Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cj0xJnA9MjAyNC0wNC0zMCswMyUzQTM0JTNBMzcuMTE4MjE0JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI0LTA0LTMwKzAzJTNBNTElM0EwOC40NzQ0ODYlMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNC0wNC0zMCswNiUzQTQyJTNBMjAuNTYxODk0JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2024-04-30T06:42:20.561894Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Priyansh998/1.embed", "fid": "Priyansh998:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Priyansh998/1/9_1SHXB89UV7OM4JQB91LC9HVYA2VQTM.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Priyansh998/1/2_XTNHAKWFW3JFVJQW41W0BZ48UCR4CX.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Priyansh998/1/8_PFNIGNCZDALQG1O02DFC6GCU67EBGW.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Priyansh998/1/9_1SHXB89UV7OM4JQB91LC9HVYA2VQTM.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Priyansh998:1", "plots": "https://api.plotly.com/v2/plots/Priyansh998:1", "parent": "https://api.plotly.com/v2/folders/home?user=Priyansh998" }, "owner": "Priyansh998", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Priyansh998/1/", "world_readable": true, "date_modified": "2024-04-30T07:15:47.315Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Priyansh998/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "name": "Weight", "type": "scatter", "xsrc": "Priyansh998:0:e6de23", "ysrc": "Priyansh998:0:908106" }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "lines", "name": "Deflection", "type": "scatter", "xsrc": "Priyansh998:0:e6de23", "ysrc": "Priyansh998:0:92fe57", "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "lines", "name": "Stress", "type": "scatter", "xsrc": "Priyansh998:0:e6de23", "ysrc": "Priyansh998:0:d42a75", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "category", "range": [ 0, 2 ], "title": { "text": "Weight, deflection and stress curve under 1000 kN load" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0.6320194444444445, 3.1246305555555556 ], "autorange": true }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Priyansh998", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/36.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 06:41:36", "mapbox_access_tokens": null, "has_password": null, "username": "Priyansh998", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T06:32:54.656234Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~T_Oshima/4.embed", "fid": "T_Oshima:4", "filename": "歴史年表", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/T_Oshima/4/9_6WJRATW9GUJGXCEDAPF6DR2HLXMM2V.png", "image_urls": { "default": "https://api.plotly.com/v2/files/T_Oshima:4/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/T_Oshima:4/image?image_name=block-thumb", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/T_Oshima/4/9_6WJRATW9GUJGXCEDAPF6DR2HLXMM2V.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/T_Oshima:4", "plots": "https://api.plotly.com/v2/plots/T_Oshima:4", "parent": "https://api.plotly.com/v2/folders/home?user=T_Oshima" }, "owner": "T_Oshima", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 51, "web_url": "https://chart-studio.plotly.com/~T_Oshima/4/", "world_readable": true, "date_modified": "2024-12-06T15:32:10.884Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~T_Oshima/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "00_人類の起源", "type": "bar", "xsrc": "T_Oshima:208:460d1a", "ysrc": "T_Oshima:208:81171b", "basesrc": "T_Oshima:208:21887d", "textsrc": "T_Oshima:208:98ae78", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:5413e1", "textposition": "outside" }, { "name": "01_時代", "type": "bar", "xsrc": "T_Oshima:208:358222", "ysrc": "T_Oshima:208:878a0f", "basesrc": "T_Oshima:208:a43cd3", "textsrc": "T_Oshima:208:b2b867", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:4f7018", "textposition": "outside" }, { "name": "02_国家", "type": "bar", "xsrc": "T_Oshima:208:5f998a", "ysrc": "T_Oshima:208:681f5b", "basesrc": "T_Oshima:208:4ca627", "textsrc": "T_Oshima:208:6552c3", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:5a37e5", "textposition": "outside" }, { "name": "05_宗教", "type": "bar", "xsrc": "T_Oshima:208:77cfa7", "ysrc": "T_Oshima:208:452620", "basesrc": "T_Oshima:208:b4d741", "textsrc": "T_Oshima:208:f00a6e", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:3bc477", "textposition": "outside" }, { "name": "06_哲学", "type": "bar", "xsrc": "T_Oshima:208:bfa4df", "ysrc": "T_Oshima:208:5ff961", "basesrc": "T_Oshima:208:36e666", "textsrc": "T_Oshima:208:d27b35", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:d3372f", "textposition": "outside" }, { "name": "04_争い", "type": "bar", "xsrc": "T_Oshima:208:e5f475", "ysrc": "T_Oshima:208:31bbdb", "basesrc": "T_Oshima:208:f822e6", "textsrc": "T_Oshima:208:7183e2", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:6b306a", "textposition": "outside" }, { "name": "03_社会", "type": "bar", "xsrc": "T_Oshima:208:86980e", "ysrc": "T_Oshima:208:5806b9", "basesrc": "T_Oshima:208:3a9e95", "textsrc": "T_Oshima:208:31e04b", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:bdc2ce", "textposition": "outside" }, { "name": "09_科学・技術", "type": "bar", "xsrc": "T_Oshima:208:a9c114", "ysrc": "T_Oshima:208:b9ec16", "basesrc": "T_Oshima:208:a4c86f", "textsrc": "T_Oshima:208:e99743", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:59d8de", "textposition": "outside" }, { "name": "08_音楽", "type": "bar", "xsrc": "T_Oshima:208:d4abeb", "ysrc": "T_Oshima:208:36facb", "basesrc": "T_Oshima:208:809b11", "textsrc": "T_Oshima:208:e13508", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:43bd84", "textposition": "outside" }, { "name": "07_芸術", "type": "bar", "xsrc": "T_Oshima:208:a17dc9", "ysrc": "T_Oshima:208:3b23ef", "basesrc": "T_Oshima:208:06aabb", "textsrc": "T_Oshima:208:43d8af", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:0def86", "textposition": "outside" }, { "name": "11_環境", "type": "bar", "xsrc": "T_Oshima:208:801a78", "ysrc": "T_Oshima:208:956bfc", "basesrc": "T_Oshima:208:75f70a", "textsrc": "T_Oshima:208:e53b59", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:a68ef6", "textposition": "outside" }, { "name": "10_病気", "type": "bar", "xsrc": "T_Oshima:208:ff0b1e", "ysrc": "T_Oshima:208:e975fc", "basesrc": "T_Oshima:208:c23269", "textsrc": "T_Oshima:208:461880", "hoverinfo": "text", "orientation": "h", "hovertextsrc": "T_Oshima:208:e470b8", "textposition": "outside" } ], "layout": { "font": { "color": "white" }, "title": { "font": { "size": 20 }, "text": "歴史年表" }, "xaxis": { "title": { "text": "year" } }, "yaxis": { "autorange": "reversed", "showticklabels": false }, "colorway": [ "#709fb0", "#BDB76B", "#e76f51", "#f4a261", "#2a9d8f", "#f2cc8f", "#6A5ACD", "#9db4c0" ], "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "plot_bgcolor": "#46607A", "paper_bgcolor": "#2c3e50" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~T_Oshima", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:43:36", "mapbox_access_tokens": null, "has_password": null, "username": "T_Oshima", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T06:32:04.231316Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~iamolvr/2.embed", "fid": "iamolvr:2", "filename": "agent_stats_mean", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/iamolvr/2/9_IZOF4HNX8WBUFEKZZMAI2UAZDZ7HIY.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/iamolvr/2/2_HUCZFZU1KQ0PB8J616UYCE2DUA0V3X.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/iamolvr/2/8_51WQDNTMY6NRG7P4B1T2GBYUFONQDD.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/iamolvr/2/9_IZOF4HNX8WBUFEKZZMAI2UAZDZ7HIY.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/iamolvr:2", "plots": "https://api.plotly.com/v2/plots/iamolvr:2", "parent": "https://api.plotly.com/v2/folders/home?user=iamolvr" }, "owner": "iamolvr", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 85, "web_url": "https://chart-studio.plotly.com/~iamolvr/2/", "world_readable": true, "date_modified": "2024-04-30T07:26:30.878Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~iamolvr/2/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": false, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "data.0.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:17b305", "xaxis": "x", "yaxis": "y", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.1.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:6bd9fc", "xaxis": "x", "yaxis": "y", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.2.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:99bcd0", "xaxis": "x2", "yaxis": "y2", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.3.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:70f102", "xaxis": "x2", "yaxis": "y2", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.4.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:5ea87e", "xaxis": "x3", "yaxis": "y3", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.5.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:85c11f", "xaxis": "x3", "yaxis": "y3", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.6.