Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cj0xJnA9MjAyNS0wNy0xOCswNyUzQTI0JTNBNDYuODM5MjQyJTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI1LTA3LTE4KzA3JTNBMzElM0E1MS4zOTYzOTklMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNS0wNy0xOCsxMCUzQTIyJTNBNTguODU0MzM2JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-07-18T10:22:58.854336Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gico66/7.embed", "fid": "gico66:7", "filename": "Splices (A & B) Losses vs. Fiber Length @ 1300 nm MM", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/gico66/7/9_N26DJYK2VJ3BBDZGQW0L6SXHF5DBJD.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/gico66/7/2_Q08VJW8J04URFI6O1P9X9HACC71B6B.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/gico66/7/8_UCM87SOYQA982MUIDAT0D6VV2MP7V0.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/gico66/7/9_N26DJYK2VJ3BBDZGQW0L6SXHF5DBJD.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gico66:7", "plots": "https://api.plotly.com/v2/plots/gico66:7", "parent": "https://api.plotly.com/v2/folders/home?user=gico66" }, "owner": "gico66", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~gico66/7/", "world_readable": true, "date_modified": "2025-07-28T16:32:11.406Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gico66/7/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "I", "y": "J", "error_y": { "array": "N", "arrayminus": "O" } } }, "mode": "lines", "name": "1300 nm MM - 1000 ns", "type": "scatter", "xsrc": "gico66:6:05c730", "ysrc": "gico66:6:93ab3c", "error_y": { "meta": { "columnNames": { "array": "N", "arrayminus": "O" } }, "type": "data", "visible": true, "arraysrc": "gico66:6:762dc8", "symmetric": false, "arrayminussrc": "gico66:6:f423ba" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Splices (A & B) Losses vs. Fiber Length @ 1300 nm MM" }, "xaxis": { "type": "linear", "range": [ -0.46799999999999997, 48.891999999999996 ], "title": { "text": "Fibre Lenght (Km)" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.0905, 0.1195 ], "title": { "text": "Splice Loss (dB)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": true, "annotations": [ { "x": 16.45603074295474, "y": -0.033922834092553006, "font": { "size": 15 }, "text": "<b>Splice A</b>", "showarrow": false }, { "x": 16.371726729291204, "y": 0.0868311221669431, "font": { "size": 15 }, "text": "<b>Splice B</b>", "showarrow": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gico66", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/40.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-15 13:54:12", "mapbox_access_tokens": null, "has_password": null, "username": "gico66", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T10:22:31.571946Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~nieva/37.embed", "fid": "nieva:37", "filename": "Grafico IMSA para Boston", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/nieva:37/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/nieva/37/2_OWCNF4Z1GBR5Q0LOJK45921GWQM96N.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/nieva/37/8_ZV6KKOMRPPOTO2CREEOT4OYOL29P09.png", "list-thumb": "https://api.plotly.com/v2/files/nieva:37/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/nieva:37", "plots": "https://api.plotly.com/v2/plots/nieva:37", "parent": "https://api.plotly.com/v2/folders/home?user=nieva" }, "owner": "nieva", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 6, "web_url": "https://chart-studio.plotly.com/~nieva/37/", "world_readable": true, "date_modified": "2025-07-18T10:24:22.083Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~nieva/37/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Aleksey Seleznev" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:3abb17", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Hannes Christoph Holzer" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:2a0fd3", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Franz Tschöpe" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:ddd427", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Darcy Pigmans" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:b42523", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Marcel