Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cD0yMDI1LTA2LTE5KzIxJTNBMTYlM0ExNC4yMDM2NzklMkIwMCUzQTAw&format=api
{ "next": "https://api.plot.ly/v2/plots/?cursor=cD0yMDI1LTA2LTE5KzIwJTNBMjYlM0E0My4zMjc2MjklMkIwMCUzQTAw&format=api", "previous": "https://api.plot.ly/v2/plots/?cursor=cj0xJnA9MjAyNS0wNi0xOSsyMCUzQTUyJTNBMDAuMTIzNjI4JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-06-19T20:52:00.123628Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Anto_violetap/32.embed", "fid": "Anto_violetap:32", "filename": "MDS TF (1)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/32/9_1BB3HXMN51UCQHFEHC75ECH2R9UFE4.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/32/2_1Y1PLF7AREC5DRRWHGVRZJGE3TO2IV.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/32/8_0DXD3XA2JZ76R1VS3LZ3X2MYSFLWE9.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/32/9_1BB3HXMN51UCQHFEHC75ECH2R9UFE4.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Anto_violetap:32", "plots": "https://api.plotly.com/v2/plots/Anto_violetap:32", "parent": "https://api.plotly.com/v2/folders/home?user=Anto_violetap" }, "owner": "Anto_violetap", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Anto_violetap/32/", "world_readable": true, "date_modified": "2025-07-21T17:46:14.025Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Anto_violetap/32/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "MDS1", "y": "MDS2" } }, "mode": "markers", "type": "scatter", "xsrc": "Anto_violetap:31:6ea842", "ysrc": "Anto_violetap:31:b1fd9a", "transforms": [ { "meta": { "columnNames": { "groups": "nombre" } }, "type": "groupby", "styles": [ { "value": { "name": "Salmón de cultivo", "marker": { "line": { "width": 1 }, "size": 6, "symbol": "square" } }, "target": "salmon de cultivo" }, { "value": { "name": "Salmón chinook", "marker": { "line": { "width": 1 }, "symbol": "diamond" } }, "target": "Salmon chinook" }, { "value": { "name": "Bacalao", "marker": { "line": { "width": 1 }, "symbol": "cross" } }, "target": "bacalao" }, { "value": { "name": "Pejerrey", "marker": { "line": { "width": 1 }, "symbol": "x" } }, "target": "pejerrey" }, { "value": { "name": "Pulpo", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "triangle-up" } }, "target": "pulpo" }, { "value": { "name": "Róbalo", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "triangle-down" } }, "target": "robalo" }, { "value": { "name": "Merluza Austral", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "pentagon" } }, "target": "merluza austral" }, { "value": { "name": "Congrio", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "star" } }, "target": "congrio" }, { "value": { "name": "Nototénida Patagónica", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "star-triangle-up" } }, "target": "nototenia patagonica" }, { "value": { "name": "Cabrilla", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "star-triangle-down" } }, "target": "cabrilla" }, { "value": { "name": "Centolla", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "line-ns-open" } }, "target": "centolla" }, { "value": { "marker": { "line": { "width": 1 }, "size": 7, "color": "rgb(5, 152, 149)", "symbol": "diamond-tall" } }, "target": "Munida" }, { "value": { "marker": { "line": { "width": 2 }, "size": 7, "color": "rgb(89, 157, 89)", "symbol": "asterisk-open" } }, "target": "Jaiba" }, { "value": { "marker": { "line": { "width": 1 }, "color": "rgb(255, 0, 33)", "symbol": "star-diamond-open" } }, "target": "Calamar" }, { "value": { "name": "Pingüino Magallánico", "marker": { "line": { "width": 1 }, "size": 7, "color": "rgb(61, 243, 25)", "symbol": "diamond-wide" } }, "target": "pinguino magallanico" }, { "value": { "name": "Foca leopardo", "marker": { "size": 7, "color": "rgb(7, 7, 7)", "symbol": "hourglass" } }, "target": "foca leopardo" } ], "groupssrc": "Anto_violetap:31:d5a8a1" } ] } ], "frames": [], "layout": { "title": { "text": "<b>MDS TF (1)</b>" }, "xaxis": { "type": "linear", "range": [ -40.684189481308536, 23.31504593408873 ], "ticks": "inside", "title": { "text": "MDS 1" }, "mirror": "ticks", "showgrid": false, "showline": true, "zeroline": true, "autorange": true, "linecolor": "rgb(10, 10, 10)", "showticklabels": true }, "yaxis": { "side": "left", "type": "linear", "range": [ -23.3306478149237, 20.854516667667394 ], "ticks": "inside", "title": { "text": "MDS 2" }, "mirror": "ticks", "showgrid": false, "showline": true, "zeroline": true, "autorange": true, "linecolor": "rgb(15, 15, 15)" }, "legend": { "x": 1.0341955835962147, "y": 0.6282722513089005, "title": { "font": { "family": "Arial" }, "text": "<b>Especies</b>" }, "borderwidth": 1 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Anto_violetap", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/42.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-05-14 15:13:56", "mapbox_access_tokens": null, "has_password": null, "username": "Anto_violetap", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:34:55.281631Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Anto_violetap/30.embed", "fid": "Anto_violetap:30", "filename": "MDS SR (LMC)", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/30/9_NLW5X6UKLPT48AM96Q8G33L1MPE6DE.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/30/2_NCW5AUOM5I0EREAG2JZQ7AJWZ9PDGA.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/30/8_ZNHF3U3M5QQTB08JI7P6KWFUWEP3E9.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/Anto_violetap/30/9_NLW5X6UKLPT48AM96Q8G33L1MPE6DE.