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:56ef75", "xaxis": "x4", "yaxis": "y4", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.7.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:db8225", "xaxis": "x4", "yaxis": "y4", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.8.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:f8bfd4", "xaxis": "x5", "yaxis": "y5", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.9.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:821c96", "xaxis": "x5", "yaxis": "y5", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.10.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:eee3ad", "xaxis": "x6", "yaxis": "y6", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.11.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:3fe5bb", "xaxis": "x6", "yaxis": "y6", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.12.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:3c28d4", "xaxis": "x7", "yaxis": "y7", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.13.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:4c468e", "xaxis": "x7", "yaxis": "y7", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.14.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:a131aa", "xaxis": "x8", "yaxis": "y8", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.15.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:8aea5f", "xaxis": "x8", "yaxis": "y8", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.16.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:78e96a", "xaxis": "x9", "yaxis": "y9", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.17.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:b0c7a2", "xaxis": "x9", "yaxis": "y9", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.18.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:125fe7", "xaxis": "x10", "yaxis": "y10", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.19.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:a2295b", "xaxis": "x10", "yaxis": "y10", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.20.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:cb1803", "xaxis": "x11", "yaxis": "y11", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.21.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:9c307d", "xaxis": "x11", "yaxis": "y11", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.22.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:52c303", "xaxis": "x12", "yaxis": "y12", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.23.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:5f2c83", "xaxis": "x12", "yaxis": "y12", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.24.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:7348df", "xaxis": "x13", "yaxis": "y13", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.25.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:c2b292", "xaxis": "x13", "yaxis": "y13", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.26.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:bff664", "xaxis": "x14", "yaxis": "y14", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.27.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:a742c8", "xaxis": "x14", "yaxis": "y14", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.28.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:d3a334", "xaxis": "x15", "yaxis": "y15", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.29.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:3f5d60", "xaxis": "x15", "yaxis": "y15", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.30.x" } }, "name": "Top Agents", "type": "box", "xsrc": "iamolvr:1:0787d8", "xaxis": "x16", "yaxis": "y16", "marker": { "color": "lightseagreen" }, "boxmean": true, "boxpoints": "all" }, { "meta": { "columnNames": { "x": "data.31.x" } }, "name": "Bad Agents", "type": "box", "xsrc": "iamolvr:1:9d3160", "xaxis": "x16", "yaxis": "y16", "marker": { "color": "indianred" }, "boxmean": true, "boxpoints": "all" } ], "frames": [], "layout": { "title": { "text": "Comparison of various daily stats between top agents and other agents (starting from 2023-07-01)" }, "width": 1000, "xaxis": { "type": "linear", "range": [ -0.24315336463223788, 4.61991392801252 ], "anchor": "y", "domain": [ 0, 1 ], "autorange": true }, "yaxis": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x", "domain": [ 0.9562499999999998, 0.9999999999999998 ], "autorange": true }, "height": 4000, "xaxis2": { "type": "linear", "range": [ -2.8982873851294904, 55.067460317460316 ], "anchor": "y2", "domain": [ 0, 1 ], "autorange": true }, "xaxis3": { "type": "linear", "range": [ -2.469191919191919, 46.91464646464647 ], "anchor": "y3", "domain": [ 0, 1 ], "autorange": true }, "xaxis4": { "type": "linear", "range": [ -109.60074334898279, 2082.4141236306727 ], "anchor": "y4", "domain": [ 0, 1 ], "autorange": true }, "xaxis5": { "type": "linear", "range": [ -32.129043256949544, 610.4518218820414 ], "anchor": "y5", "domain": [ 0, 1 ], "autorange": true }, "xaxis6": { "type": "linear", "range": [ -0.05555555555555555, 1.0555555555555556 ], "anchor": "y6", "domain": [ 0, 1 ], "autorange": true }, "xaxis7": { "type": "linear", "range": [ -0.07294028722600152, 1.3858654572940285 ], "anchor": "y7", "domain": [ 0, 1 ], "autorange": true }, "xaxis8": { "type": "linear", "range": [ -4.418686868686868, 83.9550505050505 ], "anchor": "y8", "domain": [ 0, 1 ], "autorange": true }, "xaxis9": { "type": "linear", "range": [ -4.3040404040404034, 81.77676767676768 ], "anchor": "y9", "domain": [ 0, 1 ], "autorange": true }, "yaxis2": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x2", "domain": [ 0.8925, 0.9362499999999999 ], "autorange": true }, "yaxis3": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x3", "domain": [ 0.82875, 0.8724999999999999 ], "autorange": true }, "yaxis4": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x4", "domain": [ 0.765, 0.80875 ], "autorange": true }, "yaxis5": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x5", "domain": [ 0.70125, 0.745 ], "autorange": true }, "yaxis6": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x6", "domain": [ 0.6375000000000001, 0.68125 ], "autorange": true }, "yaxis7": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x7", "domain": [ 0.57375, 0.6174999999999999 ], "autorange": true }, "yaxis8": { "type": "category", "range": [ -0.5365575019040366, 1.5 ], "anchor": "x8", "domain": [ 0.51, 0.55375 ], "autorange": true }, "yaxis9": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x9", "domain": [ 0.44625000000000004, 0.49000000000000005 ], "autorange": true }, "xaxis10": { "type": "linear", "range": [ -21.24197965571205, 403.59761345852894 ], "anchor": "y10", "domain": [ 0, 1 ], "autorange": true }, "xaxis11": { "type": "linear", "range": [ -0.6932367149758454, 13.171497584541061 ], "anchor": "y11", "domain": [ 0, 1 ], "autorange": true }, "xaxis12": { "type": "linear", "range": [ -0.16, 3.04 ], "anchor": "y12", "domain": [ 0, 1 ], "autorange": true }, "xaxis13": { "type": "linear", "range": [ -1.0763888888888888, 20.45138888888889 ], "anchor": "y13", "domain": [ 0, 1 ], "autorange": true }, "xaxis14": { "type": "linear", "range": [ -3.4722222222222223, 65.97222222222223 ], "anchor": "y14", "domain": [ 0, 1 ], "autorange": true }, "xaxis15": { "type": "linear", "range": [ -0.38333333333333336, 7.283333333333334 ], "anchor": "y15", "domain": [ 0, 1 ], "autorange": true }, "xaxis16": { "type": "linear", "range": [ -1.328888888888889, 25.248888888888892 ], "anchor": "y16", "domain": [ 0, 1 ], "autorange": true }, "yaxis10": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x10", "domain": [ 0.3825, 0.42625 ], "autorange": true }, "yaxis11": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x11", "domain": [ 0.31875, 0.3625 ], "autorange": true }, "yaxis12": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x12", "domain": [ 0.255, 0.29875 ], "autorange": true }, "yaxis13": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x13", "domain": [ 0.19124999999999998, 0.235 ], "autorange": true }, "yaxis14": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x14", "domain": [ 0.1275, 0.17125 ], "autorange": true }, "yaxis15": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x15", "domain": [ 0.06375, 0.1075 ], "autorange": true }, "yaxis16": { "type": "category", "range": [ -0.5365575019040365, 1.5 ], "anchor": "x16", "domain": [ 0, 0.04375 ], "autorange": true }, "autosize": false, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ], "sequentialminus": [ [ 0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "showlegend": false, "annotations": [ { "x": 0.5, "y": 0.9999999999999998, "font": { "size": 16 }, "text": "CALLS__successful", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.9362499999999999, "font": { "size": 16 }, "text": "CALLS__total", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.8724999999999999, "font": { "size": 16 }, "text": "CALLS__total_interacted_leads", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.80875, "font": { "size": 16 }, "text": "CALLS__total_duration_sec", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.745, "font": { "size": 16 }, "text": "CALLS__average_duration_sec", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.68125, "font": { "size": 16 }, "text": "CALLS__success_to_total_ratio", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.6174999999999999, "font": { "size": 16 }, "text": "MEETINGS__to_do", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.55375, "font": { "size": 16 }, "text": "FOLLOW_UPS__created", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.49000000000000005, "font": { "size": 16 }, "text": "FOLLOW_UPS__to_do", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.42625, "font": { "size": 16 }, "text": "COMMENTS__created", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.3625, "font": { "size": 16 }, "text": "CRM_EMAIL", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.29875, "font": { "size": 16 }, "text": "IMOPENLINES_SESSION", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.235, "font": { "size": 16 }, "text": "UNSUCCESSFUL__put_by_agent", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.17125, "font": { "size": 16 }, "text": "JUNK__put_by_agent", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.1075, "font": { "size": 16 }, "text": "AVERAGE_ACTIVE_DAYS_PER_WEEK", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false }, { "x": 0.5, "y": 0.04375, "font": { "size": 16 }, "text": "HOURS__from_lead_to_call", "xref": "paper", "yref": "paper", "xanchor": "center", "yanchor": "bottom", "showarrow": false } ] } }, "height": 4000, "width": 1000, "user": { "profile_url": "https://chart-studio.plotly.com/~iamolvr", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/95.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:49:45", "mapbox_access_tokens": null, "has_password": null, "username": "iamolvr", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T06:28:22.618646Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~T_Oshima/1.embed", "fid": "T_Oshima:1", "filename": "歴史地図", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/T_Oshima:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/T_Oshima:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/T_Oshima:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/T_Oshima:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/T_Oshima:1", "plots": "https://api.plotly.com/v2/plots/T_Oshima:1", "parent": "https://api.plotly.com/v2/folders/home?user=T_Oshima" }, "owner": "T_Oshima", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 63, "web_url": "https://chart-studio.plotly.com/~T_Oshima/1/", "world_readable": true, "date_modified": "2024-12-06T16:03:39.907Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~T_Oshima/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:9c588f", "lonsrc": "T_Oshima:209:27a7cf", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:87b627", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:6538ea", "textposition": "top center", "customdatasrc": "T_Oshima:209:31f5af", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:3ff068", "lonsrc": "T_Oshima:209:4907a0", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:932a3d", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:f30ada", "textposition": "top center", "customdatasrc": "T_Oshima:209:7fb7ef", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:1bf649", "lonsrc": "T_Oshima:209:4c2e9b", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:6b4d65", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:0181ce", "textposition": "top center", "customdatasrc": "T_Oshima:209:f57d2f", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "frames": [ { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:3574ce", "lonsrc": "T_Oshima:209:30b8be", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:400051", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:000d4e", "customdatasrc": "T_Oshima:209:027933", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:6eb87f", "lonsrc": "T_Oshima:209:93b48e", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:0e42f9", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:ce118f", "customdatasrc": "T_Oshima:209:6c606c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:6a7c5a", "lonsrc": "T_Oshima:209:0f6470", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:d6a19e", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:00f68a", "customdatasrc": "T_Oshima:209:f53789", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前700万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:6db81e", "lonsrc": "T_Oshima:209:215344", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:3f59a6", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:a6fde5", "customdatasrc": "T_Oshima:209:9e062a", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:cab9ea", "lonsrc": "T_Oshima:209:62ec85", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:210a25", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:e0479b", "customdatasrc": "T_Oshima:209:8296c0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:4a9415", "lonsrc": "T_Oshima:209:85b2e7", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:14ce30", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:b968e2", "customdatasrc": "T_Oshima:209:7408e4", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前100万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:a8f4af", "lonsrc": "T_Oshima:209:babd11", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:7b428e", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:3de211", "customdatasrc": "T_Oshima:209:94ecd0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:784a3e", "lonsrc": "T_Oshima:209:d8209a", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:bf22fc", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:5e7bd5", "customdatasrc": "T_Oshima:209:81262c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:812d02", "lonsrc": "T_Oshima:209:c06898", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:3f48ad", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:ebd12c", "customdatasrc": "T_Oshima:209:1ab9f9", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前50万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:52ae38", "lonsrc": "T_Oshima:209:764d66", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:63d474", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:5b6239", "customdatasrc": "T_Oshima:209:5f6096", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:dffc38", "lonsrc": "T_Oshima:209:1d1866", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:e0fca6", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:119769", "customdatasrc": "T_Oshima:209:c8e6bd", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:24c2c7", "lonsrc": "T_Oshima:209:835724", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:898594", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:c86721", "customdatasrc": "T_Oshima:209:b54c73", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前10万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:137d7a", "lonsrc": "T_Oshima:209:13c76c", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:354bda", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:b2565e", "customdatasrc": "T_Oshima:209:d30c4c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:3856d9", "lonsrc": "T_Oshima:209:c79c23", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:2a7859", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:ac8985", "customdatasrc": "T_Oshima:209:02725c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:7753ef", "lonsrc": "T_Oshima:209:b3fc4a", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:f8f44e", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:3d1aac", "customdatasrc": "T_Oshima:209:efee4f", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前5万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:0b3f6e", "lonsrc": "T_Oshima:209:2ddd92", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:ffb163", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:84b972", "customdatasrc": "T_Oshima:209:624cf4", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:9298fb", "lonsrc": "T_Oshima:209:b5d2d4", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:346fcf", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:5c8724", "customdatasrc": "T_Oshima:209:501952", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:d05ae6", "lonsrc": "T_Oshima:209:f4b02b", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:8b94d7", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:7a832e", "customdatasrc": "T_Oshima:209:68a5af", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前4万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:e3c43d", "lonsrc": "T_Oshima:209:abe081", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:dcf0f1", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