Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cj0xJnA9MjAyNC0wNC0yOCsxOCUzQTUzJTNBMTIuNjkzMjA2JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI0LTA0LTI4KzE4JTNBNTMlM0EyMS41OTgzODklMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNC0wNC0yOCsxOSUzQTQzJTNBMDguNzQyNjI4JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2024-04-28T19:43:08.742628Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~hlockwooddesign/32.embed", "fid": "hlockwooddesign:32", "filename": "plot from API (13)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/32/9_K2RSC1JDLR7PWNRV6Y5AXTKOJK4YR3.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/32/2_XCZ14VDP4N2ZFE1IJLJA0DMPYFGZY4.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/32/8_LP3UQL0WZQE66FPRZPUNL7VQWD9YZF.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/32/9_K2RSC1JDLR7PWNRV6Y5AXTKOJK4YR3.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/hlockwooddesign:32", "plots": "https://api.plotly.com/v2/plots/hlockwooddesign:32", "parent": "https://api.plotly.com/v2/folders/home?user=hlockwooddesign" }, "owner": "hlockwooddesign", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~hlockwooddesign/32/", "world_readable": true, "date_modified": "2024-04-28T19:43:09.046Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~hlockwooddesign/32/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "xsrc": "hlockwooddesign:33:9f2076", "ysrc": "hlockwooddesign:33:90d214", "marker": { "sizesrc": "hlockwooddesign:33:f29454" } } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~hlockwooddesign", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/6.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-28 15:09:48", "mapbox_access_tokens": null, "has_password": null, "username": "hlockwooddesign", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:41:56.185035Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~hlockwooddesign/30.embed", "fid": "hlockwooddesign:30", "filename": "plot from API (12)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/30/9_W21DUO7DNHQ5MQTO0WX7DG21LEO3IO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/30/2_JUAMWARO60AHN3XX1WHM6RP5H02RUP.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/30/8_NCWB0B369QG5EGF9WS7Y3VU73UTROG.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/hlockwooddesign/30/9_W21DUO7DNHQ5MQTO0WX7DG21LEO3IO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/hlockwooddesign:30", "plots": "https://api.plotly.com/v2/plots/hlockwooddesign:30", "parent": "https://api.plotly.com/v2/folders/home?user=hlockwooddesign" }, "owner": "hlockwooddesign", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~hlockwooddesign/30/", "world_readable": true, "date_modified": "2024-04-28T19:41:56.497Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~hlockwooddesign/30/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "xsrc": "hlockwooddesign:31:dee1c2", "ysrc": "hlockwooddesign:31:48de2b", "marker": { "sizesrc": "hlockwooddesign:31:25f1d0" } } ], "layout": {} }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~hlockwooddesign", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/6.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-28 15:09:48", "mapbox_access_tokens": null, "has_password": null, "username": "hlockwooddesign", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:40:52.901964Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~DOGUINHA1/9.embed", "fid": "DOGUINHA1:9", "filename": "Plot 9", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/9/9_EHZ11YE856ED2C3Y4KZ7HP5R9ICV6C.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/9/2_QJBFTZHHEMXQRR48FEIYOBGHPDW8PX.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/9/8_7OJMEYTEWTZRCI2PM1TEXFIF35EX8N.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/9/9_EHZ11YE856ED2C3Y4KZ7HP5R9ICV6C.