Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cD0yMDI1LTA2LTI0KzEyJTNBMTglM0E0NS4xOTAwMzclMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI1LTA2LTI0KzExJTNBMTYlM0EyNC4zNjc0MjklMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNS0wNi0yNCsxMiUzQTE3JTNBMjIuODEyNDk0JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-06-24T12:17:22.812494Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fiz_01/10.embed", "fid": "fiz_01:10", "filename": "Plotly Playground 2025-06-24 18:17:17", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/fiz_01:10/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/fiz_01/10/2_SA01MIZ0FP30ARTDK1GTUCK0TRTT6E.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/10/8_8SRCB67DJ8DK2CNE0K8XXSKEFUI32V.png", "list-thumb": "https://api.plotly.com/v2/files/fiz_01:10/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fiz_01:10", "plots": "https://api.plotly.com/v2/plots/fiz_01:10", "parent": "https://api.plotly.com/v2/folders/home?user=fiz_01" }, "owner": "fiz_01", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~fiz_01/10/", "world_readable": true, "date_modified": "2025-06-24T12:17:22.823Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fiz_01/10/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "sepal_length", "type": "histogram", "xsrc": "fiz_01:9:4102f9", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(255, 153, 51, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:6f1144", "ysrc": "fiz_01:9:690f84", "xaxis": "x2", "yaxis": "y2", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:cf4a55", "ysrc": "fiz_01:9:386a13", "xaxis": "x3", "yaxis": "y3", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:c81a04", "ysrc": "fiz_01:9:dda3f8", "xaxis": "x4", "yaxis": "y4", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:b44509", "ysrc": "fiz_01:9:06c4a5", "xaxis": "x5", "yaxis": "y5", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:012d89", "ysrc": "fiz_01:9:339355", "xaxis": "x6", "yaxis": "y6", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:252333", "ysrc": "fiz_01:9:a3cf20", "xaxis": "x7", "yaxis": "y7", "marker": { "size": 2, "symbol": "circle" } }, { "name": "sepal_width", "type": "histogram", "xsrc": "fiz_01:9:56063b", "xaxis": "x8", "yaxis": "y8", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(55, 128, 191, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:07a394", "ysrc": "fiz_01:9:d9669c", "xaxis": "x9", "yaxis": "y9", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:14fe3a", "ysrc": "fiz_01:9:cbb6e3", "xaxis": "x10", "yaxis": "y10", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:a4f2e3", "ysrc": "fiz_01:9:ba602e", "xaxis": "x11", "yaxis": "y11", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:052705", "ysrc": "fiz_01:9:5ae794", "xaxis": "x12", "yaxis": "y12", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:ed49ab", "ysrc": "fiz_01:9:a1e7f6", "xaxis": "x13", "yaxis": "y13", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:1ddee1", "ysrc": "fiz_01:9:d06be5", "xaxis": "x14", "yaxis": "y14", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_length", "type": "histogram", "xsrc": "fiz_01:9:48a8f6", "xaxis": "x15", "yaxis": "y15", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(50, 171, 96, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:6e950c", "ysrc": "fiz_01:9:aa270b", "xaxis": "x16", "yaxis": "y16", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:86d190", "ysrc": "fiz_01:9:a19469", "xaxis": "x17", "yaxis": "y17", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:9:0f4db0", "ysrc": "fiz_01:9:e68268", "xaxis": "x18", "yaxis": "y18", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:ffa062", "ysrc": "fiz_01:9:0c3338", "xaxis": "x19", "yaxis": "y19", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:b5ce58", "ysrc": "fiz_01:9:96978a", "xaxis": "x20", "yaxis": "y20", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:bd0d83", "ysrc": "fiz_01:9:52989f", "xaxis": "x21", "yaxis": "y21", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_width", "type": "histogram", "xsrc": "fiz_01:9:61fac5", "xaxis": "x22", "yaxis": "y22", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(128, 0, 128, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:e05a21", "ysrc": "fiz_01:9:bcf7d9", "xaxis": "x23", "yaxis": "y23", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:9:39830d", "ysrc": "fiz_01:9:f0c6d3", "xaxis": "x24", "yaxis": "y24", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:9:866a13", "ysrc": "fiz_01:9:6d6056", "xaxis": "x25", "yaxis": "y25", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:9:c70d61", "ysrc": "fiz_01:9:e781b9", "xaxis": "x26", "yaxis": "y26", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:9:fff33d", "ysrc": "fiz_01:9:4ced94", "xaxis": "x27", "yaxis": "y27", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:9:e82b91", "ysrc": "fiz_01:9:692e76", "xaxis": "x28", "yaxis": "y28", "marker": { "size": 2, "symbol": "circle" } }, { "name": "species", "type": "histogram", "xsrc": "fiz_01:9:a98849", "xaxis": "x29", "yaxis": "y29", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(219, 64, 82, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:9:b3f4ff", "ysrc": "fiz_01:9:05917f", "xaxis": "x30", "yaxis": "y30", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:9:715a11", "ysrc": "fiz_01:9:2714cc", "xaxis": "x31", "yaxis": "y31", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:9:eb6460", "ysrc": "fiz_01:9:b61085", "xaxis": "x32", "yaxis": "y32", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:9:6c7974", "ysrc": "fiz_01:9:fe3f22", "xaxis": "x33", "yaxis": "y33", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:9:7ce54a", "ysrc": "fiz_01:9:68c2d5", "xaxis": "x34", "yaxis": "y34", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:9:e3a431", "ysrc": "fiz_01:9:98cee5", "xaxis": "x35", "yaxis": "y35", "marker": { "size": 2, "symbol": "circle" } }, { "name": "species_id", "type": "histogram", "xsrc": "fiz_01:9:ee5ee5", "xaxis": "x36", "yaxis": "y36", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(0, 128, 128, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "bargap": 