:042407", "customdatasrc": "T_Oshima:209:213645", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:5ef9af", "lonsrc": "T_Oshima:209:b6a1b7", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:37ccce", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:6e3f46", "customdatasrc": "T_Oshima:209:484009", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:2ed049", "lonsrc": "T_Oshima:209:c4ee30", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:17bcee", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:2ff7d2", "customdatasrc": "T_Oshima:209:e086c0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前3万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:768a94", "lonsrc": "T_Oshima:209:c79491", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:b0133f", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:5f78fb", "customdatasrc": "T_Oshima:209:f6afa0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:e6a075", "lonsrc": "T_Oshima:209:2a58e1", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:e79351", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:372b5d", "customdatasrc": "T_Oshima:209:6c6181", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:1260b6", "lonsrc": "T_Oshima:209:43a04f", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:803a66", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:0ac24b", "customdatasrc": "T_Oshima:209:65bdf7", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前2万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:f507b8", "lonsrc": "T_Oshima:209:ecad0b", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:4c844a", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:ef87f6", "customdatasrc": "T_Oshima:209:5e4820", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:0f63c0", "lonsrc": "T_Oshima:209:a8071e", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:87f2b1", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:779e35", "customdatasrc": "T_Oshima:209:dc095e", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:a099e8", "lonsrc": "T_Oshima:209:bf4179", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:50f964", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:7d2996", "customdatasrc": "T_Oshima:209:f991af", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前1万年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:e1bfe4", "lonsrc": "T_Oshima:209:aa746a", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:486125", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:edeefe", "customdatasrc": "T_Oshima:209:b98149", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:7a2097", "lonsrc": "T_Oshima:209:9e1f24", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:819863", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:8fb1e0", "customdatasrc": "T_Oshima:209:8d99bd", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:47a70e", "lonsrc": "T_Oshima:209:a09eea", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:2a6320", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:a4da39", "customdatasrc": "T_Oshima:209:581875", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前8000年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:b0ee1e", "lonsrc": "T_Oshima:209:3480b5", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:af57b5", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:fde532", "customdatasrc": "T_Oshima:209:e5b0f0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:055d53", "lonsrc": "T_Oshima:209:dcba21", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:17954d", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:562dea", "customdatasrc": "T_Oshima:209:4b99c3", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:29811e", "lonsrc": "T_Oshima:209:0d4e68", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:fc8385", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:f66efd", "customdatasrc": "T_Oshima:209:4dca48", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前3100年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:169566", "lonsrc": "T_Oshima:209:f93834", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:741f3b", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:c488fd", "customdatasrc": "T_Oshima:209:2c8d57", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:28a587", "lonsrc": "T_Oshima:209:46c417", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:638c60", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:d6b37d", "customdatasrc": "T_Oshima:209:43e483", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:2248e4", "lonsrc": "T_Oshima:209:cbd13c", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:058de0", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:bda445", "customdatasrc": "T_Oshima:209:a2d563", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前1000年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:ec24d4", "lonsrc": "T_Oshima:209:02796d", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:ab3df3", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:cccd91", "customdatasrc": "T_Oshima:209:a54a44", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:afacdf", "lonsrc": "T_Oshima:209:3c9df6", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:8cec56", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:55f7a4", "customdatasrc": "T_Oshima:209:46c609", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:23d47d", "lonsrc": "T_Oshima:209:0b494d", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:bca236", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:22e009", "customdatasrc": "T_Oshima:209:8615d0", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前800年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:55611a", "lonsrc": "T_Oshima:209:839da9", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:15dada", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:218cf3", "customdatasrc": "T_Oshima:209:efe6e4", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:e1caaa", "lonsrc": "T_Oshima:209:87d225", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:e6951c", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:33dea1", "customdatasrc": "T_Oshima:209:a6191f", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:84389f", "lonsrc": "T_Oshima:209:10bbee", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:44de1b", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:130969", "customdatasrc": "T_Oshima:209:dc024d", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前600年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:ea8d92", "lonsrc": "T_Oshima:209:3cbb00", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:8015d7", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:fd64a5", "customdatasrc": "T_Oshima:209:a0fbb8", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:45c543", "lonsrc": "T_Oshima:209:f93639", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:71a9c2", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:777fe9", "customdatasrc": "T_Oshima:209:baf8af", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:352e45", "lonsrc": "T_Oshima:209:4f0991", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:319cd3", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:6fac83", "customdatasrc": "T_Oshima:209:3dc158", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前500年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:74c8ed", "lonsrc": "T_Oshima:209:1b6bb6", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:f2980c", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:bf6a18", "customdatasrc": "T_Oshima:209:d66386", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:9eb1e6", "lonsrc": "T_Oshima:209:7614b4", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:9a3824", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:bcaf2b", "customdatasrc": "T_Oshima:209:e6948e", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:c31277", "lonsrc": "T_Oshima:209:9a2bb3", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:77a7ea", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:fb4684", "customdatasrc": "T_Oshima:209:8dd6ed", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前400年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:142415", "lonsrc": "T_Oshima:209:515f83", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:42a54f", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:2b47fc", "customdatasrc": "T_Oshima:209:8cf8fb", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:8cb317", "lonsrc": "T_Oshima:209:2f8999", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:ef14b8", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:6b92ba", "customdatasrc": "T_Oshima:209:7fdd15", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:fbac4a", "lonsrc": "T_Oshima:209:823fb9", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:beb867", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:0e6b0f", "customdatasrc": "T_Oshima:209:216759", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前300年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