Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cj0xJnA9MjAyNS0wNi0yNisyMCUzQTQ1JTNBMzEuMTAyMzA2JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI1LTA2LTI2KzIwJTNBNDclM0EwOC41MzYyODQlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNS0wNi0yNyswMiUzQTE4JTNBMDEuNTgwOTQxJTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-06-27T02:18:01.580941Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~legend05070911/3.embed", "fid": "legend05070911:3", "filename": "华为网卡2*100G 线程数为4时rdma的时延数据plot", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/legend05070911/3/9_IJG5MO6D2USFHVLFKKIS1WSHLDOXDJ.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/legend05070911/3/2_0WTC34AT7SD38DL6S7VRKKSAGN5U9E.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/legend05070911/3/8_RCM0BWBZ84WY18HM6QLEYHXXDDAEVV.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/legend05070911/3/9_IJG5MO6D2USFHVLFKKIS1WSHLDOXDJ.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/legend05070911:3", "plots": "https://api.plotly.com/v2/plots/legend05070911:3", "parent": "https://api.plotly.com/v2/folders/home?user=legend05070911" }, "owner": "legend05070911", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~legend05070911/3/", "world_readable": true, "date_modified": "2025-06-27T04:56:00.063Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~legend05070911/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "data.0.x", "y": "data.0.y" } }, "mode": "lines+markers", "name": "io-depth 1", "type": "scatter", "xsrc": "legend05070911:2:8cb16b", "ysrc": "legend05070911:2:b425c5" }, { "meta": { "columnNames": { "x": "data.1.x", "y": "data.1.y" } }, "mode": "lines+markers", "name": "io-depth 8", "type": "scatter", "xsrc": "legend05070911:2:54517a", "ysrc": "legend05070911:2:93ca71", "xaxis": "x" } ], "frames": [], "layout": { "title": { "text": "华为网卡2*100G 线程数为4时rdma的时延数据" }, "xaxis": { "type": "linear", "range": [ -84.832254267216, 1694.832254267216 ], "title": { "text": "连接数（per-thread）" }, "autorange": true, "showspikes": false }, "yaxis": { "type": "linear", "range": [ 13.684183410613088, 108.31581658938691 ], "title": { "text": "时延（us）" }, "autorange": true, "showspikes": false }, "legend": { "x": 0.5257591511327885, "y": 1.197547467487647 }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ], "sequentialminus": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~legend05070911", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/33.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-26 13:16:36", "mapbox_access_tokens": null, "has_password": null, "username": "legend05070911", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-27T02:04:40.883697Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cjdeok/13.embed", "fid": "cjdeok:13", "filename": "Plot 13", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cjdeok/13/9_O4C3CDHZJTGC1KVZ6HSBS3ADDF1NGB.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cjdeok/13/2_GVSDI4306HMQYYCY9GEDXRK3HHAVVZ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cjdeok/13/8_L1O56MGUP40AX57PBFWORI7WBWC6IF.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cjdeok/13/9_O4C3CDHZJTGC1KVZ6HSBS3ADDF1NGB.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cjdeok:13", "plots": "https://api.plotly.com/v2/plots/cjdeok:13", "parent": "https://api.plotly.com/v2/folders/home?user=cjdeok" }, "owner": "cjdeok", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cjdeok/13/", "world_readable": true, "date_modified": "2025-06-27T02:04:40.898Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cjdeok/13/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "연도", "y": " 102㎡초과" } }, "mode": "lines", "type": "scatter", "xsrc": "cjdeok:8:f81f3e", "ysrc": "cjdeok:8:b30529", "orientation": "v" }, { "meta": { "columnNames": { "x": "연도", "y": " 60㎡이하" } }, "mode": "lines", "type": "scatter", "xsrc": "cjdeok:8:f81f3e", "ysrc": "cjdeok:8:eb3f80", "stackgroup": null }, { "meta": { "columnNames": { "x": "연도", "y": " 60㎡초과 85㎡이하" } }, "mode": "lines", "type": "scatter", "xsrc": "cjdeok:8:f81f3e", "ysrc": "cjdeok:8:0fbd6d", "stackgroup": null }, { "meta": { "columnNames": { "x": "연도", "y": " 85㎡초과 102㎡이하" } }, "mode": "lines", "type": "scatter", "xsrc": "cjdeok:8:f81f3e", "ysrc": "cjdeok:8:cdb65f", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 2015, 2020 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 2592.401111111111, 4634.178888888889 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cjdeok", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/79.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-27 01:02:42", "mapbox_access_tokens": null, "has_password": null, "username": "cjdeok", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-27T02:03:01.771003Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~vijay.karthik/3.embed", "fid": "vijay.karthik:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/vijay.karthik/3/9_V8OTQPMLEW65EFJ27V8XJ5KYC5STMT.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/vijay.karthik/3/2_UZSN3WNHPHMPMIV7OB21UKMQ44DDCH.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/vijay.karthik/3/8_64SBF83ACD0GLR0A0FTK4451D3Z661.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/vijay.karthik/3/9_V8OTQPMLEW65EFJ27V8XJ5KYC5STMT.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/vijay.karthik:3", "plots": "https://api.plotly.com/v2/plots/vijay.karthik:3", "parent": "https://api.plotly.com/v2/folders/home?user=vijay.karthik" }, "owner": "vijay.karthik", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~vijay.karthik/3/", "world_readable": true, "date_modified": "2025-07-05T12:04:51.434Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~vijay.karthik/3/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Match Ball No", "y": "PitchLength", "z": "COF", "marker": { "color": "Paceorspin" } } }, "mode": "markers", "type": "scatter3d", "xsrc": "vijay.karthik:2:ec3234", "ysrc": "vijay.karthik:2:cc1e81", "zsrc": "vijay.karthik:2:d8da48", "marker": { "meta": { "columnNames": { "color": "Paceorspin" } }, "colorsrc": "vijay.karthik:2:0f4276" } } ], "frames": [], "layout": { "scene": { "xaxis": { "type": "linear", "title": { "text": "Ball No" } }, "yaxis": { "type": "linear", "title": { "text": "Pitch Length" } }, "zaxis": { "type": "linear", "title": { "text": "COR" } }, "camera": { "up": { "x": 0, "y": 0, "z": 1 }, "eye": { "x": -1.5127613750788849, "y": -1.2757509812169767, "z": -0.39037250739920987 }, "center": { "x": 0.10580642658373043, "y": 0.13439412071250442, "z": -0.10889593124168719 }, "projection": { "type": "orthographic" } }, "dragmode": "turntable", "aspectmode": "manual", "aspectratio": { "x": 2.3579476910000117, "y": 2.3579476910000117, "z": 2.3579476910000117 } }, "title": { "text": "Click to enter Plot title" }, "xaxis": { "range": [ -1, 6 ], "autorange": true }, "yaxis": { "range": [ -1, 4 ], "autorange": true }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~vijay.karthik", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/24.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-26 12:55:29", "mapbox_access_tokens": null, "has_password": null, "username": "vijay.karthik", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T23:54:02.347726Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~wooeng/1.embed", "fid": "wooeng:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/wooeng/1/9_68PRP2SYZA3O2UKFFJ1261HW57D2T4.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/wooeng/1/2_6Q1SJW2SW3NQ0C1ELKNZ5YMQF4SG4W.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/wooeng/1/8_6USKHYDIFKF2TO646H71KB5L55N35W.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/wooeng/1/9_68PRP2SYZA3O2UKFFJ1261HW57D2T4.