0.02, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "xaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y2", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y3", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y4", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y5", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y6", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y7", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y8", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y9", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x2", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x3", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x4", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x5", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x6", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x7", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x8", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x9", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y10", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y11", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y12", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y13", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y14", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y15", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y16", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y17", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y18", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y19", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y20", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y21", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y22", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y23", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y24", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y25", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis26": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y26", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis27": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y27", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis28": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y28", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis29": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y29", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis30": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y30", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis31": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y31", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis32": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y32", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis33": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y33", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis34": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y34", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis35": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y35", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis36": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y36", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x10", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x11", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x12", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x13", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x14", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x15", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x16", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x17", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x18", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x19", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x20", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x21", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x22", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x23", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x24", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x25", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis26": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x26", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis27": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x27", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis28": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x28", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis29": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x29", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis30": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x30", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis31": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x31", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis32": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x32", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis33": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x33", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis34": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x34", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis35": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x35", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis36": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x36", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "showlegend": false, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fiz_01", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/39.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "Mostafiz", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 11:53:22", "mapbox_access_tokens": null, "has_password": null, "username": "fiz_01", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T12:14:17.695327Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fiz_01/8.embed", "fid": "fiz_01:8", "filename": "Plotly Playground 2025-06-24 18:14:13", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/fiz_01:8/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/fiz_01:8/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/8/8_Q23M5MMM0JR6GSMIH6TUVRJ4CA3DTC.png", "list-thumb": "https://api.plotly.com/v2/files/fiz_01:8/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fiz_01:8", "plots": "https://api.plotly.com/v2/plots/fiz_01:8", "parent": "https://api.plotly.com/v2/folders/home?user=fiz_01" }, "owner": "fiz_01", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~fiz_01/8/", "world_readable": true, "date_modified": "2025-06-24T12:14:17.707Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fiz_01/8/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "survived", "text": "", "type": "bar", "xsrc": "fiz_01:7:eadde1", "ysrc": "fiz_01:7:7077c8", "marker": { "line": { "color": "rgba(255, 153, 51, 1.0)", "width": 1 }, "color": "rgba(255, 153, 51, 0.6)" }, "orientation": "v" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "showgrid": true, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fiz_01", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/39.