:332c3d", "lonsrc": "T_Oshima:209:8848bd", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:f6d829", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:5b8c03", "customdatasrc": "T_Oshima:209:5f5c96", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:8607e9", "lonsrc": "T_Oshima:209:3111e7", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:fa2068", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:b8d3fe", "customdatasrc": "T_Oshima:209:3c371a", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:ebbd59", "lonsrc": "T_Oshima:209:4ad2ea", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:5e8861", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:b50f02", "customdatasrc": "T_Oshima:209:1788c1", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前200年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:3bf4e3", "lonsrc": "T_Oshima:209:9877d3", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:3fa251", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:849321", "customdatasrc": "T_Oshima:209:742546", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:34e4d5", "lonsrc": "T_Oshima:209:5ed554", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:420868", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:1d3171", "customdatasrc": "T_Oshima:209:03c0ec", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:fcabb2", "lonsrc": "T_Oshima:209:8ef027", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:134b6a", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:9c2b5c", "customdatasrc": "T_Oshima:209:3a237d", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前100年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:fd3670", "lonsrc": "T_Oshima:209:e69b51", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:91da50", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:7ad204", "customdatasrc": "T_Oshima:209:ba873c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:ecd923", "lonsrc": "T_Oshima:209:bf5a68", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:9f3c11", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:9bd655", "customdatasrc": "T_Oshima:209:baa4ab", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:dddebf", "lonsrc": "T_Oshima:209:75cd8e", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:678995", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:1ff477", "customdatasrc": "T_Oshima:209:270109", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "紀元前0年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:a7f5ce", "lonsrc": "T_Oshima:209:fcdac9", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:b4a3c7", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:8bca30", "customdatasrc": "T_Oshima:209:1e36ee", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:c20d35", "lonsrc": "T_Oshima:209:a8e2f3", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:883bac", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:05fa1e", "customdatasrc": "T_Oshima:209:6a3ea2", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:9cef58", "lonsrc": "T_Oshima:209:ef9035", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:fd34be", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:21fc7a", "customdatasrc": "T_Oshima:209:e3b090", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "0年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:aa0df6", "lonsrc": "T_Oshima:209:54ee4e", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:889e09", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:147039", "customdatasrc": "T_Oshima:209:9e21ee", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:39663a", "lonsrc": "T_Oshima:209:cb55ec", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:a11c1b", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:5a9cac", "customdatasrc": "T_Oshima:209:4ca083", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:b08151", "lonsrc": "T_Oshima:209:6d2b7d", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:dac380", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:9b8d8c", "customdatasrc": "T_Oshima:209:12da9b", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "100年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:4f5ea0", "lonsrc": "T_Oshima:209:ab67bf", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:b1ec84", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:952bce", "customdatasrc": "T_Oshima:209:bac512", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:032292", "lonsrc": "T_Oshima:209:76ab20", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:9b3da3", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:87dc30", "customdatasrc": "T_Oshima:209:5fe043", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:66de71", "lonsrc": "T_Oshima:209:7d118b", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:16cbe7", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:8d44db", "customdatasrc": "T_Oshima:209:f37d24", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "200年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:42e87f", "lonsrc": "T_Oshima:209:a2b2d9", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:96fc70", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:197944", "customdatasrc": "T_Oshima:209:076fd8", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:813152", "lonsrc": "T_Oshima:209:996a4a", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:cb4f87", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:637bfa", "customdatasrc": "T_Oshima:209:e9ba35", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:d98df0", "lonsrc": "T_Oshima:209:dfaaad", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:d4309a", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:e993ee", "customdatasrc": "T_Oshima:209:0758f4", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "300年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:28f3d6", "lonsrc": "T_Oshima:209:a932c5", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:5b7ebf", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:b6e24c", "customdatasrc": "T_Oshima:209:8a1f32", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:a1acf7", "lonsrc": "T_Oshima:209:00ec09", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:6914dc", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:efd6e5", "customdatasrc": "T_Oshima:209:02b086", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:22d944", "lonsrc": "T_Oshima:209:a2fdc3", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:5b71e6", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:a64dae", "customdatasrc": "T_Oshima:209:f77c09", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "500年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:f69195", "lonsrc": "T_Oshima:209:7f79cc", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:acae2a", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:8532f4", "customdatasrc": "T_Oshima:209:b0ea22", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:b9c01e", "lonsrc": "T_Oshima:209:b3dbec", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:61d274", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:970c57", "customdatasrc": "T_Oshima:209:33cd3d", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:fe0584", "lonsrc": "T_Oshima:209:adcd97", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:ac1462", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:474b1f", "customdatasrc": "T_Oshima:209:9ca90a", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "600年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:fac8f3", "lonsrc": "T_Oshima:209:3c5129", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:903cb3", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:557a53", "customdatasrc": "T_Oshima:209:31be92", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:2f1cd6", "lonsrc": "T_Oshima:209:499532", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:42a7e9", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:ee33e6", "customdatasrc": "T_Oshima:209:a31d1f", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:0a8724", "lonsrc": "T_Oshima:209:07de96", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:be4278", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:8be2ae", "customdatasrc": "T_Oshima:209:8eee03", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "700年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:44bf86", "lonsrc": "T_Oshima:209:f74e73", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:108b50", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:a5ee33", "customdatasrc": "T_Oshima:209:ca36ec", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:64b5c1", "lonsrc": "T_Oshima:209:979b05", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:c1da0f", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:2bed39", "customdatasrc": "T_Oshima:209:1508d9", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:e80075", "lonsrc": "T_Oshima:209:64fe21", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:ec5c8f", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