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/DOGUINHA1:9", "plots": "https://api.plotly.com/v2/plots/DOGUINHA1:9", "parent": "https://api.plotly.com/v2/folders/home?user=DOGUINHA1" }, "owner": "DOGUINHA1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~DOGUINHA1/9/", "world_readable": true, "date_modified": "2024-04-28T19:40:52.915Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~DOGUINHA1/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Total" } }, "mode": "lines", "name": "ATIVOS", "type": "scatter", "xsrc": "DOGUINHA1:8:cdf51b", "ysrc": "DOGUINHA1:8:964706" }, { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Circulante" } }, "mode": "lines", "name": "ATIVOS", "type": "scatter", "xsrc": "DOGUINHA1:8:cdf51b", "ysrc": "DOGUINHA1:8:34b74a", "stackgroup": null }, { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Não Circulante" } }, "mode": "lines", "name": "ATIVOS", "type": "scatter", "xsrc": "DOGUINHA1:8:cdf51b", "ysrc": "DOGUINHA1:8:f8c3d6", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "EMPRESA X.S.A" }, "xaxis": { "type": "linear", "range": [ 2001, 2021 ], "title": { "text": "ANO" }, "autorange": true }, "yaxis": { "range": [ -786481.7222222222, 18878932.722222224 ], "title": { "text": "ATIVO" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~DOGUINHA1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-10 23:31:26", "mapbox_access_tokens": null, "has_password": null, "username": "DOGUINHA1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:40:13.495705Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Farouk/3.embed", "fid": "Farouk:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Farouk/3/9_NTJGJN47W1W3ELMZR085QVR08OJQGV.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Farouk/3/2_15DWVR4W91NMT8ROPJJEHSFWSENRHU.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Farouk/3/8_UGPAA41C1FQZ73E2I5LPAGQVI8WIA3.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Farouk/3/9_NTJGJN47W1W3ELMZR085QVR08OJQGV.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Farouk:3", "plots": "https://api.plotly.com/v2/plots/Farouk:3", "parent": "https://api.plotly.com/v2/folders/home?user=Farouk" }, "owner": "Farouk", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Farouk/3/", "world_readable": true, "date_modified": "2024-04-28T19:44:04.876Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Farouk/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "ecb360", "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Summer", "type": "scatter", "xsrc": "Farouk:2:b91e7a", "ysrc": "Farouk:2:2eaf41" }, { "uid": "a234bb", "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers", "name": "Winter", "type": "scatter", "xsrc": "Farouk:2:ccf401", "ysrc": "Farouk:2:d862e6", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Temperature scatter graph" }, "xaxis": { "type": "linear", "range": [ 0, 9 ], "title": { "font": { "family": "Balto" }, "text": "Sample Spots" }, "autorange": false }, "yaxis": { "type": "linear", "range": [ 1.008606378331149, 9.59139362166885 ], "title": { "text": "Temperature (°C )" }, "autorange": true }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Farouk", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/16.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-28 19:27:49", "mapbox_access_tokens": null, "has_password": null, "username": "Farouk", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:28:28.256674Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Farouk/1.embed", "fid": "Farouk:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Farouk/1/9_WTAVR90KGXTCDI2V178YBF02RTM2QH.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Farouk/1/2_MJ2XQQWUVY4S4ZROI0F4WVUE3WWAGP.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Farouk/1/8_G72C57YPHV4DONWU1E9R6GFLNDTTYC.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Farouk/1/9_WTAVR90KGXTCDI2V178YBF02RTM2QH.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Farouk:1", "plots": "https://api.plotly.com/v2/plots/Farouk:1", "parent": "https://api.plotly.com/v2/folders/home?user=Farouk" }, "owner": "Farouk", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Farouk/1/", "world_readable": true, "date_modified": "2024-04-28T19:47:30.617Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Farouk/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "4247bc", "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Sumer ", "type": "scatter", "xsrc": "Farouk:0:90c0ef", "ysrc": "Farouk:0:53212e", "visible": true, "autocolorscale": true }, { "uid": "dbf7c8", "meta": { "columnNames": { "x": "C", "y": "D" } }, "mode": "markers", "name": "Winter ", "type": "scatter", "xsrc": "Farouk:0:3291c4", "ysrc": "Farouk:0:78ad3f", "stackgroup": null }, { "uid": "726c54", "transforms": [ { "rms": "", "type": "fit", "inputUid": "4247bc", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.00579473788453449, "value": 