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "Mostafiz", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 11:53:22", "mapbox_access_tokens": null, "has_password": null, "username": "fiz_01", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T12:14:12.600791Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fiz_01/6.embed", "fid": "fiz_01:6", "filename": "Plotly Playground 2025-06-24 18:14:07", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/fiz_01:6/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/fiz_01:6/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/6/8_9P5GCUJ36F4WPPYLNQQHQDG7KF4XNY.png", "list-thumb": "https://api.plotly.com/v2/files/fiz_01:6/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fiz_01:6", "plots": "https://api.plotly.com/v2/plots/fiz_01:6", "parent": "https://api.plotly.com/v2/folders/home?user=fiz_01" }, "owner": "fiz_01", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~fiz_01/6/", "world_readable": true, "date_modified": "2025-06-24T12:14:12.612Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fiz_01/6/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "sepal_length", "type": "histogram", "xsrc": "fiz_01:5:542a8b", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(255, 153, 51, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:ec760c", "ysrc": "fiz_01:5:361d9a", "xaxis": "x2", "yaxis": "y2", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:06e266", "ysrc": "fiz_01:5:ab4796", "xaxis": "x3", "yaxis": "y3", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:b2b5ce", "ysrc": "fiz_01:5:520e77", "xaxis": "x4", "yaxis": "y4", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:6e8d9e", "ysrc": "fiz_01:5:f40a53", "xaxis": "x5", "yaxis": "y5", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:b1422c", "ysrc": "fiz_01:5:a998c8", "xaxis": "x6", "yaxis": "y6", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:5ca9a5", "ysrc": "fiz_01:5:4138aa", "xaxis": "x7", "yaxis": "y7", "marker": { "size": 2, "symbol": "circle" } }, { "name": "sepal_width", "type": "histogram", "xsrc": "fiz_01:5:fe09ad", "xaxis": "x8", "yaxis": "y8", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(55, 128, 191, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:64e220", "ysrc": "fiz_01:5:898135", "xaxis": "x9", "yaxis": "y9", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:0679f3", "ysrc": "fiz_01:5:2c97d0", "xaxis": "x10", "yaxis": "y10", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:521aea", "ysrc": "fiz_01:5:6ba81e", "xaxis": "x11", "yaxis": "y11", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:58e480", "ysrc": "fiz_01:5:c19dd8", "xaxis": "x12", "yaxis": "y12", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:a235d8", "ysrc": "fiz_01:5:2e7ea3", "xaxis": "x13", "yaxis": "y13", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:43f6e8", "ysrc": "fiz_01:5:55c209", "xaxis": "x14", "yaxis": "y14", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_length", "type": "histogram", "xsrc": "fiz_01:5:926bb2", "xaxis": "x15", "yaxis": "y15", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(50, 171, 96, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:7cb5bb", "ysrc": "fiz_01:5:2b6720", "xaxis": "x16", "yaxis": "y16", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:b8605d", "ysrc": "fiz_01:5:7681cd", "xaxis": "x17", "yaxis": "y17", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:5:84b87b", "ysrc": "fiz_01:5:27c115", "xaxis": "x18", "yaxis": "y18", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:2dd422", "ysrc": "fiz_01:5:eac92b", "xaxis": "x19", "yaxis": "y19", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:c73e04", "ysrc": "fiz_01:5:83c033", "xaxis": "x20", "yaxis": "y20", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:faa31d", "ysrc": "fiz_01:5:4459c0", "xaxis": "x21", "yaxis": "y21", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_width", "type": "histogram", "xsrc": "fiz_01:5:8bb172", "xaxis": "x22", "yaxis": "y22", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(128, 0, 128, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:916698", "ysrc": "fiz_01:5:c54955", "xaxis": "x23", "yaxis": "y23", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:5:c6fe3c", "ysrc": "fiz_01:5:cfc735", "xaxis": "x24", "yaxis": "y24", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:5:445831", "ysrc": "fiz_01:5:505b7c", "xaxis": "x25", "yaxis": "y25", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:5:c10dc4", "ysrc": "fiz_01:5:7143ba", "xaxis": "x26", "yaxis": "y26", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:5:23fb8e", "ysrc": "fiz_01:5:79a51b", "xaxis": "x27", "yaxis": "y27", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:5:db0c61", "ysrc": "fiz_01:5:f68269", "xaxis": "x28", "yaxis": "y28", "marker": { "size": 2, "symbol": "circle" } }, { "name": "species", "type": "histogram", "xsrc": "fiz_01:5:23aa30", "xaxis": "x29", "yaxis": "y29", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(219, 64, 82, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:5:4e0a7b", "ysrc": "fiz_01:5:7ffb58", "xaxis": "x30", "yaxis": "y30", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:5:6712e5", "ysrc": "fiz_01:5:bb68b5", "xaxis": "x31", "yaxis": "y31", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:5:20a6c7", "ysrc": "fiz_01:5:512726", "xaxis": "x32", "yaxis": "y32", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:5:45559e", "ysrc": "fiz_01:5:c7c82c", "xaxis": "x33", "yaxis": "y33", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:5:a98755", "ysrc": "fiz_01:5:2ca9a3", "xaxis": "x34", "yaxis": "y34", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species_id", "text": "", "type": "scatter", "xsrc": "fiz_01:5:08be5c", "ysrc": "fiz_01:5:d0fa1c", "xaxis": "x35", "yaxis": "y35", "marker": { "size": 2, "symbol": "circle" } }, { "name": "species_id", "type": "histogram", "xsrc": "fiz_01:5:bc961c", "xaxis": "x36", "yaxis": "y36", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(0, 