:7b669c", "customdatasrc": "T_Oshima:209:5f6eb9", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "800年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:60bc30", "lonsrc": "T_Oshima:209:a42970", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:9e2c29", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:a3817c", "customdatasrc": "T_Oshima:209:7b94aa", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:c98efd", "lonsrc": "T_Oshima:209:7fb271", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:e38c9c", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:bda257", "customdatasrc": "T_Oshima:209:927075", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:d1a8b5", "lonsrc": "T_Oshima:209:d1014e", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:6c2e78", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:fcbe5e", "customdatasrc": "T_Oshima:209:a32072", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "900年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:cae8a4", "lonsrc": "T_Oshima:209:959025", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:e9ea5d", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:8ac921", "customdatasrc": "T_Oshima:209:7e8e3b", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:64aede", "lonsrc": "T_Oshima:209:331b4f", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:a360d2", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:87d25a", "customdatasrc": "T_Oshima:209:8ade59", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:8151fd", "lonsrc": "T_Oshima:209:c75d75", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:0f1536", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:806858", "customdatasrc": "T_Oshima:209:67fca9", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1100年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:5c4bc4", "lonsrc": "T_Oshima:209:77381f", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:e279c0", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:ec59bb", "customdatasrc": "T_Oshima:209:80c980", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:876dcb", "lonsrc": "T_Oshima:209:799825", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:689914", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:80fe34", "customdatasrc": "T_Oshima:209:dc33ff", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:f8f5b7", "lonsrc": "T_Oshima:209:3f67cc", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:e8f582", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:c8cb4a", "customdatasrc": "T_Oshima:209:4020ed", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1200年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:4ae4cc", "lonsrc": "T_Oshima:209:1a7992", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:82c24d", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:a994b3", "customdatasrc": "T_Oshima:209:211474", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:5ce37a", "lonsrc": "T_Oshima:209:6d6e7b", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:781072", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:866d81", "customdatasrc": "T_Oshima:209:21f779", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:2acf99", "lonsrc": "T_Oshima:209:543198", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:3b2c12", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:c7100e", "customdatasrc": "T_Oshima:209:54a4a4", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1300年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:a2a153", "lonsrc": "T_Oshima:209:7db74d", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:1ecaf1", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:009601", "customdatasrc": "T_Oshima:209:001a92", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:58f35f", "lonsrc": "T_Oshima:209:d377da", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:176ab3", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:4f2341", "customdatasrc": "T_Oshima:209:008bd1", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:d82462", "lonsrc": "T_Oshima:209:26278b", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:5726b6", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:de433b", "customdatasrc": "T_Oshima:209:7c8fe5", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1400年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:1ecdd4", "lonsrc": "T_Oshima:209:bb58fe", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:6876ad", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:85060c", "customdatasrc": "T_Oshima:209:9e3374", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:fce2d2", "lonsrc": "T_Oshima:209:ba0ed4", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:e8cf68", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:7e11eb", "customdatasrc": "T_Oshima:209:9f3926", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:b53390", "lonsrc": "T_Oshima:209:8ed403", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:e100c9", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:d356e1", "customdatasrc": "T_Oshima:209:6948b9", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1500年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:fe3f7d", "lonsrc": "T_Oshima:209:a38e67", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:abbd53", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:aa8141", "customdatasrc": "T_Oshima:209:4ba358", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:e5fa24", "lonsrc": "T_Oshima:209:13d38f", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:a9b15c", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:316d4a", "customdatasrc": "T_Oshima:209:732a72", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:f46da9", "lonsrc": "T_Oshima:209:84eeab", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:bfb508", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:2dc673", "customdatasrc": "T_Oshima:209:42ec7b", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1600年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:27fa32", "lonsrc": "T_Oshima:209:b783b0", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:f9c6da", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:a8e1b2", "customdatasrc": "T_Oshima:209:fb7638", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:55e524", "lonsrc": "T_Oshima:209:c11cad", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:d2c8b5", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:9a0f76", "customdatasrc": "T_Oshima:209:841080", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:af121f", "lonsrc": "T_Oshima:209:db84c9", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:39bae2", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:639cc8", "customdatasrc": "T_Oshima:209:b0992a", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1700年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:df69aa", "lonsrc": "T_Oshima:209:d463ed", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:709923", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:e100fb", "customdatasrc": "T_Oshima:209:dba717", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:ffc0ef", "lonsrc": "T_Oshima:209:bc3a62", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:f020e6", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:fcfca1", "customdatasrc": "T_Oshima:209:0c8e1b", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:e6089e", "lonsrc": "T_Oshima:209:ecd65d", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:0a3f73", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:210e3a", "customdatasrc": "T_Oshima:209:36f553", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1800年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:d093f3", "lonsrc": "T_Oshima:209:a3ea24", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:f5d271", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:2406a8", "customdatasrc": "T_Oshima:209:54afae", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:89bb17", "lonsrc": "T_Oshima:209:3539fd", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:80a825", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:be86e7", "customdatasrc": "T_Oshima:209:b08339", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:862ee5", "lonsrc": "T_Oshima:209:8de4c5", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:0445ed", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:fcd458", "customdatasrc": "T_Oshima:209:4a056c", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "1900年代" }, { "data": [ { "geo": "geo", "mode": "markers+text", "name": "01_出来事", "type": "scattergeo", "latsrc": "T_Oshima:209:5df428", "lonsrc": "T_Oshima:209:3798b5", "marker": { "color": "#636efa", "symbol": "circle" }, "textsrc": "T_Oshima:209:21bed4", "showlegend": true, "legendgroup": "01_出来事", "hovertextsrc": "T_Oshima:209:422548", "customdatasrc": "T_Oshima:209:102acf", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "02_概念", "type": "scattergeo", "latsrc": "T_Oshima:209:580705", "lonsrc": "T_Oshima:209:3d0185", "marker": { "color": "#EF553B", "symbol": "circle" }, "textsrc": "T_Oshima:209:21ab7f", "showlegend": true, "legendgroup": "02_概念", "hovertextsrc": "T_Oshima:209:bb471e", "customdatasrc": "T_Oshima:209:7b9ce8", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" }, { "geo": "geo", "mode": "markers+text", "name": "03_人物", "type": "scattergeo", "latsrc": "T_Oshima:209:c2332b", "lonsrc": "T_Oshima:209:e7a0df", "marker": { "color": "#00cc96", "symbol": "circle" }, "textsrc": "T_Oshima:209:cf4ac0", "showlegend": true, "legendgroup": "03_人物", "hovertextsrc": "T_Oshima:209:a01fb8", "customdatasrc": "T_Oshima:209:331267", "hovertemplate": "<b>%{hovertext}</b><br><br>カテゴリ=%{customdata[0]}<br>年代=%{customdata[16]}<br>内容=%{customdata[2]}<br>緯度=%{customdata[6]}<br>経度=%{customdata[7]}<br>ジャンル=%{customdata[1]}<br>開始年=%{customdata[3]}<br>終了年=%{customdata[4]}<br>メインエリア=%{customdata[5]}<br>説明=%{customdata[8]}<br>キーワード=%{customdata[9]}<br>相関関係=%{customdata[10]}<br>関係性=%{customdata[11]}<br>影響の対象=%{customdata[12]}<br>影響=%{customdata[13]}<br>影響の詳細=%{customdata[14]}<br>期間=%{customdata[15]}<extra></extra>" } ], "name": "2000年代" } ], "layout": { "geo": { "center": {}, "domain": { "x": [ 0.0, 1.0 ], "y": [ 0.0, 1.0 ] }, "showland": true, "lakecolor": "LightBlue", "landcolor": "honeydew", "showlakes": true, "showocean": true, "oceancolor": "LightBlue", "projection": { "type": "equirectangular" }, "resolution": 110, "rivercolor": "LightBlue", "showrivers": true }, "title": { "font": { "size": 20 }, "text": "歴史マップ" }, "legend": { "title": { "text": "カテゴリ" }, "tracegroupgap": 0 }, "margin": { "t": 60 }, "sliders": [ { "x": 0.1, "y": 0, "len": 0.9, "pad": { "b": 10, "t": 60 }, "steps": [ { "args": [ [ "紀元前700万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前700万年代", "method": "animate" }, { "args": [ [ "紀元前100万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前100万年代", "method": "animate" }, { "args": [ [ "紀元前50万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前50万年代", "method": "animate" }, { "args": [ [ "紀元前10万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前10万年代", "method": "animate" }, { "args": [ [ "紀元前5万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前5万年代", "method": "animate" }, { "args": [ [ "紀元前4万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前4万年代", "method": "animate" }, { "args": [ [ "紀元前3万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前3万年代", "method": "animate" }, { "args": [ [ "紀元前2万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前2万年代", "method": "animate" }, { "args": [ [ "紀元前1万年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前1万年代", "method": "animate" }, { "args": [ [ "紀元前8000年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前8000年代", "method": "animate" }, { "args": [ [ "紀元前3100年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前3100年代", "method": "animate" }, { "args": [ [ "紀元前1000年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前1000年代", "method": "animate" }, { "args": [ [ "紀元前800年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前800年代", "method": "animate" }, { "args": [ [ "紀元前600年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前600年代", "method": "animate" }, { "args": [ [ "紀元前500年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前500年代", "method": "animate" }, { "args": [ [ "紀元前400年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前400年代", "method": "animate" }, { "args": [ [ "紀元前300年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前300年代", "method": "animate" }, { "args": [ [ "紀元前200年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前200年代", "method": "animate" }, { "args": [ [ "紀元前100年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前100年代", "method": "animate" }, { "args": [ [ "紀元前0年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "紀元前0年代", "method": "animate" }, { "args": [ [ "0年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "0年代", "method": "animate" }, { "args": [ [ "100年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "100年代", "method": "animate" }, { "args": [ [ "200年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "200年代", "method": "animate" }, { "args": [ [ "300年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "300年代", "method": "animate" }, { "args": [ [ "500年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "500年代", "method": "animate" }, { "args": [ [ "600年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "600年代", "method": "animate" }, { "args": [ [ "700年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "700年代", "method": "animate" }, { "args": [ [ "800年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "800年代", "method": "animate" }, { "args": [ [ "900年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "900年代", "method": "animate" }, { "args": [ [ "1100年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1100年代", "method": "animate" }, { "args": [ [ "1200年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1200年代", "method": "animate" }, { "args": [ [ "1300年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1300年代", "method": "animate" }, { "args": [ [ "1400年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1400年代", "method": "animate" }, { "args": [ [ "1500年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1500年代", "method": "animate" }, { "args": [ [ "1600年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1600年代", "method": "animate" }, { "args": [ [ "1700年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1700年代", "method": "animate" }, { "args": [ [ "1800年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1800年代", "method": "animate" }, { "args": [ [ "1900年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "1900年代", "method": "animate" }, { "args": [ [ "2000年代" ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "2000年代", "method": "animate" } ], "active": 0, "xanchor": "left", "yanchor": "top", "currentvalue": { "prefix": "年代=" } } ], "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "updatemenus": [ { "x": 0.1, "y": 0, "pad": { "r": 10, "t": 70 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": true, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "▶", "method": "animate" }, { "args": [ [ null ], { "mode": "immediate", "frame": { "redraw": true, "duration": 0 }, "transition": { "easing": "linear", "duration": 0 }, "fromcurrent": true } ], "label": "◼", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "left", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~T_Oshima", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/97.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:43:36", "mapbox_access_tokens": null, "has_password": null, "username": "T_Oshima", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T05:35:33.884505Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~gwen.rounds/13.embed", "fid": "gwen.rounds:13", "filename": "Plot 13", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/gwen.rounds/13/9_UJIKUG7XJHJFVXAHCJSPKXUSFY16QP.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/gwen.rounds/13/2_GCE9N6KUAB0WXQQWR8PZXQ6Z212P7N.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/gwen.rounds/13/8_MZHINOHUZQ0Z1DTBJ49HNEMXV2L6NV.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/gwen.rounds/13/9_UJIKUG7XJHJFVXAHCJSPKXUSFY16QP.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/gwen.rounds:13", "plots": "https://api.plotly.com/v2/plots/gwen.rounds:13", "parent": "https://api.plotly.com/v2/folders/home?user=gwen.rounds" }, "owner": "gwen.rounds", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~gwen.rounds/13/", "world_readable": true, "date_modified": "2024-04-30T05:35:33.894Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~gwen.rounds/13/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Year", "y": "Glob" } }, "mode": "markers", "type": "bar", "xsrc": "gwen.rounds:12:64aae2", "ysrc": "gwen.rounds:12:fbad4c", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Southern Hemisphere Temperatures" }, "xaxis": { "type": "linear", "range": [ 1879.5, 2014.5 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -53.77777777777778, 81.77777777777777 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~gwen.rounds", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/57.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-6.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2022-04-28 05:12:48", "mapbox_access_tokens": null, "has_password": null, "username": "gwen.rounds", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T05:29:34.704181Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Kamikuz/6.embed", "fid": "Kamikuz:6", "filename": "Plot 6", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Kamikuz/6/9_8SJ6DOLGWH91D89E3CGJNUY4NZ30CN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Kamikuz/6/2_SJGV530PQ93TIAM7M2VP4Z6CHYKN6S.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Kamikuz/6/8_N6MWOWXXFQGUK5RT91ILU9R7QKYAK8.