Minnerup" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:731086", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Marton Pajor" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:07a432", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Velin Vitanov" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:e505ce", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Pablo Vicente" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:9997cc", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Gareth Higgins" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:97192a", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Gonzalo Vergara" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:03d193", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Mohamed Buhdeima" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:92c385", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Robert Bodogae" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:c94bf7", "marker": { "size": 3 }, "visible": true, "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Samuel Caseirito" } }, "mode": "markers+lines", "name": "Samuel Caseirito", "type": "scatter", "ysrc": "nieva:36:b5416e", "marker": { "size": 3 }, "visible": true, "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Connor Spree" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:75f728", "marker": { "size": 3 }, "visible": true, "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Joss Marie" } }, "mode": "markers+lines", "name": "Joss Marie", "type": "scatter", "ysrc": "nieva:36:c03c23", "marker": { "size": 3 }, "visible": true, "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Emanuele Marra" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:2744e2", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Marco Zaccari2" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:006764", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Dominic Anspach-Sobetzke" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:be6cdf", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Néstor de la Fuente" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:dedb6d", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Antoine Lecointre" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:b7184b", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Thomas Bos" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:4ca075", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Harry J Lawrance" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:d3d527", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Riccardo Groppi" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:6b96c6", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Giuseppe Lo Faro" } }, "mode": "markers+lines", "name": "Giuseppe Lo Faro", "type": "scatter", "ysrc": "nieva:36:ff3e2e", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null }, { "line": { "width": 1 }, "meta": { "columnNames": { "y": "Sebastian Stamm" } }, "mode": "markers+lines", "name": "%{meta.columnNames.y}", "type": "scatter", "ysrc": "nieva:36:a98615", "marker": { "size": 3 }, "visible": "legendonly", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Grafiquito para Boston" }, "xaxis": { "range": [ -1.9328390754470126, 33.93283907544701 ], "title": { "text": "Lap" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -5.378624767225326, 52.02362476722533 ], "title": { "text": "Gap to Boston" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~nieva", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/4.