128, 128, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "bargap": 0.02, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "xaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y2", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y3", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y4", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y5", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y6", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y7", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y8", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y9", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x2", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x3", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x4", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x5", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x6", "domain": [ 0.8916666666666666, 0.9999999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x7", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x8", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x9", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y10", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y11", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y12", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y13", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y14", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y15", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y16", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y17", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y18", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y19", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y20", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y21", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y22", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y23", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y24", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y25", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis26": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y26", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis27": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y27", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis28": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y28", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis29": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y29", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis30": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y30", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis31": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y31", "domain": [ 0.0, 0.125 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis32": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y32", "domain": [ 0.175, 0.3 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis33": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y33", "domain": [ 0.35, 0.475 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis34": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y34", "domain": [ 0.525, 0.65 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis35": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y35", "domain": [ 0.7, 0.825 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis36": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y36", "domain": [ 0.875, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x10", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x11", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x12", "domain": [ 0.7133333333333334, 0.8216666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x13", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x14", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x15", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x16", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x17", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x18", "domain": [ 0.5349999999999999, 0.6433333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x19", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x20", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x21", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x22", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x23", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x24", "domain": [ 0.3566666666666667, 0.465 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x25", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis26": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x26", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis27": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x27", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis28": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x28", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis29": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x29", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis30": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x30", "domain": [ 0.17833333333333334, 0.2866666666666667 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis31": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x31", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis32": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x32", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis33": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x33", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis34": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x34", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis35": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x35", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis36": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x36", "domain": [ 0.0, 0.10833333333333332 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "showlegend": false, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fiz_01", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/39.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "Mostafiz", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 11:53:22", "mapbox_access_tokens": null, "has_password": null, "username": "fiz_01", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T12:12:44.790763Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fiz_01/4.embed", "fid": "fiz_01:4", "filename": "iris_plot", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/fiz_01/4/9_R4OLVK0IWK8O6JBR1OEWNO9VXGCAFG.