename": "panc_rna_joint_embed", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/WeixiangFang:42/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/WeixiangFang:42/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/WeixiangFang/42/8_I9SS0D89L08MVJJ4UH87J1N1LK5H1X.png", "list-thumb": "https://api.plotly.com/v2/files/WeixiangFang:42/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/WeixiangFang:42", "plots": "https://api.plotly.com/v2/plots/WeixiangFang:42", "parent": "https://api.plotly.com/v2/folders/home?user=WeixiangFang" }, "owner": "WeixiangFang", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://plotly.com/~WeixiangFang/42/", "world_readable": true, "date_modified": "2019-04-22T02:05:50.289Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~WeixiangFang/42/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "WeixiangFang:41:d881ee", "ysrc": "WeixiangFang:41:e148bb", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "width": 0, "colorsrc": "WeixiangFang:41:bff0d9" }, "opacity": 0.75, "colorsrc": "WeixiangFang:41:a5754a" }, "textsrc": "WeixiangFang:41:a73404", "textfont": { "colorsrc": "WeixiangFang:41:b63cb5" }, "showlegend": true }, { "mode": "markers", "name": "ENCODE Bulk RNA-seq", "type": "scatter", "xsrc": "WeixiangFang:41:12965e", "ysrc": "WeixiangFang:41:6a5d8d", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "#385170", "width": 5 }, "size": 10, "color": "#c8e6f5", "symbol": 6, "opacity": 1 }, "textsrc": "WeixiangFang:41:42fdc0", "textfont": { "colorsrc": "WeixiangFang:41:fbfb4f" }, "showlegend": true, "hoverinfosrc": "WeixiangFang:41:59eb54" } ], "layout": { "xaxis": { "title": "X1", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "X2", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~WeixiangFang", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2013-11-02 17:29:20", "mapbox_access_tokens": null, "has_password": null, "username": "WeixiangFang", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:05:34.270428Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~JacksonTransy/1.embed", "fid": "JacksonTransy:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/JacksonTransy:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/JacksonTransy:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/JacksonTransy:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/JacksonTransy:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/JacksonTransy:1", "plots": "https://api.plotly.com/v2/plots/JacksonTransy:1", "parent": "https://api.plotly.com/v2/folders/home?user=JacksonTransy" }, "owner": "JacksonTransy", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://plotly.com/~JacksonTransy/1/", "world_readable": true, "date_modified": "2019-04-22T02:05:34.285Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~JacksonTransy/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "Full (male)", "type": "box", "ysrc": "JacksonTransy:0:2901ba", "boxpoints": false }, { "name": "Full (female)", "type": "box", "ysrc": "JacksonTransy:0:5fae9b", "boxpoints": false }, { "name": "Associate (male)", "type": "box", "ysrc": "JacksonTransy:0:68dfb3", "boxpoints": false }, { "name": "Associate (female)", "type": "box", "ysrc": "JacksonTransy:0:0fdfa7", "boxpoints": false }, { "name": "Assistant (male)", "type": "box", "ysrc": "JacksonTransy:0:877899", "boxpoints": false }, { "name": "Assistant (female)", "type": "box", "ysrc": "JacksonTransy:0:bef304", "boxpoints": false } ], "frames": [], "layout": { "title": { "text": "Box plot for base salary by rank and gender" }, "xaxis": { "type": "category", "range": [ -0.5, 5.5 ], "autorange": false }, "yaxis": { "type": "linear", "range": [ 42117.333333333336, 99770.66666666667 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~JacksonTransy", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/10.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 02:04:59", "mapbox_access_tokens": null, "has_password": null, "username": "JacksonTransy", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:04:27.705476Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~IFFranciscoME/64.embed", "fid": "IFFranciscoME:64", "filename": "scatter-mode", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/IFFranciscoME:64/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/IFFranciscoME:64/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/IFFranciscoME/64/8_VD44CBTILBZD4IF07ZTAPFSSZHN8TG.png", "list-thumb": "https://api.plotly.com/v2/files/IFFranciscoME:64/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/IFFranciscoME:64", "plots": "https://api.plotly.com/v2/plots/IFFranciscoME:64", "parent": "https://api.plotly.com/v2/folders/home?user=IFFranciscoME" }, "owner": "IFFranciscoME", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "markers, lines+markers, lines", "views": 