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/wooeng:1", "plots": "https://api.plotly.com/v2/plots/wooeng:1", "parent": "https://api.plotly.com/v2/folders/home?user=wooeng" }, "owner": "wooeng", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~wooeng/1/", "world_readable": true, "date_modified": "2025-06-26T23:54:02.357Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~wooeng/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "ì ì", "y": "ì ë¥" } }, "mode": "markers", "type": "scatter", "xsrc": "wooeng:0:42a771", "ysrc": "wooeng:0:7b42cf" }, { "meta": { "columnNames": { "x": "ì ì", "y": "ì¶ë ¥" } }, "mode": "markers", "type": "scatter", "xsrc": "wooeng:0:42a771", "ysrc": "wooeng:0:d3d740", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ -0.021180789232181106, 1.461180789232181 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.00010750968264276831, 0.003641865237942768 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~wooeng", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-26 23:42:00", "mapbox_access_tokens": null, "has_password": null, "username": "wooeng", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T23:50:24.452624Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gtchen/11.embed", "fid": "gtchen:11", "filename": "Plot 11", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/gtchen/11/9_K0MGZKFNQL34CTBG7O8G4ZDOKTV0J8.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/gtchen/11/2_F32ZJSE3ZBG0O3VH0CKPXMZ35Q9259.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/11/8_8RSMEIIE96RHB3SMAVCPLGIY12I6SE.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/11/9_K0MGZKFNQL34CTBG7O8G4ZDOKTV0J8.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gtchen:11", "plots": "https://api.plotly.com/v2/plots/gtchen:11", "parent": "https://api.plotly.com/v2/folders/home?user=gtchen" }, "owner": "gtchen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~gtchen/11/", "world_readable": true, "date_modified": "2025-06-26T23:50:24.465Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gtchen/11/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "markers+lines", "name": "Baseline Kissat ", "type": "scatter", "xsrc": "gtchen:10:0709e1", "ysrc": "gtchen:10:5f1638", "marker": { "opacity": 0.6 } }, { "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers+lines", "name": "ML-Kissat", "type": "scatter", "xsrc": "gtchen:10:91f7d0", "ysrc": "gtchen:10:6440f7", "marker": { "symbol": "diamond", "opacity": 0.6 } } ], "frames": [], "layout": { "font": { "size": 20 }, "title": { "text": "Figure 4: Baseline Kissat vs ML-Kissat" }, "xaxis": { "type": "linear", "range": [ -11.66453447050462, 219.66453447050463 ], "title": { "text": "Problems solved" }, "autorange": true }, "yaxis": { "type": "linear", "dtick": 1000, "range": [ -260.8206256109482, 4262.820625610948 ], "tick0": 0, "title": { "text": "Time" }, "tickmode": "linear", "autorange": true }, "images": [], "legend": { "x": 0.9585681914199025, "y": 1 }, "shapes": [], "autosize": true, "dragmode": "zoom", "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gtchen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-03-16 01:32:56", "mapbox_access_tokens": null, "has_password": null, "username": "gtchen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T23:47:18.037460Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gtchen/9.embed", "fid": "gtchen:9", "filename": "Plot 9", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/gtchen/9/9_YY4YROWXKND4NW6ECHO27KBDXIRZ9W.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/gtchen/9/2_00XC89VNS64C3XL3J46Q9YNN7EWTZ6.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/9/8_Q1L94601QV9GWVFK7NAT5V6E4MEI7A.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/9/9_YY4YROWXKND4NW6ECHO27KBDXIRZ9W.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gtchen:9", "plots": "https://api.plotly.com/v2/plots/gtchen:9", "parent": "https://api.plotly.com/v2/folders/home?user=gtchen" }, "owner": "gtchen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~gtchen/9/", "world_readable": true, "date_modified": "2025-06-26T23:47:18.049Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gtchen/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "markers+lines", "name": "Baseline Glucose ", "type": "scatter", "xsrc": "gtchen:8:de162c", "ysrc": "gtchen:8:28a9c6", "marker": { "size": 6, "opacity": 0.6 } }, { "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers+lines", "name": "ML-Glucose", "type": "scatter", "xsrc": "gtchen:8:53f1e2", "ysrc": "gtchen:8:725147", "marker": { "size": 6, "color": "rgb(255, 180, 14)", "symbol": "diamond", "opacity": 0.6 } } ], "frames": [], "layout": { "font": { "size": 20 }, "title": { "text": "Figure 3: Baseline Glucose vs ML-Glucose" }, "xaxis": { "type": "linear", "dtick": 1000, "range": [ -10.218813905930473, 194.21881390593046 ], "tick0": 0, "title": { "text": "Problems solved" }, "tickmode": "auto", "autorange": true }, "yaxis": { "type": "linear", "dtick": 1000, "range": [ -258.6891495601173, 4262.689149560118 ], "title": { "text": "Time" }, "tickmode": "linear", "autorange": true }, "images": [], "legend": { "x": 0.9585681914199025, "y": 1 }, "shapes": [], "autosize": true, "dragmode": "zoom", "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gtchen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-03-16 01:32:56", "mapbox_access_tokens": null, "has_password": null, "username": "gtchen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T23:42:14.585192Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gtchen/7.embed", "fid": "gtchen:7", "filename": "Plot 7", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/gtchen/7/9_LR64ILDIFNDN82OCDKUAHPREH6KVG4.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/gtchen/7/2_X3OEC8N8IA7PPRLKEXZK4QDP48ZXXV.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/7/8_PN2A66FLLL9LSOA2VTO27F9VN66HS5.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/gtchen/7/9_LR64ILDIFNDN82OCDKUAHPREH6KVG4.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gtchen:7", "plots": "https://api.plotly.com/v2/plots/gtchen:7", "parent": "https://api.plotly.com/v2/folders/home?user=gtchen" }, "owner": "gtchen", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~gtchen/7/", "world_readable": true, "date_modified": "2025-06-26T23:42:14.597Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gtchen/7/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "markers+lines", "name": "Baseline Kissat ", "type": "scatter", "xsrc": "gtchen:6:d11c54", "ysrc": "gtchen:6:5406a9", "marker": { "opacity": 0.6 } }, { "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers+lines", "name": "ML-Kissat", "type": "scatter", "xsrc": "gtchen:6:edc0de", "ysrc": "gtchen:6:c54207", "marker": { "symbol": "diamond", "opacity": 0.6 } } ], "frames": [], "layout": { "font": { "size": 20 }, "title": { "text": "Figure 4: Baseline Kissat vs ML-Kissat" }, "xaxis": { "side": "bottom", "type": "linear", "range": [ 0, 220 ], "ticks": "", "title": { "font": { "size": 20 }, "text": "Problems solved" }, "domain": [ 0, 1 ], "showline": true, "tickfont": { "size": 20 }, "autorange": false, "showspikes": false, "rangeslider": { "range": [ -11.578905630452024, 220 ], "yaxis": {}, "visible": false, "autorange": true, "thickness": 0 }, "spikethickness": 20 }, "yaxis": { "side": "left", "type": "linear", "dtick": 1000, "range": [ 0, 4000 ], "tick0": 0, "title": { "font": { "size": 20 }, "text": "Time" }, "domain": [ 0, 1 ], "showline": true, "tickfont": { "size": 20 }, "tickmode": "linear", "autorange": false, "tickangle": "auto", "automargin": false, "showspikes": false, "tickformat": "", "tickprefix": "", "showexponent": "all", "exponentformat": "none", "showticklabels": true, "separatethousands": false }, "images": [], "legend": { "x": 0.9585681914199025, "y": 1, "font": { "size": 20 }, "title": { "font": { "size": 10 }, "text": "<br>" }, "borderwidth": 0, "orientation": "v" }, "shapes": [], "autosize": true, "dragmode": "select", "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gtchen", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/73.