0.035952380952354666 }, { "hold": false, "name": "b", "error": 0.029261991940664523, "value": 6.180714285714404 } ], "regressand": "y", "correlation": "", "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] }, { "uid": "37a4dd", "transforms": [ { "rms": "", "type": "fit", "inputUid": "dbf7c8", "regressor": "x", "parameters": [ { "hold": false, "name": "m", "error": 0.02175033991618636, "value": -0.07702380952387818 }, { "hold": false, "name": "b", "error": 0.10983383269729707, "value": 6.770357142857456 } ], "regressand": "y", "correlation": "", "fitfunction": "m*x + b", "inputxrange": [], "outputxrange": [], "interpolation": 50 } ] } ], "frames": [], "layout": { "font": { "family": "Balto" }, "title": { "text": "pH Scatter Graph" }, "xaxis": { "type": "linear", "range": [ 0.579728857327308, 8.420271142672693 ], "title": { "text": "Sample Spots" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 5.981507208387942, 6.828492791612058 ], "title": { "text": "pH " }, "autorange": true }, "legend": { "x": 1.02, "y": 1 }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Farouk", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/16.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-28 19:27:49", "mapbox_access_tokens": null, "has_password": null, "username": "Farouk", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:15:17.840991Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~DOGUINHA1/7.embed", "fid": "DOGUINHA1:7", "filename": "Plot 7", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/7/9_CLPSQ1YJP8XKULJX3S6HWY842K7OJN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/7/2_TTIXAE2VWNLIPGDT0G54HLGZ1PRQF3.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/7/8_6DF7LYBF7Q4CYOP6O7QUS9O5Y3GR38.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/DOGUINHA1/7/9_CLPSQ1YJP8XKULJX3S6HWY842K7OJN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/DOGUINHA1:7", "plots": "https://api.plotly.com/v2/plots/DOGUINHA1:7", "parent": "https://api.plotly.com/v2/folders/home?user=DOGUINHA1" }, "owner": "DOGUINHA1", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~DOGUINHA1/7/", "world_readable": true, "date_modified": "2024-04-28T19:21:23.165Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~DOGUINHA1/7/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Total" } }, "mode": "markers", "name": "ATIVOS", "type": "bar", "xsrc": "DOGUINHA1:6:5e9656", "ysrc": "DOGUINHA1:6:c48fae", "orientation": "v" }, { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Circulante" } }, "name": "ATIVOS", "type": "bar", "xsrc": "DOGUINHA1:6:5e9656", "ysrc": "DOGUINHA1:6:f31e7f", "orientation": "v" }, { "meta": { "columnNames": { "x": "Ano", "y": "Ativo Não Circulante" } }, "name": "ATIVOS", "type": "bar", "xsrc": "DOGUINHA1:6:5e9656", "ysrc": "DOGUINHA1:6:0086d3", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "EMPRESA X.S.A" }, "xaxis": { "type": "linear", "range": [ 2000.5, 2021.5 ], "title": { "text": "ANO" }, "autorange": true }, "yaxis": { "range": [ 0, 18837538.94736842 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~DOGUINHA1", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/27.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-10 23:31:26", "mapbox_access_tokens": null, "has_password": null, "username": "DOGUINHA1", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T19:13:37.829740Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~monmikova95/15.embed", "fid": "monmikova95:15", "filename": "SDNN survivors", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/monmikova95:15/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/monmikova95:15/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/monmikova95/15/8_UNOZ1VO8ZJETGECO36K9OZOHCUKGA6.png", "list-thumb": "https://api.plotly.com/v2/files/monmikova95:15/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/monmikova95:15", "plots": "https://api.plotly.com/v2/plots/monmikova95:15", "parent": "https://api.plotly.com/v2/folders/home?user=monmikova95" }, "owner": "monmikova95", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~monmikova95/15/", "world_readable": true, "date_modified": "2024-06-17T09:58:22.182Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~monmikova95/15/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "poradi1", "y": "SDNN1", "marker": { "size": "pocet1" }, "error_y": { "array": "mean1" } } }, "mode": "markers", "name": "CHF