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Anto_violetap:30", "plots": "https://api.plotly.com/v2/plots/Anto_violetap:30", "parent": "https://api.plotly.com/v2/folders/home?user=Anto_violetap" }, "owner": "Anto_violetap", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Anto_violetap/30/", "world_readable": true, "date_modified": "2025-07-24T13:13:23.074Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Anto_violetap/30/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "MDS1", "y": "MDS2" } }, "mode": "markers", "type": "scatter", "xsrc": "Anto_violetap:29:8bf901", "ysrc": "Anto_violetap:29:4cb96e", "transforms": [ { "meta": { "columnNames": { "groups": "nombre" } }, "type": "groupby", "styles": [ { "value": { "mode": "markers", "name": "Sardina", "marker": { "line": { "width": 1 }, "size": 7, "color": "rgb(71, 10, 127)", "symbol": "circle" } }, "target": "sardina" }, { "value": { "name": "Merluza austral", "marker": { "line": { "width": 1 }, "size": 6, "symbol": "diamond" } }, "target": "merluza austral" }, { "value": { "name": "Merluza de cola", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "diamond-tall" } }, "target": "merluza de cola" }, { "value": { "name": "Jaiba", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "triangle-down" } }, "target": "jaiba" }, { "value": { "name": "Congrio dorado", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "diamond-wide" }, "legendgroup": "" }, "target": "congrio dorado" }, { "value": { "name": "Merluza común", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "star-diamond" } }, "target": "merluza comun" }, { "value": { "name": "Róbalo", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "cross" } }, "target": "robalo" }, { "value": { "name": "Salmón Coho", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "star" } }, "target": "salmon coho" }, { "value": { "name": "Cisne cuello negro", "marker": { "line": { "width": 1 }, "symbol": "star-square" } }, "target": "cisne cuello negro" }, { "value": { "name": "Salmón de cultivo", "marker": { "line": { "width": 1 }, "size": 8 } }, "target": "salmon de cultivo" }, { "value": { "name": "Lobo marino común", "marker": { "line": { "width": 1 }, "size": 7, "symbol": "bowtie" } }, "target": "lobo marino comun" }, { "value": { "name": "Foca leopardo", "marker": { "size": 7, "color": "rgb(32, 32, 32)", "symbol": "hourglass" } }, "target": "foca leopardo" } ], "groupssrc": "Anto_violetap:29:2f240a" } ] } ], "frames": [], "layout": { "font": { "family": "Arial" }, "title": { "font": { "family": "Arial" }, "text": "<b>MDS SR (LMC)</b>" }, "xaxis": { "type": "linear", "range": [ -42.868267102732915, 31.03492470273291 ], "ticks": "inside", "title": { "text": "MDS 1" }, "mirror": "ticks", "showgrid": false, "showline": true, "zeroline": true, "autorange": true, "linecolor": "rgb(0, 0, 0)", "linewidth": 1, "showspikes": false, "showticklabels": true }, "yaxis": { "side": "left", "type": "linear", "range": [ -19.057892102630962, 19.832956832630963 ], "ticks": "inside", "title": { "text": "MDS 2" }, "mirror": "ticks", "showgrid": false, "showline": true, "zeroline": true, "autorange": true, "gridcolor": "rgb(227, 227, 227)", "gridwidth": 0, "linecolor": "rgb(10, 10, 10)", "linewidth": 1, "showspikes": false }, "legend": { "x": 1.02, "y": 1.0252100840336134, "title": { "text": "<b>Especies</b>" }, "xanchor": "left", "yanchor": "top", "borderwidth": 1, "orientation": "v" }, "modebar": { "orientation": "h" }, "autosize": true, "dragmode": "pan", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.08333333333333333, "#1910d8" ], [ 0.16666666666666666, "#3c19f0" ], [ 0.25, "#6b1cfb" ], [ 0.3333333333333333, "#981cfd" ], [ 0.4166666666666667, "#bf1cfd" ], [ 0.5, "#dd2bfd" ], [ 0.5833333333333334, "#f246fe" ], [ 0.6666666666666666, "#fc67fd" ], [ 0.75, "#fe88fc" ], [ 0.8333333333333334, "#fea5fd" ], [ 0.9166666666666666, "#febefe" ], [ 1, "#fec3fe" ] ] }, "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Anto_violetap", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/42.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-05-14 15:13:56", "mapbox_access_tokens": null, "has_password": null, "username": "Anto_violetap", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:30:07.050108Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~isirios/3.embed", "fid": "isirios:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/isirios:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/isirios:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/isirios/3/8_0EIMZ0ED377LWIQ10Q5UCMCUAGJUQ5.png", "list-thumb": "https://api.plotly.com/v2/files/isirios:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/isirios:3", "plots": "https://api.plotly.com/v2/plots/isirios:3", "parent": "https://api.plotly.com/v2/folders/home?user=isirios" }, "owner": "isirios", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~isirios/3/", "world_readable": true, "date_modified": "2025-06-19T20:30:07.063Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~isirios/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid", "color": "#030303", "shape": "linear" }, "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "lines", "name": "Datos tabulados", "type": "scatter", "xsrc": "isirios:1:3e5650", "ysrc": "isirios:1:e49d2e", "visible": true, "connectgaps": false }, { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Esfera grande", "type": "scatter", "xsrc": "isirios:2:8b5d9a", "ysrc": "isirios:2:84f360", "marker": { "color": "#ff280e" } }, { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Esfera pequeña", "type": "scatter", "xsrc": "isirios:0:c8aecc", "ysrc": "isirios:0:23b881", "marker": { "color": "#2c38a0" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Coeficiente de arrastre (Cd) vs Número de Reynolds" }, "xaxis": { "side": "bottom", "type": "log", "dtick": 1, "range": [ -0.999238570560194, 6 ], "title": { "text": "Reynolds" }, "autorange": false }, "yaxis": { "type": "log", "range": [ -1.299332676063295, 2.467104543277995 ], "title": { "text": "Coeficiente de arrastre" }, "autorange": true, "rangemode": "normal" }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~isirios", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/83.