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-03-16 01:32:56", "mapbox_access_tokens": null, "has_password": null, "username": "gtchen", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T22:57:49.513025Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~4e/452.embed", "fid": "4e:452", "filename": "Plot 452", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/4e/452/9_0AVC48SDZK4JJJS4CGPBZE4WGMD02L.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/4e/452/2_37YVCT20QMNKGUOV7TEAEYIVAA6OL8.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/4e/452/8_24FF150M5CUMO2FS4D7VYEJFR6M0LJ.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/4e/452/9_0AVC48SDZK4JJJS4CGPBZE4WGMD02L.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/4e:452", "plots": "https://api.plotly.com/v2/plots/4e:452", "parent": "https://api.plotly.com/v2/folders/home?user=4e" }, "owner": "4e", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~4e/452/", "world_readable": true, "date_modified": "2025-06-27T00:38:33.431Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~4e/452/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(99, 193, 250)" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:450:b65197", "ysrc": "4e:450:8fbad5", "visible": true, "connectgaps": true }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:450:b65197", "ysrc": "4e:450:040aa9", "visible": true, "stackgroup": null }, { "line": { "color": "rgb(231, 159, 23)" }, "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:450:b65197", "ysrc": "4e:450:d3ae8a", "yaxis": "y2", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "bonniebonniebonniebonnie (prev. bonnieuh, baddiebonnie, bonn_ie)" }, "xaxis": { "type": "category", "range": [ 0, 2800 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -1277777.7777777778, 24277777.777777776 ], "autorange": true }, "yaxis2": { "side": "right", "type": "linear", "range": [ 0.2777777777777778, 14.722222222222221 ], "autorange": true, "overlaying": "y" }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "x" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~4e", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/25.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-09-12 13:44:49", "mapbox_access_tokens": null, "has_password": null, "username": "4e", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T22:13:16.131169Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Neharnia/1.embed", "fid": "Neharnia:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Neharnia/1/9_7EFDP7CFLQKZPW8YCKIKAMV0RLFZ6F.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Neharnia/1/2_CERKLN2F44TM1ALR7VZVPLI9N16G63.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Neharnia/1/8_M5MGOOSX9ZLX87FKGEOAYBHAJXE5RV.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Neharnia/1/9_7EFDP7CFLQKZPW8YCKIKAMV0RLFZ6F.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Neharnia:1", "plots": "https://api.plotly.com/v2/plots/Neharnia:1", "parent": "https://api.plotly.com/v2/folders/home?user=Neharnia" }, "owner": "Neharnia", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Neharnia/1/", "world_readable": true, "date_modified": "2025-06-26T22:13:16.142Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Neharnia/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Year", "y": "SHem" } }, "mode": "markers", "type": "bar", "xsrc": "Neharnia:0:53f0c5", "ysrc": "Neharnia:0:fe1b84", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Southern Hemisphere Temperatures 1880-2014" }, "xaxis": { "type": "linear", "range": [ 1879.5, 2014.5 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -52.888888888888886, 64.88888888888889 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Neharnia", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/17.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-26 21:10:46", "mapbox_access_tokens": null, "has_password": null, "username": "Neharnia", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-26T20:47:08.536284Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~benjaleivas/43.embed", "fid": "benjaleivas:43", "filename": "schoolai_bp1_fig_9", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/benjaleivas:43/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/benjaleivas:43/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/benjaleivas:43/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/benjaleivas:43/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/benjaleivas:43", "plots": "https://api.plotly.com/v2/plots/benjaleivas:43", "parent": "https://api.plotly.com/v2/folders/home?user=benjaleivas" }, "owner": "benjaleivas", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 340, "web_url": "https://chart-studio.plotly.com/~benjaleivas/43/", "world_readable": true, "date_modified": "2025-07-15T22:03:20.337Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~benjaleivas/43/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "regular_hover", "type": "scatter", "xsrc": "benjaleivas:307:482917", "ysrc": "benjaleivas:307:6d6552", "xaxis": "x", "yaxis": "y", "marker": { "size": 0, "opacity": 0 }, "visible": true, "showlegend": false, "customdatasrc": "benjaleivas:307:7f1e19", "hovertemplate": "%{customdata}<extra></extra>" }, { "fill": "tozeroy", "line": { "color": "#8c1515", "width": 0 }, "mode": "none", "name": "Student Chatbots", "type": "scatter", "xsrc": "benjaleivas:307:90f0da", "ysrc": "benjaleivas:307:2ecb0b", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#8c1515", "hoverinfo": "skip", "legendrank": 1000, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#faa54a", "width": 0 }, "mode": "none", "name": "Teacher Productivity Tools", "type": "scatter", "xsrc": "benjaleivas:307:332816", "ysrc": "benjaleivas:307:7be417", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#faa54a", "hoverinfo": "skip", "legendrank": 1001, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#009ab4", "width": 0 }, "mode": "none", "name": "Teacher Chatbot Assistants", "type": "scatter", "xsrc": "benjaleivas:307:d27536", "ysrc": "benjaleivas:307:c0d64a", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#009ab4", "hoverinfo": "skip", "legendrank": 1002, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#2e5d54", "width": 0 }, "mode": "none", "name": "Reference Materials", "type": "scatter", "xsrc": "benjaleivas:307:01d58b", "ysrc": "benjaleivas:307:a67bc5", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#2e5d54", "hoverinfo": "skip", "legendrank": 1003, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#590c56", "width": 0 }, "mode": "none", "name": "Homepage/Auth", "type": "scatter", "xsrc": "benjaleivas:307:f6e232", "ysrc": "benjaleivas:307:b035f5", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#590c56", "hoverinfo": "skip", "legendrank": 1004, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#005e87", "width": 0 }, "mode": "none", "name": "Other", "type": "scatter", "xsrc": "benjaleivas:307:7b0499", "ysrc": "benjaleivas:307:fd7ce4", "xaxis": "x", "yaxis": "y", "visible": true, "fillcolor": "#005e87", "hoverinfo": "skip", "legendrank": 