0, "web_url": "https://plotly.com/~IFFranciscoME/64/markers-linesmarkers-lines/", "world_readable": true, "date_modified": "2019-04-22T02:04:28.117Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~IFFranciscoME/64/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "edc7206c-1ab7-456b-a847-bd2a3762cef7", "mode": "markers", "name": "markers", "type": "scatter", "xsrc": "IFFranciscoME:65:0b82e6", "ysrc": "IFFranciscoME:65:4392d7" }, { "uid": "5f39418d-b0d9-4bd3-af51-03ab701be2e7", "mode": "lines+markers", "name": "lines+markers", "type": "scatter", "xsrc": "IFFranciscoME:65:0b82e6", "ysrc": "IFFranciscoME:65:62668c" }, { "uid": "9f8c4142-3379-4b13-8239-a2b6acc5224f", "mode": "lines", "name": "lines", "type": "scatter", "xsrc": "IFFranciscoME:65:0b82e6", "ysrc": "IFFranciscoME:65:5a4297" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~IFFranciscoME", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "Financial Engineer + Data Scientist", "nickname": "IF.Francisco.ME", "website": "https://iffranciscome.wordpress.com/", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2015-10-20 18:21:20", "mapbox_access_tokens": null, "has_password": null, "username": "IFFranciscoME", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T02:03:58.865083Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~kevinshuang/6.embed", "fid": "kevinshuang:6", "filename": "GA_flow_shop_scheduling_tardyjob", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/kevinshuang:6/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/kevinshuang:6/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/kevinshuang:6/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/kevinshuang:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/kevinshuang:6", "plots": "https://api.plotly.com/v2/plots/kevinshuang:6", "parent": "https://api.plotly.com/v2/folders/home?user=kevinshuang" }, "owner": "kevinshuang", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "Gantt Chart", "views": 0, "web_url": "https://plotly.com/~kevinshuang/6/gantt-chart/", "world_readable": true, "date_modified": "2019-04-22T02:03:59.323Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~kevinshuang/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "da1631ee-53ad-45e7-bd51-87ed29b4e6c7", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:2d2003", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "c2be8c12-c4b2-4dcd-95a3-87c12eb91305", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:35f3be", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "519ffe52-06ac-49af-a3fb-381af0378c25", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:1b0df4", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "c2916502-7499-4658-a84a-96a82124b554", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:af461e", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "c51938a0-a9bd-4857-bc1d-0a8094340e94", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:001b6a", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "41a86464-7cb5-4dea-ad30-e7bfca1df5dd", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:a62c48", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "b99f809c-53d2-450b-8649-f298cfb3d00b", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:c5b20e", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "3439e6e7-e5ab-42f7-9840-1b2c8e6df459", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:db17fe", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "e29a925b-05d4-4ffc-bea7-cbddc0d27014", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:8cb3a0", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "bf003944-bb88-4848-af0f-2b1c3ed5cfb0", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:ee32a2", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "5f387a8e-ae83-4799-bfbf-5c29483a25e1", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:a969ec", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "c29ce697-39f7-4db8-8cef-daeb92d0dc71", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:c2f21a", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "c131449d-da73-4bb1-9fca-86061a278c0c", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:d5eb6f", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "f2b83928-759d-4f49-ab23-9be230fe3820", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:ee1ddb", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "91a66bad-aa0f-41ab-9862-a3bcd094cc1d", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:5514b9", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "cd7f29a7-e3ad-492d-b364-979a360ebaf2", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:272d86", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "f48fca08-ff31-4b0a-9129-72d7c9efef6b", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:2e0833", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "f17993f1-ba88-46fd-80a9-1cefd4521e56", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:7959d2", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "f1a6378b-589f-464a-974b-acd4edf78c09", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:a3f8a6", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "18f46b23-0b9e-41a9-814c-9707b6d70e0f", "name": "", "type": "scatter", "xsrc": "kevinshuang:7:e8cc1d", "ysrc": "kevinshuang:7:88a626", "marker": { "color": "white" } }, { "uid": "b40b590d-f509-446c-aa1c-d003199dcc48", "name": "Job 1", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:88a626", "marker": { "size": 1, "color": "rgb(0, 139, 0)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "8e3f0625-b76d-4460-9622-b6ac1df8da5b", "name": "Job 10", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:0846b5", "marker": { "size": 1, "color": "rgb(255, 140, 0)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "c22c5915-25ae-4914-972c-843ad14ecad2", "name": "Job 11", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:51c17f", "marker": { "size": 1, "color": "rgb(227, 207, 87)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "1480c017-20ea-47ad-9f4f-ee075bd848eb", "name": "Job 12", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:1b4ce0", "marker": { "size": 1, "color": "rgb(0, 0, 205)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "673f602e-c6b1-4524-a590-e0110aee3c2f", "name": "Job 13", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:cfe8b1", "marker": { "size": 1, "color": "rgb(122, 197, 205)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "7974b724-af52-4246-aa50-32c66124c326", "name": "Job 14", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:9d8da1", "marker": { "size": 1, "color": "rgb(237, 145, 33)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "4f83fcaf-613c-48b3-bb28-aa162ba3fa65", "name": "Job 15", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:084a00", "marker": { "size": 1, "color": "rgb(118, 238, 0)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "0b4fcc14-ebd4-44d3-9dc0-d759bbae3df6", "name": "Job 16", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:6fa2ed", "marker": { "size": 1, "color": "rgb(100, 149, 237)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "2efe5226-8d7f-4fd9-bab9-a69e3220c925", "name": "Job 17", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:71d324", "marker": { "size": 1, "color": "rgb(0, 139, 139)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "cb67aabc-89ab-469d-b8e9-e9c0df7a6ac2", "name": "Job 18", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:1da60d", "marker": { "size": 1, "color": "rgb(169, 169, 169)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "66db9642-7b10-4b52-87a8-b5c7f398e084", "name": "Job 19", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:58088b", "marker": { "size": 1, "color": "rgb(162, 205, 90)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "6ad04593-41fc-4e5b-9b8a-585f39540346", "name": "Job 2", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:c19aec", "marker": { "size": 1, "color": "rgb(154, 50, 205)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "671eb16c-fcd9-4c9a-a961-bb2c737e634f", "name": "Job 20", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:57ddae", "marker": { "size": 1, "color": "rgb(143, 188, 143)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "747f062d-dda3-4410-8dfd-2bbbccffa903", "name": "Job 3", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:47a202", "marker": { "size": 1, "color": "rgb(238, 201, 0)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "a0e0c588-d755-44d7-a05f-4946a8b49e94", "name": "Job 4", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:b79d40", "marker": { "size": 1, "color": "rgb(238, 230, 133)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "0e24e878-7b87-465b-b748-79b6184aee16", "name": "Job 5", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:102eef", "marker": { "size": 1, "color": "rgb(205, 193, 197)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "b24693fc-70dc-488d-a7c7-5b56d62fcaa3", "name": "Job 6", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:757355", "marker": { "size": 1, "color": "rgb(154, 192, 205)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "c35a730d-2c6f-4551-838a-c95e7d866144", "name": "Job 7", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:660a3b", "marker": { "size": 1, "color": "rgb(238, 162, 173)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "0950e55f-72ba-4297-8a1f-4be11fe37f4f", "name": "Job 8", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:1cbd56", "marker": { "size": 1, "color": "rgb(0, 250, 154)" }, "hoverinfo": "none", "showlegend": true }, { "uid": "194b7ea0-1ac6-43cf-a87d-665e5386c2f1", "name": "Job 9", "type": "scatter", "xsrc": "kevinshuang:7:5e0e9f", "ysrc": "kevinshuang:7:a1f9e7", "marker": { "size": 1, "color": "rgb(205, 179, 139)" }, "hoverinfo": "none", "showlegend": true } ], "layout": { "title": { "text": "Gantt Chart" }, "width": 900, "xaxis": { "type": "date", "showgrid": true, "zeroline": false, "rangeselector": { "buttons": [ { "step": "day", "count": 7, "label": "1w", "stepmode": "backward" }, { "step": "month", "count": 