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-19 20:28:40", "mapbox_access_tokens": null, "has_password": null, "username": "isirios", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:27:05.554476Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38838.embed", "fid": "cpsievert:38838", "filename": "Plot 38838", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38838/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38838/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38838/8_CT35PEDWMF61TNFJA1QXQADHDWHVTX.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38838/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38838", "plots": "https://api.plotly.com/v2/plots/cpsievert:38838", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38838/", "world_readable": true, "date_modified": "2025-06-19T20:27:05.591Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38838/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "bar", "xsrc": "cpsievert:38837:e7bbcb", "ysrc": "cpsievert:38837:502b34", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "transparent", "width": 1.8897637795275593 }, "color": "rgba(89,89,89,1)", "autocolorscale": false }, "basesrc": "cpsievert:38837:ed7474", "textsrc": "cpsievert:38837:169394", "widthsrc": "cpsievert:38837:09796e", "hoverinfo": "text", "showlegend": false, "orientation": "v", "textposition": "none" } ], "layout": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "xaxis": { "type": "linear", "range": [ 0.055000000000000104, 10.944999999999999 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "1:10" }, "anchor": "y", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "2.5", "5.0", "7.5", "10.0" ], "tickvals": [ 2.5, 5, 7.500000000000001, 10 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "2.5", "5.0", "7.5", "10.0" ], "categoryorder": "array", "showticklabels": true }, "yaxis": { "type": "linear", "range": [ -0.05, 1.05 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "count" }, "anchor": "x", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "tickvals": [ 0, 0.25, 0.5, 0.75, 1 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "categoryorder": "array", "showticklabels": true }, "legend": { "font": { "size": 11.68949771689498, "color": "rgba(0,0,0,1)", "family": "" }, "bgcolor": "rgba(255,255,255,1)", "bordercolor": "transparent", "borderwidth": 0 }, "margin": { "b": 37.26027397260275, "l": 48.94977168949772, "r": 7.305936073059362, "t": 23.305936073059364 }, "shapes": [ { "x0": 0, "x1": 1, "y0": 0, "y1": 1, "line": { "color": null, "width": 0, "linetype": [] }, "type": "rect", "xref": "paper", "yref": "paper", "layer": "below", "fillcolor": null } ], "barmode": "relative", "hovermode": "closest", "showlegend": false, "plot_bgcolor": "rgba(235,235,235,1)", "paper_bgcolor": "rgba(255,255,255,1)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:27:03.578268Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38836.embed", "fid": "cpsievert:38836", "filename": "Plot 38836", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38836/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38836/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38836/8_1LOF5GLTFTF9G69YL97TG1D0T23VAL.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38836/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38836", "plots": "https://api.plotly.com/v2/plots/cpsievert:38836", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38836/", "world_readable": true, "date_modified": "2025-06-19T20:27:03.613Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38836/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38835:33216e", "ysrc": "cpsievert:38835:4b0c6d", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:4eec6f", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:3f0b3b", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38835:f8deb5", "ysrc": "cpsievert:38835:088a15", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38835:d3022f", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "frames": [ { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38835:c17bc2", "ysrc": "cpsievert:38835:fad06f", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:08eb71", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:fbfda5", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "1", "traces": [ 0 ] }, { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38835:c42fe0", "ysrc": "cpsievert:38835:1f5b99", "frame": "2", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:658ecb", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38835:c7af0a", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "2", "traces": [ 0 ] } ], "layout": { "xaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" }, { "args": [ [ "2" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "2", "value": "2", "method": "animate" } ], "visible": true } ], "hovermode": "closest", "showlegend": false, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:27:01.730744Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38834.embed", "fid": "cpsievert:38834", "filename": "Plot 38834", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38834/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38834/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38834/8_E6E1Q61QPLHR01JRMNAE4PQWD9NF6O.