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/fiz_01/4/2_CAIQL037OIO56FNAO2IH4Y878UN5GG.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/4/8_PEW0CNRAM6002NJ9G7VPKI3NSQMZ44.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/4/9_R4OLVK0IWK8O6JBR1OEWNO9VXGCAFG.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fiz_01:4", "plots": "https://api.plotly.com/v2/plots/fiz_01:4", "parent": "https://api.plotly.com/v2/folders/home?user=fiz_01" }, "owner": "fiz_01", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~fiz_01/4/", "world_readable": true, "date_modified": "2025-06-24T12:12:44.800Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fiz_01/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "name": "setosa", "type": "scatter", "xsrc": "fiz_01:3:b4062f", "ysrc": "fiz_01:3:90486a", "xaxis": "x", "yaxis": "y", "marker": { "color": "#636efa", "symbol": "circle" }, "showlegend": true, "legendgroup": "setosa", "orientation": "v", "hovertemplate": "species=setosa<br>sepal_width=%{x}<br>sepal_length=%{y}<extra></extra>" }, { "mode": "markers", "name": "versicolor", "type": "scatter", "xsrc": "fiz_01:3:d4781f", "ysrc": "fiz_01:3:8dbc82", "xaxis": "x", "yaxis": "y", "marker": { "color": "#EF553B", "symbol": "circle" }, "showlegend": true, "legendgroup": "versicolor", "orientation": "v", "hovertemplate": "species=versicolor<br>sepal_width=%{x}<br>sepal_length=%{y}<extra></extra>" }, { "mode": "markers", "name": "virginica", "type": "scatter", "xsrc": "fiz_01:3:1399dc", "ysrc": "fiz_01:3:7705bb", "xaxis": "x", "yaxis": "y", "marker": { "color": "#00cc96", "symbol": "circle" }, "showlegend": true, "legendgroup": "virginica", "orientation": "v", "hovertemplate": "species=virginica<br>sepal_width=%{x}<br>sepal_length=%{y}<extra></extra>" } ], "layout": { "xaxis": { "title": { "text": "sepal_width" }, "anchor": "y", "domain": [ 0.0, 1.0 ] }, "yaxis": { "title": { "text": "sepal_length" }, "anchor": "x", "domain": [ 0.0, 1.0 ] }, "legend": { "title": { "text": "species" }, "tracegroupgap": 0 }, "margin": { "t": 60 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fiz_01", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/39.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "Mostafiz", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 11:53:22", "mapbox_access_tokens": null, "has_password": null, "username": "fiz_01", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T12:11:13.673430Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~fiz_01/2.embed", "fid": "fiz_01:2", "filename": "Plotly Playground 2025-06-24 18:11:09", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/fiz_01/2/9_PMLBNHXWE4KIRYLCFXZ6SGBB3LOCOP.png", "image_urls": { "default": "https://api.plotly.com/v2/files/fiz_01:2/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/2/8_REWGBG6IS4K3BBYZ8U40IW9255ZV67.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/fiz_01/2/9_PMLBNHXWE4KIRYLCFXZ6SGBB3LOCOP.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/fiz_01:2", "plots": "https://api.plotly.com/v2/plots/fiz_01:2", "parent": "https://api.plotly.com/v2/folders/home?user=fiz_01" }, "owner": "fiz_01", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~fiz_01/2/", "world_readable": true, "date_modified": "2025-06-24T12:11:13.684Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~fiz_01/2/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "sepal_length", "type": "histogram", "xsrc": "fiz_01:1:b90727", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(255, 153, 51, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:26eadb", "ysrc": "fiz_01:1:05f19c", "xaxis": "x2", "yaxis": "y2", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:7b03e9", "ysrc": "fiz_01:1:302c1e", "xaxis": "x3", "yaxis": "y3", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:b2a186", "ysrc": "fiz_01:1:565203", "xaxis": "x4", "yaxis": "y4", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:767cb3", "ysrc": "fiz_01:1:4c70eb", "xaxis": "x5", "yaxis": "y5", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:3af0e6", "ysrc": "fiz_01:1:68b43f", "xaxis": "x6", "yaxis": "y6", "marker": { "size": 2, "symbol": "circle" } }, { "name": "sepal_width", "type": "histogram", "xsrc": "fiz_01:1:a7d3da", "xaxis": "x7", "yaxis": "y7", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(55, 128, 191, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:590cb4", "ysrc": "fiz_01:1:f2edf2", "xaxis": "x8", "yaxis": "y8", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:716b8d", "ysrc": "fiz_01:1:b49bf0", "xaxis": "x9", "yaxis": "y9", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "sepal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:224b66", "ysrc": "fiz_01:1:f87d28", "xaxis": "x10", "yaxis": "y10", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:2b215a", "ysrc": "fiz_01:1:75bed8", "xaxis": "x11", "yaxis": "y11", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:f183c5", "ysrc": "fiz_01:1:e7a022", "xaxis": "x12", "yaxis": "y12", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_length", "type": "histogram", "xsrc": "fiz_01:1:12c41b", "xaxis": "x13", "yaxis": "y13", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(50, 171, 96, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:a70a00", "ysrc": "fiz_01:1:cc4a1c", "xaxis": "x14", "yaxis": "y14", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_length", "text": "", "type": "scatter", "xsrc": "fiz_01:1:772432", "ysrc": "fiz_01:1:a0c1b9", "xaxis": "x15", "yaxis": "y15", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:63b4dd", "ysrc": "fiz_01:1:db253f", "xaxis": "x16", "yaxis": "y16", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:6c102b", "ysrc": "fiz_01:1:b73db7", "xaxis": "x17", "yaxis": "y17", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:0587eb", "ysrc": "fiz_01:1:e65ed7", "xaxis": "x18", "yaxis": "y18", "marker": { "size": 2, "symbol": "circle" } }, { "name": "petal_width", "type": "histogram", "xsrc": "fiz_01:1:604660", "xaxis": "x19", "yaxis": "y19", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(128, 0, 128, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "petal_width", "text": "", "type": "scatter", "xsrc": "fiz_01:1:12f6fc", "ysrc": "fiz_01:1:6f00fb", "xaxis": "x20", "yaxis": "y20", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:1:217805", "ysrc": "fiz_01:1:5cc951", "xaxis": "x21", "yaxis": "y21", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:1:dd036c", "ysrc": "fiz_01:1:1cadb1", "xaxis": "x22", "yaxis": "y22", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:1:d76b32", "ysrc": "fiz_01:1:6dff3c", "xaxis": "x23", "yaxis": "y23", "marker": { "size": 2, "symbol": "circle" } }, { "line": { "dash": "solid", "color": "rgba(128, 128, 128, 1.0)", "shape": "linear", "width": 1.3 }, "mode": "markers", "name": "species", "text": "", "type": "scatter", "xsrc": "fiz_01:1:907168", "ysrc": "fiz_01:1:719d71", "xaxis": "x24", "yaxis": "y24", "marker": { "size": 2, "symbol": "circle" } }, { "name": "species", "type": "histogram", "xsrc": "fiz_01:1:5d3247", "xaxis": "x25", "yaxis": "y25", "marker": { "line": { "color": "#4D5663", "width": 1.3 }, "color": "rgba(219, 64, 82, 1.0)" }, "nbinsx": 10, "opacity": 0.8, "histfunc": "count", "histnorm": "", "orientation": "v" } ], "layout": { "title": { "font": { "color": "#4D5663" } }, "xaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y", "domain": [ 0.0, 0.16 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x", "domain": [ 0.856, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "bargap": 0.02, "legend": { "font": { "color": "#4D5663" }, "bgcolor": "#F5F6F9" }, "xaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y2", "domain": [ 0.21000000000000002, 0.37 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y3", "domain": [ 0.42000000000000004, 0.5800000000000001 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y4", "domain": [ 0.63, 0.79 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y5", "domain": [ 0.8400000000000001, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y6", "domain": [ 0.0, 0.16 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y7", "domain": [ 0.21000000000000002, 0.37 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y8", "domain": [ 0.42000000000000004, 0.5800000000000001 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y9", "domain": [ 0.63, 0.79 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis2": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x2", "domain": [ 0.856, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis3": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x3", "domain": [ 0.856, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis4": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x4", "domain": [ 0.856, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis5": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x5", "domain": [ 0.856, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis6": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x6", "domain": [ 0.6419999999999999, 0.7859999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis7": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x7", "domain": [ 0.6419999999999999, 0.7859999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis8": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x8", "domain": [ 0.6419999999999999, 0.7859999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis9": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x9", "domain": [ 0.6419999999999999, 0.7859999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y10", "domain": [ 0.8400000000000001, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y11", "domain": [ 0.0, 0.16 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y12", "domain": [ 0.21000000000000002, 0.37 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y13", "domain": [ 0.42000000000000004, 0.5800000000000001 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y14", "domain": [ 0.63, 0.79 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y15", "domain": [ 0.8400000000000001, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y16", "domain": [ 0.0, 0.16 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y17", "domain": [ 0.21000000000000002, 0.37 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y18", "domain": [ 0.42000000000000004, 0.5800000000000001 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y19", "domain": [ 0.63, 0.79 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y20", "domain": [ 0.8400000000000001, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y21", "domain": [ 0.0, 0.16 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y22", "domain": [ 0.21000000000000002, 0.37 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y23", "domain": [ 0.42000000000000004, 0.5800000000000001 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y24", "domain": [ 0.63, 0.79 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "xaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "y25", "domain": [ 0.8400000000000001, 1.0 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis10": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x10", "domain": [ 0.6419999999999999, 0.7859999999999999 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis11": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x11", "domain": [ 0.428, 0.572 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis12": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x12", "domain": [ 0.428, 0.572 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis13": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x13", "domain": [ 0.428, 0.572 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis14": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x14", "domain": [ 0.428, 0.572 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis15": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x15", "domain": [ 0.428, 0.572 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis16": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x16", "domain": [ 0.214, 0.358 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis17": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x17", "domain": [ 0.214, 0.358 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis18": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x18", "domain": [ 0.214, 0.358 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis19": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x19", "domain": [ 0.214, 0.358 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis20": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x20", "domain": [ 0.214, 0.358 