1005, "stackgroup": "one_time_regular", "legendgroup": "category_legend" }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:02d582", "ysrc": "benjaleivas:307:5ead49", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:728233", "ysrc": "benjaleivas:307:88876b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:36b363", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e0265a", "ysrc": "benjaleivas:307:9a4ac6", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:24d3df", "ysrc": "benjaleivas:307:f21711", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6ef2d8", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:00a00e", "ysrc": "benjaleivas:307:244e33", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:b37f33", "ysrc": "benjaleivas:307:6eb87c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:0862ea", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:69a6cb", "ysrc": "benjaleivas:307:c2da9d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:d73468", "ysrc": "benjaleivas:307:0e1e81", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:f684e6", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:736d13", "ysrc": "benjaleivas:307:c9e721", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:ee9b33", "ysrc": "benjaleivas:307:524a52", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:785eec", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:05e208", "ysrc": "benjaleivas:307:7ef4f7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:04e3cd", "ysrc": "benjaleivas:307:b4528b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:dc689c", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b62adc", "ysrc": "benjaleivas:307:038144", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:2099db", "ysrc": "benjaleivas:307:bb31fe", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:811fd3", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:289bea", "ysrc": "benjaleivas:307:3a917e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:0776b0", "ysrc": "benjaleivas:307:2ae74e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:23bca2", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6a0447", "ysrc": "benjaleivas:307:43bb59", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:39a8db", "ysrc": "benjaleivas:307:42c20c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4ce28c", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:eec05e", "ysrc": "benjaleivas:307:bc65e5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:22e823", "ysrc": "benjaleivas:307:cdf3f5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:cd23f2", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6dbaf9", "ysrc": "benjaleivas:307:96fc8f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:b2ea29", "ysrc": "benjaleivas:307:a60de7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:7c9751", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:1eb289", "ysrc": "benjaleivas:307:61f2dc", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:4a32df", "ysrc": "benjaleivas:307:e7adc3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:20810e", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:88aefe", "ysrc": "benjaleivas:307:a4bf1f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:44253a", "ysrc": "benjaleivas:307:6b31a7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4d65e4", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d417f1", "ysrc": "benjaleivas:307:2022de", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:cc94ab", "ysrc": "benjaleivas:307:159503", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:eba35d", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d68f23", "ysrc": "benjaleivas:307:3b497c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:e71ff9", "ysrc": "benjaleivas:307:401ac9", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:e47b72", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:035d77", "ysrc": "benjaleivas:307:cd4db3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:12658b", "ysrc": "benjaleivas:307:620e15", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1de0d3", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:cb472f", "ysrc": "benjaleivas:307:43d9db", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:871cb8", "ysrc": "benjaleivas:307:df189b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:cccecb", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3cc1b0", "ysrc": "benjaleivas:307:fc3fcb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:398add", "ysrc": "benjaleivas:307:6e702d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:b585d0", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:c76da6", "ysrc": "benjaleivas:307:bf4e7e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:73dc61", "ysrc": "benjaleivas:307:7d0cfe", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:e7d9e7", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e83857", "ysrc": "benjaleivas:307:fbd780", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1b5fb5", "ysrc": "benjaleivas:307:239d25", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:32ae36", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5dcda5", "ysrc": "benjaleivas:307:1ecaaf", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:90d057", "ysrc": "benjaleivas:307:3596d9", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:d93118", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b71113", "ysrc": "benjaleivas:307:ed6cf5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:5d5579", "ysrc": "benjaleivas:307:2a2f8b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:c4be79", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:098d9e", "ysrc": "benjaleivas:307:70048c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:57e8c2", "ysrc": "benjaleivas:307:7c9cdb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:be2597", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:9a6de5", "ysrc": "benjaleivas:307:c7cc6a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1c5603", "ysrc": "benjaleivas:307:a46a5b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:03a8fe", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:def23c", "ysrc": "benjaleivas:307:6f06d8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:3d2d69", "ysrc": "benjaleivas:307:59cc52", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:541039", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:155f2d", "ysrc": "benjaleivas:307:550992", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:df97cd", "ysrc": "benjaleivas:307:429d4f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:654403", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:1358eb", "ysrc": "benjaleivas:307:2e2a59", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:3576a8", "ysrc": "benjaleivas:307:427209", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:28e2f1", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7d81bf", "ysrc": "benjaleivas:307:b5d930", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:70e41c", "ysrc": "benjaleivas:307:f3c1fd", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:67c5ef", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7f5f6b", "ysrc": "benjaleivas:307:2e0eae", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:01beae", "ysrc": "benjaleivas:307:8207f9", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:19609c", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3c069f", "ysrc": "benjaleivas:307:bc6234", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:9a8398", "ysrc": "benjaleivas:307:81835a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:bc70df", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:26ac06", "ysrc": "benjaleivas:307:d83333", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:9945e5", "ysrc": "benjaleivas:307:c0b09a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:afdb20", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b1cab2", "