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-05-09 08:11:18", "mapbox_access_tokens": null, "has_password": null, "username": "nieva", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T10:06:56.007063Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~idunnolol/5.embed", "fid": "idunnolol:5", "filename": "Plot 3 copy", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/idunnolol:5/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/idunnolol/5/2_CQ74XICK46KXQFMHTJZT35KXDF0NSZ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/idunnolol/5/8_03U37VOF5OCA2KXH7WKUL0B54TSIAL.png", "list-thumb": "https://api.plotly.com/v2/files/idunnolol:5/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/idunnolol:5", "plots": "https://api.plotly.com/v2/plots/idunnolol:5", "parent": "https://api.plotly.com/v2/folders/home?user=idunnolol" }, "owner": "idunnolol", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~idunnolol/5/", "world_readable": true, "date_modified": "2025-07-18T10:06:56.314Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~idunnolol/5/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3cf03d", "meta": { "columnNames": { "x": "A", "y": "B", "error_y": { "array": "C", "arrayminus": "D" } } }, "mode": "markers", "name": "Data", "type": "bar", "xsrc": "idunnolol:4:597c85", "ysrc": "idunnolol:4:5b5f22", "error_x": { "type": "percent", "color": "#444", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "error_y": { "meta": { "columnNames": { "array": "C", "arrayminus": "D" } }, "type": "data", "visible": true, "arraysrc": "idunnolol:4:4666cc", "symmetric": false, "arrayminussrc": "idunnolol:4:6c7f23" }, "orientation": "v" }, { "uid": "8409a9", "line": { "dash": "dot" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers+lines", "name": "Trendline", "type": "scatter", "xsrc": "idunnolol:4:597c85", "ysrc": "idunnolol:4:5b5f22", "marker": { "size": 4, "opacity": 1 }, "connectgaps": false, "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Adjusted Harmonic Clarity (100 - |dB|) against Material" }, "xaxis": { "side": "bottom", "type": "category", "range": [ 0.009090909090909038, 4.009090909090909 ], "title": { "text": "Material<br>" }, "autorange": false, "automargin": false, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 0, 78.94736842105263 ], "title": { "text": "Adjusted clarity / dB" }, "autorange": false }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~idunnolol", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-18 06:50:34", "mapbox_access_tokens": null, "has_password": null, "username": "idunnolol", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T09:55:42.851396Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~KUNLIN/17.embed", "fid": "KUNLIN:17", "filename": "Plot 17", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/KUNLIN/17/9_RERVSFJM0WPONCTGQQTKEHUTT346S4.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/KUNLIN/17/2_85C6GHFWFQ8WDWAHV4KHCX08ACXJXK.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/KUNLIN/17/8_6JRULTKVSMUWR6S2WYQD4F3FLRGGTH.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/KUNLIN/17/9_RERVSFJM0WPONCTGQQTKEHUTT346S4.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/KUNLIN:17", "plots": "https://api.plotly.com/v2/plots/KUNLIN:17", "parent": "https://api.plotly.com/v2/folders/home?user=KUNLIN" }, "owner": "KUNLIN", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~KUNLIN/17/", "world_readable": true, "date_modified": "2025-07-18T10:19:06.528Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~KUNLIN/17/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(255, 153, 51, 1.0)", "width": "1.3" }, "meta": { "columnNames": { "x": "T", "y": "Qw" } }, "mode": "lines", "name": "GOLF QW", "type": "scatter", "xsrc": "KUNLIN:19:b4e029", "ysrc": "KUNLIN:19:3c5267", "visible": true }, { "line": { "color": "rgba(55, 128, 191, 1.0)", "width": "1.3" }, "meta": { "columnNames": { "x": "T2", "y": "QW2" } }, "mode": "lines", "name": "ORI QW", "type": "scatter", "xsrc": "KUNLIN:19:434722", "ysrc": "KUNLIN:19:9704d1", "visible": true }, { "meta": { "columnNames": { "x": "T", "y": "Qx" } }, "mode": "lines", "name": "GOLF QX", "type": "scatter", "xsrc": "KUNLIN:19:b4e029", "ysrc": "KUNLIN:19:1687a6", "stackgroup": null }, { "meta": { "columnNames": { "x": "T2", "y": "QX2" } }, "mode": "lines", "name": "ORI QX", "type": "scatter", "xsrc": "KUNLIN:19:434722", "ysrc": "KUNLIN:19:651ea8", "stackgroup": null }, { "meta": { "columnNames": { "x": "T", "y": "Qy" } }, "mode": "lines", "name": "GOLF QY", "type": "scatter", "xsrc": "KUNLIN:19:b4e029", "ysrc": "KUNLIN:19:02df04", "stackgroup": null }, { "meta": { "columnNames": { "x": "T2", "y": "QY2" } }, "mode": "lines", "name": "ORI