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis21": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x21", "domain": [ 0.0, 0.144 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis22": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x22", "domain": [ 0.0, 0.144 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis23": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x23", "domain": [ 0.0, 0.144 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis24": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x24", "domain": [ 0.0, 0.144 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "yaxis25": { "title": { "font": { "color": "#4D5663" }, "text": "" }, "anchor": "x25", "domain": [ 0.0, 0.144 ], "showgrid": false, "tickfont": { "color": "#4D5663" }, "gridcolor": "#E1E5ED", "zerolinecolor": "#E1E5ED" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "showlegend": false, "plot_bgcolor": "#F5F6F9", "paper_bgcolor": "#F5F6F9" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~fiz_01", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/39.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "Mostafiz", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 11:53:22", "mapbox_access_tokens": null, "has_password": null, "username": "fiz_01", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T11:23:37.524325Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pradeep03/31.embed", "fid": "pradeep03:31", "filename": "chart-c2a1fc03-73cf-420f-8d97-78a48e0ce69d", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pradeep03:31/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pradeep03:31/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/pradeep03/31/8_DP9Z4CIXJXGJ8ULN405OHBXR9ZMA4R.png", "list-thumb": "https://api.plotly.com/v2/files/pradeep03:31/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pradeep03:31", "plots": "https://api.plotly.com/v2/plots/pradeep03:31", "parent": "https://api.plotly.com/v2/folders/home?user=pradeep03" }, "owner": "pradeep03", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~pradeep03/31/", "world_readable": true, "date_modified": "2025-06-24T11:23:37.534Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pradeep03/31/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "blue", "width": 2 }, "mode": "lines+markers", "name": "Gross Margin %", "type": "scatter", "xsrc": "pradeep03:30:1c30a5", "ysrc": "pradeep03:30:ae8815", "marker": { "line": { "color": "black", "width": 1 }, "color": "blue" } }, { "line": { "color": "green", "width": 2 }, "mode": "lines+markers", "name": "Net Margin %", "type": "scatter", "xsrc": "pradeep03:30:3dc76a", "ysrc": "pradeep03:30:726e71", "marker": { "line": { "color": "black", "width": 1 }, "color": "green" } } ], "layout": { "title": { "text": "Gross Margin and Net Margin as % of Revenue" }, "xaxis": { "title": { "text": "Month" } }, "yaxis": { "title": { "text": "Margin (%)" } }, "legend": { "x": 0, "y": -0.2, "orientation": "h" }, "margin": { "b": 60, "l": 40, "r": 40, "t": 60 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pradeep03", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 05:37:05", "mapbox_access_tokens": null, "has_password": null, "username": "pradeep03", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T11:21:36.735870Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pradeep03/29.embed", "fid": "pradeep03:29", "filename": "chart-adc147ad-279e-49a5-8b1d-6729158cb106", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pradeep03:29/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pradeep03:29/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/pradeep03/29/8_NQ49SX5D7FZQBU7W0YBXXJ0O6GRR43.png", "list-thumb": "https://api.plotly.com/v2/files/pradeep03:29/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pradeep03:29", "plots": "https://api.plotly.com/v2/plots/pradeep03:29", "parent": "https://api.plotly.com/v2/folders/home?user=pradeep03" }, "owner": "pradeep03", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~pradeep03/29/", "world_readable": true, "date_modified": "2025-06-24T11:21:36.749Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pradeep03/29/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "Net Profit (₹ Cr)", "type": "bar", "xsrc": "pradeep03:28:258002", "ysrc": "pradeep03:28:6dba81", "marker": { "colorsrc": "pradeep03:28:2cd82b" } } ], "layout": { "title": { "text": "Net Profit Comparison: July & August vs Most Profitable Month" }, "xaxis": { "title": { "text": "Month" } }, "yaxis": { "title": { "text": "Net Profit (₹ Cr)" } }, "legend": { "x": 0, "y": -0.2, "orientation": "h" }, "margin": { "b": 60, "l": 40, "r": 40, "t": 60 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pradeep03", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 05:37:05", "mapbox_access_tokens": null, "has_password": null, "username": "pradeep03", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T11:18:35.871296Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mconway/66.embed", "fid": "mconway:66", "filename": "Plot 66", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mconway:66/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/mconway:66/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/mconway:66/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/mconway:66/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mconway:66", "plots": "https://api.plotly.com/v2/plots/mconway:66", "parent": "https://api.plotly.com/v2/folders/home?user=mconway" }, "owner": "mconway", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~mconway/66/", "world_readable": true, "date_modified": "2025-06-25T10:07:58.306Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mconway/66/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(34, 116, 213)" }, "meta": { "columnNames": { "x": "Date_Stamp", "y": "Budget" } }, "mode": "markers+lines", "name": "Budget", "type": "scatter", "xsrc": "mconway:65:ff145b", "ysrc": "mconway:65:58e23c", "marker": { "color": "rgb(34, 99, 213)" }, "opacity": 1, "visible": true, "showlegend": true, "orientation": "v" }, { "meta": { "columnNames": { "x": "Date_Stamp", "y": "Estimated Spend" } }, "mode": "lines", "name": "Estimated Spend", "type": "bar", "xsrc": "mconway:65:ff145b", "ysrc": "mconway:65:06c7df", "xaxis": "x2", "yaxis": "y", "marker": { "line": { "width": 0 }, "color": "rgb(223, 129, 38)", "opacity": 1 }, "error_x": { "type": "percent", "color": "#444", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "opacity": 