ysrc": "benjaleivas:307:747c95", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:a03f2d", "ysrc": "benjaleivas:307:4b653c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1532c9", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:44be85", "ysrc": "benjaleivas:307:392af4", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:6d612d", "ysrc": "benjaleivas:307:7a0c97", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:fca9bb", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:87825b", "ysrc": "benjaleivas:307:8e3eec", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:aef240", "ysrc": "benjaleivas:307:daf776", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4bf523", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:38a7f2", "ysrc": "benjaleivas:307:439fb2", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7d0e1e", "ysrc": "benjaleivas:307:332634", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:c2455b", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:4cbd51", "ysrc": "benjaleivas:307:7fab0f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:28a3a7", "ysrc": "benjaleivas:307:89b500", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:a29d18", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:4d4f67", "ysrc": "benjaleivas:307:5c56b3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:b9e242", "ysrc": "benjaleivas:307:2837ea", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:ecb0cc", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:266daa", "ysrc": "benjaleivas:307:f3a6e5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:e036b2", "ysrc": "benjaleivas:307:06b1c0", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:27b1f1", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:660a88", "ysrc": "benjaleivas:307:189872", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:f12e58", "ysrc": "benjaleivas:307:3f51d0", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6ce8f7", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2b85e2", "ysrc": "benjaleivas:307:4468f6", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:e8924b", "ysrc": "benjaleivas:307:5de857", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:729915", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5adfad", "ysrc": "benjaleivas:307:8260fe", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:50fad5", "ysrc": "benjaleivas:307:b5333e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:aca3f5", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:0fa6e6", "ysrc": "benjaleivas:307:f39bbb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:35e930", "ysrc": "benjaleivas:307:ed5fd5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:e4bc61", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:597265", "ysrc": "benjaleivas:307:71abf3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:72d337", "ysrc": "benjaleivas:307:789ebe", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1e2ee0", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:87436b", "ysrc": "benjaleivas:307:bfcd85", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:bad272", "ysrc": "benjaleivas:307:90c3a4", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:56f41e", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3e510d", "ysrc": "benjaleivas:307:09e5b1", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:56c445", "ysrc": "benjaleivas:307:eef0d2", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:7d87ea", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:99f412", "ysrc": "benjaleivas:307:223ed8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:599801", "ysrc": "benjaleivas:307:fb83b1", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:0e1a82", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:fa7892", "ysrc": "benjaleivas:307:5d1134", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:240651", "ysrc": "benjaleivas:307:e9a817", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:b8812f", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b536bd", "ysrc": "benjaleivas:307:60eced", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:616f2d", "ysrc": "benjaleivas:307:f4587c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:62036f", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d7a565", "ysrc": "benjaleivas:307:0c565b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7dd360", "ysrc": "benjaleivas:307:3fda04", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:5c504e", "visible": true, "hoverinfo": "skip", "showlegend": false }, { "name": "regular_hover_bar", "type": "bar", "xsrc": "benjaleivas:307:62fc2c", "ysrc": "benjaleivas:307:ffaadc", "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "width": 0 }, "color": "rgba(0,0,0,0)" }, "visible": true, "showlegend": false, "customdatasrc": "benjaleivas:307:82ea82", "hovertemplate": "<b>Day %{x}</b><br>Total Regular Users: %{customdata[1]}<br>Tracked Regular Users: %{customdata[0]}<extra></extra>" }, { "mode": "markers", "name": "power_hover", "type": "scatter", "xsrc": "benjaleivas:307:ec3585", "ysrc": "benjaleivas:307:2b58fd", "xaxis": "x", "yaxis": "y", "marker": { "size": 0, "opacity": 0 }, "visible": false, "showlegend": false, "customdatasrc": "benjaleivas:307:679a10", "hovertemplate": "%{customdata}<extra></extra>" }, { "fill": "tozeroy", "line": { "color": "#8c1515", "width": 0 }, "mode": "none", "name": "Student Chatbots", "type": "scatter", "xsrc": "benjaleivas:307:0b2d99", "ysrc": "benjaleivas:307:169e8b", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#8c1515", "hoverinfo": "skip", "legendrank": 1000, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#faa54a", "width": 0 }, "mode": "none", "name": "Teacher Productivity Tools", "type": "scatter", "xsrc": "benjaleivas:307:24611b", "ysrc": "benjaleivas:307:606e2e", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#faa54a", "hoverinfo": "skip", "legendrank": 1001, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#009ab4", "width": 0 }, "mode": "none", "name": "Teacher Chatbot Assistants", "type": "scatter", "xsrc": "benjaleivas:307:0a769e", "ysrc": "benjaleivas:307:d3eeb2", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#009ab4", "hoverinfo": "skip", "legendrank": 1002, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#2e5d54", "width": 0 }, "mode": "none", "name": "Reference Materials", "type": "scatter", "xsrc": "benjaleivas:307:82c1c7", "ysrc": "benjaleivas:307:250c0e", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#2e5d54", "hoverinfo": "skip", "legendrank": 1003, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#590c56", "width": 0 }, "mode": "none", "name": "Homepage/Auth", "type": "scatter", "xsrc": "benjaleivas:307:ff7070", "ysrc": "benjaleivas:307:5cb3e2", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#590c56", "hoverinfo": "skip", "legendrank": 1004, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "fill": "tonexty", "line": { "color": "#005e87", "width": 0 }, "mode": "none", "name": "Other", "type": "scatter", "xsrc": "benjaleivas:307:c0523e", "ysrc": "benjaleivas:307:7708c4", "xaxis": "x", "yaxis": "y", "visible": false, "fillcolor": "#005e87", "hoverinfo": "skip", "legendrank": 