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38834/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38834", "plots": "https://api.plotly.com/v2/plots/cpsievert:38834", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38834/", "world_readable": true, "date_modified": "2025-06-19T20:27:01.764Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38834/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38833:33b198", "ysrc": "cpsievert:38833:277504", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38833:c94eaf", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38833:f7f1a4", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] } }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38833:839d76", "ysrc": "cpsievert:38833:3a51db", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38833:1f44e5", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:26:59.856835Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38832.embed", "fid": "cpsievert:38832", "filename": "Plot 38832", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38832/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38832/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38832/8_I607QNX7Q623005THBMZD029SEZEED.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38832/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38832", "plots": "https://api.plotly.com/v2/plots/cpsievert:38832", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38832/", "world_readable": true, "date_modified": "2025-06-19T20:26:59.891Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38832/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38831:85c2cb", "ysrc": "cpsievert:38831:d141e2", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "red" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:26:57.044294Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38830.embed", "fid": "cpsievert:38830", "filename": "b7835e57b73", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38830/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38830/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/cpsievert:38830/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38830/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38830", "plots": "https://api.plotly.com/v2/plots/cpsievert:38830", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38830/", "world_readable": true, "date_modified": "2025-06-19T20:26:58.235Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38830/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "title": "test", "xaxis": { "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:26:49.530262Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38828.embed", "fid": "cpsievert:38828", "filename": "Plot 38828", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38828/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38828/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/cpsievert:38828/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38828/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38828", "plots": "https://api.plotly.com/v2/plots/cpsievert:38828", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38828/", "world_readable": true, "date_modified": "2025-06-19T20:26:49.566Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38828/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38827:61388b", "ysrc": "cpsievert:38827:d949e2", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38827:d8dbba", "ysrc": "cpsievert:38827:f5a536", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38827:5b4a2b", "ysrc": "cpsievert:38827:76a14f", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "frames": [ { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38827:8c42ee", "ysrc": "cpsievert:38827:588d7f", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38827:6d2eaf", "ysrc": "cpsievert:38827:0c14cd", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38827:d3d7b2", "ysrc": "cpsievert:38827:b14e24", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "0", "traces": [ 0, 1, 2 ] }, { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38827:03b437", "ysrc": "cpsievert:38827:8d01a7", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38827:b93aa8", "ysrc": "cpsievert:38827:f33388", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38827:2e8bb0", "ysrc": "cpsievert:38827:b0acf6", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": false, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "1", "traces": [ 0, 1, 2 ] } ], "layout": { "xaxis": { "range": [ 9.225, 35.074999999999996 ], "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 1.3174499999999998, 5.61955 ], "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "0" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "0", "value": "0", "method": "animate" }, { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" } ], "visible": true, "currentvalue": { "font": { "size": 16, "color": "rgba(204,204,204,1)" }, "prefix": "factor(vs): ", "xanchor": "right" } } ], "hovermode": "closest", "showlegend": true, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-19T20:26:43.327629Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38826.embed", "fid": "cpsievert:38826", "filename": "Plot 38826", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38826/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38826/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/cpsievert:38826/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38826/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38826", "plots": "https://api.plotly.com/v2/plots/cpsievert:38826", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38826/", "world_readable": true, "date_modified": "2025-06-19T20:26:43.363Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38826/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38825:3717b9", "ysrc": "cpsievert:38825:7ffdec", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38825:4ae5e1", "ysrc": "cpsievert:38825:1c71cf", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38825:e67a1c", "ysrc": "cpsievert:38825:775d2b", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "textfont": { "color": "rgba(141,160,203,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