1, "visible": true, "hoverinfo": "x+y+name", "hoverlabel": { "namelength": 15 }, "showlegend": true, "stackgroup": 1, "legendgroup": "", "orientation": "v", "hovertemplate": "" }, { "meta": { "columnNames": { "x": "Date_Stamp", "y": "Billed-OpEx" } }, "name": "Billed-OpEx", "type": "bar", "xsrc": "mconway:65:ff145b", "ysrc": "mconway:65:3bfef5", "marker": { "color": "rgb(6, 225, 57)" }, "hoverinfo": "x+y+name", "showlegend": true, "legendgroup": "", "orientation": "v" }, { "meta": { "columnNames": { "x": "Date_Stamp", "y": "Billed-CapEx" } }, "name": "Billed-CapEx", "type": "bar", "xsrc": "mconway:65:ff145b", "ysrc": "mconway:65:ba6937", "xaxis": "x", "marker": { "color": "rgb(255, 255, 0)" }, "orientation": "v" } ], "frames": [], "layout": { "font": { "size": 12, "family": "Roboto" }, "title": { "font": { "size": 15 }, "text": "<br>" }, "xaxis": { "type": "date", "range": [ "2025-01-14 01:11:17.5684", "2025-12-18 22:48:42.4316" ], "title": { "text": "<br>" }, "autorange": true, "fixedrange": true, "rangeslider": { "range": [ "2025-01-01", "2025-12-31" ], "yaxis": {}, "bgcolor": "rgb(236, 238, 235)", "visible": false, "autorange": true, "thickness": 0.1, "bordercolor": "rgb(222, 222, 222)", "borderwidth": 1 }, "rangeselector": { "visible": true } }, "yaxis": { "side": "left", "type": "linear", "range": [ 0, 2000000 ], "ticks": "", "title": { "text": "€" }, "mirror": false, "nticks": 15, "showgrid": true, "showline": false, "tickmode": "auto", "zeroline": true, "autorange": false, "gridcolor": "rgb(222, 222, 222)", "gridwidth": 1, "automargin": true, "showspikes": true, "rangeselector": { "visible": true }, "zerolinecolor": "rgb(222, 222, 222)", "zerolinewidth": 2, "showticklabels": true, "separatethousands": false }, "bargap": 0.19999999999999996, "margin": { "b": 40, "l": 0, "r": 0, "t": 40, "pad": 0 }, "xaxis2": { "side": "bottom", "type": "date", "range": [ "2025-01-18", "2025-12-15" ], "title": { "text": "<br>" }, "autorange": true, "fixedrange": false, "overlaying": "x", "showspikes": true, "rangeselector": { "visible": true }, "showticklabels": false }, "barmode": "relative", "barnorm": "", "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hoverlabel": { "font": { "size": 10, "family": "Roboto" } }, "bargroupgap": 0.7, "uniformtext": { "mode": false }, "plot_bgcolor": "rgb(244, 245, 245)", "paper_bgcolor": "rgb(244, 245, 245)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mconway", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-0.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2020-12-11 11:21:42", "mapbox_access_tokens": null, "has_password": null, "username": "mconway", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T11:16:37.407174Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~pradeep03/27.embed", "fid": "pradeep03:27", "filename": "chart-0d1d0bae-e1c1-4155-87f3-fd5834d42aa1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/pradeep03:27/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/pradeep03:27/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/pradeep03/27/8_WYIFYA5OYSL338WXSR8GPY98LNDV1H.png", "list-thumb": "https://api.plotly.com/v2/files/pradeep03:27/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/pradeep03:27", "plots": "https://api.plotly.com/v2/plots/pradeep03:27", "parent": "https://api.plotly.com/v2/folders/home?user=pradeep03" }, "owner": "pradeep03", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~pradeep03/27/", "world_readable": true, "date_modified": "2025-06-24T11:16:37.416Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~pradeep03/27/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "green", "width": 2 }, "mode": "lines+markers", "name": "Net Profit Margin (%)", "type": "scatter", "xsrc": "pradeep03:26:ccbb69", "ysrc": "pradeep03:26:0e87fd", "marker": { "line": { "color": "black", "width": 1 }, "color": "blue" } }, { "line": { "color": "red", "width": 2 }, "mode": "lines+markers", "name": "Total Revenue (₹ Cr)", "type": "scatter", "xsrc": "pradeep03:26:1fdf65", "ysrc": "pradeep03:26:e65f76", "yaxis": "y2", "marker": { "line": { "color": "black", "width": 1 }, "color": "orange" } } ], "layout": { "title": { "text": "Revenue vs. Net Profit Margin (%)" }, "xaxis": { "title": { "text": "Month" } }, "yaxis": { "title": { "text": "Net Profit Margin (%)" } }, "legend": { "x": 0, "y": -0.2, "orientation": "h" }, "margin": { "b": 60, "l": 40, "r": 40, "t": 60 }, "yaxis2": { "side": "right", "title": { "text": "Total Revenue (₹ Cr)" }, "overlaying": "y" }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~pradeep03", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-24 05:37:05", "mapbox_access_tokens": null, "has_password": null, "username": "pradeep03", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-24T11:16:24.367429Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~ThadLee/190.embed", "fid": "ThadLee:190", "filename": "GA4 Tauc 0.5", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/ThadLee/190/9_EWKW78VR9RWPBARE3NTN60G4AEKGCE.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/ThadLee/190/2_AUDWXR11IKDCYO34WGTHTRVHACCQG0.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/ThadLee/190/8_C8HPIFHUDJKNZB5JODCAN268YNGCCP.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/ThadLee/190/9_EWKW78VR9RWPBARE3NTN60G4AEKGCE.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/ThadLee:190", "plots": "https://api.plotly.com/v2/plots/ThadLee:190", "parent": "https://api.plotly.com/v2/folders/home?user=ThadLee" }, "owner": "ThadLee", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~ThadLee/190/", "world_readable": true, "date_modified": "2025-06-24T11:22:41.881Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~ThadLee/190/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "uid": "62bf0c", "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "scatter", "xsrc": "ThadLee:189:26970c", "ysrc": "ThadLee:189:21604c" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 1.377778, 5 ], "autorange": false }, "yaxis": { "type": "linear", "range": [ 12.776933888888887, 411.8280561111111 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~ThadLee", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/14.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2023-08-26 05:56:46", "mapbox_access_tokens": null, "has_password": null, "username": "ThadLee", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