1, "label": "1m", "stepmode": "backward" }, { "step": "month", "count": 6, "label": "6m", "stepmode": "backward" }, { "step": "year", "count": 1, "label": "YTD", "stepmode": "todate" }, { "step": "year", "count": 1, "label": "1y", "stepmode": "backward" }, { "step": "all" } ] } }, "yaxis": { "range": [ -1, 2 ], "showgrid": false, "ticktext": [ "Machine" ], "tickvals": [ 0 ], "zeroline": false, "autorange": false }, "height": 600, "shapes": [ { "x0": "2018-07-14 0:00:27", "x1": "2018-07-14 0:00:37", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(0, 139, 0)" }, { "x0": "2018-07-14 0:00:40", "x1": "2018-07-14 0:00:50", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(154, 50, 205)" }, { "x0": "2018-07-14 0:02:11", "x1": "2018-07-14 0:02:24", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(238, 201, 0)" }, { "x0": "2018-07-14 0:00:00", "x1": "2018-07-14 0:00:04", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(238, 230, 133)" }, { "x0": "2018-07-14 0:00:18", "x1": "2018-07-14 0:00:27", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(205, 193, 197)" }, { "x0": "2018-07-14 0:01:44", "x1": "2018-07-14 0:01:48", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(154, 192, 205)" }, { "x0": "2018-07-14 0:01:21", "x1": "2018-07-14 0:01:29", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(238, 162, 173)" }, { "x0": "2018-07-14 0:01:06", "x1": "2018-07-14 0:01:21", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(0, 250, 154)" }, { "x0": "2018-07-14 0:00:59", "x1": "2018-07-14 0:01:06", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(205, 179, 139)" }, { "x0": "2018-07-14 0:02:42", "x1": "2018-07-14 0:02:43", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(255, 140, 0)" }, { "x0": "2018-07-14 0:00:50", "x1": "2018-07-14 0:00:59", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(227, 207, 87)" }, { "x0": "2018-07-14 0:00:04", "x1": "2018-07-14 0:00:07", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(0, 0, 205)" }, { "x0": "2018-07-14 0:01:29", "x1": "2018-07-14 0:01:44", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(122, 197, 205)" }, { "x0": "2018-07-14 0:01:48", "x1": "2018-07-14 0:01:57", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(237, 145, 33)" }, { "x0": "2018-07-14 0:02:43", "x1": "2018-07-14 0:02:54", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(118, 238, 0)" }, { "x0": "2018-07-14 0:00:12", "x1": "2018-07-14 0:00:18", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(100, 149, 237)" }, { "x0": "2018-07-14 0:00:07", "x1": "2018-07-14 0:00:12", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(0, 139, 139)" }, { "x0": "2018-07-14 0:01:57", "x1": "2018-07-14 0:02:11", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(169, 169, 169)" }, { "x0": "2018-07-14 0:02:24", "x1": "2018-07-14 0:02:42", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(162, 205, 90)" }, { "x0": "2018-07-14 0:00:37", "x1": "2018-07-14 0:00:40", "y0": -0.2, "y1": 0.2, "line": { "width": 0 }, "type": "rect", "xref": "x", "yref": "y", "opacity": 1, "fillcolor": "rgb(143, 188, 143)" } ], "hovermode": "closest", "showlegend": true } }, "height": 600, "width": 900, "user": { "profile_url": "https://plotly.com/~kevinshuang", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/78.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-11 04:38:21", "mapbox_access_tokens": null, "has_password": null, "username": "kevinshuang", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2019-04-22T01:57:54.858505Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://plotly.com/~tx900901/2.embed", "fid": "tx900901:2", "filename": "plot from API (1)", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/tx900901:2/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/tx900901:2/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/tx900901:2/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/tx900901:2/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/tx900901:2", "plots": "https://api.plotly.com/v2/plots/tx900901:2", "parent": "https://api.plotly.com/v2/folders/home?user=tx900901" }, "owner": "tx900901", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://plotly.com/~tx900901/2/", "world_readable": true, "date_modified": "2019-04-22T01:57:55.226Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://plotly.com/~tx900901/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "10b18413-88a6-4014-bdb4-890928a0fd5a", "mode": "markers", "type": "scatter", "xsrc": "tx900901:3:ffa01d", "ysrc": "tx900901:3:b1cb52" }, { "uid": "ef7b1298-239b-486c-8b1e-b2408aec8efb", "type": "scatter", "xsrc": "tx900901:3:ffa01d", "ysrc": "tx900901:3:2b5306" } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://plotly.com/~tx900901", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/54.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-04-22 01:52:14", "mapbox_access_tokens": null, "has_password": null, "username": "tx900901", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