QY", "type": "scatter", "xsrc": "KUNLIN:19:434722", "ysrc": "KUNLIN:19:7c8b43", "stackgroup": null }, { "meta": { "columnNames": { "x": "T", "y": "Qz" } }, "mode": "lines", "name": "GOLF QZ", "type": "scatter", "xsrc": "KUNLIN:19:b4e029", "ysrc": "KUNLIN:19:c1cf8a", "stackgroup": null }, { "meta": { "columnNames": { "x": "T2", "y": "QZ2" } }, "mode": "lines", "name": "ORI QZ", "type": "scatter", "xsrc": "KUNLIN:19:434722", "ysrc": "KUNLIN:19:ee5627", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 154.94077448747151, 396.72665148063777 ], "title": { "font": { "color": "#4D5663" }, "text": "" }, "tickfont": { "color": "#4D5663" }, "autorange": false, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "type": "linear", "range": [ -0.2109244367284704, 0.3954497777336106 ], "title": { "font": { "color": "#4D5663" }, "text": "Price" }, "tickfont": { "color": "#4D5663" }, "zeroline": false, "autorange": false, "gridcolor": "#E1E5ED", "tickprefix": "$", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "autosize": true, "dragmode": "zoom", "hovermode": "closest", "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~KUNLIN", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/35.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-03 02:48:53", "mapbox_access_tokens": null, "has_password": null, "username": "KUNLIN", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T08:12:41.355110Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~RuotongNie/3.embed", "fid": "RuotongNie:3", "filename": "SH-cocoa soy pea rice", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/RuotongNie/3/9_WA4BEBAG6FIOHFJ82WDXKMCCQLIUBP.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/RuotongNie/3/2_BGBERJ8XZ9WDJB8PX5MOODPOTM1AIS.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/RuotongNie/3/8_QT4YVF6PG3O011Z6JDJP6XCO9M9GY0.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/RuotongNie/3/9_WA4BEBAG6FIOHFJ82WDXKMCCQLIUBP.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/RuotongNie:3", "plots": "https://api.plotly.com/v2/plots/RuotongNie:3", "parent": "https://api.plotly.com/v2/folders/home?user=RuotongNie" }, "owner": "RuotongNie", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~RuotongNie/3/", "world_readable": true, "date_modified": "2025-07-18T08:20:36.778Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~RuotongNie/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Protein", "y": "SH (μmol/100g)", "error_y": { "array": "Error bar" } } }, "mode": "markers", "name": "SH-protein in pH 6.5", "type": "bar", "xsrc": "RuotongNie:2:69ed6d", "ysrc": "RuotongNie:2:5ec772", "marker": { "line": { "width": 1 }, "color": "#636efa", "opacity": 1 }, "error_y": { "meta": { "columnNames": { "array": "Error bar" } }, "type": "data", "width": 3, "visible": true, "arraysrc": "RuotongNie:2:1f0393", "symmetric": true, "thickness": 1 }, "opacity": 1, "bandwidth": 0, "boxpoints": false, "orientation": "v", "autocolorscale": true } ], "frames": [], "layout": { "font": { "size": 14, "family": "Times New Roman" }, "title": { "x": 0.1, "text": "reactive sulfhydryl groups content of pea, soy, rice and cocoa protein" }, "xaxis": { "type": "category", "range": [ -1.7637540453074436, 8.101941747572814 ], "title": { "font": { "size": 16 } }, "domain": [ 0, 0.75 ], "autorange": false }, "yaxis": { "type": "linear", "range": [ -0.10933333333333334, 0.41733333333333333 ], "title": { "font": { "size": 16 }, "text": "SH (μmol/100g)" }, "domain": [ 0, 1 ], "autorange": true }, "bargap": 0.09999999999999998, "barnorm": "", "autosize": true, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": false, "bargroupgap": 0.1, "uniformtext": { "mode": "show", "minsize": 1 }, "plot_bgcolor": "rgb(254, 254, 254)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~RuotongNie", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/63.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-17 21:28:39", "mapbox_access_tokens": null, "has_password": null, "username": "RuotongNie", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T07:55:18.595451Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~KNG_71/2.embed", "fid": "KNG_71:2", "filename": "Alfa Romeo Giulia", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/KNG_71/2/9_5KE2328O0UYM9YWNJDFVCMJN21MHQ1.