patients - survivors", "type": "scatter", "xsrc": "monmikova95:13:4accf5", "ysrc": "monmikova95:13:83f15e", "marker": { "line": { "color": "rgb(0, 0, 250)" }, "meta": { "columnNames": { "size": "pocet1" } }, "color": "rgb(0, 0, 250)", "sizeref": 2, "sizesrc": "monmikova95:13:1505ff", "sizemode": "area" }, "error_y": { "meta": { "columnNames": { "array": "mean1" } }, "type": "data", "color": "rgb(0, 0, 0)", "value": 10, "width": 4, "visible": true, "arraysrc": "monmikova95:13:7ab2db", "symmetric": true, "thickness": 2, "valueminus": 10 } }, { "meta": { "columnNames": { "x": "poradi2", "y": "SDNN2", "marker": { "size": "pocet2" }, "error_y": { "array": "error+", "arrayminus": "error-" } } }, "mode": "markers", "name": "trace 1", "type": "scatter", "xsrc": "monmikova95:13:3fc318", "ysrc": "monmikova95:13:cce720", "marker": { "meta": { "columnNames": { "size": "pocet2" } }, "color": "rgb(0, 0, 250)", "sizeref": null, "sizesrc": "monmikova95:13:a64081", "sizemode": "area" }, "error_x": { "type": "percent", "color": "#EF553B", "value": 10, "width": 4, "visible": false, "symmetric": false, "thickness": 2, "valueminus": 10 }, "error_y": { "meta": { "columnNames": { "array": "error+", "arrayminus": "error-" } }, "type": "data", "color": "rgb(0, 0, 0)", "width": 4, "visible": true, "arraysrc": "monmikova95:13:472440", "traceref": 0, "symmetric": false, "thickness": 2, "arrayminussrc": "monmikova95:13:0b74b3" }, "showlegend": false, "stackgroup": null }, { "meta": { "columnNames": { "x": "poradiC", "y": "SDNNC", "marker": { "size": "pocetC" }, "error_y": { "array": "meanC" } } }, "mode": "markers", "name": "CHF patients - nonsurvivors", "type": "scatter", "xsrc": "monmikova95:13:83d429", "ysrc": "monmikova95:13:3097aa", "marker": { "meta": { "columnNames": { "size": "pocetC" } }, "color": "rgb(0, 255, 0)", "sizeref": 2, "sizesrc": "monmikova95:13:3bd4f5", "sizemode": "area" }, "error_y": { "meta": { "columnNames": { "array": "meanC" } }, "type": "data", "color": "rgb(0, 0, 0)", "visible": true, "arraysrc": "monmikova95:13:c3efef", "symmetric": true }, "hoverinfo": "x+y+name", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "type": "linear", "range": [ -0.03250357802608206, 18.21120610052796 ], "title": { "font": { "size": 15 } }, "domain": [ 0, 0.75 ], "tickfont": { "size": 16 }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -12.700000000000005, 233.3 ], "title": { "font": { "size": 20 }, "text": "SDNN mean + SD" }, "domain": [ 0, 1 ], "tickfont": { "size": 16 }, "autorange": true }, "legend": { "x": 0.09107096574105875, "y": 1.2916666666666667, "font": { "size": 20 } }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~monmikova95", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2023-04-24 21:32:33", "mapbox_access_tokens": null, "has_password": null, "username": "monmikova95", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T18:59:17.798851Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~onegafer/1.embed", "fid": "onegafer:1", "filename": "tfg-attribute-queries", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/onegafer/1/9_CTITN9AG0IH2PGIL1I7ZZN0OKH6RGI.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/onegafer/1/2_OEO2LQ99H95EESMZUAMVGSWM74CU00.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/onegafer/1/8_MMPHAXB4SEVR29Z442ODRX4MRPCASF.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/onegafer/1/9_CTITN9AG0IH2PGIL1I7ZZN0OKH6RGI.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/onegafer:1", "plots": "https://api.plotly.com/v2/plots/onegafer:1", "parent": "https://api.plotly.com/v2/folders/home?user=onegafer" }, "owner": "onegafer", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~onegafer/1/", "world_readable": true, "date_modified": "2024-04-28T19:06:02.339Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~onegafer/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "fill": "none", "meta": { "columnNames": { "x": "E", "y": "Extended" } }, "mode": "markers+lines", "name": "Extended", "type": "scatter", "xsrc": "onegafer:0:89d263", "ysrc": "onegafer:0:db0356", "marker": { "line": { "width": 3 }, "size": 14, "color": "rgb(47, 83, 185)", "symbol": "square-open" }, "hoverinfo": "x+y", "hovertemplate": "" }, { "fill": "none", "meta": { "columnNames": { "x": "E", "y": "Pools" } }, "mode": "markers+lines", "name": "Pools", "type": "scatter", "xsrc": "onegafer:0:89d263", "ysrc": "onegafer:0:d1c8fb", "marker": { "line": { "width": 