1005, "showlegend": false, "stackgroup": "one_time_power", "legendgroup": "category_legend" }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e83a65", "ysrc": "benjaleivas:307:9e6c52", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:a8e73e", "ysrc": "benjaleivas:307:6dc634", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:0e6b99", "ysrc": "benjaleivas:307:df7a1f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:822bdf", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3972b6", "ysrc": "benjaleivas:307:5c45e5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:59f838", "ysrc": "benjaleivas:307:7cdc87", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6860d9", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:eeac0a", "ysrc": "benjaleivas:307:b5e9a8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:c30af2", "ysrc": "benjaleivas:307:d774e8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:992e65", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d0fb10", "ysrc": "benjaleivas:307:cc9304", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:289931", "ysrc": "benjaleivas:307:d5df6c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:137c2c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:ff0785", "ysrc": "benjaleivas:307:50a438", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:28e09a", "ysrc": "benjaleivas:307:5fd223", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:97e22c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:96da15", "ysrc": "benjaleivas:307:edfa8a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:eec397", "ysrc": "benjaleivas:307:6cae2f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:5725f9", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5c9900", "ysrc": "benjaleivas:307:dce148", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:cb5df0", "ysrc": "benjaleivas:307:611e03", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:0d9d69", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:9fe0c1", "ysrc": "benjaleivas:307:437d83", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:8dffa2", "ysrc": "benjaleivas:307:350bdb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:dd5dad", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:de3a42", "ysrc": "benjaleivas:307:49b8d7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:fc392d", "ysrc": "benjaleivas:307:1a65f6", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:3d5dc7", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:26c801", "ysrc": "benjaleivas:307:691b6a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:55da5e", "ysrc": "benjaleivas:307:ec4545", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:43e758", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:34a0d0", "ysrc": "benjaleivas:307:2962c9", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:582d5e", "ysrc": "benjaleivas:307:af7e7f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:27b6b3", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2ce38a", "ysrc": "benjaleivas:307:ccda62", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:f471f4", "ysrc": "benjaleivas:307:74618f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7a0574", "ysrc": "benjaleivas:307:099ac2", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:924114", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:965136", "ysrc": "benjaleivas:307:6efb3c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:e818ab", "ysrc": "benjaleivas:307:14b871", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:db1b1a", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:049b18", "ysrc": "benjaleivas:307:c96f26", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1d230a", "ysrc": "benjaleivas:307:215a9a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:a9ea61", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:48c635", "ysrc": "benjaleivas:307:4de714", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:eadcdc", "ysrc": "benjaleivas:307:31f86a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6dc14c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7a988f", "ysrc": "benjaleivas:307:b52179", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:4c61d4", "ysrc": "benjaleivas:307:daea51", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:c1e267", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:eeba06", "ysrc": "benjaleivas:307:c78d5c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7f531a", "ysrc": "benjaleivas:307:07d667", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:d9871b", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:a9076b", "ysrc": "benjaleivas:307:80c169", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:c01dad", "ysrc": "benjaleivas:307:219aeb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:c9dfe0", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:05f216", "ysrc": "benjaleivas:307:576de3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:2379b5", "ysrc": "benjaleivas:307:4c6e39", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:0b317e", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:137053", "ysrc": "benjaleivas:307:7dd7ca", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1abfa8", "ysrc": "benjaleivas:307:d780d9", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:adb089", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3defa8", "ysrc": "benjaleivas:307:856238", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7fd99d", "ysrc": "benjaleivas:307:dcb978", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:92d89a", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:ae801b", "ysrc": "benjaleivas:307:07e791", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:d479bb", "ysrc": "benjaleivas:307:5c0b34", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:875c14", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:32b004", "ysrc": "benjaleivas:307:2de8a3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:3d0e7c", "ysrc": "benjaleivas:307:5fa77e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:bbc825", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:f0b88a", "ysrc": "benjaleivas:307:dbc1bd", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:3f13e7", "ysrc": "benjaleivas:307:f3c47c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:cabe95", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2c59ab", "ysrc": "benjaleivas:307:5f1562", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:23df54", "ysrc": "benjaleivas:307:fc2a37", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:e3aa70", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5218a8", "ysrc": "benjaleivas:307:391b64", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1ea32b", "ysrc": "benjaleivas:307:ce0775", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:cb2096", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6069ce", "ysrc": "benjaleivas:307:67663f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:461a2e", "ysrc": "benjaleivas:307:0dd27e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1a3662", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b7b906", "ysrc": "benjaleivas:307:ba141a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:bb4f96", "ysrc": "benjaleivas:307:af3c08", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1403e0", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:260092", "ysrc": "benjaleivas:307:0b98b8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:75fa54", "ysrc": "benjaleivas:307:9dd0f8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:f2eed4", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:322a14", "ysrc": "benjaleivas:307:22b73f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:4e30b9", "ysrc": "benjaleivas:307:e1f59a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:3556ef", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:741127", "ysrc": "benjaleivas:307:826861", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:86570a", "ysrc": "benjaleivas:307:c1caca", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:68ac8c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7a30b2", "ysrc": "benjaleivas:307:234b54", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:cc76b9", "ysrc": "benjaleivas:307:1a1e87", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:031c31", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:814830", "ysrc": "benjaleivas:307:08e6d3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:43938a", "ysrc": "benjaleivas:307:390f1e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:610334", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:ce2d91", "ysrc": "benjaleivas:307:a26801", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:353d0c", "ysrc": "benjaleivas:307:bac021", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:df9d75", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:a194cd", "ysrc": "benjaleivas:307:f3d662", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:f46798", "ysrc": "benjaleivas:307:b3ef0e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:383ab0", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7b62ec", "ysrc": "benjaleivas:307:a557c6", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:299846", "ysrc": "benjaleivas:307:1f7625", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:87bb1e", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5dfaf1", "ysrc": "benjaleivas:307:b9ccf8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:256f5e", "ysrc": "benjaleivas:307:f38f8a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:e499bb", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:8fcd1e", "ysrc": "benjaleivas:307:a9798c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:ab8ada", "ysrc": "benjaleivas:307:6a22fe", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:ceb283", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6b2bcb", "ysrc": "benjaleivas:307:0671b8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:3a8671", "ysrc": "benjaleivas:307:4bae47", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4c7325", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:acc1d6", "ysrc": "benjaleivas:307:80d896", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:521a23", "ysrc": "benjaleivas:307:34827d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:f23f0e", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:63b3b7", "ysrc": "benjaleivas:307:c698bc", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:313552", "ysrc": "benjaleivas:307:cf4b13", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:26734c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6d9840", "ysrc": "benjaleivas:307:a0b000", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:42d058", "ysrc": "benjaleivas:307:748f5b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:c0970f", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3669e6", "ysrc": "benjaleivas:307:88cc0e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:845d32", "ysrc": "benjaleivas:307:4ea76a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:36a60d", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:33a91d", "ysrc": "benjaleivas:307:972e9d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:f5d550", "ysrc": "benjaleivas:307:54955c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:07c445", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7fc92e", "ysrc": "benjaleivas:307:a797ff", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:65a284", "ysrc": "benjaleivas:307:9ebf18", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4a713c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:6adc8c", "ysrc": "benjaleivas:307:6d551f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:359fb8", "ysrc": "benjaleivas:307:268e97", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6da579", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:693cbd", "ysrc": "benjaleivas:307:dd52f3", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:732f55", "ysrc": "benjaleivas:307:701de2", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:60cd29", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:675beb", "ysrc": "benjaleivas:307:eb612e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:100b58", "ysrc": "benjaleivas:307:e4c190", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:bd9dfb", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:9c889c", "ysrc": "benjaleivas:307:96f59d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:597ad6", "ysrc": "benjaleivas:307:b9ca57", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:8a6b9d", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:308ad1", "ysrc": "benjaleivas:307:e9ee57", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:1609df", "ysrc": "benjaleivas:307:690699", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:75f3c1", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:c0facd", "ysrc": "benjaleivas:307:f38360", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:7ab397", "ysrc": "benjaleivas:307:57e73a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:d218b1", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:818792", "ysrc": "benjaleivas:307:92eb8b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:52b361", "ysrc": "benjaleivas:307:bebed5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:2a7968", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:1acb9a", "ysrc": "benjaleivas:307:71b0de", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:8e3832", "ysrc": "benjaleivas:307:dad36a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:09ae13", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:3471ae", "ysrc": "benjaleivas:307:af0936", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:c45752", "ysrc": "benjaleivas:307:f8a8cd", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:bbc090", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:5d5980", "ysrc": "benjaleivas:307:2f8e3d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:6a8818", "ysrc": "benjaleivas:307:97fa00", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4ef0e8", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:ba4d8c", "ysrc": "benjaleivas:307:524626", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:aaa87d", "ysrc": "benjaleivas:307:6a57d8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6428e2", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:fcf41a", "ysrc": "benjaleivas:307:dbc608", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:c5819e", "ysrc": "benjaleivas:307:c267a5", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:4fcf19", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:decd4e", "ysrc": "benjaleivas:307:a338fc", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:f1338d", "ysrc": "benjaleivas:307:3ff00b", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:a13d3c", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e05410", "ysrc": "benjaleivas:307:6f98b7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2047cf", "ysrc": "benjaleivas:307:fa247f", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:df7b71", "ysrc": "benjaleivas:307:b349fd", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:107c23", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:032d99", "ysrc": "benjaleivas:307:c7fc35", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:6b5f7b", "ysrc": "benjaleivas:307:7a456e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:5261dc", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:a4d707", "ysrc": "benjaleivas:307:ab7e3e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:81a7ea", "ysrc": "benjaleivas:307:912422", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:bb7601", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:239989", "ysrc": "benjaleivas:307:78f8e7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:45dbbc", "ysrc": "benjaleivas:307:0320ea", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