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/KNG_71/2/2_VLZFK76TCH2UM0SIXLJ4RRHI3HPXQ4.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/KNG_71/2/8_703ERR8KO5LQ8K3U0HR8DYEXV22S0O.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/KNG_71/2/9_5KE2328O0UYM9YWNJDFVCMJN21MHQ1.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/KNG_71:2", "plots": "https://api.plotly.com/v2/plots/KNG_71:2", "parent": "https://api.plotly.com/v2/folders/home?user=KNG_71" }, "owner": "KNG_71", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~KNG_71/2/", "world_readable": true, "date_modified": "2025-07-18T08:00:11.682Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~KNG_71/2/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Czas [s]", "y": "Ciśnienie doładowania [mbar]" } }, "mode": "lines", "name": "Ciśnienie doładowania [mbar]", "type": "scatter", "xsrc": "KNG_71:1:4e9906", "ysrc": "KNG_71:1:385996" }, { "meta": { "columnNames": { "x": "Czas [s]", "y": "Oczekiwane ciśnienie doładowania [mbar]" } }, "mode": "lines", "name": "Oczekiwane ciśnienie doładowania [mbar]", "type": "scatter", "xsrc": "KNG_71:1:4e9906", "ysrc": "KNG_71:1:404df9", "stackgroup": null }, { "meta": { "columnNames": { "x": "Czas [s]", "y": "Pozycja pedału przyspieszenia [%]" } }, "mode": "lines", "name": "Pozycja pedału przyspieszenia [%]", "type": "scatter", "xsrc": "KNG_71:1:4e9906", "ysrc": "KNG_71:1:028c49", "yaxis": "y2", "stackgroup": null }, { "fill": "tozerox", "line": { "color": "rgb(196, 149, 247)" }, "meta": { "columnNames": { "x": "Czas [s]", "y": "Włączo0y bieg [ ]" } }, "mode": "lines", "name": "Włączony bieg [ ]", "type": "scatter", "xsrc": "KNG_71:1:4e9906", "ysrc": "KNG_71:1:9c7e96", "yaxis": "y3", "fillcolor": "rgba(209, 179, 242, 0.5)", "stackgroup": null }, { "meta": { "columnNames": { "x": "Czas [s]", "y": "Prędkość pojazdu [km/h]" } }, "mode": "lines", "name": "Prędkość pojazdu [km/h]", "type": "scatter", "xsrc": "KNG_71:1:4e9906", "ysrc": "KNG_71:1:6f19b7", "yaxis": "y4" } ], "frames": [], "layout": { "title": { "text": "Alfa Romeo Giulia 2.0T test" }, "xaxis": { "side": "bottom", "type": "linear", "range": [ 2548.959970493319, 2634.8480449841823 ], "title": { "text": "Czas [s]" }, "anchor": "y", "domain": [ 0, 1 ], "autorange": false, "rangeslider": { "range": [ 0, 2748.0210526315786 ], "yaxis": { "rangemode": "match" }, "yaxis2": { "rangemode": "match" }, "yaxis3": { "rangemode": "match" }, "yaxis4": { "rangemode": "match" }, "visible": true, "autorange": true } }, "yaxis": { "side": "left", "type": "linear", "range": [ -473.1129664169192, 2884.2102497816504 ], "title": { "text": "Ciśnienie [mbar]" }, "autorange": false }, "yaxis2": { "side": "left", "type": "linear", "range": [ 0, 240 ], "title": { "text": "Aktywacja [%]" }, "autorange": false, "overlaying": "y" }, "yaxis3": { "side": "right", "type": "linear", "range": [ 0, 24 ], "title": { "text": "Bieg<br>" }, "autorange": false, "overlaying": "y" }, "yaxis4": { "side": "right", "type": "linear", "range": [ 0, 400 ], "title": { "text": "Prędkość [km/h]" }, "autorange": false, "overlaying": "y" }, "autosize": true, "dragmode": "pan", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "x" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~KNG_71", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-15 08:02:25", "mapbox_access_tokens": null, "has_password": null, "username": "KNG_71", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T07:53:21.237538Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Dona34/327.embed", "fid": "Dona34:327", "filename": "biomass", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Dona34:327/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Dona34:327/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Dona34/327/8_3JBW7LXUBJBT6BRJIAOVVEKBIXH76E.png", "list-thumb": "https://api.plotly.com/v2/files/Dona34:327/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Dona34:327", "plots": "https://api.plotly.com/v2/plots/Dona34:327", "parent": "https://api.plotly.com/v2/folders/home?user=Dona34" }, "owner": "Dona34", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Dona34/327/", "world_readable": true, "date_modified": "2025-07-21T13:52:36.474Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Dona34/327/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "name": "C", "type": "box", "xsrc": "Dona34:326:a6a009", "ysrc": "Dona34:326:eecde4", "frame": null, "log_y": true, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "boxpoints": "all", "fillcolor": "rgba(102,194,165,0.5)" }, { "line": { "color": "rgba(141,160,203,1)" }, "name": "R", "type": "box", "xsrc": "Dona34:326:aa8fff", "ysrc": "Dona34:326:129e13", "frame": null, "log_y": true, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "boxpoints": "all", "fillcolor": "rgba(141,160,203,0.5)" } ], "layout": { "title": "Biomass distribution between Crop reference (R) and Crop test (C) (albioma2) <br><span style='font-size:10px;'>Generated on 21/07/25 at 15h46", "xaxis": { "type": "category", "title": "Label (C : Root test or Crop test, R : Root reference or Crop reference)", "domain": [ 0, 1 ], "automargin": true, "categoryarray": [ "C", "R" ], "categoryorder": "array" }, "yaxis": { "title": "Biomass", "domain": [ 0, 1 ], "linecolor": "black", "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "autosize": true, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Dona34", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/58.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-03-15 10:39:28", "mapbox_access_tokens": null, "has_password": null, "username": "Dona34", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T07:38:54.270053Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~idunnolol/3.embed", "fid": "idunnolol:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/idunnolol/3/9_5FW5QLX2TXZMHGAKSXB26RVG99ZR7T.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/idunnolol/3/2_V59XUHYGOB6QWDDFJ4WLUY2MC1CU6A.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/idunnolol/3/8_SR0AG3YE41JKHJJN7BZCPTSKSEYLC0.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/idunnolol/3/9_5FW5QLX2TXZMHGAKSXB26RVG99ZR7T.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/idunnolol:3", "plots": "https://api.plotly.com/v2/plots/idunnolol:3", "parent": "https://api.plotly.com/v2/folders/home?user=idunnolol" }, "owner": "idunnolol", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~idunnolol/3/", "world_readable": true, "date_modified": "2025-07-18T07:38:54.281Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~idunnolol/3/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3cf03d", "meta": { "columnNames": { "x": "A", "y": "B", "error_y": { "array": "C", "arrayminus": "D" } } }, "mode": "markers", "name": "Data", "type": "bar", "xsrc": "idunnolol:2:597c85", "ysrc": "idunnolol:2:5b5f22", "error_x": { "type": "percent", "color": "#444", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "error_y": { "meta": { "columnNames": { "array": "C", "arrayminus": "D" } }, "type": "data", "visible": true, "arraysrc": "idunnolol:2:4666cc", "symmetric": false, "arrayminussrc": "idunnolol:2:6c7f23" }, "orientation": "v" }, { "uid": "8409a9", "line": { "dash": "dot" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers+lines", "name": "Trendline", "type": "scatter", "xsrc": "idunnolol:2:597c85", "ysrc": "idunnolol:2:5b5f22", "marker": { "size": 4, "opacity": 1 }, "connectgaps": false, "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Adjusted Harmonic Clarity (100 - |dB|) against Material" }, "xaxis": { "side": "bottom", "type": "category", "range": [ 0.009090909090909038, 4.009090909090909 ], "title": { "text": "Material<br>" }, "autorange": false, "automargin": false, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 0, 78.94736842105263 ], "title": { "text": "Adjusted clarity / dB" }, "autorange": false }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~idunnolol", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-18 06:50:34", "mapbox_access_tokens": null, "has_password": null, "username": "idunnolol", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T07:38:45.159978Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~AlexPirker/9.embed", "fid": "AlexPirker:9", "filename": "R_P_Stufen", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/AlexPirker/9/9_6IE8WOJH1PVJ4L14V9NEUMSRU092ZM.