3 }, "size": 14, "color": "rgb(34, 175, 239)", "symbol": "square-open" }, "stackgroup": null }, { "fill": "none", "meta": { "columnNames": { "x": "E", "y": "House Type" } }, "mode": "markers+lines", "name": "House Type", "type": "scatter", "xsrc": "onegafer:0:89d263", "ysrc": "onegafer:0:ddef52", "marker": { "line": { "width": 3 }, "size": 14, "symbol": "square-open" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "" }, "xaxis": { "side": "bottom", "type": "category", "range": [ -0.1296632000763287, 2.1296632000763287 ], "ticks": "", "title": { "font": { "size": 19 }, "text": "<br>" }, "tickson": "labels", "showgrid": true, "tickfont": { "size": 34, "color": "rgb(0, 0, 0)", "family": "Times New Roman" }, "autorange": false, "tickcolor": "rgb(68, 68, 68)", "automargin": false, "rangeslider": { "range": [ -0.1296632000763287, 2.1296632000763287 ], "yaxis": {}, "visible": false, "autorange": true }, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ -0.1, 0.8340942928039703 ], "title": { "font": { "size": 33, "color": "rgb(0, 0, 0)", "family": "Times New Roman" }, "text": "aNDCG" }, "tickfont": { "size": 29, "color": "rgb(0, 0, 0)", "family": "Times New Roman" }, "autorange": false }, "legend": { "font": { "size": 24, "color": "rgb(0, 0, 0)", "family": "Times New Roman" } }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~onegafer", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/72.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-28 18:58:28", "mapbox_access_tokens": null, "has_password": null, "username": "onegafer", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T18:57:33.542469Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~invictus.8497/13.embed", "fid": "invictus.8497:13", "filename": "Peak pressure", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/invictus.8497/13/9_0TQ4928S7S6PK2I47XLE6RX5VNH8Z3.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/invictus.8497/13/2_80MN0G1MBT2HTF53Z9QMLF125Q4IEO.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/invictus.8497/13/8_V8C4GY1GJUCR8P9WDH9QYJ77ZKCF7K.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/invictus.8497/13/9_0TQ4928S7S6PK2I47XLE6RX5VNH8Z3.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/invictus.8497:13", "plots": "https://api.plotly.com/v2/plots/invictus.8497:13", "parent": "https://api.plotly.com/v2/folders/home?user=invictus.8497" }, "owner": "invictus.8497", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~invictus.8497/13/", "world_readable": true, "date_modified": "2024-04-29T15:59:22.805Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~invictus.8497/13/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(0, 0, 0)", "shape": "spline", "smoothing": 1.3 }, "meta": { "columnNames": { "x": "A", "y": "M" } }, "mode": "lines", "name": "<b>H18CNG82</b>", "type": "scatter", "xsrc": "invictus.8497:12:887b4a", "ysrc": "invictus.8497:12:e40fc8", "stackgroup": null }, { "line": { "shape": "spline", "smoothing": 1.3 }, "meta": { "columnNames": { "x": "A", "y": "J" } }, "mode": "lines", "name": "<b>H10CNG90</b>", "type": "scatter", "xsrc": "invictus.8497:12:887b4a", "ysrc": "invictus.8497:12:39b6b1", "stackgroup": null }, { "line": { "dash": "dot", "shape": "spline", "width": 5, "smoothing": 1.3 }, "meta": { "columnNames": { "x": "A", "y": "G" } }, "mode": "lines", "name": "<b>H5CNG95</b>", "type": "scatter", "xsrc": "invictus.8497:12:887b4a", "ysrc": "invictus.8497:12:680fbd", "stackgroup": null }, { "line": { "shape": "spline", "width": 2, "smoothing": 1.3 }, "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "lines", "name": "<b>CNG</b>", "type": "scatter", "xsrc": "invictus.8497:12:887b4a", "ysrc": "invictus.8497:12:295b09" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 991.2600334251348, 5691.260033425135 ], "ticks": "outside", "title": { "text": "<b>Speed ( RPM )</b>" }, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "yaxis": { "type": "linear", "range": [ 11.628895313588858, 73.65854515924536 ], "ticks": "outside", "title": { "text": "<b>Peak Pressure ( bar )</b>" }, "showgrid": false, "showline": true, "zeroline": false, "autorange": false }, "legend": { "x": 0.7114819086676065, "y": 0.21 }, "autosize": true, "dragmode": "pan" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~invictus.8497", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/36.