:f895e1", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:01e684", "ysrc": "benjaleivas:307:693aed", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:ba6547", "ysrc": "benjaleivas:307:923cc6", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:791438", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:9986aa", "ysrc": "benjaleivas:307:8550e0", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:f4620d", "ysrc": "benjaleivas:307:62c130", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b89bf2", "ysrc": "benjaleivas:307:e046d7", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7b06ca", "ysrc": "benjaleivas:307:276bbb", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:0016d2", "ysrc": "benjaleivas:307:c9eb3c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:f39b5a", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:a0d8ea", "ysrc": "benjaleivas:307:6dbf78", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2862d7", "ysrc": "benjaleivas:307:4b7657", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:d96753", "ysrc": "benjaleivas:307:407f64", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:6767b7", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e8c306", "ysrc": "benjaleivas:307:dfc363", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:87cef6", "ysrc": "benjaleivas:307:5cbeab", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d568ec", "ysrc": "benjaleivas:307:e051db", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:bdbd0e", "ysrc": "benjaleivas:307:8f104d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:d0c0c9", "ysrc": "benjaleivas:307:bd19ff", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e8a5f1", "ysrc": "benjaleivas:307:3bea5a", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_red", "type": "bar", "xsrc": "benjaleivas:307:a10dff", "ysrc": "benjaleivas:307:34638d", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "red", "width": 1 }, "color": "white" }, "basesrc": "benjaleivas:307:1b6882", "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:eff4d9", "ysrc": "benjaleivas:307:6772ff", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:e9dc6f", "ysrc": "benjaleivas:307:73c65e", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7cbdff", "ysrc": "benjaleivas:307:8c05fa", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:78e09a", "ysrc": "benjaleivas:307:27b79c", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:7e6fff", "ysrc": "benjaleivas:307:c76129", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:2ac14a", "ysrc": "benjaleivas:307:9385f2", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:b6b2d7", "ysrc": "benjaleivas:307:faedb8", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_bar_black", "type": "bar", "xsrc": "benjaleivas:307:cc63de", "ysrc": "benjaleivas:307:905f85", "width": 0.8, "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "white" }, "visible": false, "hoverinfo": "skip", "showlegend": false }, { "name": "power_hover_bar", "type": "bar", "xsrc": "benjaleivas:307:419d48", "ysrc": "benjaleivas:307:e5feaa", "xaxis": "x2", "yaxis": "y2", "marker": { "line": { "width": 0 }, "color": "rgba(0,0,0,0)" }, "visible": false, "showlegend": false, "customdatasrc": "benjaleivas:307:c86322", "hovertemplate": "<b>Day %{x}</b><br>Total Power Users: %{customdata[1]}<br>Tracked Power Users: %{customdata[0]}<extra></extra>" }, { "mode": "markers", "name": "Tracked", "type": "scatter", "xsrc": "benjaleivas:307:c9d27a", "ysrc": "benjaleivas:307:ba6a64", "legend": "legend2", "marker": { "line": { "color": "black", "width": 2 }, "size": 12, "color": "white", "symbol": "square" }, "visible": true, "legendrank": 100, "showlegend": true, "legendgroup": "bottom_legend" }, { "mode": "markers", "name": "Untracked", "type": "scatter", "xsrc": "benjaleivas:307:f515f0", "ysrc": "benjaleivas:307:c8786f", "legend": "legend2", "marker": { "line": { "color": "red", "width": 2 }, "size": 12, "color": "white", "symbol": "square" }, "visible": true, "legendrank": 101, "showlegend": true, "legendgroup": "bottom_legend" } ], "layout": { "width": 1000, "xaxis": { "anchor": "y", "domain": [ 0.0, 1.0 ], "matches": "x2", "showticklabels": false }, "yaxis": { "range": [ 0, 100 ], "title": { "text": "Share of Time (%)" }, "anchor": "x", "domain": [ 0.33499999999999996, 0.9999999999999999 ] }, "height": 700, "legend": { "x": 1.02, "y": 1.015, "xanchor": "left", "yanchor": "top", "traceorder": "normal", "orientation": "v" }, "margin": { "b": 200, "l": 50, "r": 50, "t": 50 }, "shapes": [ { "x0": 0, "x1": 1, "y0": 0, "y1": 0.3, "line": { "width": 0 }, "type": "rect", "xref": "paper", "yref": "paper", "layer": "below", "fillcolor": "white" } ], "xaxis2": { "range": [ 1, 49 ], "title": { "text": "Days Using Platform" }, "anchor": "y2", "domain": [ 0.0, 1.0 ], "showgrid": false }, "yaxis2": { "range": [ 0, 4041.4000000000005 ], "title": { "text": "Active Users" }, "anchor": "x2", "domain": [ 0.0, 0.285 ], "showgrid": false, "showline": true, "linecolor": "black", "linewidth": 1 }, "legend2": { "x": 1.02, "y": 0.1, "xanchor": "left", "traceorder": "normal", "orientation": "v" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "hovermode": "x unified", "annotations": [ { "x": 0.0, "y": -0.18, "font": { "size": 17, "color": "black" }, "text": "<b>Figure 9</b>: How Regular/Power Users Spend Their Time on Each Feature", "xref": "paper", "yref": "paper", "xanchor": "left", "yanchor": "top", "showarrow": false }, { "x": 0.0, "y": -0.24, "font": { "size": 13, "color": "black" }, "text": "<b>Notes:</b> The top panel shows how Regular/Power Users allocate their time across SchoolAI features, for each day since their first session. The<br>bottom panel shows how many Regular/Power Users were active each day, distinguishing between teachers whose actions we were able to track and<br>the ones we weren't able to due to incomplete \"runs\"—continuous periods during which a teacher interacts with a single feature before switching or<br>ending their session for the day. To avoid skewed results, we remove outlier runs (those ± 2 standard deviations away from the feature's average<br>duration) and drop each teacher's final run of the day since its actual end time is unknown (unless it was their only run of the day).", "xref": "paper", "yref": "paper", "align": "left", "xanchor": "left", "yanchor": "top", "showarrow": false } ], "updatemenus": [ { "x": 0.08, "y": 1.15, "pad": { "r": 10, "t": 10 }, "type": "buttons", "buttons": [ { "args": [ { "visible": [ true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, false, true, true, true, true, true, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, true, true ] }, { "xaxis2.range": [ 1, 49 ], "yaxis2.range": [ 0, 4041.4000000000005 ] } ], "label": "Regular Users", "method": "update" }, { "args": [ { "visible": [ false, true, true, true, true, true, true, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, false, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true, true ] }, { "xaxis2.range": [ 1, 86 ], "yaxis2.range": [ 0, 96.80000000000001 ] } ], "label": "Power Users", "method": "update" } ], "xanchor": "center", "yanchor": "top", "direction": "left", "showactive": true } ] } }, "height": 700, "width": 1000, "user": { "profile_url": "https://chart-studio.plotly.com/~benjaleivas", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/48.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "Data Scientist", "nickname": "Benjamin Leiva", "website": "https://github.com/benjaleivas", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-26 18:59:03", "mapbox_access_tokens": null, "has_password": null, "username": "benjaleivas", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