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/AlexPirker/9/2_LG8EV69S05JOOCU6AIT3VN0QTXJQQZ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/AlexPirker/9/8_QX8BK58FP7ECU5TTMOXN3AP75ENB0K.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/AlexPirker/9/9_6IE8WOJH1PVJ4L14V9NEUMSRU092ZM.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/AlexPirker:9", "plots": "https://api.plotly.com/v2/plots/AlexPirker:9", "parent": "https://api.plotly.com/v2/folders/home?user=AlexPirker" }, "owner": "AlexPirker", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 4, "web_url": "https://chart-studio.plotly.com/~AlexPirker/9/", "world_readable": true, "date_modified": "2025-07-18T08:13:37.420Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~AlexPirker/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "MessungNr", "y": "Wert", "marker": { "color": "Phase" } } }, "mode": "lines", "name": "U", "type": "scatter", "xsrc": "AlexPirker:2:9961b4", "ysrc": "AlexPirker:2:ccd54b", "marker": { "line": { "color": "rgb(0, 0, 0)", "width": 1 }, "meta": { "columnNames": { "color": "Phase" } }, "color": "rgb(0, 114, 189)", "opacity": 1 }, "error_x": { "type": "percent", "color": "rgb(0, 43, 255)", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "visible": true, "hoverinfo": "x+y+name", "hoverlabel": { "align": "auto" }, "transforms": [ { "meta": { "columnNames": { "target": "Parameter" } }, "type": "filter", "value": "R", "operation": "=", "targetsrc": "AlexPirker:2:a9dfb8" }, { "meta": { "columnNames": { "target": "Wicklung" } }, "type": "filter", "value": [ "Prim" ], "operation": "{}", "targetsrc": "AlexPirker:2:2db362" }, { "meta": { "columnNames": { "target": "Phase" } }, "type": "filter", "value": [ "U" ], "operation": "{}", "targetsrc": "AlexPirker:2:2029dc" }, { "meta": { "columnNames": { "target": "MessungNr" } }, "type": "sort", "targetsrc": "AlexPirker:2:9961b4" } ], "orientation": "v", "hovertemplate": "" }, { "meta": { "columnNames": { "x": "MessungNr", "y": "Wert" } }, "mode": "lines", "name": "V", "type": "scatter", "xsrc": "AlexPirker:2:9961b4", "ysrc": "AlexPirker:2:ccd54b", "marker": { "line": { "width": 1 }, "color": "rgb(217, 83, 25)" }, "visible": true, "transforms": [ { "meta": { "columnNames": { "target": "Parameter" } }, "type": "filter", "value": "R", "operation": "=", "targetsrc": "AlexPirker:2:a9dfb8" }, { "meta": { "columnNames": { "target": "Wicklung" } }, "type": "filter", "value": [ "Prim" ], "operation": "{}", "targetsrc": "AlexPirker:2:2db362" }, { "meta": { "columnNames": { "target": "Phase" } }, "type": "filter", "value": [ "V" ], "operation": "{}", "targetsrc": "AlexPirker:2:2029dc" }, { "meta": { "columnNames": { "target": "MessungNr" } }, "type": "sort", "targetsrc": "AlexPirker:2:9961b4" } ], "orientation": "v" }, { "meta": { "columnNames": { "x": "MessungNr", "y": "Wert" } }, "mode": "lines", "name": "W", "type": "scatter", "xsrc": "AlexPirker:2:9961b4", "ysrc": "AlexPirker:2:ccd54b", "xaxis": "x", "marker": { "line": { "width": 1 }, "color": "rgb(237, 177, 32)" }, "visible": true, "transforms": [ { "meta": { "columnNames": { "target": "Parameter" } }, "type": "filter", "value": "R", "operation": "=", "targetsrc": "AlexPirker:2:a9dfb8" }, { "meta": { "columnNames": { "target": "Wicklung" } }, "type": "filter", "value": [ "Prim" ], "operation": "{}", "targetsrc": "AlexPirker:2:2db362" }, { "meta": { "columnNames": { "target": "Phase" } }, "type": "filter", "value": [ "W" ], "operation": "{}", "targetsrc": "AlexPirker:2:2029dc" }, { "meta": { "columnNames": { "target": "MessungNr" } }, "type": "sort", "targetsrc": "AlexPirker:2:9961b4" } ], "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "" }, "xaxis": { "side": "bottom", "type": "linear", "range": [ 1, 49 ], "ticks": "inside", "title": { "font": { "size": 14, "family": "Arial" }, "text": "Stufenschalterstellung" }, "anchor": "y", "domain": [ 0, 1 ], "nticks": 0, "tickson": "boundaries", "showgrid": true, "showline": false, "tickmode": "linear", "zeroline": false, "autorange": true, "automargin": false, "fixedrange": false, "showspikes": false, "tickformat": "", "tickprefix": "", "rangeslider": { "range": [ -0.5, 9.5 ], "yaxis": {}, "yaxis2": {}, "visible": false, "autorange": true }, "showexponent": "none", "exponentformat": "none", "showticklabels": true, "separatethousands": true }, "yaxis": { "side": "left", "type": "linear", "range": [ 332.3855555555555, 436.47444444444443 ], "title": { "font": { "size": 14, "family": "Arial" }, "text": "Wicklungswiderstand in mΩ" }, "anchor": "x", "domain": [ 0, 1 ], "tickfont": { "size": 12 }, "autorange": true, "automargin": true, "tickformat": "", "showexponent": "all", "separatethousands": true }, "bargap": 0.19999999999999996, "images": [], "legend": { "x": 0.5, "y": 1.04, "font": { "family": "Arial" }, "valign": "middle", "xanchor": "center", "yanchor": "auto", "itemsizing": "trace", "traceorder": "normal", "orientation": "h" }, "shapes": [], "barmode": "group", "autosize": true, "colorway": [ "#1f77b4", "#ff7f0e", "#2ca02c", "#d62728", "#9467bd", "#8c564b", "#e377c2", "#7f7f7f", "#bcbd22", "#17becf" ], "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "x", "colorscale": { "sequential": [ [ 0, "#dcdcdc" ], [ 0.3333333333333333, "#f5c39d" ], [ 0.6666666666666666, "#f5a069" ], [ 1, "#b20a1c" ] ] }, "showlegend": true, "annotations": [], "bargroupgap": 0.05 } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~AlexPirker", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/48.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-03-24 09:57:40", "mapbox_access_tokens": null, "has_password": null, "username": "AlexPirker", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-07-18T07:31:51.396399Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~idunnolol/1.embed", "fid": "idunnolol:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/idunnolol/1/9_12TUCCNJF5V87IRB2KBL1406UOM4A4.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/idunnolol/1/2_J8DW0QAGW2C8QBS13CTP2FCCE3Y3VN.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/idunnolol/1/8_AO1A29YVQBHRC3OKPBXPRCAB5AL8J3.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/idunnolol/1/9_12TUCCNJF5V87IRB2KBL1406UOM4A4.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/idunnolol:1", "plots": "https://api.plotly.com/v2/plots/idunnolol:1", "parent": "https://api.plotly.com/v2/folders/home?user=idunnolol" }, "owner": "idunnolol", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~idunnolol/1/", "world_readable": true, "date_modified": "2025-07-18T07:31:51.406Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~idunnolol/1/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "3cf03d", "meta": { "columnNames": { "x": "A", "y": "B", "error_y": { "array": "C", "arrayminus": "D" } } }, "mode": "markers", "type": "bar", "xsrc": "idunnolol:0:9174b2", "ysrc": "idunnolol:0:acf69a", "error_x": { "type": "percent", "color": "#444", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "error_y": { "meta": { "columnNames": { "array": "C", "arrayminus": "D" } }, "type": "data", "visible": true, "arraysrc": "idunnolol:0:86a748", "symmetric": false, "arrayminussrc": "idunnolol:0:4cafc7" }, "orientation": "v" }, { "uid": "8409a9", "line": { "dash": "dot" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers+lines", "type": "scatter", "xsrc": "idunnolol:0:9174b2", "ysrc": "idunnolol:0:acf69a", "marker": { "size": 4, "opacity": 1 }, "connectgaps": false, "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Adjusted Harmonic Clarity (100 - |dB|) against Material" }, "xaxis": { "side": "bottom", "type": "category", "range": [ 0.009090909090909038, 4.009090909090909 ], "title": { "text": "Material<br>" }, "autorange": false, "automargin": false, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 0, 78.94736842105263 ], "title": { "text": "Adjusted clarity / dB" }, "autorange": false }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~idunnolol", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/75.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-07-18 06:50:34", "mapbox_access_tokens": null, "has_password": null, "username": "idunnolol", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