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-27 14:03:44", "mapbox_access_tokens": null, "has_password": null, "username": "invictus.8497", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2024-04-28T18:53:21.598389Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~monmikova95/14.embed", "fid": "monmikova95:14", "filename": "SDNN new copy", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/monmikova95/14/9_HKDCPUG4H2S666ZE91JNP1ED192947.png", "image_urls": { "default": "https://api.plotly.com/v2/files/monmikova95:14/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/monmikova95/14/8_D6KSFSX7TEDZ62Q9WLNAH7MJJM5HLC.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/monmikova95/14/9_HKDCPUG4H2S666ZE91JNP1ED192947.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/monmikova95:14", "plots": "https://api.plotly.com/v2/plots/monmikova95:14", "parent": "https://api.plotly.com/v2/folders/home?user=monmikova95" }, "owner": "monmikova95", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~monmikova95/14/", "world_readable": true, "date_modified": "2024-06-17T09:58:22.182Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~monmikova95/14/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "poradi1", "y": "SDNN1", "marker": { "size": "pocet1" }, "error_y": { "array": "mean1" } } }, "mode": "markers", "name": "CHF patients", "type": "scatter", "xsrc": "monmikova95:13:4accf5", "ysrc": "monmikova95:13:83f15e", "marker": { "line": { "color": "rgb(0, 0, 250)" }, "meta": { "columnNames": { "size": "pocet1" } }, "color": "rgb(0, 0, 250)", "sizeref": 2, "sizesrc": "monmikova95:13:1505ff", "sizemode": "area" }, "error_y": { "meta": { "columnNames": { "array": "mean1" } }, "type": "data", "color": "rgb(0, 0, 0)", "value": 10, "width": 4, "visible": true, "arraysrc": "monmikova95:13:7ab2db", "symmetric": true, "thickness": 2, "valueminus": 10 } }, { "meta": { "columnNames": { "x": "poradi2", "y": "SDNN2", "marker": { "size": "pocet2" }, "error_y": { "array": "error+", "arrayminus": "error-" } } }, "mode": "markers", "name": "trace 1", "type": "scatter", "xsrc": "monmikova95:13:3fc318", "ysrc": "monmikova95:13:cce720", "marker": { "meta": { "columnNames": { "size": "pocet2" } }, "color": "rgb(0, 0, 250)", "sizeref": null, "sizesrc": "monmikova95:13:a64081", "sizemode": "area" }, "error_x": { "type": "percent", "color": "#EF553B", "value": 10, "width": 4, "visible": false, "symmetric": false, "thickness": 2, "valueminus": 10 }, "error_y": { "meta": { "columnNames": { "array": "error+", "arrayminus": "error-" } }, "type": "data", "color": "rgb(0, 0, 0)", "width": 4, "visible": true, "arraysrc": "monmikova95:13:472440", "traceref": 0, "symmetric": false, "thickness": 2, "arrayminussrc": "monmikova95:13:0b74b3" }, "showlegend": false, "stackgroup": null }, { "meta": { "columnNames": { "x": "poradiC", "y": "SDNNC", "marker": { "size": "pocetC" }, "error_y": { "array": "meanC" } } }, "mode": "markers", "name": "controls", "type": "scatter", "xsrc": "monmikova95:13:83d429", "ysrc": "monmikova95:13:3097aa", "marker": { "meta": { "columnNames": { "size": "pocetC" } }, "color": "rgb(0, 255, 0)", "sizeref": 2, "sizesrc": "monmikova95:13:3bd4f5", "sizemode": "area" }, "error_y": { "meta": { "columnNames": { "array": "meanC" } }, "type": "data", "color": "rgb(0, 0, 0)", "visible": true, "arraysrc": "monmikova95:13:c3efef", "symmetric": true }, "hoverinfo": "x+y+name", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "type": "linear", "range": [ -3.657270029673591, 78.6572700296736 ], "title": { "font": { "size": 15 } }, "domain": [ 0, 0.75 ], "tickfont": { "size": 16 }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 8.166666666666663, 264.8333333333333 ], "title": { "font": { "size": 20 }, "text": "SDNN mean + SD" }, "domain": [ 0, 1 ], "tickfont": { "size": 16 }, "autorange": true }, "legend": { "x": 0.04554744525547453, "y": 1.1666666666666667, "font": { "size": 20 } }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~monmikova95", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2023-04-24 21:32:33", "mapbox_access_tokens": null, "has_password": null, "username": "monmikova95", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