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Kamikuz/6/9_8SJ6DOLGWH91D89E3CGJNUY4NZ30CN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Kamikuz:6", "plots": "https://api.plotly.com/v2/plots/Kamikuz:6", "parent": "https://api.plotly.com/v2/folders/home?user=Kamikuz" }, "owner": "Kamikuz", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Kamikuz/6/", "world_readable": true, "date_modified": "2024-04-30T05:38:50.540Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Kamikuz/6/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "threads", "y": "time" } }, "mode": "markers+lines", "name": "Rust", "type": "scatter", "xsrc": "Kamikuz:2:250a6b", "ysrc": "Kamikuz:2:f5b9de" }, { "meta": { "columnNames": { "x": "threads", "y": "time" } }, "mode": "markers+lines", "name": "OpenMp", "type": "scatter", "xsrc": "Kamikuz:3:b8b5e7", "ysrc": "Kamikuz:3:2e1054", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "2048 x 2048 Matrix Runtime" }, "xaxis": { "type": "category", "range": [ -0.36641524414450183, 6.366415244144502 ], "title": { "text": "Threads #" }, "anchor": "y", "domain": [ 0, 1 ], "tickson": "labels", "autorange": true }, "yaxis": { "side": "left", "type": "linear", "range": [ -30.349963883955013, 453.06796388395503 ], "title": { "text": "Time(s)" }, "domain": [ 0, 1 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "uniformtext": { "mode": false } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Kamikuz", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/47.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:28:37", "mapbox_access_tokens": null, "has_password": null, "username": "Kamikuz", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T05:21:13.053613Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~sanketh97/1.embed", "fid": "sanketh97:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/sanketh97/1/9_NFAIW7YFWUSXPB4FLSUMTJO54FKC5F.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/sanketh97/1/2_VKX6OX2ADJ3V47R22SDRS3YMMTW0YD.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/sanketh97/1/8_D2OF0TVYZJVW7FRHKTA391HUSPHBPK.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/sanketh97/1/9_NFAIW7YFWUSXPB4FLSUMTJO54FKC5F.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/sanketh97:1", "plots": "https://api.plotly.com/v2/plots/sanketh97:1", "parent": "https://api.plotly.com/v2/folders/home?user=sanketh97" }, "owner": "sanketh97", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~sanketh97/1/", "world_readable": true, "date_modified": "2024-04-30T05:21:13.065Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~sanketh97/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "bar", "xsrc": "sanketh97:0:26bc71", "ysrc": "sanketh97:0:feb4eb", "marker": { "color": "rgb(14, 99, 229)" }, "opacity": 1, "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Number of 6 digit bins" }, "xaxis": { "side": "bottom", "type": "date", "range": [ "2023-09-16 12:00", "2024-04-15 12:00" ], "title": { "text": "Month" }, "domain": [ 0, 1 ], "autorange": true }, "yaxis": { "side": "left", "type": "linear", "range": [ 0, 392322.1052631579 ], "title": { "text": "Count" }, "domain": [ 0, 1 ], "autorange": true }, "bargap": 0.78, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~sanketh97", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:20:42", "mapbox_access_tokens": null, "has_password": null, "username": "sanketh97", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T05:10:31.339798Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~srinivasanpadmini/2.embed", "fid": "srinivasanpadmini:2", "filename": "Plot 2", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/srinivasanpadmini/2/9_L5ZB2WPX9MSJYZX52NE7APXJ4NBDA8.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/srinivasanpadmini/2/2_ZSH01Z37C0C846X0QRX3WGZWQM1NYG.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/srinivasanpadmini/2/8_SHKRX6IP15Q1ZVL9WNBKHAQRAESLTG.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/srinivasanpadmini/2/9_L5ZB2WPX9MSJYZX52NE7APXJ4NBDA8.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/srinivasanpadmini:2", "plots": "https://api.plotly.com/v2/plots/srinivasanpadmini:2", "parent": "https://api.plotly.com/v2/folders/home?user=srinivasanpadmini" }, "owner": "srinivasanpadmini", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~srinivasanpadmini/2/", "world_readable": true, "date_modified": "2024-04-30T05:13:47.497Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~srinivasanpadmini/2/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "bar", "orientation": "v" }, { "meta": { "columnNames": { "x": "Lead Name - Course - Lead source - Place - State" } }, "mode": "markers", "type": "bar", "xsrc": "srinivasanpadmini:0:b257c2,a700ed,a6534e,83dea2,b024df*", "xaxis": "x2", "yaxis": "y2", "orientation": "v" } ], "frames": [], "layout": { "xaxis": { "type": "multicategory", "range": [ -7.666666666666667, 145.66666666666666 ], "autorange": true }, "yaxis": { "range": [ -0.5, 138.5 ], "autorange": true }, "xaxis2": { "side": "top", "type": "multicategory", "range": [ -0.5, 138.5 ], "autorange": true, "overlaying": "x" }, "yaxis2": { "side": "right", "range": [ 0, 145.26315789473685 ], "autorange": true, "overlaying": "y" }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~srinivasanpadmini", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 05:07:59", "mapbox_access_tokens": null, "has_password": null, "username": "srinivasanpadmini", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T03:53:27.701229Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~vishnuvinod/3.embed", "fid": "vishnuvinod:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/vishnuvinod/3/9_9HTRZWXKHH68YGF7GPKYX1AVF479IY.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/vishnuvinod/3/2_H8U7VSAXH122VHGOO0J4C71LOXDHRZ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/vishnuvinod/3/8_N33KH6OH8018AYAEQFOGL1JGSDGSE4.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/vishnuvinod/3/9_9HTRZWXKHH68YGF7GPKYX1AVF479IY.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/vishnuvinod:3", "plots": "https://api.plotly.com/v2/plots/vishnuvinod:3", "parent": "https://api.plotly.com/v2/folders/home?user=vishnuvinod" }, "owner": "vishnuvinod", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~vishnuvinod/3/", "world_readable": true, "date_modified": "2024-04-30T03:53:27.713Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~vishnuvinod/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "D - F", "y": "A - B - C" } }, "mode": "markers", "type": "scatter", "xsrc": "vishnuvinod:2:673f9a,9fde71*", "ysrc": "vishnuvinod:2:5f4621,bfc910,35758a*" } ], "frames": [], "layout": { "xaxis": { "type": "multicategory", "range": [ -3.9246954595791808, 67.92469545957918 ], "autorange": true }, "yaxis": { "type": "multicategory", "range": [ -5.2004801920768315, 77.20048019207684 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "annotations": [] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~vishnuvinod", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/22.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 03:03:46", "mapbox_access_tokens": null, "has_password": null, "username": "vishnuvinod", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-30T03:51:08.474486Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Celestaros/1.embed", "fid": "Celestaros:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Celestaros/1/9_AAMLNFYTNSZCZT9FO34UY98X8H9NCD.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Celestaros/1/2_PMEPZBJ5VI94QGQ941CY7YJOA891TP.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Celestaros/1/8_9STQXZM6JZBJKFBM6RE3ETDFV51ZQ7.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Celestaros/1/9_AAMLNFYTNSZCZT9FO34UY98X8H9NCD.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Celestaros:1", "plots": "https://api.plotly.com/v2/plots/Celestaros:1", "parent": "https://api.plotly.com/v2/folders/home?user=Celestaros" }, "owner": "Celestaros", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Celestaros/1/", "world_readable": true, "date_modified": "2024-04-30T03:51:08.488Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Celestaros/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "B", "low": "Low", "high": "High", "open": "Open", "close": "Price" } }, "mode": "markers", "type": "candlestick", "xsrc": "Celestaros:0:d54916", "lowsrc": "Celestaros:0:35b12d", "highsrc": "Celestaros:0:ae25a6", "opensrc": "Celestaros:0:b10c2d", "closesrc": "Celestaros:0:ab1076" } ], "frames": [], "layout": { "xaxis": { "type": "date", "range": [ "2014-01-01 12:00", "2024-01-01 12:00" ], "autorange": true, "rangeslider": { "range": [ "2014-01-01 12:00", "2024-01-01 12:00" ], "yaxis": { "rangemode": "match" }, "autorange": true } }, "yaxis": { "range": [ 983.9055555555557, 2213.7944444444447 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Celestaros", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/91.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-30 03:50:40", "mapbox_access_tokens": null, "has_password": null, "username": "Celestaros", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
